Sylvania SB3713-OP User manual

37 INCH BLUETOOTH SOUNDBAR WITH OPTICAL
MODEL: SB3713-OP
READ THESE INSTRUCTIONS BEFORE USE AND RETAIN FOR FUTURE REFERENCE.
SYLVANIA is a registered trademark of OSRAM Sylvania Inc. used under license.

IMPORTANT SAFETY INSTRUCTIONS
DANGEROUS VOLTAGE: The lighting flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
ATTENTION: The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
FCC STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference that may
cause undesired operation. The antenna(s) used for this transmitter must be installed to
provide a separation distance of at least 8 ft. from all persons and must not be co-located
or operated in conjunction with any other antenna or transmitter.
FCC NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
CAUTION:TO REDUCE THE ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
2

-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
To assure continued operation, follow the attached installation instructions and use only
shielded cables when connecting to other devices. Changes or modifications not
expressly approved by the party responsible for compliance could void the user's authority
to operate the equipment.
WARNING:TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT
TO RAIN OR MOISTURE.
WARNING: USE UNDER SUPERVISION OF AN ADULT DUE TO LONG CORD.This
unit has a long cord that can be easily tripped on or pulled on, causing injury. Please make
sure it is arranged so that it will not drape over a tabletop, etc., where it can be pulled on
by children or tripped over accidentally.
-- Reorient or relocate the receiving antenna.
3
CAN ICES-3 (B)/NMB-3(B)
3
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation,
Science and Economic Development Canada’s licence-exempt RSS(s). Operation is
subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Industry Canada Notice
Avis d’lndustrie Canada
Cet appareil contient des émetteurs / récepteurs exemptés de licence conformes aux RSS
(RSS)d'Innovation, Sciences et Développement économique Canada. Le fonctionnement
est soumis aux deux conditions suivantes :
(1) Cet appareil ne doit pas causer d'interférences.
(2) Cet appareil doit accepter toutes les interférences, y compris celles susceptibles de
provoquer un fonctionnement indésirable de l'appareil.
Cet appareil numérique ne dépasse pas les Rélements sur I'interférence radio par un
appareil numérique de classe B stipulées dans les Réglement sur I'lnterférence redio
d'industrie Canada.
ISED RF Exposure statement
This equipment complies with ISED radiation exposure limits set forth for an uncontrolled
environment. In order to avoid the possibility of exceeding the ISED radio frequency
exposure limits, Human proximity to the antenna shall not be less than 20 cm (7.9 inches)
during normal operation.

safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments / accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of
time.
4
4
Before using the unit, be sure to read all operating instructions carefully. Please note that
these are general precautions and may not pertain to your unit. For example, this unit may
not have the capability to be connected to an outdoor antenna.
1. Read these instructions – All the safety and operating instructions should be read
before the appliance is operated.
2. Keep these instructions – The safety and operating instructions should be kept for
future reference.
3. Heed all warnings – All warnings on the appliance and in the operating instructions
should be adhered to.
4. Follow all instructions – All operation and use instructions should be followed.
5. Do not use this apparatus near water – The appliance should not be used near water;
for example, near a bath tub, washbowl, kitchen sink, laundry tub, in a wet basement,
or near a swimming pool.
6. Clean only with dry cloth – The appliance should be cleaned only as recommended
by the manufacturer.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions. The appliance should be situated so that its location or position does not
interfere with its proper ventilation. For example, the appliance should not be
situated on a bed, sofa, rug, or similar surface that may block the ventilation
openings; or placed in a built-in installation, such as a bookcase or cabinet that may
impede the flow of air through the ventilation openings.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades and a third grounding prong, which are provided for your
GENERAL SAFETY INSTRUCTIONS
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
15. This appliance should not be exposed to dripping or splashing water and no object
filled with liquids such as vases should be placed on the apparatus.
16. Power Sources – The appliance should be connected to a power supply only of the
type described in the operating instructions or as marked on the appliance. Do not
overload wall outlet.
17. Battery should not be exposed to excessive heat such as sunshine, fire, etc.
18. Replace remote control battery only with the same or equivalent type.

5
5
PLACEMENT AND MOUNTING
Placing the device on table - Ventilation
When placing the Sound Bar on an entertainment center, bookshelf, or any type of
enclosed space, be sure to allow at least 2-3 inches of space around the Sound Bar for
ventilation. If the Sound Bar is enclosed in a tight space, without ventilation, heat
generated from the Sound Bar could produce a potential heat hazard.
2-3inches
2-3inches
19. Do not attempt to dismantle, open or repair this product yourself. If a problem occurs,
seek advice from your local qualified service technician or contact the distributor at
the telephone number at the back of this instruction manual.
20. Caution marking and nameplate are located on back or bottom of product.
Mounting to a wall
1 Mounting to a wooden wall
A. Mark the position of the mounting screws on the wall using a pencil.
B. Drill the supplied screws directly into the marks that you have made on the wall and
leave approx. 0.3 inch length to hook the sound bar.
C. Put the sound bar onto the mounting screws. Make sure they are firm and stable.
24.9 inches

5
2 Mounting to a brick wall
A. Mark the position of the mounting screws on the wall using a pencil.
B. Drill 2 holes on wall with a powerful electric drill.
C. Insert the supplied fixing plug and hammer into the holes.
D. Secure the supplied screws into the fixing plugs and leave approx. 0.3 inch length to
hook the sound bar.
E. Put the sound bar onto the mounting screws. Make sure they are firm and stable.
24.9 inches
6

6
LOCATIONOF CONTROLS:
Front View
RearView
Top View
1. Indicator
2. Remote sensor
3. Speaker 3. Speaker
5. USB port 7. AUX 29.DC IN jack
10.Standby/Source button
11. FM Scan button
12. Volume down button
7
USB
4. Antenna 6. OPTICAL input
8.AUX 1
Vol+/REC.
13.Volume up/REC. button

REMOTE CONTROL
1. STANDBY button
2. VOL(Volume) - button
3. SOURCE button
8. (Previous)/TUNE-button
9. button
10. (Mute) button
14. (Next)/TUNE+button
1
2
3
4
5
8
9
10
11
14
7. EQ (Equalizer) button
11. VOL(Volume) + button
6
7
12
13
4. BASS down button
12. BASS up button
13. TREBLE up button
6. TREBLE down button
5. PAIR button
8

BATTERY (included)
- Before Using the Remote Control:
Remove the plastic tab as picture on the right.>>>
- To Replace battery
Battery precautions
Warning: Do not ingest battery, Chemical Burn Hazard.
This product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it
can cause severe internal burn in just 2 hours and can lead to death. Keep new and used
batteries away from children. If the battery compartment does not close securely, stop using
the product and keep it away from children. If you think batteries might have been
swallowed or placed inside any part of the body, seek immediate medical attention.
Follow these precautions when using a battery in this device:
1. Use only the size and type of battery specified.
2. Be sure to follow the correct polarity when installing the battery as indicated in the battery
compartment. A reversed battery may cause damage to the device.
3. Do not mix different types of batteries together (e.g. Alkaline and Carbon-zinc) or old
batteries with fresh ones.
4. If the batteries in the device are consumed or device is not to be used for a long period of
time, remove the batteries to prevent damage or injury from possible battery leakage.
(Follow battery manufacturer's instructions.)
6. The batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
7. Clean the battery contacts and also those of the device prior to battery installation.
8.
5. Do not try to recharge the battery not intended to be recharged; it can overheat and
rupture.
RELE AS E
PUSH
OPEN
R2025
C
+
SN
Fig.1 Fig.2 Fig.3
1. Push and slide out the battery holder.
2. Replace the battery with a new CR2025 button cell as the polarity
marking facing upward.
3. Close the battery door.
9

GENERAL OPERATION
1. Connect the AC/DC adapter to the unit and wall outlet. The indicator will light up
in red, which indicates the unit is powered on and enters the standby mode.
Press the Standby/Source button on the unit or the SOURCE button on the remote
control repeatedly to switch to desired mode. The color of the indicator will turn to:
During Playback:
~ Press the VOL (Volume) + or - buttons on the unit or Remote Control to adjust
volume level as desired.
~ Press the EQ button on the Remote Control repeatedly to select your desired
EQ mode from MUSIC, TALK, MOVIE and STANDARD. Press and hold this
button to return the default EQ mode (MUSIC).
~ Press the (Mute) button on the Remote Control to turn off the sound. Press
again to resume.
When finished listening, press and hold the Standby/Source button on the unit or
press the button on the Remote Control to power OFF the unit and put in
standby mode.
Green.........................................................................FM Radio
Orange (green + red)......................................................AUX 1
Violet (blue + red)............................................................AUX 2
Blue............................................................................Bluetooth
3.
4.
5.
~ Press the BASS +/- buttons on the Remote Control to adjust the sound
level of bass.
~ Press the TREBLE +/- buttons on the Remote Control to adjust the sound
level of treble.
White (green + blue + red).................................................USB
10
Indigo (green + blue).............................................OPTICAL IN
2.Press the Standby/Source button on the unit or the button on remote control to
enter the play mode.
When the (Mute) button is pressed, the indicator will turn to white and blink
rapidly to imply that the unit has received the specified command and answer it
with the corresponding action. Press it again; the unit will turn back to normal
state. When any of the other buttons on the unit/remote control mentioned here
is pressed, the indicator on the unit will blink once and the unit will answer the
command with the corresponding action.

After searching and storing finished, press repeatedly the FM Scan button on
the unit or the button on the remote control to choose the desired station.
FM RADIO OPERATION
4. Press and hold the FM Scan button on the unit or the on the remote
control. When the indicator start to blink rapidly, release the button. Now the
unit starts searching available bands and storesthem automatically.
Press and hold the VOL+ or VOL-/REC. button on the unit, or press the
/TUNE+
or /TUNE- button on the remote control. When the indicator
blinks, release the button. The unit will start to search for radio stations.
Once a station is located, the unit will stop searching and start to play it. If
you want another one, repeat the operation to start a new search.
1.Power on the unit and enter the play mode as previously explained.
2. Press the Standby/Source button on the unit or the SOURCE button on
the remote control repeatedly until the indicator turns Green.
3.
11
Before listening to the radio, please unwind and extend FM antenna or relocate
the unit to get better reception.

BLUETOOTH PAIRING AND CONNECTION
For first time use or re-pairing, pair the unit to an external Bluetooth (BT) device
as follows:
1. Power on the unit and enter the play mode as previously explained.
Press the Standby/Source button on the unit or press the SOURCE button on
the Remote Control repeatedly until the color of the Indicator turns to Blue.
3. Power on the external BT Device and select Bluetooth to enter into search
mode. When SYLVANIA SB3713 appears from your devices list , click it to start
pairing.
After paired, the Blue Indicator will stop blinking.
If the passcode doesn't appear, see the instructions of the external BT device.
4.If you want to connect another BT device while playing, press "PAIR" Button on
remote control to disconnect this pairing, then connect another BT device
following above steps.
NOTE:
1.
2.
Normal operation after paired:
1. Power on the unit and select the playback source to BT as previously
explained.
2. Turn on the BT function of the external BT Device.
4. Play the music in the connected BT Device as usual.
5. During playback:
~ Press the
~ Press the
Press again to resume normal playback.
If the BT device asks for a password, input pairing code "0000" to confirm it to
connect to "SYLVANIA SB3713".
When the external BT Device searches the unit, The code
"SYLVANIA SB3713" will appear on the display of the external BT device.
3. Touch SYLVANIA SB3713 and wait a few seconds until the unit pairs to the
2.
/TUNE + or /TUNE - button to skip the tracks.
button or the FM Scan button on the unit on the remote control
external BT device automatically. The Blue indicator will stop blinking.
12
to pause.

3. Power on the unit and enter the play mode as previously explained.
on the Remote Control repeatedly until the color of Indicator turns to
5. Power on the connected external player and start playback as usual.
AUX 1: LISTEN TO TV/DVD/VCR/DVR
An external Video/Audio player (such as TV, DVD player, VCR, etc.) can be
connected to this unit and heard through the speakers.
2. Plug the other side of cable into Audio Out R & L jacks of the TV or external
device as the illustration below.
NOTE: Make sure to connect to AUDIO OUT. If you connect it into AUDIO IN of
external device, you will not hear the sound.
Rear view of the unit
1. Plug one side of RCA White and Red cable into the AUX 1 jacks on the rear
of the unit.
4. Press the Standby/Source button on the unit or press the SOURCE button
Orange.
Audio out jacks of
TV/DVD/VCR/DVR
13

14
TV; DVD player; BD player... etc.
2. Power on the unit and enter the play mode as previous explained
3. Press the Standby/Source button on the unit or press the SOURCE button on the
Remote Control repeatedly until the Indicator turns to Indigo.
4.
1.
Optical Connection Cable (not supplied)
Connect the Optical out jack from the external audio Player (including TV, DVD Player
BD Player, etc.) to the OPTICAL IN jack on the back of unit by the Optical Connection
Cable (not supplied) as the figure below: (For PCM format only)
Power on the connected external player and start to play music as usual. Turn on
the digital audio output and set it to PCM (Pulse Code Modulation) type as below:
Bass
Treble
Balance
Select Move MENU Exit
Sound Mode Standard
Surround Off
AVL Off
Audio Language English
Picture Time Setup Lock Off
AudioAudio
Digital Output PCMDigital Output PCM
OPTICAL DIGITAL AUDIO IN
Rear view of the unit
14
USB
(Only for demonstration. The actual view may a little differ.)

AUX 2: LISTEN TO EXTERNAL AUDIO DEVICE
An external (Auxiliary) audio source (i.e., personal CD player or MP3 player)
can be connected to this unit and heard through the speakers.
2. Plug the other end of the Aux In cable into the socket of the external audio
3. Power on the unit and enter the mode as previously explained.
5. Power on the connected external player and start playback as usual.
Audio
Player
To Audio Out Jack
Rear view of the unit
1. Plug one side of the Aux In cable into the AUX 2 jack on the rear of the unit.
on the Remote Control repeatedly until the color of Indicator turns to
4. Press the Standby/Source button on the unit or press the SOURCE button
Violet.
15
USB
source.

USB OPERATION
16
1. Insert the USB device to the USB Player port on the unit.
USB
Rear view of the unit
USB
1. Power on the unit and enter the mode as previously explained.
2. Press the Standby/Source button on the unit or press SOURCE button on the remote control
repeatedly to switch to desired mode.
3. When in playback, press and hold the Vol+/REC button on the unit or the Vol+ button on the
remote control until you hear a prompt tone, which indicates the recording process starts.
4. To stop recording, press and hold the Vol+/REC button on the unit or the Vol+ button on the
remote again. When hearing two beep tones, release the button.
•
NOTE:
The recorded tracks will be stored in USB device automatically.
•During the playback, you can press the button or the button on the remote control to
play the next or the previous recorded track, or the button to pause or play again.
•The recording function only works in BT, AUX and Line in mode.
•To play the record tracks, press the Standby/Source button on the unit or press SOURCE
button on the remote control repeatedly to switch to USB mode. It will start to play
2.Power on the unit and enter the mode as previously explained..
3.Press the Standby/Source button on the unit or press SOURCE button on the remote control
repeatedly until the color of Indicator turns to WHITE.
During the playback, you can press the button or the button on the remote control
(or press and hold the Vol- or Vol+/REC. button on the unit) to play the next or the
previous recorded track. Press the button on the remote control or the FM Scan
button on the unit to pause or play again.
•
NOTE:
The recorded tracks will be played first, then the music stored in the USB device.
4.
RECORDING OPERATION
This unit has Recording function. Please insert a USB device first when using this function.
automatically.

TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
No power Power AC/DC Adapter
not connected Connect the power AC/DC adapter
to the unit or wall outlet.
on the unit or button on the Remote
Control to turn on the unit from
Standby mode.
No sound Volume in minimum position Raise volume level by pressing the
VOL (Volume) + button.
The paired/connected device is not in
playback mode Play music/movie in the paired/ connected device as usual and make
sure the volume level of it is in high
level.
on the unit or SOURCE button on the
Remote Control repeatedly to set the
input source to the desired mode.
Sound distortion/rattle Volume level too high Reduce the volume level by pressing
the VOL (Volume ) - button.
Reduce the volume level of the
paired/connected device.
Remote Control not working The battery is weak Replace with new battery.
Bluetooth reception failure The external device is too far from the
unit Put the external BT device close to the
unit.
Have not paired Pair the unit with the BT Device as the
procedures stated in this manual.
Input source incorrect Press the Standby/Source button
Press the Standby/Source button
The unit is in standby mode
17

GENERAL SPECIFICATIONS
Power Input..................................................................AC 100-240V~; 50/60Hz
Power Output................................................................. DC12V 2A
Audio Power.............................................................................................10Wx2
Bluetooth Effective Range in Open Area.........................................Up to 32 feet
Remote Effective Range..................................................................Up to 16 feet
1 x AC/DC Adapter
1 x Remote Control
1 x Stereo Audio Connection Cable with 3.5mm stereo plugs
1 x RCA Cable
1 x User's Manual
2 x Plastic Inserts (For wall mounting)
2 x Metallic Screws (For wall mounting)
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT TO CHANGE
WITHOUT NOTICE
FM Frequency.............................................................................87.5-108.0MHz
18
For service assistance and product information, please call: 1-800-968-9853.
Curtis International Ltd.
7045 BECKETT DRIVE, UNIT 15, MISSISSAUGA, ON, L5S 2A3
www.curtisint.com

To make a warranty claim, please email [email protected] or call
1-800-968-9853.
90 day Year Warranty
This product is warranted to be free from defects in material and workmanship
for a period of ninety (90) days from the date of original purchase. During this
period, your exclusive remedy is repair or replacement of this product or
component found to be defective, at our option; however, you are responsible
for all costs associated with returning the product to us. If the product or
component is no longer available, we will replace with a similar one of equal or
greater value. Prior to a replacement being sent, the product must be rendered
inoperable or returned to us.
This warranty does not cover glass, filters, wear from normal use, use not
in conformity with the printed directions., or damage to the product resulting
from accident, alteration, abuse, or misuse. This warranty extends only to the
original consumer purchaser or gift recipient. Keep the original sales receipt, as
proof of purchase is required to make a warranty claim. This warranty is
void if the product is used for other than single-family household use or
subjected to any voltage and waveform other than as on the specified rating
on the label (e.g., 120V~60Hz).
We exclude all claims for special, incidental, and consequential damages
caused by breach of express or implied warranty. All liability is limited to the
amount of the purchase price. Every implied warranty, including any
statutory warranty or condition of merchantability or fitness for a
particular purpose, is disclaimed except to the extent prohibited by law, in
which case such warranty or condition is limited to the duration of this
written warranty. This warranty gives you specific legal rights. You may have
other legal rights that vary depending on where you live. Some states or
provinces do not allow limitations on implied warranties or special, incidental, or
consequential damages, so the foregoing limitations may not apply to you.
For faster service, locate the model, type, and serial numbers on your
appliance.

Barre de son Bluetooth 37’’
MODEL: SB3713-OP
LISEZ CES INSTRUCTIONS AVANT L’UTILISATION ET CONSERVEZ-LES POUR RÉFÉRENCE FUTURE.
SYLVANIA est une marque déposée de OSRAM Sylvania Inc. utilisée avec son autorisation.
