Synergy Global Technology LCD1U10-02 User manual
User Manual
1U LCD Keyboard Drawer
10" screen size
Models
LCD1U10-02
- With KVM options
Chapter 1 Getting Started
1.1 ImportantSafeguards..........................................................1
1.2 RegulatoryNotice................................................................2
1.3 PackageContents...............................................................3
1.4 Before Installation...............................................................4
1.5 Unpacking...........................................................................4
1.6 OptionalAccessories...........................................................4
1.7 PeripheralProducts.............................................................5
1.8 Structure Diagram...............................................................5
1.9
1.10 How to Use The Slides.......................................................6
1.11 How to Use LCD1U10-02
1.12
LCD1U10-02 (Single console)
- Use LCD-A3001 to connect to server via PS/2 interface.
................8
1.13
LCD1U10-02 (Single console)
- Use LCD-A3001 to connect to KVM via PS/2 interface ..................8
1.14
LCD1U10-02 (Single console)
- Use LCD-A3001 to connect to server via USB interface
................9
LCD1U10-02 (Single console)
- Use LCD-A3001 to connect to KVM via USB interface
..................9
Chapter 2 Operation
2.1 On-screen Display Operation............................................10
2.2 On-screen Menu...............................................................11
Chapter 3 Standard Specification
3.1 Specifications....................................................................12
3.2 Keyboard & Mouse...........................................................13
Contents
Chapter 4 Optional Specification
4.1 KVM Options.....................................................................14
4.2 DVI-DOption.....................................................................14
4.3 BNC + S-Video Option......................................................14
4.4 Audio Option.....................................................................15
4.5 DC power Options.............................................................15
4.6 Touchscreen Options........................................................16
Chapter 5 Troubleshooting...........................................................17
Chapter 6 Dimensions.......................................................................17
LCD Keyboard Drawer...............7
1.1 Important Safeguards Chapter 1
P.1
Please read all of these instructions carefully before you use the device. Save this manual for future
reference.
What the warranty does not cover
■Any product, on which the serial number has been defaced, modified or removed.
■Damage, deterioration or malfunction resulting from:
□Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modifi-
cation, or failure to follow instructions supplied with the product.
□Repair or attempted repair by anyone not authorized by us.
□Any damage of the product due to shipment.
□Removal or installation of the product.
□Causes external to the product, such as electric power fluctuation or failure.
□Use of supplies or parts not meeting our specifications.
□Normal wear and tear.
□Any other causes which does not relate to a product defect.
■Removal, installation, and set-up service charges.
P.2
1.2 Regulatory Notice Chapter 1
Legal Information
First English printing, October 2002
Information in this document has been carefully checked for accuracy; however, no guarantee is given to the
correctness of the contents. The information in this document is subject to change without notice. We are not
liable for any injury or loss that results from the use of this equipment.
Safety Instructions
■Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth.
■Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned enviro-
nment with temperatures not exceeding 40º Celsius (104º Fahrenheit).
■When installing, place the equipment on a sturdy, level surface to prevent it from accidentally falling and
causing damage to other equipment or injury to persons nearby.
■When the drawer is in an open position, do not cover, block or in any way obstruct the gap between it and
the power supply. Proper air convection is necessary to keep it from overheating.
■Arrange the equipment’s power cord in such a way that others won’t trip or fall over it.
■If you are using a power cord that didn’t ship with the equipment, ensure that it is rated for the voltage
and current labeled on the equipment’s electrical ratings label. The voltage rating on the cord should be
higher than the one listed on the equipment’s ratings label.
■Observe all precautions and warnings attached to the equipment.
■If you don’t intend on using the equipment for a long time, disconnect it from the power outlet to prevent
being damaged by transient over-voltage.
■Keep all liquids away from the equipment to minimize the risk of accidental spillage. Liquid spilled on to
the power supply or on other hardware may cause damage, fire or electrical shock.
■Only qualified service personnel should open the chassis. Opening it yourself could damage the equip-
ment and invalidate its warranty.
■If any part of the equipment becomes damaged or stops functioning, have it checked by qualified service
personnel.
Regulatory Notices Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interfer-
ence in a residential installation.
Any changes or modifications made to this equipment may void the user’s authority to operate this equip-
ment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
■Re-position or relocate the receiving antenna.
■Increase the separation between the equipment and receiver.
■Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
1.3 Package Contents Chapter 1
P.3
LCD keyboard drawer x 1 pc
LCD-A3001 Combo 4-in-1 KVM cable x 1 pc
User manual x 1 pc
Power cord x 1 pc
Auto switch power adapter ( for external power version) x 1 pc
Mounting bracket x 2 pcs
Fasteners x 4 pcs
5
4
2
6
1
3
7
User
Manual
16
5
4
3
2
7
■It is very important to locate the LCD Keyboard Drawer in a suitable environment.
■The surface for placing and fixing the LCD Keyboard Drawer should be stable and level or mounted into a suitable
cabinet.
■Make sure the place has good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat,
water, moisture and vibration.
■Position LCD Keyboard Drawer with respect to related facilities.
The LCD keyboard drawer comes with the standard parts shown on the package contents. Check and make sure they
are included and in good condition. If anything is missing, or damage, contact the supplier immediately.
1.5 Unpacking
1.4 Before Installation Chapter 1
P.4
1.6 Optional Accessories
1. Combo 4-in-1 KVM cable
1.1 LCD-A3001 6 feet
1.2 LCD-A3002 10 feet
1.3 LCD-A3003 15 feet
2. USB 2-in-1 KVM cable
2.1 LCD-A1014 6 feet
2.2 LCD-A1015 10 feet
2.3 LCD-A1016 15 feet
3. Power Cord
3.1 IEC power cord
3.2 NEMA 5-15 power cord (US)
3.3 BS 1363 power cord (UK)
3.4 CEE 7/4 power cord (German)
3.5 AS 3112 power cord (Australia)
P.5
1.7 Peripheral Products Chapter 1
Item Model No. Description
Matrix Cat6 KVM
Matrix Cat6 16 port KVM
Matrix IP Cat6 16 port KVM
Matrix Cat6 32 port KVM
Matrix IP Cat6 32 port KVM
Matrix DB-15 KVM
Matrix DB-15 8 port KVM
Matrix IP DB-15 8 port KVM
Matrix DB-15 16 port KVM
Matrix IP DB-15 16 port KVM
Combo Cat6 KVM
Combo Cat6 8 port KVM
Combo Cat6 16 port KVM
Combo Cat6 32 port KVM
Combo DB-15 KVM Combo DB-15 8 port KVM
Combo DB-15 16 port KVM
PS/2 DB-15 KVM
1.8 Structure Diagram
1
2
3
56
Carry handle to release the 2-pt lock
LCD interchangeable module kit
Mounting bracket
LCD membrane
1
2
3
5
7
6
8
7
Membrane switch (KVM option)
Micro switch for screen auto power off
Keyboard interchangeable module kit
Mouse interchangeable module kit
4
4
8
LCDK2006-2 / 3 / 4
LCDK2012- 31 / 41 / 42
LCDK2007-2 / 3 / 4
LCDK2013-31 / 41 / 42
LCDK2004- 2 / 3 / 4
LCDK2010- 31 / 41 / 42
LCDK2005-2 / 3 / 4
LCDK2011-31 / 41 / 42
LCDK2001 / 2002 / 2003
LCDK1043 / 1045 / 1047
LCDK1044 / 1046 / 1048
LCDK1020 / 1024 / 1038
LCDK1021 / 1025 / 1039
LCDK1009 / 1010 /1011 4 / 8 / 16 port PS/2 DB-15 KVM
P.6
1.9 How to Use the Slides Chapter 1
Figure 3.
Figure 2.
■Pull and hold the black arrow button on either
side of the LCD keyboard drawer to unlock.
(shown in Figure 2).
Figure 1.
LL
I
L
I
■A black arrow release button is located on the
outside of each slide. (shown in Figure 1).
■Push the LCD keyboard drawer into the rack.
(shown in Figure 3).
Caution : Keep your fingers away from the
slide stop
0 How to Use these Series LCD Keyboard Drawer
P.7
Chapter 1
1.1
■Press the carry handle button. Gently pull the
carry handle toward the front of the LCD shown
in Figure 4.
Figure 4. Sliding out the LCD keyboard drawer by pressing the carry
handle button first.
■Operate the LCD keyboard drawer shown in
Figure 6.
Figure 6. Operating the LCD keyboard drawer.
Figure 5. Flipping up the LCD to a suitable angle.
■Flip up the LCD to a suitable angle shown in
Figure 5.
P.8
Remarks :
■The above connection is only for the LCD keyboard without KVM switch built-in.
■For the LCD keyboard drawer with KVM switch built-in, please refer to attached KVM switch user manual.
Caution : The LCD keyboard drawer is hot-pluggable, but components of connected de-
vices, such as the servers and KVM switch, may not be hot-pluggable. Plugging and un-
plugging cables while servers and KVM are powered on may cause irreversible damage to
the servers, KVM and LCD keyboard drawer. Before attempting to connect anything to the
LCD keyboard drawer, we suggest turning off the power to all devices before connecting
them. Apply power to connected devices again only after the LCD keyboard is receiving
power. The company is not responsible for damage caused in this way.
Figure 10.
1.11 LCD1U10-02 (Single console) Chapter 1
Figure 9.
KVM
1.12 LCD1U10-02 (Single console)
Example of connecting LCD-A3001 Combo 4-in-1 KVM cable to KVM via PS/2 interface
- Use LCD-A3001 to connect to KVM via PS/2 interface
- Use LCD-A3001 to connect to server via PS/2 interface
Example of connecting LCD-A3001 Combo 4-in-1 KVM cable to server via PS/2 interface
LCD-A3001 6-FT COMBO CABLE
LCD-A3001 6-FT COMBO CABLE
P.9
Caution : The LCD keyboard drawer is hot-pluggable, but components of connected de-
vices, such as the servers and KVM switch, may not be hot-pluggable. Plugging and un-
plugging cables while servers and KVM are powered on may cause irreversible damage to
the servers, KVM and LCD keyboard drawer. Before attempting to connect anything to the
LCD keyboard drawer, we suggest turning off the power to all devices before connecting
them. Apply power to connected devices again only after the LCD keyboard is receiving
power. The company is not responsible for damage caused in this way.
Remarks :
■The above connection is only for the LCD keyboard without KVM switch built-in.
■For the LCD keyboard drawer with KVM switch built-in, please refer to attached KVM switch user manual.
Chapter 1
Figure 11.
Figure 12.
KVM
1.13 LCD1U10-02 (Single console)
1.14 LCD1U10-02 (Single console)
Example of connecting LCD-A3001 Combo 4-in-1 KVM cable to KVM via PS/2 interface
- Use LCD-A3001 to connect to KVM via USB interface
- Use LCD-A3001 to connect to server via USB interface
Example of connecting LCD-A3001 Combo 4-in-1 KVM cable to server via PS/2 interface
LCD-A3001 6-FT COMBO CABLE
LCD-A3001 6-FT COMBO CABLE
2.1 On-screen Display Operation Chapter 2
P.10
10” LCD membrane
Exit the OSD screen
Toggle analog, digital & video connection (DVI-D and video options only)
Scrolls through menu options and adjusts the displayed control
(To auto adjustment by pressing the button for 5 seconds)
Display the OSD menu
Power on / off LCD
Power light
Green = On
Orange = Power saving
Membrane Switch Function
P.11
2.2 On-screen Menu Chapter 2
OSD Configuration Page
Image:
To enter into the brighness, contrast, color temp, red, green, and
blue
Geometry:
To enter into the auto adjust, H position, V position, phase and
clock
Video:
To enter into the colour, tint, sharpness, noise reduction, DCDi and
TV Setup
Audio:
To enter into volume, bass, treble, balance, AVL and mute
Misc:
To enter into the language, OSD position, graphic mode, ratio,
reset and timer
P.12
3.1 Specifications Chapter 3
Item Description
Form Factor 1U rack mounting on slide-out rails
LCD Manufacturer
Series LCD1U10-02
Diagonal Size 15" TFT
Max. Resolution 1024 x 768
Brightness (cd/m²) 400
Color Support 16.2 M
Contrast Ratio (typ.) 1200:1
Viewing Angle (H/V) 176˚x 176˚
Display Area (mm) 211 x 158
Tr Response Time (ms) 10
LCD Panel MTBF (hrs) 50,000
VGA Signal Input Analog RGB, 0.7Vp-p
Sync. Type Separate H/V, Composite, SOG
Plug & Play DDC EDID 1.3
Console Port (Combo) DB-15 connector for VGA / keyboard / mouse
(Combo interface)
Power Input Auto-sensing 100 to 240VAC, 50 / 60Hz
Power Consumption Max. 48 W
att, Standby 5 Watt
Compatibility Multi-platform - Mix PCs, SUNs, IBMs, HPs & DELLs.
Regulation Approval FCC, CE
Options
KVM Integration Matrix & combo KVM with IP console and 2-console selection
Keyboard & mouse Notebook keyboard w/ touch-pad / Cherry keyboard w/ trackball
Graphic Input DVI-D, RCA, BNC & S-Video input
DC Power DC power input with 12V, 24V, 48V selection
Touchscreen Resistive & capacitive
Environmental
Operation 0˚to 50˚CDegree
Storage -5˚to 60 ˚C Degree
Relative Humidity 5~90%, non-condensing
Shock 10G acceleration (11ms duration)
Vibration 5~500Hz 1G RMS random vibration
P.13
3.2 Keyboard & Mouse Chapter 3
Cherry keyboard integrated with
trackball
C
N keyboard integrated with
touchpad
N
For LCD1U10-02
P.14
4.1 KVM Options Chapter 4
4.2 DVI-D Option
Internal power version
External power version
DVI-D
3-in-1
VGA KB mouse
console port
Remarks :
■Package includes 1 x 6ft DVI-D cable
4.3 BNC + S-Video Option
Internal power version
External power version
Remarks :
■Package includes 1 x 6ft S-Video cable
3-in-1
VGA KB mouse
console port
S-Video BNC
Our KVM is designed to seamlessly integrate into the rear of our full range of LCD drawer solutions:
■For KVM operation, please refer to KVM user manual
■Option with Multiple consoles Matrix KVM
■Option with high density & cost efficient Combo KVM integration with either 8 / 16 / 32 ports
■Option with low cost PS/2 KVM
■Please ask your supplier for full KVM details
■Single Port version includes VGA, DVI-D, BNC, S-Video and Audio inputs
■Single Port version includes VGA, DVI-D, BNC, S-Video and Audio inputs
P.15
4.5 DC Power Options
Model 12V 24V 48V
Input rating
Input voltage: 12-Volt 24-Volt 48-Volt
Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V
Input current
- No load 50 mA 50 mA 50 mA
- Full load 4950 mA 2450 mA 1220 mA
Output rating
Output voltage: 12-Volt 12-Volt 12-Volt
Output current: 4.16A 4.16A 4.16A
Efficiency 84% 85% 85%
Remarks
■Audio input is 35mm audio plug
■The speaker is sharing the same power with LCD.
Power Audio
Speaker
4.4 Audio Option Chapter 4
Internal power version
External power version
3-in-1
VGA KB mouse
console port
■Single Port version includes VGA, DVI-D, BNC, S-Video and Audio inputs
■The speaker option can be only added on single port and 8-port KVM version.
P.16
4.6 Touchscreen Options Chapter 4
Model -10TRB / -10TRS
Screen size 10"
Interface USB / serial
Optical transmittance 80% ± 3%
Surface hardness ≥3H (JIS K5400)
Operating system Windows 98 / 2000 / ME / XP / NT / CE, DOS, Linux
Capacitive
Model -10TCB / -10TCS
Screen size 10"
Interface USB / serial
Optical transmittance 93% ± 2%
Surface hardness >9H Surface hardness, withstand over 300 million touches
Operating system Windows 98 / 2000 / ME / XP / NT / CE, DOS, Linux
Resistive
Remarks
■USB touchscreen package includes 1 x 6ft USB cable, quick reference guideline and CD disc
■Serial touchscreen package includes 1 x 6ft serial cable, quick reference guideline and CD disc
■For detailed information, please refer to the attached CD disc
■As the touchscreen unit is not made of toughened glass, please handle it carefully
■Touchscreen in other brands are available on request
5. How do I adjust the resolution?
5.1 Troubleshooting Chapter 5
To change monitor resolution, click Start -> Control Panel -> Display. Select Setting tab to adjust the monitor resolution in
Desktop Area. The available resolutions, "640 x 480", "800 x 600", "1024 x 768", "1152 x 864", "1280 x 1024", are deter-
mined by the display card in your computer.
1. Is interference signal appeared on LCD normal when shutting down the computer ?
In rare cases, interference may appear on the monitor. This may be caused by signal rate of VGA card and is considered
normal. The image quality can be improved by adjusting the phase or pixel rate automatically or manually.
2. The membrane power light is not ON
Press the power On / Off on LCD membrane to check if the monitor is in the ON mode.
Check the power cord is properly connected to the LCD keyboard drawer and power outlet.
4. Is the LCD keyboard drawer hot-pluggable ?
The LCD keyboard drawer is hot-pluggable, but components of connected devices, such as the servers and KVMs, may
not be hot-pluggable. We suggest turning off the power to all devices before connecting them. Apply power to connected
devices again only after the LCD keyboard receives power.
3. Screen image is not centered or sized properly
Press the button for two seconds to automatically adjust the image.
Adjust the H-position and V-position settings via On-screen menu.
P.17
6.1 Dimensions Chapter 6
Model Product Dimension
(W x D x H) Net
Weight
LCD1U10-02 442 x 410 x 44 mm
17.4 x 16.1 x 1.73" 15 kg
33 lb
The company reserves the right to modify product specifications without prior notice and assumes no responsibility for any error which
may appear in this publication.
All brand names, logo and registered trademarks are properties of their respective owners.
Copyright 2008 Synergy Global Technology Inc. All rights reserved.
Table of contents
Other Synergy Global Technology Music Mixer manuals
