TATA Motors Voltas Beko MC 23 BSD User manual

User ’s
Manual
Microwave
MC 23 BSD
EN HI

Please read this manual first!
Dear Customer,
Thank you for purchasing a Beko product. We hope that you get the best results from
your product which has been manufactured with high quality and state-of-the-art
technology. Therefore, please read this entire user manual and all other accompanying
documents carefully before using the product and keep it as a reference for future use.
If you handover the product to someone else, give the user manual as well. Follow all
warnings and information in the user manual.
Meanings of the symbols
Following symbols are used in the various section of this user manual:
C
Important information and useful
hints about usage.
A
Warnings for dangerous situations
concerning the safety of life and
property.
Warning for hot surfaces.
This product has been manufactured in environmentally modern facilities.
This appliance conforms to the WEEE regulation. This product does not contain PCB’s

Microwave Oven / User Manual 3 / EN
CONTENTS
ENGLISH 04-33
 34- 64
01M-8813663500-3218-01

Microwave Oven / User Manual
4 / EN
1Important safety and environmental
instructions
Important Safety
Instructions Read
Carefully And Keep For
Future Reference
This section contains safety
instructions that will help protect
from risk of fire, electric shock,
exposure to leak microwave energy,
personal injury or property damage.
Failure to follow these instructions
shall void any warranty.
1.1 General safety
•The microwave oven is intended
for heating food and beverages.
Drying of food or clothing and
heating of warming pads, slippers,
sponges, damp cloth and similar
may lead to risk of injury, ignition
or fire.
This appliance is intended to be
used in household and similar
applications such as:
− Staff kitchen areas in shops,
offices and other working en-
vironments;
− Farm houses
− By clients in hotels, and other
residential type environments;
− Bed and Breakfast type envi-
ronments.
•Do not attempt to start the oven
when its door is open; otherwise
you may be exposed to harmful
microwave energy. Safety locks
should not be disabled or tam-
pered with.
•Do not place any object between
the front side and the door of the
oven. Do not allow dirt or cleaning
agent remnants to build up on the
closure surfaces.
•Any service works involving re-
moval of the cover that provides
protection against exposure to
microwave energy must be per-
formed by authorized persons/
service. Any other approach is
dangerous.
•Your product is intended for
cooking, heating and defrost
food at home. It must not be
used for commercial purposes.
Manufacturer shall not be held li-
able for damages that have arisen
from misuse.
•Do not use this appliance out-
doors, bathrooms, humid environ-
ments or in places where the it
can get wet.

Microwave Oven / User Manual 5 / EN
1Important safety and environmental
instructions
•No responsibility or warranty claim
shall be assumed for damages
arising from misuse or improper
handling of the appliance.
•Never attempt to dismantle the
appliance. No warranty claims are
accepted for damage caused by
improper handling.
•Only use the original parts or parts
recommended by the manufac-
turer.
•Do not leave this appliance unat-
tended while it is in use.
•Always use the appliance on a
stable, flat, clean dry, and non-slip
surface.
•The appliance should not be oper-
ated with an external clock timer
or separate remote control sys-
tem.
•Before using the appliance for the
first time, clean all parts. Please
see the details given in the “Clean-
ing and Maintenance” section.
•Operate the appliance for its in-
tended purpose only as described
in this manual. Do not use abrasive
chemicals or steam on this appli-
ance. This oven is particularly in-
tended for heating and cooking
the food.
•It is not intended for industrial or
laboratory use.
•Do not use your appliance to dry
clothes or kitchen towels.
•Appliance becomes very hot while
it is in use. Pay attention not to
touch the hot parts inside the
oven.
•Your oven is not designed to dry
any living being.
•Do not operate the oven empty.
•Only use utensils that are suitable
for use in microwave ovens.
•Cooking utensil may get hot due
to the heat transferred from the
heated food to the utensil. You
may need oven gloves to hold the
utensil.
•Utensils shall be checked to en-
sure that they are suitable for use
in microwave ovens.
•Do not place the oven on stoves or
other heat generating appliances.
Otherwise, it may be damaged
and the warranty becomes void.
•Microwave oven must not be
placed in a cabinet that is not in
compliance with the installation
instructions.

Microwave Oven / User Manual
6 / EN
•Steam may come out while open-
ing the covers or the foil after
cooking the food.
•Use gloves while taking any kind
of heated food out.
•The appliance and its accessible
surfaces may be very hot when
the appliance is in use.
•Door and outer glass may be very
hot when the appliance is in use.
1.1.1 Electrical safety
•If the supply cord is damaged, it
must be replaced by the manu-
facturer or its service agent or a
similarly qualified person in order
to avoid a hazard.
•Beko Microwave Ovens comply
with the applicable safety stan-
dards; therefore, in case of any
damage on the appliance or power
cable, it should be repaired or re-
placed by the dealer, service cen-
ter or a specialist and authorized
service alike to avoid any danger.
Faulty or unqualified repair work
may be dangerous and cause risk
to the user.
•Make sure that your mains power
supply complies with the informa-
tion supplied on the rating plate of
the appliance.
The only way to disconnect the
appliance from the power supply
is to remove the power plug from
the power outlet.
•Use the appliance with a grounded
outlet only.
•Never use the appliance if the
power cable or the appliance itself
is damaged.
•Do not use this appliance with an
extension cord.
•Never touch the appliance or its
plug with damp or wet hands.
•Place the appliance in a way so
that the plug is always accessible.
•Prevent damage to the power
cable by not squeezing, bending,
or rubbing it on sharp edges. Keep
the power cable away from hot
surfaces and naked flame.
•Make sure that there is no danger
that the power cable could be ac-
cidentally pulled or that someone
could trip over it when the appli-
ance is in use.
•Unplug the appliance before each
cleaning and when the appliance
is not in use.
•Do not pull the power cable of the
appliance to disconnect it from its
power supply and never wrap its
power cable around the appliance.
1Important safety and environmental
instructions

Microwave Oven / User Manual 7 / EN
•Do not immerse the appliance,
power cable, or power plug in
water or any other liquids. Do not
hold it under running water.
•When heating food in plastic or
paper containers, keep an eye on
the oven due to the possibility of
ignition.
•Ensure containers are suitable for
microwave use.
•Remove the wire strings and/or
metal handles of paper or plastic
bags before placing bags suitable
for use in microwave oven to the
oven.
•If smoke is observed, switch off
or unplug the appliance if safe to
do so and keep the door closed in
order to stifle any flames.
•Do not use microwave oven for
storage. Do not leave paper items,
cooking material or food inside the
oven when it is not being used.
•The contents of feeding bottles
and baby food jars should be
stirred or shaken and the temper-
ature checked before consump-
tion, in order to avoid burns.
•This appliance is a Group 2 Class B
ISM equipment. Group 2 contains
all ISM (Industrial, Scientific and
Medical) equipment in which ra-
dio-frequency energy is intention-
ally generated and/or used in the
form of electromagnetic radiation
for the treatment of material, and
spark erosion equipment.
•Class B equipment is suitable for
use in domestic establishments
and establishments directly con-
nected to a low voltage power
supply network.
•Door or outer surface of the appli-
ance may become hot when it is in
use.
1.1.2 Product safety
•Be careful when removing bev-
erages and food from the micro-
wave.
•Do not use cooking oil in the oven.
Hot oil may damage the compo-
nents and materials of the oven,
and it may even cause skin burns.
•Pierce food with thick crust such
as potatoes, courgettes, apples
and chestnuts.
•Appliance must be placed so that
the rear side is facing the wall.
1Important safety and environmental
instructions

Microwave Oven / User Manual
8 / EN
•Before moving the appliance,
please secure the turntable to
prevent damage.
•Eggs in their shell and whole hard-
boiled eggs must not be heated in
microwave ovens since they may
explode, even after microwave
heating has ended.
•Never remove the parts at the rear
and sides of the appliance, which
protect the minimum distances
between the cabinet walls and
the appliance in order to allow for
the required air circulation.
1.2 Intended use
•Failure to maintain the oven in a
clean condition could lead to dete-
rioration of the surface that could
adversely affect the life of the
appliance and possibly result in a
hazardous situation.
•Cleaning the door seals and adja-
cent parts: Use hot soapy water.
Clean with a dish cloth, do not
scour. Do not use a metal or glass
scraper for cleaning.
• WARNING: If the door or door
seals are damaged, the oven must
not be operated until it has been
repaired by a competent person.
• WARNING: It is hazardous for
anyone other than a competent
person to carry out any service or
repair operation which involves
the removal of a cover which gives
protection against exposure to
microwave energy.
• WARNING: Liquids and other
foods must not be heated in
sealed containers since they are
liable to explode.
•The oven should be cleaned reg-
ularly and any food deposits re-
moved.
•There should be min 30 cm free
space above the top surface of
the oven.
•Do not use the appliance for any-
thing other than its intended use.
•Do not use the appliance as a heat
source.
•Microwave oven is intended to
thaw, cook and stew food only.
•Do not over-cook foods; other-
wise, you may cause a fire.
•Do not use steam assisted clean-
ers to clean the appliance.
1Important safety and environmental
instructions

Microwave Oven / User Manual 9 / EN
1.3 Children’s safety
•Extreme caution is advised when
being used near children and per-
sons who are restricted in their
physical, sensory or mental abili-
ties.
•This appliance can be used by the
children who are at the age of 8 or
over and by the people who have
limited physical, sensory or men-
tal capacity or who do not have
knowledge and experience, as
long as they are supervised with
regard to safe use of the product
or they are instructed accordingly
or understand the risks of using
the product. Children should not
play with the appliance. Cleaning
and user maintenance procedures
should not be performed by chil-
dren unless they are controlled by
their elders.
•Danger of choking! Keep all the
packaging materials away from
children.
•Only allow children to use the
oven without supervision when
adequate instructions have been
given so that the child is able to
use the microwave oven in a safe
way and understands the hazards
of improper use.
•Due to excessive heat that arises
in grill and combination modes,
children should only be allowed to
use these modes under supervi-
sion of an adult.
•Keep the product and its power
cable so that they are inaccessible
by children under 8 years old.
•The appliance and its accessible
surfaces may be very hot when
the appliance is in use. Keep chil-
dren away.
•The appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of ex-
perience and knowledge, unless
they have been given supervised
or instruction concerning use of
the appliance by a responsible
person for their safely.
•Young children should be super-
vised to ensure that they do not
play with the appliance.
• WARNING: Only allow children
to use the oven without supervi-
sion when adequate instructions
have been given so that the child
is able to use the oven in a safe
way and understands the hazards
of improper use.
1Important safety and environmental
instructions

Microwave Oven / User Manual
10 / EN
1.4 Compliance with the WEEE
Directive and Disposing of the
Waste Product:
This product complies with EU WEEE Directive
(2012/19/EU). This product bears a classification
symbol for waste electrical and electronic
equipment (WEEE).
This product has been manufactured
with high quality parts and materials
which can be reused and are suitable
for recycling. Do not dispose of the
waste product with normal domestic
and other wastes at the end of its service life. Take
it to the collection center for the recycling of
electrical and electronic equipment. Please
consult your local authorities to learn about these
collection centers.
1.5 Compliance with RoHS
Directive
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
1.6 Package information
Packaging materials of the product are
manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials together
with the domestic or other wastes. Take them to
the packaging material collection points
designated by the local authorities.
1Important safety and environmental
instructions

Microwave Oven / User Manual 11 / EN
Markings on the product or the values stated in other documents supplied with the product are values obtained
under laboratory conditions as per relevant standards. These values may vary according to the usage of the
appliance and ambient conditions. Power values are tested at 230V.
2 Your microwave oven
2.1 Overview
1. Control panel
2. Turntable shaft
3. Turntable support
4. Glass tray
5. Oven window
6. Door group
7. Door safety interlock system
8. Grill rack (Can not be used in microwave
function and must be placed on the glass tray)
2.2 Technical data
Power consumption 230 V~50 Hz,
1300 W (Microwave)
1200 W (Grill)
Output 800 W
Input Power
(Convection)
1200 W
Turntable Diameter 270 mm
External dimensions 485X395X293mm
Oven Capacity 23 L
Net weight 15.5 kg
6
7
1
235 4
8

Microwave Oven / User Manual
12 / EN
2.3 Installing the turntable
Göbek (alt kısım)
Cam tabla
Döner tabla desteği
Döner tabla mili
•Never place the glass tray upside down. The
glass tray should never be restricted.
•Both glass tray and turntable support must
always be used during cooking.
•All food and containers of food must always
place on the glass tray for cooking.
•If glass tray or turntable support crack or break,
contact your nearest authorized service center.
2 Your microwave oven
Hub (underside)
Glass tray
Turntable shaft
Turntable support

Microwave Oven / User Manual 13 / EN
3 Installation and connection
3.1 Installation and
connection
•Remove all packing material and accessories.
Examine the oven for any damage such as dents
or broken door. Do not install if oven is damaged.
•Remove any protective film found on the
microwave oven cabinet surface.
•Do not remove the light brown Mica cover that
is attached to the oven cavity to protect the
magnetron.
•Select a flat surface that provides sufficient
space for inlet and outlet ducts.
20 cm
30 cm
20 cm
min.85 cm
30 cm
•Minimum installation height is 85 cm.
•The rear surface of appliance shall be placed
against a wall. Leave a minimum clearance of
30 cm above the oven, a minimum clearance
of 20 cm is required between the oven and any
adjacent walls.
•Do not remove the legs from the bottom of the
oven.
•Blocking the intake and / or outlet openings can
damage the oven.
•Place the oven as far away from radios and TV
as possible. Operation of microwave oven may
cause interference to your radio or TV reception.
2. Plug your oven into a standard household
outlet. Be sure the voltage and the frequency is
the same as the voltage and the frequency on
the rating label.
A
WARNING: Do not install oven
over a range cooktop or other heat-
producing appliance. If installed near
or over a heat source, the oven could
be damaged and the warranty would
be void.
The accessible surface may be hot
during operation.

Microwave Oven / User Manual
14 / EN
4.1 Control panel
Micro. /Grill
Combi. /Conve.
Weight/Time
Defrost
Clock/
Kitchen Timer
Stop/Clear
Start/+30Sec./
Conrm
Operating instructions
This microwave oven uses modern electronic
control to adjust cooking parameters to meet your
needs better for cooking.
4.2 Clock setting
When the microwave oven is energized, "0:00” will
be displayed in screen and buzzer will ring once.
1. Press “Clock/Kitchen Timer” twice and the
figures for hours will start flashing.
2. Turn to adjust the hour; the input value
should be between 0 and 23.
3. Press “Clock/Kitchen Timer” and the figures for
minutes will start flashing.
4. Turn to adjust the minutes; the input value
should be between 0 and 59.
5. Press “Clock/Kitchen Timer” to finish time set-
ting. ":" symbol will flash, and the time will light.
C
If you press “Stop/Clear” during
time setting, oven will automatically
return back to previous mode.
4.3 Microwave cooking
1. Press “Microwave/Grill/Combi./Conve.” and
“P100” will be displayed in screen.
2. Press “Microwave/Grill/Combi./Conve.” again or
turn to select the microwave power from
100% to 10%. Each time you press the key,
“P100”, “P80”, ”P50”, “P30”, “P10”, will be dis-
played respectively.
3. Press “Start/+30Sec./Confirm” to confirm and
turn to set the cooking time to a value be-
tween 0:05 and 95:00.
4 Operation

Microwave Oven / User Manual 15 / EN
4. Press “Start/+30 Sec./Confirm” again to start
cooking.
The steps for adjusting the time in coding button
are as below:
Setting the duration Increment amount
0-1 minute 5 seconds
1-5 minutes 10 seconds
5-10 minutes 30 seconds
10-30 minutes 1 minute
30-95 minutes 5 minutes
Microwave Power Chart
Press Once Twice Thrice 4 times 5 times
Microwave
Power
100% 80% 50% 30% 10%
4.4 Cooking with grill mode
1. Press “Microwave/Grill/Combi./Conve.” and
"P100” will be displayed in screen. Press
“Microwave/Grill/Combi./Conve.” for times
or turn to select the desired power. Stop
turning when “G-1” displays.
2. Press “Start/+30Sec./Confirm” to confirm and
turn to set the cooking time to a value be-
tween 0:05 and 95:00.
3. Press “Start/+30 Sec./Confirm” again to start
cooking.
4 Operation
C
When half the grill time passes,
the oven sounds twice, and this is
normal. In order to have a better
grilling effect, you should turn the
food over, close the door, and then
press “Start/+30Sec./Confirm” to
continue cooking. If no operation is
performed, the oven will continue
cooking.
4.5 Combination Cooking
1. Press “Microwave/Grill/Combi./Conve.” and
“P100” will be displayed in screen. Press
“Microwave/Grill/Combi./Conve.” for times
or turn to select the desired power. Stop
turning when “C-1”, ”C-2”, ”C-3” or “C-4” displays.
2. Press “Start/+30Sec./Confirm” to confirm and
turn to set the cooking time to a value be-
tween 0:05 and 95:00.
3. Press “Start/+30 Sec./Confirm” again to start
cooking.

Microwave Oven / User Manual
16 / EN
4 Operation
Combination instructions
Instructions Display Microwave Grill Convection
1 C-1 • •
2 C-2 • •
3C-3 • •
4 C-4 • • •
4.6 Convection Cooking (With
preheating funtion)
The convection cooking can let you to cook the
food as a traditional oven. Microwave is not used. It
is recommended that you should preheat the oven
to the appropriate temperature before placing the
food in the oven.
1. Press “Microwave/Grill/Combi./Conve.” and
“P100” will be displayed in screen. Keep pressing
“Microwave/Grill/Combi./Conve.” or turn to
select the convection function.
C
The temperature can be chosen
from 110 degrees to 200 degrees.
2. Press the “Start/+30Sec./Confirm” to confirm
the temperature.
3. Press the “Start/+30Sec./Confirm” to start pre-
heating. When the preheating temperature ar-
rives, the buzzer will sound twice to remind you
to put the food into the oven. And the preheat-
ed temperature is displayed and flash.
4. Put the food into the oven and close the door.
Turn to adjust the cooking time. (The maxi-
mum setting time is 95 minutes.)
5. Press the “Start/+30Sec./Confirm” key to start
cooking.
C
Cooking time cannot be input
until the preheating temperature
arrives. If the temperature arrives,
door must be opened to input the
cooking time.
C
If the time not input in 5 minutes,
the oven will stop preheating. The
buzzer sound five times and turn
back to waiting states.
4.7 Convection Cooking
(Without pre-heating
function)
1. Press “Microwave/Grill/Combi./Conve.” and
“P100” will be displayed in screen. Keep pressing
“Microwave/Grill/Combi./Conve.” or turn to
select the convection function.
C
The temperature can be chosen
from 110 degrees to 200 degrees.
2. Press the “Start/+30Sec./Confirm” to confirm
the temperature.
3. Turn to adjust the cooking time. (The maxi-
mum setting time is 95 minutes.)
4. Press the “Start/+30Sec./Confirm“ key to start
cooking.

Microwave Oven / User Manual 17 / EN
4 Operation
4.8 Kitchen timer
Your oven is equipped with an automatic counter
which is not linked with the oven functions and
can be used separately at the kitchen “ it can be
set to max. 95 minutes.”
1. Press “Clock/Kitchen Timer” for once and 00:00
will be displayed in LED screen.
2. Turn to enter the correct time.
3. Press “Start/+30Sec./Confirm” to confirm the
setting.
4. When the countdown from the entered time
reaches to 00:00, the buzzer will ring for 5
times. If the time is set “24-hour system”, cur-
rent time will be displayed in LED screen.
Press “Stop/Clear” to abort the timer at anytime.
C
Kitchen timer functions different
than 24-hours system. Kitchen
timer is just a timer.
4.9 Defrost by weight
1. Press “Weight/ Timer Defrost” once, and the
oven will display “d-1”.
2. Turn to select the weight of food from 100
to 2000 g.
3. Press “Start/+30Sec./Confirm” to start defrost.
4. If “Stop/Clear” is pressed, it will pause. At this
time, press “Stop/Clear” again or the time for
pause is more than 5 minutes, it will turn back
to the waiting state. Press “Start/+30Sec./
Confirm” in 5 minutes, the unit goes on working
and time counts down. When it is finished, the
buzzer sounds five times and turn back to the
waiting state.
5. When half the defrost time pass, the buzzer will
sound twice remind you to turn the food over, if
no action is taken, the unit will continue work-
ing and the defrost result is not well.
4.10 Defrost by time
1. Press “Weight/ Timer Defrost” once, and the
oven will display “d-2”.
2. Turn to select the defrost time. The maxi-
mum time is 95 minutes.
3. Press “Start/+30Sec./Confirm” to start de-
frost. If “Stop/Clear” is pressed,it will “ again
or the time for pause is more than 5 minutes,
it will turn back to the waiting state. Press
“Start/+30Sec./Confirm” within 5 minutes, the
unit goes on working and time counts down.
4.11 Auto menu
1. In waiting state, turn right to choose the
function wanted, and “A1”,”A2”,”A3”....”A153” will
be displayed.
2. Press “Start/+30Sec./Confirm” to confirm the
menu you need.
3. Turn to choose the weight of menu,and “g”
indicator will light.
4. Press “Start/+30Sec./Confirm” to start cooking.

Microwave Oven / User Manual
18 / EN
4 Operation
Auto cooking menu
Menu Weight Power
A1
Pizza
300 g P100 / Grill
400 g
A2
Potato
230 g
P100
460 g
690 g
A3
Meat
200 g
P100
300 g
400 g
500 g
A4
Fish
200 g
P80
300 g
400 g
500 g
A5
Vegetable
200 g
P100
300 g
400 g
500 g
A6
Beverage
1
P100
2
3
A7
Pasta
50 g
P80
100 g
150 g
A8
Popcorn
50 g P100
100 g
A9
Cake
475 g 160°C conv (Preheat first)
A10
Roast Chicken
750 g
C-2
1000 g
1250 g

Microwave Oven / User Manual 19 / EN
4 Operation
A11
Tea / Coffee
1
P100
2
3
A12
Popcorn
100 g P100
A13
Idli/Dhokla
8 P100
A14
Boiled Potato
200 g P100
300 g
A15
Bhindi Masala
250 g P100
500 g
A16
Mutter Paneer
250 g P100
500 g
A17
Sprouts (Moong)
200 g P100
300 g
A18
Steamed Rice
200 g P100
A19
Veg Pulav
200 g P100
A20
Boiled Dal
150 g P100
300 g
A21
Upma
150 g P100
A22
Suji Halwa
150 g P100
A23
Mushroom Cheese Masala
250 g P100
500 g
A24
Grilled Sandwich
2 Grill
A25
Paneer Tikka
250 g 200°C conv (Preheat first)
A26
Grilled Whole Chicken
800 g
C-4
1000 g
1200 g
A27
Hyderabadi Chicken Curry
800 g P100

Microwave Oven / User Manual
20 / EN
4 Operation
A28
Grilled Chicken Legs
300 g 200°C conv (Preheat first)
600 g
A29
Grilled Fish Piece
300 g Micro+grill ( c-2)
500 g
A30
Tandoori Fish
500 g Micro+grill ( c-2)
A31
Veggie Pizza
1 200°C conv (NO preheating)
A32
Vanilla Cake
1 180°C conv (Preheat first)
A33
Chocolate Cake
1 180°C conv (Preheat first)
A34
Fruit Cake
1 180°C conv (Preheat first)
A35
Black Forest Cake
1 180°C conv (Preheat first)
A36
Chocolate Cookies
1 180°C conv (Preheat first)
A37
Custard Cookies
1 180°C conv (Preheat first)
A38
Apple Jam
1 P100
A39
Payasam
1 P100
A40
Gajar Halwa
250 g P100
A41
Kesar Kheer
4 P100
A42
Tomato Rice
150 g P100
A43
Pumpkin Sambar
4 P100
A44
Veg . Coconut Curry
250 g P100
500 g
A45
Fish Curry
250 g P100
500 g
A46
Tomato Rasam
4 P100
