TCL LE50FHDE5510C User manual

Need assistance?
visit our website at www.tclusa.com
or call 1-877-300-8837 (for mainland 48 States),
or 1-877-800-1269 (for AK, HI, and Puerto Rico).
For use with models: LE50FHDE5510C
LE55FHDE5510C / LE50FHDE5510CTA / LE55FHDE5510CTA
Figures and illustrations in this User’s Guide are
actual product appearance. Product design and

1
Refer to the identication/rating label located on the back panel of your product for its proper operating voltage.
FCC regulations state that unauthorized changes or modications to this equipment may void the user’s authority to
operate it.
Cable TV Installer: This reminder is provided to call your attention to Article 820-40 of the National Electrical Code
(Section 54 of the Canadian Electrical Code, Part 1) which provides guidelines for proper grounding and, in particular,
species that the cable ground should be connected to the grounding system of the building as close to the point of
cable entry as practical.
Important: This television is a table model and is designed to sit on a rm, at surface. Don’t place the TV on soft
carpeting or similar surface because the ventilation slots on the bottom of the unit will be blocked, resulting in reduced
lifetime from overheating. To assure adequate ventilation for this product, maintain a spacing of 4 inches from the top
and side of the TV receiver and 2 inches from the rear of the TV receiver and other surfaces.
Also, make sure the stand or base you use is of adequate size and strength to prevent the TV from being accidentally
tipped over, pushed off, or pulled off. This could cause personal injury and/or damage to the TV. Refer to the
Important Safety Instructions on the next page.
The Power button (followed by the power symbol) on this TV and your remote control puts the TV into a very low-
power standby mode but will not completely turn the power off. In order to completely shut the power off, you will
need to disconnect the power cord from the outlet. The mains plug/appliance coupler is used as disconnect device,
the disconnect device shall remain readily operable. Therefore, you should ensure that the TV is installed in a manner
that allows you to disconnect the power cord when desired.
Product Registration
Please register your TCL purchase on-line at www.tclusa.com. It will make it easier to contact you should it ever be
necessary. Registration is not required for warranty coverage.
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the
serial and model numbers in case you need them. These numbers are located on the product.
Model No. ______________________ Serial No._____________________________________
Purchase Date __________________ Dealer/Address/Phone__________________________
Caution: To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside.
Refer servicing to qualied service personnel.
This symbol indicates “dangerous voltage”
inside the product that presents a risk of
electric shock or personal injury.
This symbol indicates important
instructions accompanying the product.
This symbol indicates that this product
incorporates double insulation between hazardous
main voltage and user accessible parts. When
servicing, use only identical replacement parts.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
Important Information
WARNING The batteries shall not be exposed to excessive heat such as sunshine, re or the like.
WARNING
To reduce the risk of re or electric shock, do not
expose this product to rain or moisture. This product
should not be exposed to dripping or splashing. No
objects lled with liquids, such as vases, should be
placed on the component.
WARNING
The TV is unstable if it is not properly attached to the
base or mounted to the wall. Please follow the base
or wall mounting instructions provided in the User’s
Guide to ensure your safety.

2
Important Safety Instructions
1. Read and follow all instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
5. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
6. Protect the power cord from being walked on or pinched particularly at plugs, receptacles, and the point
where it exits from the component.
7. Do not use this component near water.
8. Only use the attachments/accessories specied by the manufacturer.
9. Clean only with dry cloth.
10. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the
component. When the TV is placed on a cart, use caution when moving the cart to avoid injury from tip-
over.
11. Warning: To avoid any injury caused by lean of the product, please always ensure the whole product was
place within the table surface in horizontal.
12. Unplug this component during lightning storms or when unused for long periods of time.
13. Refer all servicing to qualied service personnel. Service is required when the component is damaged
in any way, such as power supply cord or plug damage, liquid spilled on or objects falling onto the
component, rain or moisture exposure, abnormal operation, or if the component has been dropped.
14. If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is
grounded so as to provide some protection against voltage surges and built-up static charges. Section 810
of the National Electrical Code, ANSI/NFPA No. 70-1984 (Section 54 of Canadian Electrical Code, Part 1)
provides information with respect to proper grounding of the mast and supporting structure, grounding of
the lead-in wire to an antenna-discharge unit, size of grounding conductors, location of antenna-discharge
unit, connection to grounding electrodes, and requirements for the grounding electrode. See following
example:
ANTENNA LEAD IN WIRE
GROUND CLAMP
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PARTH)
ELECTRIC SERVICE
EQUIPMENT
ANTENNA DISCHARGE
UNIT(NEC SECTION 810-20)
ANTENNA LEAD IN WIRE
GROUND CLAMP
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
GROUND CLAMPS
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
ELECTRIC SERVICE
EQUIPMENT POWER SERVICE GROUNDING
ELECTRODE SYSTEM (NEC ART
250, PARTH)

3
Table of Contents
Important Information ..............................1
Important Safety Instructions ...................2
Chapter 1 - Connections and Setup
Before Initial Setup .................................4
Check Supplied Parts .............................4
Attaching Your TV to the Table Stand ......... 5
Mounting Your TV to the Wall ..................5
Buttons on TV ...........................................6
Explanation of Jacks on TV .......................6
Choose Your Connections .......................7
Nework Connection .................................9
Connecting to a wired network .............9
Network Setup .........................................9
Internet Connections ............................9
Wired Network Setup ...........................9
Wireless Network Setup .......................10
Information ..........................................10
IP setting .............................................10
Connection Test ....................................10
Remote Control Functions .......................11
Obtain the Signal .....................................12
Switching On ...........................................12
Switching Off ...........................................12
Initial Set-up.............................................13
Chapter 2 - Menu Operation
Menu Display ...........................................14
Using Menu System ................................15
Picture Menu ...........................................15
Picture Mode ........................................15
Dynamic Backlight ................................15
Brightness ............................................15
Contrast ................................................15
Tint........................................................15
Color .....................................................15
Sharpness ............................................15
Color Temperature ................................15
Advanced Settings ...............................15
Sound Menu ............................................15
Sound Mode .........................................15
Balance ................................................15
Sound Surround ...................................15
Speaker ................................................15
SPDIF Type ..........................................15
Auto volume control..............................15
MTS ......................................................15
Default Audio Language .......................15
Current Audio Language ......................16
TV Menu ..................................................16
Signal Type ...........................................16
Channel Scan .......................................16
Channel Skip ........................................16
Time Menu ...............................................17
Time Zone ............................................17
Daylight Saving Time............................17
Time .....................................................17
Sleep timer ...........................................17
Connection Menu ....................................17
Netix ...................................................17
Yahoo! Connected TV...........................17
YouTube ...............................................17
Share & See .........................................17
Settings ................................................17
Media Menu .............................................18
Photo ....................................................18
Music ...................................................18
Video ...................................................18
Parental Menu .........................................19
Change V-Chip Password ....................19
Channel Block .....................................19
Program Block ......................................19
Input Block............................................20
Button Block ........................................20
Clean all ...............................................20
Setup Menu .............................................20
OSD Language.....................................20
Screen Mode........................................20
Closed Caption ....................................20
System Information .............................21
Software Upgrade ...............................21
Esticker .................................................21
Reset Default .......................................21
Chapter 3 - Other Information
Frequently Asked Questions (FAQs) .......22
Troubleshooting .......................................23
Care and Cleaning...................................25
Television Specications..........................26
Limited Warranty .....................................27

4
Before Initial Setup
Protect Against Power Surges
• Connect all components before you plug any power cords into the wall outlet or power strip.
• NEVER plug your TV into an outlet that is controlled by a wall switch.
• Turn off the TV before you connect or disconnect any cables.
• Make sure all antennas and cables are properly grounded. Refer to the Important Safety
Instructions.
Safety Information
• Protect components from overheating.
• Don’t block ventilation holes on any of the components. Arrange the components so that air can
circulate freely.
• Don’t stack components.
• If you place the component in a stand, make sure you allow adequate ventilation.
• If you connect an audio receiver or amplier, place it on the top shelf so the heated air from it won’t
harm other components.
Avoid Audio Interference
• Position cables properly; insert each cable rmly into the designated jack.
• If you place components above the TV, route all cables down one side of the back of the TV instead
of straight down the middle.
• If your antenna uses 300-ohm twin lead cables, do not coil the cables.
• Keep twin lead cables away from audio/video cables.
Avoid Direct Light
Don’t place the TV where sunlight or room lighting is directed toward the screen. Use soft or indirect
lighting.
Check Supplied Parts
Check that the following parts were packed with your product.
• 1 Remote Control and 2 AAA Batteries;
• Audio/Video adapter cable;
• Audio adapter cable;
• Component Video (YPbPr) adapter cable;
• User’s Guide;
• Quick Start Guide;
• Parts List for Table Stand (see page 5)
Chapter 1 Connections and Setup

5
Attaching Your TV to the Table Stand
Your TV comes without the table stand attached so that you can choose to mount your TV either to
its table stand or to a wall (wall mount sold separately). If you want to mount your TV to the wall, don’t
attach the table stand. Follow the Mounting Your TV to the Wall instructions.
First, remove the TV bag and place it on a large, at surface such as a table or countertop.
Remove the TV from the carton and place it face down on the TV bag. Be sure that the TV is
face down to avoid scratching the screen.
Then follow the steps below:
Connections and Setup
Mounting Your TV to the Wall
The VESA number is the horizontal and vertical measurement of the mounting holes. For example,
200x100 refers to the fact that the mounting measurements are 200mm horizontally and 100mm vertically.
Notes: Follow the directions included with the wall mount to mount the TV to the wall.
Caution: Your wall mount must be able to bear a minimum of ve times the TV’s net weight to avoid causing damage.
To mount your TV to the wall, purchase a VESA wall mount.
Model 50”
Model 55”
Purchase a VESA 400 x 200, M6 screw
Purchase a VESA 400 x 400 , M6 screw
12
one M3 screw
four M4 screws
TV
three M5 screws
Table Stand

6
Connections and Setup
Buttons on TV
If you cannot locate your remote, you can use the TV panel buttons on
your TV to operate many TV features.
CH+/- Selects channels stored in the channel list or acts as the
up/down arrow (▲/▼) through the menu items.
VOL+/- Increases/decreases the volume or acts as the right/left
arrow(◄/►) through the menu items.
(MENU button) Brings up the TV’s main menu.
(INPUT button) Selects the signal source.
(POWER button) Turns the TV on or to standby mode.
CH
VOL
Explanation of Jacks on TV
This section describes the jacks on the side/back panel of your TV. There are
several ways to connect components.
Ethernet
Lets you connect an Ethernet cable to access the Internet.
AUDIO OUT Adapter
(you must connect an audio adpter cable with two color jacks to this adpater jack rst, red and
white jacks for R AUDIO and L AUDIO connection)
Use an RCA audio cable to connect your TV to a compatible audio
receiver.
VGA (PC IN) Connect your computer or other component with a VGA output to this jack using a 15-pin,D-sub cable.
DVI/PC AUDIO IN (used for DVI/PC only) Provides audio connection when using HDMI/DVI INPUT 1 jack for DVI
or when using VGA (PC IN).
AV 2 IN adapter
Lets you connect a component that has composite video jacks, such as a VCR or DVD player. (Note
that you must connect an Audio/Video adpter cable with three color jacks to this adapter jack rst, Yellow jack for VIDEO
connection, red and white jacks for R AUDIO and L AUDIO connection. For mono audio sources, be sure to use the L
AUDIO INPUT. )
ANTENNA/CABLE/SAT IN Lets you connect a coaxial cable to receive the signal from your antenna, cable, or
cable box, satellite receiver.
CMPT AUDIO IN adapter Provides left and right audio connection when using the CMPT VIDEO input.
(Note that
you must connect an Audio adpter cable with two color jacks to this adapter jack rst, red and white jacks for R AUDIO
and L AUDIO connection. For mono audio sources, be sure to use the L AUDIO INPUT. )
CMPT IN (Y Pb Pr) adapter Lets you connect a component that has component video jacks, such as a DVD
player. (Note that you must connect a Component Video adpter cable with three color jacks to this adapter jack rst:
Green jack for Y, Blue jack for Pb and Red jack for Pr )
• YPbPr(ComponentVideo) Provides good picture quality because the video is separated into three signals. Use
three video-grade or component video cables for the connection.
Ethernet AUDIO OUT
adapter DVI/PC
AUDIO IN
AV 2 IN
adapter
ANTENNA
/CABLE/SAT IN
CMPT IN
adapter
CMPT AUDIO
IN adapter
PC IN

7
Connections and Setup
USB
Allows you to connect a compatible mass storage device.
SPDIF(optical) - DIGITAL AUDIO OUT
Use a digital optical cable to connect your TV to a compatible audio receiver.
(HEADPHONE)
Allow you to connect headphones to listen to the sound coming from the TV.
AV 1 IN adapter
Lets you connect a component that has composite video jacks, such as a VCR or
DVD player. (Note that you must connect an Audio/Video adpter cable with three color
jacks to this adapter jack rst, Yellow jack for VIDEO connection, red and white jacks
for R AUDIO and L AUDIO connection. For mono audio sources, be sure to use the
L AUDIO INPUT. )
HDMI 2 IN / HDMI 3 IN / HDMI 4 IN
Lets you connect a component, such as a digital cable box, with an HDMI output
for the best picture quality.
HDMI 1/DVI IN
(High-Denition Multimedia Interface/Digital Visual Interface) Provides an
uncompressed digital connection that carries both video and audio data by way
of an integrated mini-plug cable. Since HDMI technology is based on Digital
Visual Interface (DVI), the jack on the back of your TV is also compatible with DVI
components.
Note: If using a DVI component, remember to connect the audio cable because the
DVI cable carries only the picture signal, not the sound.
USB
SPDIF
(optical)
HDMI 1
/DVI IN
HDMI 2 IN
HDMI 3 IN
HDMI 4 IN
AV 1 IN
adapter
Choose Your Connections
There are several ways to connect components, such as BD player, DVD players and set-top boxes, to your
TV.
Note: No cables are supplied with this unit. Please purchase the necessary cables. A high-speed HDMI cable
is recommended for better compatibility.
Input Signal Compatability
Antenna/Cable 480i, 480p, 720p, 1080i (NTSC, ATSC, and QAM formats)
Composite Video 480i
Component Video 480i, 480p, 720p/60Hz, 1080i/60Hz, 1080p/60Hz
HDMI 480i, 480p, 720p/60Hz, 1080i/60Hz, 1080p/60Hz
PC VGA SVGA XGA

8
Connections and Setup
or
Set-top box
HDMI Connection (Best)
HDMI 2 IN
CMPT AUDIO
IN adapter CMPT IN
adapter AV 1 IN
adapter
Component Video Connection (Better) Composite Video Connection (Good)
or
DVI/PC
AUDIO IN
DVI/PC
AUDIO IN
HDMI 1/DVI IN
PC Connection HDMI/DVI Connection
HDMI-DVI
conversion
cable
HDMI cable
(Same connnection to HDMI 1 IN, HDMI 3 IN and HDMI 4 IN)
Audio/video
adapter cable
VGA
cable
Audio
cable
Audio
cable
Y
Pb
Pr RL
Y
Pb
Pr RL
Y
Pb
Pr RL
RLVIDEO
VIDEO
RL
AUDIO
AUDIO
AUDIO
AUDIO
RL
AV 2 IN
adapter
or
CMPT Video
adapter cable
CMPT Audio
adapter cable
Main
TV
AV 1
AV 2
Component
PC
HDMI 1
HDMI 2
HDMI 3
HDMI 4

9
Connections and Setup
Network Connection
To access the Internet from this TV, you must separately subscribe to high speed broadband Internet service with
your Internet Service Provider.
Your TV is internet-ready, and can be connected to your home network in two ways:
• Wired, using the RJ45 (Ethernet) connector on the back panel.
• Wirelessly, built-in a wireless setting and your home wireless network.
Note: following are just the usual ways to connect your TV to the wired or wireless network. The connection method
may be different and you can make the connection depending on your actual network conguration. Please refer to
your Internet Service Provider.
Network Setup
After you connect your home network to the TV, follow the steps below to conguire your TV to be connected to the
network.
Press MENU to display the main menu, select Connection > Settings > Conguration, press
OK/► to display its
options:
Internet Connections This option allows you to turn Internet connection on or off. You must set in On mode to
congure the following network settings.
Wired Network Setup
Select Connection > Settings > Conguration > Interface, press ◄/► to select Ethernet to connect to a wired
network.
Connecting to a wired network
To connect to a wired network:
1. Ensure you have:
• An ethernet cable long enough to reach your TV
• A router or modem with an available Ethernet port
• A high-speed internet connection
• An Ethernet port on the back of the TV
2. Connect your ethernet cable to the router and to the
Ethernet port on the back of the TV.
3. Use the Network Setup to congure the TV.

Modem 

Router
Ethernet
Port on the
back panel
or


10
Connections and Setup
Wireless Network Setup
1. Select Connection > Settings > Conguration > Interface, press ◄/► to select Wierless to connect to a WiFi
wireless network.
2. Select
Connection > Settings > Conguration > Wireless Setting, press OK/► to enter.
3. Connection Methods: you can setup the wireless network connection three ways.
- Scan
• Select Wireless setting > Scan, then press OK/►, the TV will scan all available wireless networks within
range. The networks found by the TV will be displayed.
• Select an available access point, then press OK/► to connect the TV to it.
Notes:
- If you select a secure wireless network , you will have to enter the corresponding password to access it.
- This TV will remember the password even if you switch on TV after power off.
- Manual
Select Wireless setting > Manual, then press OK/►, you will be prompted to enter the correct SSID of an
available wireless router to setup the connection.
- Auto
If your wireless networks supports WPS (Wi-Fi Protected Setup), you can connect to the network via PIN
(Personal Identication Number) or PBC (Push Button Conguration). WPS will automatically congure
the SSID and WPA key in either mode.
Select Wireless setting > Auto, then press OK/►to enter.
• PIN: select PIN, then press OK/► to enter. Generate a random PIN code and make sure this code is installed
to the AP (for the procedures, refer to your router manual), then press OK/► again to setup the connection.
• PBC: If your router has a PBC push button, select
PBC, then press OK/► to enter. Press PBC push button on
your router within 2 minutes after you press OK/► again. Your TV will automatically acquire all the network
setting values it needs and connect to your network.
Information
Select Connection > Settings > Conguration > Information, press OK/► to display the information on current
connection, such as Interface, Address type, IP address, etc..
IP setting
Select Connection > Settings > Conguration > IP Setting, then press OK/► to enter the IP setting menu.
- Set Address type to Auto, it will acquire and enter the needed IP address automatically.
- You can follow below steps to enter your IP address manually if needed.
• Set Address type to Manual, then press ▼ to go to the rst entry eld.
• Enter the IP address, Subnet mask, Default gateway, Primary DNS and Secondary DNS values. Use the
digit buttons on your remote control to enter numbers and the arrow buttons to move from one entry eld to
another.
- After setting, select Connection > Conguration > Connection Test to check the Internet connectivity again.
Connection Test
Select Connection > Settings > Configuration > Connection Test, then press OK/► to check the Internet
connectivity. If it doesn't work, follow above steps to ensure the connectivity or refer to your Internet Service Provider.

11
Remote Control Functions
(On/Off button) Turns the TV on or standby.
0-9 (Alphanumeric buttons) Enters a channel number, then
press OK (or let the entry timeout). Enters a letter, a digit
or a symbol in some functions.
• (dot) To enter a digital channel with a sub-channel, enter
the main channel; then, press the dot (•), the sub-channel,
and then the OK button.
INPUT Opens the
Input list; then press INPUT repeatedly to select .......
the video input, or press ( ▲/▼ ) to highlight options, and
press OK to select the desired option.
VOL+/- Increases or decreases the TV volume.
CH+/- Selects channels.
(Mute) Turns the volume on and off.
@
(Connection) Enters the Connection menu.
(Yahoo) Yahoo connected TV.
Goes to NETFLIX main page.
MENU Brings up the main menu or press to return to the previous ......
menu; to access or exit virtual keyboard.
▲/▼◄/► (arrows) Highlights different items in the TV menu and
adjusts the menu controls.
ZOOM+/- Selects the desired screen format.
OK Displays Channel List menu. When the TV is in the menu .........
system, press to conrm your selection.
BACK Returns you to the previously viewed channel.
CANCEL Exits the menu.
INFO If no menus are currently active, press the INFO button to ........
display the Channel Banner.
USB Goes to the Media menu.
TV Goes to the TV mode.
SLEEP set the TV to turn off after a given amount of time.
GUIDE Toggles the Electronic Programme Guide between on and .......
off. Only available for digital channels.
FAV Sets the favorite channel: select a channel rst, then press ......
FAV to open the menu, press OK to set this channle as
your favourite. Set another favourite channel, press ▼ to
move to the next line, and repeat the above step. Next
time press FAV to display the favourite channel list, press .........
▲/▼ to select a favourite channel, and p ress OK to watch. ......
Note: press OK once again will delete this channel from the .......
favourite channel list,
CH LIST Displays the channel list menu.
PIC Selects picture mode.
SOUND Selects sound mode.
CC Enters the CC menu.
Red/Green/Yellow/Blue Buttons Reserved for future application.
◄ (Previous) Goes to the previous chapter.
(Stop) Stops viewing.
► (Play/Pause) Starts, pauses or resumes viewing
► (Next) Goes to the next chapter.
◄◄ Searches backword.
►► Searches forward.
Connections and Setup
RC3100N08
Goes to You Tube main page.
RC3100N08

12
Obtain the Signal
The rst step in connecting your TV is obtaining the signal. The back panel of your TV allows you to receive
analog and/or digital channels by using the HDMI or ANT/CABLE/SAT connections. To obtain the best
quality, use the HDMI connection.
Connect the outside ariel to the ANT/CABLE/SAT IN
connection on the back of the TV to receive off-air channels.
Use an HDMI connection to display the best picture and
sound quality for satellite and cable
• If you have a set-top box, you may need to call your cable
company or satellite service provider. They may commend
special cables to allow you to view digital channels.
• The aerial socket (75 OHM - VHF / UHF / cable) can be used
for connecting an external aerial or other equipment tted
with a modulator (video recorder, satellite receiver, etc.). We
recommend that you do not connect other equipment (video
recorder, satellite receiver, etc.) to your TV set to begin with,
so as not to complicate the set-up procedure with the
additional steps involved. Connect them when you have
nished setting up the channels.
• Visit www.antennaweb.org for help in deciding what type of antenna to use in order to receive the local digital
channels available to you. Enter your location, and the program will list local analog and digital stations available
using your antenna.
Switching On
Follow the instructions on this page on how to switch on your TV set and use the remote control before going on to
following pages describing how to use the channel scan procedure.
1. Insert two AAA batteries in the remote control.
Precautions on using batteries:
- Only use the battery types specied.
- Make sure you use the correct polarity.
- Do not mix new and used batteries.
- Do not use rechargeable batteries.
- Do not expose batteries to excessive heat such as sunshine, re or the like, throw them in a re, recharge them
or try to open them, as this could cause them to leak or explode.
- Remove the batteries from the remote control if you are not using it for a long period of time.
2. Connect the power cable to a mains socket. (If the power cable is not connected to the television, please rst
connect the power cable to the television.) Your TV set should only be connected to an AC supply. It must not be
connected to a DC supply. If the plug is detached from the cable, do not, under any circumstances, connect it to a
mains socket, as there is a risk of electric shock.
3. When powered on, if the TV set is in standby mode, press on the remote control or on the TV set to turn on the
TV.
Switching Off
To put the TV set into standby mode, press on the remote control or on the TV, the TV set remains powered up,
but with low energy consumption.
To switch off the TV set, unplug the mains socket from the mains outlet.
Connections and Setup
ANTENNA
/CABLE/SAT IN
Outdoor or indoor Antenna
Cable Box,
( Wall Outlet)
RF Coaxial
Wire
(75 ohm)
Or
Or

13
Connections and Setup
Initial Setup
Initial setup involves selecting all the settings required to
be able to search for and store all the channels you can
receive. Make sure that the television is switched on and
follow all the steps in turn specied hereafter.
The rst time you switch the set on, the Initial setup
wizard opens, which guides you through the initial setup
process. Press OK to start your initial setup.
1. Press ▲/▼ to select your language, then press
OK/► to enter the next screen.
2 A menu screen asks you to set the TV Location.
• Choosing “Home” for the TV Location assigns
the optimal picture settings for most home
environments.
• Choosing “Retail,” which is not Energy Star
compliant, sets the unit up with predened
settings for retail displays. In this setting, the
power consumption may exceed the requirements
of the Energy Star® qualication.
Use ▲/▼to select the desired location setting (Home/
Retail); then press OK/► to continue to the next screen.
3. Use ▲/▼ to select the current local time zone. Press
OK/► to continue to the next screen.
4. On the Tuner screen, select either Antenna or
Cable. Press OK/► to continue to the next screen.
Note: If you are using a satellite or cable set-top box,
you do not have to complete the Channel Scan.
5. The Channel Scan screen is now displayed. The
default choice is to scan. Press OK/► to begin the
channel scan for available channels to be stored in
the TV’s memory.
Note: If you do not want to scan for channels at this
time, press the CANCEL button to stop the scanning
process.
6. The screen will change to show the progress of the
scanning process.
7. When the scanning is nished, the unit has ompleted
the Initial Setup.
8. Press CANCLE to exit the Wizard and begin watching
TV.
Welcome to use the Wizard for Initial Setup!!
Initial Setup Welcome
Please press OK to start the wizard.
Please select your language:
English
Espanol
Initial Setup Language
Back Select Next Exit
CANCEL
Please select your TV Location:
Home
Retail
Initial Setup TV Location
Back Select Next Exit
CANCEL
Initial Setup Time Zone
Please select your time zone:
Eastern
Central
Mountain
Pacific
Alaska
Hawaii
Back Select Next Exit
CANCEL
Please select your tuner mode:
Antenna
Cable/Sat
Initial Setup Tuner
Back Select Next Exit
CANCEL
Initial Setup Channel Scan
First, please connect Cable/Sat or Antenna. Scan now? If you skip this step,
Scan
Skip Scan
the Channel Scan could be performed in Setup menu later.
Back Select Next Exit
CANCEL
This mode is Energy Star compliant.

14
Menu Display
Following are just the illustration of the menu display. For some opions such as Advanced Settings in the Picture
menu, Audio Language in the Sound menu may be displayed in the next screen.
Chapter 2 Menu Operation
Picture Mode ECO
Contrast
Color
50
50
Back
Select
Dynamic Backlight Off
Brightness
50
Sharpness
8
Color Temperature
Advanced Settings
Advanced Settings
DNRMedium
MEPG NR
DI Film Mode
Blue Stretch
Low
Auto
Off
Picture Sound TV Time
Connection Med Setup
Normal
Cancel
Back
Select
Cancel
TV
Signal Type Antenna
Channel Scan
Channel Skip
Back
Select
Cancel
Time Setup
Time Zone
Time
Daylight SavingAuto
Back
Select
Cancel
Enter
OK
Parental Control
Channel Block
Program Block
InputBlock
Change Password
CleanAll
Back
Select
Cancel
Enter
OK
ButtonBLockOff
Settings
Sleep Timer Off
Setup
OSD Language
System Information
Reset Default
Engli
Shop
sh
are Upgrade
Back
Select
Cancel
Closed Caption
CEC
Version Info
Sound
Speaker
SPDIF Type
Off
PCM
Balance 0
Sound Surround
On
Auto Volume Control
Off
MTS
Stereo
Default Audio Language
English
Back
Select
Cancel
Enter
OK
Sound Mode
Current Audio Language
Not Available
NetflixYouTubeSettings
Share & See
Settings
Parental Control
ia
Esticker
Softw
Connection

15
Menu Operation
DNR(Dyanmic Noise reduction) – diminishes picture
artifacts caused by the digitizing of image motion
content that may be present in the picture. Press ◄/►
to choose between these options: Off/Low/Medium/
High/Auto.
MPEG NR (Noise Reduction): this feature allows
you to reduce visible interference caused by MPEG
compression.
DI Film Mode: Optimizes the picture for watching lm.
Select Auto or Off.
Blue Stretch: selects On or Off.
Note: some options may appear in the next screen of
Picture menu, you can press ▲/▼ to switch.
Sound Menu
The Sound Menu lets you adjust audio output. Display
the main menu by pressing MENU and select Sound,
then press OK to confirm. The Sound menu appears
with the following options:
Sound Mode: selects a sound mode
from the list
depending on the programme you are watching.
Balance:adjusts the amount of audio sent to the left
and right speakers.
Sound Surround: selects for the simulated surround
sound feature to be On or Off.
Speaker: selects to turn the internal speakers On or Off.
SPDIF Type : this option controls the type of audio
stream sent to the Digital Audio Output (SPDIF) jack.
Available options are Dolby Digital, PCM, or Off.
Auto volume control: select On mode to reduce the
annoying blasts in volume during commercial breaks
and also amplifies softer sounds in program material.
Eliminates the need to constantly adjust the volume.
MTS: this option controls the manner in which the sound
comes through your speakers. Options available vary ac-
cording to the input selected.
Mono (available for regular TV viewing only): this
option plays the sound in mono only. Use this setting
when receiving broadcasts with weak stereo signals.
Stereo: this option splits the incoming stereo audio
signal into left and right channels. Most TV programs
and recorded materials have stereo audio.
Second Audio Program (SAP): this option plays the
program’s audio in a second language, if available.
SAP audio is broadcast in mono only. SAP is also
used to broadcast a program’s audio with descriptions
of the video for the visually impaired.
Default Audio Language: choose the language
you prefer for dialog on digital channels. If the preferred
language is not broadcasted with the program, then the
Using Menu System
This section explores the menus of your TV. Each menu
is outlined and detailed to help you get the most from
your TV. To access the menu system:
1. Press MENU to display the main menu.
2. Press ▲/▼/◄/► to select the desired item, then
press OK to open the corresponding submenu.
3. In submenus, use ▲/▼ to select menu options,
use ◄/►to set functions or change values. Press
OK to activate a setting. Use OK/► to open the
corresponding submenu.
4. Press MENU to return to the previous menu or press
Cancel repeatedly to close the menu.
Picture Menu
The menus for adjusting the picture are used to obtain
the best picture settings according to your preference,
the type of program you are watching and the ambient
lighting.
Display the main menu by pressing MENU and select
Picture, then press OK to conrm. The Picture options
are as below:
Note: some options may be not available for certain
signal sources.
Picture Mode:displays a list that lets you select one
of the preset picture settings: Natural, Sports, Personal
or ECO, Vibrant, Cinematic. Choose the setting that is
best for your viewing environment.
Note: ECO is the default setting, if you select some
other options, the power consumption may change.
Dynamic Backlight: this option automatically adjusts
the brightness of the backlight according to the content
of the incoming signal. Dynamic Backlight optimizes
the picture quality and decreases power consumption.
Note: When LightSensor or DynamicBacklight is
set to Off, the power consumption may exceed the
requirements of the Energy Star® qualication.
Brightness: adjusts the brightness of the picture.
Contrast: adjusts the difference between light and dark
areas of the picture.
Tint: this option adjusts the balance between the red
and green levels.
Color: adjusts the richness of colour.
Sharpness: adjusts the crispness of the edges in the
picture.
Color Temperature: Adjusts the color temperature of
the picture. Use◄/►to scroll through the color settings:
Cool for a more blue palette of picture colors; Standard;
and Warm for a more red paletteof picture colors.
Advanced Settings: press OK/► to display its
submenu.

16
Menu Operation
TV plays the default audio for the program (usually Eng-
lish in the US). There are 2 available default languages
(English, Spanish).
Note: The DefaultAudioLanguage option is only avail-
able for digital channels.
Current Audio Language: press ◄/► to choose
from the list of languages available for the program
you’re watching. The language chosen becomes your
preferred language for all digital channels until you
turn the TV off. If the language chosen is not being
broadcasted with a program, the TV plays the default
language for the program (usually English in the US).
Note: The CurrentAudioLanguage option is only
available for digital channels.
TV Menu
When you rst used your TV you will have setup your TV
for DTV / TV channels using the Initial Setup screens. If
you did not do this or if your setup has changed, you can
do this from the TV menu.
Signal Type: chooses the type of signal (Cable/Sat or
Antenna) depending upon which equipment you have
connected to the ANT/CABLE/SAT IN.
Channel Scan: selects this item and press OK/► to
start channel scan automatically. (Note: If you wish to
stop the search, press the Cancelbutton.)
When you perform a Channel Scan, your TV searches
for channels with signals and stores the channel infor-
mation in the Channel List. Then, as you watch TV and
press CH+ or CH-, your TV goes to the next or previous
channel in the Channel List and skips the channels that
do not have signals.
If the TV signal source changes – for example, if you
change from an outdoor antenna to cable TV – you will
need to rescan for channels.
Channel Skip: After the TV has stored all of the avail-
able channels in memory you will nd that some chan-
nels will be too weak to watch comfortably or they may
be channels you do not want to see, you can hide these
channels in the channel list.

17
Menu Operation
Connection Menu
Access to the Internet is required to use the features in
this section. Please refer to the “Network Connection”
part of the “Connections and Setup” section of this
manual.
Note: More Internet applications will be upgraded later.
Kindly check with sales representative for more details
and upgrading schedule.
Netix
Netix is available in certain countries. Unlimited mem-
bership required. More information at www.netix.com.
With a Netix unlimited membership, instantly watch TV
episodes & movies streamed over the Internet from Net-
ix right to your TV.
Select Connections > Netix, and press OK to enter,
then follow the options and hints appear on the screen
to operate.
Yahoo! Connected TV
Yahoo! Connected TV provides an integrated Internet
and TV experience. then follow the options and hints ap-
pear on the screen to operate.
YouTube
YouTube is a place to discover and watch videos.
Select Connections > YouTube, and press OK to
enter and follow the menu guide to operate.
Share & See
With Share & See, you can enjoy recorded video,
picture, music and/or text les saved on your PC.
Adding media from your PC for sharing
Install a DLNA media server in your PC. One example
is Microsoft Windows Media Player 11. Allow your TV to
share the designated les on your PC.
1. Open Microsoft Windows Media Player 11.
- Select Library > Media sharing.
- Check the checkbox Share my media to.
- Select the icon of the TV set connected to your PC.
- Select Allow to allow the TV set to access your PC,
and select OK to enable your allowing.
Note: you can push Settings button to customize
your desired settings.
2. - Select Library > Add to Libray.
- Select your personal folders or folders of other
users that you can access for sharing.
- Select Add and press OK to enable your adding.
Share & See application
1. Select Conenctions > Share & See, then press
OK to display its options.
2. Select Photo or Music. The same operation as
Photo, Music or Video in Media Menu.
Settings
Conguration: this option helps to connect your TV to
internet. For details please see "Network Connection"
& "Network Setup".
Time Menu
Time Zone
You can set the correct Time Zone for your area.
To choose a time zone:
1. Select Time > Time Zone, then press OK/► to open
Time Zone screen
2. Press ◄/► to select the time zone for your area.
3. Press MENU to go back to the previous screen, or
press CANCEL repeatedly to close the menu.
Daylight Saving selects Auto to set the daylight sav-
ing time for your area automatically.
Time: press OK/► to open Time submenu
Auto synchronization: use ◄/► to select On or Off.
If On selected, the TV will get the time automatically
from DTV signals, and the Time item cannot be
adjusted. If you select Off, you should set date and
time at Date and Time item. Highlight
Date or Time,
use ◄/► to select input space, enter the current date
or time by using the number buttons .
Note: if Off selected, the time set in Time option will
not be memorized when turning on the TV next time,
and the TV 's time will start from the default.
Power on timer: use ◄/► to select Once, On or
Off. If you select Once or On, you should set a time
period after which the TV automatically switches to on
at Timer below this item. Highlight Timer, use ◄/► to
select input space, enter the on time using the number
buttons .
Power on channel: press OK/► to display its
submenu. Highlight Select mode, use ◄/► to select
Last status, the power on channel will be the last
channel you watched before powered off. Or you
can select User select, then press ▲/▼ to select the
channel you want to watch when the TV is turned on
automatically next time, and press OK to conrm.
Power off timer: use ◄/► to select Once, On or
Off. If you select Once or On, you should set a time
period after which the TV automatically switches to off
at Timer below this item. Highlight Timer, use ◄/►
to select input space, enter the off time using the digit
keys.
Sleep timer: sets a period of time after which the TV
set goes into standby mode. Use ◄/► to set the period
(240 minutes maximum). To disable this function, select
Off.

18
Menu Operation
Application:
Netix: allows you logout the old user and log in new
user of Netix.
ESN: allows you get the local user ID automatically.
Media Menu
This connection allows you to insert a USB ash drive
directly or connect a compatible mass storage device
with USB, such as a digital camera, a multi-format card
reader, or an MP3 player. If you have a USB drive, plug
it into the drive directly. If you have a device with a USB
port, connect one end of the USB cable to the USB port
and the other end to the USB jack on the side of the TV.
The USB feature on your TV allows you to play audio
files (format supported: MP3) and video files(format
supported: AVI, MPG, MPEG2) or display pictures (format
supported: JPEG).
To access and adjust the options of the USB device,
press MENU to display the main menu, then select
Media, and press OK to enter the Media screen. Or you
can press the Media button on the remote control to
enter the Media screen directly.
To browse photos if available.
1. Select Media > Photo (icon), then press OK to enter
the main le content browser.
2. In the main le content browser, use ▲/▼/◄/► to
select a photo or subfolder.
3. If there are photos in a certain subfolder, select the
subfolder and press OK to enter.
4. Use ▲/▼/◄/► to select a photo or subfolder in
either main or sub le content browser. Press MENU
to display the menu. With the menu, you can do the
operations like Sort, Media Type, Thumbnail Size,
or Recursive.
5. Select a photo, press OK to watch, and a slide show
begins from the selected photo.Press MENU to display
the control menu. The menu options include Pause/
Play, Repeat, shufe, Rotate, Zoom and Show
Info.
6. Press the related buttons on the remote control to
perform the available functions shown on the function
bar at the bottom of the TV screen.
7. Press Cancel to exit and go back to the previous
menu.
Music
To playback music if available.
1. Select Media > Music (icon), then press OK to enter
the main le content browser.
2. In the main le content browser, use ▲/▼/◄/► to
select a song or subfolder.
3. If there are songs in a certain subfolder, select the
subfolder and press OK to enter.
4. Use ▲/▼/◄/► to select a song or subfolder in
either main or sub le content browser. Press MENU
to display the menu. With the menu, you can do the
operations like Sort, Media Type, Thumbnail Size,
or Recursive.
5. Select a song, press OK to play, and an automatic
playback begins from the selected song. Press MENU
to display the control menu. The menu options
include Pause/Play, Repeat, Show Info, Hide
Spectrum, Lyric Options and Audio only.
6. Press the related buttons on the remote control to
perform the available functions shown on the function
bar at the bottom of the TV screen.
7. Press Cancel to exit and go back to the previous
menu.
Video
To watch video if available.
1. Select Media > Video (icon), then press OK to enter
the main le content browser.
2. In the main le content browser, use ▲/▼/◄/► to
select a video or subfolder.
3. If there are videos in a certain subfolder, select the
subfolder and press OK to enter.
4. Use ▲/▼/◄/► to select a video or subfolder in
either main or sub le content browser. Press MENU
to display the menu. With the menu, you can do the
operations like Sort, Media Type, Thumbnail Size,
or Recursive.
5. Select a video, press OK to play, and an automatic
playback begins from the selected video. Press
MENU to display the control menu. The menu options
include Pause/Play, Repeat, Show Info, Picture
Mode, Screen Mode.
6. Press the related buttons on the remote control to
perform the available functions shown on the function
bar at the bottom of the TV screen.
7. Press Cancel to exit and go back to the previous
menu.

19
Menu Operation
Parental Menu
The choices in the US V-Chip and Canada V-Chip
menus involve software inside your TV, referred to as
V-Chip, which allows you to block TV programs and
movies. TV programs can be blocked by age-based
ratings, such as TV-MA . If available, TV programs can
also be blocked by content, such as adult language (L) .
Movies can only be blocked by age-based ratings . Once
you block programs, you can unblock them by entering
a password. By default, the software inside your TV is
turned off or unlocked.
V-Chip reads the program’s age-based rating (TV-MA,
TV-14, etc.) and content themes (Violence (V), Adult
Language (L), etc.). If you have blocked the rating and/or
content themes that the program contains, you receive a
message that the channel is currently blocked. Change
the channel or to enter your password and temporarily
deactivate the parental controls.
Broadcasters are not required to provide content
themes, so programs received with no content themes
are blocked only if you block their age-based rating.
You can also block programs that have been given
an Exempt rating, and programs that are considered
unrated.
Change V-Chip Password
The rst time you enter the Parental
Control
menu, you
must enter the default code (1234) in order to adjust other
parental control settings. You can set a personal V-Chip
Password rst, follow these steps:
1. Selelct Parental Control>
Change Password, press
OK/► to enter the
Change Password screen.
2. Use the number buttons to enter the four-digit number
for your password.
3. Re-enter the same code to conrm the password.
Note: the password must be entered before the TV will
continue with Parental settings next time. The super
password is 5351, If you forget your password, enter it
to override any existing password.
Channel Block
To block a specic channel, follow these steps:
1. Select Parental Control > Channel Block, press
OK/► to enter the next screen with channnel list on.
2. Press ▲/▼ to select the channel you wish to block.
3. Press OK to place a checkmark in the box to block
that channel. When you tune to that channel, you will
need to enter a password to view the channel
programming.
Program Block
Press OK/► to display its submenus:
Rating Enable
Select Parental Control > Program Block > Rating
Enable, then press ◄/► to turn this option on or off.
You must remember to set Rating Enable to On
mode to have the following V-Chip rating limits to take
effect.
U.S. TV Ratings
You can automatically block all program ratings above
a specied age-based rating level.
1. Select Parental Control > Program Block > U.S.
TV Ratings, press OK/► to enter the U.S. TV
Ratings screen.
In the Block TV Rating panel you can customize
the program blocking of the following TV ratings:
TV–Y All children
TV–Y7 Children 7 years and older
TV–G General audience
TV–PG Parental guidance suggested
TV–14 Parents strongly cautioned
TV–MA Mature audience only
You can also customize the TV ratings for the
following content:
A Sexual dialog
D Sexual explicit dialog
L Adult language
S Sexual situations
V Violence
FV Fantasy violence
2. Press ▲/▼/◄/► to navigate through the TV rating
options. Press OK to block (locked) or allow
(unlocked).
U.S. Movie Ratings
You can automatically block all program ratings above
a specied age-based rating level.
1. Select Parental Control > Program Block > U.S.
Movie Ratings, press OK/► to enter the U.S.
Movie Ratings screen.
In the Block Movie Rating panel you can customize
the program blocking of the following Movie ratings:
G General audience
PG Parental guidance suggested
PG-13 Unsuitable for children under 13
R Restricted, under 17 requires companying
parent or adult guardian
NC-17 No one under 17 admitted
X Mature audience only
