sunjoe SPX4001 User manual

A Division of Snow Joe®, LLC
R
OPERATOR’S MANUAL
© 2021 by Snow Joe®, LLC
All rights reserved. Original instructions. 1
SAVE THESE INSTRUCTIONS
Model SPX4001 Form No. SJ-SPX4001-880E-MR6
14.5A ELECTRIC PRESSURE WASHER
2030 PSI MAX PRESSURE AT INITIAL DISCHARGE PER CSA INTERNAL PRESSURE TESTING
1.76 GPM MAX FLOW WITH NOZZLE OPEN AT MINIMUM PRESSURE
EN
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
mWARNING! This indicates a hazardous situation, which,
if not avoided, could result in death or serious injury.
mCAUTION! This indicates a hazardous situation, which,
if not avoided, could result in minor or moderate injury.
mDANGER! This indicates a hazardous situation, which,
if not followed, will result in death or serious injury.
General Safety
mWARNING! This appliance is not intended for use
by children or by unassisted, unsupervised persons whose
physical, sensory or mental capabilities prevent them from
using it safely. Children should be supervised to ensure that
they do not play with the appliance.
Before starting up your machine, please check it carefully for
any defects. If you nd any, do not start up your machine.
Contact your authorized Snow Joe®+ Sun Joe®dealer or
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
mWARNING! When using the pressure washer, basic
safety precautions should always be followed to reduce the
risk of re, electric shock, and personal injury. These include:
• Know your product – Know how to stop the machine and
bleed pressure quickly. Thoroughly familiarize yourself with
the controls.
• Keep bystanders away – All visitors and pets should be
kept a safe distance away from the work area.
• Use the right product – Do not use this machine for any
job except that for which it is intended.
• Dress properly – Do not wear loose clothing or jewelry.
They can get caught in moving parts. Protective rubber
gloves and non-slip footwear are recommended when
working outdoors.
• mCAUTION! – Exercise caution to avoid slipping or falling.
Wear protective footwear that will protect your feet and
improve your footing on slippery surfaces.
• Stay alert – Watch what you are doing. Use common
sense. Do not operate the pressure washer when you are
tired, or under the inuence of alcohol or drugs.
• Do not overreach – Keep proper footing and balance at
all times.
• Avoid unintentional starting – Do not carry a plugged-
in machine with your nger on the trigger. Make sure the
switch is o before plugging in the machine.
• Do not abuse the cord – Never carry the machine by the
cord or yank the cord to disconnect it from the receptacle.
Keep the cord away from heat, oil, and sharp edges.
• Use safety glasses – Also use safety footwear, snug-tting
clothing, protective gloves, hearing and head protection.
• Check the water temperature – This pressure washer is
not meant to pump hot water. NEVER connect it to a hot
water supply as it will signicantly reduce the life of the
pump.
• Store indoors – NEVER store the pressure washer
outdoors or where it could freeze. The pump could be
seriously damaged.
• Ground Fault Circuit Interrupter (GFCI) – This product
is provided with a ground fault circuit interrupter built into
the power cord plug. If replacement of the plug or cord is
needed, use only identical replacement parts.
• Inspect electrical cables – The insulation of the power
cord should be perfectly intact. If the power cord is
damaged or shows any signs of wear or tear, do not use the
pressure washer. Contact your authorized Snow Joe®+
Sun Joe®dealer or call the Snow Joe®+ Sun Joe®customer
service center at 1-866-SNOWJOE (1-866-766-9563).
mWARNING! Do not use this appliance without reading
this instruction manual.
mWARNING! This appliance has been designed for
use with cleaning agents that are recommended by the
manufacturer. The use of other cleaning agents or chemicals
may adversely aect the safety of the appliance.
mWARNING! Do not use the appliance within range of
persons unless they are wearing protective clothing.
mWARNING! High-pressure jets can be dangerous if
subject to misuse. The jet must not be directed at persons,
pets, live electrical equipment, or the appliance itself.
• Do not direct the jet at yourself or others in order to clean
clothes or footwear.

2
• Risk of explosion – Do not spray ammable liquids.
• Disconnect the tool – Disconnect from the electrical power
supply before performing any maintenance task.
• Keep children away – This high-pressure electric
power washer must not be used by children or untrained
personnel.
• To ensure appliance safety, use only original replacement
parts from the manufacturer or those approved by the
manufacturer.
mWARNING! Water that has owed through backow
preventers is considered to be non-potable.
mWARNING! During cleaning, maintenance or when
replacing parts, the machine must be disconnected from its
power source by removing the plug from the socket outlet.
mWARNING! High-pressure hoses, ttings, and
couplings are important for the safe operation of the appliance.
Use only hoses, ttings, and couplings recommended by the
manufacturer.
• Check for damaged parts – Do not use the appliance if
the supply cord or other important parts of the appliance
are damaged (e.g. safety devices, high-pressure hoses,
trigger gun).
mWARNING! If an extension cord is used, the plug and
socket must be of watertight construction.
mWARNING! Inadequate extension cords can be
dangerous.
• This high-pressure electric power washer must not be used
at temperatures below 32ºF (0°C).
mWARNING! Power cords on drums should always be
completely unwound to prevent the cord from overheating.
• Power cord connections should be kept dry and o the
ground.
• If the power cord is damaged, do not use the appliance.
Contact your authorized Snow Joe®+ Sun Joe®dealer or
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
• Keep the machine on a stable, at surface during operation,
handling, transportation, and storage. Sudden overturn of
the machine can cause bodily injury.
• In the event of an accident or breakdown, switch o the
machine immediately. (If contact with detergent occurs,
rinse with an abundance of clean water.)
Electrical Safety
ATTENTION: If there are problems with the electrical
MAINS, short voltage drops may appear when starting the
equipment. This can, in turn, inuence other equipment
(e.g. cause a lamp to blink). If the MAINS-IMPEDANCE Zmax
< 0.335 OHM, such disturbances are not expected. (If you
require assistance, contact your local supply authority for
further information.)
mWARNING! Electrical Shock Hazard – Before starting
up your machine, please check it carefully for any defects.
If you nd any, do not start up your machine and contact your
distributor.
The following should be observed when connecting the
high-pressure electric power washer to the electric supply:
• The electric supply connection should be performed by a
qualied person.
• The electric supply to this appliance should include either
a residual current device that will interrupt the supply if the
leakage current to the earth exceeds 30 mA for 30 ms or a
device that will interrupt the earth circuit (GFCI).
IMPORTANT: Only use water without any impurities.
If there is a risk of running sand into the inlet water (i.e. from
your own well), an additional lter should be installed.
Safety Devices
The unloader valve can reduce pressure if it exceeds preset
values. The spray gun features a locking device. When the lock
is activated, the spray gun cannot be operated.
1. Thermal sensor – A thermal sensor protects the motor
against overloading. The machine will restart after a few
minutes when the thermal sensor has cooled.
2. Double insulation – In a double-insulated appliance, two
systems of insulation are provided instead of grounding.
No grounding means is provided on a double-insulated
appliance, nor should a means for grounding be added
to the appliance. Servicing a double-insulated appliance
requires extreme care and knowledge of the system, and
should be performed only by qualied service personnel at
an authorized Snow Joe®+ Sun Joe®dealer. Replacement
parts for a double-insulated appliance must be identical
to the parts they replace. A double-insulated appliance
is marked with the words “Double Insulation” or “Double
Insulated.” The symbol (square within a square) may
also be marked on the appliance.
3. Ground fault circuit interrupter (GFCI) protection –
This pressure washer is provided with a ground-fault
circuit-interrupter (GFCI) built into the plug of the power-
supply cord. This device provides additional protection
from the risk of electric shock. Should replacement of
the plug or cord become necessary, use only identical
replacement parts that include GFCI protection.
4. It is not recommended to use an extension cord with
this pressure washer. The unit comes standard with a
35 ft GFCI power cable. Using an extension cord may
cause a drop in line voltage resulting in loss of power and
overheating.
5. To reduce the risk of electric shock, this appliance has
a polarized plug (i.e. one blade is wider than the other).
The appliance plug will t into a polarized outlet only
one way.
If the appliance plug does not t fully into the outlet,
reverse the plug. If the plug still does not t, make sure
that you are using the correct polarized wall outlet. If the

3
plug still does not t, contact a qualied electrician to
install the proper wall outlet. Do not modify the appliance
plug, power cord receptacle, or power cord plug in any
way.
6. To prevent the appliance cord from disconnecting from the
extension cord during operation, make a knot with the two
cords as shown in Table 1.
7. Do not abuse the cord. Never pull the pressure washer
by the cord or yank the cord to disconnect it from the
receptacle. Keep the cord away from heat, oil, and
sharp edges.
Risk of Electrocution
• Inspect cord before using.
• Do not use if cord is damaged.
• Keep all connections dry and o the ground.
• Do not touch plug with wet hands.
• Keep cord away from heat and sharp edges.
• Do not spray electrical apparatus and wiring.
Risk of Explosion
• Do not spray ammable liquids.
• Do not use acids, bases, solvents, or any ammable
material in this product. These substances can cause
physical injuries to the operator and irreversible damage to
the machine.
Additional Safety Instructions
• High-pressure: keep clear of nozzle.
• Injection hazard: equipment can cause serious injury if the
spray penetrates the skin.
• Do not point the gun at anyone or at any part of the body.
• In case of skin penetration, seek medical aid immediately.
• Before servicing, cleaning, or removing any parts, shut o
the power and relieve pressure.
• This machine is not suitable for connection to the potable
water mains.
Product Description
Purpose
• This high-pressure electric power washer is intended for
residential use to clean vehicles, machines, buildings,
facades, etc.
Areas of Application
• Never use the machine in potentially explosive areas under
any circumstances!
• The operating temperature must be between 32ºF (0ºC) and
104ºF (40ºC).
• The machine consists of an assembly with a pump, which
is encased in a shock-absorbing housing. To provide the
operator with an optimal working position, the machine is
equipped with a spray wand and a non-slip handle grip,
whose shape and conguration comply with applicable
regulations.
• Do not cover or modify the spray wand or the spray nozzles
in any way.
• The high-pressure electric power washer is designed to be
used with cold or lukewarm water; higher temperatures can
damage the pump.
• Do not use water that is dirty, gritty, or contains any
chemical products, as these could impair operation and
shorten the life of the machine.
mWARNING m
Electric shock may cause SEVERE INJURY or
DEATH. Heed these warnings:
• Do not allow any part of the electric pressure washer
to make contact with water while it is in operation. If
the appliance becomes wet while turned o, wipe dry
before starting.
• Do not use an extension cord over 25 ft. The
pressure washer comes equipped with a 35 ft power
cable. Combined cord length must not exceed 60 ft.
Any extension cord must be 14-gauge (or heavier) to
safely power the pressure washer.
• Do not touch the appliance or its plug with wet hands
or while standing in water. Wearing rubber boots
oers some protection.
EXTENSION CORD CHART
Cord Length:
Min. Wire Gauge (A.W.G.):
25 ft (7.6 m)
14
(B) Connect plug and receptacle
Cord set Appliance cord
(A) Tie cord as shown
Table 1. Method of Securing Extension Cord

4
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
To reduce the risk of injury, user
must keep all bystanders at least
49 ft (15 m) away.
Sound power level is 96 dB(A).
Always keep the power cord
away from heat sources, oils, or
sharp edges. Immediately remove
plug from the mains if the cord is
damaged, frayed, or entangled.
READ THE OPERATOR'S
MANUAL(S) – Read, understand,
and follow all instructions in the
user manual(s) before attempting
to assemble and operate.
SAFETY ALERT – Indicates a
precaution, a warning, or a danger.
WEAR EYE AND HEARING
PROTECTION – For protection
against injury, wear ear defenders
and safety goggles.
Double Insulation – When servicing,
use only identical replacement parts.
WARNING! Do not expose the unit
to rain or wet conditions. Keep dry.
Machine not suitable for connection
to the potable water mains.
WARNING! Electrical shock hazard –
Do not touch the plug with wet hands.
WARNING! Turn the machine OFF
and disconnect it from the power
supply before inspecting, cleaning,
changing accessories, or conducting
any other maintenance task.
Symbols SymbolsDescriptions Descriptions
Wear non-slip footwear that will
protect your feet and improve your
footing on slippery surfaces.
Wear safety gloves during
use to protect hands.
Store indoors. Never store the
pressure washer outdoors.
If the pump freezes, permanent
damage may result.

5
Know Your Electric Pressure Washer
Read the owner’s manual and safety instructions carefully before operating the electric pressure washer. Compare the illustration
below to the electric pressure washer in order to familiarize yourself with the location of the various controls and adjustments.
Save this manual for future reference.
Technical Data
Rated Voltage .......................................................120V ~ 60 Hz
Motor...........................................................................14.5-amp
Max Water Inlet Temperature ...................................104ºF/40ºC
Max Water Inlet Pressure .............................................0.7 MPa
Detergent Tank Capacity ...................................54.1  oz (1.6 L)
Hose Length............................................................... 20 ft (6 m)
Power Cord Length ............................................... 35 ft (10.7 m)
Net Weight...................................................... 32.2 lbs (14.6 kg)
Max Pressure at initial discharge ................................ 2030 PSI
per CSA internal pressure testing
Rated Pressure under typical load ........................ Low 870 PSI
High 1450 PSI
Max Flow with nozzle open ......................1.76 GPM (6.7 L/min)
at minimum pressure
Rated Flow ...................................... Low 1.05 GPM (4.0 L/min)
under typical load High 1.24 GPM (4.7 L/min)
1. Transport handle
2. Trigger gun
3. Safety lock (Locate lock in center of trigger.
Pull up and snap in place. See Fig. 12, pg. 8)
4. Trigger
5. High-pressure hose connection
6. Trigger gun holder
7. Spray wand
8. Detergent dial
9. ON/OFF switch (Pressure select dial)
10. Water inlet + Garden hose adapter (female coupler)
11. Detergent tank
12. High-pressure hose
13. Hand crank
14. Hose reel
15. Cable holder
16. Power cord with GFCI
17. Wheel (x2)
18. Needle clean-out tool
19. 0º Quick-Connect nozzle (red)
20. 15º Quick-Connect nozzle (yellow)
21. 25º Quick-Connect nozzle (green)
22. 40º Quick-Connect nozzle (gray)
23. Soap Quick-Connect nozzle (black)
15º
25º
0º
SOAP
40º
18
19 20 21 22 23
1
2
3
4
13
14
16
12
17
5
7
6
9
15
8
10
11

6
Unpacking
Carton Contents
• Upper handle frame + hose reel assembly
• Lower handle + pressure washer assembly
• Trigger gun
• Spray wand
• Five (5) Quick-Connect nozzles (0º, 15º, 25º, 40º and Soap)
• Trigger gun holder
• Needle clean-out tool
• High-pressure hose
• Garden hose adapter (female coupler)
• Manual with registration card
1. Carefully remove the pressure washer and check to see
that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store.
Please call the Snow Joe®+ Sun Joe®customer service
center at 1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new electric
pressure washer. The packaging is made of recyclable
materials. Properly dispose of these materials in
accordance with local regulations.
IMPORTANT! The equipment and packaging material are
not toys. Do not let children play with plastic bags, foils,
or small parts. These items can be swallowed and pose a
suocation risk!
mWARNING! Do not connect to power supply until
assembly is complete. Failure to comply could result in
accidental starting and possible serious personal injury.
Assembly
1. Position the washer as CLOSE as possible to the
water supply.
2. The washer must be used on a secure and stable surface
in a standing, upright position (Fig. 1).
3. Slide the upper handle frame into lower handle then
depress the small button at the end of the upper handle
frame, push and insert into lower handle until it snaps
securely into place (Figs. 2 – 3).
Fig. 1
Fig. 2
Upper
handle
frame
Lower
handle
Fig. 3
Upper
handle
frame
Lower
handle
Push
button

7
6. Insert high pressure hose into opening, as shown,
until it clicks securely in place (Fig. 4).
4. Fit the stainless steel lance into the trigger gun and rotate
the collar until the two parts are completely locked (Fig. 5).
5. Connect the high-pressure hose to the trigger gun
(Fig. 6).
mWARNING! Keep hose away from sharp objects.
Bursting hoses may cause injury. Examine hoses
regularly and replace if damaged. Do not attempt to
mend a damaged hose.
7. Connect the garden hose adapter (female coupler) to
the water inlet of the pressure washer, then thread your
garden hose (male end) into the garden hose adapter
(Figs. 7 – 8). The garden hose must have an
internal diameter of at least 13 mm (1/2 in.) and must be
reinforced. The water supply must be at least equal to the
washer delivery capacity.
NOTE: The machine is not suitable for connection to the
potable water main.
Fig. 4
High pressure hose
Hose reel
opening
Fig. 5
Stainless
steel lance
Trigger gun
Collar
High-pressure hose Trigger gun
Fig. 6
This end to the
water inlet on
the unit
Garden hose
(male end)
Fig. 7
Water inlet
(female coupler)
(FRONT)
Garden hose adapter
(female coupler)
Fig. 8
Garden hose adapter
(female coupler)
(FRONT)
Garden hose

8
8. Attach garden hose to water supply (Fig. 9).
mWARNING! Do not connect to potable water system.
mWARNING! If connection is made to a potable water
system, the system shall be protected against backow
mWARNING! The intake water temperature must not
exceed 104ºF/40ºC. The water supply must not exceed
0.7 MPa.
mCAUTION! The washer must only be used with clean
water; use of unltered water containing corrosive
chemicals will damage the washer.
9. Make sure the ON/OFF switch (pressure select dial) is
pushed to the STOP (0) position before plugging the unit
into the power outlet (Fig. 10).
10. Check that the electrical supply voltage and frequency
(Volt/Hz) correspond to those specied on the pressure
washer rating plate. If the power supply is correct,
you may now plug the pressure washer into the power
outlet (Fig. 11).
NOTE: The GFCI may need to be reset when rst plugged
into the electric outlet. Press the "Reset" button until the
power light indicator on the GFCI illuminates.
Operation
mIMPORTANT! This pressure washer is equipped with
a micro-switch sensitive to water ow. This Total Stop System
(TSS) senses water ow in the pump. When the trigger is
released, water stops owing through the pump. The TSS then
automatically turns the motor o to protect the pump from
overheating, thus saving energy and prolonging pump life.
1. Turn the water supply tap on completely.
2. Make sure the safety lock is down and in its original
position (Fig. 12), then press the trigger for a few seconds
until water ow is steady. This will allow air to escape and
discharge any residual pressure in the hose.
Fig. 9
Connect to water supply
Garden hose
STOP
LOW
0
HIGH
Fig. 10
RESET
TEST
Fig. 11
GFCI
Power light
indicator
Reset
Fig. 12
Safety lock
Slot
Trigger

9
3. Turn the ON/OFF switch (pressure select dial) to the LOW (I)
or HIGH (II) position to start the pressure washer (Fig. 13).
Using the Nozzles
Before beginning any cleaning task, determine the best nozzle
for the job. Each of the nozzles has a dierent spray pattern.
The nozzle patterns are 40˚ (for gentle cleaning), 25˚ (for
all-purpose cleaning), 15˚ (for tough jobs), 0˚ (for spot cleaning
or hard-to-reach areas) and the Soap nozzle (for detergent
application).
mCAUTION! NEVER change nozzles without locking the
safety lock on the trigger handle.
mWARNING! High-pressure jets can be dangerous if
subject to misuse. The jet must not be directed at persons,
pets, live electrical equipment, or the appliance itself.
This electric pressure washer is equipped with ve (5)
Quick-Connect nozzles that easily snap onto the
Quick-Connect collar of the spray wand.
To connect a nozzle to the spray wand:
1. Turn o the pressure washer and shut o the water supply.
Pull the trigger to release water pressure.
2. Engage the safety lock on the trigger handle by pushing
up on the safety lock until it clicks into the slot (Fig. 14).
3. Snap the desired nozzle onto the Quick-Connect collar
until it clicks into place (Fig. 15).
To disconnect a nozzle from the spray wand once the cleaning
job is complete:
4. Turn o the pressure washer and shut o the water supply.
Pull the trigger to release water pressure.
5. Engage the safety lock on the trigger handle by pushing
up on the safety lock until it clicks into the slot (Fig. 14).
6. Remove the nozzle by placing your hand over the nozzle
while pulling back on the Quick-Connect collar.
mWARNING! Do not make changes to the nozzle while
the trigger is engaged. Doing so could result in damage to the
pressure washer or injury to the user.
Working with Detergents
When cleaning with the pressure washer, some cleaning tasks
can be solved with water alone, but for most tasks cleaning
with detergent allows for more eective dirt removal.
mWARNING! Use only detergents specically designed
for use with pressure washers. DO NOT USE household
detergents, acids, alkaline solutions, bleaches, solvents,
ammable material, or industrial grade solutions. These could
damage the pressure washer. Many detergents may require
mixing prior to use. Prepare the cleaning solution as instructed
on the solution bottle.
1. Remove the cap from the detergent tank and ll the tank
with detergent (Fig. 16).
STOP
LOW
0
HIGH
Fig. 13
Fig. 14
Safety lock
Slot
Fig. 15
Nozzle
“Click”
Quick-Connect collar
Spray wand
Fig. 16
Pressure washer
detergent Detergent
tank

10
2. Install the soap nozzle (black) on the spray wand (Fig. 15).
3. Turn on the pressure washer. Pull the trigger to operate
the unit. The liquid detergent will automatically mix with
water and be discharged through the nozzle.
mCAUTION! Always test the detergent in an
inconspicuous area before use.
4. Turn the detergent dial to adjust the suction volume of the
detergent solution (Fig. 17).
5. Apply detergent from the bottom to the top of the dry
surface to be cleaned.
NOTE: Wetting the surface rst is not recommended as it
dilutes the detergent and reduces its cleaning ability.
6. Allow the detergent to remain on the surface for a short
time before rinsing. Do not allow the detergent to dry on
the surface.
mCAUTION! Damage may occur to painted surfaces if
the detergent is allowed to dry on the surface. Wash and rinse
a small section at a time. Avoid working on hot surfaces or in
direct sunlight.
7. When nished using the pressure washer, you must rst
drain and rinse the detergent tanks. Run the pressure
washer in low pressure until all of the soap is drained from
the detergent tanks.
mCAUTION! Failure to follow these cleaning instructions
will cause the injection system to become clogged and
inoperable.
Rinsing with the Pressure Washer
1. Turn o the pressure washer and shut o the water supply.
2. Pull the trigger to release water pressure.
3. Engage the safety lock on the trigger handle by pushing
up on the safety lock until it clicks into the slot (Fig. 14).
4. Remove the nozzle by placing your hand over the nozzle
while pulling back on the quick-connect collar.
5. Select the right nozzle for the job (Fig. 18):
I) The 0º intense-jet nozzle (red) is an extremely powerful
nozzle that delivers a high-pressure,
pencil-point jet stream. It is used to cut heavy dirt
deposits in a small, concentrated area. It is ideal for
dissolving stubborn substances, like tar and grease
spots on concrete, or for removing caked mud from
equipment. Use this nozzle to clean hard-to-reach
areas including the facades of 2-story buildings or the
undersides of lawn mowers and tractors.
NOTE: Care should be used when choosing the
right nozzle to avoid permanently gouging wood or
damaging fragile surfaces.
II) Use the 15º fan-tip nozzle (yellow) for intense cleaning
jobs on hard surfaces. Applications include stripping
paint, removing oil stains, grease, heavy mildew stains,
and rust from steel. This nozzle should only be used in
areas that can withstand the high-pressure from this
nozzle.
III) Use the 25º fan-tip nozzle (green) to clean home siding,
brick patios, wood decks, driveways, or sidewalks.
When using this nozzle, test a small area rst to avoid
surface damage.
IV) Use the 40º wide-spray tip nozzle (gray) to clean items
such as cars, trucks, boats, patio furniture, or lawn
equipment.
V) Use the Soap nozzle (black) for low-pressure detergent
application to clean equipment, remove mildew and
oxidation stains from houses, clean bricks or degrease
grimy surfaces.
NOTE: When using detergent, make sure to install the
correct Soap nozzle (black). All of the other colored
nozzles will not work for detergent application.
6. Start at the top of the area to be rinsed and work your way
down, making sure to overlap your strokes.
MIN
MAX
Fig. 17
Detergent dial
15º
SOAP
25º 40º
0º
Fig. 18

11
mIMPORTANT! NEVER USE:
• Bleach, chlorine products, and other corrosive chemicals
• Liquids containing solvents
(e.g. paint thinners, gasoline, oils)
• Tri-sodium phosphate products
• Ammonia products
• Acid-based products
These chemicals will harm the unit and will damage
the cleaning surface.
Shutting Down
1. Turn the switch to the STOP (0) position and unplug the
power cord from the outlet.
2. Turn o the water source.
3. Hold the trigger to release water pressure.
4. Disconnect the garden hose from the water inlet on
the unit.
5. Disconnect the high-pressure hose connection on the
trigger gun handle.
6. Release the trigger and engage the gun safety lock.
mWARNING! Turn o the water supply and squeeze the
trigger to depressurize the unit. Failure to do so could result in
personal injury due to discharge of high-pressure water.
Taking a Break
If you are taking a break of ve minutes or more between
cleaning tasks:
1. Engage the gun safety lock (Fig. 14).
2. Turn the switch to the STOP (0) position.
3. Unplug the power cord from the outlet.
Storage
Hose reel
1. Unlock the hose reel by pulling out on the handle out
(Fig. 19).
2. Turn the handle counterclockwise to wind the hose
(Fig. 20).
3. Wind the hose until you reach the hose's end.
4. Push the handle in to lock the reel.
mCAUTION! Always store your pressure washer in a
location where the temperature will not fall below 32ºF (0ºC).
The pump in this machine is susceptible to permanent damage
if it freezes. FREEZE DAMAGE IS NOT COVERED BY THE
WARRANTY.
• Store the pressure washer indoors in a dry, covered area
where it is not subject to adverse weather conditions.
• It is important to store this product in a frost-free area.
• Always empty water from all hoses, the pump, and the
detergent tank before storing.
mCAUTION! The use of a pump protector is
recommended to prevent cold weather damage during storage
over the winter months.
Winterizing + Long-Term Storage
If you must store your pressure washer in a location where
the temperature falls below 32ºF (0ºC), you can minimize the
chance of damage to your machine by utilizing the following
procedure:
• Disconnect all water connections.
• Turn on the machine for a few seconds until the remaining
water in the pump exits. Turn o immediately.
• Do not allow the high-pressure hose to become kinked.
• Store the machine and accessories in a room that does
not reach freezing temperatures.
• Do not store near a furnace or other sources of heat that
may dry out the pump seals.
• Operate the pressure washer with non-corrosive/non-toxic
anti-freeze, a pump saver, or a pump protector before
storing for the winter.
Fig. 19
Hose reel
handle
Fig. 20
Hose reel
handle

12
mWARNING! Before reusing, completely ush the unit
out with clear water. Anti-freeze products can damage
paintwork, so you must ensure there is no anti-freeze left in the
system before using it again.
Maintenance
mCAUTION! Before working on the pressure washer,
disconnect the plug from the power supply socket.
1. To ensure good performance, check and clean the water
inlet lter (Fig. 21). Remove the pre-lter and water inlet
lter and rinse with warm water to prevent any foreign
matter from clogging the pump (Figs. 22 – 23).
2. Clean the nozzle with the needle clean-out tool provided
(Fig. 24). Remove the spray wand from the gun;
remove any dirt from the nozzle hole and rinse.
3. Remove additional debris by back ushing water through
the nozzle and spray wand. To do this, place the end of
your garden hose (with water running) to the tip of the
nozzle, pushing water and debris out of the back opening
of the nozzle and spray wand.
Disposal
Recycling the Washer
• Do not dispose of electrical appliances as unsorted
municipal waste. Use separate collection facilities.
• Contact your local government agency for information
regarding the collection systems available.
• If electrical appliances are disposed of in landlls
or dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging your
health and well-being.
• When replacing old appliances with new ones, the retailer
is legally obligated to take back your old appliance for
disposal at least free of charge.
Service + Support
If your Sun Joe®SPX4001 electric pressure washer requires
service or maintenance, please call the Snow Joe®+
Sun Joe®customer service center at 1-866-SNOWJOE
(1-866-766-9563).
Model + Serial Numbers
When contacting the company, reordering parts, or arranging
service from an authorized dealer, you will need to provide the
model and serial numbers, which can be found on the decal
located on the housing of the unit. Copy these numbers into
the space provided below.
Fig. 21 (FRONT)
Waterinletlter
Garden hose adaptor
Pre-lter
Fig. 22
Pre-lter
Fig. 23
Inletlter
15º
Fig. 24
Needle clean-out tool
Record the following numbers from the housing or handle of your
new product:
S P X 4 0 0 1
Model #:
Serial #:

13
Federal Communications
Commission (FCC)
mWARNING! Any changes or modications to this
unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the
equipment.
Class B device:
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur
in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.

14
Troubleshooting
• Disconnect the unit from the electrical power supply before carrying out maintenance on the machine or when checking that its
parts are in proper working order.
• To avoid unnecessary hassles, consult the following table before contacting customer service with any mechanical issues.
Problems Possible Cause Possible Solution
Machine refuses
to start
• Power failure/machine not
plugged into a working receptacle.
• Defective socket.
• Fuse has blown.
• Defective extension cord.
• Check to make sure machine is plugged into
a working outlet.
• Check the power cord and reset the GFCI.
Try a dierent outlet.
• Replace fuse. Switch o any other machines
that are using the same circuit.
• Try the unit without an extension cord.
• Check the hoses and connections are airtight.
• Clean or replace valves/seals.
• Please call the Snow Joe®+ Sun Joe®customer
service center at 1-866-SNOWJOE (1-866-766-9563)
for assistance.
• Replace fuse. Switch o other machines using
the same circuit.
• Check that the mains voltage corresponds to
specication on the model tag.
• Leave the washer for 5 minutes to cool down.
• Clean the nozzle.
• Install a fuse with a higher amp rating than the
amp consumption of the machine. Try the unit
without an extension cord.
• Allow machine to run by holding the trigger until
regular working pressure resumes.
• Check that the water supply corresponds to the
specications required.
•WARNING! Avoid using long, thin hoses
(minimum 1/2 in. diameter).
• Clean the nozzle.
• Clean the water inlet lter.
• Straighten out the hose to remove any kinks/blockages.
• Please call Snow Joe®+ Sun Joe®customer service
center at 1-866-SNOWJOE (1-866-766-9563) for
assistance.
• Wait for pump/hoses or accessories to thaw.
• Connect inlet water.
• Clean the water inlet lter.
• Clean the nozzle.
• Pump sucking air.
• Valves dirty, worn out, or stuck.
• Pump seals worn out.
• Fuse has blown.
• Incorrect mains voltage.
• Thermal sensor activated.
• Nozzle partially blocked.
• Fuse too small.
• Air in inlet hose.
• Inadequate supply of mains water.
• Nozzle partially blocked.
• Water lter blocked.
• Hose kinked.
• Pump/spray gun is leaking.
• Trigger mechanism is broken.
• Pump/hoses or accessories frozen.
• No water supply.
• Water inlet lter blocked.
• Nozzle blocked.
Fluctuating pressure
Machine stops
Fuse blows
Machine pulsating
Machine often starts
and stops by itself
Machine starts, but
no water comes out

15
Accessories
mWARNING! ALWAYS use only authorized Snow Joe®+ Sun Joe®replacement parts and accessories. NEVER use
replacement parts or accessories that are not intended for use with this electric pressure washer. Contact Snow Joe®+ Sun Joe®
if you are unsure whether it is safe to use a particular replacement part or accessory with your pressure washer. The use of any
other attachment or accessory can be dangerous and could cause injury or mechanical damage.
Sun Joe’s complete line of premium pressure washer accessories and attachments
make it easy to get your dirty work done, and also help you get the most out of your model!
SHOP ONLINE now at sunjoe.com
NOTE: Accessories are subject to change without any obligation on the part of Snow Joe®+ Sun Joe®to provide notice of such
changes. Accessories can be ordered online at sunjoe.com or via phone by contacting the Snow Joe®+ Sun Joe®customer
service center at 1-866-SNOWJOE (1-866-766-9563).
Solid Brass Universal Quick-Connect Coupler
(Garden Hose to Pressure Washer Adapter)
SPX3000-TPS
SPX-25H
SPX-UQC
ModelAccessories Item
1
2
3
1155ºº
SOSOAAPP
2255ºº4400ºº
00ºº
4Sun Joe®House + Deck All-Purpose Pressure
Washer Rated Concentrated Cleaner
Sun Joe®Premium Snow Foam Pressure
Washer Rated Car Wash Soap + Cleaner
Sun Joe®All-Purpose Heavy Duty Pressure
Washer Rated Cleaner + Degreaser
SPX-HDC1G
SPX-FCS1G
SPX-APC1G
Spray Tip Set
(Compatible with most
SPX Series Pressure Washers)
25 ft Medium-Duty
High Pressure Extension Hose
(For SPX Pressure Washer Series)

R4_01282020
SNOW JOE®+ SUN JOE®CUSTOMER PROMISE
OUR WARRANTY:
Snow Joe warrants new, genuine, powered and non-powered Products to be free from defects in material or workmanship when used
for ordinary household use for a period of two years from the date of purchase by the original, end-user purchaser when purchased
from Snow Joe or from one of Snow Joe’s authorized sellers with proof of purchase. Because Snow Joe is unable to control the quality
of its Products sold by unauthorized sellers, unless otherwise prohibited by law, this Warranty does not cover Products purchased from
unauthorized sellers. If your Product does not work or there’s an issue with a specic part that is covered by the terms of this Warranty,
Snow Joe will elect to either (1) send you a free replacement part, (2) replace the Product with a new or comparable product at no
charge, or (3) repair the Product. How cool is that!
This Warranty gives you specific legal rights, and you may also have other rights which vary from State to State.
PRODUCT REGISTRATION:
Snow Joe strongly encourages you to register your Product. You can register online at snowjoe.com/register, or by printing and
mailing in a registration card available online from our website, or calling our Customer Service Department at 1-866-SNOWJOE
(1-866-766-9563), or by e-mailing us at [email protected]. Failure to register your Product will not diminish your warranty
rights. However, registering your Product will allow Snow Joe to better serve you with any of your customer service needs.
WHO CAN SEEK LIMITED WARRANTY COVERAGE:
This Warranty is extended by Snow Joe to the original purchaser and original owner of the Product.
WHAT IS NOT COVERED?
This Warranty does not apply if the Product has been used commercially or for non-household or rental applications. This Warranty also
does not apply if the Product was purchased from an unauthorized seller. This Warranty also does not cover cosmetic changes that do
not aect performance. Wearing parts like belts, augers, chains and tines are not covered under this Warranty, and can be purchased
at snowjoe.com or by calling 1-866-SNOWJOE (1-866-766-9563).
ABOVE ALL ELSE, Snow Joe, LLC (“Snow Joe”) is dedicated to you, our customer. We strive to make your experience as pleasant as
possible. Unfortunately, there are times when a Snow Joe®, Sun Joe®, or Aqua Joe®product (“Product”) does not work or breaks under
normal operating conditions. We think it’s important that you know what you can expect from us. That’s why we have a Limited Warranty
(“Warranty”) for our Products.
16
EN

17

SP
Una división de Snow Joe®, LLC
R
MANUAL DEL OPERADOR
© 2021 Snow Joe®, LLC
Derechos reservados. Instrucciones originales. GUARDE ESTAS INSTRUCCIONES
19
Modelo SPX4001 Forma No. SJ-SPX4001-880S-MR6
14.5 A HIDROLAVADORA ELÉCTRICA
2,030 PSI MÁX.AL MOMENTO DE LA DESCARGA INICIAL SEGÚN PRUEBA DE PRESIÓN INTERNA DE CSA
6.7 L/min MÁX. CON BOQUILLA ABIERTA A MÍNIMA PRESIÓN
¡IMPORTANTE!
Instrucciones de seguridad
Todos los operadores deberán leer
estas instrucciones antes del uso
m¡ADVERTENCIA! Esto indica una situación peligrosa
la cual, de no ser evitada, puede resultar en lesiones severas o
la muerte.
m¡PRECAUCIÓN! Esto indica una situación peligrosa
la cual, de no ser evitada, puede resultar en lesiones menores
o moderadas.
m¡PELIGRO! Esto indica una situación peligrosa la cual,
de no ser evitada, dará como resultado lesiones severas o la
muerte.
Seguridad general
m¡ADVERTENCIA! Este artefacto no ha sido diseñado
para su uso por niños o por otras personas sin asistencia o
supervisión cuyas habilidades físicas, sensoriales o mentales
les impidan usarlo de forma segura. Los niños deben estar
bajo supervisión para garantizar que no jueguen con el
artefacto.
Antes de encender su hidrolavadora eléctrica, inspecciónela
cuidadosamente para cerciorarse de que no tenga defecto
alguno. Si encuentra algún defecto, no la encienda. Contacte
a un concesionario autorizado Snow Joe®+ Sun Joe®o
comuníquese con la central de servicio al cliente Snow Joe®+
Sun Joe®llamando al 1-866-SNOWJOE (1-866-766-9563).
m¡ADVERTENCIA! Al usar esta hidrolavadora eléctrica,
se deberán tomar siempre precauciones básicas de seguridad
para reducir el riesgo de incendio, choque eléctrico y lesiones
personales. Estas precauciones básicas incluyen:
• Conozca su producto: sepa cómo detener la máquina y
purgar la presión de forma rápida. Familiarícese a fondo
con los controles.
• Mantenga alejados a los transeúntes: todas las personas
y mascotas deberán encontrarse a una distancia segura del
área de trabajo.
• Use el producto adecuado: no utilice esta máquina para
ningún otro trabajo excepto para el cual ha sido diseñada.
• Vístase apropiadamente: no utilice prendas holgadas ni
joyería. Pueden llegar a engancharse en las partes móviles.
Al trabajar en exteriores, se recomienda el uso de guantes
de goma y calzado antideslizante.
• m¡PRECAUCIÓN! Tenga cuidado y evite resbalar o caer.
Utilice calzado protector que proteja sus pies y mejore su
posición de pie en supercies resbaladizas.
• Manténgase alerta: vea lo que está haciendo. Utilice su
sentido común. No opere la hidrolavadora eléctrica si usted
está cansado o bajo la inuencia del alcohol o las drogas.
• No adopte una postura inclinada: mantenga con sus pies
balance y posición adecuados todo el tiempo.
• Evitelosencendidosaccidentales: no transporte la
máquina enchufada con su dedo en el gatillo. Asegúrese de
que el interruptor esté en la posición de apagado antes de
enchufar la unidad.
• No abuse del cable: nunca jale la máquina por el
cable ni tire bruscamente de él para desconectarlo del
tomacorriente. Mantenga el cable alejado del calor,
aceites y bordes losos.
• Use gafas protectoras use también calzado protector,
ropa que se ajuste a su cuerpo, guantes protectores y
protección auditiva y para la cabeza.
• Compruebe la temperatura del agua: esta hidrolavadora
eléctrica no está hecha para bombear agua caliente.
NUNCA la conecte a una fuente de agua caliente ya que
reducirá signicativamente el ciclo de vida de la bomba.
• Guárdela en un lugar bajo techo: NUNCA almacene
la hidrolavadora eléctrica en exteriores o donde pueda
congelarse. La bomba podría dañarse seriamente.
• Interruptor de circuito de falla de conexión a tierra
(GFCI): este producto incluye un interruptor de circuito de
falla de conexión a tierra incorporado al enchufe de cable
de alimentación. Si se necesita reemplazar el enchufe
o cable de alimentación, use solo partes de repuesto
idénticas.
• Inspeccionesloscableseléctricos: el aislamiento del
cable de alimentación debe estar perfectamente intacto.
Si el cable de alimentación está dañado o hay señales
de desgaste o deterioro, no use esta hidrolavadora
eléctrica. Contacte a un concesionario autorizado
Snow Joe®+ Sun Joe®o comuníquese con la central
de servicio al cliente Snow Joe®+ Sun Joe®llamando al
1-866-SNOWJOE (1-866-766-9563).
m¡ADVERTENCIA! No use este artefacto sin leer este
manual de instrucciones.

20
m¡ADVERTENCIA! Este artefacto ha sido diseñado
para su uso con agentes de limpieza recomendados por el
fabricante. El uso de otros agentes de limpieza o químicos
puede afectar de forma negativa la seguridad del artefacto.
m¡ADVERTENCIA! No use el artefacto cerca de
personas, a menos que estén usando ropa protectora.
m¡ADVERTENCIA! Los chorros de alta presión pueden
ser peligrosos si se manipulan incorrectamente. El chorro no
deberá estar dirigido a personas, mascotas, equipos eléctricos
activos, o al artefacto en sí.
• No dirija el chorro hacia usted o demás personas para
limpiar ropa o calzado.
• Riesgo de explosión: no rocíe líquidos inamables.
• Desconecte la hidrolavadora: desconecte la hidrolavadora
eléctrica de la fuente de alimentación antes de llevar a cabo
cualquier mantenimiento.
• Mantenga alejados a los niños: esta hidrolavadora
eléctrica de alta presión no debe ser usada por niños o
personas no capacitadas.
• Para garantizar un uso seguro del artefacto, use solo partes
de repuesto del fabricante o aprobadas por éste.
m¡ADVERTENCIA! El agua que ha uido a través de
válvulas contra-reujo se considera como no potable.
m¡ADVERTENCIA! La máquina deberá estar
desconectada de su fuente de alimentación, es decir
desenchufada del tomacorriente, durante la limpieza,
mantenimiento o reemplazo de las partes.
m¡ADVERTENCIA! Las mangueras, juntas y
acoplamientos para presiones altas son importantes para
la seguridad del artefacto. Use solo mangueras, juntas y
acoplamientos recomendados por el fabricante.
• Inspeccione la unidad en búsqueda de partes dañadas:
no use el artefacto si hay daños en el cable de alimentación
o en partes importantes; p. ej., dispositivos de seguridad,
mangueras para presión alta o pistola rociadora.
m¡ADVERTENCIA! Si se usa un cable de extensión,
el enchufe y tomacorriente deben ser a prueba de agua.
m¡ADVERTENCIA! Los cables de extensión
inadecuados pueden ser peligrosos.
• Esta hidrolavadora eléctrica de alta presión no debe ser
usada a temperaturas menores de 32ºF (0°C).
m¡ADVERTENCIA! El cable sobre los tanques debe
estar siempre desenrollado por completo para evitar el
sobrecalentamiento.
• Las conexiones de cables de alimentación deben
permanecer secas y por encima del nivel del suelo.
• Si el cable de alimentación está dañado, no utilice la
hidrolavadora. Contacte a un concesionario autorizado
Snow Joe®+ Sun Joe®o comuníquese con la central
de servicio al cliente Snow Joe®+ Sun Joe®llamando al
1-866-SNOWJOE (1-866-766-9563).
• Mantenga la máquina en una supercie estable y
plana durante la operación, manipulación, transporte y
almacenamiento. Un volcado repentino de la máquina
puede causar lesiones corporales.
• En caso de accidente o desperfecto, desenchufe la
máquina inmediatamente. (Si hay contacto con el
detergente: enjuague con abundante agua limpia).
Seguridad eléctrica
ATENCIÓN:si hay problemas con la RED ELÉCTRICA,
pueden ocurrir caídas breves de voltaje al encender el equipo.
Estas a su vez pueden afectar otros equipos (como por
ejemplo, el parpadeo de una lámpara). Si la IMPEDANCIA
DE LA RED (Zmax) es menor que 0.335 ohmios, estas
uctuaciones no son esperadas (si necesita ayuda, puede
contactar a su empresa local de suministro eléctrico para
más información).
m¡ADVERTENCIA! Peligro de descarga eléctrica:
antes de encender su máquina, por favor inspecciónela
cuidadosamente para comprobar que no tenga defectos.
Si encuentra algún defecto, no la encienda y contacte a su
distribuidor.
Se deberá cumplir lo siguiente al conectar la hidrolavadora
eléctrica de alta presión a la red eléctrica:
• La conexión al suministro eléctrico deberá haber sido
hecha por una persona calicada.
• La alimentación de electricidad a este artefacto deberá
incluir ya sea un dispositivo de corriente residual (RCD)
que interrumpirá el suministro si la corriente de fuga a
tierra excede los 30 mA durante 30 ms, o un interruptor de
circuito a tierra (GFCI).
IMPORTANTE:solo use agua sin impurezas. Si hay un
peligro de arena uida en el agua de entrada (p. ej., de su
propio pozo), se deberá instalar un ltro adicional.
Dispositivos de seguridad
La válvula del descargador puede reducir la presión si ésta
excede los valores predeterminados. La pistola rociadora
incluye un dispositivo de trabado. Cuando el trabado está
activado, la pistola rociadora no puede ser operada.
1. Sensor térmico: un sensor térmico protege el motor
contra las sobrecargas. La máquina se reiniciará luego de
unos cuantos minutos, cuando el sensor térmico se haya
enfriado.
2. Doble aislamiento: en un artefacto de doble aislamiento,
se proporcionan dos sistemas de aislamiento en
lugar de una conexión a tierra. Un artefacto de doble
aislamiento no posee una conexión a tierra, y no debe
agregársele ninguna. La reparación de un artefacto de
doble aislamiento requiere sumo cuidado y conocimiento
del sistema, y solo debe ser realizada por personal
técnico calicado en un centro de servicio autorizado por
Snow Joe®+ Sun Joe®. Las partes de repuesto de un
