Pioneer PDP-S28-LR User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2004
RRV3007
T-ZZE SEPT. 2004 Printed in Japan
PDP-S28-LR
SPEAKER SYSTEM
XIN/E
FOR PRECAUTION OF
REASSEMBLY AND DISASSEMBLY
The grille is attached to the baffle by press-fitting. It is not able
to detach it.
The woofer is attached to the baffle by 4 internal screws.
To detach it, unfasten those screws. When attaching the
woofer, face its small terminal upward. Exchanging the woofer
for a new one,attach it after applying a cushion to woofer mag-
netic circut. Refer to “ PRODUCT APPEARANCE ”.
The tweeter is attached to the baffle by 2 internal screws.
To detach it, unfasten those screws. When attaching it, face its
downward.
The choke coil of the Network Assy is attached to the cabinet
by an internal screw with adhesive. To detach it, unfasten its
screw.
65S
This service manual is intended for qualified service technicians; it is not meant for the
casual do-it-yourselfer. Qualified technicians have the necessary test equipment and
tools, and have been trained to properly and safely repair complex products such as
those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability
of the product and may void the warranty. If you are not qualified to perform the repair
of this product properly and safely, you should not risk trying to do so and refer the
repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals
which are known to the state of California to cause cancer, birth defects or other
reproductive harm.
Health & Safety Code Section 25249.6 – Proposition 65

2
1234
1234
C
D
F
A
B
E
PDP-S28-LR
Metal Reinforce SNA1442
NSP Cabinet SNK2827
Baffle SNK2828
Grille ASSY SMG1827
NSP Grille Cloth SAS1578
NSP Grille Frame SMH1041
Network ASSY SWN1738
NSP Model Label (L) SAN3511
NSP Model Label (R) SAN3512
Flanged Anchor Bolt SBA1209
Serrated Flange Nut SBN1052
Packing (for Baffle,Cab,Terminal) SEB1228
NSP Packing (for Cabinet) SEB1229
NSP Packing (for Baffle,Cabinet) SEB1230
Cushion (for Woofer Magnet) SEB1231
NSP Packing (for Cabinet) SEB1233
Packing (for Cabinet) SEC1565
Packing (for Cabinet) SEC1566
Input Terminal KKX1015
NSP Acoustic Absorbent (for Cabinet) SMV2097
NSP Acoustic Absorbent (for Cabinet) SMV2098
NSP Acoustic Absorbent (for Cabinet) SMV2099
NSP Acoustic Absorbent (for Cabinet) SMV2100
Installation Board (R) SNK2570
Installation Board (L) SNK2571
NSP Label Serial (Model Label L,R) SRW1083
Speaker (Woofer) A142CU60-51F
Speaker (Tweeter) FK26AP13-55F
Screw (for Tweeter) APZ30P080FMC
Screw (for Input Terminal) BBZ35P140FMC
Screw (for Woofer) BPZ40P100FMC
Screw (for Baffle-Cabinet) BPZ40P160FZK
Screw (for NW Choke Coil) BPZ40P350FMC
Mark No. Description Part No.
For Packing
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
N
OTES:
PARTS LIST
Mark No. Description Part No.
Accessory Set SME3565
Speaker Wire SDS1171
NSP Screw Set SEA1563
Screw CMZ50P120FZK
Bolt SBA1210
Hexagon Wrench SEX1021
NSP Polyethylene Bag S1 SHL1304
Bracket SET SEA1608
NSP Polyethylene Bag S1 KHL1079
Bracket SNA1412
Bracket (R) SET SEA1609
NSP Polyethylene Bag S1 KHL1079
Bracket (R) SNA1413
Bracket (L) SET SEA1610
NSP Polyethylene Bag S1 KHL1079
Bracket (L) SNA1414
NSP Polyethylene Bag S2 SHL1309
NSP Installation Manual Set SME3564
NSP Polyethylene Bag S2 SHL1309
Operating Instructions SRD1275
(English,French,German,Italian,
Dutch,Spanish)
Protector SHA2324
Inner Partition SHD1049
Packing Case SHG2597
NSP Polyethylene Bag S2 SHL1307
NSP Label Serial SRW1087

3
1234
1234
C
D
F
A
B
E
PDP-S28-LR
SCHEMATIC DIAGRAM
Network ASSY (SWN1738)
Woofer
I N
Red
Red
Black
Blue
White
White
Tweeter
1.8µF/63V
1.0mH
L
C

4
1234
1234
C
D
F
A
B
E
PDP-S28-LR
PRODUCT APPEARANCE
>ABS<
20
11
28
25
24
11
26
12
11
RED
RED
WOOFER
BLACK
BLUE
WHITE
TEWEETER
8
5
21
3
27
13
1
17
2
9
11
5
18
15
10
29
11
4
19
9
22
23
11
14
7
6
5
16
17
No. Part No. Part Name Num. Remarks No. Part No. Part Name Num. Remarks
1
2
3
4
5
6
7
(7)
8
9
10
11
12
13
14
15
1
1
3
1
4
1
1
(1)
3
3
2
5
1
2
2
2
16
17
18
19
20
21
22
23
24
25
26
27
28
29
(29)
1
2
1
1
1
1
1
1
2
1
4
12
1
1
(1)
SNK2827
SNK2828
SNA1442
SMG1827
SEB1228
SWN1738
SAN3511
(SAN3512)
SBA1209
SBN1052
SEB1229
SEB1230
SEB1231
SEB1233
SEC1565
SEC1566
CABINET
BAFFLE
METAL REINFORCE
GRILLE ASSY
PACKING
NETWORK ASSY
MODEL LABEL(L)
MODEL LABEL(R)
FLANGED ANCHOR BOLT
SERRATED FLANGE NUT
PACKING
PACKING
CUSHION
PACKING
PACKING
PACKING
BAFFLE,TERMINAL,CABINET
CABINET
BAFFLE,CABINET
WOOFER MAGNET
CABINET
CABINET
CABINET
KKX1015
SMV2097
SMV2098
SMV2099
SMV2100
SRW1083
A142CU60-51F
FK26AP13-55F
APZ30P080FMC
BBZ35P140FMC
BPZ40P100FMC
BPZ40P160FZK
BPZ40P350FMC
SNK2571
(SNK2570)
INPUT TERMINAL
ACOUSTIC ABSORBENT
ACOUSTIC ABSORBENT
ACOUSTIC ABSORBENT
ACOUSTIC ABSORBENT
LABEL SERIAL
SPEAKER
SPEAKER
SCREW
SCREW
SCREW
SCREW
SCREW
INST.BOARD(L)
INST.BOARD(R)
WOOFER
TWEETER
TWEETER
INPUT TERMINAL
WOOFER
BAFFLE-CABINET
CHOKE COIL
