Symbol MicroKiosk MK1000 User manual

MK1000
MicroKiosk

MK1000
MicroKiosk
©2002 SYMBOL TECHNOLOGIES, INC. All rights reserved.
Symbol reserves the right to make changes to any product to improve reliability,
function, or design.
Symbol does not assume any product liability arising out of, or in connection with, the
application or use of any product, circuit, or application described herein.
No license is granted, either expressly or by implication, estoppel, or otherwise under
any patent right or patent, covering or relating to any combination, system,
apparatus, machine, material, method, or process in which Symbol products might
be used. An implied license exists only for equipment, circuits, and subsystems
contained in Symbol products.
Symbol and the Symbol logo are registered trademarks of Symbol Technologies, Inc.
Other product names mentioned in this manual may be trademarks or registered
trademarks of their respective companies and are hereby acknowledged.
Symbol Technologies, Inc.
One Symbol Plaza
Holtsville, N.Y. 11742-1300
http://www.symbol.com
Patents
This product is covered by one or more of the following U.S. and foreign Patents:
U.S. Patent No. 4,593,186; 4,603,262; 4,607,156; 4,652,750; 4,673,805; 4,736,095; 4,758,717;
4,760,248; 4,806,742; 4,816,660; 4,845,350; 4,896,026; 4,897,532; 4,923,281; 4,933,538;
4,992,717; 5,015,833; 5,017,765; 5,021,641; 5,029,183; 5,047,617; 5,103,461; 5,113,445;
5,130,520; 5,140,144; 5,142,550; 5,149,950; 5,157,687; 5,168,148; 5,168,149; 5,180,904;
5,216,232; 5,229,591; 5,230,088; 5,235,167; 5,243,655; 5,247,162; 5,250,791; 5,250,792;
5,260,553; 5,262,627; 5,262,628; 5,266,787; 5,278,398; 5,280,162; 5,280,163; 5,280,164;
5,280,498; 5,304,786; 5,304,788; 5,306,900; 5,324,924; 5,337,361; 5,367,151; 5,373,148;
5,378,882; 5,396,053; 5,396,055; 5,399,846; 5,408,081; 5,410,139; 5,410,140; 5,412,198;
5,418,812; 5,420,411; 5,436,440; 5,444,231; 5,449,891; 5,449,893; 5,468,949; 5,471,042;
5,478,998; 5,479,000; 5,479,002; 5,479,441; 5,504,322; 5,519,577; 5,528,621; 5,532,469;
5,543,610; 5,545,889; 5,552,592; 5,557,093; 5,578,810; 5,581,070; 5,589,679; 5,589,680;
5,608,202; 5,612,531; 5,619,028; 5,627,359; 5,637,852; 5,664,229; 5,668,803; 5,675,139;
5,693,929; 5,698,835; 5,705,800; 5,714,746; 5,723,851; 5,734,152; 5,734,153; 5,742,043;
5,745,794; 5,754,587; 5,762,516; 5,763,863; 5,767,500; 5,789,728; 5,789,731; 5,808,287;
5,811,785; 5,811,787; 5,815,811; 5,821,519; 5,821,520; 5,823,812; 5,828,050; 5,848,064;
5,850,078; 5,861,615; 5,874,720; 5,875,415; 5,900,617; 5,902,989; 5,907,146; 5,912,450;
5,914,478; 5,917,173; 5,920,059; 5,923,025; 5,929,420; 5,945,658; 5,945,659; 5,946,194;
5,959,285; 6,002,918; 6,021,947; 6,029,894: 6,031,830; 6,036,098; 6,047,892; 6,050,491;
6,053,413; 6,056,200; 6,065,678; 6,067,297; 6,082,621; 6,084,528; 6,088,482; 6,092,725;
6,101,483; 6,102,293; 6,104,620; 6,114,712; 6,115,678; 6,119,944; 6,123,265; 6,131,814;
6,138,180; 6,142,379; 6,172,478; 6,176,428; 6,178,426; 6,186,400; 6,188,681; 6,209,788;
6,209,789; 6,216,951; 6,220,514; 6,243,447; 6,244,513; 6,247,647; 6,308,061 6,250,551;
6,295,031; 6,308,061; 6,308,892; 6,321,990; 6,328,213; 6,330,244; 6,336,587; 6,340,114;
6,340,115; 6,340,119; 6,348,773; D305,885; D341,584; D344,501; D359,483; D362,453;
D363,700;D363,918;D370,478;D383,124;D391,250;D405,077;D406,581;D414,171;D414,172;
D418,500; D419,548; D423,468; D424,035; D430,158; D430,159; D431,562; D436,104.
Invention No. 55,358; 62,539; 69,060; 69,187 (Taiwan); No. 1,601,796; 1,907,875; 1,955,269
(Japan); European Patent 367,299; 414,281; 367,300; 367,298; UK 2,072,832; France 81/03938;
Italy 1,138,713
rev. 03/02

1
Quick Reference
Introduction
The MK1000 is a scanning system that allows retail shoppers to
easily verify prices on bar coded merchandise and obtain up-to-
the-minute information on in-store promotions -- while they shop.
The MK1000 does more than price verification. Its large easy-to-
read display can be used as an electronic billboard for instant in-
store merchandising and comes complete with the ability to
display graphicsand text messagesto promote seasonal sales, in-
store promotions, and upcoming events. The programmable
function buttons can enhance in-store applications and allow for
customer interaction.
About This Guide
This guide describes how toset up and use the MK1000. Specific
topics covered include:
•Parts of the MK1000 on page 2
•Function Buttons on page 3
•Reset Button and Contrast Control Button on page 3
•Bar Code Scanning on page 4
•Scanning Modes on page 4
•Specular Reflection on page 5
• Mechanical Setup and Installation on page 6
•Mounting the MK1000 on a Wall on page 7
•Configuring for Host Communication on page 8.

2
MK1000
MicroKiosk
Parts of the MK1000
Reset Button (R)
Contrast Control (C)
Lower Right Side
Mounting
brackets (4)
Back View
Front View
Function
Buttons (4)
Scan Window
Label Cover
Com/Scanner
Port
Power Port
LAN (Local Area
Network) Port

3
Quick Reference
Function Buttons
The MK1000 has four programmable function buttons. These
buttons can be programmed to allow the user to perform various
tasks such as navigating through an application and making
decisions when prompted.
Reset Button and Contrast Control Button
Reset Button
The Reset button can be used to reset the system. The Reset
button is located on the lower right-hand side of the unit and
marked with . Use a paper clip to push the switch.
Contrast Control Button
The display Contrast Control button is located below the Reset
button and marked with . Use the tip of a small screwdriver to
make contrast adjustments, if required.

4
MK1000
MicroKiosk
Bar Code Scanning
The MK1000 automatically decodes a bar code presented in its
field of view. It can decode all standard 1-dimensional bar codes
plus PDF, micro-PDF, and composite bar codes.
Scanning Modes
The MK1000 operates in a number of different scan modes. Two
of the most commonly used modes are described below.
Scan Mode Description
Cyclone Omnidi-
rectional 1D Scan
Pattern (factory
default)
This is a highly efficient scan pattern which decodes 1D and
EAN/UCC reduced space symbologies in any orientation
Note: While in this mode, the MK1000 does not decode 2D
bar codes like PDF.
Smart Raster
Scan Pattern Creates a single scan line which opens vertically for PDF- 417 symbols using the Smart Raster feature. This feature
autodetects the type of bar code being scanned and adjusts
its pattern accordingly. This provides optimal performance
on 1D, PDF-417, EAN/UCC, RSS and Composite Codes.

5
Quick Reference
Specular Reflection
When laser beams reflect directly back into the scanner from the
barcode,theycan“blind”thescannerandmakedecodingdifficult.
This phenomenon is called specular reflection.
To avoid this, scan the bar code so that thebeam does not bounce
directly back. But don’t scan at too oblique an angle; the scanner
needs to collect scattered reflections from the scan to make a
successful decode. Practice quickly shows what tolerances to
work within.
Reflected beam is
within specular dead
zone and prevents
decode.
Decode can occur.
Tilt Bar Code At Slight Angle (Up to 30°)
No Specular Reflection. Specular Reflection.

Top
Drill Holes Here
Drill Holes Here
Note: There must be a clearance of at least 9/16 of an inch (14.3 mm) between the center of the right side mount holes and the nearest object.
Mounting Template

6
MK1000
MicroKiosk
Mechanical Setup and Installation
TheMK1000canbeconnectedto ahostusingoneofthefollowing
four MK1000 communication interfaces.
See the Product Reference Guide (p/n 72-53977-XX) for cable
pinouts.
Communication Interface Description
Wireless Ethernet (2Mb or 11Mb RF)
• Power via AC outlet
• Power via Power-over-Ether-
net
The MK1000 can communicate with a
host via a wireless (RF) Ethernet con-
nection.
When communicating in this manner the
MK1000 can be powered either using
the MK1000’s power supply connected
to an AC outlet, or by receiving Power-
over-Ethernet via cable.
Wired Ethernet (10 Base-T cable
• Power via AC outlet
• Power via Power-over-Ether-
net
The MK1000 can communicate with a
host via a wired Ethernet connection
(10Base-T cable).
When communicating in this manner the
MK1000 can be powered either using
the MK1000’s power supply connected
to an AC outlet, or by receiving Power-
over-Ethernet through the Ethernet ca-
ble.
Wired RS-485 (Serial cable) The MK1000 can communicate with a
host via a wired RS-485 Serial connec-
tion while receiving power via a power
supply plugged into an AC outlet.
For MK1000 devices installed where
pre-existing PCK 9100 wiring exists, an
RS-485 pin-out converter can be used.
This pin-out converter maps the PCK
9100 signals into the required MK1000
pin-out and attaches to the existing PCK
9100 wiring, and then into the MK1000.
Wired RS-232 (Serial cable) The MK1000 can communicate with a
host via a Serial cable connected to the
Com/Scannerportwhile receiving power
via a power supply plugged into and AC
outlet.

7
Quick Reference
Mounting the MK1000 on a Wall
The MK1000 can be mounted on a wall, pole or counter top.
Separately sold mounting accessories are listed below.
• Wall Mount Kit
• Pole Mount Kit
• Counter Top Stand
The MK1000 can also be mounted without the accessories listed
above. To mount the MK1000 on a wall without using the wall
mount kit, follow the instructions below.
1. Determine the MK1000 mounting location.
2. Using a pencil, mark the mounting screw location. Refer
to the mounting template. The screws must be 5 inches
(12.7 cm) apart, left to right: and, 6 inches (15.3 cm)
apart, top to bottom.
There must be a clearance of at least 9/16 of an inch (14.3mm)
between the center of the right side mount holes and nearest
object.
5”
6” (15.3 cm)
(12.7 cm)

8
MK1000
MicroKiosk
1. Install the mounting screws in the markings on the wall, leav-
ing room for the mounting holes on the back of the MK1000
toslideonto.Ensurethescrewsaresecurelyanchoredtothe
wall.
2. Place the MK1000 on the wall, aligning the notches on the
back of the unit with the mounting screws. Ensure all cables
lie neatly in the channel provided on the back of the unit.
3. Slide the MK1000 to the left and down to secure in place.
Configuring for Host Communication
The MK1000 can communicate with a host via PCK emulation.
See the Product Reference Guide (p/n 72-53977-xx) for default
Host Communication parameters, corresponding bar codes, and
decode parameter bar codes.

9
Quick Reference
Ergonomic Recommendations
Caution: In order to avoid or minimize the potential risk of ergonomic injury follow the
recommendations below. Consult with your local Health & Safety Manager to ensure that you are
adhering to your company’s safety programs to prevent employee injury.
• Reduce or eliminate repetitive motion
• Maintain a natural position
• Reduce or eliminate excessive force
• Keep objects that are used frequently within easy reach
• Perform tasks at correct heights
• Reduce or eliminate vibration
• Reduce or eliminate direct pressure
• Provide adjustable workstations
• Provide adequate clearance
• Provide a suitable working environment
• Improve work procedures.
Regulatory Information
All Symbol devices are designed to be compliant with rules and regulations in locations they are
sold and will be labeled as required.
Any changes or modifications to Symbol Technologies equipment, not expressly approved by
Symbol Technologies, could void the user's authority to operate the equipment.
FCC RF Exposure Guidelines
To comply withFCC RFexposure requirements, antennas that are mounted externally
at remote locations or operating near users at stand-alone desktop of similar
configurations must operate with a minimum separation distance of 20 cm from all
persons.
Radio Frequency Interference Requirements
This equipment has been tested and found to comply withthe limits for
a Class B digital device, pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However there is no guarantee that interference will not
occur in a particular installation. If the equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Re-orient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
• Consult the dealer or an experienced radio/TV technician for help.
Radio Frequency Interference Requirements - Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Tested to comply
with FCC Standards
FOR HOME OR OFFICE USE

10
MK1000
MicroKiosk
This device complies with RSS 210 of Industry & Science Canada. Operation is subject to the
followingtwoconditions:(1)thisdevicemaynotcauseharmfulinterferenceand(2)thisdevicemust
accept any interference received, including interference that may cause undesired operation.
Laser Devices
Symbol products using lasers comply with US 21CFR1040.10, and IEC825-1:1993,
EN60825-1:1994+A11:1996. The laser classification is markedon one of the labels on
the product.
Class1Laserdevicesarenotconsideredtobe hazardouswhenusedfortheirintended
purpose. The following statement is required to comply with US and international regulations:
Caution: Use of controls, adjustments or performance of procedures other than those specified
herein may result in hazardous laser light exposure.
Class2laser scannersuse a lowpower, visiblelightdiode.Aswithanyverybrightlightsource,such
as the sun, the user should avoid staring directly into the light beam. Momentary exposure to a
Class 2 laser is not known to be harmful.
Marking and European Economic Area (EEA)
RLAN’s (2.4GHz) for use through the EEA have the following restrictions:
•·Maximum radiated transmit power of 100 mW EIRP in the frequency range 2.400 -
2.4835 GHz
• ·France, equipment is restricted to 2.4465 -2.4835 GHz frequency range
• ·Belgium outside usage, the equipment is restricted to 2.460 -2.4835 GHz frequency range
• ·Italy requires a user license for outside usage.
Other Countries
• Mexico - Restrict Frequency Range of: 2.450 - 2.4835 GHz.
Statement of Compliance for radio devices
Symbol Technologies, Inc., hereby, declares that this device is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC. A Declaration of Conformity
may be obtained from http://www2.symbol.com/doc/
Power Supply
Note: Use only a Symbol-approved power supply output rated 12-36 Vdc or
12-24-vac and minimum 16va. The power supply is certified to
EN60950 with SELV outputs.
Hinweis: Benutzen Sie nur eine Symbol Technologies genehmigt
Stromversorgung) in den Ausgabe: 12-36 Vdc or 12-24-vac und
minimum 16va. Die Stromversorgung ist bescheinigt nach EN60950
mit SELV Ausgaben.

11
Quick Reference
Scanner Labeling
LASERLICHT - NICHT IN DEN STRAHL BLICKEN. LASER KLASSE 2
LUMIÈRE LASER -NE PAS REGARDER DANS LE FAISCEAU APPAREIL
À LASER DE CLASSE 2. CAUTION-LASER LIGHT. DO NOT STARE INTO
BEAM. IEC CLASS 2 LASER PRODUCT 630-680 nM, 1.0 mW LASER
CAUTION
630-680nM LASER 1.0 mW MAX OUTPUT
CLASS II LASER PRODUCT
LASER LIGHT-DO NOT STARE INTO BEAM

12
MK1000
MicroKiosk
In accordance with Clause 5, IEC 825 and EN60825, the following information is provided to the
user:
ENGLISH HEBREW
CLASS 1 CLASS 1 LASER PRODUCT
CLASS 2 LASER LIGHT
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
DANISH / DANSK ITALIAN / ITALIANO
KLASSE 1 KLASSE 1 LASERPRODUKT CLASSE 1 PRODOTTO AL LASER DI CLASSE 1
KLASSE 2 LASERLYF CLASSE 2 LUCE LASER
SE IKKE IND I STRÅLEN NON FISSARE IL RAGGIOPRODOTTO
KLASSE 2 LASERPRODUKT AL LASER DI CLASSE 2
DUTCH / NEDERLANDS NORWEGIAN / NORSK
KLASSE 1 KLASSE-1 LASERPRODUKT KLASSE 1 LASERPRODUKT, KLASSE 1
KLASSE 2 LASERLICHT KLASSE 2 LASERLYS IKKE STIRR INN I LYSSTRÅLEN
NIET IN STRAAL STAREN LASERPRODUKT, KLASSE 2
KLASSE-2 LASERPRODUKT
FINNISH / SUOMI PORTUGUESE / PORTUGUÊS
LUOKKA 1 LUOKKA 1 LASERTUOTE CLASSE 1 PRODUTO LASER DA CLASSE 1
LUOKKA 2 LASERVALO CLASSE 2 LUZ DE LASER NÃO FIXAR O RAIO LUMINOSO
ÄLÄ TUIJOTA SÄDETTÄ PRODUTO LASER DA CLASSE 2
LUOKKA 2 LASERTUOTE
FRENCH / FRANÇAIS SPANISH / ESPAÑOL
CLASSE 1 PRODUIT LASER DE CLASSE 1 CLASE 1 PRODUCTO LASER DE LA CLASE 1
CLASSE 2 LUMIERE LASER CLASE 2 LUZ LASER
NE PAS REGARDER LE RAYON FIXEMENT NO MIRE FIJAMENTE EL HAZ
PRODUIT LASER DE CLASSE 2 PRODUCTO LASER DE LA CLASE 2
GERMAN / DEUTCH SWEDISH / SVENSKA
KLASSE 1 LASERPRODUKT DER KLASSE 1 KLASS 1 LASERPRODUKT KLASS 1
KLASSE 2 LASERSTRAHLEN KLASS 2 LASERLJUS STIRRA INTE MOT STRÅLEN
NICHT DIREKT IN DEN LASERSTRAHL SCHAUEN LASERPRODUKT KLASS 2
LASERPRODUKT DER KLASSE 2

13
Quick Reference
Warranty
Symbol Technologies, Inc. (“Symbol”) manufactures its hardware products in
accordance with industry-standard practices. Symbol warrants that for a period of
twelve (12) months from date of shipment, products will be free from defects in
materials and workmanship.
This warranty is provided to the original owner only and is not transferable to any third
party. It shall not apply to any product (i) which has been repaired or altered unless
done or approved by Symbol, (ii) which has not been maintained in accordance with
any operating or handling instructions supplied by Symbol, (iii) which has been
subjected to unusual physical or electrical stress, misuse, abuse, power shortage,
negligence or accident or (iv) which has been used other than in accordance with the
product operating and handling instructions. Preventive maintenance is the
responsibility of customer and is not covered under this warranty.
Wear items and accessories having a Symbol serial number will carry a 90-day
limited warranty. Non-serialized items will carry a 30-day limited warranty.
Warranty Coverage and Procedure
During the warranty period, Symbol will repair or replace defective products returned
to Symbol’s manufacturing plant in the US. For warranty service in North America,
call the Symbol Support Center at 1-800-653-5350. International customers should
contact the local Symbol office or support center. If warranty service is required,
Symbol will issue a Return Material Authorization Number. Products must be shipped
in the original or comparable packaging, shipping and insurance charges prepaid.
Symbol will ship the repaired or replacement product freight and insurance prepaid in
North America. Shipments from the US or other locations will be made F.O.B.
Symbol’s manufacturing plant.
Symbol will use new or refurbished parts at its discretion and will own all parts
removed from repaired products. Customer will pay for the replacement product in
case it does not return the replaced product to Symbol within 3 days of receipt of the
replacement product. The process for return and customer’s charges will be in
accordance with Symbol’s Exchange Policy in effect at the time of the exchange.
Customer acceptsfullresponsibilityforitssoftwareanddataincluding the appropriate
backup thereof.
Repair or replacement of a product during warranty will not extend the original
warranty term.
Symbol’s Customer Service organization offers an array of service plans, such as on-
site, depot, or phone support, that can be implemented to meet customer’s special
operational requirements and are available at a substantial discount during warranty
period.
General
Except for the warranties stated above, Symbol disclaims all warranties, express or
implied, on products furnished hereunder, including without limitation implied
warranties of merchantability and fitness for a particular purpose. The stated express
warranties are in lieu of all obligations or liabilities on part of Symbol for damages,
including without limitation, special, indirect, or consequential damages arising out of
or in connection with the use or performance of the product.

72-52968-02
Revision A — March 2002
Symbol Technologies, Inc. One Symbol Plaza Holtsville, NY 11742-1300
Service Information
Before you use the unit, it must be configured to operate in your facility’s network and
run your applications.
Ifyouhaveaproblemrunning yourunit orusingyourequipment,contact yourfacility’s
Technical or Systems Support. If there is a problem with the equipment, they will
contact the Symbol Support Center:
For the latest version of this guide go to:http://www.symbol.com/
manuals.
United States11-800-653-5350
1-631-738-2400 Canada 905-629-7226
United Kingdom 0800 328 2424 Asia/Pacific 337-6588
Australia 1-800-672-906 Austria/Österreich 1-505-5794-0
Denmark/Danmark 7020-1718 Finland/Suomi 9 5407 580
France 01-40-96-52-21 Germany/Deutchland 6074-49020
Italy/Italia 2-484441 Mexico/México 5-520-1835
Netherlands/Nederland 315-271700 Norway/Norge +47 2232
4375
South Africa 11-8095311 Spain/España [phone]
Sweden/Sverige 84452900
Latin America
Sales Support 1-800-347-0178 Inside US [phone] Outside US
Europe/Mid-East
Distributor Operations Contact local distributor or call [phone]
1Customer support is available 24 hours a day, 7 days a week.
