Sterling Finesse 6305-30 User manual

Features
•CleanCoatTM glass coating
•Frameless design maximizes glass area
•Inside and outside elegant pull handles
•Two roller-compression latches allow for smooth,
secure door closure
•A concealed hinge provides smooth, stable operation
•No top header eliminates clearance issues
•1-1/2″(3.8 cm) width adjustability for out-of-plumb
conditions
•Aluminum components extruded from alloy 6063-T5
•Stainless steel hardware prevents rusting or corrosion
•1/4″(6 mm) thick tempered glass
•Available in sizes to fit 28-3/4″(73 cm) to 32-3/4″
(83.2 cm) opening
Codes/Standards Applicable
Specified model meets or exceeds the following:
•ANSI Z97.1 (tempered glass)
•16 CFR Part 1201
FRAMELESS HINGE SHOWER DOOR
6300 Series
Colors/Finishes
•Refer to the Price Book for current frame finish and glass
options
Specified Model
Model A Width (Max/Min)* B (Height)* C Walk Through Max)*
6305-30** 30-1/4″(76.8 cm) / 28-3/4″(73 cm) 65-1/2″(166.4 cm) 23-13/16″(60.5 cm)
6305-31** 31-1/2″(80 cm) / 30″(76.2 cm) 65-1/2″(166.4 cm) 25-1/16″(63.7 cm)
6305-32** 32-3/4″(83.2 cm) / 31-1/4″(79.4 cm) 65-1/2″(166.4 cm) 26-5/16″(66.8 cm)
6305-34** 34″(86.4 cm) / 32-1/2″(82.6 cm) 65-1/2″(166.4 cm) 27-9/16″(70 cm)
6305-35** 35-1/4″(89.5 cm) / 33-3/4″(85.7 cm) 65-1/2″(166.4 cm) 28-13/16″(73.2 cm)
6305-36** 36-1/2″(92.7 cm) / 35″(88.9 cm) 65-1/2″(166.4 cm) 30-1/16″(76.4 cm)
6305-37** 37-3/4″(95.9 cm) / 36-1/4″(92.1 cm) 65-1/2″(166.4 cm) 31-5/16″(79.5 cm)
6305-39** 39″(99.1 cm) / 37-1/2″(95.3 cm) 65-1/2″(166.4 cm) 32-9/16″(82.7 cm)
* Note: Consult the diagram on the next page for the location of the measurements.
** Note: Add appropriate frame color/finish code to the end of the unit model # when ordering.
FINESSETM
Page 1 of 2
1019156-4-J
For more information
visit SterlingPlumbing.com
or call 1-800-STERLING

A
B
C
3-7/8"
(9.8 cm)
1-3/8"
(3.5 cm)
1-1/2"
(3.8 cm)
Product Diagram
FINESSETM
FINESSETM FRAMELESS HINGE SHOWER DOOR
Page2of2
1019156-4-J
