SunStar C4P14CF User manual

Copyright © C4P Inc. 2016
www.c4pinc.com
NOTE: Read this manual carefully before operating the appliance.
Do not dispose and keep manual safe.
USER MANUAL :
14cu. . Chest Freezer
Model: C4P14CF

NORTH AMERICAN TOLL FREE : 1 (855) 230 - 4008 NORTH AMERICAN TOLL FREE : 1 (855) 230 - 4008

Table of Contents
Dear Customer: Please follow the user manual in order to achieve
the optimal performance for the lifetime of your machine.
TOPIC DESCRIPTION PAGE
NUMBER
1 What’s in the box 1
2 External Appearance 1
3 Major Technical Parameters 2
4 Transport and Storage 3
5 Startup and Temperature Regulations 4 - 5
6 Safety and Precautions 5
7 Cable Requirements 6
8 Circuit Diagram 6
9 General Issues and Troubleshooting 7 - 8
10 Notices and Routine Maintenance 9
11 Contact Information 10
NORTH AMERICAN TOLL FREE : 1 (855) 230 - 4008 NORTH AMERICAN TOLL FREE : 1 (855) 230 - 4008

CONTACT INFORMATION
PHONE : (905) 230 - 4008
NORTH AMERICAN TOLL FREE : 1 (855) 230 - 4008
FAX : (905) 230 - 6010
What’s in the box
is SunStar Appliance should come with everything on the list
below. Please contact the number on page 10 of the manual if
something is missing.
Item Number Description Quantity
1 Freezer 1
2 User Manual 1
3 Warranty Registration Card 1
4 Suspending Basket 1
5 Cabinet Divider 1
EXTERNAL APPEARANCE
NORTH AMERICAN TOLL FREE : 1 (855) 230 - 4008 NORTH AMERICAN TOLL FREE : 1 (855) 230 - 4008

MAJOR TECHNICAL
PARAMETERS
Product Model Power Available Capacity
C4P14CF DC 12V/24V 400L
14 cu/Ft
Operating Input Power Consumption
Temperature Power 24 hour cycle
-15°C ~ -22°C 95W 1.1kWh / 91.67Ah
5°F ~ 7.6°F
Refrigerant Net Weight Exterior Dimensions
R-134a Amount
190g 85kg 136cm x 80.6cm x 96.6cm
0.42 lbs 187.42 lbs 53.5in x 31.7in x 38in
NOTICES & ROUTINE
MAINTENANCE
1) After transportation, let the unit sit upright and undisturbed
for at least 1 hour. If the unit has been put beyond the 45°
angle from upright at any point, then let the appliance sit for
a minimum of 2 hours prior to operation. Let the appliance
operate for 2 hours prior to food storage
2) DO NOT turn the unit on within 5 minutes after a sudden power
failure or disconnect. Wait at least 10 minutes to 30 minutes prior to
powering the unit up again.
3) Food should be stored with some separation to allow cold air to
circulate better and for the appliance to operate more efficiently.
4) It is recommended that the temperature of the food to be stored
in the unit should not be warmer than the ambient temperature of
the room.
5) Acids, alkaline, corrosive substances, volatile, or inflammable
materials MUST NOT be stored in case of damage to the cabinet of
the unit. Any resulting damage as a result of improper storage is not
covered by the manufacturer
6) How to clean your SunStar appliance:
a) Set your appliance to the off position and disconnect from power
source
b) Wipe down the interior walls with a soft cloth dipped in a
neutral detergent.
c) Dry the interior of the unit with a clean cloth.
d)The exterior of the unit can be wiped with a damp cloth. Do not
use harsh chemicals.
7) Seasonally wipe off any dust that has accumulated on the
condenser, fan, and compressor.
NORTH AMERICAN TOLL FREE : 1 (855) 230 - 4008 NORTH AMERICAN TOLL FREE : 1 (855) 230 - 4008

TRANSPORT AND STORAGE
1) When loading and unloading the unit, the angle of
inclination should not exceed more than 45° in any direction
while loading or transportation. Please try to keep the unit
steady when in transit.
(See Figure 1).
2)e unit should be placed away from direct exposure to
sunlight. is unit should be placed in a well-ventilated,
dry, and cool environment.
(See Figure 2).
3) Aer unpacking and removing all packaging materials
please ensure that the appliance has a minimum of 6”
inches of clearance from every side.
(See Figure 3).
FIGURE 3
FIGURE 1
FIGURE 2
Troubleshoot Chart
NORTH AMERICAN TOLL FREE : 1 (855) 230 - 4008 NORTH AMERICAN TOLL FREE : 1 (855) 230 - 4008
Error indicators and / or non-operation of the compressor e compressor is running abnormally or with unusual noise e successive automatic shut-o of the compressor several minutes aer start up e storage temperature rises while the compressor is running properly Abnormal noise is being produced
1. loose contact 2. loose cables
e supply voltage is 85% lower than the rated value e supply voltage is 110% higher than the rated value
1. Frequent opening of the doors 2. e cabinet is overloaded with tightly packed food 3. Excessive frost accumulation 4. Door leakage 5. Gasket failure
1. Try to open doors less frequently 2. Arrange the food orderly with enough space for smooth air circulation 3. Take out frozen food and remove the frost. 4. Adjust the door sealing
1. e unit is not leveled 2. Loose fastening parts 3. Unwanted contact between pipes
1. Switch the unit o immediately until the recovery of the voltage supply is normal. A voltage regulator with an input power ve (5) times larger is required if the voltage uctuation exceeds specications 2. Check the input voltage on the module and power supply battery if it is out of operating voltage 3. Check the cable length between the battery and module. Please refer to "Cable Requirements" on page 7 of the User Manual
1. Ensure contact points are secure 2. Ensure contact points are secure
1. Adjust the unit to a stable and leveled oor 2. Tighten loose parts 3. Keep the parts away from each other
Problem Cause Solution

START UP & TEMPERATURE
REGULATIONS
1) START UP
a) Turning the power on, the red indicating light on the
temperature control panel will light up (See Figure 4 on
page 5), and the compressor will start up. e machine
will begin to refrigerate/freeze.
b) e protection signal of the controller is a green
indicating light. It will ash a number of times if error
occurs. Count the number of ashes and compare with
the chart below:
(e module will operate at higher than desired temperatures if
the unit system has been overloaded or if the ambient temperature
is higher than 55°C/131°F. To ensure the longevity of the appliance,
please ensure that the unit is not overloaded and stored in an
environment where the ambient temperature is lower than
55°C/131°F)
c) The unit will not run if there is an error in connecting the
anode (positive) and cathode (negative) voltage connectors.
2) TEMPERATURE REGULATIONS
The temperature will gradually drop when the knob of the thermostat
is turned clockwise and will gradually gain when the knob is turned
counter-clockwise. For the longevity of the appliance, it is not
recommended to leave the temperature dial at the coldest setting for
prolonged use.
GENERAL ISSUES &
TROUBLESHOOTING
1) In case of an abnormal operation, please refer to the
Troubleshooting chart shown on page 8 for
inspection and possible solutions. If the issue cannot
be solved, please contact the service department of our
company or our local institutions with special
engagement.
The following are NOT results of faulty equipment:
1) The condenser in the corresponding internal wall will
make the external condenser feel hotter than normal.
2) e intermitting noises heard in the cabinet during the
operation of the unit aer the compressor shuts down is
caused by the circulating ow of coolant in the
condensing pipes.
3) e surface temperature of the compressor may rise to a
range between 70°C/150°F and 90°C/194°F.
4) The condensed water beads on the external side of the
unit or door during the rainy seasons will not affect the
operation of the unit. The water beads may be wiped off
with a dry cloth.
NORTH AMERICAN TOLL FREE : 1 (855) 230 - 4008 NORTH AMERICAN TOLL FREE : 1 (855) 230 - 4008
Number of ashes Error / Issue

FIGURE 4
SAFETY PRECAUTIONS
1) Use an independent 12V/24V DC outlet with a capacity of no
less than 12A. e appliance does not require grounding.
2) If the unit is to be stored or le unused for prolonged periods,
please ensure that the unit is turned o and disconnected
from the power source. When reconnecting, please ensure that
connectors and power source is working order.
3) Do not immediately switch the freezer on and o it may result
in damage to the compressor module. Please ensure that the unit
remains in the o position for a minimum of 10 minutes prior to
turning the freezer back on.
4) The appliance is a native 12/24v chest freezer. Never directly
connect the appliance to a AC power source as it will cause
permanent damage to the hardware.
5) The supplier is not responsible for any damages or losses as a
direct result of failing to comply with the safety and standards
outlined in this manual. The supplier is also not responsible for
any accidents or damages as a result of an act of God.
CABLE REQUIREMENTS
To ensure the correct start and operating conditions for the unit,
the following cable dimensions must be observed:
Cross-section (mm2) Max. Length between battery
and compressor module (m)
12V/DC 24V/DC
2.5 (10 AWG) 2.5 5
4 (6 AWG) 4 8
6 (2.5 AWG) 6 12
10 (3/0 AWG) 10 20
CIRCUIT DIAGRAM
