UC-15I
Service Manual

Page 2
Installation Information Model UC-15I (Undercounter Ice Machine)
2-2
#7012423 - Revision B - May, 2011
PRE-INSTALLATION CONSIDERATIONS
To properly make and store ice, the model UC-15I:
• Must have an open site (gravity) drain available
(applies to models without a drain pump only). Refer
to specifications found later in this section.
• Must have a grounded, polarized electrical power
supply on a separate circuit servicing only this appli-
ance. If GFCI (ground fault circuit interrupter) is
required by local electrical code or is part of an out-
door installation, it must be breaker type, not outlet
type. Refer to specifications found later in this sec-
tion.
• Must have a cold water supply line available at ice
machine. Refer to specifications found later in this
section.
• Specifications for clearance and air temperature
requirements must be met. Refer to specifications
found later in this section.
• Must be re movable for yearly cleaning procedure.
Refer to specifications found later in this section.
Dimensions in parentheses are in millimeters unless otherwise specified.
OVERALL DIMENSIONS
33-5/8"
(854 mm)
33-5/8"
(854 mm)
14-3/4"
(375 mm)
29-5/8"
(752 mm)
4"
(102 mm)
21-5/16"
(541 mm)
1-11/16"* (43 mm)
21-5/16"
(541 mm)
TOP VIEW
14-3/4"
(375 mm)
115˚
DOOR SWING
SIDE VIEWFRONT VIEW
*Does not include door panel
6-1/2"
(165 mm)
18"
(457 mm)
ALL MODELS
Dimensions may vary ± 1/8" (3 mm).
Overall Width 14-3/4" (375 mm)
Rough Opening Depth 24" (610mm)
Minimum Height Required
(levelers in) 33-5/8" (854 mm)
Rough Opening Height 34-1/2" (876 mm)
Rough Opening Width 15-1/4" (387 mm)
Minimum Door Clearance 18" (457 mm)
Overall Depth 23" (584 mm)
Overall Height (levelers in) 33-5/8" (854 mm)
PROPER INSTALLATION REQUIRES CONNECTION
TO A WATER SUPPLY, A DRAIN AND A DEDICATED
ELECTRICAL CIRCUIT. THESE CONNECTIONS
ARE THE RESPONSIBILITIES OF THE
OWNER/OPERATOR. IMPROPER CONNECTIONS
CAN RESULT IN PERSONAL INJURY, SUBSTAN-
TIAL PROPERTY DAMAGE AND ERRATIC
MACHINE OPERATION. IF UNABLE TO SAFELY
CONNECT THE ICE MACHINE, CONSULT QUALI-
FIED PROFESSIONALS OR CONTACT SUB-ZERO.
NOTE: Failure to follow installation guide lines may
affect warranty coverage.

Page 3
Model UC-15I (Undercounter Ice Machine) Installation Information
2-3 #7012423 - Revision B - May, 2011
Location of the Ice Machine
The location selected for the ice machine must meet
the following criteria. If any of these criteria are not
met, select another location.
• The ice machine may be built into a cabinet, however
the location must allow removal of the ice machine for
cleaning and servicing. Service diagnostics are per-
formed from the top of the ice machine.
• The location must be free of airborne and other con-
taminants.
• Do not place the unit within 18" (457) of a trash com-
pactor or trash/recycling container.
• The air temperature must be at least 50°F (10°C).
But, the air temperature must not exceed 100°F
(38°C) for models UC-15I and UC-15IP, and 110°F
(43°C) for models UC-15IO and UC-15IPO.
• The location must not be near heat-generating equip-
ment.
• The location must not obstruct air flow through the
kickplate (airflow is in and out the front of the ice
machine).
• The location must allow enough clearance for water,
drain and electrical connections at the rear of the ice
machine.
• Models UC-15IO and UC-15IPO are designed and
approved for outdoor installation.
The ice machine must be protected if it will be sub-
jected to ambient temperatures below 32°F (0°C).
Component failure caused by exposure to freezing
temperatures is not covered by the warranty.
Area Requirements
Before moving the ice machine into place, be sure the
finished opening dimensions, electrical location and
plumbing location are accurate.
Be sure the plumber, electrician and cabinet installer
have this information before finishing work is complet-
ed.
Models UC-15I and UC-15IO are gravity drain models
that require a drain tube that is pitched down from the
outlet at the back of the unit to the sanitary sewer con-
nection.
Models UC-15IP and UC-15IPO have a built in drain
pump that will pump water up to a drain point, such as
a nearby sink. Refer to specifications found later in this
section.
NOTES:
•If the ice machine is installed in a corner, the door
swing may be limited due to handle contact with the
wall or cabinet face.
•The floor under the ice machine must be at the same
level as the surrounding finished floor.
•When moving the unit, use a hand truck or dolly, posi-
tion the dolly on the side of the unit and secure the
door so it does not open while transporting the unit.
Any finished flooring should be protected with
appropriate material to avoid any damage from
moving the unit.

Page 4
Installation Information Model UC-15I (Undercounter Ice Machine)
2-4
#7012423 - Revision B - May, 2011
ELECTRICAL REQUIREMENTS
Prepare electrical circuit before installation of the ice
machine. Installation requires a grounded (three-
prong), polarized receptacle (See Figure 2-2), with a
separate fuse/circuit breaker in an electrical service
box.
Proper Three-Prong Polarized Receptacle
ELECTRICAL SHOCK HAZARD. DO NOT USE AN
EXTENSION CORD OR TWO PRONG ADAPTER.
ELECTRICAL GROUND IS REQUIRED ON THIS
APPLIANCE. DO NOT REMOVE THE POWER SUP-
PLY CORD GROUND PRONG.
All electrical work, including wire routing and grounding,
must conform to local, state and national electrical
codes. The following precautions must be observed:
• The ice machine must be grounded.
NOTE: All National Electrical Code regulations must be
followed. In addition, be aware of local codes and ordi-
nances when installing the services.
Voltage
• The minimum wire size is #14 for less than 100 feet
(30.5 m) or #12 for more than 100 feet (30.5 m) to
200 feet (61 m) (solid copper conductor only). The
recommended breaker is 15 amp. Local or state
electrical code, length of run or materials used, can
increase the minimum wire gauge required. A quali-
fied electrician must determine the proper wire size,
although #14 is the minimum size allowed.
NOTE: Observe correct polarity of incoming line volt-
age. Incorrect polarity can lead to erratic ice machine
operation and a safety issue.
Minimum Circuit Requirements
The minimum circuit requirement is used to help select
the wire size of the electrical supply.
NOTE: Minimum Circuit Amps listed below is not the
ice machine’s running amp load.
MAXIMUM BREAKER SIZE AND
MINIMUM CIRCUIT AMPERAGE
Voltage / Phase / Cycle 115 / 1 / 60
Maximum Fuse/Circuit Breaker Amps 15
Minimum Circuit Amps 4.1
GFCI Requirements
For Models UC-15IO and UC-15IPO or if a GFCI
(ground fault circuit interrupter) is required by local elec-
trical code, it must be breaker type.
34
1
/ 2 " (876)
ROUGH
OPENING
HEIGHT
33
5
/ 8 " (854)
MINIMUM
HEIGHT
REQUIRED
15
1
/ 4 " min (387)
ROUGH
OPENING WIDTH
POSITION OUTLET
WITH GROUNDING
PRONG ON RIGHT
FRONT VIEW
4"
(102)
LOCATE
ELECTRICAL
WITHIN
SHADED AREA
INSTALLATION SPECIFICATIONS
Dimensions in parentheses are in millimeters unless otherwise specified.
• A separate fuse/circuit breaker must be
provided for each ice machine.
• The maximum allowable voltage variation
is +/-10% of the rated voltage at ice
machine start-up (when the electrical load
is highest).

Page 5
Model UC-15I (Undercounter Ice Machine) Installation Information
2-5 #7012423 - Revision B - May, 2011
PLUMBING REQUIREMENTS
NOTE: Plumbing must conform to state and local
codes.
Water Supply
Prepare water supply line and drain before installation
of the ice machine. Installation requires a minimum
1/4” ID copper cold water line and compression fitting
(not supplied). Models UC-15I and UC-15IO are sup-
plied with a drain hose for gravity draining. The option-
al drain pump or pump models UC-15IP and UC-15IPO
must be purchased if a gravity drain is not possible.
Both drain methods require routing to an open site
drain. Do not connect directly to drain line as bacteria
from drain line may contaminate the ice machine.
The included water filter is designed to inhibit scale for-
mation, filter sediment, and remove chlorine odor and
taste. The life expectancy of the water filter is 6 months
during normal usage. The ice machine control board
will monitor water usage and indicate when replace-
ment is required.
Water Inlet Lines
Follow these guidelines to install water inlet lines:
• Do not connect the ice machine to a hot water supply.
Be sure all hot water restrictors installed for other
equipment are working. (Check valves on sink
faucets, dishwashers, etc.)
• If water pressure exceeds the maximum recommend-
ed pressure (80 psi–551.5 kPA), obtain a water pres-
sure regulator from a local plumbing contractor.
• Install a water shut-off valve for the ice making water
lines.
• Insulate the water inlet line to prevent condensation.
Drain Connections
Follow these guidelines when installing drain lines to
prevent drain water from flowing back into the ice
machine and storage bin:
• Drain lines must have a 1-1/2” drop per 5 feet of run
(2.5 cm per meter), and must not create traps.
• The floor drain must be large enough to accommo-
date drainage from all drains.
• Drain pump discharge line must terminate at an open
site drain.
• Maximum rise – 12 feet (3.7 m)
• Maximum run – 100 feet (30.5 m).
APPROXIMATE HEIGHT OF
ICE MACHINE DRAIN
Standard Installation 5” (127mm)
Improper drainage can lead to water flowing back
into ice machine and poor performance.

Page 6
Installation Information Model UC-15I (Undercounter Ice Machine)
2-6
#7012423 - Revision B - May, 2011
NOTES
• If air temperature is less than 60°F (16°C), water temperature must be equal to or greater than 50°F (10°C).
• Plumbing must conform to state and local codes.
• Although the ice machine has been designed to be serviced in place, in some cases it may be necessary to pull
the unit out for service. For that reason do not restrict access to the unit at the front, top and bottom. If a floor is
to be installed after the ice machine, shims the thickness of the floor should be installed under the unit to keep the
ice machine level with the floor. Also, allow 1/8” (3) clearance on each side of the unit for protruding screw heads.
Installations on a Cement Slab:
Use a Model UC-15IPO or UC-15IP, with built-in drain pump and pump the water to the point of drainage. Drain
pump models will pump 12 feet (3.7 m) high.
Installations Over a Crawl Space or Basement:
If there is not enough room behind the ice machine for a drain/waste water receptacle, the drain will have to be
below the floor.
WATER SUPPLY AND DRAIN LINE SIZING / CONNECTIONS
Water
Temperature
50°F (10°C) Min.
80°F (27°C) Max.
__
__
Water
Pressure
20 psi (137.9 kPA) Min.
80 psi (551.5 kPA) Max.
__
__
Ice Machine
Fitting
1/4” (6.4 mm) ID
Copper Tubing
3/4” (19mm)
Hose Barb
3/8” (9.5mm)
Hose
Tubing size up to
Ice Machine Fitting
1/4” (6.4 mm) minimum
Inside Diameter
3/4” (19mm)
minimum
Inside Diameter
3/8” (9.5mm)
minimum
Inside Diameter
Ice Making
Water Inlet
Models
UC-15I and
UC-15IO
Models
UC-15IP and
UC-15IPO
24"
(610 mm)
ROUGH
OPENING
DEPTH
LOCATION
OF
WATERLINE
8"
(203 mm)
TOP VIEW
INSTALLATION SPECIFICATIONS
1/2 "
(13 mm)
Dimensions in parentheses are in millimeters unless otherwise specified.

Page 7
Model UC-15I (Undercounter Ice Machine) Installation Information
2-7 #7012423 - Revision B - May, 2011
1. Prepare the site by following the instructions under
Electrical Requirements and Plumbing
Requirements found earlier in this section.
2. Remove ice machine from carton
3. Inspect ice machine for damage.
4. Remove literature/warranty packet and drain hose
from inside the ice machine.
5. Adjust leveler legs. Refer to Leveling found later in
this section.
6. Reverse door if desired. Refer to Reverse the Door
Swing found later in this section.
7. Gravity drain model: Install drain hose to drain on
back of ice machine and route to open site drain.
Refer to Plumbing Requirements found earlier in
this section.
Pump model: Route drain tubing through drain fit-
ting on the back of the ice machine and install drain
hose on drain pump. Route other end of drain tub-
ing to drain site. Refer to Plumbing Requirements
found earlier in this section.
8. Use compression fitting to connect the Water Inlet
on back of ice machine to the prepared 1/4” ID cold
water line. Refer to Plumbing Requirements found
earlier in this section.
Drain
Fitting
Water
Inlet
THE ICE MACHINE MUST BE GROUNDED IN
ACCORDANCE WITH NATIONAL AND LOCAL
ELECTRICAL CODES. DO NOT USE AN EXTEN-
SION CORD OR ADAPTER.
IMPROPER WATER SUPPLY AND DRAIN CONNEC-
TIONS CAN RESULT IN PERSONAL INJURY AND
SUBSTANTIAL PROPERTY DAMAGE. THESE
CONNECTIONS ARE THE RESPONSIBILITY OF
THE OWNER/OPERATOR.
9. Open the shut-off valve on the water line.
10. Check all visible connections for water leakage.
Failure to do so could cause flooding.
11. Connect electrical plug to grounded (three prong),
polarized outlet. See Electrical Requirements found
earlier in this section.
12. Place ice machine back in position and check level-
ing again. Make any necessary adjustments.
(CONTINUED ON NEXT PAGE)
INSTALLATION PROCEDURE
Water Line and Drain fitting at Rear of Unit

Page 8
Installation Information Model UC-15I (Undercounter Ice Machine)
2-8
#7012423 - Revision B - May, 2011
13. Prepare sanitizer solution and sanitize the ice
machine according to In Place Cleaning/Sanitizing
instructions found in the Installation & Operation
manual.
14. Put one gallon (4 L) of cold water into a container
that will easily pour under the lifted water shutters.
Refer to page 17 to identify water shutters. Open
shutters and add one gallon (4 L) of cold water.
Watch for proper drainage.
15. Press POWER button.
16. At initial start-up, ice machine will need approxi-
mately 30 minutes to freeze ice and up to 5 minutes
to harvest the ice. Wait for first cycle of cubes to
drop to ensure proper installation.
Gravity Drain Model
15
1
/ 4 " min
(387)
OPENING WIDTH
TOP VIEW
FRONT VIEW
1
/ 8 " (3)
DRAIN
TUBE
WATER
INLET TUBE SHUT-OFF
VALVE
DRAIN
TUBE
WATER
INLET
TUBE
SHUT-OFF
VALVE
DRAIN
INSTALLATION SPECIFICATIONS
15
1
/ 4 " min
(387)
OPENING WIDTH
TOP VIEW
FRONT VIEW
1
/ 8 " (3)
DRAIN TUBE
SHUT-OFF
VALVE
AIR GAP
DEVICE
DRAIN TUBE
AIR GAP
DEVICE
WATER
INLET TUBE
SHUT-OFF
VALVE
WATER
INLET TUBE
Drain Pump Model
INSTALLATION SPECIFICATIONS
The unit must be allowed to have ventilation through
these fins. The door panel may hang in front of the
fins, but a decorative kickplate must not cover the fins.
It is possible to paint the kickplate another color. Follow
these easy steps:
•Rough up surface to be painted with fine grit sandpa-
per.
•Wipe with alcohol to ensure it is clean and dry.
•Use an appliance or industrial grade, oil base, high
gloss enamel paint.
Do NOT cover the kickplate area
Dimensions in parentheses are in millimeters unless otherwise specified.

Page 9
Model UC-15I (Undercounter Ice Machine) Installation Information
2-9 #7012423 - Revision B - May, 2011
LEVELING
1. Adjust the levelers close to desired height.
2. Move the bin into its final position.
3. Level the ice machine to assure that the bin door
closes and seals properly. Use a level on top of the
bin. Turn the base of each foot as necessary to
level the bin. Refer to the illustration below.
SECURE THE ICE MACHINE
To secure the ice machine, install two #8 x 1/2” flat
head screws through each hinge. Refer to the illustra-
tion below.
NOTE: If the door swing is to be changed, refer to
Reversing the Door Swing before securing the unit.
Turn Clockwise
to Lower Unit
Flat Head
Screws
SIDE PANELS
With the Sub-Zero ice machine, the side panels must
be securely fastened to the adjacent cabinets and floor.
Panels should be fastened to the floor and walls using
’L’ brackets (hardware not provided). To help move the
unit into place, rout out an area in the floor so the ‘L’
bracket will sit flush with the floor level. Brackets and
screws are provided for mounting the unit to adjoining
cabinets and side panels.
REVERSING THE DOOR SWING
The hinged side of the door may be reversed to the
other side if desired. The Sub-Zero ice machine is
shipped with the door hinged at the right. The door and
hinges are designed for placing the hinges on either
the right or the left side of the unit. Moving the hinges
to the left in the pre-drilled holes, allows the door to
pivot from the left side. Refer to the illustrations below.
NOTE: The plastic molding which covers the top area
of the door, packaged with the ice machine, is required
for this procedure.
1. To begin, remove the four screws that secure the
door hinges to the ice machine. Refer to the illus-
tration below.
NOTE: Remove the shim located between the cab-
inet and bottom hinge, this shim will transfer to the
left side bottom hinge.
Step 1
Remove Door
(CONTINUED ON NEXT PAGE)
Adjusting Leveling Leg
Secure Ice Machine to Cabinets

Page 10
Installation Information Model UC-15I (Undercounter Ice Machine)
2-10
#7012423 - Revision B - May, 2011
2. Remove the hinges from the door by removing the
four screws (two each hinge) that secure the hinges
to the door. Refer to the illustration below.
3. Remove the upper plastic trim piece (right hand
configured) from the door by removing the two
screws that secure it to the door. Then replace it
with left hand trim piece. Refer to illustration below.
4. Transfer the hinges to the left side of the door and
re-attach. The upper hinge will need to become the
lower hinge and the lower hinge will now need to
become the upper. Refer to the illustration below.
Step 4
Step 5
Hinge Transfer
Remove Top Cover
Step 6
Step 8
Reversing Top Rail
Repositioning Slide Rail
Step 2
Step 2
Step 3
Remove Hinges
and Plastic Trim
5. Remove the top ice machine cover by removing the
two screws along the back of the unit. Refer to the
illustration below.
6. Remove four screws from the front top rail. Refer
to the illustration below.
7. Pivot top rail end for end to expose the two left
hand top hinge screw holes and reinstall.
8. Remove 2 screws from bottom trim plate and slide
to cover right hand hinge mounting screw holes and
expose left hand hinge mounting screw holes.
Refer to illustration below.
9. Install the door using the left-hand door mounting
holes. Install shim removed in step 1 between the
hinge and cabinet.
10. Check the operation of the door by opening.

Page 11
Model UC-15I (Undercounter Ice Machine) Installation Information
2-11 #7012423 - Revision B - May, 2011
DOOR PANEL INSTALLATION
Be sure of the door panel size and placement before
proceeding with the installation. If there are questions,
contact the Sub-Zero dealer or cabinet supplier.
Instructions regarding sizing of the door panel are pro-
vided in the Sub-Zero design guide.
For door handle hardware, a D-style pull centered on
the edge opposite the door hinge side is recommended.
Screw heads may have to be countersunk to ensure
that the hardware does not interfere with the panel fit-
ting flush with the unit door.
DOOR PANEL DIMENSIONS
Door Panel Width – 1/8” (3) reveal 15” (381)
Door Panel Height – 1/8” (3) reveal
4” (102) toe space 30-3/8” (772)
Door Panel Thickness 5/8” (16) min
Door Panel Weight 15 lbs (6.8 kg) max
Dimensions may vary +_ 1/8” (3).
PANEL DESIGN NOTE: Additional panel design infor-
mation can be found in the Sub-Zero design guide.
Check our website at subzero.com.
Panel Preparation and Installation
1. Remove the handle side bracket attached to the
front of the door and set aside.
2. Place the door panel lying face down on a protect-
ed surface to ensure the front is not scratched or
damaged.
3. Position the template provided flush with the upper
edge of the panel. Be sure to follow the exact loca-
tion for the RH or LH door position. Refer to the
illustration below.
NOTE The door panel is being viewed from the back
side in the illustration. The overall size of the panel
shown is the minimum size necessary to cover the door
of the unit. The exact measurements of the door panel
may vary depending on the particular installation being
followed.
4. Once the proper position for the hardware has been
located, mark the holes, remove template, and drill
pilot holes for mounting of the hardware.
NOTE: It is recommended to start the first few holes,
positioning the hardware, drilling remaining pilot holes,
and securing the mounting brackets with the #8 x 1/2”
screws. Refer to the illustrations below.
5. Install the panel onto door by engaging the tabbed
bracket to the door first and then sliding the hinge
side hardware over the positioning screws. There
will be will have a 1/4" inch adjustment, up and
down, side to side, with this hardware.
6. Once the panel is in place, attach the remaining #8
x 1/2" screws to the hinge side mounting bracket
and install decorative caps.
Flush with Top and Side
of Panel
Drill Template Position
BACK SIDE
OF PANEL
Right-Hand Door Panel
BACK SIDE
OF PANEL
Right-Hand Door Panel
Exercise caution when drilling holes for hardware.
This is especially critical with inset panels.

Page 12
Installation Information Model UC-15I (Undercounter Ice Machine)
2-12
#7012423 - Revision B - May, 2011
90-Degree Door Stop Installation
Certain installations may require the door to stop at 90-
degree instead of the full 115-degrees. A door stop pin
is supplied with the unit. To install the 90-degree door
stop pin (Refer to illustration below)l:
1. Open door to approximately 80 degrees.
2. Insert 90-degree stop pin down through holes in
bottom hinge bracket.
3. Insert 90-degree stop pin up through holes in top
hinge bracket.
NOTE: The pins must be inserted until their heads
makes contact with the hinge brackets.
4. Check for proper door operation.
Hinge Cover Installation
NOTES:
• Do NOT Install the hinge covers until after installation
of the ice machine is complete.
• The 90-degree door stop must be installed prior to
installing the hinge covers.
• If the 90-degree stop pins are installed, it will be nec-
essary to remove the knock-outs from the hinge cover
opposite the head of the pin.
• Hinges must be free of dirt and grease before
attempting to install the hinge covers.
1. Remove backing paper from adhesive pads of
upper and lower hinge covers, then adhere covers
to top and bottom of each hinge bracket as shown
below.
2. The center hinge covers are magnetic. Install them
to center of each hinge bracket as shown illustra-
tion below.
Hinge Cover Installation
Door Stop Pin
90 Degree Door Stop
If the reveal on the hinge side of the door panel is
less than 1/4", and the panel has a square corner,
severe finger pinching or damage to the unit may
occur.
Knock-out
