USER’S MANUAL
Industrial Wireless Access Point
WAP-5XXX Series
Ver. 1.0, Dec. 2007

1
Table of Content
TABLE OF CONTENT ............................................................................................................................................ 1
GETTING TO KNOW YOUR ACCESS POINT............................................................................................................ 3
1.1 About the Wireless Access Point ..................................................................................................................3
1.2 Software Features.........................................................................................................................................3
1.3 Hardware Features .......................................................................................................................................3
HARDWARE INSTALLATION.................................................................................................................................. 4
2.1 Installation WAP on DIN-Rail ........................................................................................................................ 4
2.2 Wall Mounting Installation ............................................................................................................................. 5
HARDWARE OVERVIEW....................................................................................................................................... 7
3.1 Front Panel ...................................................................................................................................................7
3.2 Front Panel LEDs..........................................................................................................................................8
3.3 Bottom Panel ................................................................................................................................................9
3.4 Rear Panel....................................................................................................................................................9
CABLES AND ANTENNA..................................................................................................................................... 10
4.1 Ethernet Cables.......................................................................................................................................... 10
4.1.1 100BASE-TX/10BASE-T Pin Assignments............................................................................................................10
4.2 Wireless Antenna.........................................................................................................................................11
MANAGEMENT INTERFACE ................................................................................................................................12
5.1 Explore WAP-5002/WAP-5002P................................................................................................................. 12
5.1.1 WAP-Tools software................................................................................................................................................12
5.1.2 UPnP Equipment......................................................................................................................................................13
5.2 Configuration by Web Browser ................................................................................................................... 14
5.2.1 About Web-based Management...............................................................................................................................14
5.2.1.1 Main Interface...............................................................................................................................................15
5.2.2 Basic Setting............................................................................................................................................................16
5.2.2.1 Setting Operation Mode ................................................................................................................................16
5.2.2.2 Setting WDS..................................................................................................................................................16
5.2.2.3 Setting Wireless.............................................................................................................................................20
5.2.2.4 LAN Setting..................................................................................................................................................23
5.2.2.5 Setting DHCP Server.....................................................................................................................................25
5.2.3 Advanced Setting.....................................................................................................................................................26
5.2.3.1 Wireless.........................................................................................................................................................26
5.2.3.2 MAC Filter....................................................................................................................................................27
5.2.3.3 System Event.................................................................................................................................................28
5.2.4 System Tools............................................................................................................................................................31
5.2.4.1 Administrator ................................................................................................................................................31

2
5.2.4.2 Date & Time..................................................................................................................................................32
5.2.4.3 Configuration................................................................................................................................................33
5.2.4.4 Firmware Upgrade ........................................................................................................................................34
5.2.4.5 Miscellaneous................................................................................................................................................34
5.2.5 System Status...........................................................................................................................................................35
5.2.5.1 System Info...................................................................................................................................................35
5.2.5.2 System Log ...................................................................................................................................................36
5.2.5.3 Traffic Statistics ............................................................................................................................................36
5.2.5.4 Wireless Clients.............................................................................................................................................36
5.2.6 Online Help..............................................................................................................................................................37
TECHNICAL SPECIFICATIONS............................................................................................................................. 38

3
1
Getting to Know Your Access Point
1.1 About the Wireless Access Point
WAP-5002/WAP-5002P is a reliable IEEE802.11b/g WLAN with 2 ports LAN Access Point. It can be configured to
operate in AP/Bridge/Repeater mode. You can configure WAP-5002/WAP-5002P by Window Utility or WEB
interfaces via LAN port or WLAN interface. WAP-5002/WAP-5002P provides dual Ethernet ports in switch mode, so
you can use Daisy Chain to reduce the usage of Ethernet switch ports. WAP-5002P also provides PD feature on
ETH2 which is fully compliant with IEEE802.3af PoE specifications. Therefore, these wireless access points are best
communication solution for industrial grade wireless application.
1.2 Software Features
High Speed Air Connectivity: WLAN interface support up to 54Mbps link speed connection
Highly Secured Tranimission: WEP/WPA/WPA2/802.1X/Radius/TKIP supported
Support AP/Bridge/Repeater Mode
Switch Mode Supported: Daisy Chain support to reduce usage of switch ports
Secured Management by HTTPS and SSH
Event Warning by Syslog, Email, SNMP Trap, Relay and Beeper
1.3 Hardware Features
Fully Compliant with IEEE802.3af (Power Device at ETH2, WAP-5002P only)
Redundant Power Inputs: 12~48 VDC on terminal block
Operating Temperature: -10 to 55oC
Storage Temperature: -20 to 85oC
Operating Humidity: 5% to 95%, non-condensing
Casing: IP-30
10/100Base-T(X) Ethernet port
Dimensions(W x D x H) : 52 mm(W)x 106 mm( D )x 144 mm(H)

4
2
Hardware Installation
2.1 Installation WAP on DIN-Rail
Each WAP has a Din-Rail kit on rear panel. The Din-Rail kit helps WAP to fix on the Din-Rail. It is easy to install
the WAP on the Din-Rail:
Step 1: Slant the WAP and mount the metal spring to Din-Rail.
Metal Spring

5
Step 2: Push the WAP toward the Din-Rail until you heard a “click” sound.
2.2 Wall Mounting Installation
Each WAP has another installation method to fix the switch. A wall mount panel can be found in the package.
The following steps show how to mount the WAP on the wall:
Step 1: Remove Din-Rail kit.

6
Step 2: Use 6 screws that can be found in the package to combine the wall mount panel. Just like the picture shows
below:
The screws specification shows in the following two pictures. In order to prevent switches from any damage, the
screws should not larger than the size that used in WAP-5002/WAP-5002P.
Pozidrive
Step 3: Mount the combined WAP on the wall.

7
3
Hardware Overview
3.1 Front Panel
The following table describes the labels that stick on the WAP-5002/WAP-5002P.
Port Description
10/100 RJ-45 fast
Ethernet ports
2 10/100Base-T(X) RJ-45 fast Ethernet ports support auto-negotiation.
Default Setting :
Speed: auto
Duplex: auto
Flow control : disable
P.O.E. PD Port ETH2 of WAP-5002P compliant with IEEE802.3af PoE. specifications
ANT. Reversed SMAconnector for external antenna.
WAP-5002P WAP-5002
Industrial Wireless Access Point Industrial Wireless Access Point
WAP-5002WAP-5002P
PWR1
PWR2
Fault
ETH1
ETH2
10/100M
WLAN
ANT.
PWR1
PWR2
Fault
ETH1
ETH2
PoE
10/100M
WLAN
ANT.
PoE

8
1. 2.4GHz antenna with typical 2.0dbi antenna.
2. LED for PoE power and system status. When the PoE power links, the green led will be light on.
3. LED for PWR1 and system status. When the PWR1 links, the green led will be light on.
4. LED for PWR2 and system status. When the PWR2 links, the green led will be light on.
5. LED for Fault Relay. When the fault occurs, the amber LED will be light on.
6. 10/100Base-T(X) Ethernet ports.
7. 10/100Base-T(X) Ethernet ports. (WAP-5002P contains PD function of PoE).
8. LED for WLAN link status.
9. LED for WLAN signal strength.
3.2 Front Panel LEDs
LED Color Status Description
Green On PoE power connected.
PoE Green/Red Red blinking
Indicates an IP conflict, or
DHCP or BOOTP server did
not respond properly
On DC power 1 activated.
PWR1 Green/Red Red blinking
Indicates an IP conflict, or
DHCP or BOOTP server did
not respond properly
On DC power 2 activated.
PWR2 Green/Red Red blinking
Indicates an IP conflict, or
DHCP or BOOTP server did
not respond properly
Fault Amber On Fault relay. Power failure or
Port down/fail.
On WLAN activated.
WLAN Green Blinking WLAN Data transmitted.
WLAN
Strength Green On
WLAN signal strength.
1<25%, 2<50%, 3<75%,
4<100%
10/100Base-T(X) Fast Ethernet ports
On Port link up at 10Mbps.
10Mbps
LNK/ACT Amber Blinking Data transmitted.
100Mbps Green On Port link up at 100Mbps.

9
LNK/ACT Blinking Data transmitted.
3.3 Bottom Panel
The bottom panel components of WAP-5002/WAP-5002P are showed as below:
1. Terminal block includes: PWR1, PWR2 (12 ~ 48V DC) and Relay output (1A@24VDC).
2. Reset bottom. Push the bottom 3 seconds for reset; 5 seconds for factory default.
PWR1, PWR2 (12-48V DC) and
ResetButton Relayoutput(1A@24VDC).
3.4 Rear Panel
The rear panel components of WAP-5002/WAP-5002P are showed as below:
1. Screw holes for wall mount kit.
2. Din-Rail kit

10
4
Cables and Antenna
4.1 Ethernet Cables
The WAP-5002/WAP-5002P switches have standard Ethernet ports. According to the link type, the switches use CAT
3, 4, 5,5e UTP cables to connect to any other network device (PCs, servers, switches, routers, or hubs). Please refer
to the following table for cable specifications.
Cable Types and Specifications
Cable Type Max. Length Connector
10BASE-T Cat. 3, 4, 5 100-ohm UTP 100 m (328 ft) RJ-45
100BASE-TX Cat. 5 100-ohm UTP UTP 100 m (328 ft) RJ-45
1000BASE-TX Cat. 5/Cat. 5e 100-ohm
UTP UTP 100 m (328ft) RJ-45
4.1.1 100BASE-TX/10BASE-T Pin Assignments
With 100BASE-TX/10BASE-T cable, pins 1 and 2 are used for transmitting data, and pins 3 and 6 are used for
receiving data.
RJ-45 Pin Assignments
Pin Number Assignment
1 TD+
2 TD-
3 RD+
4 Not used
5 Not used
6 RD-
7 Not used
8 Not used

11
The WAP-5002/WAP-5002P Ethernet ports support auto MDI/MDI-X operation. You can use a straight-through cable
to connect PC and switch. The following table below shows the 10BASE-T/ 100BASE-TX MDI and MDI-X port pin
outs.
MDI/MDI-X pins assignment
Pin Number MDI port MDI-X port
1 TD+(transmit) RD+(receive)
2 TD-(transmit) RD-(receive)
3 RD+(receive) TD+(transmit)
4 Not used Not used
5 Not used Not used
6 RD-(receive) TD-(transmit)
7 Not used Not used
8 Not used Not used
Note: “+” and “-” signs represent the polarity of the wires that make up each wire pair.
4.2 Wireless Antenna
A 2.4GHz antenna is used for WAP-5002/WAP-5002P and connected with a reversed SMA connector.

12
5
Management Interface
5.1 Explore WAP-5002/WAP-5002P
5.1.1 WAP-Tools software
Each model contains friendly software, WAP-Tools, to explore WAP-5002/WAP-5002P on local area network.
Step 1: Open the WAP tool and click “Refresh list”, the WAP devices will show on the list.
Step 2: Choose your access point, and it will show the WAP attribute. Simultaneity, you can manual set the WAP’s
IP address.
Step 3: Click “Access via web” button, it will go to web page.

13
5.1.2 UPnP Equipment
Step 1: To check whether the UPnP UI of the computer is connected to the WAP-5002/WAP-5002P, go to Control
Panel>Add or Remove Programs>Windows Components Wizard>Networking Servers>UPnP User
Interface and pitch on the UPnP User Interface.
Step 2: At the right-below corner of the computer, you will find a sign of the UPnP equipment.

14
Step 3: Click the sign of the UPnP equipment, then you will find the UPnP equipment in the network neighborhood.
Step 4: Right click the UPnP equipment to choose “Properties”, it will show as the following pictures:
Step 5: Right click the UPnP equipment or double click the UPnP equipment to transfer; it will go to the web page.
5.2 Configuration by Web Browser
This section introduces the configuration by Web browser.
5.2.1 About Web-based Management
Inside the CPU board of the access point, it contains an embedded HTML web site residing in flash memory. With its
advanced management features, it allows you to manage the WAP from anywhere on the network through a
standard browser such as Microsoft Internet Explorer.
The Web-Based Management supports Internet Explorer 5.0. It is based on Java Applets with an aim to reduce
network bandwidth consumption, enhance access speed, and present an easy viewing screen.
Note: By default, IE5.0 or later version does not allow Java Applets to open sockets. You need to explicitly modify the
browser setting in order to enable JavaApplets to use network ports.

15
Enter the IP address of Wireless WAP (Default IP address is 192.168.1.1) in the Internet Explorer and press Enter,
you will see as follows, enter your user name (admin) and your password (admin), then click OK to continue.
Login screen
For security reasons, we strongly suggest you change the password. Click on System ToolsÆAdministrator and
modify the password.
5.2.1.1 Main Interface
The Home screen will appear. Please click “Run Wizard” to go to the HomeÆSetup Wizard page to quick install the
WAP.
Main interface

16
5.2.2 Basic Setting
5.2.2.1 Setting Operation Mode
Operation mode interface
The following table describes the labels in this screen.
Label Description
Bridge This mode provides Static LAN-to-LAN Bridging functionality. The
static LAN-to-LAN bridging function is supported through Wireless
Distribution System (WDS).
AP This mode provides Access Point services for other wireless clients.
In either mode, the WAP-5002/WAP-5002P forwards packet between its Ethernet interface and wireless interface for
wired hosts on the Ethernet side, and wireless hosts on the wireless side.
5.2.2.2 Setting WDS
This type of wireless link is established between two IEEE 802.11 access points. Wireless packets transmitted along
the WDS link comply with the IEEE 802.11 WDS (Wireless Distribution System) format at the link layer.

17
The following table describes the labels in this screen.
Label Description
WDS Mode A Wireless Distribution System is a system that enables the wireless
interconnection of access points in an IEEE 802.11 network. It allows a
wireless network to be expanded using multiple access points without
the need for a wired backbone to link them, as is traditionally required.
The notable advantage of WDS over other solutions is that it preserves
the MAC addresses of client packets across links between access
points.
This provides different options (restricted mode, repeater mode, bridge
mode). Select the appropriate mode as per your application needs.
Encryption Type Select the type of security for your wireless network
WDS Key Fill in the encryption key when Encryption Type is TKIP orAES.
Peer MAC
Address
Set the MAC address(es) of other access point(s). Click on the box to
“Enable” it.
First of all, if WAPs link with WDS mode, it should obey the following rules:
1. LAN IPAddress should set different IP in the same network.

18
2. All WAP’s DHCP Server should disabled.
3. WDS should set Enable.
4. Each WAP should have the same setting except ‘Peer MacAddress’set to the other’s Mac address
5. WEP Key and Channel should be the same, and each WAP’s SSID should be broadcast to see in the other’s
computer.
6. WAP’s distance should limit to a certain area.
WDS –Restricted Mode
The peer WDS WAPs are according to the MAC address listed in "Peer MacAddress" fields.
WDS –Bridge Mode
Same as Restrict mode in functionality and also one WDS link side can not set Peer Mac Address 1-4.

19
The working principle of Bridge Mode as follows:
In the figure, the WAP behaves as a standard bridge that forwards traffic between WDS links (links that connect to
other WAP/wireless bridges) and an Ethernet port. As a standard bridge, the WAP learns MAC addresses of up to 64
wireless or 128 total wired and wireless network devices, which are connected to their respective Ethernet ports to
limit the amount of data to be forwarded. Only data destined for stations which are known to reside on the peer
Ethernet link, multicast data or data with unknown destinations need to be forwarded to the peer WAP via the WDS
link.
WDS –Repeater Mode
Same as Restrict mode in functionality and also one WDS link side can be set Peer Mac Address 1-4.
