TE Connectivity M210 Operation and maintenance manual

TE CONNECTIVITY SENSORS /// USER NOTICE M210_EN 03/2018
Page 1
Important note
The M210 device is an electronic which puts forward its analogue output before its display (the display works as an
output copy). All metrological check has to be done thru the analogue output.
1. Before you start
•Connect the sensor to the conditioning module as per the wiring scheme.
•Ensure that the wires are correctly tightened into the terminal block.
•Connect the M210 to the 230 Vac – 50Hz supply or DC supply (depending on version).
•Wait a few moments for the display to stabilise (warm-up time).
NOTE: The standard M210 can function with 115 V –50 Hz (main supplied version) by changing an internal
jumper.
USER NOTICE M210

USER NOTICE M210
TE CONNECTIVITY SENSORS /// USER NOTICE M210_EN 03/2018
Page 2
2. Analogue output
2.1 SETTING THE ZERO
•Use the front panel potentiometer (bottom right hand side) to set the output to 0 Vdc.
2.2 SETTING THE GAIN
•The gain is set using the calibration function and the gain potentiometer. The gain
potentiometer is hidden behind the front panel on the bottom right hand side, above the zero
potentiometer.
•The calibration function simulates a pressure, or force, as determined during calibration.
•To simulate the pressure (or force) press the calibration pushbutton (see section II of the
"ADJUSTMENT" section if no pushbutton is present).
•Use the gain potentiometer to obtain the calibration value on the analogue output.
•Release the pushbutton, check the zero and refine the adjustments if necessary.
•The analogue output is adjusted correctly
Now adjust the display.

USER NOTICE M210
TE CONNECTIVITY SENSORS /// USER NOTICE M210_EN 03/2018
Page 3
3. Display
3.1 SETTING THE ZERO
•Use the front panel potentiometer (bottom left hand side) to adjust the analogue output to 0
Vdc with the sign flashing.
3.2 SETTING THE DISPLAY GAIN
•The gain is set using the calibration function and the gain potentiometer. The gain
potentiometer is hidden behind the front panel on the bottom left hand side, above the zero
potentiometer.
•The calibration function simulates a pressure, or force, as determined during calibration.
•To simulate the pressure (or force) press the calibration pushbutton (see section II of the
"ADJUSTMENT" section if no pushbutton is present).
•Use the gain potentiometer to obtain the calibration value on the display.
•Release the pushbutton, check the zero and refine the adjustments if necessary.
The M210 is ready to function

USER NOTICE M210
TE CONNECTIVITY SENSORS /// USER NOTICE M210_EN 03/2018
Page 4
TECHNICAL DATA SHEET M210
1 Supply
•Main: 230 or 115 V (± 10%) / 50 to 60 Hz; (6 VA).
Internal jumper S1:A = 115 V and B = 230V.
•DC versions:
M210/12:10 to 18 V / 0.5 A.
M210/24:20 to 28 V / 0.25 A.
•Operating temperature range: 0 to 50 °C (RH < 95% at +40°C no condensation).
•Storage temperature range: -40 to + 85 °C.
•Dimensions (w x h x d) : 96 x 48 x 155 mm
•Drilling dimensions: 92 x 45 mm.
•Mass: 500 grams.
2 Sensor excitation
•Voltage*:5 or 10 Vdc (Short-circuit protected).
•Drift: 100 ppm /°C.
•Sensor sensitivity: 10 to 1000 mV F.S.
•Maximum current: 50 mA.
* Sensor excitation 10 V : wire between pins 4 (-5 V) and 5 (+5 V)
5 V : wire between pins 6 (0 V) and 5 (+5 V)

USER NOTICE M210
TE CONNECTIVITY SENSORS /// USER NOTICE M210_EN 03/2018
Page 5
3 Sensors signal amplification
•Gain: from 10 to 1000 (resistance).
•Input impedance: 100 k.
•Stability: 1V /°C (typ.) closed loop
4 Analogue output (A.O.)
•Amplitude: ± 10 Vdc / 5 mA (short-circuit protected).
•Bandwidth at –3 dB: 1000 Hz.
•Amplification accuracy: ± 0.01%
•Output impedance: 10 .
•Noise: < 10 mV pk. to pk.
•Sensitivity (A.O.): ± 20 % (potentiometer).
•Zero adjustment (A.O.): ± 20 % (potentiometer).
5 Display
•Display capacity: ± 2 000 points.
•Conversion frequency: 2.5 updates per second.
•Accuracy: ± 0.2 % Full Scale
•Digit height: 14 mm (red LEDs).
•Scale adjustment: From 200 to 1999 points for 10 V on A.O.
•Zero adjustment: ± 10 points (potentiometer).

USER NOTICE M210
TE CONNECTIVITY SENSORS /// USER NOTICE M210_EN 03/2018
Page 6
Decimal point position on the display
To define the decimal point position on the display, points 1, 2 or 3 on the left of the display are
connected with a solder point (see the drawing below).
Short-circuit :
None for "1999"
1 for "1.999"
2 for "19.99"
3 for "199.9"
N.B.
Gain Aff = Display Gain
Zéro Aff = Display Zero
Gain S.A = A.O. Gain Zéro
S.A = A.O. Zero

USER NOTICE M210
TE CONNECTIVITY SENSORS /// USER NOTICE M210_EN 03/2018
Page 7
ADJUSTMENT M210
I. RG1 gain resistance calculation for ±10 V output
The position of the RG1 gain resistor is shown in the schema included in this document.
RG1 GAIN RESISTANCE CALCULATION FORMULA:
















7,8
10
435
14
Ve
RG
RG1 is in k.
Ve corresponds to the sensor sensitivity in mV for Full Scale.
•Example :
Pressure transducer : 1 bar.
Sensitivity : 2 mV/V.
Excitation : 10 V.
RG1 = 0.885 k.
Use the closest standard resistance value (± 1 %/50ppm/°C), in this case 887  and use the
gain potentiometer to fine tune the analogue output.














7,8
102
10000
435
1RG

USER NOTICE M210
TE CONNECTIVITY SENSORS /// USER NOTICE M210_EN 03/2018
Page 8
II. Calibration resistance RC1
The positions of the RC1 calibration resistor and BP are shown in the schema included in this document.
RC1 RESISTANCE DETERMINATION
•Short-circuit BP, and put a variable resistance (decade box) in place of RC1.
•Manually choose the value of RC1 which simulates approximately 80 % of full scale
•Choose the closest standard resistance value
•Mount RC1 in its place and replace BP with a pushbutton
•Note the values of the analogue outputs and the display when the test pushbutton is pressed,
these two values correspond to the calibration values.
To calibrate the measurement chain once the pushbutton is mounted, see
paragraphs I and II of "USER NOTICE".
Attention !
The RC1 calibration resistance values are measured after having adjusted the gain and
the zero of the measurement chain.
To set up the measurement chain correctly, one should:
1) Load the sensor and determine its sensitivity.
2) Calculate the value of RG1, fine adjust using the front panel potentiometers (zero unloaded
and gain loaded).
3) Determine the calibration resistance value RC1.
4) Note the calibration values obtained with the calibration

USER NOTICE M210
TE CONNECTIVITY SENSORS /// USER NOTICE M210_EN 03/2018
Page 9
CONNECTIONS M210
•3 PIN TERMINAL "SUPPLY"
1= Earth
2= Phase or –V =
3= Phase or +V =
•10 PIN TERMINAL "MEASUREMENT"
1= Sensor shield 6= - Current output (Option I)
2= - Sensor signal 7= + Current output (Option I)
3= + Sensor signal 8= + Voltage output
4= - Sensor excitation 9= - Voltage output
5= + Sensor excitation 10= shield outputs
Rear-Panel
MESUREMENT SUPPLY
1 10
1 3

USER NOTICE M210
TE CONNECTIVITY SENSORS /// USER NOTICE M210_EN 03/2018
Page 10

USER NOTICE M210
TE CONNECTIVITY SENSORS /// USER NOTICE M210_EN 03/2018
Page 11
USER NOTICE M210 AL1 OR AL2
AL1 = High threshold (HT).
AL2 = High threshold (HT) and Low threshold (LT).
A. Adjustments
•Adjustments are carried out once the M210 standard set up has been accomplished.
•The threshold values are set using the pushbuttons and potentiometers in the upper corners
of the front panels.
•Press the pushbutton and adjust the corresponding potentiometer to obtain the desired
threshold level on the display.
•Release the pushbutton. The unit is ready to function
Note: No calibration pushbutton is present on the M210 AL1 or AL2.
B. Threshold card(s) specifcations
(Controlled by APC (Active-Passive-Common) relays operating in positive logic)
•Threshold adjustment range: ± 2000 points.
•Comparison precision: ± 1 point.
•Overall precision: ± 2 points on the threshold value.
•Comparison bandwidth (–3 dB): 50 Hz.
•Relay switching time: 10 ms
•Vmax on the contacts: 200 Vdc or 250 Vac.
•Relay cut-off power: 50 W or 115 VA (resistive load).
•Operating temperature: 0 to + 50°C (RH < 85%).

USER NOTICE M210
TE CONNECTIVITY SENSORS /// USER NOTICE M210_EN 03/2018
Page 12
C. Six pin connector wiring scheme
1= Common LT 4= Common HT
2= Rest LT 5= Rest HT
3= Work LT 6= Work HT
Rear Panel
Front Panel
Note: SH = High Threshold; SB = Low Threshold
THRESHOLDS
MEASUREMENT SUPPLY
1 10
1 3
1 6

USER NOTICE M210
