Suncruiser 35L User manual

TABLE OF CONTENTS
5 - DASH / AUTO
Rev. 0921110131 Part No. 161500-09-016
Copyright 2008 Winnebago Industries, Inc. All rights reserved.
1 – INTRODUCTION
About this Manual ............................................................................................................................ 1-1
Safety Messages Used in this Manual .............................................................................................. 1-1
Pre-Delivery Inspection .................................................................................................................... 1-2
Front Axle Tire Alignment ............................................................................................................... 1-2
Service and Assistance ...................................................................................................................... 1-2
Reporting Safety Defects .................................................................................................................. 1-2
Occupant and Cargo Carrying Capacity Label ................................................................................. 1-3
Vehicle Certification Label ............................................................................................................... 1-4
Specifications and Capacities ........................................................................................................... 1-5
Owner and Vehicle Information ....................................................................................................... 1-7
2009 New Vehicle Limited Warranty ............................................................................................... 1-8
2 – SAFETY AND PRECAUTIONS
General Warnings ............................................................................................................................. 2-1
Driving Safety ................................................................................................................................... 2-1
Fuel and Propane Gas ....................................................................................................................... 2-1
LP Gas Leaks .................................................................................................................................... 2-2
Propane Gas Leak Detector .............................................................................................................. 2-2
Carbon Monoxide Warning .............................................................................................................. 2-3
Carbon Monoxide Alarm .................................................................................................................. 2-3
Smoke Alarm .................................................................................................................................... 2-4
Fire Extinguisher ............................................................................................................................... 2-4
Electrical ........................................................................................................................................... 2-5
Loading ............................................................................................................................................. 2-5
Maintenance ...................................................................................................................................... 2-5
Emergency Exits ............................................................................................................................... 2-5
Formaldehyde Information ............................................................................................................... 2-6
Mold, Moisture, and Your Motor Home ........................................................................................... 2-6
Roadside Emergency ........................................................................................................................ 2-7
Jump Starting .................................................................................................................................... 2-8
Engine Overheat ............................................................................................................................... 2-8
3 – DRIVING YOUR MOTOR HOME
Seats – Driver/Co-Pilot ..................................................................................................................... 3-1
Passenger Footrest ............................................................................................................................ 3-2
Seat Belts .......................................................................................................................................... 3-3
Child Restraints ................................................................................................................................. 3-4
Mirrors – Power Electric ................................................................................................................... 3-5
Rearview Monitor System ................................................................................................................ 3-5
Power Sunvisors ............................................................................................................................... 3-6
Brake-Shift Interlock ........................................................................................................................ 3-6
Parking Brake – Foot Pedal .............................................................................................................. 3-6

Table Of Contents
Parking Brake – Automatic/Pull-Button ........................................................................................... 3-7
Grade Brake ...................................................................................................................................... 3-7
Fuel Pump Shut-Off Switch .............................................................................................................. 3-7
Overdrive Switch .............................................................................................................................. 3-8
Tow/Haul Transmission Mode ......................................................................................................... 3-8
Hazard Warning Flashers .................................................................................................................. 3-8
Map Light Switch ............................................................................................................................. 3-9
Battery Boost Switch ........................................................................................................................ 3-9
Air Conditioner/Heater – Automotive (Dash) .................................................................................. 3-9
Heater – Rear Coach (Automotive) .................................................................................................. 3-9
Defrost Fans .................................................................................................................................... 3-10
Radio – In-Dash .............................................................................................................................. 3-10
Sirius® Plug and Play Satellite Radio ............................................................................................ 3-11
CB Radio Power Wiring ................................................................................................................. 3-12
Engine Access – Exterior ................................................................................................................ 3-12
Engine Access – Interior ................................................................................................................. 3-13
Engine Cooling System .................................................................................................................. 3-14
Chassis Battery Disconnect Switch ................................................................................................ 3-14
Tires ................................................................................................................................................ 3-15
Suspension Alignment and Tire Balance ........................................................................................ 3-15
Lights .............................................................................................................................................. 3-15
Circuit Breakers and Fuses – Chassis/Dash Automotive 12-Volt ..................................................3-16
Mountain Driving ........................................................................................................................... 3-16
4 – APPLIANCES AND SYSTEMS
Refrigerator ....................................................................................................................................... 4-1
Ice Maker .......................................................................................................................................... 4-2
Refrigerator Service Access Compartment .......................................................................................4-2
Range and Oven ................................................................................................................................ 4-2
Microwave Oven/Range Hood ......................................................................................................... 4-3
OnePlace® Systems Monitor Panel .................................................................................................. 4-4
Solar Charger Panel .......................................................................................................................... 4-6
Energy Management System (EMS) ................................................................................................ 4-6
Washer/Dryer .................................................................................................................................... 4-6
Water Heater - Gas/ Electric ............................................................................................................. 4-7
Pressure-Temperature Relief Valve .................................................................................................. 4-8
MotorAid Water Heater .................................................................................................................... 4-9
Propane Gas Furnace ........................................................................................................................ 4-9
Electronic Thermostat ..................................................................................................................... 4-10
Furnace-A/C Thermostat Operation Chart ......................................................................................4-12
Heat Pump ....................................................................................................................................... 4-12
Central Air Conditioner .................................................................................................................. 4-13
Air Conditioner Filter ..................................................................................................................... 4-13
5 – PROPANE GAS
Propane Gas Supply .......................................................................................................................... 5-1
Safe Use of the Propane Gas System ................................................................................................ 5-2
Propane Gas Warnings and Precautions ...........................................................................................5-3
Propane Gas Pressure Regulator ....................................................................................................... 5-4

Table Of Contents
Propane Vaporization in Cold Weather ............................................................................................ 5-5
6 – ELECTRICAL
Electrical Cautions ............................................................................................................................ 6-1
Electrical System – House 120-Volt AC ..........................................................................................6-1
External Power Cord ......................................................................................................................... 6-1
Power Center ..................................................................................................................................... 6-3
Circuit Breakers – House 120-Volt AC ............................................................................................ 6-3
Electrical Outlets – House 120-Volt AC .......................................................................................... 6-4
Ground Fault Circuit Interrupter ....................................................................................................... 6-4
Electrical Generator .......................................................................................................................... 6-5
Electrical System – House 12-Volt DC ............................................................................................ 6-6
Auxiliary Battery Disconnect Switch ............................................................................................... 6-6
Battery Access .................................................................................................................................. 6-7
Battery Care ...................................................................................................................................... 6-7
Circuit Breakers – House 12-Volt .................................................................................................... 6-9
7 – PLUMBING
Fresh Water System .......................................................................................................................... 7-1
Utility Light ...................................................................................................................................... 7-2
Water Pump ...................................................................................................................................... 7-2
Filtered Water Faucet ........................................................................................................................ 7-4
Full-Coach Water Filtration System ................................................................................................. 7-5
Disinfecting Your Fresh Water System ............................................................................................ 7-6
Shower Hose Vacuum Breaker ......................................................................................................... 7-7
Exterior Shower/Wash Station .......................................................................................................... 7-7
Toilet ................................................................................................................................................. 7-7
Waste Water System ......................................................................................................................... 7-8
WaterLine & Tank Drain Valves .................................................................................................... 7-10
Water Heater Bypass Winterization Valve ..................................................................................... 7-11
Winterizing Procedures ................................................................................................................... 7-11
Winterizing Optional Appliances ................................................................................................... 7-16
Water System Drain Valve Locations ............................................................................................ 7-18
8 – ENTERTAINMENT
Video Selection System .................................................................................................................... 8-1
Front TV Ignition Switch Interlock .................................................................................................. 8-2
Audio-Video System Basic Operation .............................................................................................. 8-2
DVD Home Theater System ............................................................................................................. 8-2
CD/DVD Player - Bedroom .............................................................................................................. 8-3
Bedroom DVD Cables ...................................................................................................................... 8-4
Compact Disc Changer ..................................................................................................................... 8-4
Electrical Inverter ............................................................................................................................. 8-4
TV Antenna ....................................................................................................................................... 8-5
TV Signal Amplifier ......................................................................................................................... 8-6
Cable and Satellite Hook-Ups ........................................................................................................... 8-6
TV Digital Satellite System Wiring .................................................................................................. 8-6
TV Digital Satellite System – Manual .............................................................................................. 8-7
TV Digital Satellite System – Automatic ......................................................................................... 8-7

Table Of Contents
TV Digital Satellite Dish – In-Motion .............................................................................................. 8-8
Exterior Entertainment Center .......................................................................................................... 8-9
9 – FURNITURE AND SOFTGOODS
Lounge Chair Base Clamp ................................................................................................................ 9-1
Table and Chairs ............................................................................................................................... 9-1
Sleeping Facilities ............................................................................................................................. 9-2
Dinette/Bed Conversion .................................................................................................................... 9-2
U-Shaped Dinette/Bed Conversion ................................................................................................... 9-3
Sofa/Bed Conversion ........................................................................................................................ 9-4
Rest Easy® Multi-Position Lounge .................................................................................................. 9-5
Theater Seating/Bed Conversion ...................................................................................................... 9-7
Sleep Number® Bed ......................................................................................................................... 9-8
Day/Night Pleated Blinds ................................................................................................................. 9-9
Wood Furniture and Cabinetry ....................................................................................................... 9-10
10 – SLIDEOUT ROOMS AND LEVELING
Slideout Room Travel Locks .......................................................................................................... 10-1
Slideout Room Travel Lock ............................................................................................................ 10-1
Slideout Room Operation – Electric ............................................................................................... 10-3
Slideout Room Operation – Hydraulic ........................................................................................... 10-5
Slideout Room – Extreme Weather Precaution .............................................................................. 10-7
Slideout Room Troubleshooting – Electric .................................................................................... 10-8
Slideout Room Troubleshooting – Hydraulic ................................................................................. 10-9
Slideout Emergency Retraction – Electric .................................................................................... 10-10
Slideout Emergency Retraction - Electric ..................................................................................... 10-11
Slideout Emergency Retraction – Hydraulic ................................................................................ 10-12
Slideout Emergency Retraction - Bedroom .................................................................................. 10-15
General Slideout Care ................................................................................................................... 10-15
Leveling System ........................................................................................................................... 10-16
Checking Hydraulic Oil Level ...................................................................................................... 10-19
11 – MAINTENANCE AND STORAGE
Sealants – Inspection and General Information .............................................................................. 11-1
Roof ................................................................................................................................................ 11-1
Undercarriage .................................................................................................................................. 11-1
Exterior Automotive Paint Finish ................................................................................................... 11-2
Care of Appliques and Decals ......................................................................................................... 11-4
Front End Masks and Paint Damage ............................................................................................... 11-4
Plastic Parts – Cleaning .................................................................................................................. 11-4
Hood Cowl Panel – Cleaning .......................................................................................................... 11-5
Headlights and Exterior Lights ....................................................................................................... 11-5
Interior Soft Goods ......................................................................................................................... 11-6
Cabinetry – Cleaning ...................................................................................................................... 11-7
Solid Surface Countertop – Corian® .............................................................................................. 11-7
Galley Sink ..................................................................................................................................... 11-8
Range and Refrigerator ................................................................................................................... 11-8
Bathroom ........................................................................................................................................ 11-8
Doors and Windows ........................................................................................................................ 11-9

Table Of Contents
Vehicle Storage – Preparation ........................................................................................................ 11-9
Vehicle Storage – Removal .......................................................................................................... 11-10
Coach Maintenance Chart ............................................................................................................. 11-11
Sealants – Recommended Application ......................................................................................... 11-14
12 – MISCELLANEOUS
Loading the Vehicle ........................................................................................................................ 12-1
Weighing Your Loaded Vehicle ..................................................................................................... 12-1
Car or Trailer Towing ..................................................................................................................... 12-3
Trailer Wiring Connector ................................................................................................................ 12-4
Towing Guidelines .......................................................................................................................... 12-4
Fireplace .......................................................................................................................................... 12-5
Entry Step – Electric ....................................................................................................................... 12-6
Tool Storage .................................................................................................................................... 12-7
Roof Ladder .................................................................................................................................... 12-7
Storage Compartment Doors .......................................................................................................... 12-8
Power Awning ................................................................................................................................ 12-8
Manual Awning .............................................................................................................................. 12-9
Windows ......................................................................................................................................... 12-9
Power Roof Ventilator .................................................................................................................. 12-10
Effects of Prolonged Occupancy .................................................................................................. 12-10

1-1
5 - DASH / AUTO
SECTION 1 – INTRODUCTION
Congratulations! We welcome you to the
exciting world of motor home travel and
camping. You will find it convenient and
enjoyable to have all the comforts of home and
still enjoy the great outdoors wherever you
choose to go. Your motor home has been
carefully designed, engineered, and
manufactured to provide years of enjoyment.
Before sliding into the driver’s seat, please
become familiar with operations and features. In
addition, spend some time with the dealer when
you take delivery to learn all you can about your
new motor home.
ABOUT THIS MANUAL
This operator’s manual was prepared to aid
you in the proper care and operation of the
vehicle and equipment.
Please read this manual completely to
understand how everything in your coach works
before taking it on its “maiden voyage”.
NOTE: This manual describes many features of
your motor home and includes
instructions for its safe use.
This manual, including photographs and
illustrations, is of a general nature only.
Some equipment and features described
or shown in this manual may be
optional or unavailable on your model.
Because of Winnebago Industries®’
continuous program of product
improvement, it is possible that recent
product changes and information may
not be included.
The instructions included in this manual
are intended as a guide, and in no way
extend the responsibilities of Winnebago
Industries beyond the standard written
warranty as presented in this manual.
The descriptions, illustrations, and
specifications in this manual were
correct at the time of printing. We reserve
the right to change specifications or
design without notice, and without
incurring obligation to install the same
on products previously manufactured.
The materials in your InfoCase contain
warranty information and operating and
maintenance instructions for the various
appliances and components in your motor home.
NOTE: Many of the instruction sheets and
manuals for the various appliances and
components have been incorporated into
the Operator’s Manual Supplement for
your convenience.
Please read the FAQ in Section 1 of the
Operator’s Manual Supplement for more
details.
Throughout this manual, frequent reference is
made to the vehicle chassis manual that is
provided by the manufacturer of the chassis on
which this motor home is built.
Consult the chassis manual for operating,
safety, and maintenance instructions pertaining
to the chassis section of the motor home.
SAFETY MESSAGES USED IN
THIS MANUAL
Throughout this manual, certain items are
labeled Danger, Warning, Caution, or Note.
These terms alert you to precautions that may
involve damage to your vehicle or a risk to your
personal safety. Read and follow them carefully.
DANGER
DANGER indicates a directly hazardous
situation which, if not avoided, will result
in death or serious personal injury.

SECTION 1 –
INTRODUCTION
1-2
NOTE: A “Note” is not necessarily safety-
related, but indicates a recommendation
or special point of information that could
assist in understanding the use or care of
a feature item.
PRE-DELIVERY INSPECTION
This motor home has been thoroughly
inspected before shipment. Your dealer is
responsible for performing a complete pre-
delivery inspection of the chassis and all motor
home components.
As a part of the pre-delivery inspection
procedure, the dealer is responsible for road
testing the motor home, noting, and correcting
any problems before delivery.
FRONT AXLE TIRE
ALIGNMENT
We recommend that you have the front
suspension and steering alignment checked and
adjusted after you have fully loaded the vehicle
according to your needs. Thereafter, have
alignment inspected periodically to maintain
vehiclesteeringperformanceandprevent uneven
tire wear.
SERVICE AND ASSISTANCE
Your dealer will be glad to provide any
additional information you need, as well as
answer any questions you might have about
operating the equipment in your motor home.
When it comes to service, remember that your
dealer knows your vehicle best and is interested
in your satisfaction. Your dealer will provide
qualitymaintenance and anyother assistancethat
you may require during your ownership of this
vehicle.
If you need warranty repairs while traveling,
you may take your motor home to any authorized
Winnebago Industries®dealership and request
their assistance.
See the Motor Home Service Dealer directory
in your InfoCase.
REPORTING SAFETY DEFECTS
If you believe that your vehicle has a defect
which could cause a crash or could cause injury
or death, you should immediately inform the
National Highway Traffic Safety Administration
(NHTSA) in addition to notifying Winnebago
Industries, Inc.
If NHTSA receives similar complaints, it may
open an investigation, and if it finds that a safety
defect exists in a group of vehicles, it may order
a recall and remedy campaign. However,
NHTSA cannot become involved in individual
problems between you, your dealer, or
Winnebago Industries®.
To contact NHTSA, you may either call the
Vehicle Safety Hotline toll-free at:
1-888-327-4236; (TTY: 1-800-424-9153)
or go to their website at http://www.safercar.gov
or write to:
Administrator, NHTSA
1200 New Jersey Avenue S.E.
Washington, D.C. 20590
You can also obtain other information about
motor vehicle safety from the NHTSA website
at http://www.safercar.gov
WARNING
WARNING indicates a potentially
hazardoussituationwhich,ifnotavoided,
could result in death or serious personal
injury.
CAUTION
CAUTION indicates a potentially
hazardoussituationwhich,ifnotavoided,
could result in damage mainly to
equipmentorproperty,butinsomecases
may also result in minor or moderate
personal injury.

1-3
SECTION 1 –
INTRODUCTION
OCCUPANT AND CARGO
CARRYING CAPACITY LABEL
Thislabelis affixed inthe driver’s area next to
or near the Vehicle Certification Label. It
contains vehicle occupant and cargo carrying
capacity along with the number of seat belt
positions in the vehicle. The label also provides
the weight of a full load of water and advises that
this weight, along with the tongue weight counts
as cargo.
If any weight exceeding 45.4 kg (100 lbs.) is
added to your coach between final vehicle
certification and first retail sale, the occupant and
cargo carrying capacity must be corrected and a
label similar to the one shown below will be
affixed inside your coach.

SECTION 1 –
INTRODUCTION
1-4
VEHICLE CERTIFICATION LABEL
This label is affixed to the lower driver side armrest panel, driver door, or the driver side door jamb,
depending on model. It contains vehicle identification numbers and other important reference information.
EXPLANATION OF DATA
1. Chassis manufacturer.
2. Chassis manufacture date.
3. MonthandyearofmanufactureatWinnebago
Industries®.
4. Gross Vehicle Weight Rating: Total
permissible weight of the vehicle, including
driver, passengers, total cargo carried
(including all liquids), and equipped with all
options.
5. Gross Axle Weight Rating: Total permissible
weight allowed for the front and rear axles
(listed in pounds and kilograms).
6. Suitable Tire Choice: Tires recommended to
meethandlingandsafetyrequirements.When
replacing any of the tires on your vehicle,
always replace with a tire that meets these
specifications.
7. Suitable Rim Choice: Wheel rims
recommended to meet handling and safety
requirements.Whenreplacingany oftherims
onyourvehicle,alwaysreplacewitharimthat
meets these specifications.
8. ColdInflation Pressure:Inflation pressures at
Gross Axle Weight Ratings recommended
(while cold) for the tires originally equipped
onyourvehicle.Thesepressurelevelsmustbe
maintained to assure proper handling, safety,
and fuel economy.
9. Rear Axle Wheel Configuration: Single or
Dual as it relates to the inflation.
10. Serial Number: This is the serial number
assigned to the completed vehicle by
Winnebago Industries.
11. Vehicle Identification Number (VIN): This
number identifies the chassis on which the
motorhomeisbuilt.The10thdigitoftheVIN
designates the chassis model year. (7=2007,
8=2008,etc.).Thisinformationisusefulwhen
ordering chassis repair parts.
12. Type: States the NHTSA designated usage
classification for your motor home. MPV
signifies a Multi-purpose Passenger Vehicle.
13. Model: Lists the Winnebago®product model
number of your vehicle.
14. Color: Signifies the color code number of the
decor used throughout the vehicle. This
numberisnecessaryfororderingreplacement
cushions, curtains, carpet, etc.

1-5
SECTION 1 –
INTRODUCTION
Model 32H 35L 35P 38T
Length 32' 10" 36' 35' 5" 38' 9" Exterior Height112' 3" 12' 3" 12' 3" 12' 3"
Exterior Width28' 5" 8' 5" 8' 5" 8' 5"
Exterior Storage3(cu.ft.) 72.7 78 85.9 100.4
Awning Length 16' 15' 17' 13' Interior Height 7' 2" 7' 2" 7' 2" 7' 2" Interior Width 8' 8' 8' 8' Freshwater Capacity w/Heater4(gal.) 85 88 85 88
Holding Tank Capacity - Black/Gray4(gal.) 43/48 65/53 43/60 52/68
LP Capacity5(gal.) 23 28 28 28
Fuel Capacity (gal.) 75 75 75 75 GCWR6(lbs.) 26,000
A
/26,000B26,000
A
/30,000
A
/26,000B/30,000C26,000
A
/30,000
A
/26,000B/30,000C30,000
A
/30,000C
GVWR (lbs.) 22,000
A
/22,000B22,000
A
/24,000
A
/22,000B/24,000C22,000
A
/24,000
A
/22,000B/24,000C24,000
A
/24,000C
GAWR - Front (lbs.) 7,500
A
/8,500B7,500
A
/9,000
A
/8,500B/9,000C7,500
A
/9,000
A
/8,500B/9,000C9,000
A
/9,000C
GAWR - Rear (lbs.) 14,500
A
/15,000B14,500
A
/15,500
A
/15,000B/15,500C14,500
A
/15,500
A
/15,000B/15,500C15,500
A
/15,500C
Wheelbase 220" 228" 228" 266"
SEE NOTES ON FOLLOWING PAGE.
SPECIFICATIONS AND CAPACITIES

SECTION 1 –
INTRODUCTION
1-6
A
Ford
®
Chassis 6.8L Super-Duty V10 SOHC Triton
®
engine, 362-hp, TorqShift
™
, 5-speed overdrive transmission, HydroMax brakes, 4-wheel ABS, 130-amp.
alternator
B
Workhorse
™
Chassis W22-Series 8.1L GM Vortec V8 340-hp, Allison
®
1000 MH 6-speed automatice with overdrive transmission, 145-amp. alternator, 4-
wheel ABS
C
Workhorse
™
Chassis W24-Series 8.1L GM Vortec V8 340-hp, Allison
®
2350 MH 6-speed with two overdrive gears, 145-amp. alternator, 4-wheel ABS
1
The height of each model is measured to the top of the tallest standard feature and is based on the curb weight of a typically equipped unit. The actual height
of your vehicle may vary by several inches depending on chassis or equipment variations. Please contact your dealer for further information.
2
Floorplans feature a wide-body design - over 96". In making your purchase decision, you should be aware that some states restrict access on some or all state
roads to 96" in body width. Before making your purchase decision, you should confirm the road usage laws in the states of interest to you.
3
The load capacity of your motor home is designated by weight, not by volume, so you cannot necessarily use all available space when loading your motor
home.
5
Capacities shown are tank manufacturer's listed water capacity (W.C.). Actual filled LP capacity is 80% of listing due to overfilling prevention device on tank.
6
Actual towing capacity is dependent on your particular loading and towing circumstances which includes the GVWR, GAWR, and GCWR as well as adequate
trailer brakes. Please refer to the chassis operator's manual of your vehicle for further towing information.
4
Capacities are based on measurements prior to tank installation. Slight capacity variations can result due to installation applications.
See Towing Guidlines in Miscellaneous Section Specifications and Capacities Notes:

1-7
SECTION 1 –
INTRODUCTION
OWNER AND VEHICLE INFORMATION
OWNER INFO
Owner’s Name(s) __________________________________________________________________
Address __________________________________________________________________________
__________________________________________________________________________
VEHICLE INFORMATION
Motor Home Model Number _________________________________________________________
Motor Home Serial Number __________________________________________________________
Chassis Vehicle Identification No. (VIN)________________________________________________
Vehicle Mileage at Delivery __________________________________________________________
Selling Dealer Name________________________________________________________________
Address __________________________________________________________________________
__________________________________________________________________________
YOUR WINNEBAGO INDUSTRIES®DEALER /SERVICE CENTER
Name____________________________________________________________________________
Address __________________________________________________________________________
__________________________________________________________________________
Contact ____________________________________________Phone ________________________
CHASSIS SERVICE CENTER
Name____________________________________________________________________________
Address __________________________________________________________________________
__________________________________________________________________________
Contact ____________________________________________Phone ________________________
RV INSURANCE POLICY
Company_________________________________________________________________________
Policy Number ____________________________________________________________________
Agent______________________________________________Phone ________________________

SECTION 1 –
INTRODUCTION
1-8
2009 NEW VEHICLE LIMITED WARRANTY
WINNEBAGO INDUSTRIES, INC.
WARRANTY COVERAGE TO OWNER
Winnebago Industries, Inc. of Forest City, Iowa, warrants each new
Winnebago and Itasca motor home to the owner for recreational use
in the U.S.A. and Canada as follows:
BASIC LIMITED WARRANTY
WINNEBAGO INDUSTRIES’ RESPONSIBILITY
Any part of the vehicle subject to this warranty that is found to be
defective in material or workmanship under normal use and
maintenance will be repaired or replaced at Winnebago Industries’
option without charge to the customer for parts or labor upon notice
of the defect.
WARRANTY PERIOD
The basic Warranty Period is 12 months or 15,000 miles (24,135
kilometers), on the odometer, whichever occurs first. The Warranty
Period for all coverages begins on the date the vehicle is delivered to
the first retail purchaser or first placed in service as a demonstrator
or company vehicle.
ONLY WARRANTY
This limited warranty is the only warranty made or authorized by
Winnebago Industries. Winnebago Industries makes no other
promises, representations or warranties concerning the vehicle or
other matters set forth herein. Winnebago Industries does not
authorize any person to create for it any other obligations or liability
in connection with this vehicle.
DEALER’S REPRESENTATIONS EXCLUDED
Winnebago Industries shall not be bound by any undertaking,
representation, or warranty made by any dealers selling its product
to any purchaser of its products.
EXCLUSIVE REMEDY
THE PERFORMANCE OF REPAIRS IS THE EXCLUSIVE REMEDY
UNDER THIS LIMITED WARRANTY OR ANY IMPLIED
WARRANTY. ANY IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE APPLICABLE TO
THIS VEHICLE ARISING BY WAY OF STATE LAW IS LIMITED IN
DURATION TO THE DURATION OF THIS WRITTEN WARRANTY
AS HEREINBEFORE OR HEREINAFTER PROVIDED.
LIMITATION ON LIABILITY
WINNEBAGO INDUSTRIES SHALL NOT BE LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING
FROM BREACH OF THIS WRITTEN WARRANTY OR ANY
IMPLIED WARRANTY. SUCH DAMAGES INCLUDE, BUT ARE
NOT LIMITED TO, LOSS OF TIME, INCONVENIENCE, OR OTHER
CONSEQUENTIAL DAMAGE INCLUDING EXPENSE FOR
GASOLINE, TELEPHONE, TRAVEL, LODGING, LOSS OR
DAMAGE TO PERSONAL PROPERTY, OR LOSS OF REVENUE.
Some states do not allow limitations on how long an implied warranty
will last or the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to
you.
ITEMS NOT SUBJECT TO WARRANTY COVERAGE
Chassis, drivetrain and related components*
Wheels*
Tires*
Any other part or component covered by a written warranty issued by
its manufacturer*
Service Items, such as Windshield Wiper Blades, Lubricants, Fluids
& Filters
Adjustments
Rust and Corrosion
*These items are covered under the manufacturer’s individual
warranty.
ADDITIONAL EQUIPMENT NOT COVERED
Winnebago Industries cannot and does not accept any responsibility
in connection with any of its motor homes for additional equipment or
accessories installed at any dealership or other place of business, or
by any other party other than Winnebago Industries. Such installation
of equipment or accessories by any other party will not be covered
by the terms of this warranty.
36 MONTH/36,000 MILE STRUCTURAL WARRANTY
At the expiration of the Basic Coverage and for the remainder of the
period of 36 months or 36,000 miles (57,924 kilometers), on the
odometer, whichever occurs first, Winnebago Industries warrants the
following:
1. Structural defects of the subfloor, floor, and slide-out room
assembly. Floor lamination failure and lamination failure of the
subfloor panels and risers are covered by the structural
warranty.
2. Body Thermo-Panel®Lamination of the sidewalls and backwall
against delamination. Body Thermo-Panel®Lamination is the
bonding of the exterior skin and the interior paneling to an
insulating core material. Delamination (separation of layers)
caused by other factors such as physical damage or failed
sealants is not covered by this warranty.
This warranty gives you specific legal rights and you may also have
other rights which vary from state to state.
Also, this warranty shall not apply to failures, damage or
malfunctions resulting from normal wear, misuse, abuse, negligence,
alteration, accident, fire, improper repair of the vehicle or failure to
follow recommended maintenance requirements.
OWNER’S RESPONSIBILITY-CARE AND MAINTENANCE
It is the owner’s responsibility to perform the care, maintenance and
proper load distribution described in the operator’s manual which
accompanies your motor home. Any damage which results to your
vehicle as a result of your failure to perform such duties, is not
covered.
Damage to appearance items such as fiberglass, metal, paint,
fabrics and trim, may occur during manufacturing or transporting.
Normally, any factory defect or damage is corrected at the factory. In
addition, dealers are obligated to inspect each vehicle upon delivery
to them and prior to delivery to you. You should also immediately
inspect appearance items and advise your selling dealer of any
discrepancies. Damage and deterioration due to use and exposure,
such as rust or corrosion is not covered by this warranty.

1-9
SECTION 1 –
INTRODUCTION
OBTAINING WARRANTY REPAIRS
While any Winnebago Industries motor home dealer can perform
warranty service, we recommend you return to the dealership that
sold you your vehicle. If you are touring or have moved, contact any
Winnebago Industries motor home dealer in the United States or
Canada for warranty service.
If a part of the system covered by this limited warranty fails to
function or requires service during the warranty period:
1. Promptly take the vehicle to the selling dealer for repair or
inspection.
2. Written notice of defects must be given to the selling dealer and
manufacturer.
3. If the dealer is incapable of making the repairs, request that he
contact Winnebago Industries, Inc.
4. If, after the above steps are completed and the repair is not
made, the customer should contact Winnebago Industries, Inc.,
605 West Crystal Lake Road, P.O. Box 152, Forest City, Iowa
50436, Attention: Owner Relations Department (800-537-1885)
and furnish the following information:
− The complete serial number of the vehicle
− Date of retail purchase
− Selling dealer’s name
− Nature of the service problem, and a brief explanation of
the steps or service the dealer has performed, and the
results obtained. The customer may be directed to another
dealer or service center for repairs to be completed, if such
a dealer or service center is better able to complete the
repair.
Winnebago Industries may, at its option, request the vehicle be
returned to Forest City, Iowa for repair. If the customer refuses to
allow repairs to be performed at the Forest City, Iowa facility, the
warranty on that repair will be voided.
5. If after the above steps are completed and the repairs are not
satisfactory, the customer may contact the Service
Administration Manager of Winnebago Industries, and request a
customer relations board meeting to resolve the problem. This
action, however, is not mandatory.
6. Certain components are covered by warranties provided by
individual component manufacturers. Please refer to the
component’s information supplied in the vehicle’s InfoCase.
COMMENCEMENT OF ACTIONS
Any action for breach of The Basic Limited or Structural Warranty or
any implied warranty shall be commenced within one-year after
expiration of the warranty.
CHANGES IN DESIGN
Winnebago Industries, Inc. reserves the right to make changes in
design and changes or improvements upon its products without
imposing any obligation upon itself to install the same upon its
products theretofore manufactured.
NEW YORK:
If your motor home has been repaired three or more times for the
same nonconformity, defect, or condition, or if your motor home has
been out of service by reason of repair for twenty-one days, Section
198-a of the General Business Law of the State of New York
requires you to provide written notice by certified mail, return receipt
requested, to Winnebago Industries or its authorized dealer before
making any claim under that section of the law. If you do have
problems with your motor home, you should provide written notice to
Winnebago Industries at the following address:
Winnebago Industries, Inc.
605 West Crystal Lake Road
P.O. Box 152
Forest City, Iowa 50436
Attn: Owner Relations
CALIFORNIA:
Winnebago Industries participates in the Consumer Arbitration
Program for Recreation Vehicles (CAP-RV). This third-party dispute
resolution program is available, at no charge to you, to settle
unresolved warranty disputes for recreational vehicles. This dispute
resolution program reviews eligible product and service related
complaints involving warranty covered components.
To find out more about the program, or to request an
application/brochure, please call the Arbitration Administration office
toll-free 800-279-5343.
The CAP-RV program operates as a certified mechanism under the
review of the California Arbitration Certification Program. You must
utilize the arbitration program before claiming rights conferred by 15
USC section 2310 (Uniform Commercial Code) or Civil Code section
1793.22(b) (Tanner Consumer Protection Act). You are not required
to use the program if you choose to seek redress by pursuing rights
and remedies not created by those laws.
Members of the Armed Forces who purchased the vehicle in
California, or who were stationed in or a resident of California at the
time of purchase (regardless of state of purchase) or who are
stationed in California at the time of application to this program, may
utilize the CAP-RV program.
12/07

2-1
5 - DASH / AUTO
SECTION 2 – SAFETY AND PRECAUTIONS
GENERAL WARNINGS
• Only seats equipped with seat belts are to be
occupied while the vehicle is moving.
• Make sure all passengers have seat belts
fastened. Lap belts should fit low on the hips
and upper thighs. The shoulder belt should be
positioned snug over the shoulder.
• For pregnant women, the lap belt should be
placed under the abdomen and across the
upper thighs. The shoulder belt should be
positioned across the center of the chest.
Consult your doctor if you have any
questions.
• Child restraints should be installed properly
accordingtomanufacturer’sinstructions. See
“Child Restraints”.
• All moveable or swiveling seats should be
placed and locked in position while the
vehicle is moving.
• Never let passengers stand or kneel on seats
while the vehicle is moving.
• Sleeping facilities are not to be utilized while
vehicle is moving.
• Examine the escape window and be familiar
with its operation.
• Inspect the fire extinguisher monthly for
proper charge and operating condition. This
should also be done before beginning a
vacation or any extended trip.
DRIVING SAFETY
• Donotattempttoadjustthedriver’sseatwhile
the vehicle is moving.
• Donot adjust tilt steeringin a movingvehicle.
• Do not operate the cruise control on icy or
extremely wet roads, winding roads, in heavy
traffic, or in any other traffic situation where
a constant speed cannot be maintained.
• Usecarewhenacceleratingordeceleratingon
a slippery surface. Abrupt speed changes can
cause skidding and loss of control.
• Never drive the vehicle with a slideout room
extended.
• Drivingthroughwaterdeepenoughtowetthe
brakes may affect stopping distance or cause
the vehicle to pull to one side. Check brake
operation in a safe area to be sure they have
notbeenaffected.Neveroperateanyvehicleif
a difference in braking efficiency is
noticeable.
• Adverse weather conditions and extremes in
terrain may affect handling and/or
performance of your vehicle. Refer to your
chassis manual for related information.
FUEL AND PROPANE GAS
• All pilot lights must be extinguished and
appliances turned off while refilling the fuel
tank or LP gas tank.
• Never smoke while refilling vehicle fuel tank
or LP gas tank.
• Do not bring or store LP gas containers,
gasoline, or other flammable liquids onboard
the vehicle because a fire or explosion may
result. LP gas containers are equipped with
safety valves, which relieve excessive
pressure by discharging gas to the
atmosphere.
DANGER
Allpilotlights,appliances,andtheir
ignitors(seeoperatinginstructions)
shall be turned off before refueling
of motor fuel tanks and/or propane
containers.Failureto complycould
result in death or serious injury.

SECTION 2 –
SAFETY AND PRECAUTIONS
2-2
• Never use an open flame to test for LP gas
leaks. Replace all protective covers and caps
on LP system after filling. Make sure valve is
closed and the door is latched securely.
• Never connect natural gas to the LP gas
system.
• When lighting range burners, do not turn
burner controls to “On” and allow gas to
escape before lighting match.
• Portable fuel-burning equipment, including
wood and charcoal grills and stoves shall not
be used inside the recreational vehicle. The
use of this equipment inside the recreational
vehicle may cause fires or asphyxiation.
• LP gas regulators must always be installed
with the diaphragm vent facing downward.
Regulators are equipped with a protective
cover. Make sure that the regulator vent faces
downward and that the cover is kept in place
tominimizeventblockage,whichcouldresult
in excessive gas pressure causing fire or
explosion.
• The following warning label is located in the
cooking area to remind you to provide an
adequate supply of fresh air for combustion.
Unlike large homes, the oxygen supply inside
a recreational vehicle is limited due to its size. To
avoid danger of asphyxiation, provide proper
ventilation when using the gas range top or gas
oven. It is especially important that the gas oven
and range top not be used for comfort heating.
Danger of asphyxiation is greater when these
appliances are used for long periods of time.
LP GAS LEAKS
The following procedures are located in the
vehicle near the range area. If you smell gas
within the vehicle, quickly and carefully perform
the procedures listed.
IF YOU SMELL GAS
• Extinguish any open flames, pilot lights, and
all smoking materials.
• Do not touch electrical switches.
• Shut off the gas supply at the tank valve(s) or
gas supply connection.
• Open doors and other ventilating openings.
• Leave the area until odor clears.
• Have the gas system checked and leakage
source corrected before using again.
PROPANE GAS LEAK
DETECTOR
Your coach is equipped a propane gas leak
detector, similar to the one shown below. The
leak detector sounds an alarm if an unsafe
amount of propane gas is present inside the
coach.
Because propane gas is heavier than air, the
leak detector is located on a cabinet face near the
floor of the coach.
WARNING
It is not safe to use cooking
appliances for comfort heating.
Cooking appliances need fresh air for
safe operation. Before operation:
• Open overhead vent or turn on
exhaust fan and;
• Open window. Propane Gas Leak Detector (Typical)

2-3
SECTION 2 –
SAFETY AND PRECAUTIONS
Power Connection
The propane gas leak detector is powered by
the house batteries. If the house/coach battery
switch is shut off or the battery cable is
disconnected from the batteries, the alarm will
not work. The propane gas leak detector fuse or
circuit breaker is located in the 12-volt house
electrical load center.
Because the propane gas leak detector is
connected to the house battery, it is always
drawing a small amount of current. Even though
thiscurrentdrawisslight, itcoulddrainthehouse
battery during storage periods when the house
battery will not be charged regularly by the
engine or shoreline.
Further Information
See the manufacturer’s information in your
InfoCase for further instructions on nuisance
alarms and care and testing of the propane gas
leak detector.
CARBON MONOXIDE
WARNING
The best protection against carbon monoxide
entry into the vehicle body is a properly
maintained engine exhaust and ventilation
system. It is recommended that the exhaust
system and body be inspected by a qualified
motor home service center:
• Each time the vehicle is serviced for an oil
change.
• Whenever a change in the sound of the
exhaust system is noticed.
• Whenever the exhaust system, underbody, or
rear of the vehicle is damaged.
To allow proper operation of the vehicle’s
ventilation system, keep front ventilation inlet
grill clear of snow, leaves, or other obstructions
at all times. DO NOT OCCUPY A PARKED
VEHICLE WITH ENGINE RUNNING FOR
AN EXTENDED PERIOD.
Do not run engine in confined areas, such as a
garage, except to move vehicle into or out of the
area.
CARBON MONOXIDE ALARM
Your coach is equipped with a carbon
monoxide (CO) alarm located on the ceiling in
the bedroom area. The CO alarm is powered by a
9-volt battery and has a sensor that is designed to
detect toxic carbon monoxide gas fumes
resulting from incomplete combustion of fuel. It
will detect CO gas from any combustion source
suchasthe furnace, gasrange/oven, water heater,
refrigerator, chassis engine, and electric
generator engine.
WARNING
EXPLOSION HAZARD: DONOT use an
open flame to test for gas leaks. When
testing for gas line leaks with a soapy
water solution, DO NOT use a detergent
containing ammonia or chlorine. These
substances may generate a chemical
reaction causing corrosion to gas lines,
resulting in dangerous leak conditions.
Death or serious injury can result.
WARNING
Avoid inhaling exhaust gases, as they
contain carbon monoxide, which is a
colorless, odorless, and poisonous gas.
Press button to test
Carbon Monoxide Alarm

SECTION 2 –
SAFETY AND PRECAUTIONS
2-4
Replacement
When replacing this alarm, we recommend
replacingonlywitha similarmodel. Otherbrands
may not be recommended for RV application.
We recommend obtaining a replacement from
your Winnebago Industries®dealer.
Further Information
Please read the information provided by the
manufacturer,whichisincluded inyourInfoCase
for further information.
SMOKE ALARM
Your motor home is equipped with a smoke
alarm located on the ceiling in the lounge area.
The smoke alarm is powered by a 9-volt battery
and has a sensor that is designed to detect smoke.
The following label is affixed to the smoke
alarm.
Further Information
See the manufacturer’s information in your
InfoCase for further instructions.
Replacement
When replacing this alarm, we recommend
replacingonlywithasimilarmodel.Otherbrands
may not be recommended for RV application.
We recommend obtaining a replacement from
your Winnebago Industries®dealer.
FIRE EXTINGUISHER
A dry chemical fire extinguisher is located
near the main entrance door.
We recommend that you become thoroughly
familiarwith theoperatinginstructionsdisplayed
on the side of the fire extinguisher or in the
information supplied in your InfoCase.
We also recommend that you inspect the fire
extinguisher for proper charge at least once a
month in accordance with National Fire
Protection Association (NFPA)
recommendations as stated on the label.
If the charge is insufficient, the fire
extinguisher must be replaced.
WARNING
Failure to replace this product by the
“REPLACE BY DATE” printed on the
alarm cover may result in death by
Carbon Monoxide poisoning.
Smoke Alarm
Press button to test
Fire Extinguisher
(Typical installation - your coach may
vary according to model and floorplan)
