suvil I-T Click Click BT User manual

| I-T Click Click BT |
User guide

| I-T Click Click BT | User Guide 2
Items included
System Requirements
Charging the battery
Synchronising the Bluetooth software
Starting the IT Click, Click BT
Positioning the Mouse and fingers
Side mini LED signals
Specifications
Important information
Index
ENGLISH

| I-T Click Click BT | User Guide 3
Items included
Battery recharging cable “mini-USB male -
USB male” and extension for Desktops “USB
female - USB male”.
System Requirements
- Windows 98, ME, 2000, Server 2003, XP,
Windows Vista and Macintosh Mac OS 10.2.8
or later.
- USB port for recharging the battery.
- Bluetooth hardware (with software).
- Bluetooth software manufacturers:
Widcomm (recommended), IVT, or that
included by Microsoft (Widcomm) in recent
operating systems.
Charging the Battery
The first time you use the IT Click, Click BT,
connect the USB cable to the mouse and
your computer (if necessary, also connect
the USB extension). Charge it fully to make
the battery last longer; this process may
take about 4 hours.
Synchronising the Bluetooth
Software
The first time you install your IT Click, Click
BT mouse, you will need the help of another
mouse or Touchpad (of a laptop).
First make sure that your computer has
Bluetooth software installed (and that this
has its corresponding Bluetooth hardware).
If you use a Bluetooth USB dongle on your
desktop, the Bluetooth software has to
be previously installed. If possible, use
Widcomm Bluetooth software, which is the
Bluetooth software that Microsoft uses. It is
very important to have the latest versions of
Widcomm or IVT.
Suvil manufactures only the Bluetooth
mouse. This manual helps to synchronise
the IT Click, Click BT with the Bluetooth
software manufacturers. However, you
should preferably have some experience
with the installation, synchronisation
and handling of these programs, or have
someone experienced nearby, to give you a
hand if necessary.
Step 1. Turn on the IT Click, Click BT and
switch the multifunction button to ON
(located at the bottom of the mouse). This
button is used to switch the mouse “ON”
or “OFF” and to synchronise it with the
computer Bluetooth software when you
press the multifunction switch.
Step 2. Connecting the IT Click, Click
BT with its USB Bluetooth dongle or the
Bluetooth hardware on your laptop:
Press the multifunction button (underneath
the mouse) and hold for about 2 or 3
seconds until the red LED sensor mouse
(located below the mouse) changes
continuously from a bright light “ON”
to weak light “ON” to no light “OFF”.
The IT Click, Click BT will then be in
synchronisation mode and will stay in this
mode for about two minutes.
Step 3. Synchronisation or Pairing
Procedure:
A: Synchronisation with Widcomm
software (recommended)
A1. Make sure you have the Widcomm
software installed and that the Bluetooth
function in your computer is turned on (in
| I-T Click Click BT | User Guide 3
Items included
Battery recharging cable “mini-USB male -
USB male” and extension for Desktops “USB
female - USB male”.
System Requirements
- Windows 98, ME, 2000, Server 2003, XP,
Windows Vista and Macintosh Mac OS 10.2.8
or later.
- USB port for recharging the battery.
- Bluetooth hardware (with software).
- Bluetooth software manufacturers:
Widcomm (recommended), IVT, or that
included by Microsoft (Widcomm) in recent
operating systems.
Charging the Battery
The first time you use the IT Click, Click BT,
connect the USB cable to the mouse and
your computer (if necessary, also connect
the USB extension). Charge it fully to make
the battery last longer; this process may
take about 4 hours.
Synchronising the Bluetooth
Software
The first time you install your IT Click, Click
BT mouse, you will need the help of another
mouse or Touchpad (of a laptop).
First make sure that your computer has
Bluetooth software installed (and that this
has its corresponding Bluetooth hardware).
If you use a Bluetooth USB dongle on your
desktop, the Bluetooth software has to
be previously installed. If possible, use
Widcomm Bluetooth software, which is the
Bluetooth software that Microsoft uses. It is
very important to have the latest versions of
Widcomm or IVT.
Suvil manufactures only the Bluetooth
mouse. This manual helps to synchronise
the IT Click, Click BT with the Bluetooth
software manufacturers. However, you
should preferably have some experience
with the installation, synchronisation
and handling of these programs, or have
someone experienced nearby, to give you a
hand if necessary.
Step 1. Turn on the IT Click, Click BT and
switch the multifunction button to ON
(located at the bottom of the mouse). This
button is used to switch the mouse “ON”
or “OFF” and to synchronise it with the
computer Bluetooth software when you
press the multifunction switch.
Step 2. Connecting the IT Click, Click
BT with its USB Bluetooth dongle or the
Bluetooth hardware on your laptop:
Press the multifunction button (underneath
the mouse) and hold for about 2 or 3
seconds until the red LED sensor mouse
(located below the mouse) changes
continuously from a bright light “ON”
to weak light “ON” to no light “OFF”.
The IT Click, Click BT will then be in
synchronisation mode and will stay in this
mode for about two minutes.
Step 3. Synchronisation or Pairing
Procedure:
A: Synchronisation with Widcomm
software (recommended)
A1. Make sure you have the Widcomm
software installed and that the Bluetooth
function in your computer is turned on (in

| I-T Click Click BT | User Guide 4
B2. Click on the “Bluetooth” window and
select Add a Bluetooth device.
B3. Put the IT Click, Click BT in Sync mode;
see Step 2 of the manual.
B4. In the Bluetooth Setup window, click on
Next and wait until the system finds the IT
Click, Click BT Mouse, which will appear on
the Bluetooth Device Selection screen. Then
select the icon “Suvil I-T Click, Click BT” and
click on Next.
the taskbar, select the Bluetooth icon using
the side button of the IT Click, Click BT. In
the drop-down menu that appears, choose
Start Bluetooth device). Double-click on the
icon
and the Widcomm window My Bluetooth
Places will be displayed.
Follow the instructions from Section B2, as
the Microsoft Bluetooth driver is the same
as Widcomm.
(Note: The icon to open the Bluetooth
window is in the Task Bar, in the
Control Panel and in My Computer).
*Note: If you use a Bluetooth USB dongle
connector and install Widcomm Bluetooth
2.0 driver but do NOT load the EDR version,
a number of different screens will appear in
section B2. They are very intuitive to follow
and similar to those shown in section B2,
however there is one worth mentioning:
When you see the screen below, select
Don’t use a passkey and click on Next.
The system will automatically install the
Bluetooth driver.
B: Synchronisation with the Microsoft
BT software:
B1. Make sure the BT function of the
computer is on. Double-click on the
icon and the My Bluetooth Places
screen will be displayed.















| I-T Click Click BT | User Guide 5
B5. Finally, select Click here in the
Confirmation Required window. The IT
Click, Click BT will be synchronised with the
Bluetooth software on your computer and
ready to use.
C: Synchronisation with the IVT
Bluetooth software:
C1. Make sure the IVT software is
installed and that the computer Bluetooth
function is on. Put the I-T Click, Click BT
in Synchronisation mode (see Step 2 of
the manual). Open the My Bluetooth menu
and choose Bluetooth Device Discovery or
double click on the orange ball in the middle
of the screen.
C2. Click the IT Click, click BT mouse icon
then click on the side button of the mouse.
Select Refresh Services from the window
that appears.
(C3. Depending on the level of security on
your computer, you may have to follow this
intermediate step: Select the IT Click, click
BT mouse icon again plus another click of
the button on the side of the mouse. Select
Pair Device from the window that appears.
Another window appears, asking for the
password. Type in 0000 then OK.)
C4. From the IVT screen, select the IT Click,
Click BT mouse icon again. Click on the
side button of the mouse and a window will
be displayed. Click on Connect then select
Bluetooth Human Interface Device Service.
The Bluetooth driver will be automatically
installed.
Starting the I-T Click, Click BT
If, after pairing (or synchronising) your
mouse with your computer, you restart your
computer and the IT Click, Click BT does not
respond, click on the top mouse button to
re-activate it. The same applies if you turn









| I-T Click Click BT | User Guide 6
your computer on another time, or if you
have put the multifunction battery into the
OFF position to save the battery.
Positioning the Mouse and
fingers
The I-T Click, Click must be inclined at
an angle of 20 - 30º to its point, in the
direction of the laptop (your hand must not
be inclined, only the Mouse).
The thumb is placed on the side button, the
index finger on the upper button, the middle
finger on the small scroll wheel, the ring
finger slightly behind the small scroll wheel
and the little finger slightly behind the ring
finger. The distances between the ring and
little fingers will vary according to the size
of the user’s fingers and hand.
The correct positioning of the middle,
ring and little fingers mean the Mouse is
sufficiently well held and absorbs the lateral
force exerted when using the thumb to
press the side button, thereby preventing
the I-T Click Click from moving sideways.
1- You must rest the palm of your hand
on the desk (not on the mouse as with a
traditional mouse) and hold the mouse just
with your fingers (each one in its position).
The I-T Click, Click must be operated with
gentle movements of the wrist.
2- How to get rid of “the hand inertia”:
Once you have learnt how to Position,
Hold and Handle the I-T Click, Click, at the
beginning you will experience a problem
controlling the Mouse. This problem is
caused by “the hand inertia” brought about
by the habit acquired previously using much
heavier and larger mice than the Suvil (with
traditional mice the user applies a lot more
force to move them).
To avoid this “hand inertia” acquired
previously, you must start to handle the
I-T Click, Click very slowly to start with
(not getting nervous). Once your brain
has forgotten the old inertia you will move
the I—Click, Click very quickly because it is
very light as it has been manufactured with
polycarbonate plastic materials.
We have put a video on Youtube to help you
understand more intuitively how to handle
the I-T Click Click: http://www.youtube.com/
watch?v=sKrX3hDR2aU .
Mouse Status and Electrical
Consumption
Side mini LED signals
Mini LED dual colour
Charging the battery “Blue” when ON
Battery Charged Off
Battery Low Flashing “red”
Working Off
Status Consumption To start
At rest (without
moving for 30
seconds)
1-2 mA Move the mouse or click on the
top button
Stand-by
(without moving
for 5 min)
0.3 mA Click the top
button
Working 22 mA

| I-T Click Click BT | User Guide 7
Specifications
Type: Optical Mouse “Bluetooth” styled and
shaped with buttons on the top and at the side.
Resolution: Optical sensor Avago 5030
1000 CPI.
Bluetooth Transmission: Chipset
Broadcom 2042 - Bluetooth 2.0 Class 2.
Operating Frequency: 2.4 - 2.4835 GHz.
Operating distance: Up to 10 m (without
obstacles).
Precision: + 95%.
Battery: Li-ion 350 mA (more than 5
working days between charges).
Recharging the battery: Via USB.
Cable length: 1 m (mini USB male to USB
male), for laptop.
Extension cable length: 1 m (USB female
to USB male).
ON-OFF Switch/Synchronisation: At the
bottom of the mouse.
2-colour Mini LED: Red (low battery), Blue
(battery charging). Located on the side of
the mouse.
Dimensions: 11.2 x 38.3 x 24.8 mm.
Weight: 40 g.
Important information
- FCC radiation declaration:
1. This device complies with the FCC
regulations on radiation emissions.
2. The apparatus should not be placed near
a radio antenna or other devices as these
may interfere with its use.
More information at: www.suvil.com

| I-T Click Click BT | User Guide 8
Elementos incluidos
Requisitos del sistema
Carga de la batería
Sincronización del software BT
Activación del I-T Click, Click BT
Posicionamiento del Ratón y de los dedos de la mano
Indicaciones del mini LED lateral
Especificaciones técnicas
Notas importantes
Índice
ESPAÑOL

| I-T Click Click BT | User Guide 9
Elementos incluidos
Ratón I-T Click, Click BT , Cable de recarga
de la batería “mini USB macho – USB
macho” y cable alargador para ordenadores
de sobremesa “USB hembra – USB macho”.
Requisitos del Sistema
- Windows 98, ME, 2000, Server 2003, XP,
Windows Vista y Macintosh Mac OS 10.2.8 o
posterior.
- Puerto USB para recargar la batería.
- Hardware Bluetooth (con su software).
- Fabricantes de Software Bluetooth:
Widcomm (recomendado), IVT, o el incluido
por Microsoft (Widcomm) en sus últimos
sistemas operativos.
Carga de la Batería
La primera vez que vaya a utilizar el I-T
Click, Click BT conecte el cable USB al ratón
y a su ordenador (si se necesita, conecte
también el cable alargador USB) y cárguelo
completamente; esto hará que la batería
del mismo dure más tiempo; este proceso
puede durar unas 4 horas.
Sincronización del Software
Bluetooth
La primera vez que instale su ratón I-T Click,
Click BT, necesitará de la ayuda de otro
ratón o de un Touchpad (el que incorporan
los notebook).
Asegúrese primero que su ordenador
tiene instalado un software Bluetooth (y
que este tenga su hardware bluetooth
correspondiente). Si utiliza un Dongle USB
Bluetooth en su ordenador de sobremesa,
el software bluetooth tiene que estar
previamente instalado. Utilice si es posible
como software Bluetooth a Widcomm que es
a su vez el software Bluetooth que Microsoft
utiliza. Es muy importante disponer de las
últimas versiones existentes de Widcomm o
de IVT.
Suvil fabrica únicamente el ratón Bluetooth;
este manual ayuda a sincronizar el I-T Click,
Click BT con los fabricantes de software
Bluetooth del mercado, pero conviene
que Vd. tenga cierta experiencia en la
instalación, en la sincronización y en el
manejo de estos programas o que alguien
cercano a Vd. pueda echarle una mano si así
fuera necesario.
Paso 1. Encienda el I-T Click, Click BT
poniendo el botón multifunción en ON. (El
botón multifunción esta localizado en la
parte inferior del ratón). Este botón sirve
para encender “ON”, para apagar “OFF” y
para sincronizar el mismo con el software
Bluetooth del ordenador cuando pulsamos el
conmutador multifunción.
Paso 2. Conectando el I-T Click, Click
BT con su Dongle USB Bluetooth o con
el hardware Bluetooth de su notebook:
Pulse y mantenga pulsado durante unos 2
ó 3 segundos el botón multifunción (el que
esta debajo del ratón) hasta que el LED rojo
del sensor del ratón (el que esta debajo
del ratón) cambie intermitentemente de
estar con luz fuerte “ON” a luz débil “ON”
a estar sin luz “OFF”. Entonces el I-T Click,
Click BT estará en modo Sincronización. El
I-T Click, Click BT permanecerá en modo
Sincronización durante unos dos minutos
aproximadamente.
| I-T Click Click BT | User Guide 3
Items included
Battery recharging cable “mini-USB male -
USB male” and extension for Desktops “USB
female - USB male”.
System Requirements
- Windows 98, ME, 2000, Server 2003, XP,
Windows Vista and Macintosh Mac OS 10.2.8
or later.
- USB port for recharging the battery.
- Bluetooth hardware (with software).
- Bluetooth software manufacturers:
Widcomm (recommended), IVT, or that
included by Microsoft (Widcomm) in recent
operating systems.
Charging the Battery
The first time you use the IT Click, Click BT,
connect the USB cable to the mouse and
your computer (if necessary, also connect
the USB extension). Charge it fully to make
the battery last longer; this process may
take about 4 hours.
Synchronising the Bluetooth
Software
The first time you install your IT Click, Click
BT mouse, you will need the help of another
mouse or Touchpad (of a laptop).
First make sure that your computer has
Bluetooth software installed (and that this
has its corresponding Bluetooth hardware).
If you use a Bluetooth USB dongle on your
desktop, the Bluetooth software has to
be previously installed. If possible, use
Widcomm Bluetooth software, which is the
Bluetooth software that Microsoft uses. It is
very important to have the latest versions of
Widcomm or IVT.
Suvil manufactures only the Bluetooth
mouse. This manual helps to synchronise
the IT Click, Click BT with the Bluetooth
software manufacturers. However, you
should preferably have some experience
with the installation, synchronisation
and handling of these programs, or have
someone experienced nearby, to give you a
hand if necessary.
Step 1. Turn on the IT Click, Click BT and
switch the multifunction button to ON
(located at the bottom of the mouse). This
button is used to switch the mouse “ON”
or “OFF” and to synchronise it with the
computer Bluetooth software when you
press the multifunction switch.
Step 2. Connecting the IT Click, Click
BT with its USB Bluetooth dongle or the
Bluetooth hardware on your laptop:
Press the multifunction button (underneath
the mouse) and hold for about 2 or 3
seconds until the red LED sensor mouse
(located below the mouse) changes
continuously from a bright light “ON”
to weak light “ON” to no light “OFF”.
The IT Click, Click BT will then be in
synchronisation mode and will stay in this
mode for about two minutes.
Step 3. Synchronisation or Pairing
Procedure:
A: Synchronisation with Widcomm
software (recommended)
A1. Make sure you have the Widcomm
software installed and that the Bluetooth
function in your computer is turned on (in

| I-T Click Click BT | User Guide 10
B: Sincronización con el software BT
que incorpora Microsoft:
B1. Asegúrese que la función BT del
ordenador ha sido activada. Haga doble
clic sobre el icono y se desplegará la
pantalla Mis sitios de Bluetooth “My
Bluetooth Places”.
B2. Haga clic sobre la ventana “Bluetooth” y
seleccione Agregar un dispositivo Bluetooth
”Add a Bluetooth Device”.
B3. (Ponga el I-T Click, Click BT en modo
Sincronización, Paso 2 del manual).
B4. En la ventana Configuración de
Bluetooth “Bluetooth Setup”, haga clic
sobre el botón Siguiente “Next” y espere
Paso 3. Procedimiento de
Sincronización o Emparejamiento:
A: Sincronización con el software de
Widcomm (recomendado):
A1. Asegúrese que tiene instalado el
software de Widcomm y que la función
Bluetooth del ordenador ha sido activada
(en la barra de tareas, seleccione con el
botón lateral del I-T Click, Click BT el icono
de Bluetooth; en la ventana desplegable
que aparecerá, elija Iniciar el dispositivo
Bluetooth para activarlo). Haga doble
clic sobre el icono y la ventana de
Widcomm Mis sitios de Bluetooth “My
Bluetooth Places” se desplegará.
Siga las instrucciones a partir del Punto B2:
ya que el driver Bluetooth de Microsoft es el
mismo que el de Widcomm.
(Nota: El Icono para abrir la ventana de
Bluetooth se encuentra en la Barra de
Tareas, en el Panel de Control y en Mi PC).
*Nota: Si Vd. Utiliza un conector Dongle
USB Bluetooth e instala el driver de
Widcomm Bluetooth 2.0 pero No carga
la versión EDR; le aparecerán algunas
pantallas distintas al punto B2:; éstas son
muy intuitivas de seguir y similares a las del
punto B2:, solo hay una que merece la pena
mencionar:
Cuando le aparezca la pantalla de abajo;
seleccione donde pone No utilice Password
”Don´t use a Passkey” y cliquee en
Siguiente “Next”. El sistema instalará
automáticamente el driver Bluetooth.
Bluetooth driver.










