Tecsun PL-880 Assembly instructions

Front panel layout:
The front panel has the speaker on the left hand side and the LCD display and all
the push button controls are grouped on the right hand side.
So considering the right hand side, the LCD display takes up the top 40% of that
side and is smooth to touch.
Below the LCD display there are 5 buttons. They are thinner and marginally
longer than any of the other buttons. From left to right they are:
Time set, alarm set, display (toggles between current time, alarm time and signal
level) - shared key with the key-lock function, FM stereo shared key with the AM
bandwidth function, and VF/memory key, which allows the user to select from
pre-stored frequencies in memory or VF the free tuning mode.
Below that first single row of 5 buttons the remaining space is divided in two.
On the left hand side (and these buttons are longer than those on the right hand
side) is the 12 key numeric keypad, 4 rows each having 3 buttons.
Unfortunately there is no raised dimple on the 5 key unlike some other Tecsun
models.
Top row from left to right: 1,2,3
Second row: 4,5,6
Third row: 7,8,9
Fourth row: memory access , 0(zero), memory delete
On the right hand side of the lower portion (below the single row of 5 buttons)
there are a total of 8 buttons arranged in 4 rows of 2 buttons.
www.tecsunradios.com.au
stores.ebay.com.au/tecsunradiosaustralia/
PL-880 tips and tricks for a blind user

From left to right on each row:
- Row 1 : AM, FM
- Row 2: SW bands UP and DOWN
- Row 3: USB, LSB. Note press USB once to activate USB mode, and press
again to revert to AM. It takes 2 seconds to toggle.
- Row 4: PAGE +, PAGE- (for stored frequencies
Along the right hand side of the receiver from top to bottom:
Large square button; POWER momentary push button
Large rotary control: TUNING (for incrementing in 1Khz steps in SSB mode)
First small rotary control: FINE TUNING (for incrementing in 10Hz steps in
SSB mode)
The keypad section of the front panel has a raised surround. Adjacent to the
bottom RH corner there is a small hole for the CPU RESET function. Use a
paper-clip and hold for 3 seconds to reset.
Along the left hand side of the receiver, there are 4 connectors and 1
switch.
From top to bottom:
External antenna socket for shortwave and FM
Input attenuator switch. 3 positions top DX, middle NORM and bottom LOCAL
3.5mm stereo socket for headphones
3.5mm socket for LINE OUTPUT recording
Mini USB socket for charging the battery
