Thank you for your purchasing the CAREU WT1
Vehicle Tracker. We are very pleased to introduce you
our excellent product, and you will enjoy great benefits
by applying such a smart device.
The CAREU WT1 Vehicle Tracker is an all-in-one
device that integrates multiple applications of GPS
(Global Position System), GSM (Global System for
Mobile Communication) and GIS (Geographic
Information Systems) with each other.
Designed with the latest GPS technology, the CAREU WT1 delivers positioning message by GSM
wireless transmission to GIS platform, and then helps back-end users proceed with the analysis
and the applications of vehicle transport, management, anti-theft, security and tracking.
1.1 Features
• Cost effective and easy installation
• SMS, GPRS TCP/ UDP, USSD, FTP communications
• Geo-fencing reports
• Remote configuration
• Real-time tracking (time, distance interval or intelligent mode, and heading)
• Intelligent power management
• Power low/lost alarm
• Journey report wireless downloads
• GSM/GPRS simultaneously
• Firmware upgrade over the air (via GPRS from FTP)
• Up data log capacity

CAREU
WT1
Lite
V
ehicle
T
r
acker User
Guide
1.2 Scope
This document will guides you to start the CAREU WT1 Vehicle Tracker. However, as
this document contains basic device configuration only, please see the CAREU WT1
Protocol Document for the advanced information.
1.3 About WT1
The CAREU WT1 Vehicle Tracker transmits the wireless signals such as location,
peripheral, and vehicle control data to a control center. The onboard GPS receiver provides
users with location data including speed, direction, mileage and altitude. It uses an
onboard GSM/ GPRS module to accomplish wireless transmission.
A microcontroller can probe location and command data at regular intervals, derive actions
from location, peripheral and control data, and execute such actions.
Among the best features of the CAREU WT1 Vehicle Tracker, in particular, they transmit
data in ASCII mode or binary mode.
Peripheral data indicates the status of various peripherals connected to and/or controlled by
the device. The peripherals include, but not limited to, door locks/un-locks, starter interrupt,
ignition, battery, engine and panic button.
The firmware in the device applies intelligent filtering to overcome coverage limitations for
both GPS and GSM/GPRS networks.
Motion sensor controls the status of the device, whether in sleep, idle or fully-powered
mode, and thereby controls the amount of current consumed by the device.
Backup battery and tamper sensing GPS Antennas primarily indicate the loss of Main
Power and the interruption of GPS antenna connectivity.
The device supports over-the-air firmware upgrade to deliver additional functionality without
physically touching the device once installed.
In consideration of technicality and marketability, the CAREU WT1 has so many
excellences to be competitive enough to stand out in the market. With regard to the
technicality, the CAREU WT1 saves and records more data even under inactive
communication staus, and it also provides better power management, coexistence of GPRS
and SMS modes. When it comes to the marketability, the CAREU WT1 users are
provided with the convenience that its firmware can be upgraded through mini USB
without disassembling the device.

Chapter 1
CAREU WT1 Vehicle Tracker User
1.4 Hardware Architecture
As hardware is concerned, the CAREU WT1 is comprised of a micro-controller,
regulator, GPS receiver, GSM/GPRS modem, G-Force sensor, flash memory data
storage, I/Os interface and LED status indicators.
• Users can connect PC's HyperTerminal to the Diagnostic/setting port for the AVL
configuration.
• G-Sensor for man down warning.

CAREU
WT1
Lite
V
ehicle
T
r
acker User
Guide
1.5 Related Document
[1] CAREU WT1 Protocol Document

CAREU WT1 Vehicle Tracker User
Chapter 2. Taking a Tour of CAREU WT1
This chapter will guide you to the major connectors of the WT1 device.
2.1 Dimensions

CAREU
WT1
Lite
V
ehicle
T
r
acker User
Guide
2.2 Lateral view
No. Name Description
Red Button SOS SOS Function,User define Message & Action mode
Blue Button Page LCD View change key,User define function.

CAREU WT1 Vehicle Tracker User
2.3 Front View
No. Name Description
Micro USB USB USB for change battery & Function set.
Reset Button Reset H/W Reset Key.

CAREU
WT1
Lite
V
ehicle
T
r
acker User
Guide
Chapter 3. Getting Started with CAREU WT1
3.1 USB Device Driver Installation
The CAREU WT1 communicates with your host computer by either RS-232 or USB
interface.
In some newer editions of Windows XP, the CAREU WT1 device can be installed as a "virtual
COM port" device whereby the CAREU WT1 would automatically access Windows XP's
inbox USB drivers. While in some other earlier editions of Windows XP, you would need to
manually install the USB driver for the CAREU WT1 device. In the following content of this
section, you will be guided to how the installation can be done in both cases.
To install the device driver for the CAREU WT1, connect the CAREU WT1 device to
your system with an USB cable as mentioned in Mini USB Cable Connection on
section 3.1.
As soon as the connection is made between the CAREU WT1 and your computer, a
balloon appears above the notification area saying an USB device is found.
Click on this balloon to start the [Found New Hardware] wizard.
Select No, not this time. Press the Next button to proceed.

CAREU WT1 Vehicle Tracker User
1. Automatic Installation
If the wizard prompts to help you install the software for "STMicroelectronics Virtual
COM Port". Select Install the software automatically (Recommended). Press the
Next button to proceed.
The wizard proceeds to install the driver.

CAREU
WT1
Lite
V
ehicle
T
r
acker User
Guide
The installation completes.
In [Device Manager], the CAREU WT1 device is included under Ports (COM & LPT) as
"STMicroelectronics Virtual COM Port". COM port number is displayed as well.

CAREU WT1 Vehicle Tracker User
2. Manual Installation
After you select No, not this time, if the wizard only prompts to help you install software
for "USB device", you need to manually install the driver. Select Install from a list or
specific location (Advanced). Press the the Next button to proceed.

CAREU
WT1
Lite
V
ehicle
T
r
acker User
Guide
Select Search for the best driver in these locations. Check Include this location
in the search. Press the Browse button to assign where your the CAREU WT1 device
driver locates on your local disk.
Press the OK button.
You can download the USB device driver from http://www.systech.com.tw/downloads.php.

CAREU WT1 Vehicle Tracker User
Press the Next button to proceed.
The wizard proceeds to install the driver.

CAREU
WT1
Lite
V
ehicle
T
r
acker User
Guide
The installation completes.
In [Device Manager], the CAREU WT1 device is included under Ports (COM & LPT) as
"S&T Tracker". COM port number is displayed as well.

CAREU WT1 Vehicle Tracker User
3.2 Device Configuration
1. In Windows XP desktop, click Start | All Programs | Accessories |
Communications | HyperTerminal.
2. If you are prompted to input the information of your location, complete them to proceed.
3. On the File menu of HyperTerminal, click New Connection.
4. In the Name box, type a name that describes the connection. In the Icon box, click
an appropriate icon. Press the OK button to proceed.
5. For Com port properties, configure as follows:
Baud Rate --> 115200 bps
Data Bits --> 8
Parity --> None
Stop Bits --> 1
Flow Control --> None

CAREU
WT1
Lite
V
ehicle
T
r
acker User
Guide
6. In the connection that you have just set up, click File | Properties. Select the
[Connect To] tab. From the [Connect using] drop down list, select the correct com
port by checking it up at Windows XP's [DeviceManager] as previously mentioned
on page 21. Go there by clicking Start | Control Panel | System | Hardware |
Device Manager.

CAREU WT1 Vehicle Tracker User
7. In the File menu, click Properties. Click the [Settings] tab. Press the ASCII Setup
button.
8. In the [ASCII Sending] group box. Select both Send line ends with line feeds and
Echo typed characters locally. Press the OK button.
