SunSynk 8K-SG04LP3 User guide

THREE-PHASE
HYBRID INVERTER
SUNSYNK 8K-SG04LP3 / SUNSYNK 10K-SG04LP3/
SUNSYNK 12K-SG04LP3
INSTALLER MANUAL
v.14 (05/03/22)
Global Tech China Ltd, 3 Floor, Wai Yip Industrial Building.
171 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong.
Tel: [phone] Fax: [phone]
www.sunsynk.com / [email protected]

Hybrid Inverter | Installer Manual
Australian Manual
For Australian market, a grid code must be selected before the inverter can operate. For compli-
ance with AS/NZS 4777.2:2020 please select from Australia A, Australia B, Australia C or New
Zealand. Please contact your local grid operator for which region to select.
This inverter complies with IEC 62109-2 clause 13.9 for earth fault alarm monitoring. If an Earth
Fault Alarm occurs, the fault code F24 will be displayed on the inverter screen /the LED indica-
tor fault will light up.
SUNSYNK 8K-SG04LP3
SUNSYNK 10K-SG04LP3
SUNSYNK 12K-SG04LP3
Importer
Sunsynk Australia Pty Ltd
230 Morrison Road, Midvale, WA 6056, Australia
[phone]
Website: www.sunsynk.com.au
Email: [email protected]
Manufacturer
Sunsynk Limited HK ( Part of Global Tech )
171 Wai Yip Street
Kwun Tong
Kowloon
Tel: [phone] Fax: [phone]
Website: http://www.sunsynk.com
E-mail: [email protected]

Hybrid Inverter | Installer Manual
PREFACE
This Installer Manual contains information needed for proper installation, operation, maintenance,
and care of the Sunsynk Three-Phase Hybrid Inverter. A deep understanding of the instructions
described in this document will help you get the most of your new inverter.
This document should be read thoroughly, and all the procedures described in this manual
should be followed carefully. If you have questions or concerns about the operation and mainte-
nance of this product, please contact our customer support.
All personnel involved in the installation, setup, operation, maintenance, and repair of this ma-
chine should read and understand this manual, mainly its safety instructions. Substandard per-
formance and longevity, property damage, and personal injury may result from not knowing and
following these instructions.
In order to ensure long product life, Sunsynk recommends that you utilize the product and
perform maintenance by correctly following the instructions described in this guide. The manu-
facturer’s warranty does not cover any damage resulting from the neglect of these instructions.
Sunsynk assumes no liability for damage caused by operation contrary to what is specified in
this operating manual.
All information in this User Guide is based on the latest product information available at the time
of printing approval. Sunsynk reserves the right to make changes at any time without notice and
without incurring any obligation.
Please always keep this manual together with the inverter as a reference to everyone who uses
this product.

Hybrid Inverter | Installer Manual
Table of Contents
1. SAFETY ........................................................................................................6
1.1. General Safety ............................................................................................................6
1.2. Symbols ......................................................................................................................6
1.3. Safety Instructions .....................................................................................................7
1.4. Disposal Remarks ......................................................................................................7
2. PRODUCT INTRODUCTION........................................................................8
2.1. System Overview........................................................................................................8
2.2. Product Size ...............................................................................................................9
2.3. Features ....................................................................................................................10
2.4. Basic System Architecture.......................................................................................11
3. TECHNICAL SPECIFICATIONS .................................................................12
4. INSTALLATION ...........................................................................................15
4.1. Parts List...................................................................................................................15
4.2. Selecting the Mounting Area ...................................................................................16
4.3. Mounting the Inverter...............................................................................................17
4.4. Battery Connection ..................................................................................................19
4.4.1. Function Ports Denition.....................................................................................20
4.4.2. Temperature Sensor Connection for Lead-Acid Battery.....................................21
4.5. Connecting the AC and Backup Load Connection.................................................22
4.6. Connecting the CT Coil ...........................................................................................25
4.6.1. System Connection for the CHNT Meter ............................................................26
4.6.2. System Connection for the Eastron Meter..........................................................26
4.7. Earth Connection (MANDATORY) ............................................................................27
4.8. PV Connection..........................................................................................................28
4.8.1. PV Module Selection...........................................................................................28
4.8.2. PV Module Wiring ...............................................................................................29
4.9. System Wiring for Inverter .......................................................................................31
4.10. Wiring Diagram.......................................................................................................32
4.11. Typical Application Diagram of Diesel Generator .................................................33
5. OPERATION ...............................................................................................34
5.1. Display ......................................................................................................................34
5.2. Switching ON/OFF....................................................................................................35
5.3. Home Page ...............................................................................................................35
5.4. Status Page ..............................................................................................................36
5.5. System Flow Page....................................................................................................37
5.6. Setup Page ...............................................................................................................38
5.7. Set Time (Clock) .......................................................................................................38
5.8. Set Company Name / Beeper / Auto dim................................................................39

Hybrid Inverter | Installer Manual
5.9. Factory Reset and Lock Code ................................................................................40
5.10. Battery Setup Page ................................................................................................41
5.11. Generator & Battery Page......................................................................................42
5.12. Battery Discharge Page .........................................................................................45
5.13. Setting Up a Lithium Battery..................................................................................47
5.13.1. Reactive Power Setting (QV).............................................................................51
5.13.2. Active Power Setting (QV).................................................................................51
5.14. Program Charge & Discharge Times .....................................................................52
5.15. Grid Supply Page ...................................................................................................55
5.16. Advanced Settings for Paralleling Inverters (UNDER DEVELOPMENT) ..............56
5.17. Solar Power Generated..........................................................................................57
5.18. Grid Power..............................................................................................................57
5.19. Advanced Settings for Auxiliary Load ...................................................................58
5.20. Advanced Settings for Peak Shaving....................................................................59
5.21. Connecting the DRM’s ...........................................................................................59
5.22. Fault Codes ............................................................................................................60
5.23. Operation Modes....................................................................................................64
5.23.1. MODE I: Basic...................................................................................................64
5.23.2. MODE II: With Generator ..................................................................................64
5.23.3. MODE III: With Smart-Load ..............................................................................65
5.23.4. MODE IV: AC Couple ........................................................................................65
6. COMMISSIONING......................................................................................66
6.1. Start-Up / Shutdown Procedure .............................................................................66
6.2. Information for Commissioning the Inverter ...........................................................67
6.3. GDFI Fault.................................................................................................................68
7. MAINTENANCE..........................................................................................68
APPENDIX A ...................................................................................................68
APPENDIX B ...................................................................................................69
APPENDIX C...................................................................................................69
APPENDIX D...................................................................................................70

1. SAFETY
This device should only be used in accordance o instructions within this manual and in
compliance with local, regional and national laws and regulations. Only allow this device
to be installed, operated, maintained, repaired by other persons who have also read and
understood this manual. Ensure the manual is included with this device should it be passed
to a third party.
DO NOT allow minors, untrained personnel, or person(s) suffering from a physical or mental
impairment that would affect their ability to follow this manual, install, maintain or repair this
device.
Any untrained personnel who might get near this device while it is in operation MUST be
informed that it is dangerous and instructed carefully on how to avoid injury.
Page | 6 Hybrid Inverter | Installer Manual
1.1. General Safety
This symbol indicates information that if ignored, could result in per-
sonal injury or even death due to incorrect handling.
This symbol indicates information that if ignored, could result in per-
sonal injury or physical damage due to incorrect handling.
Indicates information that is considered important, but not haz-
ard-related.
1.2. Symbols

1.3. Safety Instructions
Be sure to read this manual thoroughly before installation.
Do not attempt to install the inverter by yourself. Installation work must be carried out in
compliance with national wiring standards and by suitably qualified personnel only. Do not
turn on the power until all installation work is complete.
Do not disassemble the inverter. If you need repair or maintenance, contact a professional
service centre.
Always use an individual power supply line protected by a circuit breaker and operating on
all wires with a distance between contacts of at least 3mm for this unit.
The unit must be correctly grounded and the supply line must be equipped with a suitable
breaker and RCD to protect people.
Disconnect all wires/cables before performing any maintenance or cleaning to reduce the
risk of electrical shock.
The unit is not explosion-proof, so it should not be installed in an explosive atmosphere.¬
Never touch electrical components immediately after the power supply has been turned off
since the system can still have residual energy, so electric shock may occur. Therefore, after
turning off the power, always wait 5 minutes before touching electrical components.
This unit contains no user-serviceable parts. Always consult an authorised contractor for
repairs.
HIGH LIFE RISK DUE TO FIRE OR ELECTROCUTION.
The Sunsynk Single-Phase Hybrid Inverter can only be installed by a qualified li-
censed electrical contractor. This is not a DIY product.
1.4. Disposal Remarks
DO NOT dispose this product with domestic waste!
Electrical devices should be disposed of in accordance with regional directives on electronic
and/ or electronic-waste disposal. In case of further questions, please consult your supplier. In
some cases, the supplier can take care of proper disposal.
Page | 7Hybrid Inverter | Installer Manual

2. PRODUCT INTRODUCTION
The Sunsynk Three-Phase Hybrid Inverter is a highly efficient power management tool that al-
lows the user to hit those ‘parity’ targets by managing power-flow from multiple sources such
as solar, mains power (grid) and generators, and then effectively storing and releasing power
as and when utilities require.
Page | 8 Hybrid Inverter | Installer Manual
2.1. System Overview

Page | 9Hybrid Inverter | Installer Manual
1. Inverter Indicators 7. Meter-485 port 13. Grid
2. LCD Display 8. Battery input connectors 14. Load
3. Function Buttons 9. Function Port 15. Generator input
4. Power on/off button 10. Modbus Port 16. WiFi Interface
5. DC switch 11. BMS Port
6. Parallel port 12. PV input with two MPPT
2.2. Product Size

Page | 10 Hybrid Inverter | Installer Manual
2.3. Features
INTERACTIVE
Easy and simple to understand LCD display;
Supporting Wi-Fi or GSM monitoring;
Visual power flow screen;
Built-in 2 strings for 1 MPP tracker and 1 string for 1 MPP tracker;
Smart settable 3-stage MPPT charging for optimised battery performance;
Auxiliary load function;
Multi-inverter function: grid-tied and off-grid;
COMPATIBLE
Compatible with mains electrical grid voltages or power generators;
Compatible with wind turbines;
230V/400V Three-phase Pure Sinewave Inverter;
Self-consumption and feed-in to the grid;
Auto restart while AC is recovering;
Maximum charging/discharging current of 190A (8kW), 210A (10kW), and 240A (12kW);
DC and AC couple to retrofit existing solar system;
Compatible with a 48V low-voltage battery;
Up to 10 inverters connected in parallel;
CONFIGURABLE
Fully programmable controller;
Programmable supply priority for battery or grid;
Programmable multiple operation modes: on-grid/off-grid & UPS;
Configurable battery charging - current/voltage based on applications by LCD setting;
Configurable AC / solar / generator charger priority by LCD setting;
6 time periods for battery charging/discharging;
SECURE
Overload/over-temperature/short-circuit protection;
Smart battery charger design for optimised battery protection;
Limiting function installed to prevent excess power overflow to grid;
Isolation transformer design;
APPLICATIONS
Marine (vessel power management);
Power shedding (home/office/factory);
UPS (fuel-saving systems);
Remote locations with solar and wind generators;
Building sites;
Telecommunication;

2.4. Basic System Architecture
The following diagram explains the basic application and architecture of this 3-Phase Inverter.
It also includes following devices to have a Complete running system.
Generator or Utlity
PV modules
Batteries
Normal and smart loads
Monitoring system
Consult with your system integrator for other possible system architectures depending on your
requirements.
This inverter can power all kinds of appliances in home or once environment, including motor
type appliances such as refrigerator and air conditioner.
Page | 11Hybrid Inverter | Installer Manual

3. TECHNICAL SPECIFICATIONS
Model SUNSYNK-8K-SG04LP3
Product Type Hybrid Inverter
Enclosure IP65
Ambient Temperature -45ºC ~ 60ºC (>45ºC derating)
Protection Level Class I
Max. Efficiency 97.60%
Compatible Batteries Lithium-ion / Lead-acid
Charge Mode
Battery Voltage 48Vd.c (40Vd.c ~ 60Vd.c)
Battery Current 190Ad.c (max.)
AC Input Voltage 3L/N/PE 220/380Va.c, 230/400Va.c
AC Input Frequency 50/60Hz
AC Input Rated Current 11.6Aa.c
Max. AC Input Current 17.4a.c (max.)
Max. AC Input Power 8000W
Max. Apparent Input Power 8000VA
PV Input Voltage 550Vd.c (160Vd.c ~ 800Vd.c)
MPPT Input Voltage 200Vd.c ~ 650Vd.c
PV Input Current 13Ad.c + 13Ad.c
Max. PV Input Power 10400W
Max. PV Isc 17Ad.c + 17Ad.c
Utility-Interactive
AC Output Voltage 3L/N/PE 230/400, 240/415V.a.c
AC Output Frequency 50/60Hz
AC Output Rated Current 11.6Aa.c
Max. AC Output Current 17.4a.c (max.)
Max. AC Output Power 8000W
Rated Apparent Output Power 8000VA
Max. Apparent Output Power 8000VA
AC Output Power Factor 0.8 leading to 0.8 lagging
Max. AC Isc 75Aa.c
Battery Discharge Voltage 40Vd.c ~ 60Vd.c
Battery Discharge Current 190Ad.c (max.)
Battery Discharge Power 8000W
Stand Alone
AC Output Voltage 3L/N/PE 230/400, 240/415V.a.c
AC Output Frequency 50/60Hz
AC Output Rated Current 11.6Aa.c
Max. Apparent Output Power 8000VA
Max. Continuous AC Passthrough Current 45Aa.c
Battery Discharge Voltage 40Vd.c ~ 60Vd.c
Max. Discharge Current 190A (max.)
Peak Output Power 16000W 10s
Compliance IEC/EN62109-1&2; IEC/EN61000-6-1/2/3/4, AS/NZS4777.2
Page | 12 Hybrid Inverter | Installer Manual

Page | 13Hybrid Inverter | Installer Manual
Model SUNSYNK-10K-SG04LP3
Product Type Hybrid Inverter
Enclosure IP65
Ambient Temperature -45ºC ~ 60ºC (>45ºC derating)
Protection Level Class I
Max. Efficiency 97.60%
Compatible Batteries Lithium-ion / Lead-acid
Charge Mode
Battery Voltage 48Vd.c (40Vd.c ~ 60Vd.c)
Battery Current 210Ad.c (max.)
AC Input Voltage 3L/N/PE 220/380Va.c, 400Va.c
AC Input Frequency 50/60Hz
AC Input Rated Current 14.5Aa.c
Max. AC Input Current 21.7Aa.c (max.)
Max. AC Input Power 10000W
Max. Apparent Input Power 10000VA
PV Input Voltage 550Vd.c (160Vd.c ~ 800Vd.c)
MPPT Input Voltage 200Vd.c ~ 650Vd.c
PV Input Current 26Ad.c + 13Ad.c
Max. PV Input Power 13000W
Max. PV Isc 34Ad.c + 17Ad.c
Utility-Interactive
AC Output Voltage 3L/N/PE 230/400, 240/415V.a.c
AC Output Frequency 50/60Hz
AC Output Rated Current 14.5Aa.c
Max. AC Output Current 21.7Aa.c (max.)
Max. AC Output Power 10000W
Rated Apparent Output Power 10000VA
Max. Apparent Output Power 10000VA
AC Output Power Factor 0.8 leading to 0.8 lagging
Max. AC Isc 75Aa.c
Battery Discharge Voltage 40Vd.c ~ 60Vd.c
Battery Discharge Current 210Ad.c (max.)
Battery Discharge Power 10000W
Stand Alone
AC Output Voltage 3L/N/PE 230/400, 240/415V.a.c
AC Output Frequency 50/60Hz
AC Output Rated Current 14.5Aa.c
Max. Apparent Output Power 10000VA
Max. Continuous AC Passthrough Current 45Aa.c
Peak Output Power 20000W (10 seconds)
Battery Discharge Voltage 40Vd.c ~ 60Vd.c
Max. Discharge Current 210A (max.)
Peak Output Power 20000W 10s
Compliance IEC/EN62109-1&2; IEC/EN61000-6-1/2/3/4, AS/NZS4777.2

Page | 14 Hybrid Inverter | Installer Manual
Model SUNSYNK-12K-SG04LP3
Product Type Hybrid Inverter
Enclosure IP65
Ambient Temperature -45ºC ~ 60ºC (>45ºC derating)
Protection Level Class I
Max. Efficiency 97.60%
Compatible Batteries Lithium-ion / Lead-acid
Charge Mode
Battery Voltage 48Vd.c (40Vd.c ~ 60Vd.c)
Battery Current 240Ad.c (max.)
AC Input Voltage 3L/N/PE 220/380Va.c, 400Va.c
AC Input Frequency 50/60Hz
AC Input Rated Current 17.4Aa.c
Max. AC Input Current 26.1Aa.c (max.)
Max. AC Input Power 12000W
Max. Apparent Input Power 12000VA
PV Input Voltage 550Vd.c (160Vd.c ~ 800Vd.c)
MPPT Input Voltage 200Vd.c ~ 650Vd.c
PV Input Current 26Ad.c + 13Ad.c
Max. PV Input Power 15600W
Max. PV Isc 34Ad.c + 17Ad.c
Utility-Interactive
AC Output Voltage 3L/N/PE 230/400, 240/415V.a.c
AC Output Frequency 50/60Hz
AC Input Rated Current 17.4Aa.c
Max. AC Input Current 26.1Aa.c (max.)
Max. AC Output Power 12000W
Rated Apparent Output Power 12000VA
Max. Apparent Output Power 12000VA
AC Output Power Factor 0.8 leading to 0.8 lagging
Max. AC Isc 75Aa.c
Battery Discharge Voltage 40Vd.c ~ 60Vd.c
Battery Discharge Current 240Ad.c (max.)
Battery Discharge Power 12000W
Stand Alone
AC Output Voltage 3L/N/PE 230/400, 240/415V.a.c
AC Output Frequency 50/60Hz
AC Output Rated Current 17.4Aa.c
Max. Apparent Output Power 12000VA
Max. Continuous AC Passthrough Current 45Aa.c
Battery Discharge Voltage 40Vd.c ~ 60Vd.c
Max. Discharge Current 240A (max.)
Peak Output Power 24000W 10s
Compliance IEC/EN62109-1&2; IEC/EN61000-6-1/2/3/4, AS/NZS4777.2

4. INSTALLATION
4.1. Parts List
Check if you received all the items listed below. Ensure that nothing is damaged in the package.
Page | 15Hybrid Inverter | Installer Manual

4.2. Selecting the Mounting Area
Page | 16 Hybrid Inverter | Installer Manual
For proper heat dissipation, allow a clearance of approximately 500mm to the side, 500mm
above and below the unit, and 1000mm to the front of the unit.
DO NOT install the inverter in the following areas:
Areas with high salt content, such as the marine environment. It will deteriorate the metal
parts and possibly lead to water/dampness penetrating the unit.
Areas filled with mineral oil or containing splashed oil or steam such as found in kitchens. It
will deteriorate plastic parts of the unit, causing those parts to fail or allow water/damp to
penetrate the unit.
Areas that generate substances that adversely affect the equipment, such as sulphuric gas,
chlorine gas, acid, or alkali. These can cause the copper pipes and brazed joints to corrode
and fail to conduct electricity reliably.
Areas that can cause combustible gas to leak, which contains suspended carbon-fibre or
flammable dust, or volatile inflammable such as paint thinner or gasoline.
Areas where there may be gas leaks and where gas may settle around the unit as this is a
fire risk.
Areas where animals may urinate on the unit or ammonia may be generated.
High altitude areas (over 4000 metres above sea level).
Environments where precipitation or humidity are above 95%
Areas where the air circulation is too low.

4.3. Mounting the Inverter
ALSO CONSIDER:
Installing the indoor unit, outdoor unit, power supply cable, transmission cable, and remote
control cable at least 1 metre away from any television or radio receiver. This will prevent TV
reception interference or radio noise. This will prevent radio signal interference from external
units that might interfere with the Wi-Fi or GSM monitoring.
If children under 10 years old may approach the unit, take preventive measures so that they
cannot reach and touch the unit.
Install the indoor unit on the wall where the height from the floors is higher than 1600mm.
Before connecting all wires, please take the metal cover off removing the screws as shown
below:
Select installation locations that adequate to support the weight of the converter.
Install this inverter at eye-level to allow the LCD to be read anytime.
An appropriate ambient temperature is between -25 ~ 60°C to ensure optimal operation.
Be sure to keep other objects and surfaces as shown in the figure to guarantee sufficient
heat dissipation and have enough space to remove wires.
For proper air circulation to dissipate heat, allow a clearance of approximately 50cm to the
side.
Page | 17Hybrid Inverter | Installer Manual
Risk of injury (Heavy Object)
Remember that this inverter is heavy (45kg) so users must be careful in handling
the unit during installation especially when mounting or removing from a wall.

Choose the recommend drill head (as shown in below pic) to drill 4 holes on the wall, 52-60mm
deep.
1. Use a proper hammer to fit the expansion bolt into the holes.
2. Carry the inverter and holding it, make sure the hanger aim at the expansion bolt,fix the
inverter on the wall.
3. Fasten the screw head of the expansion bolt to finish the mounting.
Page | 18 Hybrid Inverter | Installer Manual

Page | 19Hybrid Inverter | Installer Manual
4.4. Battery Connection
For safe operation and compliance, an individual DC overcurrent protector or disconnection
device is required for the connection of the battery and the inverter. Users are recommended to
utilise a suitable fuse and DC isolator (see next page). In some applications, switching devices
may not be required, but overcurrent protectors must be used. Please refer to the typical am-
perage in the table below for the required fuse or circuit breaker size.
Model Wire Size Cable (mm2) Torque value (max.)
8kW 1AWG 40 24.5N.m
10kW 1/0 AWG 60 24.5N.m
12kW 1/0 AWG 60 24.5N.m
Please follow below steps to implement battery connection:
1. Please choose a suitable battery cable (appropriate rating) with the correct connector to
attach to the battery terminals.
2. Use a suitable screwdriver that matches the bolt size to unscrew the bolts to fit the battery
connectors. Then tighten the bolts with the connectors in place with a torque of 24.5N.m
in a clockwise direction.
3. Make sure polarity is correct at both the battery and inverter terminals
Battery connector screw size: M10.
Reverse Polarity
All wiring/connecting must be performed by qualified personnel. Before making
the final DC connection or closing the DC Breaker/disconnection device, ensure
the inverter unit is wired correctly. A reverse-polarity connection on the battery will
damage the inverter.

Page | 20 Hybrid Inverter | Installer Manual
4.4.1. Function Ports Definition
Dry contact
