SWF EMBROIDERY MACHINE
How to Replace the Presser Foot Pressure Spring
1 Remove the thread 3mm T-wrench,＋driver
tension adjusting plate
2 Remove the head face plate ＋driver,－driver
3 Replace the presser foot －driver(small)
pressure spring 2.5 T-wrench
4 Set the upper dead & manual knob, presser lower drop
lower drop point and foot height control point gauge
the presser foot height rubber (0.5t,1t) and presser
foot
5 Assemble the thread 3mm T-wrench,＋driver height gauge
tension adjusting plate
6 Assemble the head face plate ＋driver,－driver
1. Remove the Thread Tension Adjusting
Plate
Refer to Picture 1
1)Change the color at a position that the needle bar
to be replaced does not interfere with reciprocator.
(If the presser foot of #2 needle bar is replaced,
change the color with a needle bar other than #2)
2)Remove the thread tension adjusting plate.
2.Remove the Head Face Plate
1) Remove the head face plate (L) & (U).
Refer to Picture 1
[K] HEAD
A. Content
SWB-M-56
Order Tools Required
B. Order
C. Details
JIG /
Instruments
No.
CD CODE No:
Picture 1
Head Face
Plate(L)
Head Face
Plate(U) Head
─ Ver.2009 1st ────────────────────── SunStar Co., Ltd ─

SWF EMBROIDERY MACHINE
3.Replace the Presser Foot Pressure Spring
Refer to Picture 2
1) Use 2.5 T-wrench to remove the upper dead point
stopper and the needle bar holder.
2)Use "-" driver (small) to remove the needle bar
fixed holder. Refer to Picture 3
Needle Bar Fixed Holder
Picture 2
Picture 3
Picture 2-2
For Thick
Material
General
Type
Upper Dead
Point Stopper
Needle Bar
Holder
─ Ver.2009 1st ────────────────────── SunStar Co., Ltd ─

SWF EMBROIDERY MACHINE
3) As shown in Picture 4, lift the needle bar up and
replace presser foot pressure spring.
4.Set the Upper Dead Point/Lower Drop Point
and the Presser Foot Height
Refer to SWB-M-30
5.Assemble the Thread Tension Adjusting
Plate
1)Attach the disassembled thread tension
adjusting plate.
8.Assemble the Head Face Plate
1)Assemble the head face plate (L) & (U).
2)Assemble the thread guide (L).
Picture 4
