TaoTronics TT-EF002 User manual

Questions or Concerns?
[e-mail] User Manual
TAOTRONICS
REFRIGERATOR
TT-EF002

21 3 4 5 6
CONTENTS
IMPORTANT
SAFETY
INSTRUCTIONS
01-03
KNOWING
YOUR
REFRIGERATOR
USING
YOUR
REFRIGERATOR
REVERSING THE
REFRIGERATOR
DOOR
CLEANING
AND
MAINTENANCE
TROUBLE-
SHOOTING
GUIDE
04-05 06-07 08-09 10-11 12-13

1
IMPORTANT
SAFETY
INSTRUCTIONS
01
DO NOT allow
children to climb!
DO NOT plug in
and operate with
wet hands.
DO NOT operate
if plug and cord is
damaged.
24h
This unit may have been tilted or placed
upside down during transportation. Please
set the Refrigerator upright for at least 24
hours before initial use to allow the
refrigerant to stabilize.
THANK YOU
FOR BEING OUR CUSTOMER
Your purchase is truly appreciated!
We hope you are over-the-moon with our product!

WHEN USING ELECTRICAL APPLIANCES,
BASIC PRECAUTIONS SHOULD ALWAYS BE
FOLLOWED TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK, AND INJURY TO PERSONS,
INCLUDING THE FOLLOWING:
WARNING
INTENDED USE
· This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning the use of the appliance
by person responsible for their safety.
· This refrigerator and its packaging are not intended to be played with or used by
children. Close supervision is necessary when any appliance is used by or near
children.
· Use the appliance only for intended household purposes as described in this
User Manual.
RELATED TO USE
· Make sure the refrigerator is placed in a well-ventilated, indoor environment
on flat, sturdy ground.
· Keep the ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
· If the refrigerator was transported tilted on its side, you must position it upright
again and wait at least 24 hours before using it.
· DO NOT use sharp metal objects to remove excess ice build-up in the freezer
compartment.
· DO NOT place heavy objects on the top of the appliance.
· If installed near another refrigerator or freezer, keep it at a minimum distance of
2 cm.
· DO NOT use mechanical, electrical or chemical products other than those
recommended by the manufacturer to speed up the defrosting process.
· DO NOT use steam jets to clean the appliance.
· Always unplug the appliance in the event of a fault or when performing cleaning
or maintenance.
· After your refrigerator is in operation, do not touch the cold surfaces in the
freezer compartment, particularly when hands are damp or wet. Skin may
adhere to these extremely cold surfaces.
· If the refrigerating appliance is left empty for long periods, switch off, defrost,
clean, dry, and leave the door open to prevent mould developing within the
appliance.
· Before you throw awayyour old refrigerator, Remove the doors.
· Remove refrigerant by a qualified technician.
02
ELECTRICITY SAFETY
· This appliance must be provided with correct voltage via a professionally installed
power socket. Make sure the voltage indicated on the label of the appliance is the
same as your local supply.
· DO NOT locate multiple portable socket-outlets or portable power supplies at the
rear of the appliance.
· Never unplug your refrigerator by pulling on the power cord. Always grasp the
plug firmly and pull straight out from the outlet.
· DO NOT use the appliance with a damaged cord or plug or after malfunctions
occur, or has been damaged in any manner.
· DO NOT use an extension cord.
· DO NOTattempt to modify or repair the product by yourself. Doing so could void
the warranty and cause damage or personal injury. Only a qualified technician may
disassemble or repair this product.
03
RELATED TO PLACING ITEMS
· DO NOT use electrical appliances inside food storage compartments unless
these are of the type recommended by the manufacturer.
· DO NOT store inflammable, explosive or volatile substances.
· DO NOT keep explosive substances, such as spray bottles with flammable
propellants in the appliance.
· Bottles containing strong alcoholic drinks must be tightly closed and stored
vertically.
· DO NOT place flammable items near the refrigerator to avoid a fire hazard.
※ IMPORTANT: For Soda or Soft Drinks, please set the temperature as
recommended on the beverage bottles (e.g., 38°F / 3°C). Do not set the
temperature too low, or place the soda or soft drinks in the freezer compartment.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
SPECIFICATIONS
Model
Input
Energy Consumption
Energy Class
Total Capacity
TT-EF002
115V~ 60Hz
220 Kwh/Y
E-Star
3.3cu.ft. (93L)

2
KNOWING
YOUR
REFRIGERATOR
04 05
Temperature
Control Top Hinge
Bottle
Storage
Refrigerator
Door
Leveling
Feet
Refrigerator
Compartment
Drip Tray
Chiller
Compartment
Temperature Control
OFF
MIN
MED
MAX
OFF
Turn unit OFF
OFF
MIN
MED
MAX
MIN
Less Cool
OFF
MIN
MED
MAX
MED
Normal
OFF
MIN
MED
MAX
MAX
Coolest

3
USING
YOUR
REFRIGERATOR
Operations and Functions
For the first time you use the refrigerator, turn the knob to “MED”. Before
placing food in the refrigerator or freezer compartment, allow the unit to
cool down completely. A full 24 hours is recommended.
After it is fully cooled, adjust towards “MIN” to make less cool or towards
“MAX” to cool more to best suit your needs. However, the setting of
“MED” should be appropriate for home or office refrigerator use.
When the knob is turned to “OFF”, the refrigerator will stop running.
OFF
MIN
MED
MAX
Do not place the soda or soft drinks in the freezer
compartment.
1
2
3
06 07
Getting Started
Remove
packaging and
protective film.
1. 2.
Place on a level, stable floor. Adjust the feet
clockwise and counterclockwise to keep it level.
3.
Place in a well-ventilated, indoor environment.
Avoid placing it in direct sunlight
or too close to a heat source.
4.
10cm
10cm
30cm
Leave an enough
circulation space.
5.
Plug into a properly installed-grounded wall outlet.
① ②

5
4
REVERSING THE
REFRIGERATOR
DOOR
Remove the top hinge.
Remove the bottom hinge
and door stopper.
Remove the left
leveling foot.
08 09
Disassemble
Assemble to
Other Side
①
③②
①
②
③

5
CLEANING
AND
MAINTENANCE
10
Do not use
abrasive or
corrosive
detergents.
Do not use rough
or abrasive materials
or sharp metal
scrapers.
Periods of Non-operation
· Disconnect the appliance from electricity supply.
· Remove all foods.
· Clean the appliance and all accessories.
· Leave the door open to prevent unpleasant smells.
OFF
MIN
MED
MAX
Always turn off the appliance
and unplug it from the mains
before cleaning or maintenance.
11
1. 2. 3.
Outer surface: Wipe with a soft cloth dampened
with soapy water, detergent, etc., and then wipe dry.
Narrow gaps or corners: Wipe with a soft cloth,
soft brush, or combined with some auxiliary tools.
Dry all parts thoroughly before reconnecting to the
power source.

6
TROUBLESHOOTING
GUIDE
Problem Possible Causes Solution
Not properly plugged in
Power failure or no power is passing through the unit
The temperature knob is set to the “OFF” position
The door is being opened too frequently
The refrigerator is too full loaded
The temperature is set too warm
Warm and hot foods are stored
The door is opened too often or not closed properly
The door is slightly open
Refrigerants circulating in the refrigerant lines
The refrigerator is not on a level surface
The gaskets are dirty
Make sure the refrigerator is connected to a powered electrical outlet
Check the power, and make sure that your circuit breaker or fuse is working properly
Turn the knob to MIN, MED or MAX as desired
Reduce the frequency and shorten the time of opening the door
Try not to store too many foods
Adjust the temperature to a lower setting
Allow hot foods cool to room temperature before storage
Reduce the frequency and shorten the time of opening the door
Close the refrigerator properly
It is normal and will not affect the cooling effect and operation
Place the refrigerator on a level and sturdy ground
Clean the gaskets regularly
If problems persist, contact
the Customer Support at
12 13
[email protected]
Refrigerator does
not operate
Refrigerator is not
cool enough
Moisture build-up
on inside walls
Airflow sound
during operation
Door is not close
completely

Thanks for choosing TaoTronics Refrigerator.
This product is covered with TaoTronics product and labor warranty for
12 months from the date of its original purchase.
The warranty will not apply in cases of:
- Accident, misuse, or repairs performed by unauthorized personnel.
- Any unit that has been tampered with or used for commercial purpose.
- Normal wear and tear of wearable parts.
- Use of force, damage caused by external influences.
- Damage caused by non-observance of the User Manual, e.g. connection to an
unsuitable mains supply or non-compliance with the instructions.
- Partially or completely dismantled appliances.
- Defects caused by or resulting from damages from shipping or from repairs,
service, or alteration to the product or any of its parts that have been
performed by a repair person not authorized by TaoTronics.
We can only provide after sales service for products that are sold by TaoTronics
or TaoTronics authorized retailers and distributors. If you have purchased your
unit from a different place, please contact your seller for return and warranty
issues.
※Please have your invoice and order ID ready before contacting
Customer Support.
WARRANTY AND SERVICE
Rev_1.1_EN
MADE IN CHINA
[email protected]
Manufacturer: Shenzhen NearbyExpress Technology Development Co.,Ltd.
Address: Floor 7, Building E, Galaxy World Phase II, Shenzhen, China
www.taotronics.com
