Sharp SMD2480CSC User manual

1E
SPECIAL WARNING
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER.
IMPORTANT: SAVE this installation manual FOR LOCAL ELECTRICAL INSPECTOR’S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CLEARANCES AND DIMENSIONS
For SAFETY CONSIDERATIONS do not install drawer in any combustible cabinetry, which is not in accord with the stated
clearances and dimensions on pages 2 - 5. See Figures 1 - 7.
Microwave Drawer : SMD2480CSC
INSTALLATION MANUAL
UNPACKING YOUR MICROWAVE DRAWER
• Remove all packing
materials from inside
the Microwave Drawer.
DO NOT REMOVE
THE WAVEGUIDE
COVER, which is
located on the top of
the Microwave Drawer.
• Remove the feature
sticker, if there is one.
Check the drawer for
any damage, such as
misaligned or bent
drawer, damaged drawer
seals and sealing surfaces, broken or loose Microwave Drawer
guides and dents inside the cavity or on the front side of the
drawer. If there is any damage, do not operate the Microwave
Drawer and contact your dealer or a SHARP AUTHORIZED
SERVICER.
IMPORTANT NOTES TO THE INSTALLER
• Read all of the Installation Manual before installing the
Microwave Drawer.
• Remove all packing material before connecting the electrical
supply.
• Observe all governing codes and ordinances.
• Be sure to leave these instructions with the consumer.
IMPORTANT NOTES TO THE CONSUMER
Keep this manual with your Operation Manual for future
reference.
• As when using any microwave oven generating heat, there
are certain safety precautions you should follow. These are
listed in the Operation Manual. Read all and follow carefully.
• Be sure your Microwave Drawer is installed and grounded
properly by a qualied installer or service technician.
IMPORTANT SAFETY INSTRUCTIONS
If the information in this manual is not followed
exactly, a re or electrical shock may result that could cause
property damage, personal injury or death.
To reduce the risk of tipping, the Microwave
Drawer must be secured by a properly installed Anti-Tip block.
• This Microwave Drawer must be electrically grounded in
accordance with local codes.
• Make sure the wall coverings and the cabinets around the
Microwave Drawer can withstand the heat generated by the
Microwave Drawer.
Never leave children alone or unattended in
the area where a Microwave Drawer is in use. Never leave the
drawer open when the microwave is unattended.
Stepping, leaning or sitting on the drawer may
result in serious injuries and can also cause damage to the
Microwave Drawer.
• Do not use the Microwave Drawer as a storage space.
This creates a potentially hazardous situation.
• Check that the time-of-day is in the display. If not,
touch STOP/CLEAR for safety reasons and to prevent
unintended use.
Waveguide
Cover
Sealing
Surface
Oven
Cavity
Sealing
Surface
1
TINSKB252MRR0

2
E
D
G
A
B
C
J
H
I
F
E
CLEARANCES AND DIMENSIONS
•Dimensions that are shown in Figure 1 must be used. Given
dimensions provide minimum clearance. Locate electrical
outlet in the shaded area in the upper left-hand corner of the
cutout. See Figure 9.
•Contact surface must be solid and level. Pay special attention
to the oor on which the Microwave Drawer will sit. The
oor of the opening should be constructed of plywood strong
enough to support the weight of the oven (about 100 pounds).
• Check location where the Microwave Drawer will be
installed for proper electrical supply.
• Your oven can be built into a cabinet or wall by itself or
under a gas or electric wall oven.
• Be sure that the clearance of the oor between the wall oven
and the microwave drawer is a minimum of 2-inches.
•The microwave interior will easily accommodate a 9" x 13"
oblong dish or a bag of microwave popcorn.
• The oven can also be mounted ush. Please see instructions
for ush mounting.
24" MICROWAVE DRAWER STANDARD MOUNT AND MEASUREMENTS
B
C
G
D
B
C
DE
F
GH
I
I
J
K
L
M
N
O
P
A
A
F
E
Figure 1
Figure 2
A. 6" (152.40 mm)
B. Suggested electrical
outlet location*
C. Anti-Tip block
D. 5" (127 mm)
E. 3-1/2" (88.90 mm)
F. 4" (101.60 mm)
G. 22-1/8" (561.97 mm)
opening
H. 14-13/16" (376.24 mm) to
bottom of Anti-Tip block
I. Allow 7/8" (22.22 mm)
overlap
J. 23-1/2" (596.90 mm)
minimum depth
K. Allow 7/16" (11.11 mm)
overlap
L. 36" (914.40 mm)
countertop height
M. Allow 7/16" (11.11 mm)
minimum space
N. Floor must support 100 lb
(45.4 kg)
O. 24" (609.60 mm) cabinet
minimum
P. 15-9/16" (395.29 mm)
opening
Figures 1 and 2 contain many Microwave Drawer measurements
for reference when planning the drawer’s location.
This Microwave Drawer can be installed below any electric or
gas wall oven.
* Can also be installed using an electrical outlet in an adjacent cabinet
within the area where the provided electrical cord can reach. Power
cord access hole in cabinet should be a minimum 1 1/2" diameter
hole and deburred of all sharp edges.
IMPORTANT Always allow sufcient power cord length to the
electrical outlet to prevent tension.
Always check electrical codes for requirements.
A. 21-5/8" (549.28 mm)
B. 4-11/16" (119.06 mm)
C. 1-3/4" (44.45 mm)
D. 21-7/8" (555.63 mm)
E. 23-5/8" (600.07 mm)
F. 16" (406.4 mm)
G. 14-19/32" (370.68 mm)
H. 1-17/32" (38.89 mm) door thickness
I. 15" (381 mm) auto drawer opening
J. 4" (101 mm)

3E
B
C
G
D
B
C
DE
F
GH
I
I
J
K
L
M
N
O
P
A
Q
A
F
E
Figure 3 represents a typical standard cabinet. If installed in
custom cabinets with extended counter tops, take into account
visibility and access to controls. See Figure 4.
Move oven location downward for
extended countertops
Extended countertops
Figure 4
Figure 3
A. 25" (635 mm)
B. 1/2" (12.7 mm) minimum
C. 16" (406.4 mm)
D. 36" (914.40 mm)
E. Control panel shown in
open position
F. 24" (609.60 mm)
G. 34-1/2" (876.30 mm)

4
E
24" MICROWAVE DRAWER FLUSH MOUNT AND MEASUREMENTS
C
N
H
E
F
D
A
B
J
L
I
M
K
G
1. Prepare cabinet opening as shown in Figures 5, 6, 7
CL
Top view
A
Anti-Tip block
Mounting cleat
BC
Drawer face Cabinet
face
Note: the mounting surface of the finished cleat must
sit 1
17
/32" (38.89 mm) back from the face of the cabinet.
Figure 5
Figure 6
A. 6" (152.40 mm)
B. Suggested electrical outlet location
C. Anti-Tip block
D. 5" (127 mm)
E. 3-1/2" (88.90 mm)
F. 4" (101.60 mm)
G. 23-7/8" (606.43 mm)
H. 14-13/16" (376.24 mm) to bottom of
Anti-Tip block
I. 1-1/16" (26.97 mm)
J. 23-1/2" (596.90 mm) minimum depth
K. 22-1/8" (561.97 mm)
L. 1-17/32" (38.89 mm) to front of shelf
M. 16-1/4" (412.75 mm) opening
N. Floor must support 100 lb (45.4 kg)
A. 22-1/8" (596.9 mm) mounting cleat opening width
B. 0" ush
C. 1-17/32" (38.89 mm) front of cleat to cabinet face
C
Front view
No oven shown
B
A
Suggested electrical
outlet location Anti-Tip block
Figure 7
A. 22-1/8" (561.97 mm) mounting cleat opening width
B. 23-7/8" (606.43 mm) ush opening width
C. 1/8" (3.17 mm) from opening to top of shelf

5E
ANTI-TIP BLOCK
NORMAL INSTALLATION STEPS
ANTI-TIP BLOCK INSTALLATION INSTRUCTIONS
To reduce the risk of tipping of the drawer, the Anti-Tip block must
be properly installed located 14 13/16-inches above the oor on
which the Microwave Drawer will sit. The 6-inch Anti-Tip block
must be provided by the installer. See Figure 1. The Anti-Tip block
prevents serious injury that might result from spilled hot liquids.
If the Microwave Drawer is ever moved to a different location, the
Anti-Tip block must also be moved and installed. When installed
to the wall, make sure that the screws completely penetrate the
dry wall and are secured in wood or metal so that the block is
totally stable. When fastening, be sure that the screws do not
penetrate electrical wiring or plumbing.
Figure 8
ELECTRICAL OUTLET
The electrical requirements are a 120 volt 60 Hz, AC only, 15
amp. or more protected electrical supply. It is recommended that
a separate circuit serving only this appliance be provided.
The drawer is equipped with a 3-prong grounding plug. It must
be plugged into a wall receptacle that is properly installed and
grounded. Should you only have a 2-prong outlet, have a qualied
electrician install a correct wall receptacle.
Note: If you have any questions about the grounding or electrical
instructions, consult a qualied electrician or service person.
* Can also be installed using an electrical outlet in an adjacent cabinet
within the area where the provided electrical cord can reach.
Always check electrical codes for requirements.
Figure 9
GROUNDING INSTRUCTIONS
This appliance must be grounded. The Microwave Drawer is
equipped with a cord having a grounding wire with a grounding
plug. It must be plugged into a wall receptacle that is properly
installed and grounded in accordance with the National Electrical
Code and local codes and ordinances. In the event of an electrical
short circuit, grounding reduces risk of electric shock by providing
an escape wire for the electric current.
– Improper use of the grounding plug can result
in a risk of electric shock. Do not use an extension cord. If the
power supply cord is too short, have a qualied electrician or
serviceman install an outlet near the appliance.
3-Prong plug
Grounding pin
3-Prong receptacle
Grounded receptacle box
Grounding adapter
Grounded receptacle box
Screw
Tab for grounding screw
DRAWER INSTALLATION
1. Place the drawer adjacent to the wall or cabinet opening. Plug
the power supply cord into the electrical outlet.
2. Carefully guide the drawer into the prepared opening. Avoid
pinching the cord between the oven and the wall.
3. Slide the drawer all the way until the mounting ange is ush
with the face of the cabinet. See Figure10.
4. Open the drawer. Using the 4 holes on the drawer as a template,
pre drill the cabinet using a 1/16" bit. See Figure 10.
5. Secure the drawer with the 4 screws supplied. See Figure 11.
Mounting
flange
Figure 10
Parts supplied - 4 Screws
Figure 11

6
E
MODEL AND SERIAL NUMBER LOCATION
The name plate includes model and serial number. Open the
Microwave Drawer fully. The label is beyond the back wall of
the microwave cavity facing up from the at surface.
CARE, CLEANING AND MAINTENANCE
Refer to the Operation Manual for cleaning instructions.
BEFORE YOU CALL FOR SERVICE
Read the BEFORE YOU CALL and operating instruction sections
in your Operation Manual. It may save you time and expense.
The list includes common occurrences that are not the result of
defective workmanship or materials in this microwave.
Refer to the warranty in your Operation Manual for Sharp’s
toll-free service number and address. Please call or write if you
have inquiries about your microwave product and/or need to
order parts.
SHARP ELECTRONICS OF CANADA LTD
335 Britannia Road East • Mississauga, Ontario • L4Z 1W9
