sumas SM-30BT Mounting instructions

SM-30BT
USER OPERATION MANUAL

TABLE OF CONTENTS
Safety Information …….………………………………………………………… 1
Park/Brake wire ………………………………………………………………….. 1
Installation/Removal ……….………………………………………………….. 2
Playable Disc, DVD Care, MP3 ……….…………………………………….. 3
Maintenance …………………………………………………………………….… 3
Replacing Remote Control Battery ………….…………………………….. 3
Remote Control …………………………………………………………………... 4
Remote Control Functions ……………………………………………………. 5
Front Panel ………………………………………………………………………… 6
Front Panel Functions …………………………………………………………. 7
Basic Setup …..…….……………………………………………………….….... 8-9
Bluetooth ………………………………………………………………………….. 10
Radio Mode ……………………………………………………………………….. 10
Music/MP3 Mode ……………………………………………………………….. 11
DVD Mode …………………………………………………………………………. 11
USB Mode …………………………………………………………………….……. 11
Auxiliary Mode (Input) …………………………………………………………. 11
Trouble Shooting …………………………………………………………..……. 12
Specification ………..…………………………………………………………….. 13
Accessories ………………………………………………………………….…..… 14

Safety Information
Please read this manual thoroughly and keep in your vehicle for easy future reference.
We highly recommend that you find a licensed professional installer for the installation of
this product, it is illegal to watch DVD player while driving.
CAUTION: This unit is a class 1 Laser Product. To prevent direct exposure to Laser
system, DO NOT OPEN the unit. The Laser Beam may hurt or damage your eyes. If the
unit requires adjustments, please contact Sumas Media.
USE THIS PRODUCT SAFELY
Make sure you fully understand the following safety information:
When Driving
Keep the unit at an appropriate sound level. Driving with the sound at a level that
prevents you from hearing the sounds outside and around the car may cause an
accident.
When cleaning your interior
Do not expose the product to any type of liquid or excessive moisture. This could cause
short circuit, fire or other severe damage to the unit or you vehicle.
When Parked
Parking in direct sunlight, especially in the summer time can produce very high
temperature inside you vehicle. This may cause the unit to not work properly. Let the
interior of your car to cool down before turning on the unit.
Note: Do not use or store player in dusty, high temperature or high humidity environments.
Park wire/Brake wire
Park wire is to connect to your parking brake (Hand brake) or your unit will not function,
also for your safety; when car is operate will restrict you to play/watch DVD while driving,
display shows: safety off, do not play DVD,
But some make or model of automobile if you have problem to connect to your brake,
you can also ground this wire to your car’s chassis, unit will play; but restriction will be
disabled, so please do not watch your unit when driving!
Replacing the Fuse
When replacing the fuse, be sure to use one matching the amperage rating stated on the
original fuse.
WARNING!
NEVER replace any Fuse with higher amperage
than the original. This may cause damage to your
unit and/or your vehicle’s electrical wiring.
1

Installation
Note: Remove the protection screws (A)
before installing and operation the unit.
Please find the front panel inside carry caddy. Reinstall panel by placing as
flipped down position, insert panel left side into front adaptor first, then gently
click right side into place. When completed correctly panel should be flip up in
place.
To remove the panel, gently pull out the right side first after flipped down.
oThis unit is designed for 12V DC, (connecting to other than 12V unit will be damage)
negative ground operation system only.
oWhen replacing a fuse, be sure to match the amperage as the original fuse. Using the
wrong fuse may cause your unit not to function or even electrical shortage
oThe negative battery terminal must be disconnected before making connections, which
can prevent damaging the unit due to short circuit.
oBe sure to connect the color coded leads correctly according to the wiring diagram.
Incorrect connections may cause damage or malfunction or even damage the vehicle’s
electrical system.
oBe sure to connect the speaker (-) leads to the speaker (-) terminal, and the speaker
(+) leads to the speaker (+) speaker terminal and so on. Never cross connect the left /
right channel speaker cables or to the vehicle body/frame.
oDo not block the unit’s vents or heat sink. Blocking can cause heat to build up inside
and may damage your unit.
oAfter the completion of the installation. Reconnect negative cable of vehicle to the (-)
battery terminal, and then press the RESET in the front panel with the push pin to set
the unit to initial status. Please refer below. ( see picture below)
Unit Reset
Unit Installation & Removal
2

Maintenance
Playable discs
DVD, Video CD and CD discs that display the logos shown below can be played back on this unit.
DVD video disc region numbers:
(This unit is for region one ONLY)
If you encounter region problems, please call toll free service number on back page, we will help you resolve if.
DVD Care
If you use an irregular disc it may jam the DVD player or not play, for this reason only use round discs
Be sure to check all discs for cracks and scratches before playing, discs in those conditions will not play properly.
Also, be sure to avoid touching the recorded (plain) side of the disk, avoid scratching the disc. Store CDs in case when not in use.
Keep discs out of direct sunlight (it will cause them to warp andcrack) to clean the CDs, wipe with a soft cloth from the inside of
the disc outward.
MP3
MP3 files on CD-ROM, CD-R and CD-RW are compatible with this unit.
Discs compatible with ISO9660 level one and two or with ROMEO and JULIET, recorded discs with the multi sections can also be
played. MP3 files are incompatible with the transportation of read-in files.
The max character width of the folder name is 32.If the file is recorded through ROMEO and JULIET system, only the former 32
characters are displayed. While playing discs with MP3 and CD-DA, such as CD EXTRA and MIXED MODE CD the system can only
switch between MP3 and CD-DA. The selected folder sequence of playing and other operations will be the sequence to write in the
software. So the anticipated sequence of playing should not conflict with the actual playing sequence. However, there is, indeed some
software that play sequence is allowed to be set. The file is compatible with Id3 label version 1.0 and 1.1, so as to display the music titles
and authors. The enhancing function is valid only when playing MP3 in 32, 44.1 and 48 KHz sample frequencies 16,22,05,24, 32, 44.1
KHz can be played. The tone of MP3s file can usually be bettered when the bit rate is increased. This machine can play recordings
between 8KBPS and 320 KBPS. However, in order to enjoy a good tone, we recommend discs over 128KBPS.
!!!!!IMPORTANT!!!!!
While naming an MP3 file, add relevant extending name “.mp3”
This machine will play files with .mp3 as MP3; do not use this extending name on non mp3 files to avoid noises and other problems.
MP4
Due to new DivX version restriction on decoding, this unit will play most of the DivX format but some of the newer version will not.
It can also play most of the .avi files with MPEG 4 codec.
Replacing Remote Control Battery
* When the remote control operation range becomes an issue or none functional at all.
Replace the battery with a new button cell. Make sure to purchase the same size battery.
2. Put the button-type
battery (+) mark
upward into the
battery holder.
3. Insert the Battery
Holder into the
Remote Control.
1. Pull out the
Battery Holder while
pressing the stopper.
3

Remote Control
4

REMOTE CONTROL FUNCTIONS
1. PWR: Power (on/off)
SUB-T/REC: Language subtitle (on/off)
MUTE: Mute enable/disable sound
SRC: To switch between modes
2. BND/RDM: To select different bands (radio mode) To turn on random playing
APS/PRG: Automatic scan/program (radio mode)
ST/RPT: Stereo/Mono switch (radio mode) Repeat on/off
3. : Play/Pause
: Stop
Setup: For system settings
Title: Title Menu
Enter: Confirm/play
: Directional buttons
4. Phone call pick-up/send/ring on
OSD: Screen info Display
: End phone call/ring off
5. 0-9: Number buttons for dialing phone calls
GOTO: GOTO search
RO/RS: Radio Scan
6. AF/TA/PTY – None functional buttons. (only for European models)
7. : Skip forward/next chapter/track
: Previous/last chapter/track
: Increase/decrease volume
SEL: System settings
CLK: Clock display button
EQ: Preset sound effects (equalizer)
N.P/Angle: Video switch/Angle Adjustment
R.L/Language: Left/Right soundtrack switch dialogue language
5

Front Panel
1. Release Button 9. USB Port
2. MenuButton 10.Play/Pause/APS button
3. RDM/Band Select button 11. CLK/ Button
4. SourceButton 12.TFTLCDScreen
5. Four Way Directional button 13. Volume Button
6. ST/RPT 14.DiscSlot
7. MIC 15.SDSlot
8. Mute Button 16. Reset Button
17. Eject Button
6

FRONT PANEL FUNCTIONS
1. – Front panel release button
2. Menu – System settings
3. Band/RDM – To toggle change between FM1/FM2/FM3/AM1/AM2 and Random
Play
4. Source/Power – To turn the unit on and toggle between Modes
DVD/CD/Tuner/USB/SD/AUX/Bluetooth modes
5. Four directional buttons – To change setting using up/down/left/right
6. ST/RPT – To change audio from Stereo/Mono/Repeat on/off
7. MIC – (microphone) Use when on Bluetooth mode
8. Mute– Mute
9. USB Port – For inserting supported USB device
10. APS/ – Reception Scan/Play/Pause
11. CLK/ – Clock display/Stop button
12. TFT LCD Screen – 3” Full touch TFT LCD Screen
13. Volume Knob – For adjusting volume levels
14. Disc Slot – For inserting discs
15. SD/MMC Slot – Memory Card Slot
16. Reset – To reset all setting to factory default
17. – To eject inserted discs
7

Basic Setup
Powering the unit ON/OFF
- Press the Source/Power button once to turn the unit on. Press and hold to turn off.
Note: When using the remote, just press “PWR” power button once to turn unit on/off.
Switching Modes
- Press the Source/Power Button on the unit repeatedly to cycle through the Modes.
When on the main screen, simply touch the desired icon. (See below)
Main Screen
Video Setting
-To change settings,press MENU button on the panel or Setup on the remote control.
Scroll down or touch the option you want to change directly on the screen, press
to change settings. Play with these options to get the desired setting. Touch
VMODE then to cycle through preprogrammed video settings.
8

Basic Setup cont.
Audio Settings
- To change settings, press the Menu or Setup on the remote control, then touch
“AUDIO” tab on the screen or press on the remote. Touch the screen on the desired
option, then press to change the settings. (Setup between 0-14) Play with
these options to get the desired audio output. For the preset equalizer settings, simply
touch EQ then to cycle through NORM, ROCK, POP and CLAS.
System Mode Settings
-To change settings, press the Menu on the screen or Setup on the remote control
then touch “System” on the screen or press twice on the remote. Touch the screen
on the desired option then press to turn settings on/off. Play with these
options to get the desired setting. To change/set time touch or scroll down to TIME
ADJ, then touch the hour 00:00 section and press to adjust time, repeat steps
to change minutes.
Note: Time is set to military time only, (24hr time mode).

Basic Operation
9
BLUETOOTH MODE
Pairing/link your cell phone
-Operating “Bluetooth” mode: Select from the main screen by touching the icon or by pressing
the “SOURCE” button repeatedly until “Bluetooth” is displayed. Press “Setup” on the screen,
then press on/off and press “Connect”.
-Turn your cell phone’s Bluetooth on; select either “Search Audio Enhancement” or “Pair or
link with Device”. Once your cell phone has done searching, the car DVD should display as
“Car Kit”. Press “Connect” or “OK” on phone, when asked for a security code,
Enter “0000” then press “Accept”.
Once pairing/link completed both devices will say connected.
You can now make and receive phone calls through your car DVD player.
Note: Some phones will have a feature to allow the car DVD to connect to your cell phone automatically without a security code.
Bluetooth Main Screen Bluetooth Setup Screen Bluetooth Call History Screen
Making phone calls
-To make a call simply use touch dials from screen and press to send. To end the call press
to end.
-You can review a history list of in/out calls by pressing the folder icon.
To redial, press the desired number on screen and then press to send.
-To end connect and transfer call back to you cell phone, just press transfer on the screen.
**When calls come in while you’re on the phone using Bluetooth, please be aware Bluetooth does not
have call waiting feature, and this is how it actually works:
- While on the phone and another call comes in, you will hear 2 short soft beeps, as an alert on
incoming call, which will be the only notification you get. There will be no display on the unit
for the other incoming call; however your cell phone will display the incoming call. You can
only pick up the 2nd call from your cell phone; otherwise inbound call will go into voicemail.
Note: Some phones will repeat the beep at least twice depending on the brand of your phone and your service provider.
Playing Music
-Some Phones that have built-in music player, music can be play through the car DVD via Bluetooth.
-All functions of the music player can only be control through your phone. However we do not
recommend using this function while driving; it’s dangerous to take your focus away from the road.
Note: When a call comes in, the unit will automatically switch to Bluetooth mode.
Radio Mode
- Press Power/SRC button on the unit, and then touch the “Radio” icon the screen.
- Band Select: Touch “BAND”to select from FM1, FM2, FM3, AM1 or AM2.
- Manual Tuning: Touch repeatedly to locate the desired frequency.
- Automatic Tuning: Touch and hold for 3 seconds to search available frequencies.
-Storing Radio Stations: To store stations to the unit, locate the desired station using
, then press and hold the desired number on the remote control (from 1 to 6).
Unit will beep once set. Repeat steps for the rest of the numbers and Band section.
- Automatic Radio Station Storing: To randomly store available frequencies,
Simply touch and hold the “APS” button for about 2 seconds then release.
*NOTE: This unit can store up to 18 FM Stations (FM1=6, FM2=6, FM3=6) and up to 12 AM Stations (AM1=6 AM2=6).
10

Basic Operation cont.
Music/MP3-4 CD Mode
-Inserting a CD: Press the “Release” to open front panel, then insert a Music or MP3 Disc
into the disc slot with label facing up. Then push front panel back into place. Unit should
automatically switch to “DISC” mode. The unit will start playing the first track on the CD.
- Track Select: To skip forward or backwards through the tracks simply press . Or
ouch screen and submenu will appear with play control functions. (See Fig. A)
- Random Playing: Press “Band/RDM” button once to play track in random order, press
again to turn random off.
- Repeat Play: Press “ST/RPT” button to repeat what’s currently playing, press
again to turn off repeat play. For MP3 playing to repeat a whole folder press “RPT” 2x and 3x
to turn off random.
Fig. A
DVD Mode
-Inserting a DVD: Press the “Release” button to open front panel to insert DVD or VCD Disc
into the disc slot. (Make sure label is facing up), Flip the panel back into place. Unit should
automatically switch to “DVD” mode. The unit will start playing the content of the DVD.
-To skip or find chapters press on the unit or touch the screen to bring up submenu
controls. (See Fig. A)
-Press ►II to pause and play movie.
- For “Subtitle”. Simply press “SUB-T” on the remote to turn on/off.
-For “Repeat playing” press “RPT” once to repeat “Chapter” (current track), twice for “Title”
(the entire movie), and three times to end repeat play.
USB/SD/MMC Mode
(Note: USB PORT is for flash drive only, will not work for IPOD).
-Inserting a USB media device: Remove the protective cover of the USB input, plug in
device into the unit. (Unit will automatically switch to USB mode). If audio files are
present, then the first track will play automatically. To view pictures press the ►right arrow on
the remote then ◄left until the is highlighted on the bottom of the screen, then press
“Enter” then press up arrow and then “Enter” to play the first file. For playing Videos repeat
above steps but highlight on the bottom of the screen.
- Inserting SD/MMC memory card: Remove front panel (see page 1). Then insert the memory
into the slot all the way in until the unit grabs the card, reinstall front panel back into the unit.
Turn unit back on, and select the SD mode from the main menu.
When removing memory card, first removed the panel, then lightly/ quickly push the memory card in for
make ejecting of the card, then pull card out to remove.
*Note: Random play is only available on pictures and audio files. Repeat play is available on all.
AUX MODE
- To use “AUX” (auxiliary) mode: Plug RCA audio/video cables into the “AUX input” on
the back of the unit to your device. Press the SOURCE button repeatedly to select
Auxiliary mode or go to the main screen and press “Input” icon.
*Note: You can only control your device functions through the inserted device.
11

Trouble Shooting
Problem Reason/Cause Conclusion/Solution
Will not turn on. Incorrect wiring connections. Check all wires are properly connected.
Please refer to the wiring diagram
Remote control not
functional.
Insufficient battery power.
Remote sensor blocked.
Replace battery. (page 3)/ Make sure there is
nothing blocking the remote control sensor.
DVD/CD will not play,
or play properly.
Disk is dirty or scratched.
Disc isn’t compatible with unit.
Content of the disc is not
supported.
Clean the disc with a soft cloth.
Check disc compatibility. (see page 3)
Try another disc that is compatible.
No Sound/Volume or
will not increase.
Incorrect wiring connection.
Unit is on mute, playing frame by
frame, fast forwarding or
rewinding is turned on.
Check all the speaker wires are connected
properly with the unit and the speakers
themselves.
Un-Mute the unit.
Certain speaker will
not output sound.
Fader/Balance settings activated.
Speaker(s) might be damage.
Make sure all the connections linking the
speakers are properly connected.
Make sure all the speakers work properly.
LCD does not display
picture, or say
“picture off for
safety.”
“Brake in” wire not connected
properly to the park brake wiring.
/Parking brake is not applied or
wiring not properly connected.
Picture will only appear when parking brake
is applied for safety. / Check wiring and
make sure everything is properly connected.
Make sure “Brake in” wire is properly
connected to the hand brake or ground.
When the unit powers
on, there is a loud
noise.
The unit is reading inserted disc.
The disc drive is resetting to its
normal position.
Normal function.
USB flash drive or SD
card will not read.
Loose or dirty connection.
Or no connecting properly
Over capacity or not compatible
Check/clean connections.
Make sure the USB flash/SD card drive is
securely inserted into USB/SD port.
Unit can only read up to 2- 4GB, depending
on the size of the date
No subtitle.
Subtitle in the wrong
language.
Subtitle not activated. / DVD
movie does not have subtitle in
the desired language.
Press “SUB-T” on the remote to switch on.
Make sure DVD movie has subtitle with the
desired language.
Videos/Pictures are
obscure or blurred.
Video/picture resolutions are low. Make sure the videos/pictures have the
appropriate resolution for a 3” screen.
Does not play
Music/MP3 files.
Files are not supported. Check that the files are supported.
(see page 3)
Make sure the files are converted correctly.
Bluetooth not making
connecting to my
phone.
Bluetooth on the cell phone or the
car DVD is turned off.
/Not link properly.
Make sure Bluetooth is turn on both devices,
and is link properly. Turn car DVD on/off.
/try reconnect again.
My Bluetooth phone
will not connect or
reconnect.
Bluetooth is enabled on both
devices, or not paired properly.
Redo Bluetooth connection process and try
again. Some LG phone’s Bluetooth software
is not compatible with the common Bluetooth
program.
MP4 video will not
play.
Require compatible MP4
format/codec.
See page 3 (MP4).
Can’t set “BASS” or
“TREBLE” on set up “EQ” is not on “ NORM”
When “EQ” is on other then “ NORM” no
setting can be change,
set “EQ” to “ NORMAL”
12

Specifications
General
-Power Requirements …........ 12 V DC
-Load Impedance …………..……. 4Ω-8Ω
-Tone Control …………………….… ±8dB (Bass 100Hz, Treble 10KHz)
-Dimensions ……………………….… Approx. 7.36”D x 6.69”W x 2”H
-Mounting Dimensions …....... 7.50”D x 6.75”W x 2.25”H
-Weight …………………….………..…. 4.25lbs
DVD Deck Section
-Disc Play ……………………..…….…. MP4, DVD, VCD 1.0/1.1/2.0/3.0, MP3, CD, CD-R, CD-RW, PICTURE-CD
-Video System ……………..…….…. Auto/NTSC/AUTO
-Mounting Angle ……………………. 0° to +/- 30°
Video Section
-Video System ………………..….. 16:9 Wide screen
-Video Output Level …….……... 1.0Vp-p 75 ohms
-Horizontal Resolution ……….... 500 lines
Audio Section
-Maximum Output Level …….... 2Vrms (+/-3dB)
-Frequency Response ……….….. 20 to 20KHz
-Signal-to-Noise Ratio ……….…. 85dB
-Separation ……………….………….. 80dB
AM Tuner Section
-Frequency Range …………………. 530-1710 (USA)
-IF Range …………………….……..... 450 KHz
-Usable Sensitivity (-20dB) ….. 25dB
FM Tuner Section
-Tuning Range ………………………… 87.5 – 107.9
-IF Range ……………………………….. 10.7 MHz
-Usable Sensitivity (-30dB) ……. 15dB
-Signal-to-Noise Ratio ……………. 60dB
-Stereo Separation …………………. 30dB (1KHz)
-Frequency Response …………….. 30~15000Hz
13

Accessories
Fa
ceplate Frame Dash Insert Casing Screws
Push Pin Wiring Harness Extractors
Remote Control
Faceplate Caddy
Manual Wiring Diagram
14
