Techpro CVIPTZ-EL2L12X User manual

1
yr
Warranty
1080p
Resolution
Elite Series PTZ -User's Manual
View From
Anywhere
CVIPTZ-EL2L12X

i
Table of Contents
1FEATURES AND FUNCTIONS...........................................................................................1
1.1 General Introduction...................................................................................................................................................1
1.2 Features .......................................................................................................................................................................1
1.2.1 HD Video.................................................................................................................................................................1
1.2.2 Long-Distance Transmission without Any Loss ................................................................................................1
1.2.3 Coaxial Control.......................................................................................................................................................1
1.2.4 On-Screen Menu....................................................................................................................................................1
1.2.5 Proportional Pan and Tilt......................................................................................................................................1
1.2.6 On-screen Tips.......................................................................................................................................................1
1.2.7 Preset ......................................................................................................................................................................1
1.2.8 Auto Scan................................................................................................................................................................1
1.2.9 Auto Tour ................................................................................................................................................................2
1.2.10 Auto Pattern.......................................................................................................................................................2
1.2.11 Privacy Masking................................................................................................................................................2
1.2.12 Action on Alarm.................................................................................................................................................2
1.2.13 Auto Flip .............................................................................................................................................................2
1.2.14 Self-diagnosis....................................................................................................................................................2
1.2.15 Day/Night Mode (B/W & Color Mode)............................................................................................................2
1.2.16 Auto Focus.........................................................................................................................................................2
1.2.17 Backlight Compensation ..................................................................................................................................2
1.2.18 Pan Tilt and Zoom.............................................................................................................................................2
1.2.19 3D Intelligent Location......................................................................................................................................2
1.2.20 Idle Status ..........................................................................................................................................................2
1.2.21 Power up ............................................................................................................................................................2
1.2.22Image Flip...........................................................................................................................................................2
2PREPARATION WORKS....................................................................................................3
2.1 HDCVI ..........................................................................................................................................................................3
2.2 Serial.............................................................................................................................................................................3
2.2.1 Protocol/Baud Rate /Address Setup ...................................................................................................................3
2.2.2 Baud Rate and Parity............................................................................................................................................4
2.2.3 Set address dial switch .........................................................................................................................................5

ii
3MENU .................................................................................................................................6
3.1 Screen Menu Index ..................................................................................................................................................6
3.2 Self-diagnosis System Information ..........................................................................................................................7
3.3 Main Menu ...................................................................................................................................................................7
3.4 Menu Operation ........................................................................................................................................................8
3.4.1 System Setting.......................................................................................................................................................8
3.4.2 Display Setting .......................................................................................................................................................9
3.4.3 Camera Setting ......................................................................................................................................................9
3.4.4 Function Setting...................................................................................................................................................14
3.4.5 Alarm Setting........................................................................................................................................................20
3.5 Dome Abnormal Phenomenon Operation........................................................................................................20
3.5.1 Restore to Factory Default Setup......................................................................................................................20
3.5.2 PTZ Movement is not smooth............................................................................................................................20
3.5.3 Can not use coaxial cable to control the speed dome ...................................................................................20
4CABLE CONNECTION .....................................................................................................21
4.1 Cable Connection...................................................................................................................................................21
4.2 System Layout ........................................................................................................................................................22
4.2.1 System Connection .............................................................................................................................................22
4.2.2 Alarm Connection ................................................................................................................................................22
4.2.3 Keyboard Connection..........................................................................................................................................23
5FAQ...................................................................................................................................24
5.1 Daily Maintenance..................................................................................................................................................24
5.2 Problems and Solutions .......................................................................................................................................24
6APPENDIX ⅠLIGHTENING PROTECTION AND SURGE PROTECTION ........................25
7APPENDIX 2 THE RELATIONSHIP BETWEEN THE 24V AC CABLE DIAMETER AND
THE TRANSMISSION DISTANCE...........................................................................................26

iii
8APPENDIX 3 WIRE GAUGE REFERENCE SHEET.........................................................27
9APPENDIX 4 TOXIC OR HAZARDOUS MATERIALS OR ELEMENTS ...........................28

iv
Welcome
Thank you for purchasing our product!
This user’s manual is designed to be a reference tool for the operation of your system.
Here you can find information about this speed dome features and functions, as well as a detailed menu tree.
Please keep it well for future reference!
Before installation and operation, please read the following safeguards and warnings carefully!

v
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited
power source is rated 24V AC in the IEC60950-1.
We assume no liability or responsibility for all the fires or electrical shock caused by improper handling
or installation.
We are not liable for any problems caused by unauthorized modification or attempted repair.
2．Transportation Security
No heavy stress, violent vibration or water splash are allowed during transportation, storage and
installation.
Please use the original packing material (or the material of the same quality) when you ship it back to
the manufacturer.
3．Installation
Do not apply power to the product before completing installation.
Please install the proper power cut-off device during the installation connection.
Do not put object on the product.
4．Environment
This series product should be installed in a cool, dry place away from direct sunlight, inflammable,
explosive substances and etc.
Please keep it away from the electromagnetic radiation object and environment.
Please keep the sound ventilation.
Do not allow the water and other liquid falling into the device.
Please make sure the CCD (CMOS) component is out of the radiation of the laser beam device.
Otherwise it may result in CCD (CMOS) optical component damage.
Thunder-proof device is recommended to be adopted to better prevent thunder.
The grounding holes of the product are recommended to be grounded to further enhance the reliability
of the camera.
5. Daily Maintenance
Current series product has no power button. Please unplug all corresponding power cables before your
begin installation or daily maintenance work.
Please keep the dustproof cap back to protect the CCD or CMOS part if the device does not work for a
long time.
Do not touch CCD (CMOS) component. You can use the blower to clean the dust on the surface of the
device. You can use the dry cloth with some alcohol or mild detergent to clear if necessary.
Do not use the volatility solvent such as the benzene or thinner, or detergent with strong abradibility. It
may result in lens damage or it may adversely affect the device performance.

vi
If there is too much dust, please use the water to dilute the mild detergent first and then use it to clean
the device. Finally use the dry cloth to clean the device.
6. About Accessories
Always use all the accessories recommended by manufacturer.
Before installation, please open the package and check that all the components are included in the package:
Contact you local retailer ASAP if something is missing in your package.

1
1Features and Functions
1.1 General Introduction
HDCVI (High Definition Composite Video Interface）is the HD video transmission specifications via the
coaxial cable. It adopts analog modulation technology to transmit progressive HD video.
This product integrates block camera and PTZ together. It is easy to install and use. It enjoys high
resolution, which meets the customers' needs for surveillance at HD level. This product also supports
privacy masking, alarm activation, WDR, high light reduce and some other functions. Comparing with the
traditional HD transmission distance limit, it uses HDCVI technology to guarantee transmission safety
and reliability of the audio/video. Thus, it realizes a real-time surveillance from anywhere at anytime. It
can transmit multiple-signal via one cable and it is easy to operate.
Comparing with the general products, this series HDCVI speed dome has some new features. It
supports PTZ rotation speed can automatically adjust according to the zoom rate of the lens. It supports
various languages, real-time clock function and protocol auto recognition. It supports 360°continuously
pan, 90°tilt and 180°auto flip. It can realize no blind spot monitor.
1.2 Features
This series speed dome has the following features:
1.2.1HD Video
Megapixel HD resolution.
1.2.2Long-Distance Transmission without Any Loss
More than 500M transmission distance via 75-3 coaxial cable.
1.2.3Coaxial Control
Support control signal transmission via the coaxial cable.
1.2.4On-Screen Menu
This series product menu supports multiple languages.
It is easy for you to view dome information and configure dome, camera parameters.
1.2.5Proportional Pan and Tilt
This function keeps the image from moving too fast when there is a large amount of zoom.
This series speed dome continually decreases or increases pan and tilt speeds in proportion to depth of
zoom. When zooms speed is increasing, the camera moving speed becomes slow. When zooms speed
is decreasing, the camera moving speed becomes fast.
1.2.6On-screen Tips
Via menu, here you can view:
Call preset and preset ID, speed dome title when calling touring.
Dome system temperature.
Dome address, direction.
1.2.7Preset
Preset function is to save the address information (such as PTZ pan/tilt, focus and etc) to the memory so
that you can quickly adjust the dome and PTZ to the correct position.
1.2.8Auto Scan

2
Camera scans back and forth regularly in a horizontal field. Here you need to set left and right limit and
scan speed.
1.2.9Auto Tour
Add presets into a routine in a desired order and then set time and stop duration for each address. The
dome will begin an auto touring between these presets.
1.2.10 Auto Pattern
Memorize dome operation such as pan, tilt, and zoom to repeat. You can call it to repeat the previous
operation.
1.2.11 Privacy Masking
Privacy masking is a user-defined, four-sided area that can not be viewed by you. The masking area will
move with pan and tilt functions and automatically adjust in size as the lens zooms.
1.2.12 Action on Alarm
There are 2 alarm inputs (NO/NC) and 1 NO outputs. Alarms can be individually programmed to initiate
an associated operation when received.
1.2.13 Auto Flip
As long as you continue to hold the keyboard joystick in the down position, the dome rotates 180
degrees and repositions itself for uninterrupted viewing of any subjects that passes directly beneath the
dome.
1.2.14 Self-diagnosis
There is a self diagnosis procedure when dome boots up.
Tilt and vertical engine check
Camera diagnosis
1.2.15 Day/Night Mode (B/W & Color Mode)
There are several modes such as auto/color/B&W. This function needs the speed dome driver (camera)
supported.
1.2.16 Auto Focus
Support auto focus function.
1.2.17 Backlight Compensation
Balance the brightest and darkest sections of a scene to produce a more vivid picture.
1.2.18 Pan Tilt and Zoom
Supports zoom in and zoom out during tilt and pan movement.
In this period auto focus and auto iris can still get vivid image.
1.2.19 3D Intelligent Location
Support 3D intelligent positioning function, speed dome can auto track to the specified zone. .
1.2.20 Idle Status
When there is no available order for specified period, the speed dome can implement previously set idle
operation.
1.2.21 Power up
The speed dome executes the power up operation after it rebooted and completed the initialization. The
power up function includes auto, preset, scan, tour, pattern and none.
1.2.22 Image Flip
You can enable image flip in the menu. The flip function allows you to view continuous video.
This function needs the speed dome driver (camera) supported.

3
2Preparation Works
These series products support two control modes: Serial/HDCVI.
For HDCVI series product, please select control mode as HDCVI. The control signal is sent to the
PTZ via the coaxial cable.
For the serial mode, the control signal is sent to the PTZ via the RS485 port.
2.1 HDCVI
Important
If you want to control the speed dome via the coaxial cable, you need to use the corresponding
HDCVI DVR.
Please go to the PTZ setup interface of the DVR and then set the control mode as HDCVI and the
protocol as DH-SD1. You do not need to set address and the baud rate. See Figure 2-1.
Please refer to the HDCVI series DVR user’s manual for detailed information.
After the setup, please connect the DVR to the speed dome via the video cable. Now you can control the
speed dome.
Figure 2-1
2.2 Serial
If you want to control the speed dome via the serial port, please set the control mode as serial. The
address, baud rate and parity value shall be the same as the dial switch of the speed dome. Otherwise,
you can not control the speed dome.
2.2.1 Protocol/Baud Rate /Address Setup
Important
If you are using HDCVI series DVR to control the speed dome, you can skip this chapter.
Before you use serial port to control the speed dome, you need to follow the contents listed below to set
address, baud rate, parity and etc. Otherwise, you can not control the device.

4
Open the transparent enclosure, there are two dial switch buttons on the PCB of one side of the speed
dome (There are labels.). You can use them to set speed dome protocol, baud rate, address and etc.
See Figure 2-2 .
After setup, you need to click on-off button or go to the OSD menu to select restart option to
reboot the device to activate new setup.
Figure 2-2
2.2.2 Baud Rate and Parity
Please note the IR speed dome can automatically recognize the industrial standard protocol,
PELCO-D. PELCO-P. Usually you do not need to set the protocol.
The interface is shown as in Figure 2-3.
Figure 2-3
Please refer to the baud rate sheet for detailed information.
1
2
Baud Rate
OFF
OFF
9600bps
ON
OFF
4800bps
OFF
ON
2400bps
ON
ON
1200bps

5
Please refer to the parity sheet for detailed information.
3
4
Parity
OFF
OFF
NONE
ON
OFF
EVEN
OFF
ON
ODD
ON
ON
NONE
2.2.3 Set address dial switch
The encode mode adopts binary system. 1 to 8 is the valid bit. The highest address bit is 255. See
Figure 2-4.
Figure 2-4
You can refer to the following sheet for more information.
Address
1
2
3
4
5
6
7
8
1
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
1
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
2
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
3
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
4
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
5
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
6
OFF
ON
ON
OFF
OFF
OFF
OFF
OFF
7
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
8
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
……
…………………………………………………………………
254
OFF
ON
ON
ON
ON
ON
ON
ON
255
ON
ON
ON
ON
ON
ON
ON
ON

6
3Menu
3.1 Screen Menu Index
Note:
ERR means current setup is invalid.
…means there is submenu.
SYSTEM INFORMATION
ADDR INFORMATION
SET NORTH
LANGUAGE : ENGLISH
FACTORY DEFAULT
RESTART
BACK EXIT
PRESET : ON
AZIMUTH DISP : ON
POSITION : OFF
INSIDE TEMP : OFF
BACK EXIT
DISPLAY SETTING
SYSTEM SETTING
CAMERA SETTING
FUNCTION SETTING
EXIT
WB SETTING
EXPOSURE SETTING
DAY/NIGHT SETTING
FOCUS SETTING
IMAGE ADJUST
ZOOM SPEED : 8
NEXT PAGE
BACK EXIT
PRESET
AUTO PAN
AUTO SCAN
AYTO TOUR
PATTERN
IDLE MOTION
NEXT PAGE
BACK EXIT
ALARM SETTING
ALARM NO : 1
ACTION : NO
PARAMETER : NO
CONTACT : N/O
RELAY OUT : OFF
RESET DELAY : 3S
SAVE
BACK EXIT

7
ADDR ：001-H
BR ：9600
PARITY ：None
VERSION ：V1.00.0.R
SYSTEM SETTING
DISPLAY SETTING
CAMERA SETTING
FUNCTION SETTING
ALARM SETTING
EXIT
The above diagram illustrates the overall structure of the speed dome setup menu.
Note:
ERR means current setup is invalid. Please restore factory default setup.
Please make sure all the cable connections are right.
3.2 Self-diagnosis System Information
Figure 3-1 Self-diagnosis
After installation, please connect speed dome to power. The system goes on a self-diagnosis, and then
it pops up the above interface to show the system information.
The above interface disappears after speed dome received the first command (or the display time lasts
for 4 minutes.)
ADDR: Here you can view dome address information. For example, 001-H, -H is the hardware
address number, -S is software address mode.
BR: Dome communication baud rate.
PARITY: Communication parity bit format.
VERSION: Dome software version.
When you are using the control keyboard or the matrix host to control the device, please make
sure the control parameter of the keyboard or the matrix host is the same with the speed dome
OSD (including address, baud rate, parity). Please make sure the cable connection is OK.
3.3 Main Menu
You can open speed dome menu via control keyboard, matrix, or speed dome control terminal.
Figure 3-2 Main menu
SYSTEM SETTING：Dome system information, address information, system time, set north
direction, language, factory default setup, and restart and so on.
DISPLAY SETTING: Display dome preset, azimuth display, direction, and dome internal
temperature and etc information.
CAMERA SETTING：Display dome white balance setup, exposure setup, day/night setup, focus
setup, image adjustment, zoom speed, aperture setup, aperture restrain level, digital zoom, image
flip, image output mode, factory default setup, camera restart and etc.
FUNCTION SETTING: Set preset, auto pan, auto scan, auto tour, auto pattern, idle motion, privacy
mask and etc.
ALARM SETTING：Set dome alarm number, action, parameter, contact, replay out, reset time and
etc.
EXIT: Log out the system menu.

8
SYSTEM INFORMATION
ADDR INFORMATION
SET NORTH
LANGUAGE ：ENGLISH
FACTORY DEFAULT
RESTART
BACK EXIT
ADDR ：001
BAUD RATE ：9600
PARITY ：NONE
SOFTWARE ：V1.00.0.RHCJEK
BACK EXIT
3.4 Menu Operation
In the speed dome main menu, you can use the left/right button on the keyboard or in the speed dome
terminal menu to configure the system menu. Before setup, please move the cursor to the current item
you want to configure.
In main menu, please click confirm button to go to the sub menu or use left/right key to configure
setup.
Use up/down button to select back option and then click confirm button to go back to the previous
menu.
Use up/down button to select exit option and then click confirm button to log out system menu.
All setup here will not lose when encounter power failure.
3.4.1 System Setting
Figure 3-3 System setting
SYSTEM INFORMATION: Move the cursor to SYSTEM INFORMATION and then click confirm
button to go to the third submenu.
ADDR INFORMATION: Move the cursor to SITE INFORMATION and then click confirm button to go
to the third submenu.
SET NORTH: Set dome benchmark direction so that you can know the angel between the
benchmark and then current location. Please move the cursor to the option and then click confirm
button until you see O.K. Now you have set north direction.
LANGUAGE: The dome menu language. There are several languages for you to select. Please use
the left/right button on the keyboard or in the speed dome terminal menu to set.
FACTORY DEFAULT: Restore dome factory default setup. Please move the cursor to the option
and then click confirm button until you see O.K. Now you can see the IP dome begin rebooting to
restore factory default setup.
RESTART: Reboot the speed dome.
BACK: Go back to the previous menu.
EXIT: Log out system menu.
3.4.1.1 System information
Figure 3-4 System information
Move the cursor to SYSTEM INFORMATION and then click confirm button, you can see the above
interface.
Here you can view dome basic information.

9
3.4.1.2 Address Information
Figure 3-5 Address information
Move the cursor to SITE INFORMATION and then click confirm button.
ADDR TYPE: There are two options: soft and hard. Please use the left/right button on the keyboard
or in the speed dome terminal menu to set.
ADDR-HARD: It is an address you set in the dial switch. You can not modify it through software.
ADDR-SOFT: You can set address via software. It is to say, you can use menu to modify dome
address.
BACK: Go back to the previous menu.
EXIT: Log out system menu.
3.4.2 Display Setting
Figure 3-6 Display setting
Move the cursor to DISPLAY SETUP and then click confirm button, you can go to the third submenu.
Please use the left/right button on the keyboard or in the speed dome terminal menu to set. After
completed setup, please click save button to save current setup.
PRESET: Display dome preset title or not. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set. You can go to Function Setup->Preset section to set
corresponding preset value and preset title.
AZIMUTH DISP: Display dome current coordinates or not. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.
POSITION: Display the angel between the benchmark and then current location. Please use the
left/right button on the keyboard or in the speed dome terminal menu to set.
INSIDE TEMPERATURE: Display dome internal temperature or not. There are three options: ℃
/F/Off. Please use the left/right button on the keyboard or in the speed dome terminal menu to set.
BACK: Go back to the previous menu.
EXIT: Log out system menu.
3.4.3 Camera Setting
Figure 3-7 Camera setting Figure 3-8 Next page
ADDR TYPE ：HARD
ADDR-HARD ：1
ADDR-SOFT ：0
BACK EXIT
WB SETTING
EXPOSURE SETTING
DAY/NIGHT SETTING
FOCUS SETTING
IMAGE ADJUST
ZOOM SPEED ：8
NEXT PAGE
BACK EXIT
APERTURE ：9
APERTURE RESTRAIN ：10
DIGITAL ZOOM ：OFF
PICTUER FLIP ：OFF
LENS INITIALIZATION
PICTURE MODE ：720P/25
NEXT PAGE
BACK EXIT
PRESET TITLE ：ON
AZIMUTH DISP ：ON
POSITION ：OFF
INSIDE TEMP ：℃
BACK EXIT

10
Figure 3-9 Next page
Move the cursor to CAMERA SETTING and then click confirm button, you can go to the submenu.
WHITE BALANCE SETUP: It is to set camera white balance mode. Move the cursor to current
option and then click confirm button, you can go to the third menu.
EXPOSURE SETTING: It is to set camera exposure mode, gain and etc. Move the cursor to current
option and then click confirm button, you can go to the third menu.
DAY/NIGHT: Set day/night mode. Move the cursor to current option and then click confirm button,
you can go to the third menu.
FOCUS SETTING: It is to set the camera focus mode, focus limit and etc. Please move the light to
highlight current item and then click the OK button to go to the next level menu.
IMAGE ADJUSTMENT: It is to set the camera hue, saturation, color control, gamma, style and etc.
There is the third menu. Please move the light to highlight current item and then click the OK button
to go to the next level menu.
ZOOM SPEED: The bigger the value, the faster the speed. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.
NEXT PAGE: It includes the following options: APERTURE, APERTURE RESTRAIN, DIGITAL
ZOOM, PICTURE FLIP, IMAGE OUTPUT MODE, CAMERA FACTORY DEFAULT SETUP, and
CAMERA RESTART. Please use the left/right button on the keyboard or in the speed dome terminal
menu to set.
APERTURE: It is to adjust the lens to achieve clear video. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.
APERTURE RESTRAIN: System can auto reduce the aperture to lower the video noise when it is in
low illumination environment. Please use the left/right button on the keyboard or in the speed dome
terminal menu to set.
DIGITAL ZOOM: You can use the left/right button to enable/disable the digital zoom function.
PICTURE FLIP: There are two options: on/off. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set.
LENS INITIALIZATION: It is to initialize lens.
IMAGE OUTPUT MODE: it is to set image output mode. There are several resolutions. Please use
the left/right button on the keyboard or in the speed dome terminal menu to set on/off.
NEXT PAGE: It includes the following options: CAMERA FACTORY DEFAULT SETTING,
CAMERE RESTART.
CAMERA FACTORY DEFAULT SETTING: Move the cursor to current item and then click confirm
button to restore factory default setup.
CAMERE RESTART: Move the cursor to current item and then click confirm button to reboot the
camera.
BACK: Go back to previous menu.
EXIT: Log out system menu.
3.4.3.1 White Balance Setup
WB MODE ：AUTO
R GAIN ：50
B GAIN ：50
BACK EXIT
CAMERA FACTORY DEFAULT
CAMERA RESTART
BACK EXIT

11
Figure 3-10 White balance
Move the cursor to WHITE BALANCE MODE and then click confirm button, you can go to the submenu.
WHITE BALANCE MODE: Set white balance adjustment mode. There are several modes such as
auto, ATW, indoor, outdoor, and manual and etc. Please use the left/right button on the keyboard or
in the speed dome terminal menu to set.
R GAIN: Before you set R GAIN option, please note the mode is manual. Please use the left/right
button on the keyboard or in the speed dome terminal menu to set.
B GAIN: Before you set B GAIN option, please note the mode is manual. Please use the left/right
button on the keyboard or in the speed dome terminal menu to set.
BACK: Go back to previous menu.
EXIT: Log out system menu.
3.4.3.2 Exposure Setting
Figure 3-11 Exposure setting Figure 3-12 Next page
Figure 3-13 Next page
AE MODE: Here you can set the camera exposure mode. It includes: auto/manual/AV (iris
priority)/TV (shutter priority). Please use the left/right button on the keyboard or in the speed dome
terminal menu to set.
oAuto: The gain, iris, shutter are in auto mode.
oManual: You need to set the gain setting, shutter, and iris setting manually.
oIris Priority (AV): It is for you to set the iris manually. Gain and shutter are in auto mode.
oShutter Priority (TV): It is for you to set the shutter manually, Gain and iris are in auto
mode.
GAIN SETTING: It is to set camera gain. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.
SHUTTER: It is to set camera shutter. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.
IRIS SETTING: It is to set camera iris. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.
EXPOSURE COMP: It is to set camera exposure compensation. Please use the left/right button on
the keyboard or in the speed dome terminal menu to set.
SLOW SHUTTER: In lower illumination environment, you can lower the cameras auto exposure
time to capture the image and enhance the definition. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.
NEXT PAGE: It includes: AGC GAIN LIMIT, SLOW SHUTTER LIMIT, NOISE REDUCTION, 3D
NOISE REDUCTION, BLC, HIGH LIGHT REDUCE, WDR, AE RECOVERY, BACK, and EXIT.
Move the cursor to the item and then click the left/right button to set.
AE MODE ：AUTO
GAIN SETTING ：2
SHUTTER ：1/50
IRIS SETTING ：4
EXPOSURE COMP ：8
SLOW SHUTTER ：ON
NEXT PAGE
BACK EXIT
AGC GAIN LIMIT ：2
SLOW SHUTTER LIMIT ：1/25
NOISE REDUCTION ：3
3D NOISE REDUCTION ：OFF
BLC ：OFF
WDR SETTING
NEXT PAGE
BACK EXIT
HIGH LIGHT REUDCE ：OFF
AE RECOVERY ：15M
BACK EXIT

12
WDR MODE ：OFF
BACK EXIT
DAY/NIGHT ：AUTO
THRESHOLD ：4
DAY/NIGHT TYPE ：ELECTRONIC
SAVE
BACK EXIT
oAGC GAIN LIMIT: It is to set auto gain high limit. Please click the left/right button to set.
oSLOW SHUTTER LOW LIMIT: Please click the left/right button to set.
oNOISE REDUCTION: There may noise when the camera is monitoring the low
illumination environments. You can use the digital filter to process the noise to
guarantee the clear video.
o3D NOISE REDUCTION: It is to set the speed dome 3D noise reduction setup. Please
use the left/right button on the keyboard or in the speed dome terminal menu to set.
oBLC: It is an abbreviation for back light compensation. System can compensate the
object in the dark light to achieve a clear video. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.
oWDR SETTING: Please make sure your camera supports current function. It includes
WDR mode, detection sensitivity, shadow correction and etc. Move the cursor to current
item and then click the OK button to go to the fourth level menu. Please use the left/right
button on the keyboard or in the speed dome terminal menu to set.
oNEXT PAGE: It includes: HIGH LIGHT REDUCE, AE RECOVERY. Move the cursor to
the item and then click the left/right button to set.
oHIGH LIGHT REDUCE: It is to adjust image whole brightness to restrain the extra high
brightness section to get vivid video. Please click the left/right button to set on/off.
oAE RECOVERY: Manually click the “+”and “-“button on the PTZ interface, system cam
resume previous exposure value after specified time (The exposure value does not
resume if this function is off.).
BACK: Go back to previous menu.
EXIT: Log out system menu.
3.4.3.3 WDR
Move the cursor to WDR and then click confirm button, you can go to the submenu.
Figure 3-14 WDR
WDR MODE: Please make sure your purchased camera support this function. System can auto
adjust image brightness when there is a harsh contrast between image dark and bright section.
Please use the left/right button on the keyboard or in the speed dome terminal menu to set
on/off/auto.
BACK: Go back to previous menu.
EXIT: Log out system menu.
3.4.3.4 Day/Night Setting
Move the cursor to DAY/NIGHT SETTING and then click confirm button, you can go to the submenu.
Figure 3-15 Day/night setting

13
FOCUS MODE ：AUTO
FOCUS LIMIT ：10CM
AF SENSITIVITY ：NORMAL
IR CORRECTION ：ATUO
BACK EXIT
HUE ：50
BRIGHTNESS ：50
SATURATION ：50
CHROMA SUPPRESS ：01
GAMMA ：01
CONTRAST ：50
STYLE ：STANDARD
BACK EXIT
DAY/NIGHT: It is to set camera day/night switch mode. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.
THRESHOLD: The speed dome can switch the day/night mode when it reached the threshold you
set here.
DAY/NIGHT MODE: It is to set day/night switch mode. Click left/right button to set.
SAVE: This button is for DAY TIME and NIGHT TIME setup. After you set the day time (or night
time), you need to move the cursor here and then click confirm button to save current time setup.
For other setups, you do not need to use this button.
BACK: Go back to previous menu.
EXIT: Log out system menu.
3.4.3.5 Focus Setting
Figure 3-16 Focus setting
FOCUS MODE: It is to set the camera focus mode. It includes several modes such as auto, manual,
semiautomatic. Please use the left/right button on the keyboard or in the speed dome terminal menu
to set.
FOCUS LIMIT: It is to set the camera focus limit. Please use the left/right button on the keyboard or
in the speed dome terminal menu to set.
AF SENSITIVITY: It is to set the camera focus sensitivity. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.
IR CORRECTION: It is to set the camera IR light focus correction. Please use the left/right button
on the keyboard or in the speed dome terminal menu to set.
BACK: Go back to previous menu.
EXIT: Log out system menu.
3.4.3.6 Image Adjust
Move the cursor to IMAGE ADJUST and then click confirm button to go to the submenu to set.
Figure 3-17 Image Adjust
HUE: It is to set picture hue. Please use the left/right button on the keyboard or in the speed dome
terminal menu to set.
BRIGHTNESS: It is to set picture brightness. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set.
SATURATION: It is to set picture saturation. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set.
CHROMA SUPPRESS: It is to set picture color control. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.
