Haier HRF580YPS User manual

HRF580YPS
HRF580YPC

Thank you for purchasing a Haier Product.
Please read these instructions carefully before using this appliance. The instructions contain
important information which will help you get the best out of the appliance and ensure safe
and proper installation, use and maintenance.
Keep this manual in a convenient place so you can always refer to it for the safe and proper
use of the appliance.
If you sell the appliance, give it away, or leave it behind when you move house, make sure you
also pass this manual so that the new owner can become familiar with the appliance and safty
warnings.
Legend
Warning – Important Safety information
General information and tips
Environmental information
Disposal
Help protect the environment and human health. Put
the packaging in applicable containers to recycle it.
Help to recycle waste of electrical and electronic
appliances.marked with this symbol with the household
waste. Return the product to your local recycling facility
or contact your municipal office.
Risk of injury or suffocation!
Refrigerants and gases must be disposed of professionally. Ensure that the tubing of
the refrigerant circuit is not damaged before being properly disposed of. Disconnect
the appliance from the mains supply. Cut off the mains cable and dispose of it.
Remove the trays and drawers as well as the door catch and seals, to prevent children
and pets to get closed in the appliance.

25
30
28
37
33
Accessories
Check the accessories and literature in accordance with this list:
2
7
9
10
11
1
Water pipe

Before switching on the appliance for the first time read the following
safety hints!
Before first use
Make sure there is no transport damage.
Remove all packaging and keep out of children´s reach.
Wait at least two hours before installing the appliance in order to ensure the
refrigerant circuit is fully efficient.
Handle the appliance always with at least two persons because it is heavy.
Installation
The appliance should be placed in a well-ventilated place. Ensure a space of
at least 10 cm above and around the appliance.
Never place the appliance in a damp area or location where it might be
splashed with water. Clean and dry water splashes and stains with a soft
clean cloth.
Do not install the appliance in direct sunlight or in the near of heat
sources(e.g. stoves, heaters).
Install and level the appliance in an area suitable for its size and use.
WARNING:Keep ventilation openings in the appliance or in the in-built
structure clear of obstruction.
Make sure that the electrical information on the rating plate agrees with the
power supply. If it does not, contact an electrician.
Connect the appliance to the electrical supply （220V-240V 50Hz) with the
fitted plug and lead .
Abnormal voltage fluctuation may cause the appliance to fail to start, or
damage to the temperature control or compressor, or there may be an
abnormal noise when operating. In such case, an automatic regulator shall
be mounted.
Do not use multi-plug adapters and extension cables.
WARNING:Do not locate multiple portable socket-outlets or portable
power supplies at the rear of the appliance.
WARNING:When positioning the appliance, ensure the supply cord is not
trapped or damaged.
2

Use a separate earthed socket for the power supply which is easy
accessible. The appliance must be earthed.
WARNING:Do not damage the refrigerant circuit.
Daily use
This appliance is not intended for use by persons (including children) with
reduced physical,sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children aged from 3 to 8 years are allowed to load and unload, but not
allowed to clean or install the refrigerating appliances.
Keep away children under 3 years of age from the appliance unless they
are constantly supervised.
Children should be supervised to ensure that they do not play with the
appliance.
If cool gas or other inflammable gas is leaking in the vicinity of the
appliance, turn off the valve of the leaking gas, open the doors and
windows and do not unplug a plug in the power cable of the refrigerator
or any other appliance.
Notice that the appliance is set for operation at a specific ambient range
between 16 and 38℃. The appliance may not work properly if it is left for
a long period at a temperature above or below the indicated range.
Do not place unstable articles (heavy objects, containers filled with
water) on top of the refrigerator, to avoid personal injury caused by falling
or electric shock caused by contact with water.
Do not pull on the door shelves. The door may be pulled slant, the bottle
rack, may be pulled away, or the appliance may topple.
Open and close the doors only with the handles. The gap between the
doors and between the doors and the cabinet is very narrow.
Do not extend your hands in these areas to avoid pinching your fingers.
Open or close the refrigerator doors only when there are no children
standing within the range of door movement.
Do not store or use inflammable, explosive or corrosive materials in the
appliance or in the vicinity.
3

Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
Do not store medicines, bacteria or chemical agents in the appliance.
This appliance is a household appliance. It is not recommended to store
materials that require strict temperatures.
Never store liquids in bottles or cans (besides high percentage spirits)
especially carbonated beverages in the freezer, as these will burst
during freezing.
Check the condition of food if a warming in the freezer has taken place.
Do not set unnecessarily low temperature in the refrigerator
compartment. Minus temperatures may occur at high settings.
Attention: Bottles can burst
Do not touch frozen goods with wet hands (wear gloves).
Especially do not eat ice lollies immediately after removal from the
freezer compartment. There is the risk to freeze or the formation of
frost blisters. FIRST aid: keep immediately under running cold water.
Do not pull away!
Do not touch the inside surface of the freezer storage compartment
when in operation, especially with wet hands, as your hands may freeze
onto the surface.
Unplug the appliance in the event of a power interruption or before
cleaning. Allow at least 5 minutes before restarting the appliance, as
frequent starting may damage the compressor.
WARNING: Do not use electrical devices inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
Maintenance / cleaning
Make sure children are supervised if they carry out cleaning and
maintenance. Disconnect the appliance from the electrical supply
before undertaking any routine maintenance. Allow at least 5 minutes
before restarting the appliance, as frequent starting may damage the
compressor.
4

Hold the plug, not the cable, when unplugging the appliance.
Do not clean the appliance with hard brushes, wire brushes, detergent
powder, petrol, amyl acetate, acetone and similar organic solutions, acid or
alkaline solutions. Please clean with special refrigerator detergent to avoid
damage.
Do not scrape off frost and ice with sharp objects. Do not use sprays,
electric heaters like heater, hair dryer, steam cleaners or other sources of
heat in order to avoid damage to the plastic parts.
WARNING:Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
Do not try to repair, disassemble or modify the appliance by yourself.
In case of repair please contact our customer service.
Eliminate the dust on the back of the unit at least once in the year to avoid
hazard by fire, as well as increased energy consumption.
Do not spray or flush the appliance during cleaning.
Do not use water spray or steam to clean the appliance.
Do not clean the cold glass shelves with hot water. Sudden temperature
change may cause the glass to break.
Refrigerant gas information
The appliance contains the flammable refrigerant ISOBUTANE(R600a).
Make sure the refrigerant circuit is not damaged during transportation or
installation. Leaking refrigerant may cause eye injuries or ignite. If a damage
has occurred, keep away open fire sources, throughly ventilate the room,
do not plug or unplug the power cords of the appliance or any other
appliance.Inform the customer service. In case of eyes get into contact
with the refrigeran, rinse immediately it under running water and call
immediately the eye specialist.
5

This product contains flammable refrigerant isobutane (R600a)
It is hazardous for anyone other than an Authorised Service Person to
service this appliance. In Queensland – the authorized Service Person
MUST hold a Gas Work Authorisation f or hydrocarbon refrigerants, to
carry out Servicing or repairs which involve the removal of covers .
The symbol indicates there is a risk of fire since flamma-
ble materials are used. Take care to avoid causing a fire
by ingiting flammable material.
6

-
Please abandon the refrigerator according to local regulators for it use flammable blowing gas
and refrigerant.
Intended use
This appliance is intended to be used in household and similar applications such as
– staff kitchen areas in shops, offices and other working environments;
– farm houses and by clients in hotels, motels and other residential type environments;
– bed and breakfast type environments;
– catering and similar non-retail applications.
Changes or modifications to the device are not allowed. Unintended use may cause hazards
and loss of warranty claims.
7

8
Storage tray
Switch Zone storage drawer
Door shelf
Cabinet shelf
Ceiling light
10 Ice storage bin
15 Storage drawer
17 Adjustable feet
12 Air duct
9 Air duct
C:Switch Zone compartment
16 Adjustable feet
8
Water dispenser
5 Water filter
11 Storage tray
Humidity zone drawer
C

Before first use
Remove all packaging materials, keep them out of children`s reach and dispose them in an
environmentally friendly manner.
Clean the inside and outside of the appliance with water and a mild detergent before putting
any food in it.
After the appliance has been levelled and cleaned, wait for at least 2-5 hours before
connecting it to the power supply. See Section INSTALLATION.
Precool the compartments at high settings before loading with food. The function Super-
Freeze helps to cool down the compartments quickly.
The refrigerator temperature ,Switch Zone temperature and freezer temperature are
automatically set to5℃，-18℃and -18℃respectively. These are the recommended
settings. If desired, you can change these temperatures manually. Please see ADJUST THE
TEMPERATURE.
A Fridge Compartment
B Switch Zone
C Freezer Compartment
D Temperature Display
E Ice Boost
F Water Filter Replacement
G Super Freeze Function
H Ice Maker
I Water On
J Panel lock
K Temperature control "-"
L Compartment selection
M Temperature control "+"
N Super Freeze function selector
O Ice maker function selector
P Water On function selector
Q Panel lock selector
9
H
J
KL
M
P
N
O
Q
EF
G
I

O
edal
box
10

The appliance is preset to the remomended temperature of 5 ℃（Refrigerator）-18℃
（Switch Zone）and -18℃（Freezer）.Under normal ambient condition you need not to
set a temperature.
When the appliance is switched on after disconnection from the main power supply, it may
take up to 12 hours for the correct temperatures to be reached.
Sensor keys
The buttons on the control panel are sensor keys, which already respond when lightly
touched with the finger.
Switch on /off the appliance
The appliance is in operation as soon as it is connected to the power supply.
When the refrigerator is first powered on, the indicator “D” (Temperature display)
illuminates.
The fridge temperature, Switch Zone temperature and freezer temperature are
automatically set to 5℃, -18℃and -18℃respectively.
Maybe the panel lock is active.
Empty the appliance before switching off.To switch of the appliance,pull the power cord
out of the power socket.
11

Standby-mode
Manual adjusting mode
If you want to manually adjust the temperature of the appliance ,you can set the
temperature via a temperature adjust button （refer to ADJUST THE
TEMPERATURE）.
Adjust the temperature
The indoor temperatures are influenced by the following factors:
Ambient temperature
Frequency of door opening
Amount of stored foods
Installation of the appliance
Lock/unlock panel
The display screen turns off automatically 30seconds after pressing a key .The display
will be automatically locked.It lights up automatically when pressing any key or
opening any door （Alarm does not light up the display screen）
Door alarm
Door alarm will trigger when door opens for long time or not closed properly, as a
reminder.
12

Adjust the temperature for Freezer
Unlock the settings by long pressing key “Q” for 3
seconds.
Under unlock state, press key “L” (Temperature zone
selector) to toggle across compartments. When
indicator “C” (Freezer Compartment indicator) lights up,
press key “K” (Temperature control “-”) or key “M”
(Temperature control “+”) to adjust Freezer
compartment temperature. Value displayed on indicator
“D” decreases by 1 °C when key “K” is pressed each time.
The display flahes and turns solid with the set
temperature, then goes off after a few seconds.
Accordingly, value displayed on indicator “D” increases by
1 °C when key “M” is pressed each time. The display
flahes and turns solid with the set temperature, then
goes off after a few seconds. Freezer compartment
temperature can be adjusted from -14 °C to -24 °C with
1 °C incremental.
Freezer temperature can't be adjusted under Super Freeze and lock state.
13

Unlock the settings by long pressing key “Q” for 3
seconds.
Under unlock state, press key “L” (Temperature zone
selector) to toggle across compartments. When
indicator “A” (Fridge compartment indicator) lights up,
press key “K” (Temperature control “-”) or key “M”
(Temperature control “+”) to adjust the fridge
compartment temperature. Value displayed on
indicator “D” decreases by 1 °C when key “K” is
pressed each time. The display flahes and turns solid
with the set temperature, then goes off after a few
seconds. Accordingly, value displayed on indicator “D”
increases by 1 °C when key “M” is pressed each time.
The display flahes and turns solid with the set
temperature, then goes off after a few seconds.
Fridge compartment temperature can be adjusted
from 1 °C to 9 °C with 1 °C incremental.
Adjust the temperature for Fridge
14
Fridge temperature can't be adjusted under lock state.

Unlock the settings by long pressing key “Q” for 3 seconds.
Under unlock state, press key “L” (Temperature zone
selector) to toggle across compartments. When indicator “B”
(SwithcZone indicator) lights up, press key “K” (Temperature
control “-”) or key “M “(Temperature control “+”) to adjust
SwitchZone compartment temperature. Value displayed on
indicator “D” decreases by 1 °C when key “K” is pressed each
time. The display flahes and turns solid with the set
temperature, then goes off after a few seconds. Accordingly,
value displayed on indicator “D” increases by 1 °C when key
“M” is pressed each time. The display flahes and turns solid
with the set temperature, then goes off after a few seconds.
Switch Zone compartment temperature can be adjusted
from 5 °C to -18 °C with 1 °C incremental.
Adjust Switch Zone temperature
Switch Zone temperature can't be adjusted under lock state.
15

Super Freeze function
Super Freeze function can freeze the fresh food as soon as
possible to the core by accelerating the freezing to preserve
the best nutritional value, appearance and taste of food. If
you need to freeze a large amount of food once, it is
recommended to set the Super Freeze function on ahead
for 24 hours before the usage of freezer compartment.
Under unlock state, press key “N” (Super Freeze function
selector), indicator “G” (Super Freeze function indicator)
lights up, product enters Super Freeze mode. Product
automatically exits Super Freeze mode after 50 hours of
activation. For manually exiting Super Freeze mode, press
key “N” (Super Freeze function selector) under unlock state,
indicator “G” (Super Freeze function indicator) goes off,
product exits Super Freeze mode.
Under Super Freeze mode, key “K” (Temperature control “-”) & key “M” (Temperature
control “+”) are locked when freezer compartment is selected and freezer compartment
temperature cannot be adjusted.
16

Under unlock state, press key “O” (Ice maker
selector), indicator “H” (Ice maker indicator) lights up,
product enters Ice maker mode. For exiting Ice
maker mode, press key “O” (Ice maker selector)
under unlock state, indicator “H” (Ice maker indicator)
goes off, product exits Ice maker mode.
Ice maker
The ice maker is off by default when the refrigerator is powered on for the first time.
The ice maker is designed to automatically dispense ice into the ice storage bin and it will
stop when it detects the bin is full. The more ice you use, the more ice it makes.
17

3 Sec.Ice Boost
Under unlock state, press key “O”(Ice maker selector) for 3
seconds, indicator “H”(Ice maker indicator) and indicator
“E”(Ice Boost indicator) light up, and Ice Boost function is
enabled.
In unlock state and under Ice Boost function, press key “O”
(Ice maker selector) for 3 seconds, after hearing one
beeping sound, Indicator “E”(Ice Boost indicator) goes off,
product exits Ice Boost function. And Ice maker indicator
“H” still lights up, with Ice maker function still activated.
Note: If the Ice maker is enabled before entering the Ice Boost function. When products
exits Ice Boost function, Ice maker indicator “H” still lights up and Ice maker is still working
normally; If the ice maker is disabled before entering the Ice Boost function, when
product exits Ice Boost function, the Ice maker indicator “H” goes off and the ice maker
stops working as well.
18
