Struers 05766116 User manual

Cooling unit pumps
Instruction Manual
Original Instructions
Doc. no.: 15767026-02_A_en-us
Date of release: 2022.12.01

Copyright
The contents of this manual are the property of Struers ApS. Reproduction of
any part of this manual without the written permission of Struers ApS is not
allowed.
All rights reserved. © Struers ApS 2022.12.01.
2 Cooling unit pumps

Table of Contents
1 About this manual 4
2 Safety 4
2.1 Intended use 4
2.2 Device description 4
2.3 Cooling unit pumpssafety precautions 5
2.3.1 Read carefully before use 5
2.4 Safety messages 6
2.5 Safety messages in this manual 7
3 Transport and storage 8
3.1 Transport 8
3.2 Long-term storage or shipping 8
4 Installation 9
4.1 Unpack the machine 9
4.2 Check the packing list 9
5 Power supply 9
6 The recirculation pump 10
7 Maintenance and service 10
7.1 General cleaning 11
7.2 Service and repair 11
7.3 Disposal 12
8 Technical data 13
8.1 Technical data 13
8.2 Legal and regulatory information 13
9 Manufacturer 14
Declaration of Incorporation of Partly Completed
Machinery 15
Cooling unit pumps 3

1 About this manual
Instruction Manuals
Struers equipment must only be used in connection with and as described in the
Instruction Manual supplied with the equipment.
Note
Read the instruction manual carefully before use.
Note
If you wish to view specific information in detail, see the online
version of this manual.
2 Safety
2.1 Intended use
The pumps are intended for use with Struers cooling systems for recirculation of
cooling fluid. The machine is designed for use with Struers cooling systems.
The machine is for use in a professional working environment (e.g. a
materialographic laboratory).The machine must be operated only by
skilled/trained personnel.
Do not use the machine for the
following
Pumping of any type of explosive
and/or flammable material, or
materials which are not stable during
machining, heating or pressure.
Furthermore, the machine must not be
used with consumables (cutting fluids)
that are not compliant with function
and materials of the pump.
Model Cooling unit pumps
2.2 Device description
The pump is a machine used for recirculation of cooling fluid.
The pump is controlled via a Cooli-1 control box, which activates and stops the
pump. This means that it starts and stops based on the power output from the
Cooli-1 control box, and is on stand-by when circulation is not required.
4 Cooling unit pumps
1 About this manual

If the Emergency stop is activated on the main machine, the Cooli-1 pump
also stops.
2.3 Cooling unit pumpssafety precautions
2.3.1 Read carefully before use
1. Ignoring this information and mishandling of the equipment can lead to
severe bodily injuries and material damage.
2. The machine must be installed in compliance with local safety
regulations. All functions on the machine and any connected equipment
must be in working order.
3. The operator must read the safety precautions and Instruction Manual, as
well as relevant sections of the manuals for any connected equipment
and accessories.
4. Only use original Struers consumables as this ensures maximum safety
and prolongs the machine's lifetime.
5. When working with cooling fluid always observe the safety regulations for
handling, mixing, filling, emptying and disposing of the cooling fluid
additive. Never use flammable cooling fluid. Note that the cooling fluid
can be hot and must therefore be handled with care.
6. Always wear protective gloves and safety goggles when you clean and fill
up the tank.
7. The recirculation pump must be disconnected from the electrical power
supply before it can be removed from the cooling unit.
8. All safety functions must be intact and in working order. If they are not,
they must be replaced or repaired before the machine can be used.
9. Always use the handle to close the cover.
10. Do not insert your hands through the openings into the water inlet ducts
on the cover.
11. Cooling fluid can be slippery - therefore always keep the area around the
tank clean.
12. If you observe malfunctions or hear unusual noises, switch off the
machine and call technical service.
13. In case of fire, alert bystanders and the fire brigade. Disconnect the
electrical power supply. Use a powder fire extinguisher. Do not use water.
14. Always switch off the electrical power supply and remove the plug or
power cable before dismantling the machine or installing additional
components.
2 Safety
Cooling unit pumps 5

15. The machine must be disconnected from the electrical power supply before
any service.
16. Struers equipment must only be used in connection with and as described in
the Instruction Manual supplied with the equipment.
17. If the equipment is subjected to misuse, incorrect installation, alteration,
neglect, accident or incorrect repair, Struers will accept no responsibility for
damage to the user or the equipment.
18. Dismantling of any part of the equipment, during service or repair, should
always be performed by a qualified technician (electromechanical, electronic,
mechanical, pneumatic, etc.).
2.4 Safety messages
Struers uses the following signs to indicate potential hazards.
ELECTRICAL HAZARD
This sign indicates an electrical hazard which, if not avoided, will
result in death or serious injury.
DANGER
This sign indicates a hazard with a high level of risk which, if not
avoided, will result in death or serious injury.
WARNING
This sign indicates a hazard with a medium level of risk which, if not
avoided, could result in death or serious injury.
CAUTION
This sign indicates a hazard with a low level of risk which, if not
avoided, could result in minor or moderate injury.
CRUSHING HAZARD
This sign indicates a crushing hazard which, if not avoided, could
result in minor, moderate or serious injury.
HEAT HAZARD
This sign indicates a heat hazard which, if not avoided, can
result in minor, moderate or serious injury.
6 Cooling unit pumps
2 Safety

General messages
Note
This sign indicates that there is a risk of damage to property, or a
need to proceed with special care.
Hint
This sign indicates that additional information and hints are
available.
2.5 Safety messages in this manual
WARNING
Struers equipment must only be used in connection with and as
described in the Instruction Manual supplied with the equipment.
WARNING
Switch off the machine, disconnect the electrical power cable
before you dismantle the machine or install additional
components.
ELECTRICAL HAZARD
Switch off the electrical power supply before installing electrical
equipment.
The machine must be earthed (grounded).
Make sure that the actual electrical power supply voltage
corresponds to the voltage stated on the type plate of the
machine.
Incorrect voltage can damage the electrical circuit.
WARNING
Do not use the machine with defective safety devices.
Contact Struers Service.
WARNING
Safety critical components must be replaced after a maximum
lifetime of 20 years.
Contact Struers Service.
2 Safety
Cooling unit pumps 7

3 Transport and storage
If, at any time after the installation, you have to move the unit or place it in storage,
there is a number of guidelines we recommend that you follow.
• Package the unit securely before transportation.
Insufficient packaging could cause damage to the unit and will void the
warranty. Contact Struers Service.
• We recommend that you keep all original packaging and fittings for future
use.
3.1 Transport
• Clean and dry the pump.
• Disconnect the pump from the control unit.
• Disconnect the water inlet and the water outlet.
3.2 Long-term storage or shipping
Note
We recommend that you keep all original packaging and fittings for
future use.
• Disconnect the control unit from the electrical power supply.
• Disconnect the water inlet and the water outlet.
• Clean the machine and all accessories thoroughly.
• Remove the control unit, the pump and the water level gauge. Place the items
in a box.
• Place the box in the tank.
• Build a case around the machine.
• To keep the machine dry, plastic-wrap the machine and place a bag of
desiccant (silica gel) in the case.
• Place a lid on the case.
At the new location
At the new location, make sure that the facilities required are in place.
8 Cooling unit pumps
3 Transport and storage

4 Installation
4.1 Unpack the machine
Note
We recommend that you keep all original packaging and fittings
for future use.
1. Remove the transport case.
2. Remove the plastic wrapping.
3. Lift off the pump.
4.2 Check the packing list
Optional accessories may be included in the packing box.
The packing box contains the following items:
Pcs. Description
1 Recirculation pump
1 Gekka connection with pressurized hose
1 Instruction Manual set
The pump is available in the following variants:
Small pump 05766116, 05766123, 05766216, 05766122,
05766124
Large pump 05766016, 05766023, 05766022, 05766024
Large pump (long) 05765016, 05765023, 05765022. 05765024
5 Power supply
ELECTRICAL HAZARD
The machine must be earthed (grounded).
Switch off the electrical power supply before installing electrical
equipment.
Make sure that the actual electrical power supply voltage
corresponds to the voltage stated on the type plate of the
machine.
Incorrect voltage can damage the electrical circuit.
4 Installation
Cooling unit pumps 9

Power socket
The electrical power supply socket must be easy to access.
Note
The equipment is shipped with 2 types of electrical power cables. If
the plug supplied on these cables is not approved in your country, the
plug must be replaced with an approved plug.
6 The recirculation pump
• Mount the recirculation pump on the connection for the pump.
Adapter ring
• A small pump: use the adapter ring to decrease the diameter of the
connection.
• A large pump: remove the adapter ring to increase the diameter of the
connection.
Magnetic filter
• Mount the magnetic filter in the hole. See the section "Assembling the cooling
unit" in the Cooli System Instruction Manual.
Water level gauge
• Mount the water level indicator in the hole. See the section "Assembling the
cooling unit" in the Cooli System Instruction Manual.
7 Maintenance and service
Proper maintenance is required to achieve the maximum up-time and operating
lifetime of the machine. Maintenance is important in ensuring continued safe
operation of your machine.
The maintenance procedures described in this section must be carried out by
skilled or trained personnel.
Safety Related Parts of the Control System (SRP/CS)
For specific safety related parts, see the section "Safety Related Parts of the
Control System (SRP/CS)" in the section "Technical data" in this manual.
10 Cooling unit pumps
6 The recirculation pump

Technical questions and spare parts
If you have technical questions or when you order spare parts, state serial
number and voltage/frequency. The serial number and the voltage are stated
on the type plate of the machine.
7.1 General cleaning
To ensure a longer lifetime for your machine, Struers strongly recommends
regular cleaning.
Note
Disconnect the machine from the power supply before cleaning
it.
If the machine is not to be used for a longer period of time
• Clean the machine and all accessories thoroughly.
7.2 Service and repair
We recommend that a regular service check be carried out yearly or after
every 1500 hours of use.
When the machine is started up, the display shows information about total
operation time and the machines service information.
After 1500 hours of operation time, the display will show a message
reminding the user that a service check should be scheduled.
Note
Service must only be performed by a Struers engineer or a
qualified technician (electromechanical, electronic, mechanical,
pneumatic, etc.).
Contact Struers Service.
Service check
We offer a range of comprehensive maintenance plans to suit the
requirements of our customers. This range of services is called
ServiceGuard.
The maintenance plans include equipment inspection, replacement of wear
parts, adjustments/calibration for optimal operation, and a final functional test.
7 Maintenance and service
Cooling unit pumps 11

7.3 Disposal
Equipment marked with a WEEE symbol contains electrical
and electronic components and must not be disposed of as
general waste.
Contact your local authorities for information on the correct
method of disposal in accordance with national legislation.
For disposal of consumables and recirculation fluid, follow
local regulations.
Note
Dispose of swarf according to the current local safety regulations for
handling and disposal of swarf and cooling fluid additive.
Note
The cooling fluid contains additive and cutting swarf and may not be
disposed of into a main drain. Cooling fluid must be disposed of in
compliance with local safety regulations.
Depending on which metals are being cut, it is possible that the combination of the
metallic swarf (cutting debris) from metals with a large difference in electrode-
positivity (a large distance apart in the electrochemical series), could result in
exothermic reactions when ‘favorable’ conditions are present.
Always bear in mind which metals you cut and the amount of swarf the cutting
produces. Some combinations of metals can result in exothermic reactions if a
large amount of swarf is collected during cutting.
Examples:
Aluminum and Copper
Zinc and Copper
12 Cooling unit pumps
7 Maintenance and service

8 Technical data
8.1 Technical data
Electrical data
Small
pump
1 x
100V/50
Hz
1 x 100-
120V/60
Hz
1 x 100-
120V/50/6
0Hz
1 x 220-
240V/50
Hz
1 x 220-
240V/60
Hz
Power
consump
tion
120 W 120 W 120 W 90 W 90 W
Current,
nominal
load
1.5 A 1.7 A 1.8 A 0.7 A 0.87 A
Current,
maximum
load
3 A 3.4 A 3.6 A 1.4 A 1.74 A
Electrical data
Large
pump/large
pump, long
1 x
100V/50Hz
1 x 100-
120V/60Hz
1 x 220-
240V/50Hz
1 x 220-
240V/60Hz
Power
consumption
550 W 550 W 550 W 550 W
Current,
nominal load
8.6 A 8.5 A 4.6 A 4.5 A
Current,
maximum
load
17.2 A 17 A 9.2 A 9 A
8.2 Legal and regulatory information
FCC notice
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
8 Technical data
Cooling unit pumps 13

frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
9 Manufacturer
Struers ApS
Pederstrupvej 84
DK-2750 Ballerup, Denmark
Telephone: [phone]
Fax: [phone]
www.struers.com
Responsibility of the manufacturer
The following restrictions should be observed, as violation of the restrictions may
cause cancellation of Struers legal obligations.
The manufacturer assumes no responsibility for errors in the text and/or
illustrations in this manual. The information in this manual is subject to change
without notice. The manual may mention accessories or parts not included in the
supplied version of the equipment.
The manufacturer is to be considered responsible for effects on safety, reliability,
and performance of the equipment only if the equipment is used, serviced, and
maintained in accordance with the instructions for use.
14 Cooling unit pumps
9 Manufacturer

Struers ApS
Pederstrupvej 84
DK-2750 Ballerup, Denmark
Based on: 15767902 B
Declaration of Incorporation of Partly Completed Machinery
Manufacturer Struers ApS • Pederstrupvej 84 • DK-2750 Ballerup • Denmark
Name Cooling unit pumps
Model N/A
Function Circulation of cooling water through a filter, magnetic or static or both
Type N/A
Cat. no. 05766116 05766123 05766216 05766122 05766124, 05766016 05766023
05766022 05766024, 05765016 05765023 05765022 05765024
In combination with:
05761116, 05766906 05766905 05766929 05766930 05766931
The above listed machinery is only intended to
be used with:
And shall not be put into service until the final
machinery into which it is to be incorporated
has been declared in conformity with this
regulation, where appropriate.
Struers machinery, cooling units and consumables
Serial no.
Module H, according to global approach EU
We declare that the product mentioned is in conformity with the following legislation, directives and standards:
2006/42/EC EN 60204-1:2018
2011/65/EU EN 63000:2018
Additional standards NFPA 79, FCC 47 CFR Part 15 Subpart B
Authorized to compile technical file/
Authorized signatory
Date: [Release date]
15/16

en For translations see
www.struers.com/Library
