STI 34108 User manual

Installation and Operation Manual
STI 8-Channel Receiver
Thank you for purchasing this fine product. Your satisfaction is very important to us. Please read this manual carefully to get the
most from your new product.
HOW THE PRODUCT WORKS
STI offers multiple wireless products designed to alert you of several different conditions. The STI 8-CHANNEL RECEIVER is a
433 MHz radio signal receiver that allows you to monitor up to 8 different STI devices at a single, convenient location. When
placed in enroll mode, it allows you to select 1 of 8 different zones that will represent your STI device(s) best, and enrolls it
when the monitor detects the STI device’s wireless signal. The STI wireless device family uses a system that also ensures
other devices (not from STI) are not enrolled or detected. There are no concerns of accidental enrollment, alerts or crosstalk.
The RECEIVER allows you to choose which devices shall have a latching memory condition, when selected during enrollment.
It also allows you to select turning on a siren, sounding a chime, triggering a normally open or normally closed switch or
turning on an external 12 VDC output. The STI 8-CHANNEL RECEIVER also acts as a console repeater when paired with other
STI 8-CHANNEL RECEIVERS to receive wireless transmissions in up to 4 other areas over long distances or around disruptive
terrain.
BEFORE YOU START
Refer to this drawing to become familiar with all the parts.
Model: STI-34108
ANCHOR
(4) PROVIDED
MARK AND DRILL
3/16 DIAMETER HOLES
(4) PLACES
NYLON WASHER
(4) PROVIDED
#6 x 1 1/4 in. PHILLIPS PAN
HEAD SCREW (4) PROVIDED
PUSH BUTTON
#4 x 5/16 in. FRONT COVER SCREW
PUSH BUTTON SWITCH
Represents any STI 433 MHz sensor transmitting ONLY to a Master Receiver
SYSTEM 1 SYSTEM 2
MULTLIPLE SYSTEMS
Master
Receiver Mirror #1
Receiver
Mirror #2
Receiver
Up to
1000 ft
Up to
1000 ft
Up to
1000 ft Up to
1000 ft Up to
1000 ft
Up to
1000 ft
Master
Receiver Mirror #1
Receiver
Master
Receiver
Mirror #1
Receiver
Mirror #2
Receiver
- Last
Mirror #2
Receiver
- Last
Monitors Housed in a
Central Office or Location
SINGLE SYSTEM
Mirror #3
Receiver
Up to
1000 ft
Mirror #4
Receiver
- Last
Up to
1000 ft
Switches (1-8) - For reference, information is also written on the
receiver case (located under Zone ID list).
1 - MIRROR MASTER OFF/ON
2 - NORMAL/ENROLL
3 - AUTO RESTORE/LATCH
4 - SIREN TIME/MIRROR#
5 - SIREN TIME/MIRROR#
6 - CHIME OFF/ON
7 - NORMAL/DELETE
8 - MIRROR SLAVE OFF/ON
SIREN
SW4 SW5 TIME MIRROR #
OFF OFF DISABLED 1
ON OFF 30 SEC 2
OFF ON 180 SEC 3
ON ON ON CONT 4
Embossed Programming Instructions:
ZONES:
LEFT BUTTON
“CALL”
RIGHT BUTTON
“RESTORE”
NO ZONE:
ON and OFF
BUTTONS
1 - MIRROR MASTER OFF/ON
2 - NORMAL/ENROLL
3 - AUTO RESTORE/LATCH
4 - SIREN TIME/MIRROR#
5 - SIREN TIME/MIRROR#
6 - CHIME OFF/ON
7 - NORMAL/DELETE
8 - MIRROR SLAVE OFF/ON
SIREN
SW4 SW5 TIME MIRROR #
OFF OFF DISABLED 1
ON OFF 30SEC 2
OFF ON 180 SEC 3
ON ON ON CONT 4
ANTENNAS
SWITCHES 1-8
ZONE LEDs
PUSH BUTTON
PIEZO
COVER
SCREW
DIPSWITCH
FUNCTIONS
WIRE ROUTE
OPTION 1
FORM C
SWITCH OUTPUTS
12V INPUTS
TERMINALS 500mA
12V OUTPUTS
TERMINALS 300mA
WIRE ROUTE
OPTION 2
TRIGGERED OUTPUT PLUG
12V , 75mA
PLUG IN ADAPTER
12V , 500mA
SURFACE FEET (x4)
(WALL MOUNTING HOLES)
EMBOSSED
INPUT AND
OUTPUTS
FCC ID: TXL34108
MODEL #34108
IC: 6335A-34108
SAFETY TECHNOLOGY INTERNATIONAL
WATERFORD, MI U.S.A.
REDDITCH, WORCESTERSHIRE UK
Trigger
Output
12 V
75mA
N.O.
COM
N.C.
+ 12V
- IN
500 mA
300 mA
PLUGINADAPTER
12 V 500mA
ANTENNAS
SWITCHES 1-8
ZONE LEDs
PUSH BUTTON
PIEZO
COVER
SCREW
DIPSWITCH
FUNCTIONS
+ 12V
- OUT
WIRE ROUTE
OPTION 1
FORM C
SWITCH OUTPUTS
12V INPUTS
TERMINALS 500mA
12V OUTPUTS
TERMINALS 300mA
WIRE ROUTE
OPTION 2
TRIGGERED OUTPUT PLUG
12V , 75mA
PLUG IN ADAPTER
12V , 500mA
EMBOSSED
INPUT AND
OUTPUTS
FCC ID: TXL34108
MODEL #34108
IC: 6335A-34108
SAFETY TECHNOLOGYINTERNATIONAL
WATERFORD,MI U.S.A.
REDDITCH, WORCESTERSHIRE UK
Trigger
Output
12 V
75mA
N.O.
COM
N.C.
+ 12V
- IN
500 mA
300 mA
PLUGINADAPTER
12 V 500mA
+ 12V
- OUT
ANTENNAS
SWITCHES 1-8
ZONE LEDs
PUSH BUTTON
PIEZO
COVER
SCREW
DIPSWITCH
FUNCTIONS
ANCHOR
(4) PROVIDED
MARK AND DRILL
3/16 DIAMETER HOLES
(4) PLACES
NYLON WASHER
(4) PROVIDED
#6 x 1 1/4 in. PHILLIPS PAN
HEAD SCREW (4) PROVIDED
PUSH BUTTON
#4 x 5/16 in. FRONT COVER SCREW
PUSH BUTTON SWITCH
Represents any STI 433 MHz sensor transmitting ONLY to a Master Receiver
SYSTEM 1 SYSTEM 2
MULTLIPLE SYSTEMS
Master
Receiver Mirror #1
Receiver
Mirror #2
Receiver
Up to
1000 ft
Up to
1000 ft
Up to
1000 ft Up to
1000 ft Up to
1000 ft
Up to
1000 ft
Master
Receiver Mirror #1
Receiver
Master
Receiver
Mirror #1
Receiver
Mirror #2
Receiver
- Last
Mirror #2
Receiver
- Last
Monitors Housed in a
Central Office or Location
SINGLE SYSTEM
Mirror #3
Receiver
Up to
1000 ft
Mirror #4
Receiver
- Last
Up to
1000 ft
Switches (1-8) - For reference, information is also written on the
receiver case (located under Zone ID list).
1 - MIRROR MASTER OFF/ON
2 - NORMAL/ENROLL
3 - AUTO RESTORE/LATCH
4 - SIREN TIME/MIRROR#
5 - SIREN TIME/MIRROR#
6 - CHIME OFF/ON
7 - NORMAL/DELETE
8 - MIRROR SLAVE OFF/ON
SIREN
SW4 SW5 TIME MIRROR #
OFF OFF DISABLED 1
ON OFF 30 SEC 2
OFF ON 180 SEC 3
ON ON ON CONT 4
Embossed Programming Instructions:
ZONES:
LEFT BUTTON
“CALL”
RIGHT BUTTON
“RESTORE”
NO ZONE:
ON and OFF
BUTTONS
1 - MIRROR MASTER OFF/ON
2 - NORMAL/ENROLL
3 - AUTO RESTORE/LATCH
4 - SIREN TIME/MIRROR#
5 - SIREN TIME/MIRROR#
6 - CHIME OFF/ON
7 - NORMAL/DELETE
8 - MIRROR SLAVE OFF/ON
SIREN
SW4 SW5 TIME MIRROR #
OFF OFF DISABLED 1
ON OFF 30SEC 2
OFF ON 180 SEC 3
ON ON ON CONT 4
ANTENNAS
SWITCHES 1-8
ZONE LEDs
PUSH BUTTON
PIEZO
COVER
SCREW
DIPSWITCH
FUNCTIONS
WIRE ROUTE
OPTION 1
FORM C
SWITCH OUTPUTS
12V INPUTS
TERMINALS 500mA
12V OUTPUTS
TERMINALS 300mA
WIRE ROUTE
OPTION 2
TRIGGERED OUTPUT PLUG
12V , 75mA
PLUG IN ADAPTER
12V , 500mA
SURFACE FEET (x4)
(WALL MOUNTING HOLES)
EMBOSSED
INPUT AND
OUTPUTS
FCC ID: TXL34108
MODEL #34108
IC: 6335A-34108
SAFETY TECHNOLOGY INTERNATIONAL
WATERFORD, MI U.S.A.
REDDITCH, WORCESTERSHIRE UK
Trigger
Output
12 V
75mA
N.O.
COM
N.C.
+ 12V
- IN
500 mA
300 mA
PLUGINADAPTER
12 V 500mA
ANTENNAS
SWITCHES 1-8
ZONE LEDs
PUSH BUTTON
PIEZO
COVER
SCREW
DIPSWITCH
FUNCTIONS
+ 12V
- OUT
WIRE ROUTE
OPTION 1
FORM C
SWITCH OUTPUTS
12V INPUTS
TERMINALS 500mA
12V OUTPUTS
TERMINALS 300mA
WIRE ROUTE
OPTION 2
TRIGGERED OUTPUT PLUG
12V , 75mA
PLUG IN ADAPTER
12V , 500mA
EMBOSSED
INPUT AND
OUTPUTS
FCC ID: TXL34108
MODEL #34108
IC: 6335A-34108
SAFETY TECHNOLOGYINTERNATIONAL
WATERFORD,MI U.S.A.
REDDITCH, WORCESTERSHIRE UK
Trigger
Output
12 V
75mA
N.O.
COM
N.C.
+ 12V
- IN
500 mA
300 mA
PLUGINADAPTER
12 V 500mA
+ 12V
- OUT
ANTENNAS
SWITCHES 1-8
ZONE LEDs
PUSH BUTTON
PIEZO
COVER
SCREW
DIPSWITCH
FUNCTIONS

— 2 —
INSTALLATION GUIDE
Surface Installation
1. Ensure mounting screws are removed.
2. Insert rubber feet (provided) into holes on bottom cover.
3. Route wires under the product.
Wall Mounted Installation
1. Ensure rubber feet are removed.
2. Remove front cover screw.
3. Remove cover (be careful not to lose push button).
4. Mark mounting holes on wall using bottom cover as template.
5. Drill holes with 3/16” drill bit.
6. Insert wall anchors (provided).
7. Insert power cord and wires and route on the back.
8. Insert mounting screws (provided) into plastic washers (provided).
9. Insert mounting screws into PCB holes through back of cover.
10. Insert mounting screws into wall anchors and tighten.
11. Press fit push button onto the push button switch on the circuit board.
12. Insert top cover tabs into bottom cover slots.
13. Carefully close top cover ensuring the push button inserts into cover hole and antennas rest in the side cover grooves.
14. Insert front cover screw and tighten.
15. Plug in AC adaptor.
If using for the first time or for enrollment adjustments, follow Zone Enrolling instructions. Otherwise, STI 8-CHANNEL
RECEIVER should be fully functional.
