Swarts Tools SW1075 User manual










 3

1. Keepyourworkareacleanandfreefromclutter.
2. Haveasafeworkingenvironmentwherethetoolisnotexposedtorainormoisture,thatiswelllitandthereare
noammablematerialsinthearea.
3. Guardyourselfagainstelectricalshockbyavoidingbodycontactwithearthedorgroundedsurfaces.
4. Allvisitorsorbystandersshouldbekeptatasafedistanceatalltimesandarenottotouchthetool,materialor
powersource.
5. Thistoolshouldbestoredinacool,dry,secureplace,disconnectedfromallpowersources.
6. Donotforcethistool.Cuttingataslowandsteadypacewherethesawisdoingalltheworkisnotonlysafer,it
willalsodoabetterjobandextendthetool’sworkinglife.
7. Thistoolisonlytobeusedfor,thepurposeslistedinthismanual.Misuseofthistoolisdangerousand
automaticallyvoidsallwarrantiesandguarantees.
8. Dressproperly.Donotwearloosehanginggarmentsorjewelleryasthismaygetcaughtinmoving 
components.Alwayswearahairnetforlonghair,rubberworkglovesandnon-skidfootweararerecommended
whenusingthistool.
9. Wearsafetyglasses,hearingprotectionandfaceordustmasksatalltimeswhenoperatingthissaw.
10. Thissawisttedwithadustextractionnozzle.Pleaseensurethatitishookedupcorrectlybeforeuse.
11. Nevercarrythissawbyitscordoryankitfromthepowerpoint.Keepthiscordawayfromsharpobjects,water
andoil.
12. Alwaysuseclampsorvicestosecuretheworkpieceyouarecutting.
13. Keeparmfootingandstaybalancedatalltimes.
14. Makesurethesawbladeiskeptsharpandcleanatalltimes.Pleasefollowallserviceinstructions
accurately.Donotattempttoservicethistool.TakeittoalicensedrepairerofSwartsTools.
15. Stayalert,watchwhatyouaredoingandusecommonsensewhenoperatingapowertool.Donotusetoolwhile
tiredorundertheinuenceofdrugs,alcoholormedication.Amomentofinattentionwhileoperatingpowertools
mayresultinseriouspersonalinjury.
16. Avoidaccidentalstarting.Ensuretheswitchisintheoff-positionbeforepluggingin.Carryingtoolswithyournger
ontheswitchorplugginginpowertoolsthathavetheswitchoninvitesaccidents.
17. Removeadjustingkeyorwrenchbeforeturningthetoolon.Awrenchorakeyleftattachedtoanymovingpartof
thetoolmayresultinpersonalinjury.

1) Powertoolplugsmustmatchtheoutlet.Nevermodifythepluginanyway.Donotuseanyadapterplugs
2) Don’texposepowertoolstorainorwetconditions.Waterenteringapowertoolwillincreasetheriskof
 electricshock.
3) Whenoperatingapowertooloutdoors,useanextensioncordsuitableforoutdooruse.Usingaofcordsuitablefor
 outdoorusereducestheriskofelectricshock.


4


1. Donotforcethepowertool,Usethecorrectpowertoolforyourapplication.Thecorrectpowertoolwilldothejob
betterandsaferattherateforwhichitwasdesigned.
2. Donotusethepowertooliftheswitchdoesnotturnitonandoff.Anypowertoolthatcannotbecontrolledwiththe
switchisdangerousandmustberepaired.
3. Disconnectthepowertoolplugfromthepowersourcebeforemakinganyadjustments,changing
accessoriesorstoringpowertools.Suchpreventivesafetymeasuresreducetheriskofstartingthepower
toolaccidentally.
4. Storeidlepowertoolsoutofthereachofchildrenanddonotallowpersonsunfamiliarwiththepowertoolorthese
instructionstooperatethepowertool.Powertoolsaredangerousinthehandsofuntrainedusers.
5. Maintainpowertools.Checkformisalignmentorbindingofmovingparts,breakageofpartsandanyother
conditionthatmayaffectthepowertool’soperation.Ifdamaged,havethepowertoolrepairedbeforeuse.Many
accidentsarecausedbypoorlymaintainedpowertools.
6. Usethepowertool,accessoriesandtoolbits,etc.inaccordancewiththeseinstructions,takingintoaccountthe
workingconditionsandtheworktobeperformed.Useofthepowertoolforoperationsdifferentfromthose
intendedcouldresultinahazardoussituation.

1. Donotattempttoremovejammedorexcessmaterialwhilethebladesarestillspinningandthesawispluggedin.
2. Alwayscheckthatthebladeguardisfunctioningproperlybeforeuse.Neverrestraintheguard.Iftheguardisstick-
ingornotretractingproperlydonotusethesaw.SendittoanauthorisedSwartsToolsRepairCentre.
3. Regularlyblowawayallsawdustanddebriswithcompressedairincludingintheguard.Ensurethesawisun
pluggedbeforestartingthisprocess.
4. Alwaysusethehandleprovidedtomovetheguardandonlywhennecessary.
5. Alwaysensuretheguardiscompletelyclosedbeforeplacingthetooldown.
6. Beawareatalltimesthatthebladeswillstillspinaftertheswitchisreleased.
7. Alwaysholdthesawbytheinsulatedgrippingsurface.Ifyoucontactpowerwiththesawandtheareholdingmetal
componentsthosecomponentswillbecomelive.
8. OnlyuseSwartsToolsbladesandaccessorieswiththissaw.Useofotherbladescancauseabladecollisionor
damage.
9. Alwaysensurewhencarryingortransportingthesawthatyoudonotcomeincontactwiththebladeevenifoff
10. Usethemachineonlyfordrycutting.Penetrationofwaterintothemachineincreasestheriskofanelectricshock.
11. Keephandsawayfromthesawingrange.
12. Donotreachundertheworkpiece.Contactwiththesawbladecanleadtoinjuries.
13. Usesuitabledetectorstodetermineifutilitylinesarehiddenintheworkareaorcallthelocalutilitycompanyfor
assistance.Contactwithelectriclinescanleadtoreandelectricshock.Damagingagaslinecanleadtoan
explosion.Penetratingawaterlinecausespropertydamageandmaycauseanelectricshock.
14. Keepyourworkpiececlean.Blendsofmaterialsareparticularlydangerous.Dustfromlightalloyscanburnor
explode.
15. Donottreatthesurfacetobeworkedwithsolvent-containinguids.


 5

FURTHERSAFETYINSTRUCTIONSFORALLSAWS-Kickbackcausesandrelatedwarnings
Causesandoperatorpreventionofkickback:
• Kickbackisasuddenreactiontoapinched,boundormisalignedsawblade,causinganuncontrolledsawtoliftup
andoutoftheworkpiecetowardtheoperator;
• Whenthebladeispinchedorboundtightlybythekerfclosingdown,thebladestallsandthemotorreactiondrives
theunitrapidlybacktowardtheoperator;
• Ifthebladebecomestwistedormisalignedinthecut,theteethatthebackedgeofthebladecandigintothetop
surfaceofthewoodcausingthebladetoclimboutofthekerfandjumpbacktowardtheoperator.Kickbackisthe
resultofsawmisuseand/orincorrectoperatingproceduresorconditionsandcanbeavoidedbytakingproper
precautionsasgivenbelow.
1. Maintainarmgripwithbothhandsonthesawandpositionyourarmstoresistkickbackforces.Position 
yourbodytoeithersideoftheblade,butnotinlinewiththeblade.Kickbackcouldcausethesawtojump 
backwards,butkickbackforcescanbecontrolledbytheoperator,ifproperprecautionsaretaken.
2. Whenabladeisbinding,orwheninterruptingacutforanyreason,releasethetriggerandholdthesaw 
motionlessinthematerialuntilthebladecomestoacompletestop.Neverattempttoremovethesawfrom 
theworkorpullthesawbackwardwhilethebladeisinmotionorkickbackmayoccur.Investigateandtake 
correctiveactiontoeliminatethecauseofbladebinding.
3. Whenrestartingasawintheworkpiece,centrethesawbladeinthekerfandcheckthatsawteethare
 notengagedinthematerial.Ifthesawbladeisbinding,itmayorkickbackfromtheworkpieceasthesawis
restarted.
4. Supportlargepanelstominimisetheriskofbladepinchingandkickback.Largepanelstendtosagunder 
theirownweight.Supportsmustbeplacedunderthepanelonbothsides,nearthelineofcutandnearthe 
edgeofthepanel.
5. Donotusedullordamagedblades.Unsharpenedorimproperlysetbladesproducenarrowkerfcausing 
excessivefriction,bladebindingandkickback.
6. Useextracautionwhenmakinga“plungecut”intoexistingwallsorotherblindareas.Theprotrudingblade 
maycutobjectsthatcancausekickback.
7. Whenrestartingacutthathasalreadybeenstartedensureyouareinthemiddleofthekerfandthebladecanspin
freely
8. Alwayssupportbothsidesofthejob,ifthejobbendstowardsthesawunderitsownweightitwilljam.
9. Alwaysknowwhatisbehindtheareayouarecuttingasyoumaycomeincontactwithsomethingontheotherside.
10. Mostimportantly,usecommonsense,ifyoufeelyoushouldn’tbeusingitthewayyouareorifyouareunsureof
whatyouaredoingthendon’tdoit.PleasecalloremailtheSwartsToolssupportteamandwecanclarify.


6


1. Donotletfamiliaritywiththetoolmakeyourelaxtherules;itonlytakesafractionofasecondforsomethingtogo
wrong.
2. Alwaysletthebladesgettofullspeedbeforecommencingcutting.
3. Alwaysensurethatbothbladescontactthejobatthesametime.
4. Thesideofthebladecannotbeusedforcutting.

ThisSawissuppliedwithTCTsawbladesthatareonlyintendedforuseonMetal,WoodandPlastic.Ifyouareusingthe
DiamondbladestheymayonlybeusedforcuttingStoneandCeramics.

1. Alwaysusethissawaccordingtotheinstructionsinthemanual
2. Neverplacethesawonapieceofthematerialthatwillfalloffoncecut
3. Alwaysusethewaxstripsprovided.
4. Allby-standersmustbeaminimumof5metresawayunlessyouhaveanapprovedbarrierbyWHSstandards


 7

Spec 125mm Twin Saw 155mm Twin Saw
Voltage 240V50Hz 240V50Hz
MotorOutput 860W 1010W
BladeSize 125mm 155mm
VariableSpeed 3000–5500RPM 3000–5500RPM
Weight 3KG 3.5KG
SoundPressureLevel 95dB(A) 95dB(A)
MaxCut 30mm 45mm
Warning:HearingProtectionshouldbewarnatalltimeswhenoperatingthistool.
SW1075 SW1080
Material Speed Grade Maximum Material Thickness Maximum Material Thickness
Plastic 1To4 30mm 45mm
Steel 4To6 5mm(3mmwallthicktubing) 5mm
Wood 4To6 30mm 45mm
Aluminium 5To6 5mm 5mm
Ceramics&Stone 6 25mm 40mm

Speedistherateyoupushthesawthroughthematerialyouarecutting.
Speedisdeterminedbythedensity,thicknessandtypeofmaterialbeingcut.
Refertopicture6whencuttingmaterialslessthan5mmthick,feedthebladesinwithadownwardsmotionuntilthe
bladesprotrude10to12mmouttheotherside.
Ifthespeedistoolowthebladeswillonlypressdownonthematerialratherthancutit.
Ifthespeedittoofastthiswillcauseanoverload,whichwillresultindamagetotheblades.


Itisimportantthatyouusethecorrectbladespeedwhenusingthissaw.Youmustuseappropriatespeedsfordifferent
materialsandthicknesses.
Always follow the guide below:
Note:Ifyoufeelyourmotorisstrugglingwithsomematerials,assomeareharderthanothersyoumayneedtoincrease
thecuttingspeed.
Operating Instructions:
Protectthesawbladesagainstshock.Guidethemachinewithanevenpressureinastraightcuttingdirection.Forcing
thesawwillsignicantlyreducethelifeofbothofthebladesandthesawandreducethequalityofthecut.


8


Tostartthemachine,rstpushtheSwitchlockbuttonandthenpresstheSwitchTrigger,keepingitpressedin.
(Pleaseseethepicturebelow)
Toswitchoffthemachine,releasetheSwitchTrigger.
Note:Forsafetyreasons,theSwitchTriggercannotbelocked;itmustremainpressedinduringtheentireoperation.
VariableSpeedSwitch
SwitchTrigger
SwitchLock

1.LowerGuard 4.Switch  7.DustExtractor  10.LubricationFeedWheel
2.BladeBolt 5.VariableSpeedswitch8.FrontHandle  11.FixedGuard
3.SawBlades 6.DustCap 9.SpindleLock
AllenKey
5 6
4
7 8
9
10
11
1
2
3



 9


INSTRUCTION FOR CUTTING
VARIOUS CROSS SECTION MATERIALS

Note: ALWAYS use the lubricating device (included) when cutting Aluminum,
Copper, Stainless Steel & Cast Iron materials, because they have a tendency to
smear and adhere to the blades. But for normal steel plate and steel tube cutting
is no need.
If run out the lubrication sticks, the best way is add Lubricating oil (5W-20
or 5W-40) in the saw blade teeth area. It will help to get smooth cutting
surface and keep the blade teeth sharpening for all kinds of metal cutting.
15
Note:ALWAYSusethelubricatingsticks(included)whencuttingAluminium,Copper,StainlessSteel&CastIron
materials,becausetheyhaveatendencytosmearandadheretotheblades.Butfornormalsteelplateandsteeltube
cuttingthereisnoneed.
If run out the lubrication sticks, the best way is add Lubricating oil (5W-20 or 5W-40) in the saw blade tooth area.
It will help to get smooth cutting surface and keep the blade teeth sharp.
Aluminium & Copper


10

REPLACING / MOUNTING THE SAW BLADE
! WARNING Before any work on the machine itself, pull the mains plug.
When mounting the saw blade, wear protective gloves. Danger of injury when touching the saw
blade.
Only use saw blades that correspond with the characteristic data given in the operating
instructions.
Selecting a Saw Blade
An overview of recommended saw blades can be found at the end of this manual.
REMOVAL OF THE SAW BLADE ( Fig1, Fig2, Fig3, Fig4).
For removing the blades, it is best to place the machine with the blade B printing side facing the
user.
Loosening
Fig1 Fig2 Fig3
Fig4 Fig5 Fig6
Tightening
Fig7
16

WARNING Before commencing any work on the machine itself, disconnect the mains plug.
When mounting the saw blade, wear protective gloves, due to risk of injury.
Only use saw blades that correspond with the characteristic data given in the operating instructions.
REMOVAL OF THE SAW BLADE ( Fig1, Fig2, Fig3, Fig4).
Whenremovingtheblades,itisbesttoplacethemachinewithbladeBprintingsidefacingtheuser.

Unplug the power and allow the saw blade to cool down.
1. Pressthespindlelockbutton,lockthedrivingshaftwiththehelpofaspindlelockasinFig1.
2. UnscrewBladeboltwiththehelpofanAllenkeyinClockwiseDirectionasinFig2.
3. UnscrewtheBladeboltwithanAllenkeyturninginClockwiseDirection.
4. OpenthelowerguardasFig3.
5. Toremovethe2in1TwinBladePackfromthespindleasFig4.
6. OpenthelowerguardasinFig5.
7. Placethe2in1TwinBladePackontothespindleandrotatearoundthebladestomakesurethethreedriving
bossesonthebladestomatchthethreenotchesontheoutputspindle;whilethebladespackwellseated,rotate
thetwobladestogethercouldfeelthegearcollisionasFig5,Fig6.
8. PressspindlelockbuttonandwiththehelpofAllenkeytightentheBladeboltincounterclockwisedirectionas
Fig7.
9. ReleaseSpindlelockbuttonandturntheAllenkeytodrivethebladerotatingacoupleturns,ifthebladescan
rotatesmoothly;RemovetheAllenkey,themachineisreadyforyoutouse.


 11
LUBRICATION
All of the bearings in this tool are lubricated with a sufficient amount of high-grade lubricant for the
life of the tool under normal operating conditions. Therefore, no further lubrication is required.
LUBRICANT INSTRUCTIONS (Fig 1, Fig 2, Fig 3)
The blades are equipped with Dry Cut teeth. As a rule these need not be lubricated. However, in
extreme cutting conditions, cutting paste can be applied.
When cutting Aluminum/Copper/Stainless steel and cast iron, the lubricating device must always
be used. Identify the lubrication unit next to the laser guide as Fig 1.
Position the wax stick on to lubrication unit as in fig 2.
Before always starting a cut lower the Lubrication stick on to saw blade by turning the knob as in
Fig 3. We recommend that you buy Lubrication stick available from your nearest dealer.
IMPORTANT! The lubricating stick is added by turning the Feed wheel.
Fig 1 Fig 2 Fig3
18

Allofthebearingsinthistoolarelubricatedwithasufcientamountofhigh-gradelubricantforthelifeofthetoolunder
normaloperatingconditions.Therefore,nofurtherlubricationisrequired.

ThebladesareequippedwithDryCutteeth.Asaruletheseneednotbelubricated.However,inextremecutting
conditions,cuttingpastecanbeapplied.
WhencuttingAluminium/Copper/Stainlesssteelandcastiron,thelubricatingdevicemustalwaysbeused.Identifythe
lubricationunitnexttothelaserguideasFig1.
PositionthewaxstickontolubricationunitasinFig2.
Beforestartingacut,lowerthelubricationstickontosawbladebyturningtheknobasinFig3.Werecommendthatyou
buylubricationstickavailablefromyournearestdealer.
IMPORTANT!ThelubricatingstickisaddedbyturningtheFeedwheel.

Theservicingofatoolwithdoubleinsulationrequiresextremecareandknowledgeofthesystemandshouldbe
performedonlybyaqualiedservicetechnician.Forservice,werecommendthatyoureturnthetooltoourauthorised
ServiceCentreforrepair.
ALWAYSuseoriginalfactoryreplacementpartswhenservicing.

Theuseofanyextensioncordwillcausesomelossofpower.Tokeepthelossataminimumandtopreventoverheating,
useanextensioncordthatisheavyenoughtocarrythecurrentthatthetoolwilldraw.


12


IMPORTANT
The servicing of a tool with double insulation requires extreme care and knowledge of the system
and should be performed only by a qualified service technician. For service, we recommend that
you return the tool to our authorized Service Center for repair.
ALWAYS use original factory replacement parts when servicing.
EXTENSION CORDS
The use of any extension cord will cause some loss of power. To keep the loss at a minimum and
to prevent overheating, use an extension cord that is heavy enough to carry the current that the
tool will draw.
PROBLEM SHOOTING
PROBLEM CAUSE SOLUTION
1. Damaged teeth 1. Replace blades
2. Feed speed is too fast 2. Reduce the feed speed
An unusually
large amount
of sparks 3. Blunt teeth 3. Replace blade pack
1. Feed speed is too fast 1. Reduce the feed speed
2. Damaged teeth 2. Replace blade pack
3. Blunt teeth 3. Replace blade pack
A lot of wear
in sections 4. Not cutting parallel or
perpendicular to work surface 4 Hold saw parallel to work surface
1. Damaged teeth 1. Replace blade pack
2. Feed speed is too fast 2. Reduce feed speed
3. Speed selected too high 3. Lower the speed grade
4. Blunt teeth 4. Replace blade pack
5. Blades have buckled 5. Replace blade pack
Blades are
breaking
6. Blades have burned out 6. Replace blade pack
1. Teeth badly broken or worn off 1. Replace blade pack Blades Split
off 2. Blunt teeth 2. Replace blade pack
19


 13

MaintenanceandCleaning
Beforecommencinganyworkonthemachineitself,disconnectthemainsplug.
Forsafeandproperworking,alwayskeepthemachineandventilationslotsclean.
Theretractingbladeguardmustalwaysbeabletomovefreelyandretractautomatically.
Therefore,alwayskeeptheareaaroundtheretractingbladeguardclean.Removedustandchipsbyblowingoutwith
compressedairorwithabrush.
Sawbladesthatarenotcoatedcanbeprotectedagainstcorrosionwithathincoatofacid-freeoil.Beforeuse,theoil
mustberemovedagain;otherwisethewoodwillbecomesoiled.
Resinandglueresidueonthesawbladeproducespoorcuts.Therefore,cleanthesawbladeimmediatelyafteruse.
Ifthemachineshouldfaildespitethecaretakeninmanufacturingandtestingprocedures,repairshouldbecarriedoutby
anauthorisedservicecentre.


Haveyourpowertoolservicedbyaqualiedrepairpersonusingonlyidenticalreplacementparts.Thiswillensure
thatthesafetyofthepowertoolismaintained.

Theproductiswarrantedtobefreefromdefectsinmaterialsandworkmanshipundernormaluseandserviceforape-
riodof24monthsfromthedateofsale.Thiswarrantycoversdefectivepartsandworkmanshipprovidedthattheproduct
isshippedpre-paidtothesellerwithin24monthsofpurchaseofgoods.Thiswarrantyislimitedtotherepairorreplace-
ment(atthemanufacturers’discretion)ofpartsandshippingprepaidtotheoriginaldespatchdestination.Weregret
thatnoliabilitycanbeacceptedforconsequentialorspecialdamagesofanykindhowsoeverarisinginconnectionwith
productssuppliedbytheseller.Thiswarrantyisinlieuofallotherwarrantiesexpressedorimplied.Norepresentativeis
authorisedtoassumefortheselleranyotherliabilityinconnectionwiththeseller’sproducts.


