Stiga Park series Instruction manual

Workshop
manual
Park
2008-2015

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 1
1 General instructions
Contents in this chapter
General
This Workshop Manual is intended for GGP Park models 2008-2015 with steering chain or
steering wire. The GGP Park model 2015 with steering cylinder has a separate workshop
manual. The article numbers and product names are designated in the tables under
“Technical specification” at page 18.
This Manual do not cover repair instructions for the engines. Regarding engines, contact
the respective representative in the actual country.
This Manual and its specifications are valid for machines in their original design. In case of
modified or changed machine, i.e. the engine is replaced, the manual accordance is limited.
The manual is divided in the following chapters:
Chapter 1 is this chapter
Chapter 2 Chassis
Chapter 3 Steering
Chapter 4 Hydraulic system
Chapter 5 Belts
Chapter 6 Control Wires
Chapter 7 Electrical system
1.3 Unpacking and assembly......... 4
1.3.1 Unpacking.............................. 4
1.3.2 Battery .................................. 5
1.3.3 Final checks........................... 6
1.4 Service....................................... 7
1.4.1 Service times......................... 7
1.4.2 First Service........................... 8
1.4.3 Basic service.......................... 9
1.5 Engine - Transmission ............. 14
1.5.1 Engine oil and oil filter, interval16
1.5.2 Air filter, serviceinterval.......... 17
1.5.3 Transmissions........................ 17
1.6 Technical specifications .......... 18
1.6.1 Machines ............................... 18
1.6.2 General tightening torque...... 31
1.7 Instructions for use .................. 31
1.1 Introduction................................2
1.1.1 Responsibility declaration.......2
1.1.2 How this manual is used ........2
1.1.3 Abbreviations..........................2
1.2 Safety Precautions ....................2
1.2.1 Symbols and warnings...........3
1.2.2 Warm parts.............................3
1.2.3 Moving parts...........................3
1.2.4 Lifting and blocking up............3
1.2.5 Cleanliness.............................3
1.2.6 Tightening torque ...................3
1.2.7 Sharp edges...........................3
1.2.8 Replacement parts.................3
1.2.9 Inspection...............................3

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 2
1.1 Introduction
1.1.1 Responsibility declaration
In spite of the great care we have taken there may be errors in this publication.
The author cannot be made liable for incorrect or missing information.
GGP SE reserves the right to regularly change product specifications without prior notice.
All the information in this book is based on the information available at the time of
production. Illustrations and photographs may be arranged schematically, which implies
that one picture may cover several models and therefore not correspond exactly with all
models.
1.1.2 How this manual is used
To make this manual easy to understand we have divided the machine into its main
systems and components. These parts are now the different chapters in the book.
Each chapter is divided up into sections.
There is a quick-guide on the cover of this book, which refers to the different chapters. In
each chapter there is a detailed table of contents so that you can easily and quickly find
what you are looking for.
Always check that you are reading the right chapter for your particular machine before
starting the repair work.
1.1.3 Abbreviations
The following abbreviations are used in this manual:
HST Hydrostatic Transmission PTO Power Take Off
1.2 Safety Precautions
This manual has been written primarily for trained mechanics working in a well-equipped
workshop.
A basic knowledge of repairs, tools and repair instructions is, however, always a
prerequisite for first-rate results.
A qualified mechanic should always be consulted if the owner does not have sufficient
knowledge to carry out repairs.
During the warranty period all service must be carried out by an Authorised Workshop for
the warranty to be valid.
The following basic points should be observed if the machine is to function perfectly:
• Follow the service schedule.
• Be on the alert for sudden vibrations or abnormal noise to avoid major breakdowns.
• Always use Genuine Spare Parts
• Follow the descriptions in this manual carefully. Do not take any short cuts.

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 3
1.2.1 Symbols and general
warnings
Warning!
This symbol indicates a risk of
personal injury or damage if the
instructions are not followed.
Note!
Thistextindicatesariskofdamageto
the material or risk of unnecessarily
complicated work if the instructions
are not followed.
1.2.2 Warm parts
Please observe that engine and exhaust
system picks up a lot of heat during use.
This applies above all to the silencer of
machines equipped with catalytic
converter.
Toavoid injuries, allowthemachine to cool
before any kind of repairs are made to or
near parts of the engine or exhaust
system.
1.2.3 Moving parts
The machines are all equipped with v-belt
transmissions.Alwaysstoptheengineand
remove the starter key before inspections
or repairs are carried out.
Always use extreme caution when testing
systems with moving parts to avoid
injuries.
Always use Genuine Spare Parts during
service work.
1.2.4 Lifting and blocking up
Before work under the machine, always
make sure that lifting devices and jack-
stands are approved for the weight.
Work safe!
1.2.5 Cleanliness
Clean the machine before starting repairs.
Dirt that penetrates into sensitive
components can seriously influence the
service life of the machine.
1.2.6 Tightening torque
Unless otherwise stated the tightening
torque in the tables in the section
Technical specifications must be used for
thedifferentsizesof screws. Thisdoes not
refer to self-tapping screws, which are
mainly used for the assembly of body
parts.
1.2.7 Sharp edges
Watch out for sharp edges, especially
when working with the mower deck. The
blades can be very sharp. Always wear
gloves when working with the blades.
1.2.8 Replacement parts
Always use Genuine Spare Parts during
service work.
1.2.9 Inspection
Each part dismantled in conjunction with
service work must be inspected.
Examine for: wear, cracks, out of
roundness, straightness, dents,
discolouring, abnormal noise and
jamming.

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 4
1.3 Unpacking and assembly
Every GGP Park has undergone an extensive
control programme before delivery. The
machines are delivered as completely
assembled as possible.
Thanksto thisthe assemblyon delivery israpid
and easy.
The correct and careful assembly of the
machineondeliveryisasimplewayofensuring
satisfied customers!
Note!
The machine shall remain placed on the
pallet during the unpacking and
assembly.
1.3.1 Unpacking
Open up the crate and release the part as
follows:
1. Check the air pressure in the tyres. The
pressure is designated on the floor mat.
The air pressure in the tyres is of critical
importance for the performance and
handling of the machine. The correct air
pressure for mowing is 0.6 bar (9 psi) in the
front tyres, and 0.4 bar (6 psi) in the rear
tyres.
When using heavy accessories, e.g. snow
thrower, it may be necessary to increase the
pressure somewhat. However, the
maximum permitted pressure is always
0.8 bar (12 psi).
Too high pressure in the tyres leads to that
the machine drives poor due to:
• A small surface in contact to the ground.
• Hard tyre = less flexibility = self cleaning char-
acteristic deteriorate.
2. Remove the following parts from the
package and put them on the floor.
• The battery (some models).
• The steering wheel.
• The plastic bag, containing owners manuals,
information media and assembly screws.
Too high pressure Correct pressure

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 5
1.3.2 Battery
The battery is a valve regulated battery.
Load and assemble the battery, following the
instructions below.
The battery needs limited maintenance. Is has
no electrolyte levels or plugs.
Warning!
Do not wear rings, metallic bracelet,
chainround the neck orsimilar metal
objects when working with the
battery. It can cause short-circuit,
burns and fire.
Warning!
The battery must be fully charged be-
fore being used for the first time. The
battery must always be stored fully
charged. If the battery is stored while
discharged, serious damage will oc-
cur.
Charging with the engine
The battery can be charged using the engine’s
generator as follows:
1. Install the battery in the machine as shown
below.
2. Place the machine outdoors or install an
extraction device for the exhaust fumes.
3. Start the engine according to the
instructions in the user guide.
4. Allow the engine to run continuously for 45
minutes.
5. Stop the engine. The battery will now be
fully charged.
Storage
Thebatteryvoltageisnotallowedtodropunder
12,5 V during storage.
Make sure that the battery voltage always is
more than 12,5 during storage. If not, the
battery will be destroyed.
A
Charging using battery charger
When charging using a battery charger, a
battery charger with constant voltage
must be used.
Ordering number: 1136-0602-01.
Thebattery can bedamagedif astandard
type battery charger is used.
If the cables are disconnected/
connected in the wrong order,
there is a risk of a short-circuit
and damage to the battery.
If the cables are interchanged,
the generator and the battery
will be damaged.
Theenginemustnever bedriven
with the battery disconnected.
There is a risk of serious dam-
age to the generator and the
electrical system.

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 6
1.3.3 Final checks
Removing from pallet
All the above measures shall have been done with the machine standing on the pallet.
Now, loosen the remaining straps and roll off the machine from the pallet.
Fit and adjust accessories.
Test driving
Warning!
Do not drive without a work equipment (mover deck) attached. Risk for
turning over.
Drive the machine for a few minutes. Test all the functions. Pay special attention to the
safetyfunctions. If themachineis tobedeliveredwithmowerdeckor other accessories,
fit these before test driving the machine.
HST oil
Check the oil level in the HST’s expansion tank after test driving, and top up if
necessary.
Engine oil
Check the oil level in the engine and top up if necessary.
Steering chain / Steering wire
Check that the steering chain / steering wire is sufficiently taut. Adjust if necessary.
Miscellaneous
Give the machine a general inspection.
• Is the machine clean?
• Is there any oil leakage?
• Abnormal noise or rattle?
Receipt
By filling in the guarantee certificate you guarantee that the delivery service has been
correctly conducted.
Remember to make sure that the customer receives all the documentation when the
machine is collected / delivered.

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 7
1.4 Service
Every new machine is delivered with a service book. This service book is part of the
active post-market programme and shall be kept in a safe place during the entire
lifetime of the machine. Hand over the service book if the machine is sold in 2:nd
hand.
Service should generally be carried out at least every 50 operating hours (exception
of the first service), although in accordance with the conditions below.
There are three different grades of service events. Every service event consists of a
number of service points as described in the following paragraphs. Every service
point has a number which refer to a describing text after the schedules.
The grades of service events are:
• First service
• Intermediate service
• Basic service
Some service points do not coincide with the scheduled service intervals, but shall
beperformedinconnectionwithascheduled service when possible.E.g.someitems
shall be performed at every second service and some also between two services.
These service points are described with procedure and interval in the respective
“Instruction for use”.
Typical service points wich not coincide with scheduled service intervals are:
• Cleaning/changing air filter in some engines.
• Change of oil in some engines.
• Valve adjustments for some engines.
• Change of transmission oil in 4 WD machines.
• Change of spark plug in some engines.
1.4.1 Service times
Petrol driven machines
Diesel driven machines
Service Shall be performed
First service Within 5 hours of running
Intermediate service After the first 50 hours of running and then 50 hours after/before
every basic service.
Basic service Every 100 hours or every year, which first occur.
Service Shall be performed
First service Within 5 hours of running
Intermediate service After the first 100 hours of running and then 100 hours after/before
every basic service.
Basic service Every 200 hours or every year, which first occur.

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 8
1.4.2 First Service
This service is very important to safeguard the continuing function of the machine.
The first service includes the service points as per the table below.
1.5.2 Intermediate Service
The intermediate service is not as extensive as the Basic Service and can therefore be
conducted by the customer, or by an authorised Service Workshop. Regardless of who
conducts the service, it must be documented in the service book..
Number Service point
1Safety check.
2Tyres, air pressure.
3Engine oil and filter, see “Engine - Transmission” at
page 14.
4Oil level in HST, see “Engine - Transmission” at
page 14.
5Belt transmissions, check.
6Steering adjustment.
7Battery check.
21 Test driving.
Number Service point
1Safety check.
2Tyres, air pressure.
3Engine oil and filter, see “Engine - Transmission” at
page 14.
4Oil level in HST, see “Engine - Transmission” at
page 14.
6Steering adjustment.
9Air filter, cleaning.
10 Air filter catalytic converter, cleaning.
11 Cooling fins, clean.
12 Lubrication

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 9
1.4.3 Basic service
The Basic Service must always be conducted by an authorized Service Workshop,
and documented with a stamp in the service book.
*) See also “Safety check”.
**) See also the mover deck manual.
***) See the engine manual.
Number Service item
1Safety check
2Tires, air pressure
3Engine oil and filter, see “Engine - Transmission” at
page 14.
4Oil level in HST, see “Engine - Transmission” at
page 14.
5Belt transmissions, check
6Steering adjustment
7Battery check
8Air filter for engine, see “Engine - Transmission” at
page 14.
9Air filter catalytic converter, see “Engine -
Transmission” at page 14.
(Valid for machines with catalytic converter only)
10 Cooling fins, clean
11 Spark plug, check/replace
13 Transmission, check
14 Speed check
15 Bearing boxes, check**
16 Exhaust system, check*
17 Electrical system, check*
18 Mower deck, check**
19 Blades, check**
20 Power take-off, check
21 Control check
22 Valve play***
23 Test driving

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 10
1.5.4 Description of service points
1. Safety check
Check the safety functions. It is often appropriate to do this check in conjunction with
test driving. The following items shall be checked at all machines:
• No leakage on fuel lines and connections.
• No mechanical damages to the electrical cables. All insulation intact.
• The muffler shall be undamaged and its screws tightened. No exhaust leakage in
connections.
Machines with mechanic PTO
Test Status Action Result
1 Brake pedal not pressed.
PTO not activated. Turn the key and make a start attempt. Engine shall not start.
2 Brake pedal pressed.
PTO activated. Turn the key and make a start attempt. Engine shall not start.
3 Engine running.
PTO activated. Operator rises from the seat. Engine shall stop.
4 Engine running. Disconnectcablefromthe
shut off valve. Engine shall stopafterafew
minutes.
Machines with electric PTO
Test Status Action Result
1 Operator not sitting in seat.
Brake pedal pressed.
PTO not activated
Turn the key and make a
start attempt. Engine shall not start.
2 Brake pedal not pressed.
PTO not activated. Turn the key and make a start attempt. Engine shall not start.
3 Brake pedal pressed.
PTO magnetic clutch activated. Turn the key and make a start attempt. Engine shall not start.
4 Engine running.
PTO magnetic clutch activated. Operator rises from the seat. PTO magnetic clutch shall
disengage.
5 Cruise control activated.
(If applicable) Operator rises from the seat. Cruise control shall
disengage
6 Engine running. Disconnectcablefromthe
shut off valve. Engine shall stopafterafew
minutes.

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 11
Machines with electric PTO and hydraulic lift
Test Status Action Result
1 Operator not sitting in seat.
Brake pedal pressed.
PTO not activated
Turn the key and make a
start attempt. Engine shall not start.
2 Brake pedal not pressed.
PTO magnetic clutch not activated. Turn the key and make a start attempt. Engine shall not start.
3 Brake pedal pressed.
PTO magnetic clutch activated. Turn the key and make a start attempt. Engine shall not start.
4 Engine running.
PTO magnetic clutch activated. Operator rises from the seat. PTO magnetic clutch shall
disengage.
5 Hydraulic lift in neutral position. Attempt to engage the
PTO magnetic clutch. PTO magnetic clutch shall not
engage.
6 Engine running. Disconnectcablefromthe
shut off valve. Engine shall stopafterafew
minutes.

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 12
2 Tyres, air pressure
Checktheairpressure.Adjustif necessary.
The recommended air presure is
designated at the floor mat.
3 Engine oil and oil filter
See the “Instructions for use”, delivered
withthe machine or “Instructions for use” at
page 31.Seealsotheenginemanufacturer
manual.
4 Oil, HST
See section 4 or the “Instructions for use”,
delivered with the machine.
5 Belt transmissions, check
Check the condition of all the belts and belt
tensioners.
6 Steering, adjustment
See section 3.
7 Battery, check
Valid for dry charged batteries only.
Check the acid level. Top up with distilled
water if necessary. See page 6-7.
8 Engine air filter
See the “Instructions for use”, delivered
with the machine. See also the engine
manufacturer manual.
9 Catalytic converter air filter
See the “Instructions for use”, delivered
with the machine. See also the engine
manufacturer manual.
10 Cooling fins
Remove protective covers from the engine
and cleans between cooling fins. Use a
brush and compressed air. See also the
engine manufacturer manual.
11 Spark plug
Remove the spark plug (not valid for Pro
Diesel)andcleanitorreplaceifnecessary.
See also the engine manufacturer manual.
12 Lubrication
Lubricate the articulation point (4 nipples)
and all moving parts such as wires and
levers. See also the instruction manual,
delivered with the machine.
13 Transmission
Listen for abnormal noise.
Manual models: Check that the drive
functionworks properly at allgears. Adjust
if required.
14 Speed check
Check that the speed corresponds to the
specified value. See pages 18-22.
15 Bearing boxes
Listen for abnormal noise from the
bearings. Check that there are no wear,
play or seizure.
16 Exhaust system
Check that there are no cracks,leakage or
other damages. Check the attachment
devices. See also the engine
manufacturer manual.
17 Electrical system
Check that there are no damaged cables,
contacts or other devices. Check that all
cables are properly secured to the chassis
and with cable holders. Check that there is
no friction between cables and chassis,
which can result in cable damage and
short circuit.

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 13
18 Mower deck
Warning!
The blades are sharp. Always
wear gloves when working with
the blades to avoid injury.
Check if there are collision damages or
wear at the deck body and painting. Align,
repair and touch up the painting as
required.
Check the tightening of the bearing boxes
screws and tighten.
Rotate the blades and check the the shafts
are correct, not bent, no abnormal bearing
noise and no plays.
Check the belts and their tensions, see
section 4.
Check that the lifting mechanism moves
evenly, not jammed and no play and that it
locks in desired position.
Check the electrical function of the
electrikal mower lifter (if applicable).
Check the plastic guide bar between the
blades. Replace if required.
19 Blades
Warning!
The blades are sharp. Always
wear gloves when working with
the blades to avoid injury.
Check that the blades are sharp. Sharpen
as reqiured.
20 Power take-off (PTO)
Check that the magnetic clutch (if
applicable) engage the work equipment
rotation in the desired time and that it not
slips during normal load. Replace the
clutch if necessary.
Check that the power take-off belt (if
applicable) engage the work equipment
rotation in the desired time and that it not
slips during normal load. Adjust if
necessary. See section 4.
Check that the power take-off brake (if
applicable) brakes the rotation movement
in the desired time. Adjust if necessary.
See section 4.
21 Control check
Check that all controls function properly,
that there are no jammings or excessive
plays. Adjust if nesaccary. See section 5.
22 Valve play
See the engine manual regarding
procedure and interval.
23 Test driving
Drive the machine during a few minutes
and make the following attentions in
different speeds and turnings in right and
left. Check that all functions work evenly
and proper and without any abnormal
noise.
• Brake function
• Clutch function
•Powertake-off
• Steering
Check that there are no abnormal
vibrations.

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 14
1.5 Engine - Transmission
To find engine oil change interval, type of oil, air filter service interval, etc. for a
particular machine, first find the machine in the list below, read the engine type and go
to the actual engine in the following pages.
Art. Number Machine Engine
13-6002-XX Mountfield 4140H GGP TRE0701
13-6003-XX Mountfield 4155H B&S I/C series 15.5hp
13-6004-XX Mountfield 4155H 4WD B&S I/C series 15.5hp
13-6100-XX Park Silent/Compact Honda GXV390 16hp
13-6101-19 Park Compact 13 B&S 21 I/C 12.5 hp
13-6102-XX Park Compact 14
Castelgarden XK 140 HD
Béal Master MBF 13,5
Mountfield 4135H
B&S PowerBuilt AVS 13.5 hp
13-6103-XX Park Compact 16
Castelgarden XK 160 HD
Béal Master MBF 15,5
Mountfield 4155H
B&S PowerBuilt AVS 15.5 hp
13-6104-XX Park Compact 16 4WD
Castelgarden XK4 160 HD
Béal Master MBF 15,5
Mountfield 4155H 4WD
B&S PowerBuilt AVS 15.5 hp
13-6105-99 Mountfield XK 13 Engine B&S mod 21 I/C 21B80
13-6106-99 Mountfield XK 16 Engine B&S mod282H I/C
13-6107-99 Mountfield XK 16 4WD Engine B&S mod282H I/C
13-6109-XX Park Compact 14 STIGA WM 14
13-6111-61 OKAY Mcut 98-10/155 K4WD B&S Power Built, 4115 AVS
13-6116-XX Castelgarden XK 140 HD GGP TRE0701
13-6141-XX Park Unlimited 14 STIGA WM 14
13-6142-XX Park Unlimited Plus B&S Intek, 20 hp
13-6144-XX Park Silent Honda GCV 530 V-Twin, 16 hp
13-6175-26 Park Power 4WD B&S Vanguard V-Twin 20 hp
13-6176-16 Park Champion B&S Vanguard V-Twin 20hp
13-6177-XX Park Prestige 4WD B&S Intek 1-cyl.
13-6178-15 Park Residence 4WD B&S I/C, 15.5 hp
13-6178-16 Park Residence 4WD PowerBuilt AVS 15.5 hp
13-6179-04 Park Ranger Honda GCV 530 V-Twin, 16 hp
13-6179-05 Park Ranger Svan Honda GCV 530 2-cyl, 16 hp
13-6179-06 Park Ranger Svan Honda GCV 530 V-Twin
13-6180-XX Park Diesel Hatz 1B50
13-6181-34 Park Diesel 4WD Hatz 1B50
13-6182-14 Park Comfort B&S mod 282H I/C, 15.5 hp
13-6182-15 Park Comfort B&S I/C, 15.5 hp
13-6183-14 Park Royal Honda GCV 530 V-Twin
13-6184-XX Park President 14 B&S PowerBuilt AVS 13.5 hp
13-6185-XX Park Prestige 4WD Kohler Courage SV540, 18 hp

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 15
Art. Number Machine Engine
13-6189-XX Park Excellent 16 B&S Vanguard 16 hp 2-cyl
13-6193-XX Park Ranger B&S mod 282H I/C, 15.5 hp
13-6195-14 Park Fairway 18 Kohler Courage SV540, 18 hp
13-6196-25 Park Power 4WD B&S Intek series 20hp
13-6197-XX Castelgarden XKH4 165 HD Honda GCV530 16hp
13-6198-55 75 Years ltd version STIGA WM 14
13-6199-15 Park Residence 4WD Honda GCV 530 V-Twin
13-6241-XX Park Pro 16 4WD B&S Vanguard V-Twin
13-6241-XX Park Pro Svan 4WD Honda GXV 530 2-cyl
13-6242-64 Park Pro Bivoj 4WD Kohler Command Pro
13-6244-XX Park Pro 20 4WD B&S Vanguard V-Twin
13-6246-XX Park Pro 25 4WD Kohler Command Pro
13-6269-XX Park Pro 18 4WD B&S Vanguard 18 hp 2-cyl
13-6270-XX Park Pro 21 4WD B&S Vanguard 21 hp 2-cyl
13-6271-XX Park Pro 16 4WD B&S Vanguard 16 hp 2-cyl
13-6272-XX Park Pro Svan 4WD Honda GXV 530 2-cyl
13-6273-XX Park Pro 20 4WD B&S Vanguard V-Twin 20hp
13-6274-16 Park Pro 23 4WD B&S Vanguard V-Twin 23 hp
13-6275-16 Park Pro Silver Kohler Command Pro
13-6276-XX Park Pro 25 4WD Honda GXV 660 2-cyl
13-6310-XX Park Excellent 16, 620 W B&S Vanguard 16 hp 2-cyl
13-6311-XX Park Plus, Park 520 L B&S Intek, Series 4185
13-6312-XX Park Royal 4WD Honda GCV 530 2-cyl
13-6313-11 Park Excellent B&S Vanguard 20 hp 2-cyl
13-6314-11 Park Plus Unlimited B&S Intek, Series 4185
13-6317-XX Park 740 PWX B&S Vanguard 18 hp 2-cyl
13-6318-31 Park 520 DP Hatz 1B50V
13-6319-31 Park 520/540 DPX Hatz 1B50V
13-6320-11 Park 520 Anniversary B&S PowerBuilt AVS 15.5 hp
13-6372-11 Park Power 16 4WD B&S Vanguard 16 hp 2-cyl
13-6373-XX Park 740 WX, Park Royal 4WD B&S Vanguard 18 hp 2-cyl
13-6374-11 Park Champion 4WD B&S Intek, Series 4185
13-6375-11 Park Power 4WD B&S Vanguard 20hp
13-6377-XX Park Prestige 4WD B&S Intek, Series 4185
13-6378-XX Park Residence 4WD B&S Power Built
13-6379-XX(not -21) Park Ranger Svan Honda GCV 530 2-cyl
13-6379-21 Park Ranger B&S Power Built, Series 4155
13-6380-XX Park 620 PW B&S Vanguard 16 hp 2-cyl
13-6381-XX Park 540 LPX B&S Intek, Series 4185
13-6384-11 Park 123 B&S PowerBuilt AVS 13.5 hp
13-6384-12 Park 420 LM B&S PowerBuilt AVS 13.5 hp
2F6120520/S15 Park 320 M B&S PowerBuilt AVS 15.5 hp
2F6130520/S15 Park 340 MX B&S PowerBuilt AVS 15.5 hp
2F6220610/S15 Park 520 P B&S Intek, Series 4185

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 16
1.5.1 Engine oil and oil filter, service interval
Below is listed oil and filter data for the engines.
Regarding additional information about engines, contact the respective
representative in the actual country.
*) Metal filter, shall be cleaned and refitted after 1000 hours of operation.
**) Approximate value. The correct value is read at the dipstick max marking.
Art. Number Machine Engine
2F6220620/S15 Park 720 PW B&S Vanguard 18 hp 2-cyl
2F6220820/S15 Park 620 P B&S Intek, Series 5210
2F6230620/S15 Park 540 LX B&S Intek, Series 4185
2F6230820/S15 Park 640 PX B&S Intek, Series 5210
Oil and filter data Oil filter
change
interval
Oil
change
1:st time
Oil
change
interval
Vol.
without
filter
Vol.
with
filter
Oil
quality Oil grade
Engine
B&S 21 I/C 12.5 hp 5 h 50 h/12 m 1,6 L >SJ SAE 10W-30
B&S I/C, 15.5 hp 5 h 50 h/12 m 1,6 L >SJ SAE 10W-30
B&S Intek 1-cyl. 5 h 50 h/12 m 1,6 L >SJ SAE 10W-30
B&S Intek series 20hp 100 h 5 h 50 h/12 m 1,8 L 1,9 L >SJ SAE 10W-30
B&S Intek, 20 hp 100 h 5 h 50 h/12 m 1,8 L 1,9 L >SJ SAE 10W-30
B&S Intek, Series 4185 100 h 5 h 50 h/12 m - - >SJ SAE 10W-30
B&S mod 21 I/C 21B80 5 h 50 h/12 m 1,6 L >SJ SAE 10W-30
B&S mod 282H I/C, 15.5 hp 5 h 50 h/12 m 1,6 L >SJ SAE 10W-30
B&S mod282H I/C 5 h 50 h/12 m 1,6 L >SJ SAE 10W-30
B&S Power Built, 4115 AVS 5 h 50 h/12 m 1,6 L >SJ SAE 10W-30
B&S Power Built, 4155 AVS 5 h 50 h/12 m 1,4 L >SJ SAE 10W-30
B&S Power B, Series 3130 5 h 50 h/12 m 1,4 L >SJ SAE 10W-30
B&S Power B, Series 4115 5 h 50 h/12 m 1,6 L >SJ SAE 10W-30
B&S PowerBuilt AVS 15.5 hp 5 h 50 h/12 m 1,6 L >SJ SAE 10W-30
B&S Vanguard 16 hp 2-cyl 100 h 5 h 50 h/12 m 1,3 L 1,4 L >SJ SAE 10W-30
B&S Vanguard 18 hp 2-cyl 100 h 5 h 50 h/12 m 1,3 L 1,4 L >SJ SAE 10W-30
B&S Vanguard 20 hp 2-cyl 100 h 5 h 50 h/12 m 1,3 L 1,4 L >SJ SAE 10W-30
B&S Vanguard 21hp 2-cyl 100 h 5 h 50 h/12 m 1,3 L 1,4 L >SJ SAE 10W-30
GGP TRE0701 5 h 100 h 1,2 L SF-SG SAE 30
Hatz 1B50 *) 250 h/12 m 1,5 L**) 1,7 L >API CD SAE 10W-40
Hatz 1B50V *) 250 h/12 m 1,5 L**) >API CD SAE 10W-40
Honda GCV 530 2-cyl 100 h/6 m 20 h/1 m 100 h/6 m 0,9 1,05 >SJ SAE 10W-30
Honda GXV 390 1-cyl 20 h/1 m 100 h/6 m 1,1 L >SJ SAE 10W-30
Honda GXV 530 2-cyl 100 h/6 m 20 h/1 m 100 h/6 m 0,9 1,05 >SJ SAE 10W-30
Honda GXV 660 2-cyl 200 h 20 h/1 m 100 h/6 m SAE 10W-30
Kohler Command Pro 200 h/12m 100 h/12 m 1,9 L 2,0 L >SF SAE 10W-30
Kohler Cour. SV540, 18 hp 100 h/12m 100 h/12 m 2,0 L 2,1 L >SF SAE 10W-30
PowerBuilt AVS 15.5 hp 5 h 50 h/12 m 1,6 L >SJ SAE 10W-30
STIGA WM 14 5 h 100 h 1,2 L SF-SG SAE 30

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 17
1.5.2 Air filter, serviceinterval
Honda engines
Cleaning of the prefilter (plastic):Every 3:rd month or every 50 hours of operation.
Replacing of the main filter (paper):Every 12:th month or every 200 hours of operation.
Briggs & Stratton engines
Cleaning/replacing of the prefilter (plastic):Every 25 hours of operation.
Cleaning/replacing of the main filter (paper):Every 100 hours of operation.
Kohler engines
Cleaning of the prefilter (plastic):Every 25 hours of operation.
Replacing of the main filter (paper):Every 100 hours of operation.
GGP engines
Checking the filter:Every 5 hours of operation or every day.
Cleaning/replacing of the filter:Every 12:th month or every 25 hours of operation.
1.5.3 Transmissions
Below is listed oil and filter data for the transmissions.
Machine Transmission Oil and filter change interval Oil volume Oil grade
Description Number 1:st time Thereafter
Park 2WD K46 1137-0123-01 -- -SAE 10W-30
(20W-50)
ParkCompact
and CH 4WD
without servo
K574G 1137-0124-01 5 h 200 h 3,5 Liter Synthetic oil
5W-50
KTM10M 1134-6029-01
Park CH 2WD
with servo K57-V 1137-0126-01 1,3 Liter Synthetic oil
5W-50
Park CH 4WD
with servo K574F
KTM10M 1137-0125-01 1134-6029-01 3,6 Liter Synthetic oil 5W-50
Park Pro 4WD KPL 10ALP 1134-5700-01 5 h 200 h 4,2 Liter Synthetic oil
5W-50
KTM10G 1134-5701-01
KTM10F 1134-5702-01
KTM-13 118475000/0 5 h 200 h 4,7 Liter Synthetic oil
5W-50

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 18
1.6 Technical specifications
1.6.1 Machines
2008 Models
COMPACT 13-6101-19 COMPACT 14 13-6102-19 COMPACT 16 13-6103-19 COMPACT 16 4WD 13-6104-19 UNLIMITED 14 13-6141-54 UNLIMITED PLUS 13-6142-64 PRESIDENT 14 13-6184-04 RANGER 13-6193-04 RANGER 13-6179-04 FAIRWAY 18 13-6195-14 EXCELLENT 16 13-6189-04 COMFORT 13-6182-14 ROYAL 13-6183-14 PRESTIGE 4WD 13-6185-14 DIESEL 13-6180-34 DIESEL 4WD 13-6181-34 PRO 16 4WD 13-6241-14 PRO BIVOJ 4WD 13-6242-64 PRO SILVER 13-6245-64 PRO SVAN 4WD 13-6241-24 PRO 20 4WD 13-6244-14 PRO 25 4WD 13-6246-14
Engines
B&S mod 21 I/C
X
B&S mod 21 I/C
X
B&S mod 21 I/C
X
B&S mod282H
X
B&S mod282H
X
X
X
B&S Inte
k
X
Stiga WM 14
X
Honda GCV530
X
X
Honda GXV530
X
B&S Vanguard
X
X
B&S Vanguard
X
X
Kohler Courage
X
X
Kohler Command
X
X
Hatz B50
X
X
Power Hp 12.5 13.5 15.5 15.5 14 20 13.5 15.5 16 18 16 15.5 16 18 12 12 16 25 20 16 20 25
Cylinders 1111121121212111222222
Petrol tank
Petrol tank 2 6 litres X X X X
Petrol tank 3 14 litres XXXXXX
Petrol tank 4 12 litres X X X XXXXXXXXX
Transmissions
DANA X
TTC K46 HST X X X X X X X X X X
TTC KTM -7 4WD X X X
TTC KTM -7 2WD X X
TTC KTM -10 4WD XXXXXX
Wheels
16x6.00-8 X X
16x7.50-8 X X X X X XXXXXXXXX
17x8.00-8 XXXXXX
Steering
Cable/Chain X X X X X X X
Chain/Chain XXXXXXXXXXXXXXX
Bushings on steering rod X X X X X X X X X X X X X
Ball bearings on steering rod XXXXXXX
Mechanical servo X X X X X X X X X X X
Hydraulic servo X X X X X X
Not adj. steering column X X X X
Adj. steering column X X X XXXXXXXXXXXXXXX
Spinner on steering wheel X X X X X X X X X X X
Seat
Sliding seat X X X XXXXXXXXXXXXXXX
Arm rests X XXX
Suspension: Pivot spring X X X X X X X XXXXXXXX
Suspension: Vertical spring XXXXXXX
Controls
Mechanical PTO X X X X X X X XXXXXXXX
Electrical PTO (80 lb.ft) XX XXX
Electrical PTO (120 lb.ft) XX
Mech. lift of att. (foot ped.) X X X X X X X XXXXXXXX XXX
Adjustable drive pedal X X XXXXXXXXXXXXXXX
Hydraulic lift of attachment X XXX
Cruise control XXXXXXX
Head light X X X XXXXXXXXXXXXXXX
Hour meter X X X XXXXXXXXXXXXXXX
Electrical adj. mower deck X X X X XXXXXXXXXX
Wire prepared for rear rake XXXXXXX
Switch for rear rake on panel XXXXXXX
Wire prep. for sand spreader XXXXXXX
Switch sand spreader on panel XXXXXXX
Separat Choke
X
X
X
X
X
X
X
X
X
X
X
X

Edition Manual Chapter Page
2014-09-22 Workshop Manual, GGP Park 1 General instructions 19
2009 Models
COMPACT 14 13-6109-20 COMPACT 16 13-6103-20 COMPACT 16 4WD COMFORT 13-6182-15 RESIDENCE 4WD 13-6178-15 RANGER SVAN 13-6179-05 PRESTIGE 4WD 13-6185-15 DIESEL 13-6180-35 UNLIMITED 14 13-6141-55 SILENT 13-6144-75 EXCELLENT 16 13-6189-05 75 YERAS LIM ED 13-6198-55 RANGER 13-6193-05 PRESIDENT 14 13-6184-05 POWER 4WD 13-6196-25 RESIDENCE 4WD 13-6199-15 UNLIMITED PLUS 13-6142-65 PRO 16 4WD 13-6241-15 PRO SVAN 4WD 13-6241-25 PRO 20 4WD 13-6244-15 PRO 25 4WD 13-6246-15
Engines
B&S I/C series X
B&S I/C X
B&S I/C X X X X
GGP TRE0701, WM14 X
GGP TRE0701, WM14 X X
GGP TRE0701, WM14
Honda GCV53
0
XX X
Honda GXV53
0
X
B&S Intek series XX
B&S Vanguar
d
XX
B&S Vanguar
d
X
Kohler Courag
e
X
Kohler Comman
d
X
Hatz B50 X
Power H
p
- 15.5 15.5 15.5 15.5 16 18 12 - 16 16 - 15.5 13.5 20 16 20 16 16 20 25
Cylinder
s
111112211221112222222
Petrol tan
k
6 litres X X X
14 litres XXXX
12 litres XXXXXXXXXXXXXX
Transmission
s
TTC K46 HST X X X XXXXX X X
TTC KTM -7 4WD X X X X X
TTC KTM -7 2WD X X
TTC KTM -10 4WD XXXX
Wheels
16x6.00-8 X
16x7.50-8 XXXXXXXXXXXXXXXX
17x8.00-8 XXXX
Steering
Cable/Chain X X X X X X X
Chain/Chain XXXXX X X XXXXXXX
Bushings steering rod XXXX XXXXXX XX X
Ball bearings steering rod X X X X XXXX
Mechanical servo X X X X X X X X X X
Hydraulic servo X X X X X X X
Not adj. steering column X X X X X
Adj. steering column XXXXXX X XXXXXXXXX
Sea
t
Sliding seat XXXXXXXXXXXXXXXXXX
Arm rests XXX
Suspension: Pivot spring XXXXXXXXXXXXXXXXX
Suspension: Vertical spring XXXX
Controls
Mechanical PTO XXXXXXXXXXXXXXXXX
Electrical PTO (80 lb.ft) XXX
Electrical PTO (120 lb.ft) X
Mech. lift of att. (foot ped.) XXXXXXXXXXXXXXXXXX
Adjustable drive pedal XXXXXX XXX XXXXXXX
Hydraulic lift of attachment XXX
Cruise control XXXX
Head light XXXXXX X XXXXXXXXX
Hour meter XXXXXXXXXXXXXXXXXX
Electrical adj. mower deck XXXXX X X XX XXXX
Wire prepared for rear rake XXXX
Switch for rear rake on panel XXXX
Wire prep. for sand spreader XXXX
Switch sand spreader on panel XXXX
Separat Chok
e
XX XX XXXXXXX
