TECHWOOD TMO-279G User manual


20 L MICROWAVE OVEN
WITH GRILL
INSTRUCTION MANUAL
1

IMPORTANT SAFEGUARDS
❑Please read these instructions carefully before use.
❑Keep present instructions for future references.
❑Check that your mains voltage corresponds to that stated on
the appliance.
❑Only use the appliance for domestic purposes and
household or similar applications such as:
- staff kitchen areas, in shops, offices and other working
environments;
- By clients in hotels, motels and other residential type
environments;
- Environment type like :
• Farm Houses • Bed and Breakfast.
❑Only use the appliance in the way indicated in these
instructions.
❑Never use this unit near bathtub, shower, wash-hand basins
or other containers with water.
❑Never use this apparatus near water projections.
❑Never use this apparatus with the wet hands.
❑If, unfortunately the apparatus is wet, immediately withdraw
the cord of the socket-outlet.
❑Inform potential users of these instructions.
❑Never leave the appliance unsupervised when in use.
❑The appliance must be used only for its intended purpose. No
responsibility can be taken for any possible damage caused
by incorrect use or improper handling.
❑Children and persons with disabilities are not always aware of
the danger posed by the use of appliances.
❑This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
2

mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
❑Children shall not play with the appliance.
❑Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised.
❑Keep the appliance and its cord out of reach of children less
than 8 years.
❑In order to ensure your children‘s safety, please keep all
packaging (plastic bags, boxes, polystyrene etc.) out of their
reach.
❑Caution ! Do not allow small children to play with the foil :
THERE IS A DANGER OF SUFFOCATION !
❑From time to time check the cord for damages. Never use the
appliance if cord or appliance shows any signs of damage.
❑Never immerse the appliance in water or any other liquid for
any reason whatsoever.
❑Never place it into the dishwasher.
❑Never use the appliance near hot surfaces.
❑Do not operate the appliance with a damaged cord or plug, or
after the appliance has been damaged in any manner.
❑If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
❑Disconnect the power source cable before any operation of
cleaning of maintenance and accessories assembly.
❑Never use the appliance outside and always place it in a dry
environment.
3

❑Never use accessories, which are not recommended by the
producer. They could constitute a danger to the user and risk
to damage the appliance.
❑Never use any other connector than the one provided.
❑Never move the appliance by pulling the cord. Make sure the
cord cannot get caught in any way.
❑Never wind the cord around the appliance and do not bend it
❑Ensure that the power cord does not come into contact with
hot parts of this unit.
❑Make sure the appliance has cooled down before cleaning
and storing it.
❑The temperature of accessible surfaces may be very high
when the appliance is operating. Never touch these parts, of
apparatus, to avoid burning itself.
❑Make sure the appliance never comes into contact with
flammable materials, such as curtains, cloth, etc...& the
power cord and plug do not come in contact with water.
❑Before cleaning, always unplug the appliance from the power
supply and let it cool down.
❑This appliance is not intended to be operated by means of an
external timer or separate remote-control system.
❑Always place the unit on a flat surface. Ensure, also, not to
cover the device and not to put anything on it.
❑Always remove the plug from the wall socket when the
appliance is not in use.
❑When using an extension lead always make sure that the
entire cable is unwound from the reel. Use solely CE
approved extension leads. Input power must be at least 16A,
250V, 3000W.
❑Incorrect operation and improper use can damage the
appliance and cause injury to the user.
4

❑This device, designed for home use, complies with standards
relating to this type of product.
❑The appliance must be used and rested on a table or flat &
stable surface.
❑The item must not be left unattended when it is connected to
main supply.
❑The item is not to be used, if it has been dropped or if there
are visible signs of damage or if it is leaking.
❑Regarding the instructions for cleaning, thanks to refer to the
below paragraph of the manual.
❑This appliance is only intended for household use.
❑Warning: Avoid spilling on the connector.
There is a potential risk of injury if used incorrectly.
The surface of the heating element may remain hot for some
time after use.
(*) Competent qualified person : after sales department of the
producer or importer or any person who is qualified, approved
and competent to perform this
GENERAL INFORMATION
The symbol "OPEN BOOK" means a recommendation
to read important things contained in the record.
The symbol "BIN" crossed out, abbreviation WEEE
(Waste of Electrical and Electronic Equipment) means
that at the end of life, it should not be discarded with
household waste, but filed to the sorting of the locality.
Waste recovery can help preserve our environment.
5

The symbol "CE" is the guarantee of compliance with
harmonized European standards, voluntary, reflecting
the essential requirements into technical
specifications. These standards are not mandatory
but are guarantees of compliance with essential
requirements.
The symbol "GLASS / FORK" means that the device is
compatible and can come into contact with foodstuffs.
The symbol ROHS (Restriction of use of some
Hazardous Substances) on the Environmental
Protection, certifies that for each of the five hazardous
substances • Lead • Mercury • (hexavalent) chromium •
products for protection against flames PBB and PBDE,
the peak concentration is equal to or less than 0.1% of
the weight of homogeneous material, and 0.01% for the
6th • cadmium.
The symbol "TRIMAN" indicates that the consumer is
invited to dispose the product as part of a separate
collection (eg recycling bin, waste, voluntary intake
point).
For more information : http://www.quefairedemesdechets.fr
SPECIFIC WARNING MICROWAVE
● If the door or door seals are damaged, the oven must not be
operated until it has been repaired by a competent person.
6

● It is hazardous for anyone other than a competent person to
carry out any service or repair operation that involves the
removal of a cover which gives protection against exposure to
microwave energy
● Liquids and other foods must not be heated in hermetically
sealed containers due to the risk of explosion.
● If smoke is emitted, stop or unplug the oven and keep the
door closed to extinguish potential flames
● Heating drinks with a microwave can cause abrupt and
delayed spurting of boiling liquids. Precautions must also be
taken when handling the container.
● The contents of baby feeding bottles and food containers
must be stirred or shaken and the temperature must be
checked prior to consumption. in order to avoid burns.'
● Do not give permission to children to use the oven
unsupervised unless they have received appropriate
instructions which ensure that the child can use the oven
safely and understands the hazards associated with an
improper use
● It is not advised to heat eggs in their shells nor hard-boiled
eggs in a microwave. due to the risk of explosion. even after
cooking is complete
● It is advised to clean the oven regularly and to remove all food
deposits: if the appliance is not kept sufficiently clean. its
surface could degrade, which could inexorably affect
appliance life span and lead to a hazard
●This appliance is intended to be used freestanding and shall
not be placed in a cabinet. Make sure to leave a clearing
distance of 30cm above the appliance, 10cm at the sides.
● Only use utensils that are suitable for use in microwave ovens
7

● When heating food in plastic or paper containers, keep an eye
on the oven due to the possibility of ignition
●The microwave oven is intended for heating food and
beverages. Drying of food or clothing and heating of warming
pads, slippers, sponges, damp cloth and similar may lead to
risk of injury, ignition or fire.
● Metallic containers for food and beverages are not allowed
during microwave cooking.
● The appliance shall not be cleaned with a steam cleaner.
● This appliance is from group 2 & class B
This item is group 2 as it intentionally generates
radio-frequency energy for heating food or stuff.
This item is class B as it is suitable for use in locations in
residential environments and in establishments directly
connected to a low voltage power supply network which
supplies buildings used for domestic purposes.
● WARNING: When the appliance is operated in the
combination mode, children should only use the oven under
adult supervision due to the temperatures generated.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
● Do not attempt to operate this oven with the door open since
open door operation can result in harmful exposure to
microwave energy. It is important not to defeat or tamper with
the safety interlocks.
● Do not place any object between the oven front face and the
8

door or allow soil or cleaner residue to accumulate on sealing
surfaces.
● Do not operate the oven if it is damaged. It is particularly
important that the oven door close properly and that there is
no damage to the Door (bent), Hinges and latches (broken or
loosened), Door seals and sealing surfaces.
● The oven should not be adjusted or repaired by anyone
except properly qualified service personnel.
CLEANING AND CARE
1. Turn off the oven and remove the power plug from the wall
socket before cleaning.
2. Keep the inside of the oven clean. When food splatters or
spilled liquids adhere to oven walls, wipe with a damp cloth.
Mild detergent may be used if the oven gets very dirty. Avoid
the use of spray and other harsh cleaners as they may stain,
streak or dull the door surface.
3. The outside surfaces should be cleaned with a damp cloth.
To prevent damage to the operating parts inside the oven,
water should not be allowed to seep into the ventilation
openings.
4. Wipe the door and window on both sides, the door seals and
adjacent parts frequently with a damp cloth to remove any
spills or spatters. Do not use abrasive cleaner.
5. Do not allow the control panel to become wet. Clean with a
soft, damp cloth. When cleaning the control panel, leave
oven door open to prevent oven from accidentally turning on.
9

6. If steam accumulates inside or around the outside of the
oven door, wipe with a soft cloth. This may occur when the
microwave oven is operated under high humidity condition.
And it is normal.
7. It is occasionally necessary to remove the glass tray for
cleaning. Wash the tray in warm sudsy water or in a
dishwasher.
8. The parts (removable) in contact with food like plate, bowl,
forks, Spatula etc. can be washed in hot water with sponge
and soft detergent or put in the dishwasher.
9. The roller ring and oven floor should be cleaned regularly to
avoid excessive noise. Simply wipe the bottom surface of the
oven with mild detergent. The roller ring may be washed in
mild sudsy water or dishwasher. When removing the roller
ring from cavity floor for cleaning, be sure to replace in the
proper position.
10. Remove odours from your oven by combining a cup of
water with the juice and skin of one lemon in a deep
microwaveable bowl, microwave for 5 minutes. Wipe
thoroughly and dry with a soft cloth.
11. When it becomes necessary to replace the oven light,
please consult a dealer to have it replaced.
12. The oven should be cleaned regularly and any food
deposits removed. Failure to maintain the oven in a clean
condition could lead to deterioration of the surface that could
adversely affect the life of the appliance and possibly result in
a hazardous.
13. Please do not dispose this appliance into the domestic
rubbish bin; it should be disposed to the particular disposal
centre provided by the municipalities
10

INSTALLATION
Make sure that all the packing materials are removed from the inside of the door.
WARNING: Check the oven for any damage, such as misaligned or bent door,
damaged door seals and sealing surface, broken or loose door hinges and latches
and dents inside the cavity or on the door. If there is any damage, do not operate
the oven and contact qualified service personnel.
This microwave oven must be placed on a flat, stable surface to hold its weight
and the heaviest food likely to be cooked in the oven.
Do not place the oven where heat, moisture, or high humidity are generated, or
near combustible materials.
1. For correct operation, the oven must have sufficient airflow. Make sure to leave
a clearing distance of 30cm above the appliance, 10cm at the sides. Do not
cover or block any openings on the appliance. Do not remove feet.
2. Do not operate the oven without glass tray, roller support, and shaft in their
proper positions.
3. Make sure that the power supply cord is undamaged and does not run under
the oven or over any hot or sharp surface.
4. The socket must be readily accessible so that it can be easily unplugged in an
emergency.
5. Do not use the oven outdoors.
TO KNOW THE APPLIANCE
1. Door Safety Lock System
2. Turntable Roller
3. Oven door
4. Oven Window
5. Housing unit
6. Glass Tray
7. Waves guide
8. Power selector
9. Timer
RADIO INTERFERENCE
Operation of the microwave oven can cause interference to your radio, TV, or
similar equipment.
When there is interference, it may be reduced or eliminated by taking the following
measures:
11

Clean door and sealing surface of the oven.
Reorient the receiving antenna of radio or television.
Relocate the microwave oven with respect to the receiver.
Move the microwave oven away from the receiver.
Plug the microwave oven into a different outlet so that microwave oven and
receiver are on different branch circuits.
MICROWAVE COOKING PRINCIPLES
Arrange food carefully. Place thickest areas towards outside of dish.
Watch cooking time. Cook for the shortest amount of time indicated and add more
as needed. Food severely overcooked can smoke or ignite.
Cover foods while cooking. Covers prevent spattering and help foods to cook
evenly.
Turn foods over once during microwave cooking to speed cooking of such foods
as chicken and hamburgers. Large items like roasts must be turned over at least
once.
Rearrange foods such as meatballs halfway through cooking both from top to
bottom and from the centre of the dish to the outside.
GROUNDING INSTRUCTIONS
This appliance must be grounded. This oven is equipped with a cord having a
grounding wire with a grounding plug. It must be plugged into a wall receptacle
that is properly installed and grounded. In the event of an electrical short circuit,
grounding reduces risk of electric shock by providing an escape wire for the
electric current. It is recommended that a separate circuit serving only the oven be
provided. Using a high voltage is dangerous and may result in a fire or other
accident causing oven damage.
WARNING Improper use of the grounding plug can result in a risk of electric
shock.
Note: If you have any questions about the grounding or electrical instructions,
consult a qualified electrician or service person.
CONTROL PANEL
Power
% OF POWER OR PROGRAM
DENOMINATION
LOGO
12

18%
Low
36%
DEFROST
58%
MEDIUM POWER
81%
SUPERIOR POWER
100%
MAXIMUM POWER
100%
GRILL
COMBI 1
MICROWAVE + GRILL
COMBI 2
MICROWAVE + GRILL
COMBI 3
MICROWAVE + GRILL
13

Cooking time
Choose the cooking time from 1 to 30 minutes.
UTENSILS GUIDE
The ideal material for a microwave utensil is transparent to microwave, it allows
energy to pass through the container and heat the food.
Microwave cannot penetrate metal, so metal utensils or dishes with metallic trim
should not be used.
Do not use recycled paper products when microwave cooking, as they may
contain small metal fragments which may cause sparks and/or fires.
Round /oval dishes rather than square/oblong ones are recommended, as food in
corners tends to overcook.
Narrow strips of aluminium foil may be used to prevent overcooking of exposed
areas. But be careful don’t use too much and keep a distance of 1 inch (2.54cm)
between foil and cavity.
The list below is a general guide to help you select the correct utensils.
COOKWARE
MICROWAVE
Heat–Resistant Glass
Yes
Heat–Resistant Ceramics
Yes
Microwave–Safe Plastic Dish
Yes
Kitchen Paper
Yes
Metal Tray
No
Metal Rack
No
Non Heat–Resistant Glass
No
Aluminium Foil Containers
No
14

USE
● Unroll the power cord completely.
● Check that the tension in force in the country where you are corresponds to
that indicated on the apparatus.
● Connect the apparatus in a correct socket-outlet, (and connected to the
ground if the unit is Class I), to avoid any danger.
● Disconnect the power source cable before any operation of cleaning of
maintenance and accessories assembly.
● Never modify the appliance in anyway.
1. MICROWAVE COOKING
For real microwave cooking, there are 5 power levels from which you can choose
the one that best suits you.
The power level increases by turning the knob clockwise.
After selecting the power level, choose the cooking time.
The oven starts as soon as the timer is started.
To stop the oven, set the timer to 0 or open the door.
2. GRILL COOKING
If you wish to grill, select the GRILL position.
Choose the cooking time.
Note: The oven starts as soon as the timer is started.
3. COMBINED COOKING
Combination 1
30% of the time in the microwave, 70% of the time in the grill.
Use for fish, potatoes and gratins.
Combination 2
49% of the time in the microwave, 51% of the time in the grill.
Use for cakes, omelettes, sautéed potatoes.
Combination 3
67% of the time in the microwave, 33% of the time in the grill.
Eg : Poultry.
15

Note :
• As soon as the timer is started, the oven will start.
• When the selected time is less than 2 minutes, turn the knob beyond 2
minutes (clockwise) and return in the other direction (counterclockwise), up to 2
minutes, to correct the duration.
• To remove or check food from the oven during cooking, open the oven door or
reset the timer to 0.
• To stop the oven before the end of cooking, reset the timer to 0.
STORAGE
-Ensure the unit is completely cool and dry.
-Do not wrap the cord around the appliance, as this will cause damage.
-Keep the appliance in a cool, dry place.
16

GUARANTEE
Before being delivered, all our products are subjected to a rigorous control.
This apparatus is guaranteed 24 months starting from the date of purchase by
the consumer.
The documents in proof of guarantee are :
• The invoice and
• The filled and stamped warrantee plate (located on side or bottom of the gift
box). Without these documents in proof, no free replacement, nor no free repair,
can be carried out.
During the warranty period, we deal for free, the defects of the apparatus or the
accessories, rising from a defect of materials or manufacture by repair or,
replacement. The services within the framework of the guarantee do not involve
any extension of the warranty period and does not give right to a new guarantee !
In the event of recourse to the guarantee, bring back the complete apparatus to
your retailer, in its original packing, accompanied by the proofs of purchase.
The breakage of parts out of glass or plastic is, in all the cases, not warranted.
Defects on the accessories or the wearing parts (for example: coals of engines,
hooks, drive belts, remote control of replacement, teeth brushes of replacement,
webs etc) as well as cleaning, maintenance or it replacement of wearing parts
are not guaranteed and are thus to pay !
In the event of foreign intervention, the guarantee becomes null and void.
After flow of the warranty period, repairs can be carried out, against payment, by
a specialized trade or a repair service.
17

BEFORE CALLING FOR SERVICE
If the oven fails to operate:
Check to ensure that the oven is plugged in securely. If it is not, remove the plug
from the outlet, wait 10 seconds, and plug it in again securely.
Check for a blown circuit fuse or a tripped main circuit breaker. If these seem to be
operating properly, test the outlet with another appliance.
Check to ensure that the control panel is programmed correctly and the timer is
set.
Check to ensure that the door is securely closed engaging the door safety lock
system. Otherwise, the microwave energy will not flow into the oven.
IF NONE OF THE ABOVE RECTIFIES THE SITUATION, THEN CONTACT A
QUALIFIED TECHNICIAN. DO NOT TRY TO ADJUST OR REPAIR THE OVEN
YOURSELF.
SPECIFICATIONS
Power supply 230-240V~ 50Hz
Input Power 1100W
Output power 700W
Grill 900W
Norm Class I
Frequency 2450MHz
Capacity 20 Litres
Cooking system rotate tray
Made in P.R.C
The characteristics can change without prior notice.
18

For additional protection, the installation of a residual current device with a rated
residual operating current not exceeding 30 mA is advisable in the electrical circuit
supplying the bathroom. Ask your installer for advice.
Always unplug the appliance before any cleaning or maintenance
operation and accessories assembly.
This unit is equipped with an electrical outlet with earth and must be
earthed in an according plug.
Note : In the event of question concerning the earth or electric
connection, please consult a qualified personnel.
In the event of short-circuit, earthing reduces the risk of electric shock
while making possible the current to be evacuated by the wire of
ground.
CAUTION: In order to minimize the risks of electric shock, In the event of
breakdown, not to open the case but to call upon a qualified technician
for repairs.
This device complies with EC directives, it was controlled according to all current
European directives, applicable such as: electromagnetic compatibility (EMC) and
low voltage (LVD).
This device has been designed and manufactured in compliance with the latest
regulations and technical requirements for safety.
Imported by Sotech International
" LE PERIPOLE " N°A-107
33, Avenue du Marechal de Lattre de Tassigny
94120 Fontenay sous-bois - France
19
