OPERATION MANUAL
CS5131P
For customer Use:
Enter below the Serial NO. which is located on
the rear panel of the camera control unit.
Retain this information for future reference.
Model No. CS5131P
Serial No.

Thank you for purchasing the teli CS5131P television
color camera featuring compact arid light weight.
To take lest advantage arid gain the most service from
your camera, read this operation manual carefully and
throughly.
INFORMATION
This equipment generates and uses radio frequency energy
and if not installed and used properly, that is, in
strict accordance with the manufacturer's instructions,
may cause interference to radio and television reception.
If does so, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
Reorient the receiving antenna;
Relocate this equipment with respect to the
receiver;
Move this equipment away from the receiver;
Plug this equipment into a different outlet so that
this equipment and receiver are on different branch
circuits.
If necessary, the user should consult the dealer or an
experienced radio/television technician for additional
suggestions.
CAUTION
To prevent electric shock, do not use the polarized
plug of the AC Power adapter with an extension cord,
receptacle or other outlet unless the blades can be
fully inserted to prevent blade exposure.
For continued protection against risk of fire, replace
only with same type and rating of fuse.
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
This equipment should be used with AC 100 120 V or
AC 220 240 V that is selected by the voltage selecter
an the rear panel according to supplied voltage.
Do not use any other power source.

CONTENTS
page
1, FEATURES 1
2, PRECAUTION 1
3, CONTROLS AND ADJUSTMENTS 2
3-1 Camera head 2
3-2 Camera control unit 3
4, CONNECTIONS 7
5, SUPPLEMENTAL INFORMATION l0
(1) Color temperature 10
(2) White balance 10
(3) How to get good color 10
(4) Color temperature of various 11
artificial lighting
(5) CCD image sensor 11
(6) Smear 12
(7) ELC and AGC 12
(8) Lenses 13
6, TROUBLE-SHOOTING GUIDE 14
7, SPECIFICATIONS 15
8, CONSTITUTION 17
9, APPERANCES
(1) Camera head 18
(2) Camera control unit 19
10, MAINTENANCE 20

1, FEATURES
* Compact and light weight camera head
* Available External sync-operation
* Provided 3 kind of video outputs of a PAL, Y/C and RGB.
* Equipped with both ELC (Electric Light Control) and AGC
(Automatic Gain Control) which allows wide dynamic range
from bright to dark subjects.
* Equipped with an electronic shutter for fast moving
subjects for better definition picture.
2, PRECAUTION
(1) This equipment should be used with AC 100 120 V or
AC 220 240 V that is selected by the voltage selecter on
the rear panel. To prevent electric shocks and fire
hazards, do not use any other power source.
(2) The CS5131P is designed to be used with PAL color
television signals. It cannot be used for playback with
a television of a different standard.
(3) Please handle the equipments carefully.
(4) Do not point your camera lens directly into sunlight or
strong artificial light. This might cause irreparable
damage to the image sensor. Also, be sure to use the
lens cap when the camera is not in use.
(5) Do not expose the camera unit to high temperatures. For
example. Do not place it near a stove for long periods,
or in direct sunshine or in a car in hot weather.
Heat may cause some malfunction.
(6) Keep the camera clean. Dust can damage the camera and
cause trouble in moving parts.
Take particular care to avoid the entry of sand or grit
when changing the camera lens.
(7) Avoid jolting the equipments or exposing it to vibration.
(8) Never attempt to dismantle the equipments.
(9) Avoid folding or stretching the camera cable or other connection
cable between equipments.
(10)When the cabinet is dusty, clean by gently wiping with a
soft cloth. And avoid the use of strong cleaning agents
such as benzine or alcohol as they may damage the
cabinet.
-1-

3, CONTROLS AND ADJUSTMENTS
Get to know the name and function of every part of your
camera. That way, you can take advantage of every
applications to take beautiful pictures.
The body and accessories shown below related to CS5131P.
3-1 Camera head
(1) Iris ring (Aperture ring) for use at manual operation.
To reduce aperture, rotate the iris ring toward CLOSE
(clockwise).
To increase aperture, rotate the iris ring toward OPEN
(counter clockwise). Adjust the lens aperture according
to the amount of light entering the lens so that correct
exposure is obtained.
(2) Focus ring
Take the focus with the ring to focus for the sharpest
picture.
* CS5131P camera is fitted with the "C" type lens mounting
system using the C mount adapter. This system allows
you to use any lenses belonging to the "C" mount group
according to your applications.
* No lens is included in the provided accessories, make
choice of the most appropriate lens, according to your
system as necessary.
-2-

(3) Camera cable
The camera cable can be extended from 2 meter to maximum
30 meters as necessary.
3-2 Camera control unit (front panel)
POWER WHITE BALANCE AGC ELC CAMERA
(1) “POWER”
A power on/off switch. When power is turned on, the
pilot lamp on the power switch will light.
(2) "AGC"
AGC ON/OFF Switch.
The AGC (Automatic Gain Control) switch is to increase
sensitivity electrically in low-light situations.
Set "AGC" switch to "ON" when illumination is not
sufficient on the subject. Normally, put it "OFF"
position.
(3) "WHITE BALANCE"
The picture taken with a camera is sometimes adversely
influenced by the quality of the light illuminating the
subject. To obtain fine color images, it is necessary to
adjust color balance (white balance) in the camera's
video circuit depending on the quality, or color
temperature, available from such illuminating sources,
e,g. morning, midday, evening, and fluorescent lamp.
When making adjustment on "WHITE BALANCE", select any
one of "AUTO SET"/”AUTO”/”MANU”.
-3-

* "AUTO" (Automatic follow-up system)
The purpose of this white balance of "AUTO" is for a TV monitoring
system, which installed to shoot a scenery
with wide angle. This automatic white balance adjust-
ment is performed by the detection of the average
picture levels of red(R), green(G), and blue(B) signals picked up from
the subject while they are balanced.
Under the proper condition, this incorporated function
is automatically compensated and follows up the white balance for
color temperature even when the camera is panned during shooting,
changed the color temperature of
a light source or changed ambient condition while "AUTO" position.
However, this control system is not always perfect, for example, under
a fluorescent light or when shooting and closing up a subject with
large colored area, this
control system cannot work properly and also cannot
obtain good color-imetry (color reproduction).
The purpose of the "AUTO" position is for TV monitoring system for a
scenery with a wide angle. If white balance adjustment ,is not
possible, use "AUTO SET" position.
* "AUTO SET" (Data holding)
Turning to "AUTO SET" after adjusted the white balance
for one or two seconds at "AUTO" position taking white subject, e.g.
white wall or white paper, the data of the white balance will be held.
And the white balance is
not change anything even if changed the illumination on subject and
the data will be held for about 5 hours
backing up the data.
Normally, set it "AUTO SET" position.
If you shoot more than 5 hours after the last white adjustment, or
when lighting conditions change,
re-perform white balance adjustment.
* "MANY" (Manual)
Turning to "MANU" position, take a white object such as
a white paper or white wall all over the screen and
adjust the white balance with the knobs of (R) and (B)
-4-

while watching the color monitor. For more information
on color temperature and white balance, refer to the
supplemental information of pages to and 11.
* "ELC" (Electronic Light Control)
This camera is provided with an automatic sensitivity
control which adjusts the shutter speed according to the
amount of light entering the lens so that correct
exposure is obtained even when illumination of the
object changes. Fixed shutter and manual control are
also possible.
3-3 Camera control unit (rear panel)
Following adjustments are located at the rear panel on
the camera control unit.
AGC LEVEL FUSE
VOLTAGE SELECTER
(1) "SHUTTER" (Electronic shutter)
Switch for an electronic shutter. It is available when
"ELC" switch is turned off on the front panel.
Usually, put "OFF" position which is set a shutter speed
of 1/50 sec.
When a subject moving at high speed is shot by the
camera, select any one of shutter speeds of 1/50, 1/125,
1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000 sec. as
necessary.
* "F.L" (Flickerless)
Where the illumination of fluorescent lamps are used in
the power frequency area of 60 Hz, a flicker may appear
on the picture. And if turned to "F,L" position, it will
be set the shutter speed 1/120 sec., resulting in
decrease the flicker on the picture.
-5-

For more information on electronic shutter and ELC
(automatic sensitivity control), refer to the supple-
mental information of page 12.
(2) AGC LEVEL
When the input of video signal is rated, the output
signal should be adjusted the same level as when AGC is
"ON" and when it is "OFF".
(3) VOLTAGE SELECTER
When supplied voltage of AC INLET is AC 220 240 V, put
the voltage selecter position that appears "230V". And
the voltage is AC 100 120 V, put the position of "115V".
When you switch the voltage selecter, you should use
a minus screw driver for M3 screw. And pull up or down
a knob or the voltage selecter with the screw driver.
(4) FUSE
You must use the fuses according to chart 1
CHART 1
INPUT VOLTAGE FUSES
AC 220~240 V
AC 100~120 V
AC250V, 315mA, Normal blowing type
AC125V, 500mA, Normal blowing type
-6-

4, CONNECTIONS
When install the CS5131P camera to your system, you have
to connect between equipments.
4-1. Typical connection.
-7-

4-2 Camera control unit (rear panel)
There are thirteen connectors at the rear panel on the
camera control unit.
Figure Camera control unit rear panel
(1) "R OUT","G OUT",”B OUT" (RGB video outputs)
R,G and B video signals are output individually from
the BNC type connectors. They can be connected the
use of the monitor provided R,G and B individual input
terminals.
(2) "SYNC OUT”
Use it when other equipments required pulses SYNC to be
synchronized with the camera.
When the external sync-operation, the pulses of SYNC are
regenerated inside of the camera control unit and are
output. When no pulses from outside (at the internal
sync-operation), SYNC generated inside are come out
together from the "SYNC OUT".
-8-

(3) "Y/C OUT” (S-terminal)
Y (lumminance signal) and C (chrominance) are output
from the "Y/C OUT" individually.
The employment of an S-terminal allows reduction of
cross color, dot disturbance, and color blurring that
may occur especially during picture editing, compared to
the PAL composite video signal.
Use the equipments with S-terminal in the system.
(4) "VBS OUT1", "VBS OUT2"
The PAL composite video signals are come out from these
connectors which are employed BNC type.
(5) "CHARACTER"
This connector is used to connect the character
generator "TGR-325" that is made by SONY CO.LTD.
(6) P.E.(Protective Earth)
Only use for P.E.
(7) "HD IN",”VD IN", "VBS IN" (Input pulses for external sync)
When required external sync-operation between other
equipments, use any one of pulses for HD/VD, VBS or SYNC.
And input HD pulse from the "HD IN" connecter and VD from
"VD IN" connector for HD/VD external sync operation. And
input VBS or SYNC from “VBS IN" connector for external
sync operation by VBS or SYNC. When used HD/VD or SYNC,
the system should be synchronized for HD and VD phase.
When VBS, the system should be synchronized for HD, VD
and SC phase also.
-9-

5, SUPPLEMENTAL INFORMATION
(1) "Color temperature"
Light is composed of various color components in differ-
ent proportions. A relationship exists between tempera-
ture of a light source and the components of the emitted
light; as the temperature rises, the color of light
varies from red, orange, yellow, white to blue in that
order. "Color temperature" is a value that expresses
differences in color among light sources, measured in
Kelvin degrees. Bluish light has a higher color
temperature than reddish light.
(2) "White balance"
Making the colors look natural on TV monitor is what
white balance is all about. Because a camera is not as
adaptable as the human eye, if a light source is reddish,
white subjects in that light are recorded as reddish.
White balance adjustment is performed to compensate for
color temperature variations of light so that whites are
reproduces as white. Correct white balance makes all
other colors correct.
The CS5131P can perform automatic white balance adjust-
ment with just the press of a switch.
However, if illumination is insufficient, white balance
adjustment cannot be performed. To obtain correct colors,
therefore, sufficient illumination is essential.
(3) How to get good color pictures.
The simplest way is to provide sufficient lighting(close
to the camera's reference illuminance) and accurately
adjust the camera to the color temperature of that
lighting.
If light sources of different color temperatures are
used together, accurate white balance adjustment is very
difficult. For example, if natural light is mixed with
some artificial light, which is likely to occur next to
windows, correct colors of the subject are difficult to
obtain. It is recommended that incandescent or halogen
lamps not be used together with flourescent lighting.
-10-

(4) Color temperature of various artificial lighting.
(5) CCD image sensor
CCD, as the nucleus in the camera, converts lens-caught
optical images to TV signals. This device ithe product
of the latest semiconductor technology. Minute pixels
of 400,000 (active pixel consists of 752 X 582) or so are
integrated in ultra high density on the small area of
6.4mm(H)X 4.8mm(V) by utilizing sophisticated semi-
conductor technology. As shown in Figure four comple-
mentary color filters of yellow(Ye), cyan(Cy), magenta
(M), and green(G) are placed precisely one on top of
another in a zigzag manner on one picture element so
that color analysis of the subject can be made and
fundamental color signals of red(R), blue(B) and green(G)
are picked out in the color demodulation circuit.
Mg: Magenta Cy: Cyan
G :Green Ye: Yellow
Figure Disposition of color analysis filter on CCD
-11-
Type of illumination Color Temperature
Tungsten lamp for home use 2800 K
Tungsten lamp for photographic use
Quartz-halogen lamp
3000 K
Blue lane for photographic use 5000 K
Warm white 3500 K
White 4500 K
Fluorescent lamp
Daylight type 6500
K

The spectral transmittance characteristics of each color
filter are shown in Figure below. This spectrum offers
high color-fidelity reproduced images. The horizontal
resolution of 450 TV lines for the luminance signal (Y)
is confirmed by a reproduced Retma chart on a television
monitor with this complementary mosaic color filter-
arrangement.
Figure spectral transmittance of the color filters
(6) Smear
When the strong light hits the CCD image sensor, the
image of bands in vertical direction may appear above
and under the spot. This is called smear. Especially if
the camera shoots under the noon sun or its reflections,
a candlelight in the dark, or headlights of cars, this
smears may stand out in the picture.
The CCD used with the C55131P is designed against the
smear. However, watch out for smear when shooting
involves a strong light sources.
(7) ELC (Electronic Light Control) and AGC (Automatic Gain
Control)
When a camera is directed toward a subject, the most
proper combination of shutter speed and lens aperture is
automatically determined in accordance with the bright-
ness of the subject. This is the program AE (Automatic
Exposure) mechanism incorporated in an ordinary 35mm
still camera. Meanwhile, just like in a 35mm camera,
-12-

the program AE mechanism housed in the video camera
automatically selects the speed of the electronic
shutter depending on the lighting. Simultaneously, the
amplifier gain in the camera instead of the lens
aperture (iris) value is likewise automatically adjusted
according to the pre-selected shutter speed to obtain
the most appropriate video signal level.
(8) Lenses
Generally, there are many kind of lenses for the video
camera on the market, for example, different aperture
(iris), different focal distance, zoom lenses and so on.
Those having a shorter focal distance are called "wide-
angle" lenses, and those having a longer focal distance
are called "telephoto". Lenses of different focal
distances have special characteristics and you can take
advantage of these in shooting. When the camera is
fitted with a zoom lens, it is extremely easy to vary
the focal distance. Anyhow, make choice of the most
appropriate lens for your application or system.
-13-

6, TROUBLE-SHOOTING GUIDE
What may initially appear to be trouble is not always a
real problem. Make sure first according to the following
table before a requesting service.
Symptoms Check points
Power
No power
is supplied
*Have you connected AC power cord
correctly?
*Are fuses blown?
Picture colors
greatly differ
from actual
subject colors.
*Have you moved to a
different location after
adjusting white balance?
*Or have you shot after 5
hours have elapsed from the last
white balance adjustment?
If so, readjust white balance.
*Have you shot with the
WHITE BALANCE switch set to
“AUTO” under mixed lighting or
a cloudy sky?
If so, adjust white balance.
White balance
is not possible.
*Have you aimed the lens at
a white object?
*Is the exposure proper?
If not so, increase or
decrease lighting.
Halation or
black-out occurs.
*Check whether the iris ring has
accidentally moved out of
the normal posistion.
-14-

7. SPECIFICATIONS
(1) TV system PAL
(2) Image sensor Interline CCD
Active pixel 752(H) X 582(V)
Active image area 6.4mm(H) X 4.8mm(V)
(equivalent to 1/2 inch
optical image size)
(3) Number of
scanning lines 625 lines
(4) Scanning system 2 . I interlace
(5) Sync. system Internal / External
(automatic change over)
(6) Scanning frequencies
Horizontal drive 15,625 kHz
Vertical drive 50 Hz
(7) Aspect ratio 4 : 3
(8) Illumination
Standard 1250 lux at F8, 3000K
Minimum 5 lux (F1.4. AGC-ON,
output level for 25%)
(9) Video output
PAL VBS 1.0 Vpp/75Ω
Y/C (S terminal) 1.4 Vpp/75Ω
RGB VS 0.286Vpp/75Ω
V (when SYNC OFF) 0.7 Vpp/75Ω
(10) Resolution
Horizontal 470 TV lines
Vertical 420 TV lines
(11) S/N (luminance) 46 dB or more
(12) External sync. pulses
HD 4 Vpp ± 2 Vpp/ high impedance
negative polarity
15.625 kHz±30ppm
VD 4 Vpp ± 2 Vpp/ high impedance
negative polarity
50 Hz ± 30ppm
SYNC 2 Vpp ±1 Vpp/ high impedance
negative polarity
-15-

Horizontal 15.625 kHz± 30ppm
Vertical 50 Hz ± 30ppm
VBS 1.0 Vpp/75Ω
positive polarity
Horizontal 15.625 kHz ± 30ppm
Vertical 50 Hz -h 30ppm
SC phase 4.433619 MHz ± 30ppm
(13) Output pulses (TTL level)
SYNC negative polarity
(14) Gamma correction 0.45
(15) AGC ON / OFF selectable
control range ± 6 dB
(16) White balance auto / manual selectable
(17) Electronic shutter ON/OFF selectable
Flicker less 1/120 sec.
ELC Automatic exposure system
with AGC in process amplifier
(18) Power source AC100~120V or AC220~240V
(selectable)
(19) Power consumption approx. 11 watts
(20) Ambient condition
Temperature 0°C to +40"C
Humidity 30 to 90%
(21) Camera cable
maximum length up to 30 meters
(22) Dimensions refer to pages 18 and 19
(23) Weight
Camera head approx. 16 gr.
Camera control approx. 2000 gr.
Design and specifications subject to change
without notice.
-16-

8, CONSTITUTION
(1) Camera head (without lens) 1 pc
with head cover
(2) Camera control unit 1 pc
(3) Provided accessories
Operation manual 1 pc
AC power cord 5 meters 1 pc
Fuses 2 pcs
(AC250/315mA normal blowing type)
(4) Optional Accessories
Purchase the following optional accessories depending
on your system as necessary.
Lens Focal length & f=4 mm, F 2.2
Aperture(Iris) f=7.5 mm, F 1.6
F=15 mm, F 2.0
f=24 mm, F 3.6
Lens adapter for C-mount
CS5131P can be fitted with C mount lens using
this C mount lens adapter.
* Camera cable 2m
3m
5m
10m
* S-cable
* BNC video cable
* Camera mounting kit
-17-
Make choice of the most
appropriate cables,
according to your system
or application.
