DOOR GASKETS
• Exact Size Replacement Gaskets • Universal Compression Gaskets • Universal Magnetic Gaskets
SEALED UNIT PARTS CO., INC
P.O.Box21
2230LandmarkPlace
Allenwood,NJ 08720USA
(732)223-6644
Fax:(732)223-1617
www.supco.com
Selection Guide For Refrigerator/Freezer
DOOR GASKETS, UNIVERSAL 50 AND 100 FOOT COILS
Four of the most commonly used compression gaskets are available in both 50
and 100 foot coils. Gaskets Numbers 1160 and 1051 are designed for forming
easy corner curves with a short radius of 6" standard. Smaller radius curves to 2"
minimum radius can be made with simple notching. All gasket material is made
of refrigeration grade 100% virgin vinyl and is F.D.A. acceptable.
COILED UNIVERSAL DOOR GASKET
50 FOOT COIL 100 FOOT COIL
PART NO. PART NO. COLOR
1051-50 1051-100 WHITE
1160-50 1160-100 WHITE
5451-50 5451-100 GRAY
6662-50 6662-100 GRAY
MAGNETIC DOOR GASKETS, UNIVERSAL SIZE KITS
Designed for universal replacement on refrigerators and freezers when original
equipment replacement frame is not available. The illustrated cross sections
show the two most popular frames used where the clearance between the door
and the cabinet body is 5/8" to 3/4". Each gasket is furnished with (4) L-shaped
sections complete with factory welded corners. The magnetic insert strip is
furnished in a roll. Both the gasket and magnetic strip can be easily cut to size.
Gasket material is made of refrigeration grade virgin vinyl (F.D.A. acceptable)
and will provide long life and ease of installation.
SU2000 SERIES UNIVERSAL DOOR GASKETS
PART NO. MAX. DOOR SIZE
SU2001 20" x 30"
SU2002 32" x 42"
SU2003 32" x 55"
SU2004 36" x 84"
SU2300 SERIES
PART NO. MAX. DOOR SIZE
SU2301 20" x 30"
SU2302 32" X 42"
SU2303 32" X 55"
SU2304 36" X 84"
G.E. REPLACEMENT MAGNETIC DOOR GASKETS KITS
Same material and packaging specifications as Universal Kits shown above
except these have been designed to have the exact same gasket profile as the
G.E. models they are replacing.
PART NO. REPLACES G.E. NO.
SGE421 (BR) WR24X421
SGE422 WR24X422
SGE432 (BR) WR24X432
SGE433 WR24X433
NOTE: (BR) Indicates brown color
2
All SUPCO Replacement Door Gaskets are made of 100% virgin vinyl, to meet or exceed original equipment manufacturers specifications. Each gasket is packaged in a
reinforced corrugated box to meet shipping and stocking requirements. All gaskets have factory welded square corners to assure proper fit. Magnetic gaskets have
magnets installed prior to sealing. Some magnetic gaskets have magnets installed on only three sides to allow for ease of opening the refrigerator door.
EXACT SIZE REPLACEMENTS - O.E.M. TO SUPCO GASKET CROSS REFERENCE
NOTE: (BR) Indicates BROWN colored gasket; (TN) Indicates TAN or BEIGE colored gasket; (BK) Indicates BLACK colored gasket. Bold indicates NEW gasket.
O.E.M. NO. SUPCO NO. O.E.M. NO. SUPCO NO. O.E.M. NO. SUPCO NO.
ADMIRAL
24157-12 SAD38
26693-13 SAD51
26693-18 SAD52
26693-2 SAD53
26693-21 SAD54
26693-24 SAD55
26693-25 SAD56
56287-11 SAD77
59787-1 SAD57
66929-1 SAD75
66929-10 SAD89
66929-11 SAD94
66929-12 SAD90
66929-13 SAD91
66929-14 SAD92
66929-15 SAD93
66929-2 SAD63
66929-31 SAD76
66929-32 SAD82
66929-32 SAD95
66929-4 SAD84
66929-5 SAD85
66929-6 SAD86
66929-8 SAD87
66929-9 SAD88
68543-3 SAD79
68543-4 SAD80
69348203 SAD65
69351298 SAD64
70025-1 SAD98
70025-2 SAD99
70025-3 SAD96
70025-4 SAD97
70025-5 SAD100
70025-6 SAD101
70047-1 SAD67
70047-2 SAD69
70047-3 SAD71
70047-4 SAD74
70048-1 SAD68
70048-2 SAD70
70048-3 SAD72
70048-4 SAD73
70048-5 SAD81
AMANA
038804-2 SAM23
039282-05 SAM31
039282-07 SAM32
10359708Q SAM62
10359709Q SAM63
10359710Q SAM64 (BK)
10359711Q SAM65 (BK)
10456854Q SAM61
12550101Q SAM54 (BK)
12550109Q SAM55
12550111Q SAM56
12550112Q SAM57
12550115Q SAM58
12550116Q SAM59
D3786409 SAM22
D7065102Q SAM60 (TN)
D7092601Q SAM28
O.E.M. NO. SUPCO NO.
D7092602Q SAM29
D7092603Q SAM30
D7092608Q SAM41
D7092609Q SAM45
D7251001Q SAM50
D7251002Q SAM47
D7251004Q SAM49
D7251019Q SAM48 (TN)
D7251020Q SAM46 (TN)
D7431904Q SAM53 (TN)
D7431905Q SAM52 (TN)
D7431906Q SAM51 (TN)
D7605101Q SAM37 (TN)
D7605104Q SAM38 (TN)
D7605105Q SAM42
D7605106Q SAM43
D7605107Q SAM44
D7605108Q SAM33
D7605109Q SAM34
D7605110Q SAM35 (TN)
D7605111Q SAM36 (TN)
D7605115Q SAM39
D7605116Q SAM40
FRANKLIN
57810-10 SFN13
FRIGIDAIRE
5300622114 SFR104
5300622929 SFR94
5300622930 SFR95
5300624971 SFR99
5300624974 SFR100
5300624975 SFR101
5300627766 SFR103
5300627857 SFR105
5300628810 SFR88
5301124534 SFR85
5307112517 SFR76
5307510058 SFR71
5307512516 SFR75
5307512518 SFR77
5307512519 SFR78
5307514191 SFR80
5307516633 SFR84
5307541122 SFR86
5307545059 SFR91
5318680314 SFR79
622115 SFR93
622931 SFR96
622970 SFR106
626288 SFR102
627251 SFR104
627766 SFR103
6583286 SFR62
7546760 SFR102
GE
WR14X5032 SGE73
WR14X5034 SGE68
WR14X5035 SGE75
WR24X0517 SGE517
WR24X10049 SGE485
WR24X142 SGE42
WR24X159 SGE52
WR24X163 SGE55
WR24X164 SGE164
WR24X165 SGE82
WR24X179 SGE57
WR24X182 SGE182
WR24X192 SGE79
WR24X193 SGE76
WR24X194 SGE81
WR24X205 SGE205
WR24X220 SGE88
WR24X229 SGE229
WR24X230 SGE230
WR24X232 SGE118
WR24X233 SGE121
WR24X244 SGE244
WR24X245 SGE245
WR24X246 SGE108
WR24X247 SGE247
WR24X248 SGE248
WR24X249 SGE249
WR24X252 SGE109
WR24X256 SGE120
WR24X259 SGE259
WR24X260 SGE116
WR24X261 SGE119
WR24X266 SGE266
WR24X267 SGE117
WR24X267 SGE267
WR24X268 SGE268
WR24X269 SGE78
WR24X271 SGE126
WR24X272 SGE125
WR24X273 SGE112
WR24X274 SGE111
WR24X276 SGE276
WR24X277 SGE277
WR24X279 SGE279
WR24X282 SGE282 (BR)
WR24X283 SGE283 (BR)
WR24X284 SGE284 (BR)
WR24X285 SGE285 (BR)
WR24X286 SGE286 (BR)
WR24X287 SGE287 (BR)
WR24X289 SGE289
WR24X290 SGE290 (BR)
WR24X292 SGE292 (BR)
WR24X294 SGE294 (BR)
WR24X295 SGE295 (BR)
WR24X297 SGE297
WR24X298 SGE298
WR24X300 SGE300 (BR)
WR24X301 SGE301 (BR)
WR24X302 SGE302
WR24X303 SGE303
WR24X305 SGE305 (BR)
WR24X308 SGE308 (BR)
WR24X309 SGE309 (BR)
WR24X310 SGE310
WR24X311 SGE311
WR24X312 SGE312
WR24X313 SGE127
WR24X315 SGE110
WR24X317 SGE317
WR24X318 SGE318 (BR)
WR24X319 SGE319
WR24X389 SGE389 (BR)
WR24X390 SGE390 (BR)
WR24X391 SGE391
WR24X392 SGE392
WR24X411 SGE411 (BR)
WR24X416 SGE416 (BR)
WR24X420 SGE420 (BR)
WR24X421 SGE421 (BR)
WR24X422 SGE422
WR24X424 SGE424 (BR)
WR24X427 SGE427 (BR)
WR24X432 SGE432 (BR)
WR24X433 SGE433
WR24X435 SGE435 (BR)
WR24X436 SGE436 (BR)
WR24X437 SGE437
WR24X438 SGE438
WR24X446 SGE446
WR24X449 SGE449
WR24X450 SGE450
WR24X454 SGE454 (BR)
WR24X464 SGE464 (BR)
WR24X473 SGE473 (BR)
WR24X474 SGE474 (BR)
WR24X481 SGE481 (BR)
WR24X482 SGE482 (BR)
WR24X484 SGE484
WR24X485 SGE485
WR24X486 SGE486
WR24X490 SGE490 (BR)
WR24X5008 SGE5008 (BR)
WR24X5010 SGE104
WR24X5011 SGE105
WR24X5013 SGE107
WR24X5015 SGE5015
WR24X5017 SGE5017
WR24X5024 SGE024
WR24X5068 SGE115
WR24X5071 SGE94
WR24X5100 SGE69
WR24X5101 SGE77
WR24X5103 SGE71
WR24X5104 SGE5104
WR24X5105 SGE5105
WR24X5106 SGE106
WR24X5106 SGE5106
WR24X5113 SGE5113
WR24X5116 SGE5116
WR24X5119 SGE5119
WR24X5124 SGE113
WR24X5126 SGE102
WR24X5144 SGE5144
WR24X5148 SGE422
WR24X5149 SGE5149
WR24X5210 SGE5210
WR24X5211 SGE5211
WR24X5212 SGE5212
WR24X5231 SGE5231
WR24X5232 SGE5232
WR24X5238 SGE5238
WR24X524 SGE524
WR24X5256 SGE5256 (BR)
3
O.E.M. NO. SUPCO NO. O.E.M. NO. SUPCO NO. O.E.M. NO. SUPCO NO. O.E.M. NO. SUPCO NO.
WR24X5258 SGE5258
WR24X527 SGE527
WR24X528 SGE528
WR24X550 SGE550
WR24X558 SGE558
GIBSON
186803-03 SGI43
5308007115 SGI46
5308007124 SGI44
5308016563 SGI41
5314220908 SGI33
5315282802 SGI48
5315627301 SGI30
5318693207 SGI47
KELVINATOR
5301205009 SKL35
5301207363 SKL56
5301207364 SKL57
K1205007 SKL34
K1205008 SKL36
K1205010 SKL37
K1207363 SKL56
K1207364 SKL57
PHILCO
6007-356-1 SPH47
6007-356-11 SPH57
6007-356-2 SPH48
6007-356-3 SPH49
6007-356-4 SPH50
6007-356-6 SPH52
6007-356-7 SPH53
6007-356-8 SPH54
6007-356-9 SPH55
WCI
215608916 SWC64
215732413 SWC59
215740401 SWC62
215740402 SWC63
218730604 SWC71 (TN)
218730609 SWC59
5300412101 SWC16
5300412103 SWC67
5300627766 SWC19
5300628042 SWC18
5300661994 SWC27
5303001049 SWC36 (TN)
5303001304 SWC55 (BR)
5303001317 SWC69 (BR)
5303001398 SWC10 (TN)
5303001399 SWC11 (TN)
5303001486 SWC45 (TN)
5303007357 SWC35 (TN)
5303017189 SWC34 (BR)
5303017373 SWC41 (BR)
5303018791 SWC24
5303018792 SWC22
5303200473 SWC37 (TN)
5303200474 SWC38 (TN)
5303200799 SWC49 (TN)
5303200800 SWC48 (TN)
5303200832 SWC33
5303201013 SWC32 (TN)
5303201811 SWC39 (TN)
5303207112 SWC15
5303207113 SWC30
5303207115 SWC31
5303207345 SWC61
5303270902 SWC65 (BR)
5303271473 SWC66
5303276826 SWC34 (BR)
5303276826 SWC45 (TN)
5303288856 SWC11 (TN)
5303288856 SWC55 (BR)
530329557 SWC10 (TN)
5303297557 SWC58 (BR)
5303297557 SWC69 (BR)
5306583289 SWC47
5307510063 SWC46
5308007114 SWC44
5308007229 SWC52
5308010756 SWC25
5308015544 SWC12 (TN)
5308016562 SWC54 (TN)
5308016564 SWC51 (TN)
5308016627 SWC13
5308016628 SWC14
5308017487 SWC60 (BR)
5317532406 SWC42
5317532408 SWC43
5317532506 SWC53
5318680302 SWC21
5318680305 SWC23
5318680311 SWC26
5318680314 SWC43
5318680314 SWC44
R000900734 SWC56 (BR)
R000900798 SWC57 (BR)
WESTINGHOUSE
*R462603 SWE71
5300280161 SWE59
5300280163 SWE55
5300280166 SWE60
5300280168 SWE56
5300462603 SWE71
C280162 SWE58
C280164 SWE57
C280165 SWE61
WHIRLPOOL
1109187 SCS71
1129252 SCS49
2166000 SCS113
2188404A SCS105
2188404A SCS44
2188404A SCS94
2188405A SCS79
2188433A SCS116
2188434A SCS97
2188436A SCS91
2188437A SCS106
2188438A SCS96
2188439A SCS117
2188442A SCS73
2188444A SCS75
2188445A SCS115
2188446A SCS98
2188447A SCS99
2188448A SCS112
2188450A SCS42
2188450A SCS84
2188451A SCS46
2188452A SCS64
2188453A SCS61
2188456A SCS102
2188458A SCS103
2188459A SCS104
2188460A SCS92
2188461A SCS100
2188464A SCS93
2188465A SCS55
2188466A SCS66
4343266 SCS114
4343449 SCS107
4387567 SCS80
4387583 SCS59
4387632 SCS85
510342 SCS24
510343 SCS25
510344 SCS26
510345 SCS27
512300 SCS28
528919 SCS29
576662 SCS110
576664 SCS108
592945 SCS111
592946 SCS109
653209 SCS36
658998 SCS40
838141 SCS60
845282 SCS50
845283 SCS51
848395 SCS31
848410 SCS32
876480 SCS37
876482 SCS34
876483 SCS33
912395 SCS77
912396 SCS78
991745 SCS74
992582 SCS49
UNIVERSAL KITS
KIT SU2001
KIT SU2002
KIT SU2003
KIT SU2004
KIT SU2301
KIT SU2302
KIT SU2303
KIT SU2304
4
GEM NO. SUPCO NO. GEM NO. SUPCO NO. GEM NO. SUPCO NO. GEM NO. SUPCO NO.
2001 SU2001
2002 SU2002
2003 SU2003
2004 SU2004
2301 SU2301
2301 SU2301
2302 SU2302
2303 SU2303
2304 SU2304
AD38 SAD38
AD51 SAD51
AD52 SAD52
AD53 SAD53
AD54 SAD54
AD55 SAD55
AD57 SAD57
AD63 SAD63
AD64 SAD64
AD65 SAD65
AD67 SAD67
AD68 SAD68
AD69 SAD69
AD70 SAD70
AD71 SAD71
AD72 SAD72
AD73 SAD73
AD74 SAD74
AD76 SAD76
AD77 SAD77
AD77 SAD81
AD78 SAD78
AD79 SAD79
AD79 SAD83
AD80 SAD80
AM22 SAM22
AM23 SAM23
AM28 SAM28
AM29 SAM29
AM30 SAM30
AM31 SAM31
AM32 SAM32
CS25 SCS25
CS26 SCS26
CS27 SCS27
CS28 SCS28
CS29 SCS29
CS31 SCS31
CS32 SCS32
CS33 SCS33
CS34 SCS34
CS36 SCS36
CS37 SCS37
CS40 SCS40
CS41 SCS79
CS42 SCS42
CS43 SCS92
CS44 SCS44
CS46 SCS46
CS47 SCS100
CS49 SCS49
CS50 SCS64
CS51 SCS98
EXACT SIZE REPLACEMENTS - GEM TO SUPCO GASKET CROSS REFERENCE
CS52 SCS115
CS53 SCS55
CS54 SCS50
CS55 SCS51
CS56 SCS116
CS57 SCS102
CS58 SCS97
CS59 SCS102
CS60 SCS115
FR105 SFR105
FR106 SWC18
FR108 SWC45 (TN)
FR109 SWC38 (TN)
FR110 SWC39 (TN)
FR111 SWC34 (BR)
FR112 SWC30
FR113 SWC44
FR114 SWC32 (TN)
FR115 SWC33
FR116 SWC20
FR116 SWC36 (TN)
FR117 SWC59
FR118 SWC60 (BR)
FR119 SWC41 (BR)
FR119 SWC71 (TN)
FR122 SWC62
FR26 SWC26
FR90 SWC61
GE 42 SGE42
GE107 SGE107
GE108 SGE108
GE109 SGE109
GE110 SGE110
GE111 SGE111
GE112 SGE112
GE113 SGE113
GE115 SGE115
GE116 SGE116
GE117 SGE117
GE118 SGE118
GE119 SGE119
GE120 SGE120
GE121 SGE121
GE125 SGE125
GE126 SGE126
GE127 SGE127
GE128 SGE301 (BR)
GE129 SGE303
GE130 SGE284 (BR)
GE131 SGE285 (BR)
GE132 SGE286 (BR)
GE133 SGE318 (BR)
GE134 SGE309 (BR)
GE135 SGE319
GE136 SGE390 (BR)
GE137 SGE433
GE138 SGE287 (BR)
GE139 SGE312
GE140 SGE298
GE141 SGE311
GE142 SGE422
GE143 SGE266
GE144 SGE268
GE146 SGE276
GE147 SGE277
GE148 SGE279
GE149 SGE282 (BR)
GE150 SGE283 (BR)
GE151 SGE289
GE152 SGE292 (BR)
GE153 SGE295 (BR)
GE155 SGE300 (BR)
GE156 SGE302
GE157 SGE305 (BR)
GE158 SGE308 (BR)
GE159 SGE317
GE160 SGE389 (BR)
GE161 SGE421 (BR)
GE162 SGE432 (BR)
GE163 SGE5106
GE164 SGE230
GE165 SGE244
GE166 SGE245
GE167 SGE247
GE168 SGE248
GE169 SGE249
GE170 SGE297
GE172 SGE392
GE173 SGE411 (BR)
GE174 SGE416 (BR)
GE175 SGE420 (BR)
GE176 SGE424 (BR)
GE177 SGE427 (BR)
GE391 SGE391
GE435 SGE435 (BR)
GE437 SGE437
GE446 SGE446
GE449 SGE449
GE450 SGE450
GE464 SGE464 (BR)
GE485 SGE485
GE52 SGE52
GE5231 SGE5231
GE5232 SGE5232
GE55 SGE55
GE558 SGE558
GE57 SGE57
GE68 SGE68
GE69 SGE69
GE71 SGE71
GE72 SGE5104
GE73 SGE73
GE75 SGE75
GE76 SGE76
GE77 SGE77
GE78 SGE78
GE79 SGE79
GE81 SGE81
GE82 SGE82
GE88 SGE88
GE94 SGE94
GI30 SGI30
GI33 SGI33
GI41 SGI41
GI42 SGI48
GI43 SGI47
GI44 SGI46
KL34 SKL34
KL35 SKL35
KL36 SKL36
KL37 SKL37
KL56 SKL56
KL57 SKL57
PH47 SPH47
PH48 SPH48
PH49 SPH49
PH50 SPH50
PH52 SPH52
PH53 SPH53
PH54 SPH54
PH55 SPH55
PH57 SPH57
WC10 SWC10 (TN)
WC12 SWC12 (TN)
WE51 SWE57
WE55 SWE55
WE56 SWE56
WE58 SWE58
WE59 SWE59
WE60 SWE60
WE61 SWE61
WE70 SWC15
WE71 SWE71
WE72 SWC16
WE73 SWC67
WP104 SCS104
WP13 SCS80
WP16 SCS79
WP16 SCS85
WP17 SCS91
WP18 SCS92
WP20 SCS96
WP21 SCS105
WP28 SCS93
WP31 SCS24
WP32 SCS77
WP33 SCS78
WP449 SCS59
WP566 SCS102
WP567 SCS80
WP570 SCS100
WP572 SCS92
WP577 SCS103
WP589 SCS64
WP590 SCS46
WP591 SCS84
WP608 SCS115
WP609 SCS75
WP617 SCS79
WP622 SCS105
WP626 SCS117
WP634 SCS97
WP638 SCS116
WP745 SCS74
WP99 SCS99
5
A
SGE301 (BR) 28 5/8 X 38
SGE303 28 1/2 X 38
SGE309 (BR) 31 1/8 X 38
SGE318 (BR) 26 1/8 X 39 3/4
SGE319 26 1/4 X 39 3/4
SGE389 (BR) 21 1/4 X 32 5/8
SGE390 (BR) 32 5/8 X 38
AA
SAD67 16 3/8 X 28 1/4
SAD68 28 1/4 X 36 5/8
SAD69 18 7/16 X 28 1/4
SAD70 28 1/4 X 39 1/8
SAD71 19 3/8 X 30 3/4
SAD72 30 3/4 X 39 1/8
SAD73 32 1/4 X 39 1/8
SAM57 18 7/8 X 31 1/4
SWC27 28 X 38 7/8
AB
SGE125 28 1/4 X 41 1/2
SGE126 28 3/8 X 40
AD
SCS74 19 1/16 X 40 1/4
AE
SAM33 19 1/4 X 30 3/4
SAM34 30 7/8 X 40 1/2
SAM35 (TN) 24 X 30 3/4
SAM36 (TN) 30 3/4 X 35 1/2
SAM37 (TN) 17 1/2 X 30 3/4
SAM38 (TN) 30 3/4 X 39 1/4
SAM39 24 1/8 X 31
SAM40 30 5/8 X 35 5/8
SAM42 31 3/4 X 40 1/2
SAM43 17 1/2 X 30 3/4
SAM44 30 3/4 X 39 1/4
SAM54 (BK) 23 3/4 X 31
SAM55 28 1/2 X 39 3/4
SAM56 31 1/2 X 41 1/2
SAM58 37 3/4 X 31 1/4
SAM59 23 1/2 X 31 1/4
SAM60 (TN) 19 1/4 X 30 3/4
SAM61 18 5/8 X 28 1/4
SAM62 19 3/4 X 61
SAM63 14 1/4 X 61
SAM64 (BK) 20 X 61 1/8
SAM65 (BK) 14 1/8 X 60 3/4
SGE5238 24 X 30 3/4
AF
SAD80 31 3/4 X 38 3/4
SAD81 27 7/8 X 36 1/4
SAD82 28 X 38 7/8
SAD83 30 1/2 X 38 3/4
AG
SGE5015 27 X 45 3/4
SGE5017 27 X 70 3/4
AH
SAM46 (TN) 13 7/8 X 61 1/4
SAM47 13 7/8 X 61 1/4
SAM48 (TN) 13 3/4 X 29
SAM49 13 3/4 X 29
SAM50 14 X 19 3/4
SAM51 (TN) 27 X 44 1/B
SAM52 (TN) 14 7/8 X 21
SAM53 (TN) 21 X 42 1/8
SGE490 (BR) 23 3/8 X 41 3/8
PROFILE/
SUPCO NO. DIMENSION
PROFILE/
SUPCO NO. DIMENSION
PROFILE/
SUPCO NO. DIMENSION
PROFILE/
SUPCO NO. DIMENSION
AJ
SGE435 (BR) 32 1/2 x 39 1/2
SGE436 (BR) 21 X 32 5/16
SGE437 32 5/8 X 39 3/8
SGE438 21 1/8 X 32 7/16
SGE446 29 3/16 x 38 3/4
SGE449 18 7/8 x 27 1/4
SGE450 27 1/4 x 38 5/8
SGE481 (BR) 26 1/2 X 37 7/8
SGE482 (BR) 16 5/8 X 26 1/16
SGE484 16 5/8 X 26
SGE485 26 1/8 X 37 15/16
SGE486 25 15/16 X 41
SGE524 16 5/8 X 26 1/16
SGE558 26 X 43 1/16
AK
SCS108 26 1/2 X 58 1/2
SCS109 26 13/16 X 61
SCS110 26 1/2 X 47 3/8
SCS111 26 3/4 X 42 1/2
AM
SWC67 29 X 42 3/16
C
SAD100 19 1/8 X 29 7/8
SAD101 30 X 37 7/8
SAD57 26 7/8 X 41
SAD63 20 X 60 1/2
SAD64 28 3/4 X 38
SAD65 29 1/2 X 41
SAD75 13 1/2 X 60 5/8
SAD76 18 X 60 5/8
SAD79 28 3/8 X 38 1/4
SAD84 23 1/8 X 60 3/8
SAD85 10 3/4 X 60 1/2
SAD86 18 X 60 5/8
SAD87 10 7/8 X 18 1/4
SAD88 13 1/2 X 18 1/8
SAD89 13 1/2 X 41 1/4
SAD90 15 7/8 X 41 1/4
SAD91 10 7/8 X 41 1/4
SAD92 20 X 60 3/8
SAD93 10 7/8 X 60 1/8
SAD94 15 7/8 X 18 1/8
SAD95 10 3/4 X 60 1/8
SAD96 18 1/4 X 27 3/8
SAD97 27 3/8 X 38
SAD98 16 1/8 X 27 3/8
SAD99 27 3/8 X 35 3/8
D
SAM28 13 15/16 X 61 3/8
SAM29 20 5/16 X 61 13/32
SAM30 16 9/16 X 61 13/32
SAM31 30 7/8 x 42
SAM32 30 7/16 x 43
SAM41 20 1/4 X 61 3/8
SAM45 16 3/8 X 61 1/4
SCS36 19 1/8 X 55 11/16
SCS77 23 X 38 5/8
SCS78 13 1/4 X 73
SFR100 19 1/4 X 60 1/8
SFR101 12 1/4 X 60 1/8
SFR102 19 1/2 X 30 1/2
SFR103 28 1/2 X 41 3/4
SFR104 11 7/8 X 57 1/16
SFR105 28 5/8 X 36 1/4
SFR106 11 7/8 X 60
SFR62 21 5/8 X 45 3/8
SFR71 28 1/2 X 49 1/4
SFR75 30 1/2 X 53 1/4
SWE71 13 3/16 x 58 1/2
G
SGE102 13 1/4X 30 1/4
SGE115 19 X 30 1/8
SGE5144 32 3/8 X 65 5/8
SGE94 30 1/4 X 40 5/8
SKL34 21 1/2 X 51 5/8
SKL35 28 1/2 X 52
SKL36 28 1/2 x 42
SKL37 16 X 28 1/2
SKL56 30 X 41 3/4
SKL57 17 x 30
SU2301 21 1/8 X 30 3/4
SU2302 32 3/8 X 42 3/4
SU2303 32 3/8 X 55 1/2
SU2304 36 X 84
H
SGE024 30 1/8 X 37
SGE108 19 3/4 X 60 1/8
SGE109 11 1/4 X 59 5/16
SGE110 17 1/4 X 57 7/8
SGE230 20 X 60
SGE244 17 1/4 X 60
SGE245 11 1/4 X 60
SGE247 13 15/16 X 60
SGE248 11 X 58 1/4
SGE249 17 1/8 X 58 1/4
SGE289 19 x 28 1/2
SGE294 (BR) 11 1/4 X 57 7/8
SGE295 (BR) 19 5/8 X 59 7/8
SGE297 14 1/16 x 60 1/4
SGE300 (BR) 19 1/8 x 28 3/4
SGE302 19 1/2 X 28 3/4
SGE305 (BR) 17 1/2 X 60
SGE308 (BR) 19 1/2 X 32
SGE310 19 1/2 X 31 1/2
SGE391 21 X 33
SGE392 33 X 38 1/2
SGE411 (BR) 26 3/4 X 39 1/4
SGE416 (BR) 26 3/4 X 42
SGE420 (BR) 14 X 62
SGE421 (BR) KIT 10 X 75 1/2
SGE422 KIT 10 X 75 1/2
SGE424 (BR) 19 3/4 X 60
SGE427 (BR) 17 3/8 X 60
SGE432 (BR) KIT 20 X 62 1/2
SGE433 KIT 20 X 62 1/2
SGE454 (BR) 18 1/4 X 26 3/4
SGE464 (BR) 19 5/8 X 60 9/16
SGE473 (BR) 77 1/8 X 39 1/2
SGE474 (BR) 18 1/8 X 27
SGE5106 31 X 58 3/8
SGE5113 14 1/4 X 16 1/2
SGE5116 11 1/8 X 57 3/4
SGE5119 30 1/4 X 38 3/8
SGE5149 33 X 38 1/4
SGE5211 11 7/8 X 26 5/8
SGE5212 26 5/8 X 41 3/4
SGE5231 19 3/4 X 60
SGE5232 17 3/8 X 60
SGE5258 18 1/4 X 32 1/4
SGE527 11 7/8 X 60
SGE528 17 3/4 X 60
SGI48 18 X 58 5/8
J
SAM22 31 1/2 X 36 1/2
SAM23 31 1/2 X 59 1/8
SFN13 29 1/4 X 36 1/2
SGE5104 26 1/4 X 47 5/8
SGE68 30 X 40 3/8
SFR76 13 1/2 X 30 1/4
SFR77 30 1/4 X 38 1/2
SFR78 30 1/2 X 33 1/4
SFR79 19 X 30 1/4
SFR80 22 1/2 X 47 1/8
SFR84 22 X 32 1/4
SFR85 13 1/4 X 28 5/8
SFR86 28 5/8 X 34 5/8
SFR88 16 1/4 X 30 1/2
SFR91 30 1/2 X 39 1/2
SFR93 11 7/8 X 57
SFR94 20 1/16 X 60 I/8
SFR95 13 I/2 X 60 1/8
SFR96 17 7/8 X 60 1/8
SFR99 32 1/4 X 40 5/8
SGE113 15 7/16 X 30 1/8
SGE120 26 1/8 X 51 7/16
SGE121 29 X 59 1/4
SGE5105 30 1/8 X 54 3/4
SWC18 17 X 28 1/2
SWC19 28 3/4 X 41 7/8
SWC46 19 3/8 X 30 1/4
SWC47 30 1/4 X 39 1/2
SWC56 (BR) 23 I/8 X 37 3/4
SWC57 (BR) 14 3/4 X 23 1/8
E
SGE127 26 1/4 X 36 1/2
SGE287 (BR) 26 7/16 x 36 3/4
SGE5008 (BR) 21 1/4 X 57
F
SCS100 18 5/8 X 28 1/8
SCS102 16 1/2 X 26 3/4
SCS103 21 1/2 X 31 3/8
SCS104 19 3/8 X 31 3/8
SCS105 19 1/8 X 58 7/8
SCS106 23 1/4 X 60 3/8
SCS112 27 1/16 X 39 7/8
SCS113 18 3/4 X 27 1/8
SCS115 27 X 42 1/2
SCS116 19 1/4 X 62 1/4
SCS40 14 3/4 X 55 3/4
SCS42 31 13/32 X 39 1/8
SCS44 19 1/8 X 59 1/32
SCS46 28 13/32 X 39 1/8
SCS49 15 3/8 X 36
SCS55 16 1/16 X 28 1/2
SCS59 28 1/2 X 35 1/4
SCS61 21 1/8 x 37 3/4
SCS64 31 1/2 X 38 1/8
SCS66 14 9/16 X 26 7/8
SCS71 27 7/16 X 42 5/8
SCS73 23 1/32 X 53 11/32
SCS75 30 1/4 X 42 3/8
SCS79 11 3/8 X 59 1/8
SCS80 16 7/8 X 30 3/8
SCS84 31 1/2 X 39 3/8
SCS85 30 1/4 X 61 1/8
SCS91 27 X 60 5/8
SCS92 18 7/8 X 31 3/4
SCS93 16 1/2 X 23 1/4
SCS94 19 3/8 X 59 1/4
SCS96 31 1/2 X 59 1/8
SCS97 14 5/8 X 62 1/8
SCS98 23 1/8 X 42 1/8
SCS99 28 X 40 1/8
SGE286 (BR) 17 1/8 x 26 3/16
SGE312 17 1/8 x 26 3/16
SWC15 28 3/4 x 41 1/4
SWC16 16 1/4 X 29
SWC30 32 X 42 1/4
SWC31 29 3/8 X 55 3/4
6
PROFILE/
SUPCO NO. DIMENSION
PROFILE/
SUPCO NO. DIMENSION
PROFILE/
SUPCO NO. DIMENSION
PROFILE/
SUPCO NO. DIMENSION
SGE69 30 X 36 3/4
SGE71 26 X 54 3/4
SGE73 26 1/4 X 40 3/4
SGE75 13 1/4 X 30 1/8
SGE77 22 7/8 X 30
SU2001 23 1/8 X 32 3/4
SU2002 34 7/8 X 44 3/4
SU2003 34 3/8 X 57 1/2
SU2004 36 X 84
L&M
SCS24 24 1/4 X 48 1/2
SCS25 30 X 48 5/8
SCS26 30 X 33 3/4
SCS27 30 X 39 1/2
SCS28 19 1/8 x 30
SCS29 13 1/2 x 30
SCS31 30 X 55
SCS32 30 X 60 1/2
SCS33 30 3/16 X 39 3/4
SCS34 30 1/8 X 33 7/8
SCS37 13 7/8 x 30 1/8
SCS60 22 3/4 x 53 7/16
SGI30 28 25/32 X 34 11/16
SGI33 26 25/32 X 35 1/32
SPH47 24 7/16 X 52 1/4
SPH48 21 7/16 X 55 7/16
SPH49 29 7/16 X 54 15/16
SPH50 19 1/4 x 29 7/16
SPH52 14 1/8 x 29 7/16
SPH53 29 7/16 X 39 3/4
SPH54 29 7/16 X 34 5/8
SPH55 17 1/8 x 29 7/16
SPH57 29 7/16 X 41 3/4
N
SGE259 22 1/8 X 46
SGE292 (BR) 29 X 39 5/8
SGE311 31 1/4 X 38 1/8
SGE5256 (BR) 18 1/4 X 32 1/4
N&P
SGE276 28 1/8 X 39 5/8
SGE277 18 5/8 X 28 1/16
SGE284 (BR) 28 1/2 X 39 1/2
SGE285 (BR) 18 5/8 X 28 1/4
SGE290 (BR) 28 3/8 x 41 7/8
SGE298 18 3/4 X 28 7/16
Q&R
SCS50 23 1/32 x 38 19/32
SCS51 13 5/16 x 23 1/32
S
SGE104 26 7/16 X 48
SGE105 26 7/16 X 55
SGE106 13 15/32 X 26 7/16
SGE107 26 7/16 X 40 3/4
SGE111 29 X 39 3/8
SGE112 19 1/2 X 28 7/8
T
SAD38 20 5/8 X 58 1/2
SAD51 26 7/8 X 38 3/4
SAD52 23 X 50 7/8
SAD53 26 7/8 X 55 1/8
SAD54 27 X 42 1/2
SAD55 22 15/16 X 41 1/2
SAD56 27 X 52 1/4
SAD77 15 11/16 X 28 1/8
SAD78 22 3/4 X 50 1/2
U
SGE116 18 3/4 X 28 5/8
SGE117 18 5/8 X 28 1/8
SGE118 28 1/2 X 41 5/8
SGE119 28 5/8 X 39 9/16
SGE164 29 1/2 X 51
SGE182 22 3/4 X 32 1/4
SGE205 21 5/8 X 27 3/4
SGE229 28 3/4 X 42 3/4
SGE266 25 1/2 X 35 1/4
SGE267 18 5/8 X 27 3/4
SGE268 15 1/8 x 25 3/8
SGE282 (BR) 25 1/2 X 35 1/4
SGE283 (BR) 15 1/8 x 25 3/8
SGE42 22 X 45 15/16
SGE517 KIT 67 X 67
SGE52 28 3/4 X 39 3/4
SGE5210 22 5/16 X 30 3/8
SGE55 15 1/2 X 28 5/8
SGE57 18 1/2 X 28 3/4
SGE76 26 3/8 X 51
SGE78 15 1/2 X 26 5/8
SGE79 26 1/2 X 35 1/8
SGE81 28 3/4 X 59 1/4
SGE82 28 3/4 X 66 1/4
SGE88 28 X 39 1/2
V
SAD74 19 1/8 X 32
SCS107 30 1/2 X 43
SCS114 16 3/4 X 30 5/8
SCS117 28 1/2 X 59
SGE279 22 5/8 X 53 1/2
SGE317 26 5/8 x 57 3/4
SGE550 22 3/4 X 34 1/2
SGI41 19 1/8 X 30 1/2
SGI43 16 1/2 X 27 5/8
SGI44 27 5/8 X 39
SGI46 30 1/4 x 41 1/2
SGI47 30 7/16 x 40 1/8
SWC10 (TN) 27 1/2 x 43 1/8
SWC11 (TN) 16 1/2 X 27 1/2
SWC12 (TN) 30 3/8 X 44 1/8
SWC13 27 1/2 X 38 7/8
SWC14 13 1/2 X 27 3/8
SWC20 16 11/16 X 27 5/8
SWC21 27 5/8 X 43
SWC22 30 5/8 X 44
SWC23 13 1/2 X 21 1/2
SWC24 16 5/8 X 30 1/2
SWC25 17 1/2 X 30 3/8
SWC26 27 3/4 X 44
SWC32 (TN) 17 1/2 X 60 3/4
SWC33 11 3/4 X 60 3/4
SWC34 (BR) 16 5/8 X 30 1/2
SWC35 (TN) 30 1/2 X 57 5/8
SWC36 (TN) 14 5/8 X 60 3/4
SWC37 (TN) 19 1/2 X 60 5/8
SWC38 (TN) 11 3/4 X 60 5/8
SWC39 (TN) 17 5/8 X 60 3/4
SWC41 (BR) 27 1/2 X 44
SWC42 17 3/4 X 30 1/4
SWC43 19 1/4 X 30 3/8
SWC44 19 1/4 X 30 3/8
SWC45 (TN) 16 5/8 X 30 1/2
SWC48 (TN) 11 13/16 X 39 3/4
SWC49 (TN) 11 13/16 X 19 I/4
SWC51 (TN) 30 1/4 X 41 1 /4
SWC52 17 5/8 X 60 7/8
SWC53 14 7/16 X 60 3/8
SWC54 (TN) 27 5/8 X 53 5/8
SWC55 (BR) 16 11/16 X 27 5/8
SWC58 (BR) 27 5/8 X 43
SWC59 30 1/2 X 44
SWC60 (BR) 30 5/8 X 44 3/16
SWC61 29 X 43 7/8
SWC62 14 1/4 X 22 1/4
SWC63 22 1/4 X 37 1/2
SWC64 16 5/8 X 29
SWC65 (BR) 27 1/2 X 39 3/4
SWC66 27 1/2 X 39 3/4
SWC69 (BR) 27 3/4 X 43 1/8
SWC71 (TN) 27 1/2 X 43 3/4
X
SWE55 28 7/8 X 57 31/32
SWE56 16 1/8 X 28 15/16
SWE57 29 X 41 9/16
SWE58 28 7/16 X 55
SWE59 23 X 53
SWE60 24 3/4 X 31 1/2
SWE61 32 X 34 1/32
7
VISUAL IDENTIFICATION CHART
C
AE AF AG
AD
AK ALAJ
AH
8
AM
Each Part No. comes individually packaged and comes in a length of 14'
(unless otherwise indicated)
UNIVERSAL GASKET MATERIAL
9
Installation Tips
Pre- Installation Tips for Magnetic Gaskets
• Clean cabinet seal surface and any food reserve left under the old gasket.
• Allow the gasket to reach room temperature before removing from carton.
• When carrying or handling gasket, carry it by the corners to prevent breakage of the internal magnetic tape.
• For those refrigerators using a three-sided magnetic gasket, always install as removed, the balloon side (non-magnetic) to the hinge side
of the refrigerator.
Removing Defective Door Gasket and Installing New
• Before removing defective gasket determine how it is secured by pulling back on the inner edge of gasket. (Figures1 and 2 below).
Below are listed some of the methods employed.
• Procedure A - Retainer Mount - See Figure 1
Step 1. Where metal retainers are used loosen screws across top and half way down each side. Loosen only enough to enable
the gasket to be pulled out of the retainer. Start to remove gasket across top, then each side to point where screws are
still secure.
Step 2. Take new gasket and starting at the top of the door, slip the lip of the gasket under the retainer. Continue down each
side until you reach the point where old gasket is still retained.
Step 3. Tighten screws across top and down each side to about 2 screws above the old gasket.
Step 4. Loosen lower screws to remove remaining old gasket.
Step 5. Install remaining secton of new gsket and tighten screws.
• You should now be able to close the door and check for alignment. If door alignment is necessary, loosen slightly all the retainer screws
and flex the door in opposite direction to ensure proper door seal contact when closed. When properly aligned, grasp edge of door
about mid-point and slowly open door as to not warp, and re-tighten all screws. On some doors the hinge side seal may tend to roll as it
closed against the cabinet shell. In production, petroleum jelly (e.g. Vaseline)is used on hinge side of the gasket surface to allow door
gasket to slide into place. Petroleum jelly can also be applied on the new gasket to correct such a condition.
•Procedure B - Panel Mount - See Figure 2
Step 1. Where screws or clips are used without metal retainers, the above steps can be followed. However screw or clips have
to be removed step by step where they were only loosened on retainer style. Replace gasket as above and tighten top
screws and top sides before removing lower and bottom screws.
Step 2. Follow procedure A - Steps 4 and 5.
Non-Magnetic Gasket Installation - See Figure 3
• This gasket design is used on mechanical latch type doors and requires the same installation procedures as in either A or B depending
on whether it's a retainer or panel mount.
10
IMPORTANT INFORMATION
This carton has been designed for this gasket to minimize deformity and yet provide a
Suitable package that is acceptable for parcel post shipment, plus providing convenience
And ease of storage and handling. Allow the gasket to attain room temperature before
Removing from the carton.
RESTORING DEFORMED GASKETS
If a gasket is found to be deformed after a long storage, heat the deformed sections within
a pan of hot water or with an electric heater, hair dryer, or a 150 to 300 watt light bulb.
Move the source of heat back and forth over the deformed sections to maintain even warming, maintaining a distance three (2)
to four (4) inches between the gasket and heat source. Continue applying the heat until the gasket resumes its original shape.
Also reshaping the warm gasket by hand will speed-up the process.
It should be noted that this same procedure may be used to correct deformed gaskets already installed on a unit providing
caution is used not to damage the inner door panel.
PROPER HANDLING OF MAGNETIC GASKETS
Allow the gasket to reach room temperature before removing it from the carton. When carrying or handling the gasket, carry it
by the corners to prevent breakage of the flexible magnet. SHOULD THE MAGNET BE FOUND TO BE BROKEN, IT WILL NOT
IMPAIR ITS EFFECTIVENESS.
When a gasket with magnet on three sides balloons section on the fourth side is installed on the door, be sure the balloon
section is on the hinge side.
11
F 249-1002
SEALED UNIT PARTS CO., INC.
PO Box 21, 2230 Landmark Place, Allenwood, NJ 08720 USA
Phone: 1-800-333-9125 (732) 223-6644 Fax: 1-800-458-2818 (732) 223-1617
Edition 101
Table of contents
