SUNGOLD POWER ARC-200 110/220V User manual

1
USER’S MANUAL
MODEL: ARC-/200/250
Sun Gold Power Co.,Ltd
www.sungoldpower.com

2
1. Safety warning ………………………………………………………………………………. 1
2．Advantage …………………………………………………………………………………….. 2
3. Main technique data …………………………………………………………………………… 2
4. Electric block diagram ..………………………………………………………………………… 3
5. Operation control and description …………………………………………………………….. 3
6. Installation and operation ………………………………………………………………………. 4
7. Caution …………………………………………………………………………………………… 5
8. Maintenance ……………………………………………………………………………………… 6
9. Trouble shooting …………………………………………………………………………………. 7
Sun Gold Power Co.,Ltd
www.sungoldpower.com

3
1．Safety warning !
Electric shock may lead to serious injury or even death !
●Install earth device according to the application criteria.
●With bare skin, wet gloves or clothes, is prohibited touching the live parts.
●Make sure that you are insulated from the ground and workpiece.
●Make sure that your working position is safe.
Smoke and gas may harm health !
●Keep the head away from smoke and gas to avoid inhalation of exhaust gas from welding.
●Keep the working environment in good ventilation with exhaust or ventilation equipment when
welding.
Arc radiation may hurt eyes or burn skin !
●Wear appropriate welding masks and protective clothing to protect your eyes and body.
●Use appropriate masks or screens to protect spectators from harm.
Improper operation may cause fire or explosion !
●Welding sparks may result in a fire, so make sure no inflammable materials nearby and pay attention
to fire hazard.
●Have a fire extinguisher nearby, and have a trained person to use it.
●Airtight container welding is forbidden.
●Welding machine is forbidden for the use of thawing pipeline.
Welding is dangerous, and may cause damage to you and others, so take good
protection while welding. For details, please refer to the operator safety guidelines in conformity with
the accident prevention requirements of the manufacturer.
Sun Gold Power Co.,Ltd
www.sungoldpower.com

4
Hot workpiece may cause serious scald !
●Do no touch hot workpiece with bare hands
●Cooling is needed during continuous use of the welding torch.
Magnetic field influence heart pacemaker !
●The user of heart pacemaker should keep away from the welding spot before going to consult the
doctor.
Moving parts may lead to physical injury !
●Keep yourself away from moving parts such as fan.
●The kinds of protective device, such as door, panel, mask, baffle, should be installed tightly.
Fault -- when encountering difficulties, seek professional help !
●If you encounter any difficulties in the installation and operation, please check the relevant content of
this manual.
●If you still can not fully understand after reading, or still can not solve the problem according to the
manual or guidelines, you should immediately contact your suppliers or OUR’s service center to seek
professional help.
2．Advantage:
-- advanced IGBT inverter technology
-- advanced control module improves the performance of the welding machine to satisfy different
requirements of welding
-- small size, light weight, energy saving and no noise
-- automatic compensation for voltage fluctuation, can work normally against input voltage fluctuation
(V±15%).
-- small splashing, great penetration, easy and simple to operate and aesthetic appearance of weld
seam
-- over-voltage protection, under voltage protection, over current protection, over load protection
-- suitable for welding with different kinds of acid or basic electrode
-- Auto Hot-start and Anti-stick technology
Sun Gold Power Co.,Ltd
www.sungoldpower.com

5
3．Main technique data:
ARC-200
ARC-250
Rated input voltage（V）
AC110V±5%，
Two phase AC220V±5%,50/60Hz
110V
220V
110V
220V
Rated input power（KVA）
3.7
6.4
3.7
6.4
Rated input current（A）
34
29
34
29
Output current（A）
20-200
20-250
No-load voltage（V）
62V
62V
Rated duty cycle（%）
60%
60%
Efficiency（%）
70
70
Power factor
0.93
0.93
Protection grade
IP21
IP21
Insulation grade
F
F
Dinebsion（mm）
375*155*300
375*155*310
Net weight（kg）
6
7
4. Electric block diagram:
Sun Gold Power Co.,Ltd
www.sungoldpower.com

6
5. Operation control and description:
Front panel (picture 1):
(1) output anode: output anode is connected with the electrode holder
(2) output cathode: output cathode is connected with the workpiece
(3) current adjustment: user could adjust the output current by it
(4) over heat LED: over heat LED lights up indicating the inside temperature is too high, the machine is
in the state of over heat protection
(5) fault indicator LED: Inside the machine there is abnormal or likely to be The original device damage
Back panel (picture 2):
(6) power cable
(7) power switch
(8) cooling fan
(9) grounding
Sun Gold Power Co.,Ltd
www.sungoldpower.com

7
6. Installation and operation:
Attention: Please install the machine strictly according to the following steps !
The installation must be operated when the power is switched off !
The protection grade of the machine is IP21, so avoid to use the machine in the rain !
6.1 Installation:
(1) A primary power supply cable is available for the welding machine. Connect this power supply cable
to the rated input power.
(2) The primary cable should be tightly connected to the correct socket to avoid oxidization.
(3) Check the input voltage by multi-meter to assure the voltage is in the normal range.
(4) Insert the cable joint which is connected with the electrode holder into the output anode, fasten it
clockwise.
(5) Insert the cable joint which is connected with work clamp into the output cathode, fasten it clockwise.
(6) Make the grounding cable of the machine well earthed.
The connection as mentioned above in 6.1(4) and 6.1(5) is DCEP connection, operator could also
choose DCEN connection according to the material of workpiece and welding rod application
requirement. Generally, DCEP connection is recommended for basic electrode, while no special
requirement for acid electrode.
6.2 Operation:
(1) Turn the power switch (back panel) on, power LED on the front panel lights up and the fan begins
working.
(2) Pay attention to the polarity when connecting. Phenomena such as unstable arc, spatter and
electrode sticking could happen if improper connecting method is selected. Exchange the polarity if
necessary.
(3) If the workpiece is far away from the welding machine, the secondary cable (electrode holder and
grounding cable) is long, should choose cable with larger cross-section to reduce the voltage drop.
(4) Preset the welding current according to the type and size of the electrode, clip the electrode and then
welding can be carried out by short circuit arc starting. For welding parameters, please refer to the
6.3.
6.3 (the parameters in the table just for reference)
Diameter of electrode rod (mm)
Recommend current (A)
Recommend Voltage (V)
1.0
20-60
20.8-22.4
1.6
44-84
21.76-23.36
2.0
60-100
22.4-24.0
2.5
80-120
23.2-24.8
3.2
108-148
23.32-24.92
4.0
140-180
24.6-27.2
Note: The parameters above are for carbon steel welding, please refer to the related datas for other
kinds of material.
7. Caution:
Sun Gold Power Co.,Ltd
www.sungoldpower.com

8
7.1 Working environment
(1) Welding should be carried out in dry environment with its humidity of 90% or less.
(2) The temperature of working environment should be between -10℃ and +40℃.
(3) Avoid working in the open air unless sheltered from sunlight and rain. Keep it dry anytime and do not
place it on wet ground or in puddles.
(4) Avoid welding in dusty area or environment with corrosive chemical gas.
(5) Gas shielded arc welding should be operated in environment without strong airflow.
7.2 Safety tips
The welding machine has the over-voltage, over-current and over-heat protection. When the input
voltage, output current and the temperature inside the machine is beyond the set standards, the
machine will stop working automatically. However, overuse (for example too high voltage) can still lead
to the breakdown of machine, so please pay attention to the following instructions:
(1) Keep good ventilation!
When the machine is working, the natural air circulation can not cool down the high temperature
caused by big current flow, so a special fan is added to achieve the cooling.
Users need to make sure the back ventilator is not blocked or covered, and the machine should be
placed 0.3m away from the surroundings. It is important for users to keep good ventilation all the
time, it will be very helpful in improving the performance and service life of the machine.
(2) Over-load is forbidden!
The welding machine should be used as its duty cycle requires (refer to the corresponding duty
cycle), the welding current could not exceed the rated maximum output. The current overload will
shorten the service life of machine greatly, even destroyed.
(3) Over-voltage is forbidden!
The power voltage of the machine see the “Main parameter” table, in general situation, the
automatical voltage compensation circuit could keep the welding current in the normal range. If the
power voltage beyond the allowable values, it harms the machine, so the users should be aware of
this and take appropriate precautions.
(4) There is a grounding screw on the lower right corner of back panel. Before starting using the machine,
choose a wire (bigger than 2.5mm), and grouding the case to release static electricity.
(5) When the machine is working longer than the standard duty cycle requires, the temperature inside
the machine will be very high, it may start over-heat protection and stop working suddenly, and the
red light on the panel will light up. Under this situation, users do not have to remove the plug, so that
the fan on the back continues working and cool the machine down. When the red light is off, the
temperature goes down into the standard range, the machine could work again.
8. Maintenance:
Safety warning!
The following operation require the operator must have comprehensive electrical and safety
knowledge, as well as the qualifications. Make sure the input cable is removed from the power
supply before opening the casing.
Sun Gold Power Co.,Ltd
www.sungoldpower.com

9
(1) Check the circuit connection inside the machine regularly, if the wire joint or components is rusty or
loose, sand the rust and tighten the joint.
(2) Keep hand, hair, and tools away from the live parts, for example fan, to avoid injury.
(3) Clear the dust regularly with clean and dry compressed air. If there is heavy smoke and pollution in
the working environment, the welding machine should be cleaned once a month. The pressure of
compressed air should be controlled in a reasonable range or the small components in the machine
will be damaged.
(4) Avoid water or steam entering the machine, if it occurs, dry it in time and check the insulation with
mega meter (including that between the connection and that between the case and connection).
Start working again when nothing is abnormal.
(5) Check the cable of welding machine regularly, when insulation sleeve of cable is broken, repair or
change for new one.
(6) If the machine is no use for a long time, packing it into original box and leave it in dry place.
9. Trouble shooting:
Common problem and solution:
Common problem and solution:
Problem
Solution
Power LED does not light up, the fan
doesn’t work, no welding output
1. make sure the power is switched on
2. make sure the power source has electricity
The fan works, output current is not
stable or not controlled by current
adjustment
1. the potentiometer is breakdown, change for new one
2. Examine the connections inside the mahcine, fasten the
loose connection
Power LED lights up, the fan works, no
welding output
1. Examine the connector assemblies in the machine are
well connected.
2. Examine the joint of output is well connected.
3. Over heat LED is light up:
(1) the temperature inside the machine is too high and the
machine is in over-heat protection. Users do not have to
remove the plug, so that the fan on the back continues
working and cool the machine down. When the red light
is off, the temperature goes down into the standard
range, the machine could work again.
(2) Examine the thermo switch, if it’s damage, change for
the new one.
Electrode holder is hot
The rated current of electrode holder is smaller than then
actual output current, change for the right capacity one.
The splashing is big for MMA welding
The output connection method is not proper, change the
Safety warning!
The following operation require the operator must have comprehensive electrical and safety
knowledge, as well as the qualifications. Make sure the input cable is removed from the power supply
before opening the casing.
Sun Gold Power Co.,Ltd
www.sungoldpower.com

10
polarity of output cable.
Note: we are improving the products all the time, some parts of this manual may be changed in future
except the function and operation, please be understanding.
Sun Gold Power Co.,Ltd
www.sungoldpower.com
