GE 19210 User manual

GE Model 19210/19211
www.jascoproducts.com
Wireless Pushbutton
Required Tools: Small flat blade screwdriver, drill, drill bit, and phillips screwdriver.
Included Hardware:
(2) 3x20mm screws
(2) Double sided adhesive pads
Required Tools: Small flat blade screwdriver, drill, drill bit, and phillips screwdriver.
Chime Tune Setting
All wireless chimes may have more than one push button. The chime tune for each push
button is set with jumpers 7-9.
Single Push Button Kit: If you purchased a kit with a single push button, the chime
tune will be set to Ding Dong from the factory.
Dual Push Button Kit: If you purchased a kit with two push buttons, one push button
will be set to Ding Dong and the other push button will be set to Westminster from the
factory.
The following instructions explain how to change the tune on any wireless push button.
1. Remove the battery from the push button transmitter.
2. Locate the 9 position jumper shown below.
9 position jumper (This pushbutton is set for Ding Dong Chime since 7=off, 8=on, and
9=off.)
3. Select the desired chime sound from the table below.
Chime Sound Table
Position 7 8 9
Westminster ON OFF OFF
Ding Dong OFF ON OFF
Knock OFF OFF ON
Bronze Chime ON ON OFF
Cuckoo Clock ON OFF ON
Foghorn OFF ON ON
Gong ON ON ON

ON: Add a jumper to a location
OFF: Remove jumper from a location.
4. Remove or add the jumpers to match the table.
5. Store unused jumpers as shown.
Parking the jumper on an open set of pins. The two jumpers on the left are in the parked
position.
Setting The House Security Code
Each chime component has jumpers for setting the house security code.
In most cases you will not need to change the factory settings for the
security code. If your chime activates intermittently or does not work at all,
you may be able to solve the problem by changing your security code.
Adding Additional Buttons
When adding a pushbutton to an existing system, you need to check the security code
on the existing chime and match the new pushbutton to that code.
The chime and pushbutton must be set to the same house security code for the
combination to operate together.
Note: The push button has 3 additional jumpers that are used to set the chime tune
that will play. The chime tune jumpers do not affect the house security code.

1. Remove batteries from the pushbutton by opening the case as shown below.
2. Locate the pushbutton jumpers shown below.
Push Button Jumpers
3. Jumpers 1-6 are used to select 1 of 64 possible home security codes.
4. To change the house code, add or remove jumpers as needed. After matching
the existing security code, test the system for proper operation. Positions 1-6 on
the chime and pushbutton must match exactly.
Push Button Mounting Instructions
Note: Avoid mounting the push button on metal surfaces, as it may result in a
reduced range of transmission. Do not mount in an area of rain (direct weather.)
a. Removing the back cover

b. Replacing the back cover
1. Push buttons are typically mounted at the same height as the door knob or
handle (between 36" and 44" above the floor).
2. Before mounting, choose a mounting location that is not farther than 150 feet
from the chime unit location.
Not farther than 150 feet
3. Place the push button where you would like to mount it and with the chime as
close to its final position as possible and test operation. If it works, mount the
button. If it does not work, see TROUBLESHOOTING.
4. Use back cover of push button as a template to mark two screw holes.

5. Drill two holes with 3/32” size drill in marked locations.
6. Secure back cover to the mounting surface with two supplied mounting screws.
7. Press front housing onto back cover.
8. Test operation. If the chime does not work, see TROUBLESHOOTING.
Operation
1. Turn on the chime.
2. Gently press transmitter button to sound chime.
Troubleshooting
Chime doesn't work:
1. Make sure push button switch is depressed and held for at least 1 second.
2. Make sure plastic tag is removed from battery.
3. Make sure house code switches 1-6 on chime and push button match exactly.
4. Verify battery orientation in push button.
5. Try fresh batteries.
6. Make sure chime is not farther than 150 feet away from push button.
7. Ensure push button is not mounted on metal, near metal studs, or near the floor.
8. Try a new location for the chime.
Functional range may be adversely affected by one or more of the following factors:
weather, radio frequency interference, low transmitter battery and obstructions between
the transmitter and receiver.
This device complies with Part 15 of the FCC rules. Operation is subject to the following
conditions:

1. This device may not cause harmful interference, and
2. This device must accept interference received, including any interference that
may cause undesired operation.
For technical support contact Jasco Products Company at 1-800-654-8483
or www.jascoproducts.com
