Synchross BS77 User manual

Front Page
- Logo
Instruction
Manual
Power On/Off Press and hold
AUX IN
USB (Charging)
1) Blinking of Play/Pause: Charging
2) Solid of Play/Pause: Charging cycle done
Reset Use a pin to reset the system
Back view
USB
Reset
BS77
Use the included audio cable to connect the audio output
of your device to the Line In input on the speaker.
Use the included USB adapter to connect to the USB on
the speaker. Charging status indicator on Play/Pause key:
Power On/Of
AUX IN

BS77
Touch panel
Play/Pause
Blinking: Indicate low battery
Volume Up/Down
Press and hold to start searching Bluetooth source
1.) Blinking: Speaker attempting to connect to a paired device.
2.) Solid: Speaker connected to paired device.
3.) If unable to connect within five minutes, Bluetooth stop
searching for source
1) Press to answer/end calls.
2) Blinking: Indicate unanswered calls.
BS77
Cannot see the buttons in the dark?
Night Vision: Press Power ( )
Afraid of mis-touching the buttons while carrying the speakers?
Lock/Unlock the touch panel:
1) Press and hold the Play/Pause ( ) until all the
buttons on touch panel blink twice
2) Under Lock: Press any button on the touch panel, all the
buttons blink twice and disabled functions.
More featuring functions
Suggestion: Despite BS77 is IPX7-RATED Waterproof, the sensibility of
the touch panel will be better induced in dry condition. We recommend
you to wipe off water droplet(s) from the touch panel before usage.

Technical information
1. Power supply rating
Input: 100~240VAC，50Hz/60Hz
2. Input power rating
Input: 5VDC/1A
3. Weight
1.28 lb. (490 g)
4. Dimensions (W/H/D)
7.3 in x 2.3 in x 2.2 in (185.3mm x 57.4mm x 56mm)
5. Temperature range for use
0∘- 45∘C (32∘–131∘F)
BS77
Company Name
Telephone No.
Website
Last Page -

Please read these safety warnings and cautions carefully. Failure to read,
understand and follow these warnings can result in death or serious personal
injury and property damage.
SAFETY INFORMATION
WARNING:
•Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
•Do not place any naked flame sources, such as lighted candles, on or
near the apparatus.
•Only use attachments/accessories specified by the manufacturer.
•Unplug this apparatus during lightning storms or when unused for long
periods of time.
•Refer all servicing to qualified personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
•This product contains magnets which can be harmful to pacemaker
wearers.
•The battery pack shall not be exposed to excessive heat such as
sunshine, fire or the like.
•Do not dismantle, open or shred battery pack.
•Do not short-circuit the battery or battery pack. Do not store the
battery pack haphazardly in a box or drawer where it may short-circuit
by other metal objects.
IMPORTANT SAFETY INFORMATION
LOGO
CAUTION
RISK OF ELECTRIC SHOCK. DO NOT OPEN.
The lightning flash with arrowhead symbol within an
equilateral triangle alerts the user to the presence of
uninsulated, dangerous voltage within the system enclosure
that may be of sufficient magnitude to constitute a risk of
electric shock
The exclamation point within an equilateral triangle, as
marked on the system, is intended to alert the user to the
presence of important operating and maintenance
instructions in this owner’s guide.
Caution: To reduce the risk of electric shock. DO NOT REMOVE COVER
(OR BACK). No user-serviceable parts inside. Refer servicing to qualified
personnel.
Make no modifications to the system or accessories.
Unauthorized alterations may compromise safety, regulatory
compliance, and system performance.

【FCC Statement 】
WARNING:
•Do not subject battery pack to mechanical shock.
•In the event of a battery pack leaking, do not allow the liquid to come
in contact with the skin or eyes. If contact has been made, wash the
affected area with copious amounts of water and seek medical advice.
•Do not use any charger other than that specifically provided for use
with the equipment.
•Do not use any battery pack which is not designed for use with the
equipment.
•Keep battery pack out of the reach of children.
•The battery needs to be charged before use. Always use the correct
charger and refer to the manufacturer’s instructions or equipment
manual for proper charging instructions.
•After extended periods of storage, it may be necessary to charge and
discharge the battery pack several times to obtain maximum
performance.
•Do not leave a battery on prolonged charge when not in use.
•The battery pack gives its best performance when it is operated at
normal room temperature (20°C +/- 5°C).
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
This equipment generates uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.

The standards compliance label on the Brocade 6510 contains the CE
mark which indicates that this system conforms to the provisions of the
following European Council directives, laws, and standards:
【Electromagnetic Compatibility (EMC) Directive
2004/108/EEC】
Low Voltage Directive (LVD) 2006/95/EC
EN50082-2/EN55024:1998 (European Immunity Requirements)
EN61000-3-2/JEIDA (European and Japanese Harmonics Spec)
EN61000-3-3
【RoHS】
The Restriction of Hazardous Substances Directive 2002/95/EC, RoHS,
short for Directive on the restriction of the use of certain hazardous
substances in electrical and electronic equipment, was adopted in
February 2003 by the European Union.
Canada
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le present appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radioexempts de licence. L'exploitation est autorisee aux deux
conditions suivantes : (1) l'appareil nedoit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillageradioelectrique subi,
meme si le brouillage est susceptible d'en compromettre le fonctionnement.
【RF Exposure Information】
To comply with FCC/IC RF exposure requirements for mobile transmitting
devices, this transmitter should only be used or installed at locations where
there is at least 20 cm separation distance between the radiator and your body.
【CE statement】
ATTENTION
This is a Class A product. In a domestic environment, this product might cause
radio interference, and the user might be required to take corrective measures
Company Name & Website
