SUNFEEL CGS185SB User manual

FREEZER
instruction booklet
CGS185SB
CONGELADOR
Manual de instrucciones
CONGELADOR
Manual de Instruções

EN - 1 -
Index
BEFORE USING YOUR APPLIANCE .................................................................. 2
General warnings ............................................................................................................... 2
Old and out-of-order fridges or freezers ........................................................................... 4
Safety warnings .................................................................................................................. 4
Installing and operating your freezer ................................................................................ 5
Before using your freezer ................................................................................................... 6
Information on No-Frost Technology ................................................................................ 6
USAGE INFORMATION ...................................................................................... 7
Control panel ...................................................................................................................... 7
Warnings about temperature adjustments ...................................................................... 8
Accessories ........................................................................................................................ 9
Making Ice Cubes ........................................................................................................................ 9
Ice tray .......................................................................................................................................... 9
PLACING THE FOOD ......................................................................................... 9
CLEANING AND MAINTENANCE ....................................................................... 13
Defrosting ......................................................................................................................... 13
Replacing LED lighting .................................................................................................... 14
TRANSPORTATION AND CHANGING OF INSTALLATION POSITION ............... 14
BEFORE CALLING SERVICE ............................................................................ 15
Advice for Saving Energy.................................................................................................. 17
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ........................ 18

EN - 2 -
CHAPTER 1. BEFORE USING YOUR APPLIANCE
General warnings
WARNING: Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means to
accelerate the defrosting process, other than those recommended
by the manufacturer.
WARNING: Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: In order to avoid any hazards resulting from the instability
of the appliance, it must be fixed in accordance with the following
instructions:
WARNING: When positioning the appliance, ensure the supply cord
is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets or portable
power supplies at the rear of the appliance.
Symbol ISO 7010 W021
WARNING; Risk of fire / flammable materials
• If your appliance uses R600a as a refrigerant (this information
will be provided on the label of the cooler) you should take care
during transportation and installation to prevent the cooler
elements from being damaged. R600a is an environmentally
friendly and natural gas, but it is explosive. In the event of a leak
due to damage of the cooler elements, move your fridge away
from open flames or heat sources and ventilate the room where
the appliance is located for a few minutes.
• While carrying and positioning the fridge, do not damage the
cooler gas circuit.

EN - 3 -
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
• This appliance is intended to be used in household and domestic
applications such as:
- staff kitchen areas in shops, offices and other working
environments.
- farm houses and by clients in hotels, motels and other residential
type environments.
- bed and breakfast type environments;
- catering and similar non-retail applications.
• If the socket does not match the refrigerator plug, it must be
replaced by the manufacturer, a service agent or similarly
qualified persons in order to avoid a hazard.
• A specially grounded plug has been connected to the power
cable of your refrigerator. This plug should be used with a
specially grounded socket of 16 amperes. If there is no such
socket in your house, please have one installed by an authorised
electrician.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• If the supply cord is damaged, it must be replaced by the
manufacturer, an authorised service agent or similar qualified
persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes exceeding
2000 m.

EN - 4 -
Safety warnings
• Do not connect your freezer to the mains electricity supply using an
extension lead.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow children to
play with the appliance or let them hang off the door.
• Never touch the power cord/plug with wet hands as this could cause a
short circuit or electric shock.
• Do not place glass bottles or beverage cans in the ice-making
compartment as they can burst as the contents freeze.
• Do not place explosive or flammable material in your freezer. Place
drinks with high alcohol content vertically in the freezer and make sure
that their tops are tightly closed.
• When removing ice from the ice-making compartment, do not touch it.
Ice may cause frost burns and/or cuts.
Old and out-of-order fridges or freezers
• If your old fridge or freezer has a lock, break or remove the lock before
discarding it, because children may get trapped inside it and may cause
an accident.
• Old fridges and freezers may contain isolation material and refrigerant
with CFC or HFC. Therefore, take care not to harm environment when you
are discarding your old fridges or freezers.
Please ask your municipal authority about the disposal of the WEEE reuse, recycle and
recovery purposes.
Notes:
• Please read the instruction manual carefully before installing and using your
appliance. We are not responsible for the damage occurred due to misuse.
• Follow all instructions on your appliance and instruction manual, and keep this
manual in a safe place to resolve the problems that may occur in the future.
• This appliance is produced to be used in homes and it can only be used in domestic
environments and for the specified purposes. It is not suitable for commercial or
common use. Such use will cause the guarantee of the appliance to be cancelled
and our company will not be responsible for losses incurred.
• This appliance is produced to be used in houses and it is only suitable for cooling /
storing food. It is not suitable for commercial or common use and/or for storing
substances except for food. Our company is not responsible for losses to be incurred
in the contrary case.

EN - 5 -
• Do not touch frozen goods with wet hands. Do not eat ice-cream or ice cubes
immediately after you have taken them out of the ice-making compartment.
• Do not re-freeze frozen goods after they have melted. This may cause health issues
such as food poisoning.
• Do not cover the body or top of freezer with lace. This affects the performance
of your freezer.
• Secure any accessories in the freezer during transportation to prevent
damage to the accessories.
• When the door of the freezer is closed,
a vacuum seal will form. W ait for
about 1 minute before reopening it.
• This application is optional for easy
op en ing of the door. W ith this
application, a little condensation may
occur around this area and you may
remove it.
• Do not use plug adapter
Installing and operating your freezer
Before starting to use your freezer, you should pay attention to the following points:
• The operating voltage for your freezer is 220-240 V at 50Hz.
• W e do not accept responsibility for any damages that occur due to ungrounded
usage.
• Place your freezer where it will not be exposed to direct sunlight.
• Your appliance should be at least 50 cm away from stoves, gas ovens and heater
cores, and at least 5 cm away from electrical ovens.
• Your freezer should never be used outdoors or exposed to rain.
• When your freezer is placed next to a deep freezer, there should be at
least 2 cm between them to prevent humidity forming on the outer
surface.
• Do not place heavy items on the appliance.
• Do not place anything on your freezer, and install your freezer in a
suitable place so that at least 15 cm of free space is available above
it.
• Use the adjustable front legs to make sure your appliance is level and stable. You
can adjust the legs by turning them in either direction. This should be done before
placing food in the freezer.
• Before using your freezer, wipe all parts with a solution of warm water and a teaspoon
of sodium bicarbonate, then rinse with clean water and dry.
Place all parts in the freezer after cleaning.
• Install the plastic distance guide (the part with black vanes at the rear)
by turning it 90° (as shown in the figure) to prevent the condenser from
touching the wall.
• The freezer should be placed against a wall with a free space not
exceeding 75 mm.

EN - 6 -
Before using your freezer
• W hen using your freezer for the first time, or after transportation,
keep it in an upright position for at least 3 hours before plugging into
the mains. This allows efficient operation and prevents damage to
the compressor.
• Your freezer may have a smell when it is operated for the first time. This is normal and
the smell will fade away when your freezer starts to cool.
• This appliance is designed to work in difficult climate conditions (up to 43 °C or
110° F) and is powered with ‘Freezer Shield’ technology which ensures that
the frozen food in the freezer will not defrost even if the ambient temperature
falls as low as -15 °C. So you may then install your appliance in an unheated
room without having to worry about frozen food in the freezer being spoilt.
When the ambient temperature returns to normal, you may continue using the
appliance as usual.
Information on No-Frost Technology
No-frost freezers differ from other static freezers in their operating
principle.
In normal freezers, the humidity entering the freezer due to opening the
door and the humidity inherent in the food causes freezing in the freezer
compartment. To defrost the frost and ice in the freezer compartment,
you are periodically required to turn off the freezer, place the food that
needs to be kept frozen in a separately cooled container and remove
the ice gathered in the freezer compartment.
The situation is completely different in no-frost freezers. Dry and cold
air is blown into the freezer compartment homogeneously and evenly
from several points via a blower fan. Cold air dispersed homogeneously
and evenly between the shelves cools all of your food equally and
uniformly, thus preventing humidity and freezing.
Therefore your no-frost freezer allows you ease of use, in addition to its
huge capacity and stylish appearance.

EN - 7 -
CHAPTER 2. USAGE INFORMATION
Freezer partition temperature setting button
This button allows setting temperature of the freezer. In order to set values for freezer
partition, press this button. Use this button also to activate SF mode.
Alarm light
In case of a problem within the freezer, the alarm led will release red light
Super freezer mode
When would it be used?
• To freeze huge quantities of food.
• To freeze fast food.
• To freeze food quickly.
• To store seasonal food for a long time.
How to use?
• Press temperature set button until super freezing light comes on.
• Super freezing led will light during this mode.
• Maximum amount of fresh food (in kilograms) to be frozen within 24 hours is
shown on the appliance label.
• For optimal appliance performance in maximum freezer capacity, set the
appliance to active SF mode 24 hours before you put the fresh food into the
freezer.
During this mode:
If you press temperature set button, the mode will be cancelled and the setting will be
restored from -16.
Control panel
Freezer temperature
set button
Symbol of
Super Freezing Mode
alarm indicator led
Freezer adjusted
temperature indicator

EN - 8 -
Warnings about temperature adjustments
• If you have made any temperature adjustments, they will not be deleted if an energy
breakdown occurs.
• Do not start another adjustment before completing one adjustment.
• Temperature adjustments should be made according to the frequency of door openings
and the quantity of food kept inside the freezer.
• When you first switch on the appliance, allow it to operate for 24 hours continuously
to cool down to the correct temperature.
• During this initial 24 hour period do not open the door or place a lot of food inside the
appliance.
• If the appliance is switched off or unplugged, wait at least 5 minutes before plugging
the appliance in or restarting it in order not to damage the compressor.
• Your freezer is designed to operate within specific ambient temperature ranges,
according to the climate class stated on the information label. We do not recommend
operating your fridge outside the stated temperatures value limits.
• This appliance is designed for use at
an amb ient temperature within the
16°C - 43°C range.
Freezer temperature settings
• The initial temperature of the Setting Display is -18°C.
• Press freezer setting button once.
• Every time you press the button, the setting temperature will decrease. (-16°C, -18°C,
-20°C,.. super freezing)
• If you press freezer setting button until super freezer symbol is displayed on Freezer
Settings Display and you do not press any button within the following 3 seconds,
Super Freezing will blink.
• If you keep on pressing, it will restart from last value.
Climate Class Ambient Temperature (°C)
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
T/SN Between 10 and 43 (°C)
Important installation instructions
This appliance is designed to work in difficult climate conditions (up to 43 degrees C or
110 degrees F) and is powered with ‘Freezer Shield’ technology which ensures that the
frozen food in the freezer will not defrost even if the ambient temperature falls as low as
-15 °C. So you may then install your appliance in an unheated room without having to
worry about frozen food in the freezer being spoilt. When the ambient temperature
returns to normal, you may continue using the appliance as usual.

EN - 9 -
Ice tray
• Fill the ice tray with water and place in freezer compartment.
• After the water completely turned into ice, you can twist the tray as shown below to get
the ice cube.
Accessories
Making Ice Cubes
• Pull the lever towards you and remove the ice maker
tray
• Fill with water to the level of line
• Hold the left end of the lever and set the ice-tray on
the icebox
• When ice cubes are formed, twist the lever to drop
ice cubes into the ice box.
Do not fill the icebox with water in order to make
ice. It can break.
CHAPTER 3. PLACING THE FOOD
• The freezer compartment is used for freezing fresh food, for storing frozen foods for
the period of time indicated on packaging and for making ice cubes..
• Do not put fresh and warm food next to frozen food as it can thaw the frozen food.
• While freezing fresh foods (i.e. meat, fish and mincemeat) divide them in portions
you will use in a single serving.
• For storing frozen foods, the instructions shown on frozen food packages should
always be followed carefully. If no information is provided, food should not be stored
for more than 3 months from the purchased date.
• Maximum load: if you want to store large quantities of food and use the maximum
net capacity of the freezer, you can remove all the sliding drawers but you should
keep the upper shelf flaps. Thanks to this, it is possible to store bulky items directly
on the shelves.
• When buying frozen food ensure that these have been frozen at suitable temperatures
and that the packing is intact.
• Frozen food should be transported in appropriate containers to maintain the quality
of the food and should be returned to the freezing surfaces of the unit in the shortest
possible time.
• If a package of frozen food shows signs of humidity and abnormal swelling it is
probable that it has been previously stored at an unsuitable temperature and that the

EN - 10 -
Dairy Products Preparation Maximum Storing
time (months) Storing Conditions
Packet
(Homogenize) Milk In its own packet 2-3 Pure Milk – In its own
packet
Cheese-excluding
white cheese In slices 6-8
Original package may be
used for short storing
period. It should be
wrapped in foil for longer
periods.
Butter, margarine In its package 6
contents have deteriorated..
• The storage life of frozen foods depends on the room temperature, thermostat setting,
how often the door is opened, the type of food and the length of time required to
transport the product from the shop to your home. Always follow the instructions
printed on the packaging and never exceed the maximum storage life indicated.
If you would use maximum freezing capacity of your freezer:
• While freezing fresh foods, the maximum amount of fresh food (in kg) that can be
frozen in 24 hours is indicated on the appliance label. (your refrigerator has the
capacity to freeze 25 kg at 25°C ambient)
• For optimum appliance performance to reach maximum freezing capacity, activate
Super Freeze (SF) mode 24 hours before placing fresh food into the freezer.
• After placing fresh food into the freezer, 24 hours is generally sufficient for freezing.
”Super Freeze” mode will be deactivated automatically in 2-3 days to save energy.
If you would freeze a small amount (up to 3 kg) in your freezer:
• Place your food without touching already frozen food and activate “Fast Freezing”
mode. You can put your food next to other frozen food after it is completely frozen
(after minimum 24 hours).
• Do not re-freeze frozen food after it has thawed. This may cause health issues, such
as food poisoning.
• Allow hot food to completely cool down before placing it in the freezer.
• When buying frozen food ensure that these have been frozen at suitable temperatures
and that the packing is intact.

EN - 11 -
Maximum Storing
time (months)
Thawing time in
room temperature
(hours)
Thawing time in oven
(minutes)
Bread 4 - 6 2 - 3 4-5 (220-225 °C)
Biscuits 3 - 6 1 - 1,5 5-8 (190-200 °C)
Pastry 1 - 3 2 - 3 5-10 (200-225 °C)
Pie 1 - 1,5 3 - 4 5-8 (190-200 °C)
Phyllo dough 2 - 3 1 - 1,5 5-8 (190-200 °C)
Pizza 2 - 3 2 - 4 15-20 (200 °C)
Meat and fish Preparation Maximum Storing
time (month)
Steak Wrapping in a foil 6 - 8
Lamb meat Wrapping in a foil 6 - 8
Veal roast Wrapping in a foil 6 - 8
Veal cubes In small pieces 6 - 8
Lamb cubes In pieces 4 - 8
Minced meat In packages without using spices 1 - 3
Giblets (pieces) In pieces 1 - 3
Bologna sausage/salami Should be packaged even if it has
membrane
Chicken and turkey Wrapping in a foil 4 - 6
Goose and Duck Wrapping in a foil 4 - 6
Deer, Rabbit, Wild Boar In 2.5 kg portions and as fillets 6 - 8
Fresshwater fishes
(Salmon, Carp, Crane,
Siluroidea)
2
Lean fish; bass, turbot,
flounder 4
Fatty fishes (Tunny,
Mackarel, bluefish,
anchovy)
2 - 4
Shellfish Cleaned and in bags 4 - 6
Caviar In its package, aluminium or plastic
container 2 - 3
Snails In salty water, aluminum or plastic
container 3
After cleaning the bowels and scales of
the fish, wash and dry it; and if
neces sary, cut off the tail and head.
Note: Frozen meat should be cooked as fresh meat after being thawed. If the meat is not
cooked after being thawed, it should never be frozen again.

EN - 12 -
Vegetables and Fruits Preparation Maximum Storing
time (months)
String beans and beans Wash and cut into small pieces and
boil in water 10 - 13
Beans Hull and wash and boil in water 12
Cabbage Cleaned and boil in water 6 - 8
Carrot Clean and cut to slices and boil in
water 12
Pepper Cut the stem, cut into two pieces,
remove the core and boil in water 8 - 10
Spinach Washed and boil in water 6 - 9
Cauliflower
Take the leaves apart, cut the heart into
pieces, and leave it in water with a little
lemon juice for a while
10 - 12
Eggplant Cut to pieces of 2cm after washing 10 - 12
Corn Clean and pack with its stem or as
sweet corn 12
Apple and pear Peel and slice 8 - 10
Apricot and Peach Cut into two pieces and remove the
stone 4 - 6
Strawberry and
Blackberry Wash and hull 8 - 12
Cooked fruits Adding 10 % of sugar in the container 12
Plum, cherry, sourberry Wash and hull the stems 8 - 12

EN - 13 -
CHAPTER 4.
Evaporation
container
CLEANING AND MAINTENANCE
• Disconnect the unit from the power supply before cleaning.
• Do not clean the appliance by pouring water.
• Make sure that no water enters the lamp
housing and other electrical components.
• The freezer should be cleaned periodically using a solution of
bicarbonate of soda and lukewarm water.
• Clean the accessories separately with soap and
water Do not clean them in the dishwasher.
• Do not use abrasive products, detergents or soaps. After wash-
ing, rinse with clean water and dry carefully. W hen you have
finished cleaning, reconnect the plugto the mains supply with
dry hands.
• Clean the condenser with a broom at least twice a year.
This will help you to save on energy costs and increase
productivity.
THE POWER SUPPLY MUST BE DISCONNECTED.
Defrosting
Your freezer has fully automatic defrosting. The water
formed as a result of defrosting passes through the
water collection spout, flows into the vaporisation
container below the condenser and evaporates there.

EN - 14 -
CHAPTER 5. TRANSPORTATION AND CHANGING OF
INSTALLATION POSITION
Transportation and changing of Installation position
• The original packages and foamed polystyrene (PS) can be retained if required.
• During transportation, the appliance should be secured with a wide string or a strong
rope. The instructions written on the corrugated box must be followed while
transporting.
• Before transporting or changing the
installation position, all the moving objects
(ie, drawer, Ice trays, …) should be taken
out or fixed with bands in order to prevent
them from getting damaged.
Carry your freezer in the upright position.
Repositioning the door
• It is not possible to change the opening direction of your freezer door, if the door
handles on your freezer are installed from the front surface of the door.
• It is possible to change the opening direction of the door on models without any
handles.
• If the door opening direction of your freezer may be changed, you should contact the
nearest Authorised Service to have the opening direction changed.
Replacing LED lighting
If your refrigerator has LED lighting, contact the help desk as this should be changed by
authorized personel only.

EN - 15 -
CHAPTER 6. BEFORE CALLING SERVICE
Alarm
indicator led
is turning on
ERROR
TYPE WHY WHAT TO DO
"Failure
Warning"
There is/are some
part(s) Out of order
or there is a failure in
cooling process
Check the door is open
or not. If the door is not
open, call service for
assistance as soon as
possible.
If your freezer is not working properly, it may be a minor problem, therefore check the
following, before calling an electrician to save time and money.
What to do if your appliance does not operate;
Check that;
• There is no power,
• The general switch in your home is disconnected ,
• The socket is not sufficient. To check this, plug in another appliance that you know
which is working into the same socket.
What to do if your appliance performs poorly;
Check that;
•You have not overloaded the appliance ,
• The freezer temperature set to -16.
• The doors are closed perfectly ,
• There is no dust on the condenser ,
• There is enough place at the rear and side walls.
If your freezer is operating too loudly;
Normal Noises
Cracking (Ice cracking) Noise:
• During automatic defrosting.
• When the appliance is cooled or warmed (due to expansion of appliance material).
Short cracking: Heard when the thermostat switches the compressor on/off.
Compressor noise: Normal motor noise. This noise means that the compres-
sor operates normally Compressor may cause more noise for a short time when
it is activated.
Bubbling noise and splash: This noise is caused by the flow of the refrigerant
in the tubes of the system.
Water flow noise: Normal flow noise of water flowing to the evaporation contain-
er during defrosting. This noise can be heard during defrosting.

EN - 16 -
Air Blow Noise: Normal fan noise. This noise can be heard in No-Frost freezer
during normal operation of the system due to the circulation of air.
If the edges of freezer cabinet that the door joint contact are warm;
Especially in summer (hot weather), the surfaces that the joint contact may get warmer
during the operation of the compressor, this is normal.
If humidity builds up inside the freezer;
• Are all food packed properly? Are the containers dried before placing them in the
freezer?
• Is the freezers door opened frequently? Humidity of the room gets in the freezer when
the doors are opened. Humidity build up will be faster when you open the doors
more frequently, especially if the humidity of the room is high.
If the door is not opened and closed properly;
• Do the food packages prevent closing of the door?
• Are the drawers placed properly?
• Are door joints broken or torn?
• Is your freezer on a level surface?
Recommendations
•To stop the appliance completely, unplug from main socket (for cleaning and when
the door is left open)
IMPORTANT NOTES:
• In the event of a power cut, to prevent any damage to the compressor we recommend
that you unplug the freezer. Your appliance will start after 5 minutes, there is nothing
to worry about.
• If the appliance is not used for long time (for example during holidays) unplug it.
Clean your freezer according to Chapter 4 and leave the door open to prevent humidity
and smell.
• If the problem persists after you have followed all the instructions above, please
consult to the nearest Authorised service.
• The lifetime of your appliance stated and declared by the Department of the Industry
is 10 years (the period for retaining parts required for the proper functioning of the
appliance).

EN - 17 -
Advice for Saving Energy
• Do not install the appliance close to heat producing appliances. Such as cooker,
oven, dishwaher or radiator, and locate the appliance in the coolest part of the room.
• Locate the appliance ina cool well ventilated room and make sure that the air openings
of the appliances are not obstructed.
• Always leave warm food to cool down to room temperature before placing in the
freezer.
• Try to avoid keeping the door open for long periods or opening the door too frequently
as warm air will enter the cabinet and cause the compresor to switch on unnecessarily
often.
• Ensure there are no obstructions preventing the door from closing properly.
• Cover foods before placing them in the freezer. This cuts down on moisture build-up
inside the unit.
• Refer to the “temperature settings” section for the suggested temperature control
settings.
• Do not block cold air vents. Doing so causes the freezer to run longer and use more
energy.
• Keep freezer full.
• Level the freezer so that the door closes tightly.
• Occasionally clean the rear of the appliance with a vacuum cleaner or paint brush to
prevent an increased power consumption.
• Keep door gaskets clean and pliable. Replace gaskets if worn.

EN - 18 -
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
CHAPTER 7.
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.
1. ICE TRAY / ICE MATIC *
2. CONTROL PANEL
3. FREEZER FLAPS
4. FREEZER BIG DRAW ER
5. FREEZER DRAWERS
6. FREEZER BOTTOM DRAWER
7. LEVELLING FEET
In some models there is a shelf
with icematic in the top basket.
* In some models
1
4
3
5
6
7
2

ES - 19 -
Índice
ANTES DE UTILIZAR EL APARATO .................................................20
Advertencias generales..............................................................................20
Advertencias de seguridad.........................................................................23
Instalación y puesta en marcha del congelador.........................................24
Antes de Utilizar el Congelador..................................................................25
Información sobre la tecnología no-frost ....................................................25
INFORMACIÓN DE USO....................................................................26
Pantalla y panel de control .........................................................................26
Botón de ajuste de temperatura de la partición del congelador ..........................26
Luz de alarma......................................................................................................26
Modo super congelador.......................................................................................26
Ajustes de temperatura del congelador...............................................................27
Advertencias acerca de los ajustes de temperatura ..................................27
Accesorios..................................................................................................28
Cómo hacer cubitos de hielo...............................................................................28
Recipiente para hielo...........................................................................................28
COLOCAR LOS ALIMENTOS............................................................28
LIMPIEZA Y MANTENIMIENTO .........................................................33
Descongelación..........................................................................................33
TRASLADO Y RECOLOCACIÓN.......................................................34
Cómo cambiar la posición de la puerta ......................................................34
RESOLUCIÓN DE PROBLEMAS.......................................................34
Sugerencias para ahorrar energía .............................................................37
PARTES Y COMPARTIMENTOS DEL APARATO .............................38
