Stihl RMA 510 User manual

{
STIHL RMA 510 Instruction Manual
Notice d’emploi

GInstruction Manual
1 - 29
FNotice d’emploi
30 - 62

Original Instruction ManualPrinted on chlorine-free paper
Printing inks contain vegetable oils, paper can be recycled.
© ANDREAS STIHL AG & Co. KG, 2018 0458-723-8221-A. VA1.J18. 0000007640_005_GB
RMA 510
English
1
{This instruction manual is protected by copyright. All rights reserved, especially the rights to reproduce, translate and process
with electronic systems.
Contents
Dear Customer,
Thank you for choosing a quality
engineered STIHL product.
It has been built using modern
production techniques and
comprehensive quality assurance.
Every effort has been made to ensure
your satisfaction and trouble-free use of
the product.
Please contact your dealer or our sales
company if you have any queries
concerning this product.
Your
Dr. Nikolas Stihl
Guide to Using this Manual 2
Safety Precautions and Working
Techniques 2
Using the Unit 8
Mulching 8
Mounting the Handlebar 10
Grass Box 12
Adjusting Cutting Height 12
Connecting Charger to Power
Supply 13
Charging the Battery 13
LEDs on Battery 14
LED on Charger 16
Switching On ECO Mode 16
Switching Off ECO Mode 16
Switching On 17
Switching Off 18
Storing the Machine 19
Inspection and Maintenance by
User 19
Sharpening Instructions 20
Maintenance and Care 22
Main Parts 23
Specifications 25
Troubleshooting 27
Maintenance and Repairs 29
Battery Recycling 29
Disposal 29

RMA 510
English
2
Pictograms
The meanings of the pictograms
attached to the machine are explained in
this manual.
Depending on the model concerned, the
following pictograms may be attached to
your machine.
Symbols in text
WARNING
Warning where there is a risk of an
accident or personal injury or serious
damage to property.
NOTICE
Caution where there is a risk of
damaging the machine or its individual
components.
Engineering improvements
STIHL's philosophy is to continually
improve all of its products. For this
reason we may modify the design,
engineering and appearance of our
products periodically.
Therefore, some changes, modifications
and improvements may not be covered
in this manual.
Notes on Usage
Use the power tool only for mowing
grass.
Do not mow wet grass.
It must not be used for any other
purpose because of the increased risk of
accidents and damage to the machine.
Never attempt to modify the product in
any way since this may result in
accidents or damage.
General Notes
Observe all applicable local safety
regulations, standards and ordinances.
The use of noise emitting power tools
may be restricted to certain times by
national or local regulations.
If you have not used this model before:
Have your dealer or a trained expert
show you how to operate it properly and
safely.
Minors should never be allowed to use
this product.
Keep bystanders, especially children,
and animals away from the work area.
The user is responsible for avoiding
injury to third parties or damage to their
property.
Lend or rent your power tool only
together with this instruction manual and
only to persons who are familiar with this
model and its operation.
To operate this power tool you must be
rested, in good physical condition and
mental health.
The user must be in good physical
condition and mental health to operate
and work with the power tool. If the
user’s physical, sensory or mental ability
is restricted, he or she may work only
under the supervision of or as instructed
by a responsible person.
Children should never be allowed to play
with this power tool. Children must not
be allowed to maintain or clean the
power tool without supervision.
If you have any condition that might be
aggravated by strenuous work, check
with your doctor before operating a
power tool.
Do not operate the power tool if you are
under the influence of any substance
(drugs, alcohol) which might impair
vision, dexterity or judgment.
Guide to Using this Manual
Key for locking and
unlocking
Safety Precautions and
Working Techniques
Some special safety pre-
cautions have to be
observed when working
with this power tool
because of the very high
speed of the cutting
blade.
It is important that you
read the instruction man-
ual before first use and
keep it in a safe place for
future reference. Non-
observance of the
instruction manual may
result in serious or even
fatal injury.

RMA 510
English
3
Clothing and Equipment
Wear proper protective clothing and
equipment.
Avoid clothing that could get caught in
scrub or moving parts of the machine.
Do not wear a scarf, necktie or jewelry.
Tie up and confine long hair (e.g. with a
hair net, cap, etc.).
WARNING
Hearing protection is recommended,
e.g. earplugs or ear muffs.
STIHL offers a comprehensive range of
personal protective clothing and
equipment.
The Power Tool
Never attempt to modify your machine in
any way since this may increase the risk
of personal injury. STIHL excludes all
liability for personal injury and damage
to property caused while using
unauthorized attachments.
Transporting the Power Tool
Always switch off the machine, wait for
the cutting blade to come to a complete
standstill, remove the fuse key and
battery – even when you transport the
machine short distances. This avoids
the risk of the motor starting
unintentionally.
Wear gloves.
Always carry the machine with an
assistant.
–Both hands on the housing (1).
–Left hand on the left bracket, right
hand on the right bracket (2).
Always keep the cutting blade well away
from your body, especially your feet and
legs.
Transport the power tool only after the
motor has cooled down.
Transporting by vehicle: Properly secure
your power tool and its parts (e.g. grass
box) to prevent turnover and damage.
Attach ropes or straps to the handles.
Cleaning the Machine
Do not use a pressure washer to clean
your power tool. The solid jet of water
may damage parts of the power tool.
Do not spray the power tool with water.
Clothing must be sturdy
but allow complete free-
dom of movement. Wear
long pants.
Wear sturdy shoes with
non-slip soles.
To reduce the risk of eye
injuries, wear close-fit-
ting safety glasses in
accordance with Euro-
pean Standard EN 166.
Make sure the safety
glasses are a comforta-
ble and snug fit.
Wear heavy duty gloves
when transporting the
machine and carrying out
work on the cutting blade.
12
0000-GXX-2634-A0

RMA 510
English
4
Storing the Unit
When the machine is not in use, store it
so that it does not endanger others.
Secure it against unauthorized use.
Accessories and Spare Parts
Only use cutting blades and accessories
that are explicitly approved for this
power tool by STIHL. If you have any
questions in this respect, consult a
servicing dealer. Use only high quality
tools and accessories in order to avoid
the risk of accidents and damage to the
machine.
STIHL recommends the use of genuine
STIHL tools and accessories. They are
specifically designed to match the
product and meet your performance
requirements.
Drive
Battery
Observe the information in the leaflet or
instruction manual supplied with the
STIHL battery and keep it in a safe
place.
For further notes on safety visit
www.stihl.com/safety-data-sheets.
Charger
Observe the information in the leaflet
supplied with the STIHL charger and
keep it in a safe place.
Notes on Operation
and
before
–before carrying out inspections,
adjustments or cleaning work
–performing any work on the cutting
blade
–leaving the machine unattended
–before transporting the machine
–before storing the machine
–before performing repairs or
maintenance work
–in the event of danger or in an
emergency
This avoids the risk of the motor starting
unintentionally.
Before Starting Work
Check that your power tool is properly
assembled and in good condition – refer
to appropriate chapters in the instruction
manual.
–The switch lever and switch lever
lockout must move freely and return
to the idle position when they are
released.
–Switch lever locked in position when
switch lever lockout is not
depressed.
–Check that the cutting blade is
properly and securely mounted and
in good condition.
–Inspect the power tool for damage
or wear. Always replace damaged
parts.
–Do not use your power tool if safety
devices are damaged, the coasting
brake does not operate or safety
devices are not mounted (e.g.
ejection chute shield).
–Never use your machine with a
damaged grass box.
–Never attempt to modify the controls
or safety devices in any way.
–Keep the handles dry and clean –
free from oil and dirt – for safe
control of the power tool.
–Check contacts in battery
compartment for foreign matter.
–Fit the battery correctly – it must
engage audibly.
–Never use defective or deformed
batteries.
Removing the Fuse Key
take the battery out of the
machine

RMA 510
English
5
To reduce the risk of accidents, do not
operate your power tool if it is not
properly assembled and in good
condition.
Switching On
Start the machine on a flat surface. Do
not tilt the machine when you switch on
the motor.
Do not switch on the machine in high
grass or with the cutting height set to the
lowest level.
Operate the machine only with the cover
closed.
During Operation
Make sure you always have good
balance and secure footing.
In case of imminent danger or in an
emergency, switch off the power tool
immediately, remove the fuse key and
the battery.
To reduce the risk of injury from thrown
objects, do not allow any other persons
within 15 meters of your own position.
To reduce the risk of damage to
property, also maintain this distance
from other objects (vehicles, windows).
Do not mow at outside temperatures
below +5°C.
Do not leave the machine outdoors in
the rain.
Take special care in slippery conditions
on slopes and uneven ground.
Do not operate your machine in the rain,
during thunderstorms or when there is a
risk of lightning strikes.
Never remove or bridge the switchgear
or safety devices installed in the
machine. Do not fix the switch lever in
position (e.g. by tying it).
Never operate your machine with the
handle folded down.
Do not switch on the machine if the
discharge chute is not covered by the
discharge flap or the grass box. Do not
leave the discharge chute open.
Do not mow extremely steep slopes. To
reduce the risk of injury, do not operate
your machine on slopes with a gradient
of more than 25°.
Mow parallel to the slope, never up or
down. Take particular care when
changing direction on slopes.
If a rotating metal cutting attachment
makes contact with a rock or other solid
object there is a risk of sparking which
may cause easily combustible material
to catch fire under certain
circumstances. Dry plants and scrub are
also easily combustible, especially in hot
and dry weather conditions. If there is a
risk of fire, do not use metal cutting
attachments near combustible
materials, dry plants or scrub. Always
contact your local forest authority for
information on a possible fire risk.
Watch out for obstacles: Tree stumps,
roots, especially when moving
backwards and pulling the machine –
risk of stumbling.
Work calmly and carefully – in daylight
conditions and only when visibility is
good. Stay alert so as not to endanger
others.
15 m (50 ft)
Keep hands and feet well
clear of rotating parts and
do not touch the rotating
cutting blade. To reduce
the risk of injury, always
maintain the distance
from the ejection chute
that is defined by the
handlebar.
Do not touch the cutting
blade while the motor is
running. Never open the
ejection chute shield or
remove the grass box
while the motor is run-
ning. There is otherwise a
risk of injury from the
rotating cutting blade.
Protect from rain – do not
immerse in fluids.
Inspect the work area:
Stones, pieces of metal
or other solid objects can
be thrown and cause per-
sonal injury or damage
the cutting blade and
property (e.g. parked
vehicles, windows).

RMA 510
English
6
To reduce the risk of accidents, take a
break in good time to avoid tiredness or
exhaustion.
Be particularly alert and cautious when
wearing hearing protection because
your ability to hear warnings (shouts,
alarms, etc.) is restricted.
The dust that occurs during operation
may be harmful to health. If dust levels
are very high, wear a suitable respirator.
Avoid contact with electrical cables or
wires – risk of electric shock.
If your power tool is subjected to
unusually high loads for which it was not
designed (e.g. heavy impact or a fall),
always check that it is in good condition
before continuing work – see also
"Before Starting Work". Make sure the
safety devices are working properly. Do
not continue operating your power tool if
it is damaged. In case of doubt, consult
your servicing dealer.
Check the cutting attachment at regular
short intervals during operation or
immediately if there is a noticeable
change in cutting behavior:
–Switch off the machine, allow
cutting blade to come to a complete
standstill, remove the fuse key and
the battery.
–Check condition and tightness, look
for cracks.
In the event of contact with foreign
matter, check the cutting blade for signs
of damage. Do not operate your power
tool with a damaged or bent blade shaft
or motor shaft.
If your machine begins to vibrate
unusually: Switch off the machine – risk
of injury. Inspect the whole machine,
particularly the cutting attachment, for
signs or damage or loose parts. Do not
use your machine until damaged parts
are replaced and loose parts properly
secured. STIHL recommends an
authorized STIHL servicing dealer.
If the cutting blade becomes obstructed,
or if there is a blockages in the discharge
chute or in the area of the cutting blade,
immediately switch off the motor, allow
the cutting attachment to come to a
complete standstill, remove the fuse key
and the battery. Rectify the cause of the
problem.
Do not overload your machine during
operation to a point where the motor
slows down. If motor speed begins to
slow, select a higher cutting height or
reduce the feed rate.
If the motor is thermally overloaded
during operation, it cuts out
automatically and must cool down
before it is restarted. Causes of
overload:
–Mowing overlong grass or at too low
a cutting height
–Mowing speed too high
–Cooling air slots dirty
Switching the machine on and off
frequently within a short period may
cause the motor to overheat.
Do not attach objects to the handlebar.
The machine must not be used for
transporting persons, particularly
children, or objects.
After Finishing Work
Before leaving the power tool
unattended: Switch off the motor,
remove the fuse key and battery.
Note that the cutting attachment
continues to run for a short period after
the power tool is switched off – flywheel
effect. The machine is equipped with a
coasting brake. The coasting brake
shortens the time required for the blade
to come to a standstill – see also
"Switching Off".
Allow power tool to cool down
completely.
Always clean dust and dirt off the power
tool – do not use any grease solvents for
this purpose.
Holding and Controlling the Power Tool
The machine is operated by one person
only – do not allow other persons,
especially children, or animals in the
work area.

RMA 510
English
7
Always hold the handle firmly with both
hands.
Operate the machine at walking pace
only – never run.
Maintenance and Repairs
Always remove the fuse key and battery
from the power tool before carrying out
any repairs or maintenance work. This
avoids the risk of the motor starting
unintentionally.
Service the machine regularly. Do not
attempt any maintenance or repair work
not described in the instruction manual.
Have all other work performed by a
servicing dealer.
STIHL recommends that you have
servicing and repair work carried out
exclusively by an authorized STIHL
servicing dealer. STIHL dealers are
regularly given the opportunity to attend
training courses and are supplied with
the necessary technical information.
Only use high-quality replacement parts
in order to avoid the risk of accidents
and damage to the unit. If you have any
questions in this respect, consult a
servicing dealer.
STIHL recommends the use of genuine
STIHL replacement parts. They are
specifically designed to match your
model and meet your performance
requirements.
Never attempt to modify your power tool
in any way since this will increase the
risk of personal injury.
Regularly check the electrical contacts
and ensure that the insulation of the
connecting cord and plug of the charger
is in good condition and shows no sign
of ageing (brittleness).
Electrical components, e.g. connecting
cord of charger, may only be repaired or
replaced by a qualified electrician.
Clean plastic surfaces with a cloth. Do
not use aggressive detergents. They
may damage the plastic.
Check tightness of mounting screws, on
the cutting attachment in particular, and
retighten if necessary.
Clean cooling air openings in motor
housing as necessary.
Keep the battery guides free from
foreign matter – clean as necessary.
Replace illegible or damaged warning
labels on the power tool.
Store the power tool in a dry, locked
location with the fuse key and battery
removed.
Vibrations
This power tool minimizes the vibrations
transmitted to the operator's hands.
However, the operator should seek
medical advice in the event of suspected
circulatory problems in the hands (e.g.
tingling sensation in the fingers).
0000-GXX-2635-A0

RMA 510
English
8
Mowing
A beautiful and dense lawn is obtained
by frequent mowing.
The lawn should not be kept too short in
hot and dry weather because it will
otherwise be burned by the sun and
become unattractive.
A sharp blade produces a more
attractive finish than a dull one. Sharpen
the blade regularly – see also
"Sharpening the Cutting Blade".
Cuttings can be collected in the grass
box or ejected to the rear.
Mowing on Slopes
Your cordless lawn mower can be used
on gradients of up to 25°.
Cutting Performance
The cutting performance depends on
the type of grass and the height of cut
selected. Cutting performance is
increased by:
–Mowing frequently.
–Increasing the height of cut.
–Reducing mowing speed.
–Allowing lawn to dry before mowing.
Disposal
Do not throw cuttings in the garbage can
– they can be composted! Mulching
In the mulching mode, the grass
clippings are recirculated in the
airstream, re-cut several times into small
particles and then blown back onto the
lawn. The fine particles remain on the
lawn surface where they decompose
quickly and serve as a natural fertilizer.
Frequent mulching produces a beautiful,
dense lawn. One third of the grass
height should be cut in this process.
Mulch at least twice a week in spring and
at least once a week in summer/autumn.
Mulching Result
Prerequisites for good mulching results:
–Lawn should be dry
–Use properly sharpened blades
–Low mowing speed
–Vary mowing direction and overlap
the cuts
–Mow very high grass in gradual
stages
The housing can become clogged and
block the blade if the cutting height is too
low or the grass is wet.
Conversion for Mulching
The mulch insert must be fitted for
mulching.
Using the Unit Mulching

RMA 510
English
9
NRemove the grass box, see
“Removing the Grass Box”
NAdjust the height of cut, see
“Adjusting Cutting Height”
NFit the mulch insert, see “Fitting the
Mulch Insert”
Fitting the Mulch Insert
NOpen the discharge flap (1) and
hold it in position.
NHold the mulch insert (2) by the
handle (3) and fit it in the discharge
chute (4).
NClose the discharge flap (1).
Removing the Mulch Insert
NOpen the discharge flap (1) and
hold it in position.
NGrip the mulch insert (2) by the
handle (3) and take it out of the
discharge chute (4).
NClose the discharge flap (1).
Fitting the Side Discharge
The mulch insert must be in place when
the side discharge is fitted.
NOpen the side discharge flap (1)
and hold it in position.
NLine up recesses (2) in side
discharge (3) below the pin (4).
NClose the side discharge flap (1).
Removing the Side Discharge
NOpen the side discharge flap (1)
and hold it in position.
NRemove the side discharge (2).
NClose the side discharge flap (1).
0000-GXX-2636-A0
4
2
3
1
0000-GXX-2637-A0
1
4
2
3

RMA 510
English
10
WARNING
Place the machine on a firm and level
surface for the following work.
WARNING
The lower handle, and upper handle,
can be folded down after rotating the
locking knobs. Check that the star knobs
are firmly tightened. Hold the handle at
the highest point with one hand and
rotate the locking knobs. Risk of injury.
WARNING
The upper handle can be folded over by
loosening the star knobs. Hold the
handle at the highest point with one
hand and loosen the star knobs. Risk of
injury.
Assembling the Handle
Unfolding the lower handle
NRotate the locking knobs (1) 90°.
NUnfold the lower handle (2).
NLine up the locking knobs (1) in one
of the three positions on the
brackets (3).
NRotate the locking knobs (1) 90° so
that they engage the holes in the
brackets (3).
Make sure that both locking knobs (1)
are in the same position.
Mounting the upper handle
NLine up holes in upper handle (4)
and lower handle (5).
NInsert bolts (6) through holes in
upper handle (4) and lower handle
(5).
NScrew the star knobs (7) onto the
bolts (6) and tighten them down
clockwise.
NFit cables (8) in the cable clip (9),
Folding Down the Handle
The handle can be folded down to clean,
transport or store your cordless lawn
mower.
Make sure cables are not pinched when
you fold down the handlebar.
Folding down the lower handle
NRotate the locking knobs (1) 90°.
NFold down the lower handle (2).
Mounting the Handlebar
90°
1
2
0000-GXX-2638-A0
90°
0000-GXX-2639-A0
3
1
6
7
5
4
8
9
0000-GXX-2640-A0
2
90°
1
0000-GXX-2641-A0

RMA 510
English
11
NRotate the locking knobs (1) 90° so
that they engage the holes in the
extensions (3).
The lower handlebar (2) is now locked in
position.
Folding down the upper handle
NUnscrew the star knobs (4)
counterclockwise.
NFold down the upper handle (5).
NTighten down the star knobs (4)
clockwise.
Unfolding the Handle
Make sure cables are not pinched when
you unfold the handle.
Unfolding the lower handle
NRotate the locking knobs (1) 90°.
NUnfold the lower handle (2).
NLine up the locking knobs (1) in one
of the three positions on the
brackets (3).
NRotate the locking knobs (1) 90° so
that they engage the holes in the
brackets (3).
Make sure that both locking knobs (1)
are in the same position.
Unfolding the upper handle
NUnfold the supper handle (4).
NTighten down the star knobs (5)
clockwise.
0000-GXX-2642-A0
13
90°
1
3
0000-GXX-2643-A0
5
4
4
90°
0000-GXX-2798-A0
12
1
90°
0000-GXX-2639-A0
3
1
0000-GXX-2644-A0
4
5

RMA 510
English
12
WARNING
Place the machine on a firm and level
surface for the following work.
Fitting the Grass Box
NSwitch off the machine.
NRemove the mulch insert, see
“Removing the Mulch Insert”.
NRemove the side discharge, see
“Removing the Side Discharge”.
NOpen the discharge flap (1) and
hold it in position.
NHold grass box by the handle (2)
and engage the hooks (3) on the rod
(4).
NClose the discharge flap (1).
Emptying the Grass Box
NSwitch off the machine.
NOpen the discharge flap (1) and
hold it in position.
NHold grass box by the handle (2)
and unhook it upwards.
NClose the discharge flap (1).
NEmpty the grass box.
Different cutting heights can be
selected.
Adjusting Cutting Height
Increase cutting height:
NPull lever (1) to rear of mower.
Reduce cutting height:
NPull lever (1) to front of mower.
The selected cutting height is shown.
Grass Box
0000-GXX-2645-A0
2
341
Adjusting Cutting Height
Setting Cutting
height
1 35 mm (1.4 in)
2 43 mm (1.7 in)
352mm(2in)
4 60 mm (2.4 in)
5 71 mm (2.8 in)
679mm(3in)
7 90 mm (3.5 in)
0000-GXX-2646-A0
1

RMA 510
English
13
Power supply (mains) voltage and
operating voltage must be the same.
NInsert the plug (1) in the wall
outlet (2).
A self test is performed after the charger
is connected to the power supply. During
this process, the light emitting diode (1)
on the charger lights up green for about
1 second, then red and goes off again.
A factory-new battery is not fully
charged.
Recommendation: Fully charge the
battery before using it for the first time.
NConnect the charger to the power
supply – mains voltage and
operating voltage of the charger
must be the same – see
"Connecting Charger to Power
Supply".
Operate the charger only in enclosed
and dry rooms at ambient temperatures
between +5°C to +40°C (+41°F to
+104°F)
Only charge dry batteries. Allow a damp
battery to dry before charging.
NPush the battery (1) into the
charger (2) until noticeable
resistance is felt – then push it as far
as stop.
The LED (3) on the charger comes on
when the battery is inserted – see "LED
on Charger"
Charging begins as soon as the
LEDs (4) on the battery glow green –
see "LEDs on Battery".
The charge time is dependent on a
number of factors, including battery
condition, ambient temperature, etc.,
and may therefore vary from the times
specified.
The battery heats up during operation in
the power tool. If a hot battery is inserted
in the charger, it may be necessary to
cool it down before charging. The
charging process begins only after the
battery has cooled down. The time
required for cooling may prolong the
charge time.
The battery and charger heat up during
the charging process.
AL 300, AL 500 Chargers
The AL 300 and AL 500 chargers are
equipped with a battery cooling fan
Connecting Charger to
Power Supply
3901BA015 KN
2
1
1
3901BA019 KN
Charging the Battery
2
3901BA009 KN
4
3901BA014 KN
3

RMA 510
English
14
AL 100 Charger
The AL 100 charger has no fan and
waits for the battery to cool down before
starting the charging process. The
battery is cooled by heat transfer to the
ambient air.
End of Charge
The charger switches itself off
automatically when the battery is fully
charged:
–LEDs on the battery go off.
–The LED on the charger goes off.
–The charger's fan is switched off (if
charger is so equipped)
Remove the fully charged battery from
the charger.
Four LEDs show the battery's state of
charge and any problems that occur in
the battery or machine.
NPress button (1) to activate the
display – the display goes off
automatically after 5 seconds.
The LEDs can glow or flash green or
red.
During charging
The LEDs glow continuously or flash to
indicate the progress of charge.
A green flashing LED indicates the
capacity that is currently being charged.
The LEDs on the battery go off
automatically when the charge process
is completed.
If the LEDs on the battery flash or glow
red – see "If the red LEDs glow
continuously / flash".
LEDs on Battery
LED glows continuously green.
LED flashes green.
LED glows continuously red.
LED flashes red.
1
3901BA010 KN
3901BA018 KN
80 - 100 %
60 - 80 %
40 - 60 %
20 - 40 %
0 - 20 %

RMA 510
English
15
During Operation
NPress button (1) to activate the
display – the display goes off
automatically after 5 seconds.
The green LEDs glow continuously or
flash to indicate the state of charge.
If the LEDs on the battery flash or glow
red – see "If the red LEDs glow
continuously / flash".
If the red LEDs glow continuously / flash
1
3901BA010 KN
3901BA016 KN
80 - 100 %
60 - 80 %
40 - 60 %
20 - 40 %
0 - 20 %
A 1 LED glows
continuously
red:
Battery is too hot
1) 2)/cold 1)
1) When charging: Charge process
starts automatically after the battery
has cooled down / warmed up.
2) During operation: Machine cuts out
– allow battery to cool down; it may
be necessary to take the battery out
of the machine for this purpose.
B 4 LEDs flash
red
Malfunction in
battery 3)
C 3 LEDs glow
continuously
red:
Machine is too hot
– allow it to cool
down.
D 3 LEDs flash
red
Malfunction in
machine 4)
3901BA041 KN
A
B
C
D
3) Electromagnetic problem or fault.
Take the battery out of the machine
tool and refit it. Switch on the
machine – if the LEDs continue to
flash, the battery is faulty and must
be replaced.
4) Electromagnetic problem or fault.
Take the battery out of the
machine. Use a blunt tool to
remove dirt from the contacts in the
battery compartment. Refit the
battery. Switch on the machine – if
the light emitting diodes still flash,
the machine is faulty and must be
checked by a servicing dealer –
STIHL recommends an authorized
STIHL servicing dealer.

RMA 510
English
16
The LED (1) on the charger may glow
continuously green or flash red.
Green continuous light ...
... indicates the following:
The battery
–is being charged
–is too hot and must cool down
before charging
See also "LEDs on battery".
The green LED on the charger goes off
as soon as the battery is fully charged.
Red flashing light ...
... may indicate the following:
–No electrical contact between
battery and charger – remove and
refit the battery
–Malfunction in battery – see also
"LEDs on Battery".
–Malfunction in charger – have
checked by a servicing dealer.
STIHL recommends an authorized
STIHL servicing dealer.
When the ECO mode is selected the
mower automatically reduces motor
RPM in situations where less power is
required. This increases energy
efficiency and the battery runtime.
NSwing the cover (1) forwards.
NMove the ECO switch (2) to H.
NClose the cover (1).
The cover must always be closed during
operation.
NSwing the cover (1) forwards.
NMove the ECO switch (2) to 0.
NClose the cover (1).
The cover must always be closed during
operation.
LED on Charger
1
3901BA019 KN
Switching On ECO Mode
1
2
0000-GXX-2647-A0
Switching Off ECO Mode
1
2
0000-GXX-2648-A0

RMA 510
English
17
A factory-new battery is not fully
charged.
Recommendation: Fully charge the
battery before using it for the first time.
Opening the Cover
NLift the cover (1) up and swing it
forwards as far as stop.
Fit the fuse key
The motor can be started only when the
fuse key is fitted.
NPush the fuse key (2) into the
socket (3) as far as stop.
Fitting the Battery
NInsert the battery (4) in the battery
compartment and push it home.
The battery engages in position.
Closing the Cover
NClose the cover (1).
The cover must always be closed during
operation.
Starting
Do not start the motor in high grass or in
the lowest setting since this makes
starting more difficult.
NPress in the switch lockout
button (5) with your right hand and
hold it there.
NPull the switch lever (6) towards the
handle with your left hand and hold
it until you hear an audible click.
NRelease the lockout button (5).
Switching On
1
0000-GXX-2649-A0
0000-GXX-2651-A0
2
3
4
0000-GXX-2652-A0
1
0000-GXX-2650-A0
0000-GXX-2653-A0
5
6

RMA 510
English
18
Releasing the Switch Lever
NTo switch off the motor, release the
switch lever (1) – the cutting blade
comes to a standstill after coasting
for a few seconds.
Remove the fuse key and the battery
from the machine during breaks and
after finishing work.
The coasting brake brings the cutting
blade to a standstill in less than
3 seconds after the switch lever is
released.
Opening the Cover
NLift the cover (2) up and swing it
forwards as far as stop.
Removing the Fuse Key
NPull the fuse key (3) out of the
socket (4).
Removing the Battery
NRemove the battery (5) vertically.
Closing the Cover
NClose the cover (2).
When the cordless lawn mower is not in
use, store it so that it does not endanger
others – remove the battery and the fuse
key from the machine.
Secure it against unauthorized use.
Switching Off
0000-GXX-2654-A0
1
2
0000-GXX-2826-A0
0000-GXX-2655-A0
3
4
5
0000-GXX-3126-A0
2
0000-GXX-2827-A0
