sunjoe 24V-XFP5-CT User manual

© 2020 by Snow Joe®, LLC
All rights reserved. Original instructions.
1
A Division of Snow Joe®, LLC Model 24V-XFP5-CT Form No. SJ-24V-XFP5-CT-880E-M
R
OPERATOR’S MANUAL
CORDLESS WATER TRANSFER PUMP
– TOOL ONLY
24V MAX* | 330 GPH
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Any electrical appliance can be dangerous if used incorrectly.
Some of the safety precautions given in this manual apply
generally to many appliances. Other warnings are specic to
the use of this cordless transfer pump.
Always follow these safety guidelines. Failure to do so may
result in personal injury or property damage.
mWARNING! This unit can be dangerous! Careless or
improper use can cause serious injury.
General Safety
FOR HOUSEHOLD USE ONLY
Before using, be sure that everyone using this tool reads
and understands all safety instructions and other information
contained in this manual. Save this manual and review it
frequently prior to using this tool and when instructing
others on the proper operating procedures.
Before using the transfer pump, take the time to familiarize
yourself with the controls, especially how to stop the transfer
pump. The only individuals who should use the transfer
pump are those who have a thorough understanding of the
instructions and who know how to operate the machine.
Children should never be allowed access to the transfer pump.
Retain this manual for future reference.
mWARNING! Read all safety warnings, instructions,
illustrations and specications provided with the pump. Failure
to follow all instructions listed below may result in electric
shock, re and/or serious injury.
Work Area Safety
• Keep your work area clean and well lit. Cluttered
benches and dark areas invite accidents.
• Do not operate the product in explosive atmospheres,
such as in the presence of ammable liquids, gases, or
dust. Products create sparks which may ignite the dust or
fumes.
• Keep children and bystanders away while operating the
product. Distractions can cause you to lose control.
Personal Safety
• Do not overreach. Keep proper footing and balance at all
times. Proper footing and balance enable better control of
the product in unexpected situations.
• Do not use on a ladder or unstable support. Stable
footing on a solid surface enables better control of the
product in unexpected situations.
• Prevent unintentional starting. Ensure the switch is in the
o-position before inserting the battery pack, picking up or
carrying the tool. Carrying power tools with your nger on
the switch or energizing power tools that have the switch on
invites accidents.
• Stay alert, watch what you are doing and use common
sense when operating. Do not attempt to operate this
pump while you are tired or under the inuence of drugs,
alcohol or medication. A moment of inattention may result
in personal injury.
• Use the product only for its intended use as described in
this manual.
• If the product is not working properly, has been dropped,
damaged, left outdoors or dropped into water, contact
an authorized Snow Joe®+ Sun Joe®dealer or call
the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
• Only use attachments and accessories specied by the
manufacturer.
Transfer Pump Use and Care
mCAUTION! The pump has been evaluated for use
with water only. Do not use with acids, alkalines, solvents,
ammable material, gasoline or petroleum products, bleaches,
or industrial grade solutions. These products can cause
physical injuries to the operator and irreversible damage to the
pump.
• Do not use the pump if the switch does not turn it on
and o. Any tool cannot be controlled with the switch is
dangerous and must be repaired.
• Remove the battery before making any adjustments,
changing accessories, or storing the product. Such
preventive safety measures reduce the risk of starting the
product accidentally.
• Release the pressure and drain water from pump before
servicing.
SAVE THESE INSTRUCTIONS

2
• Keep handles and grasping surfaces dry, clean and free
from oil and grease. Slippery handles and grasping surfaces
may result in lose of handling and control of the tool in
unexpected situations.
• Clean with only dry cloth.
• Do not operate near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
• Do not remove hose while pump is still operating.
• Do not put any objects in ventilation openings. Do
not use the product with any opening blocked. Keep
openings free of dust, lint, hair and anything that may
reduce air ow.
• Maintain pump and accessories. Check for misalignment or
binding of moving parts, breakage of parts and any other
condition that may aect the pump’s operation. If damaged,
have the pump repaired before use. Accidents can be
caused by a poorly maintained pump.
Electric Safety
mWARNING! Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
1. Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of re when used with
another battery pack.
2. Use appliances only with specically designated battery
packs. Use of any other battery packs may create a risk of
injury and re.
3. When the battery pack is not in use, keep them away
from other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can make
a connection from one terminal to another. Shorting the
battery terminals together may cause burns or a re.
4. Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
ush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
5. Do not use a battery pack or appliance that is damaged
or modied. Damaged or modied batteries may exhibit
unpredictable behavior resulting in re, explosion or risk of
injury.
6. Do not expose a battery pack or appliance to re or
excessive temperature. Exposure to re or temperature
above 104°F(40.5°C) may cause explosion.
7. Follow all charging instructions and do not charge the
battery pack or appliance outside of the temperature
range specied in the instructions. Charging improperly
or at temperatures outside of the specied range may
damage the battery and increase the risk of re.
8. Do not modify or attempt to repair the appliance or the
battery pack (as applicable) except as indicated in the
instructions for use and care.
Transfer Pump Safety Warnings
1. Know your product. Read operator’s manual carefully.
Learn its applications and limitations, as well as the
specic potential hazards related to this product.
Following this rule will reduce the risk of electric shock,
re, or serious injury.
2. Do not allow children to operate the product or play with
the product as a toy. Close attention is necessary when
used near children.
3. Do not let the pump run dry.
4. Do not lift the pump by hoses.
5. Periodically inspect the pump and the hose. Ensure
hoses are free from mud, sand and debris. Disconnect
the battery before inspecting.
6. This pump has been evaluated for use with water only .
7. The pump is not submersible.
8. Risk Of Electric Shock – this pump has not been
investigated for use in swimming pool or marine areas.
9. This pump is thermally protected.
10. Battery tools do not have to be plugged into an electrical
outlet; therefore, they are always in operating condition.
Be aware of possible hazards when not using your battery
tool or when changing accessories. Following this rule will
reduce the risk of electric shock, re, or serious personal
injury.
11. Do not place the product or its batteries near re or
heat. This will reduce the risk of explosion and possibly
injury.
12. Do not crush, drop or damage battery pack. Do not use a
battery pack or charger that has been dropped or received
a sharp blow. A damaged battery is subject to explosion.
Properly dispose of a dropped or damaged battery
immediately.
13. Batteries can explode in the presence of a source
of ignition, such as a pilot light. To reduce the risk of
serious personal injury, never use any cordless product
in the presence of open ame. An exploded battery can
propel debris and chemicals. If exposed, ush with water
immediately.
14. Do not charge battery tool in a damp or wet location. Do
not use, store, or charge battery packs or products in
locations where the temperature is less than 41°F or more
than 105°F. Do not store outside or in vehicles.

3
15. Do not incinerate the battery even if it is severely
damaged. The batteries can explode in a re.
16. To reduce the risk of re or electric shock, do not use this
product with any solid-state speed control device.
17. To reduce the risk of personal injury and electric shock,
the product should not be played with or placed where
small children can reach it.
18. To reduce the risk of electric shock, do not expose to
water or rain.
19. Not for potable water or other potable liquids.
20. Do not pump water with a temperature over 104°F (40°C).
Do not pump sand, particulate, or large debris. Damage to
the pump will occur.
21. Do not allow this pump to operate unattended. Failure to
follow this warning could result in personal injury.
22. Do not pump water from a creek, pond, or source where
foreign objects may be sucked into the pump. Solids may
enter the inlet hose.
23. Secure the discharge hose before starting the pump.
An unsecured discharge hose may whip. Personal injury
and/or death could result.
Service
1. Have servicing performed by a qualied repair person
using only identical replacement parts. This will ensure
that the safety of the product is maintained.
2. When servicing the product, use only identical
replacement parts. Follow instructions in the Maintenance
section of this manual. Use of unauthorized parts or failure
to follow Maintenance Instructions may create a risk of
shock or injury.
Battery + Charger
Safety Instructions
NOTE: This unit is tool only. The battery and the charger are
not included. They must be purchased separately.
Model 24V-XFP5-CT is compatible with the iON+ 24V System
batteries and chargers. See page 15 for more information.
We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This data is then used exclusively to be able to assemble the
best possible battery packs.
Despite all the safety precautions, caution must always be
exercised when handling the battery. The following points must
be obeyed at all times to ensure safe use. Safe use can only
be guaranteed if undamaged cells are used. Incorrect handling
of the battery pack can cause cell damage.
IMPORTANT! Analyses conrm that incorrect use and poor
care of high-performance batteries are the main factors
responsible for personal and/or product damage.
mWARNING! Use only approved replacement batteries;
other batteries may damage the cordless transfer pump and
cause it to malfunction, which can lead to serious personal
injury.
mWARNING! Do not use a battery pack or appliance that
is damaged or modied. Damaged or modied battery may
exhibit unpredictable behavior resulting in re, explosion or risk
of injury.
Do not modify or attempt to repair the appliance or the battery
pack except as indicated in the instructions for use and care.
Have your battery pack serviced by a qualied repair person
using only identical replacement parts. This will ensure that the
safety of the battery pack is maintained.
mCAUTION! To reduce the risk of injury, charge the 24V
iON+ lithium-ion battery pack only in the designated 24V iON+
lithium-ion charger. Other types of chargers present risk of re,
personal injury and damage. Do not wire the battery pack to
a power supply plug or car cigarette lighter. Such misuse will
permanently disable or damage the battery pack.
• Avoid dangerous environments – Do not charge the
battery pack in rain, snow or in damp or wet locations.
Do not use the battery pack or charger in the presence of
explosive atmospheres (gaseous fumes, dust or ammable
materials) because sparks may be generated when
connecting or disconnecting the battery pack, which could
lead to a re.
• Charge in a well-ventilated area – Do not block the
charger vents. Keep them clear to allow for proper
ventilation. Do not allow smoking or open ames near a
charging battery pack. Vented gases may explode.
NOTE: The safe temperature range for the battery is 41°F –
105ºF (5°C – 40.5°C). Do not charge the battery outside in
freezing weather; charge it at room temperature.
• Maintain charger cord – When unplugging the charger, pull
the plug, not the cord, from the receptacle to reduce the
risk of damage to the electrical plug and cord. Never carry
the charger by its cord or yank it by the cord to disconnect
it from the receptacle. Keep the cord away from heat, oil
and sharp edges. Make sure the cord will not be stepped
on, tripped over or subjected to damage or stress when the
charger is in use. Do not use the charger with a damaged
cord or plug. Replace a damaged charger immediately.
• Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly
wired extension cord poses a risk of re and electric shock.
If an extension cord must be used, plug the charger into a
properly wired 16 gauge or larger extension cord with the
female plug matching the male plug on the charger. Make
sure that the extension cord is in good electrical condition.

4
• Use only recommended attachments – Use of an
attachment not recommended or sold by the battery
charger or battery pack manufacturer may result in risk of
re, electric shock or personal injury.
• Unplug charger when not in use – Make sure to
disconnect battery pack from unplugged charger.
mWARNING! To reduce the risk of electric shock,
always unplug the charger before performing any cleaning
or maintenance. Do not allow water to ow into the charger.
Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock
hazards.
• Do not burn or incinerate battery pack – Battery pack
may explode, causing personal injury or damage. Toxic
fumes and materials are created when the battery pack is
burned.
• Do not crush, drop or damage battery pack – Do not use
the battery pack or charger if they have sustained a sharp
blow, been dropped, run over or have been damaged in any
way (i.e. pierced with a nail, hit with a hammer, stepped on,
etc.).
• Do not disassemble – Incorrect reassembly may pose
a serious risk of electric shock, re or exposure to toxic
battery chemicals. If the battery or charger are damaged,
contact an authorized Snow Joe®+ Sun Joe®dealer or
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
• Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes or mouth.
If a damaged battery pack leaks battery chemicals, use
rubber or neoprene gloves to safely dispose of it. If skin
is exposed to battery uids, wash the aected area with
soap and water and rinse with vinegar. If eyes are exposed
to battery chemicals, immediately ush with water for 20
minutes and seek medical attention. Remove and dispose
of contaminated clothing.
• Do not short circuit – A battery pack will short circuit if
a metal object makes a connection between the positive
and negative contacts on the battery pack. Do not place a
battery pack near anything that may cause a short circuit,
such as paper clips, coins, keys, screws, nails and other
metallic objects. A short-circuited battery pack poses a risk
of re and severe personal injury.
• Store your battery pack and charger in a cool, dry
place – Do not store the battery pack or charger where
temperatures may exceed 105ºF (40.5ºC), such as in direct
sunlight or inside a vehicle or metal building during the
summer.
Information about the battery
1. For optimum battery performance, avoid low discharge
cycles by charging the battery pack frequently.
2. Store the battery pack in a cool place, ideally at 77°F
(25°C) and charged to at least 40%.
3. Lithium-ion batteries are subject to a natural aging
process. The battery pack must be replaced at the latest
when their capacity falls to just 80% of its capacity when
new. Weakened cells in an aged battery pack are no
longer capable of meeting the high power requirements
needed for the proper operation of your cordless transfer
pump, and therefore pose a safety risk.
4. Do not throw the battery pack into an open re as this
poses a risk of explosion.
5. Do not ignite the battery pack or expose it to re.
6. Do not exhaustively discharge the battery. Exhaustive
discharge will damage the battery cells. The most
common cause of exhaustive discharge is lengthy storage
or non-use of partially discharged battery. Stop working as
soon as the performance of the battery fall noticeably or
the electronic protection system triggers. Place the battery
pack in storage only after it has been fully charged.
7. Protect the battery and the tool from overloads. Overloads
will quickly result in overheating and cell damage inside
the battery housing even if this overheating is not apparent
externally.
8. Avoid damage and shocks. Immediately replace the
battery that has been dropped from a height of more
than one meter or has been exposed to violent shocks,
even if the housing of the battery pack appears to be
undamaged. The battery cells inside the battery may have
suered serious damage. In such instances, please read
the waste disposal information for proper battery disposal.
9. If the battery pack suers overloading and overheating,
the integrated protective cuto will switch o the
equipment for safety reasons.
IMPORTANT! Do not press the ON/OFF switch any more
if the protective cut-o has been activated. This may
damage the battery pack.
10. Use only original battery pack. The use of other batteries
poses a re risk and may result in injuries or an explosion.

5
Information about the charger and the
charging process
1. Please check the data marked on the rating plate of the
battery charger. Be sure to connect the battery charger
to a power supply with the voltage marked on the rating
plate. Never connect it to a dierent mains voltage.
2. Protect the battery charger and its cord from damage.
Keep the charger and its cord away from heat, oil and
sharp edges. Have damaged cords repaired without delay
by a qualied technician at an authorized Snow Joe®+
Sun Joe®dealer or call the Snow Joe®+ Sun Joe®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
3. Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
grounded appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
4. Keep the battery charger, battery pack and the cordless
tool out of the reach of children.
5. During periods of heavy use, the battery pack will become
warm. Allow the battery pack to cool to room temperature
before recharging.
6. Do not overcharge the battery. Do not exceed the
maximum charging times. These charging times only apply
to discharged batteries. Frequent connection of a charged
or partially charged battery pack will result in overcharging
and cell damage. Do not leave the battery connected with
the charger for days on end.
7. Never use or charge battery if you suspect that it has
been more than 12 months since the last time they were
charged. There is a high probability that the battery pack
has already suered dangerous damage (exhaustive
discharge).
8. Charging the battery at a temperature below 41°F (5°C)
will cause chemical damage to the cells and may cause a
re.
9. Do not use batteries that have been exposed to heat
during the charging process, as the battery cells may have
suered dangerous damage.
10. Do not use the battery if it suered curvature or
deformation during the charging process or exhibit other
atypical symptoms (gassing, hissing, cracking, etc.).
11. Never fully discharge the battery pack (maximum
recommended depth of discharge is 80%). A complete
discharge of the battery pack will lead to premature aging
of the battery cells.
Protection from environmental inuences
1. Wear suitable work clothes. Wear safety goggles.
2. Protect your cordless tool and the battery charger
from moisture and rain – Moisture and rain can cause
dangerous cell damage.
3. Do not use the cordless tool or the battery charger near
vapors and ammable liquids.
4. Use the battery charger and cordless tools only in dry
conditions and at an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C).
5. Do not keep the battery charger in places where the
temperature is liable to reach over 105°F (40.5°C). In
particular, do not leave the battery charger in a car that is
parked in the sunshine.
6. Protect batteries from overheating. Overloads,
overcharging and exposure to direct sunlight will result
in overheating and cell damage. Never charge or work
with batteries that have been overheated – replace them
immediately, if possible.
7. Store the charger and your cordless tool only in dry
locations with an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C). Store your lithium-ion battery packs in a
cool, dry place at a temperature of 77°F (25°C). Protect
the battery pack, charger and cordless tool from humidity
and direct sunlight. Only place fully charged batteries in
storage (charged to at least 40%).
8. Prevent the lithium-ion battery pack from freezing. Battery
packs that were stored below 32°F (0°C) for more than
60 minutes must be discarded.
9. When handling the battery, be wary of electrostatic
charge. Electrostatic discharges can damage the
electronic protection system and the battery cells. Avoid
electrostatic charging and never touch the battery poles.

6
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
READ THE OPERATOR'S
MANUAL(S) – Read, understand,
and follow all instructions in the
user manual(s) before attempting
to assemble and operate.
SAFETY ALERT – Indicates a
precaution, a warning, or a danger.
WARNING! Do not expose the
unit to rain or wet conditions.
Keep dry.
WARNING! Electrical shock hazard.
Symbols SymbolsDescriptions Descriptions
Store indoors. Never store the transfer pump outdoors.
If the pump freezes, permanent damage may result.

7
Know Your Cordless Transfer Pump
Read the owner’s manual and safety instructions carefully before operating the cordless transfer pump. Compare the illustration
below to the cordless transfer pump in order to familiarize yourself with the location of the various controls and adjustments.
Save this manual for future reference.
1. Battery compartment cover
2. Battery compartment
3. Motor housing
4. Base
5. Oil bottle
6. Puddle strainer
7. Intake hose
8. Impeller cover plate
9. Water inlet
10. Water outlet
11. Flow direction indicator
12. Handle
13. LED indicator
14. On/O switch
1
2
3
4 5
10
13
12
67
8
9
11
14
SOLD SEPARATELY Battery + Charger options available at sunjoe.com
24VBAT
24VBAT-LTE 24VBAT-LT 24VBAT-XR 24VCHRG-QC 24VCHRG-DPC
24VBAT-LTW 24VBAT-LTX

8
Technical Data
Battery Voltage*......................................................... 24 V D.C.
Battery Capacity .............................................. See page 15 for
battery options and specications
Battery Run Time Max ..................................... See page 15 for
battery options and specications
Charger Input ................................................... See page 15 for
battery options and specications
Charger Output ................................................ See page 15 for
battery options and specications
Charge Time Max ............................................ See page 15 for
battery options and specications
Motor ............................................................................... 150 W
Max Water Inlet Temperature ................................ 104ºF/40ºC
Intake Hose Length .............................................. 5.9 ft (1.8 m)
Max Flow Rate ........................................................... 330 GPH
Max Head Height ................................................ 52 ft (15.8 m)
Max Suction Lift ........................................................ 13 ft (4 m)
Fittings ............................................................... 3/4" GHT male
Enclosure ........................................................................ Type 2
Weight ................................................................. 4 lbs (1.9 kg)
* Initial no-load voltage, when fully charged, peaks at 24 volts; nominal voltage
under typical load is 21.6 volts.
Unpacking
Carton Contents
• Cordless transfer pump
• Puddle strainer
• Intake hose
• Oil bottle
• M5 tapping screws (4)
• Manuals with registration card
NOTE: In order to operate this cordless transfer pump you will
need iON+ 24V System batteries and chargers. See page 15
for battery options and specications, or visit sunjoe.com.
1. Carefully remove the transfer pump and check to see that
all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new cordless
transfer pump. The packaging is made of recyclable
materials. Properly dispose of these materials in
accordance with local regulations.
IMPORTANT! The equipment and packaging material are not
toys. Do not let children play with plastic bags, foils, or small
parts. These items can be swallowed and pose a suocation
risk!
mWARNING! Do not insert battery until assembly is
complete. Failure to comply could result in accidental starting
and possible serious personal injury.
Battery Pack Operation
The equipment is powered by a lithium-ion battery. The battery
pack is completely sealed and maintenance free.
Battery Charge Level Indicator
The battery pack is equipped with a push button for checking
the charge level. Simply press the push button to read o the
battery charge level from the LEDs of the battery indicator:
• All 3 level monitoring LEDs are lit: Battery charge level
is high.
• 2 level monitoring LEDs are lit: Battery charge level is
decreasing. Stop work as soon as possible.
• 1 level monitoring LED is lit: Battery is at. Stop work
IMMEDIATELY and charge the battery. Otherwise the
battery’s service life will be greatly shortened.
NOTE: If the charge level button does not appear to be
working, connect to the charger and charge as needed.
In order to operate this cordless transfer pump you will need
a iON+ 24V System battery and charger. See page 15 for
battery and charger options and specications, or for more
information visit sunjoe.com.
TOOL ONLY
BATTERY + CHARGER SOLD SEPARATELY
Charge level button
The battery is at 30% capacity
and requires charging
The battery is at 60% capacity
and requires charging soon
The battery is at full capacity
Light IndicatorsLights

9
NOTE: Immediately after using the battery pack, the charge
level button may display a lower charge than it will if checked
a few minutes later. The battery cells “recover” some of their
charge after resting.
Charger Operation
mWARNING! Charge only 24V iON+ lithium-ion battery
pack with its compatible 24V iON+ lithium-ion charger. Other
types of batteries may cause personal injury and damage.
To reduce the risk of electric shock, do not allow water to ow
into the charger's AC/DC plug.
When to Charge the iON+ 24V Lithium-
iON Battery
NOTE: The iON+ 24V lithium-iON battery pack does not
develop a "memory" when charged after only a partial
discharge. Therefore, it is not necessary to run down the
battery pack before inserting the charger plug.
• Use the battery indicator lights to determine when to charge
your iON+ 24V lithium-iON battery pack.
• You can "top-o" your battery pack's charge before starting
a big job or after a long day of use.
Charging the Battery
1. Open the battery compartment cover, and push the push
lock buttons on the battery to pull the battery pack out
from the battery compartment (Fig. 1).
2. Depending on your Snow Joe®+ Sun Joe®charger
model, how to recharge your lithium-ion batteries will
vary. You may either insert your 24-volt batteries into the
24VCHRG-QC Quick Charger (sold separately) or the
24VCHRG-DPC Dual Port Charger (sold separately)
(Figs. 2 – 3).
3. The battery indicator LEDs will illuminate one by one
during the charging process. Unplug the charger
immediately when the 3 LEDs are all illuminated.
4. The 24VCHRG-QC Quick Charger (sold separately) and
the 24VCHRG-DPC Dual Port Charger (sold separately)
are also equipped with additional charging indicating
lights which will indicate the charging status (Figs. 2 – 3).
mCAUTION! FIRE HAZARD. When disconnecting the
charger from the battery, be sure to unplug the charger from
the outlet rst, then disconnect the charger from the battery.
mWARNING! This charger does not automatically
turn o when the battery is fully charged. Please take care
In order to operate this cordless transfer pump you will need
a iON+ 24V System battery and charger. See page 15 for
battery and charger options and specications, or for more
information visit sunjoe.com.
TOOL ONLY
BATTERY + CHARGER SOLD SEPARATELY
Fig. 1
Battery
compartment
cover Battery pack
Push lock
button
Fig. 2 Battery pack
24VCHRG-QC
quick charger
(Sold separately)
red
Charging
green
Fully
Charged
Fig. 3 Battery pack
24VCHRG-DPC
dual port charger
(Sold separately)
red
Charging
green
Fully
Charged

10
not to leave the battery plugged into the charger. Switch
o or unplug the charger at the mains when charging is
complete.
5. Timely recharging of the battery will help prolong the
battery's life. You must recharge the battery pack when
you notice a drop in the equipment's power.
IMPORTANT! Never allow the battery pack to become fully
discharged as this will cause irreversible damage to the
battery.
6. When charging is complete, remove the battery from the
charger by pulling the push lock buttons and sliding the
battery backward to unlock it from the charger.
Assembly
mWARNING! Do not insert the battery before the unit is
fully connected with hoses and ready for use.
1. The equipment comes fully assembled. If needed, fasten
it securely to a suitable surface (e.g., a work-bench) in a
suitable place (protected against dust, dry, well-lit) with
the 4 provided M5 tapping screws (Fig. 4). Otherwise,
place the pump on a level, dry surface securely.
2. Connect a discharge hose onto the water outlet. It's
recommended to use a garden hose with standard 3/4"
GHT female connector. Thread to secure (Fig. 5).
3. Add two drops of oil into the water inlet before and after
each use (Fig. 6).
4. Connect the female end of the included intake hose onto
the water inlet. Thread to secure (Fig. 7).
Fig. 4
Base Screws
Fig. 5
Discharge hose/Garden hose
Standard 3/4" GHT
female connector
Water outlet
Fig. 6
Oil bottle
Water inlet
Fig. 7
Intake hose
Water inlet

11
NOTE: Make sure hose connections are tight before
switching on the pump. Leaking connection will greatly
reduce the suction power and the eciency of the pump.
mWARNING! Keep water discharge pointed away from all
electrical devices to reduce the risk of electrocution or electric
shock.
Operation
mWARNING! This transfer pump should only be used
to pump clear water. Do NOT pump salt water, brine, laundry
discharge, or any other application which may contain caustic
chemicals and/or foreign material. Do NOT pump sand
particulate, or large debris. Do NOT pump uids such as
gasoline, fuel oil, or kerosene. Do NOT use in a ammable or
explosive atmosphere.
mWARNING! Do not place pump under water or in wet
areas. Place pump in dry locations only.
Starting/Stopping the Transfer Pump
1. Lay out the intake hose and the discharge hose to make
sure there's no blockage, kinks or bends.
2. Drop the other end of the intake hose into the water
needing to be transferred, aiming as close to the center of
the water source as possible.
3. Secure the discharge hose and make sure it will not whip
around or move unexpectedly when pumping begins.
4. With the two hoses connected and secured, open the
battery compartment cover and insert the battery until it
clicks in place. Close the battery compartment cover
(Fig. 8).
5. Press the On/O switch on the ON(I) side to start the
machine (Fig. 9). The LED indicator will turn red when the
pump is on.
NOTE: The LED indicator is used to indicate the working
status of the pump. When the LED is lit red, the pump is
working properly. When the LED is ashing, it indicates
the pump is overheating. Shut o the pump and let it
cool down before restarting. The pump is also equipped
with overheating protection, which will turn o the unit
automatically when the pump is running dry.
NOTE: A pump running dry may cause overheating. If the
overheating is caused by the pump running dry, make sure
the intake hose is positioned properly in the water.
6. To turn o the pump, press the O (O) side of the On/
O switch (Fig. 9). Remove the battery from the battery
department.
Operating Tips
This product is designed for draining or removing water
from ooded areas, clogged sinks, water basins, etc. During
operation, pay attention to the following:
1. Keep the water inlet clean and clear of all foreign objects.
Inspect the water inlet every time before operation.
2. When the water needing to be transferred contains large
particles, or is too shallow to be sucked by the intake
hose, use the equipped puddle strainer. Simply connect
it with the male end of the intake hose, twist to secure,
and place the strainer in the center of the water to be
transferred (Fig. 10).
In order to operate this cordless transfer pump you will need
a iON+ 24V System battery and charger. See page 15 for
battery and charger options and specications, or for more
information visit sunjoe.com.
TOOL ONLY
BATTERY + CHARGER SOLD SEPARATELY
Fig. 8
Battery
pack
Battery
compartment
cover
Fig. 9 On (I)
On/O switch
O (O)
LED indicator

12
3. As soon as the pump starts to take in air, turn o the
pump.
NOTE: DO NOT allow the pump to run dry. Damage to the
pump may occur.
4. For best results, the pump should not be placed more
than 18 ft. above the inlet source.
5. During operation, do not block the air vents. This will
cause overheating.
6. Do not run the pump continuously for more than 1 hour.
7. When job is done, turn o the pump and remove the
battery. Disconnect the intake hose and discharge hose.
Make sure no water remains in the hoses before storage.
Maintenance
Please contact an authorized Snow Joe®+ Sun Joe®dealer
or call the Snow Joe®+ Sun Joe®customer service center
at 1-866-SNOWJOE (1-866-766-9563) for all maintenance
operations not foreseen in this manual. Any operation
performed in an unauthorized service center or by unqualied
personnel will completely invalidate the warranty.
mCAUTION! To reduce the risk of injury, always remove
battery pack before attempting to install, service, or maintain
the pump. Never disassemble the pump, battery pack or
charger.
General Maintenance
1. Frequently inspect the pump for issues such as abnormal
noise, misalignment or binding of moving parts, breakage
of parts, or any other condition that may aect the tool
operation. Contact your Snow Joe®+ Sun Joe®dealer or
the Snow Joe®+ Sun Joe®customer service center for
ALL repairs.
2. Clean dust and debris from vents. Keep handles clean, dry
and free of oil or grease. Only use a dry cloth to clean the
housing, since certain cleaning agents and solvents are
harmful to plastics and other insulated parts. Never use
ammable or combustible solvents around tools.
mWARNING! To reduce the risk of personal injury and
damage, never immerse your tool, battery pack or charger in
liquid or allow a liquid to ow inside them.
Replace the Impeller and O-Ring
IMPORTANT: Only use original replacement lters specied for
this pump.
You can purchase replacement impeller
(Model 24V-XFP5-IMP), O-ring (Model 24V-XFP5-ORING)
and other genuine replacement parts by visiting us online at
sunjoe.com or calling our toll-free customer service helpline at
1-866-SNOWJOE (1-866-766-9563). The use of accessories/
parts that do not meet the original equipment specications
may lead to improper performance of the pump, may
compromise operator safety and will void the manufacturer's
warranty.
1. Switch o the pump, remove the battery from the battery
compartment, and disconnect all hoses.
2. Using a screwdriver, remove the 5 screws that used to x
the impeller cover plate (Fig. 11).
3. Remove the worn impeller and O-ring (Fig. 12).
4. Replace with the new impeller and O-ring. When
assembling the impeller, make sure to align the axle with
the middle hole of the impeller, and push the impeller into
the pump as far as it will go.
Fig. 10
Puddle strainer
Intake hose
Fig. 11
Impeller cover
plate
Screws
Fig. 12
Impeller
O-ring

13
5. Make sure the O-ring is properly seated and replace
impeller cover plate. Secure with the original 5 screws.
6. Secure the hoses and insert the battery, turn on the pump
to make sure there's no leaking from the impeller cover
plate.
Proper Care for Battery + Charger
mWARNING! To reduce the risk of injury, always unplug
the charger and disconnect the battery pack from the charger
before performing any maintenance task. Never disassemble
the battery pack or charger. Contact your Snow Joe®+
Sun Joe®dealer or the Snow Joe®+ Sun Joe®customer
service center for ALL repairs.
1. To reduce the risk of injury and damage, never immerse
your battery pack or charger in liquid or allow any liquid to
ow inside these components.
2. Clean out dust and debris from charger vents and
electrical contacts by blowing with compressed air.
3. Use only a soft, clean and dry brush to clean the battery
pack and charger, keeping away from all electrical
contacts. Certain cleaning agents and solvents are
harmful to plastics and other insulated parts. Some of
these include gasoline, turpentine, lacquer thinner, paint
thinner, chlorinated cleaning solvents, ammonia and
household detergents containing ammonia. Never use
ammable or combustible solvents around battery packs,
battery chargers or tools.
4. The iON+ lithium-ion battery chargers have no serviceable
parts.
Storage
Store the pump indoors in a dry, locked-up place out of
the reach of children, with the battery pack disconnected.
Disconnect and drain all hoses. Keep away from corrosive
agents such as garden chemicals and de-icing salt.
Battery + Charger O-Season Storage
1. Do not expose your battery pack or charger to water,
rain or allow them to get wet. This could permanently
damage the charger and the battery pack. Do not use oil
or solvents to clean or lubricate your battery pack as the
plastic casing can become brittle and crack, causing a
serious risk of injury.
2. Store the battery pack and charger at room temperature
away from moisture. Do not store in damp locations where
corrosion of terminals may occur. As with other battery
pack types, permanent capacity loss can result if the pack
is stored for long periods of time at high temperatures
(over 120ºF/49ºC).
3. iON+ 24Vlithium-ion battery packs maintain their charge
during storage longer than other battery pack types.
As a general practice, it is best to unplug the battery
charger and disconnect the battery pack when they are
not in use. Recharge the battery pack every 6 months to
50% capacity (2 lights on) during o-season storage to
maintain optimal battery performance.
Recycling + Disposal
The product comes in a package that protects it against
damage during shipping. Keep the package until you are sure
that all parts have been delivered and the product is functioning
properly. Recycle the package afterwards or keep it for long-
term storage.
WEEE symbol. Waste electrical products should not
be disposed of with household waste. Please recycle
where facilities exist. Check with your local authority
or local store for recycling regulations.
Battery Caution + Disposal
Always dispose of your battery pack according to federal,
state, and local regulations. Contact a recycling agency in your
area for recycling locations.
mCAUTION! Even discharged battery packs contain
some energy. Before disposing, use electrical tape to cover
the terminals to prevent the battery pack from shorting, which
could cause a re or explosion.
mWARNING! To reduce the risk of injury or explosion,
never burn or incinerate a battery pack even if it is damaged,
dead or completely discharged. When burned, toxic fumes and
materials are emitted into the surrounding atmosphere.
1. Batteries vary according to device. Consult your manual
for specic information.
2. Install only new batteries of the same type in your product
(where applicable).
3. Failure to insert batteries in the correct polarity, as
indicated in the battery compartment or manual, may
shorten the life of the batteries or cause batteries to leak.
4. Do not mix old and new batteries.
5. Do not mix Alkaline, Standard (Carbon-Zinc) or
Rechargeable (Nickel Cadmium, Nickel Metal Hydride,
or Lithium-Ion) batteries.
6. Do not dispose of batteries in re.
7. Batteries should be recycled or disposed of as per state
and local guidelines.

14
Service + Support
If your Sun Joe® 24V-XFP5-CT cordless water transfer pump
requires service or maintenance, please call the Snow Joe®+
Sun Joe® customer service center at 1-866-SNOWJOE
(1-866-766-9563).
Model + Serial Numbers
When contacting the company, reordering parts, or arranging
service from an authorized dealer, you will need to provide the
model and serial numbers, which can be found on the decal
located on the housing of the unit. Copy these numbers into
the space provided below.
Record the following numbers from the housing or handle of your
new product:
2 4 V - X F P 5 - C T
Model #:
Serial #:

15
Optional Accessories
mWARNING! ALWAYS use only authorized Snow Joe®+ Sun Joe® replacement parts and accessories. NEVER use
replacement parts or accessories that are not intended for use with this electric pressure washer. Contact Snow Joe®+ Sun Joe®
if you are unsure whether it is safe to use a particular replacement part or accessory with your pressure washer. The use of any
other attachment or accessory can be dangerous and could cause injury or mechanical damage.
24V iON+ Lithium-Ion Battery Quick Charger 24VCHRG-QC
ModelAccessories Item
1
2
3
4
5
24V iON+ 2.0 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-AC: 1 hr 20 min | 24VCHRG-QC: 55 min | 24VCHRG-DPC: 55 min
Battery Runtime Max: 20 min
24VBAT-LTE
24V iON+ 2.5 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-AC: 1 hr 40 min | 24VCHRG-QC: 1 hr 20 min | 24VCHRG-DPC: 1 hr 10 min
Battery Runtime Max: 25 min
24VBAT-LT
24V iON+ 4.0 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-AC: 3 hrs 30 min | 24VCHRG-QC: 1 hr 50 min | 24VCHRG-DPC: 1 hr 50 min
Battery Runtime Max: 40 min
24VBAT
24V iON+ 5.0 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-AC: 3 hrs 20 min | 24VCHRG-QC: 2 hr 20 min | 24VCHRG-DPC: 2 hr 30 min
Battery Runtime Max: 50 min
24VBAT-XR
6
24V iON+ Lithium-Ion Dual-port Battery Charger 24VCHRG-DPC
7
Replacement O-ring 24V-XFP5-ORING
8
Rubber Impeller 24V-XFP5-IMP
9
10
24V iON+ 1.3 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-AC: 50 min | 24VCHRG-QC: 35 min | 24VCHRG-DPC: 35 min
Battery Runtime Max: 13 min
24V iON+ 1.5 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-AC: 60 min | 24VCHRG-QC: 40 min | 24VCHRG-DPC: 40 min
Battery Runtime Max: 15 min
24VBAT-LTW
24VBAT-LTX

16
NOTES

17
NOTES

18
NOTES

19 R4_01282020
SNOW JOE®+ SUN JOE®CUSTOMER PROMISE
OUR WARRANTY:
Snow Joe warrants new, genuine, powered and non-powered Products to be free from defects in material or workmanship when used
for ordinary household use for a period of two years from the date of purchase by the original, end-user purchaser when purchased
from Snow Joe or from one of Snow Joe’s authorized sellers with proof of purchase. Because Snow Joe is unable to control the quality
of its Products sold by unauthorized sellers, unless otherwise prohibited by law, this Warranty does not cover Products purchased from
unauthorized sellers. If your Product does not work or there’s an issue with a specic part that is covered by the terms of this Warranty,
Snow Joe will elect to either (1) send you a free replacement part, (2) replace the Product with a new or comparable product at no
charge, or (3) repair the Product. How cool is that!
This Warranty gives you specific legal rights, and you may also have other rights which vary from State to State.
PRODUCT REGISTRATION:
Snow Joe strongly encourages you to register your Product. You can register online at snowjoe.com/register, or by printing and
mailing in a registration card available online from our website, or calling our Customer Service Department at 1-866-SNOWJOE
(1-866-766-9563), or by e-mailing us at [email protected]. Failure to register your Product will not diminish your warranty
rights. However, registering your Product will allow Snow Joe to better serve you with any of your customer service needs.
WHO CAN SEEK LIMITED WARRANTY COVERAGE:
This Warranty is extended by Snow Joe to the original purchaser and original owner of the Product.
WHAT IS NOT COVERED?
This Warranty does not apply if the Product has been used commercially or for non-household or rental applications. This Warranty also
does not apply if the Product was purchased from an unauthorized seller. This Warranty also does not cover cosmetic changes that do
not aect performance. Wearing parts like belts, augers, chains and tines are not covered under this Warranty, and can be purchased
at snowjoe.com or by calling 1-866-SNOWJOE (1-866-766-9563).
ABOVE ALL ELSE, Snow Joe, LLC (“Snow Joe”) is dedicated to you, our customer. We strive to make your experience as pleasant as
possible. Unfortunately, there are times when a Snow Joe®, Sun Joe®, or Aqua Joe® product (“Product”) does not work or breaks under
normal operating conditions. We think it’s important that you know what you can expect from us. That’s why we have a Limited Warranty
(“Warranty”) for our Products.

sunjoe.com
