Scotsman UC2024 Series Installation guide

Technical Service Training
UC2024 and UC2724

Service Support
Technical Service 1-800-533-6006
Check out our mobile ready website
www.scotsman-ice.com/service

Technical Service Virtual Business Card

Training Agenda
•Introduction
•Installation
•Operation
•Maintenance
•Diagnostics
•Taking the unit apart

UC2024 and UC2724
•Cubed Ice Making
–24 inches wide
–39 inches high including legs
–Air or Water Cooled
–Airflow in and out of the
front

Component Location
Air Filter

Component Location
Control Box
Fan Motor
Ice Storage Bin

Component Location
Transformer
Controller
Lights and
Buttons
Master Switch
Slide Out Electrical Box Contactor

Component Location
Drain Hose

Component Location
Back Panel Area
Drain
Water Valve
Power Cord
Pump
Compressor
