Steinberger Synapse EMGSYN-B-1 User manual

MAT'L:
PART NO.:
PART:
645 MASSMAN DRIVE
STEINBERGER
[phone]
NASHVILLE, TN 37210
LTR REVISION DATEPCA NO.
DATE:SCALE:
DRAWN: CHK:
DIASYNB
N/A
8/19/04
DIASYNB
WIRING DIAGRAM - Steinberger Synapse EMGSYN-B-1 (BASS)
EXCEPT AS EXPRESSLY AUTHORIZED IN WRITING BY GIBSON, INC. MAY NOT BE REPRODUCED OR USED FOR ANY PURPOSE ARE THE CONFIDENTIAL PROPERTY OF GIBSON, INC. AND THIS DRAWING AND ALL OF THE INFORMATION HEREON NOTE:
PCB PIN 11
PCB PIN 10
PCB PIN 12
VR1VR2VR3
OUTPUT VOLUME ADJUSTMENT
TO SET PREAMP FOR PROPER OUTPUT LEVEL TURN TRIM POTS VR1, VR2 AND VR3 TO MAXIMUM VOLUME
OUTPUT VOLUME OF BOTH PIEZO PICKUPS AND MAGNETIC PICKUP SHOULD BE EQUAL. REDUCE VOLUME OF LOUDER PICKUP BY ADJUSTING TRIM POT IF NECESSARY TO BALANCE OUTPUT.
ADJUSTMENT FOR MAGNETIC PICKUP
ADJUSTMENT FOR PIEZO (TREBLE STRINGS) PICKUP
PCB PIN 8
PCB PIN 9
+_
+
_
PCB PIN 6 (HOT)
PCB PIN 5 (GND)
PCB PIN 1
PCB PIN 2
PCB PIN 3
RED WIRE FROM MAGNETIC PICKUP
ADJUSTMENT FOR PIEZO(BASS STRINGS) PICKUP
FROM MAGNETIC PICKUP(EMG-40P5) FROM PIEZO BRIDGE PICKUPS
9V
9V
PIN 11 = TO JACK TIP PIN 12 = V- TO JACK RING
PIN 1 = HOT FROM PIEZO #1 PIN 3 = HOT FROM PIEZO #2 PIN 4 = MAGNETIC P/U V+ RED
PIN 5 = GND FROM PICKUP
PIN 6 = SIGNAL FROM PICKUP
PIN 7 = NOT USED N/C
PIN 8 = TO BATTERY (+)
PIN 10 = TO JACK GND
PIN 9 = TO BATTERY (-)
PIN 2 = GND FROM PIEZO
IF 3 PIN CONNECTOR USED
SIDE VIEW
9 7 8
11
10
12
4 6 5 1 3 2
3
10
8
7 9
6
5
4
12
11 1
2
A12 PIN HEADER/NEW PIN OUT (EMG PCB rev E) 8/19/04
A25K
A25K (2X) B50K B50K
Center Detent Center Detent
