INSTALLATION INSTRUCTION MANUAL
LED FLOOD LIGHT, 100-277VAC
MODELS:
SL923FLF-15W; SL923FLF-30W; SL923FLF-50W; SL923FLF-80W; SL923FLF-100W; SL923FLF-150W;
SL923FLF-300W
Model number parameter list:
1. Introduction
 This LED Flood light uses the latest in solid state lighting technology for long life, low maintenance, and high
efficiency.
 An internal power-factor-corrected switch-mode supply allows it to be used from any nominal 100-277V, 60Hz AC supply
without any variation in light output.
Suitable for use in the following locations:
• Ambient Temp: -20~+40°C
• Wet Locations
Note: Save these instructions for future reference.
2. Installation
Model
Input Voltage
Power
Factor
Watt
Input Current
Weight
SL923FLF-15W
100-277VAC
>.9
15W
0.18A
0.62kg
SL923FLF-30W
100-277VAC
30W
0.35A
1.3kg
SL923FLF-50W
100-277VAC
50W
0.6A
1.9kg
SL923FLF-80W
100-277VAC
80W
0.85A
5kg
SL923FLF-100W
100-277VAC
100W
1.2A
5.4kg
SL923FLF-150W
100-277VAC
150W
1.8A
5.4kg
SL923FLF-300W
100-277VAC
300W
3.5A
10.4kg
Warning:
To avoid the risk of fire, explosion, or electric shock, this product should be
installed, inspected, and maintained by a qualified electrician only, in accordance
with all applicable electrical codes.

© 2016 Straits Lighting Company | www.straitslighting.com | Detroit | Phone: 855 - 875 - 2533 | Fax: 248 - 671 - 0624
Installation Steps:
Refer to the following diagrams when installing the fixture. There are nine installation methods, which depending on your model
and hardware accessories.
1. Directly fix to mounting surface
SL923FLF-15W
SL923FLF-30W
SL923FLF-50W
SL923FLF-80W
SL923FLF-100W
SL923FLF-150W
SL923FLF-300W
Warning:
To avoid electric shock: Be certain electrical power is OFF before and during
installation and maintenance. Luminaire must be connected to a wiring system
with an equipment-grounding conductor.
Warning:
To avoid explosion:
•Make sure the supply voltage is the same as the rated luminaire voltage.
•Do not install where the marked operating temperatures exceed the ignition
temperature of the hazardous atmosphere.
•Do not operate in ambient temperatures above those indicated on the luminaire
nameplate.
•Keep lens tightly closed when in operation.
•For supply connections use wire rated for at least 90°C

© 2016 Straits Lighting Company | www.straitslighting.com | Detroit | Phone: 855 - 875 - 2533 | Fax: 248 - 671 - 0624
1. Use expansion bolts to secure the fixture on mounting surface.
2. Keep enough wire length to ensure adjusting angle unhindered.
Connect wires into wiring terminal; white wire to “Neutral” terminal, black wire to “Live” terminal, green wire to “Ground”
terminal; and fix them with screws.
2. Mounting with a knuckle for Models: SL923FLF-15W; SL923FLF-30W; SL923FLF-50W.
Secure service wire or conduit to the wiring compartment cover with 1/2” connector (not provided). Connect white fixture
wire to white supply wire, black fixture wire to black supply wire. Service ground should be attached to green ground screw
provided. Ground must be properly attached to avoid the risk of electrical shock. Use wire nuts, crimp-on lugs, or other
approved devices to connect all wires, make sure connections are secure and that no loose wire strands are sticking out of
connectors. Secure wiring compartment cover to fixture. With black and white connections inside the wiring compartment.
Use UL and CUL Listed flexible steel waterproof conduit in trade sizes 1/2 and UL and CUL Listed Water-proof outlet box
cove.
3. Mounting with a Slipfitter for Models:SL923FLF-80W; SL923FLF-100W; SL923FLF-150W; SL923FLF-300W.
Step 1
Adjust the fixture orientation by turning the bolt. In the above
photo for the rocker installation hole, and for the sensor
installation use the hole in the bottom.
Step 2
Please use a post of diameter 2.36” for mounting,
and tighten with screws. You can open the side cover
from the side connection

© 2016 Straits Lighting Company | www.straitslighting.com | Detroit | Phone: 855 - 875 - 2533 | Fax: 248 - 671 - 0624
4. Mounting with Wall Mount for Models: SL923FLF-30W; SL923FLF-50W; SL923FLF-80W; SL923FLF-100W; SL923FLF-150W.
Wall mounting method: first a hanging plate is installed in the UL junction box, and then through the arm
seat tube connector with teeth.
5. Mounting with a Trunnion for Models: SL923FLF-80W; SL923FLF-100W; SL923FLF-150W; SL923FLF-300W.
Step 1
Please drill the holes on the square pole according to the
size above.
Step 2
Adjust the fixture to an opposite orientation, tighten the
screws.
6. Mounting with SP for models: SL923FLF-50W; SL923FLF-80W; SL923FLF-100W; SL923FLF-150W; SL923FLF-300W.
Please use a post of diameter 2.36＂for mounting. Street lamp installation: the lamp set on the lamp post, and then tighten the
two locking nuts.
7. Lifting method of mining lamp: SL923FLF-80W; SL923FLF-100W; SL923FLF-150W; SL923FLF-300W.
Use 4 screws to fix 2 wire ropes from the side to the radiator.
Then put the lamp and lamp up.

© 2016 Straits Lighting Company | www.straitslighting.com | Detroit | Phone: 855 - 875 - 2533 | Fax: 248 - 671 - 0624
8. Mounting with Arm for Models: SL923FLF-80W; SL923FLF-100W; SL923FLF-150W; SL923FLF-300W.
Directly with the screw on the lamp post. In the above straight arm has a reserved light installation hole, for the sensor installation
hole in the bottom. You can open the side cover from the side connection.
9. Wall mounted installation SL923FLF-80W; SL923FLF-100W; SL923FLF-150W;
The mounting method of the straight arm is added to a wall mounted fixing plate, and the fixing plate is mounted on the wall, and
the fixing plate is fixed by a nut.
After installation, please
Check whether the lighting fixture is firmly in place.
Check whether wires are connected correctly.
Finally, turn on the power, and check if the lighting fixture works well. If not, please turn off the power and
contact with local dealer.
