Sumvision Cyclone MKV 2 User manual

Cyclone MKV 2 Multimedia Enclosure
Page 1.
Version 1.2
CYCLONE
-MKV-
2
Full HD 1080p
HDMI Network Media Player Enclosure
User manual

Cyclone MKV 2 Multimedia Enclosure
Page 2.
Version 1.2
Contents:
Safety Instructions: ..........................................................................................5
Product Details:................................................................................................7
Packaging List:.............................................................................................7
Front View:...................................................................................................7
Back View:....................................................................................................9
Remote Control:.........................................................................................10
User Interface: ...............................................................................................13
Main Menu:.................................................................................................13
Browser Menu:...........................................................................................14
Setup Menu:...............................................................................................15
Installing a Hard Disk Drive:...........................................................................16
Basic Setup:...................................................................................................17
Connecting Power:.....................................................................................17
AV Cable:...................................................................................................17
Component output connection (YPbPr)......................................................18
HDMI Cable:...............................................................................................19
Optical Cable (Audio Only):........................................................................19
USB Host Interface:....................................................................................20
Direct PC Connection via USB:..................................................................20
Connection and Network Setup:.................................................................21
Wired Connection:......................................................................................22
DHCP IP (Auto): .....................................................................................22
Fixed IP (Manual): ..................................................................................22
Wireless:.....................................................................................................23

Cyclone MKV 2 Multimedia Enclosure
Page 3.
Version 1.2
Viewing Multimedia:.......................................................................................24
Movie Playback:.........................................................................................24
Movie Playback Options: ........................................................................25
Audio Playback:..........................................................................................27
Audio Playback Options:.........................................................................28
Image Playback:.........................................................................................29
Image Playback Options:........................................................................29
Slideshow Viewing with Background Music:...........................................30
File Copy:.......................................................................................................31
Copy / Move:..............................................................................................31
Configuring File Sharing with Windows XP:...................................................33
Configuring File Sharing with Windows Vista:................................................34
UPnP: ............................................................................................................35
Playlist ...........................................................................................................35
Playlist Creation: ........................................................................................36
Playlist Media Playback:.............................................................................36
Removing Files from Playlist:.....................................................................36
Network Media Access: .................................................................................37
Settings:.........................................................................................................39
Audio Settings Menu:.................................................................................39
Video Settings Menu:.................................................................................39
Network Settings Menu: .............................................................................42
System Settings Menu: ..............................................................................43
MISC Settings Menu: .................................................................................44
BitTorrent/Samba Installation:....................................................................45

Cyclone MKV 2 Multimedia Enclosure
Page 4.
Version 1.2
Neighbour Web Interface: ..........................................................................46
BitTorrent Download:..................................................................................47
Adding a New Torrent: ...............................................................................48
BitTorrent Settings:.....................................................................................49
Visit Neighbour:..........................................................................................51
Account Management: ...............................................................................51
Firmware Upgrade:........................................................................................53
Formatting a Hard Disk Drive:........................................................................54
Troubleshooting:............................................................................................54
Product Specifications: ..................................................................................57
Media Codec Information:..............................................................................58
Maintenance Notice:......................................................................................59

Cyclone MKV 2 Multimedia Enclosure
Page 5.
Version 1.2
Safety Instructions:
READ THESE INSTRUCTIONS:
All safety and operating instructions should be read before this product is
used.
KEEP THESE INSTRUCTIONS:
These safety and operating instructions should be retained for future
reference.
FOLLOW ALL INSTRUCTIONS:
All operating instructions should be followed.
AVOID USING PRODUCT NEAR WATER:
Do not use this product near a water source.
ALWAYS CLEAN WITH A DRY CLOTH:
Clean using a soft, dry cloth only.
HEAT:
Do not install near a heat source, such as radiators or other apparatus that
produce high level heat.
POWER OUTAGE:
Avoid use of the product during electrical storms. Disconnect device when
not in use for long periods.
SERVICING:
If product is or becomes defective please refer to a qualified service
technician.

Cyclone MKV 2 Multimedia Enclosure
Page 6.
Version 1.2
AVOID BLOCKING AIR VENTS:
Do not block the air vents in order to avoid heat build up. A minimum of 5cm
is recommended to maintain free air flow.
PROTECT THE POWER CORD:
Prevent the power cord from being walked on and being pulled with sudden
force. Protect the cord from being pinched, particularly at plugs and the point
where they exit the device.
DO NOT DROP:
Do not drop the player as this will cause irreversible damage.
ONLY USE RECOMMENDED ACCESSORIES:
It is recommended to use only manufacturer approved accessories to avoid
any compatibility issues or damage to the product.
HARD DRIVE AND OTHER MEDIA STORAGE DEVICE:
We will not be liable in any way for damage as a consequence of loss or
recovery of data on the hard drive and other attached media storage.
Customers are advised to backup data before using this device.
We are not liable for compatibility issues with the media storage unit. It is
recommended that customers buy a compatible storage media unit for this
player.

Cyclone MKV 2 Multimedia Enclosure
Page 7.
Version 1.2
Product Details:
Packaging List:
Please ensure that the following items are included in the box when opened.
If any items are missing, please contact your supplier immediately.
Media Player 1 x
Power Adapter 1 x
Remote Control 1 x
AV Cable 1 x
Support CD 1 x
Front View:
1 Press to switch the player on or go into standby
mode. The LED will light up blue when switched
on. It will light up red when switched to standby
mode.
2 HOME Press to return to the player’s main menu.
3 SETUP Press to enter the player’s setup menu.
4 STOP Press to stop media playback.
5 PLAY Press to resume media playback.
12 11 10 9 8 7 6 5 4 3 2 1

Cyclone MKV 2 Multimedia Enclosure
Page 8.
Version 1.2
6 RETURN Press to return to the previous menu.
7 ENTER Pressing this button will confirm or select an
action.
8 DOWN Press to move onscreen cursor down.
9 UP Press to move onscreen cursor up.
10 RIGHT Press to move onscreen cursor right.
11 LEFT Press to move onscreen cursor left.
12 IR Infrared sensor. LED light display.

Cyclone MKV 2 Multimedia Enclosure
Page 9.
Version 1.2
Back View:
1 DC IN 12V Power port.
2 Component YPbPr component video output
3 AV Out Composite video output.
4 Optical Optical audio output to connect to a surround
sound system.
5 HDMI High definition video output port. Used to display
high quality video and audio.
6 LAN 10/100 network port to connect the media player
to a wired network.
7 USB USB 2.0 port. Used for file transfers when
connected to a PC.
8 USB Host USB Host port to connect to multiple external
storage devices.
①③④⑤⑥⑦⑧
②

Cyclone MKV 2 Multimedia Enclosure
Page 10.
Version 1.2
Remote Control:
