Stevens SDX User manual

1
SDX
Submersible
Depth
Transmitter
User Manual
July 2017
USER INFORMATION
Stevens makes no warranty as to the information furnished in these instructions and the reader assumes all risk in the
use thereof. No liability is assumed for damages resulting from the use of these instructions. We reserve the right to
make changes to products and/or publications without prior notice.
Stevens Water Monitoring Systems, Inc.
12067 NE Glenn Widing Drive, Suite 106
Portland, OR 97220
Tel: [phone]
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Web: http://www.stevenswater.com

2
WARNING!
ELECTRICAL POWER CAN RESULT IN DEATH, PERSONAL INJURY OR CAN CAUSE DAMAGE TO
EQUIPMENT.
If the instrument is driven by an external power source, disconnect the instrument from that power source before
attempting any repairs.
WARNING!
BATTERIES ARE DANGEROUS. IF HANDLED IMPROPERLY, THEY CAN RESULT IN DEATH, PERSONAL
INJURY OR CAN CAUSE DAMAGE TO EQUIPMENT.
Batteries can be hazardous when misused, mishandled, or disposed of improperly. Batteries contain potential energy,
even when partially discharged.
WARNING!
ELECTRICAL SHOCK CAN RESULT IN DEATH OR PERSONAL INJURY.
Use extreme caution when handling cables, connectors, or terminals; they may yield hazardous currents if
inadvertently brought into contact with conductive materials, including water and the human body.
CAUTION!
Be aware of protective measures against environmentally caused electric current surges
In addition to the previous warnings and cautions, the following safety activities should be carefully observed.
Children, Adolescents
NEVER give batteries to young people who may not be aware of the hazards associated with batteries and their
improper use or disposal.
Jewelry, Watches, Metal Tags
To avoid severe burns, NEVER wear rings, necklaces, metal watch bands, bracelets, or metal identification tags near
exposed battery terminals.
Heat, Fire
NEVER dispose of batteries in fire or locate them in excessively heated spaces. Observe the temperature limit listed
in the instrument specifications.
Charging
NEVER charge "dry" cells or lithium batteries that are not designed to be charged.
NEVER charge rechargeable batteries at currents higher than recom-mended ratings.
NEVER recharge a frozen battery. Thaw it completely at room temperature before connecting charger.
Unvented Container
NEVER store or charge batteries in a gas-tight container. Doing so may lead to pressure buildup and explosive
concentrations of hydrogen.
Short circuits

3
NEVER short circuit batteries. High current flow may cause internal battery heating and/or explosion.
Damaged Batteries
Personal injury may result from contact with hazardous materials from a damaged or open battery. NEVER attempt
to open a battery enclosure. Wear appropriate protective clothing, and handle damaged batteries carefully.
Disposal
ALWAYS dispose of batteries in a responsible manner. Observe all applicable federal, state, and local regulations
for disposal of the specific type of battery involved.
NOTICE
Stevens makes no claims as to the immunity of its equipment against lightning strikes, either direct or nearby.
The following statement is required by the Federal Communications Commission:
WARNING - This equipment generates, uses, and can radiate radio frequency energy, and, if not installed in
accordance with the instructions manual, may cause interference to radio communications. It has been tested and
found to comply with the limits for a Class A computing device pursuant to Subpart J of Part 15 of FCC Rules, which
are designed to provide reasonable protection against such interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause interference in which case the user at
his own expense will be required to take whatever measures may be required to correct the interference.
Stevens SDX
Figure 1
1.1 GENERAL DESCRIPTION
The Stevens SDX ( Figure 1) is a sensing device designed for water-level measurement applications. It is totally sealed
for direct insertion into the media to be monitored, and offers multiple applications. Low range units are ideal for open
channel flow applications. Higher range units are suitable for ground water, storage tank, or other similar applications.
The SDX can also be frozen in ice without damage to sensor.
1.2 SAFETY INFORMATION
Before performing any procedure in this manual, read all applicable warnings and cautions.

4
1.3 PRINCIPLES OF OPERATION
A pressure transducer is used as the primary sensing element, and measures the water depth by sensing pressure
above the unit. Internal circuitry within the SDX housing converts the signal to a 4-20 milliampere (mA) output, with 4
mA corresponding to zero depth (atmospheric pressure) and 20 mA to rated depth for selected range. Power for the
two-wire current loop is derived from an external power supply.
The unit is equalized for atmospheric pressure changes, and is insensitive to cable parameters. The unit offers low
electrical noise pickup.
1.4 SDX SPECIFICATIONS
Power Requirements
9 - 26 VDC
Output
4-20 mA current signal, linearly
corresponding to range
Operating Temperature
-40° F to 185° F (-40° C to 85° C)
Compensated Temperature
32° F to 122° F (0° C to 50° C)
Linearity
0-2.5 ft range: 0.2% max.
0-10 ft range: 0.2% max
0-35 ft range: 0.3% max
0-50 ft range: 0.3% max
(0.1% typical for all ranges)
Repeatability & Hysteresis
Typical: ± 0.2% span
Overpressure
0-2.5 ft: 20 psi max.
0-10 ft: 20 psi max
0-35 ft: 45 psi max
0-50 ft: 45 psi max
Reverse polarity protection
Built into sensor
Shock
Qualification tested to 150 g
Wiring
Red: power
Black: 4-20 mA return
Silver: drain wire

5
Pipe threading
1/2-14 straight pipe thread (back of sensor housing near cable)
3/8-18 straight pipe thread (under removable copper nose-cone)
Physical Size (L x D)
4.00" L x 0.84" dia. (101.6 mm L x 21.33 mm dia.)
Weight (approximate)
Probe: 2.37 oz (61.19 g)
Cable: 0.43 oz (12.19 g) per foot (.4 g per cm)
(weights are approximate)
2.1 GENERAL
The Stevens SDX is a sealed unit that is suitable for submersion in water. The SDX is an isolated (floating) electrical
device. Connect the SDX, an appropriate direct current loop power supply, and the receiving device (recorder, etc.) in
a series loop. The system should be grounded at one point only, usually near the receiving device.
2.2 INSTALLING THE SDX
CAUTIONI The SDX Is a sensitive instrument. It should not be dropped or allowed to strike against a hard
surface. Avoid overpressure for specified range (see specifications). DO NOT apply excessive twisting
force to the cable.
The SDX can be installed with several different mountings.
Perform the following procedures to install the SDX:
1. Carefully inspect the instrument for shipping damage. Remove all packing materials from the SDX.
2. Select appropriate mounting.
2.2.1 Installation in Specially Designed Flumes
To install the SDX in specially designed flumes, the SDX can be mounted in the bottom in a special cavity.
Align the SDX and clip into place.
2.2.2 Installation in Standard Flumes,
Monitoring Wells, or Chambers
On standard flumes or other monitoring wells or chambers, the SDX can be bracket-mounted on the inside of the flume,
bulkhead mounted, pipe mounted, suspended, or T-mounted.
1. For bracket mounting, clip the SDX into place.
2. For pipe mounting, route the cable through the pipe, then mount the entire assembly. Do not twist the cable.
2.2.3 Installing Downhole

6
Sometimes it may be desirable to install an SDX downhole in a stilling well or groundwater monitoring well.
Normally, the SDX can be supported simply by its attached cable.
3.1 GENERAL INFORMATION
The Stevens SDX was designed and assembled to assure low maintenance and long life. The SDX contains no user-
serviceable parts. If the SDX fails to operate correctly, it must be returned to Stevens for factory repair or replacement.
3.2 PERIODIC MAINTENANCE
Optional Desiccant Cartridge
Figure 3
The pressure transducer used is a “Wet-Wet” device. While it is important to keep the SDX cable’s vent tube
unobstructed for barometric pressure compensation, this feature results in neither the pressure transducer nor internal
electronics becoming damaged by condensation or moisture entering the SDX cable’s vent tube. However, it is possible
for vapor to condense into water which could create an offset in the transducer output. Therefore, Stevens recommends
the desiccant cartridge with vent tube adapter be installed to prevent moisture from entering the vent tube.
Replace the desiccant cartridge when the indicating crystals have turned from blue to pink.
If used with a flume, weir, or stilling well, it should be kept clear of obstructions, debris, or silt. When cleaning, the SDX
should be removed prior to hosing out the channel, tank, or well.
CAUTION: The SDX contains a pressure-sensitive sensor. NEVER direct a high-pressure fluid stream at the
SDX; damage may occur. If there Is an accumulation of silt or other contamination, the SDX will need to be cleaned.
Swish the SDX gently from side to side in warm, not hot, soapy water.
3.3 FACTORY SERVICE
When contacting the factory about an instrument, include all nameplate data.

7
3.4 Ordering
Manufacturer
Part #
Description
93720-102
SDX Pressure sensor, 9-26VDC,Temp.Compensated, 2.5 ft. range, without cable.
93720-105
SDX Pressure sensor, 9-26VDC,Temp.Compensated, 5 ft. range, without cable.
93720-110
SDX Pressure sensor, 9-26VDC,Temp.Compensated, 10 ft. range, without cable.
93720-135
SDX Pressure Sensor, 9-26VDC,Temp.Compensated, 35 ft. range, without cable.
93720-150
SDX Pressure Sensor, 9-26VDC,Temp.Compensated, 50 ft. range, without cable.
44049
Cable, Vented, for SDX sensor, Price per foot.
93030-001
Desiccant Cartridge, for SDX, 20 cm (7.8 in) length
93030-001
Desiccant Cartridge, for SDX, 10 cm (3.9 in) length
