Telsa TS 8643 User manual
FROST FREE REFRIGERATOR
Fridge - Freezer
Instruction booklet
NO FROST בלושמ ררקמ
הלעפה תוארוה
EN -2-
Index
BEFORE USING THE APPLIANCE ..................................................................... 3
General warnings .........................................................................................................3
Old and out-of-order fridges .........................................................................................5
Safety warnings ............................................................................................................5
Installing and operating your fridge freezer ..................................................................6
Before using your fridge freezer ...................................................................................7
THE VARIOUS FUNCTION AND POSSIBILITIES ............................................... 7
Information about new generation cooling technology .................................................7
Display and control panel .............................................................................................8
Operating your fridge freezer........................................................................................8
Cooler temperature settings ..................................................................................................8
Super cool mode ...................................................................................................................8
Economy mode .....................................................................................................................8
Warnings about temperature adjustments....................................................................9
Accessories ..................................................................................................................9
Icematic (Making ice cubes) ..................................................................................................9
Chiller shelf ..........................................................................................................................10
Fresh dial .............................................................................................................................10
Adjustable door shelf ..........................................................................................................11
Natural ion tech / Ionisier .....................................................................................................11
Maxi-fresh preserver............................................................................................................11
ARRANGING FOOD IN THE APPLIANCE ........................................................ 12
Refrigerator compartment...........................................................................................12
Freezer compartment .................................................................................................13
CLEANING AND MAINTENANCE ..................................................................... 14
Replacing LED lighting ...............................................................................................15
TRANSPORTATION AND CHANGING OF INSTALLATION POSITION ........... 16
Repositioning the Door ...............................................................................................16
BEFORE CALLING YOUR AFTER SALES SERVICE....................................... 16
Tips for saving energy ................................................................................................18
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS .................... 19
The operating instructions apply to several models. Differences may therefore occur.
EN -3-
BEFORE USING THE APPLIANCE
General warnings
WARNING: Keep ventilation openings in the appliance enclosure
or in the built-in structure clear of obstruction.
WARNING: Do not use mechanical devices or other means, other
than those recommended by the manufacturer, to accelerate
the defrosting process.
WARNING: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of the
type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: To avoid a hazard due to the instability of the
appliance, it must be xed in accordance with the instructions.
• If your appliance uses R600a as a refrigerant (you can
nd this information on the label on the cooler) be careful
during shipment and installation to prevent your appliance’s
cooler elements from being damaged. Although R600a is
a environmental friendly and natural gas, it is explosive. If
the cooler elements have been damaged and you suspect a
leak, move the Fridge Freezer away from any heat sources
or open ame and ventilate the room the Fridge Freezer is
in for a few minutes.
• While carrying and positioning the fridge, do not damage the
cooler gas circuit.
• Do not store explosive substances such as aerosol cans
with a ammable propellant in this appliance.
• This appliance is intended to be used in household and
similar environments such as:
- staff kitchen areas in shops, ofces and other working
environments
- farm houses and by clients in hotels, motels and other
residential type environments
CHAPTER - 1
EN -4-
- bed and breakfast type environments
- catering and similar non-retail applications
• If the socket does not match the refrigerator plug, it must be
replaced by the manufacturer, its service agent or similar
qualied persons in order to avoid a hazard.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
• A specially grounded plug has been connected to the power
cable of your refrigerator. This plug should be used with a
specially grounded socket of 16 amperes. If there is no such
socket in your house, please have it installed by a qualied
electrician.
• If the supply cord is demaged it must be replaced by the
manufacturer, its service agent or similar qualied persons
in order to avoid a hazard.
• This appliance is not intended for use at altitudes exceeding
2000 m.
EN -5-
Old and out-of-order fridges
• If your old fridge has a lock, break or remove the lock before discarding it. Children may
get trapped inside it and may cause an accident.
• Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore,
take care not to harm the environment when you discard your old fridge.
Disposal of your old appliance
The symbol on the product or on its packaging indicates that this product may not
be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. By
ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For more
detailed information about recycling of this product, please contact your local city ofce, your
household waste disposal service or the shop where you purchased the product.
Notes:
• Please read the instruction manual carefully before installing and using your appliance.
We are not responsible for any damage caused due to misuse.
• Follow all instructions on your appliance and instruction manual and keep this manual
in a safe place to resolve any problems that may occur in the future.
• This appliance is produced to be used at houses and it can only be used in a house
for the specied purposes. It is not suitable for commercial or common use. Such use
will cause the guarantee of the appliance to be cancelled and our company will not be
responsible for any losses which are incurred.
• This appliance is produced to be used in houses and it is only suitable for cooling
/ storing foods. It is not suitable for commercial or common use and/or for storing
substances other than food. Our company is not responsible for any losses which are
incurred in the contrary case.
Safety warnings
• Do not connect your fridge freezer to the mainselectricity supply using an extension
lead.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow children to
play with the appliance or let them hang off the door.
• Never touch the power cord/plug with wet hands as this could cause a
short circuit or electric shock.
• Do not place glass bottles or beverage cans in the ice-making
compartment as they can burst as the contents freeze.
• Do not place explosive or ammable material in your fridge. Place
drinks with high alcohol content vertically in the fridge compartment
and make sure that their tops are tightly closed.
EN -6-
• When removing ice from the ice-making compartment, do not touch it. Ice
may cause frost burns and/or cuts.
• Do not touch frozen goods with wet hands. Do not eat ice-cream or ice cubes
immediately after you have taken them out of the ice-making compartment.
• Do not re-freeze frozen goods after they have melted. This may cause health issues
such as food poisoning.
• Do not cover the body or top of fridge with lace. This affects the performance of your
fridge.
• Secure any accessories in the fridge during transportation to prevent damage to the
accessories.
Installing and operating your fridge freezer
Before starting to use your fridge freezer, you should pay attention to the following points:
• The operating voltage for your fridge freezer is 220-240 V at 50Hz.
• We do not accept responsibility for any damages that occur due to ungrounded usage.
• Place your fridge freezer where it will not be exposed to direct sunlight.
• Your appliance should be at least 50 cm away from stoves, gas ovens and heater cores,
and at least 5 cm away from electrical ovens.
• Your fridge freezer should never be used outdoors or exposed to rain.
• When your fridge freezer is placed next to a deep freezer, there should be at least 2 cm
between them to prevent humidity forming on the outer surface.
• Do not place anything on your fridge freezer, and install your fridge freezer in a suitable
place so that at least 15 cm of free space is available above it.
• Do not place heavy items on the appliance.
• Use the adjustable levelling feet to make sure your appliance is level and
stable. You can adjust the levelling feets by turning them in either direction.
This should be done before placing food in the fridge freezer.
• Before using your fridge freezer, wipe all parts with a solution of warm
water and a teaspoon of sodium bicarbonate, then rinse with clean water and dry.
Place all parts in the fridge after cleaning.
If your refrigerator has a fan condenser:
The condenser of your fridge is placed at the bottom of cabinet. As a result of that, assemble
the spacer by xing it to holes on the cover bottom panel and turn 90° that’s shown below
gure for arranging the distance between the refrigerator and the back wall at where you
place the fridge. You can move the fridge towards the back wall until that point.
Plastic for distance setting
EN -7-
Before using your fridge freezer
• When using your fridge freezer for the rst time, or after transportation,
keep it in an upright position for at least 3 hours before plugging into
the mains. This allows efcient operation and prevents damage to the
compressor.
• Your fridge freezer may have a smell when it is operated for the rst time. This is normal
and the smell will fade away when your fridge freezer starts to cool.
THE VARIOUS FUNCTION AND POSSIBILITIES
Information about new generation cooling technology
Fridges with new generation cooling technology have a different
working system than static fridges. Other fridges may experience
ice build up in the freezer compartment due to door openings
and humidity in the food. In such fridges regular defrosting is
required; the fridge has to be periodically turned off, the frozen
food moved to a suitable container and the ice which has formed
in the freezer compartment removed.
In fridges with new generation cooling technology, dry cold air
is pumped evenly into the fridge and freezer compartments
using a fan. The cold air cools your food evenly and uniformly,
preventing humidity and ice build up.
In the refrigerator compartment, air blown by the fan located
at the top of refrigerator compartment is cooled while passing
through the gap behind the air duct. At the same time, the air is
blown out through the holes in the air duct evenly spreading cool
air throughout the refrigerator compartment.
As there is no air passage between the freezer and refrigerator
compartments there will be no odor mixing.
As a result of this, your fridge with new generation cooling
technology gives you ease of use as well as huge volume and
aesthetic appearance.
CHAPTER - 2
EN -8-
Display and control panel
It is Economy mode
indicator.
It is Super cool mode
indicator.
Set button
Button LED
Thermostat set level
indicator
Operating your fridge freezer
Cooler temperature settings
• Initial temperature value for cooler setting indicator is 3.
• Press set button once, the set value will start to blink.
• If you keep pressing set button, lower temperatures will be selected. (1, 2, 3, 4, 5, super
and eco)
• If no button is pressed for 1 second, your choice will be set, it will blink 3 times. Buzzer
will sound beep beep.
• The temperature value selected before super cool mode or economy mode is activated
will remain the same when the mode is over or cancelled. The appliance continues to
operate with this temperature value.
Super cool mode
How would it be used?
Press set button until super cool symbol will be seen on the screen. Buzzer will sound
beep beep. Mode will be set.
During this mode:
• Economy mode can not be selected.
• Super cool mode can be cancelled by the same operation of selecting.
Economy mode
How would it be used?
Press set button until eco symbol will be seen on the screen. Buzzer will sound beep
beep. Mode will be set.
During this mode:
• Super cool can be selected. Economy mode is automatically cancelled and the
selected mode is activated.
• Eco mode can be cancelled by the same operation of selecting.
EN -9-
Warnings about temperature adjustments
• Your temperature adjustments will not be deleted when an energy breakdown occurs.
• Temperature adjustments should be made according to the frequency of door openings
and the quantity of food kept inside the fridge.
• Do not pass to another adjustment before completing an adjustment.
• Your fridge should be operated up to 24 hours according to the ambient temperature
without interruption after being plugged in to be completely cooled. Do not open doors
of your fridge frequently and do not place much food inside it in this period.
• A 5 minute delaying function is applied to prevent damage to the compressor of your
fridge, when you take the plug off and then plug it on again to operate it or when an
energy breakdown occurs. Your fridge will start to operate normally after 5 minutes.
• Your fridge is designed to operate in the ambient temperature intervals stated in the
standards, according to the climate class stated in the information label. We do not
recommend operating your fridge out
of stated temperatures value limits in
terms of cooling effectiveness.
• This appliance is designed for use at an
ambient temperature within the 10°C -
43°C range.
Climate Class Ambient Temperature oC
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
Accessories
Icematic (Making ice cubes)
• Take out the ice making tray
• Fill the water to the line.
• Place the ice making tray in its original
position
• When ice cubes are formed, twist the
lever to drop ice cubes into the icebox.
Note:
• Do not ll the icebox with water to make
ice. This may damage it.
• The movement of the ice maker may be difcult while the refrigerator is running. In such
a case it should be cleaned by removing the glass shelves.
Removing the Ice maker
• Remove the freezer glass shelves
• Remove the icemaker by pulling left or right
on the shelf.
You can remove the icemaker to increase the available volume in the freezer compartment.
(In some models)
EN -10-
Ice tray
• Fill the ice tray with water and place in the freezer compartment.
• After the water has completely turned into ice, you can twist the tray as shownbelow to
remove the ice cubes.
(In some models)
Chiller shelf
Keeping food in the Chiller compartment instead of the
freezer or refrigerator compartment allows food retain
freshness and avour longer, while preserving its fresh
appearance. When chiller tray becomes dirty, remove
it and wash it with water.
(Water freezes at 0°C, but foods containing salt or
sugar freeze at temperature lower than that)
Normally people use the chiller compartment for raw
sh, lightly pickled, rice, etc...
Do not put foods you want to freeze or ice trays in order to make ice.
Removing the Chiller shelf
• Pull the chiller shelf out toward you by sliding
on rails.
• Pull the chiller shelf up from rail to remove.
(In some models)
Fresh dial
When the humidity controler in the closed position, it allows
fresh fruit and vegetables to be stored longer.
In case of the crisper is totally full, the fresh dial is located
in front of crisper, should be opened. By means of this the
air in the crisper and humidity rate will be controlled and
endurance life will be increased.
If you see any condensation on glass shelf, humidity control
should be taken into the open positions.
EN -11-
Adjustable door shelf
Five different height adjustments can be made to provide storage areas
that you need by adjustable door shelf.
To change the position of adjustable door shelf;
Lift up front of the shelf (1) and move up or down adjustable door shelf (2)
with both hands(Fig 1)
Before releasing the door shelf make sure the door shelf is located at door
positions.
(In some models)
Figure -1
(1) (2)
Natural ion tech / Ionisier
Natural Ion Tech spreads negative ions which neutralize particles of unpleasant smell and
dust in the air.
By removing these particles from the
air in the refrigerator, Natural Ion Tech
improves air quality and eliminates
odours.
• This feature is optional. It may not
exist on your product.
• The location of your ioniser device
may vary from product to product.
(In some models)
Maxi-fresh preserver
Maxi Fresh Preserver technology helps to remove ethylene gas (a
bioproduct released naturally from fresh foods) and unpleasant odors
from the crisper. In this way, food stays fresh for a longer time.
• Maxi Fresh Preserver must be cleaned once in a year. The lter
should be waited for 2 hours at 65°C in a oven.
• To clean the lter, please remove the back cover of the lter box by
pulling it in the direction of the arrow (A).
• The lter should not be washed with water or any detergent.
Notes: The assembly position of the lter may vary depending on the
crisper design. Please see the related images on page 1. For some
models, the lter cannot be attached as shown in the images. In this case
it can be simply put into the drawer.
(In some models)
Ionisier
Maxi Fresh Preserver
(In some models)
Visual and text descriptions on the accessories
section may vary according to the model of
your appliance.
EN -12-
ARRANGING FOOD IN THE APPLIANCE
CHAPTER - 3
It will be enough to set the thermostat between “2-4”, for fridge to work in normal working
conditions.
Refrigerator compartment
• To reduce humidity and consequent increase of frost never place liquids in unsealed
containers in the refrigerator.
• Never place warm food in the refrigerator. Warm food should be allowed to cool at
room temperature and arranged to ensure adequate air circulation in the refrigerator
compartment.
• Arrange meat and cleaned sh (wrapped in packages or sheets of plastic) and use
them within 1-2 days.
• You can put the fruits and vegetables into the crisper without any packaging.
Important note:
• Cover any cooked dishes when you put them in the
fridge. Place them in the fridge when they are cool,
otherwise temperature/humidity inside the fridge
increases which causes the fridge to work harder.
Covering food and beverages also preserves their
avour and aroma.
• Potatoes, onion and garlic should not be kept in the
fridge.
• Make sure food does not touch the temperature
sensor which is located in the refrigerator
compartment. To keep an optimum temperature
in the refrigerator compartment, make sure food
doesn’t make contact with the sensor.
Temperature sensor area
EN -13-
Freezer compartment
• The freezer compartment is used for freezing fresh food, for storing frozen foods for the
period of time indicated on packaging and for making ice cubes.
• Do not put fresh and warm foods in the freezer door shelves to be frozen. Only use the
door shelves for storing frozen foods.
• Do not put fresh and warm food next to frozen food as it can thaw the frozen food.
• Use the fast freezing shelf to freeze home cooking (and any other food which needs to
be frozen quickly) more quickly because of the freezing shelf’s greater freezing power.
• While freezing fresh foods (i.e. meat, sh and mincemeat) divide them in portions you
will use in a single serving.
• While freezing fresh foods, the maximum amount of fresh food (in kg) that can be frozen
in 24 hours is indicated on the appliance label.
• For optimum appliance performance to reach maximum freezing capacity, turn the
thermostat knob to the coldest setting 24 hours before placing fresh food into the
freezer.
• After placing fresh food into the freezer, having the thermostat knob set to the coldest
setting for 24 hours is generally sufcient. After 24 hours, you can reduce the thermostat
knob setting if required.
• Attention. To save energy, if you are only freezing small amounts of food, you do not
need to set the thermostat knob to the coldest setting.
• For storing frozen foods, the instructions shown on frozen food packages should always
be followed carefully. If no information is provided, food should not be stored for more
than 3 months from the purchased date.
• When buying frozen food ensure that these have been frozen at suitable temperatures
and that the packing is intact.
• Frozen food should be transported in appropriate containers to maintain the quality
of the food and should be returned to the freezing surfaces of the unit in the shortest
possible time.
• If a package of frozen food shows the sign of humidity and abnormal swelling it is
probable that it has been previously stored at an unsuitable temperature and that the
contents have deteriorated.
• The storage life of frozen foods depends on the room temperature, thermostat setting,
how often the door is opened, the type of food and the length of time required to
transport the product from the shop to your home. Always follow the instructions printed
on the packaging and never exceed the maximum storage life indicated.
In some models: while loading the freezing compartment, do not load
above the the loading lines otherwise the door may not close correctly.
If the freezer compartment door does not close correctly, excess ice may
form in the freezer compartment. To prevent the problem recurring, clear
the ice and make sure that the door is fully closed.
Also, not closing the freezer and/or fridge compartment doors would
increase your energy consumption.
EN -14-
CLEANING AND MAINTENANCE
• Make sure to unplug the fridge before starting to clean it.
• Do not wash your fridge by pouring water.
• You can wipe the inner and outer sides with a soft cloth or a sponge
using warm and soapy water.
• Remove the parts individually and clean with soapy water. Do
not wash in washing machine.
• Never use ammable, explosive or corrosive material like thinner, gas,
acid for cleaning.
• You should clean the condenser with broom at least once
a year in order to provide energy saving and increase the
productivity.
Make sure that your fridge is unplugged while cleaning.
If the lower shelf in the freezer door is removed and
food is allowed to block the air suction hole, this will
reduce the effectiveness of the fridge.
Therefore, be careful while loading the freezer
compartment and make sure not to cover the air
suction hole.
Air suction hole
CHAPTER - 4
EN -15-
Replacing LED lighting
If your refrigerator has LED lighting contact the help desk as this should be changed by
authorized personnel only.
Note: Numbers and location of led strips may be changed according to the model.
!!! Some versions may be without freezer illumination.
Freezer compartment
LED strip lamp
Fridge compartment
LED strip lamps
Fridge compartment
LED strip lamps Fridge compartment
LED strip lamps
(a)
(b)
(c)
EN -16-
TRANSPORTATION AND CHANGING OF
INSTALLATION POSITION
Transportation and Changing of Installation Position
• Original package and foam may be kept for re-transportation (optionally).
• You should fasten your fridge with thick package, bands or strong cords and follow the
instructions for transportation on the package for
re-transportation.
• Remove movable parts (shelves, accessories,
vegetable bins etc.) or x them into the fridge
against shocks using bands during re-positioning
and transportation.
Carry your fridge in the upright position.
Repositioning the Door
• It is not possible to change the opening direction of your fridge door, if the door handles
on your fridge are installed from the front surface of the door.
• It is possible to change the opening direction of the door on models without any handles.
• If the door opening direction of your fridge may be changed, you should contact the
nearest Authorized Service to have the opening direction changed.
BEFORE CALLING YOUR AFTER SALES
SERVICE
CHAPTER - 5
CHAPTER - 6
What to do if your refrigerator does not operate:
Check that:
• Your fridge is plugged in and switched on,
• The fuse is not blown and there is not a power cut,
• The thermostat setting is in the on the "1" position,
• The socket is no longer functioning. To check this, plug in an appliance that you know
is working into the same socket.
What to do if your refrigerator performs poorly:
Check that:
• You have not overloaded the appliance,
• The doors are fully closed ,
• There is no dust on the condenser,
• There is enough space for air circulation at the rear and side of the appliance.
Check Warnings;
Your fridge warns you if there is/are some part(s) out of order. In this case, LED around the
button will blink and buzzer will sound beep.
ERROR TYPE MEANING WHY WHAT TO DO
SR "Failure
Warning"
There is/are some
part(s) Out of order
Call Service for
assistance as soon as
possible.
EN -17-
If your fridge is operating too loudly:
Normal Noises
Cracking (Ice cracking) noise:
• During automatic defrosting.
• When the appliance is cooled or warmed (due to expansion of appliance material).
Click noise: Heard when the thermostat switches the compressor on/off.
Compressor noise:
• Normal motor noise: This noise means that the compressor is operating normally
• The compressor may cause more noise for a short time when it is rst activated.
Bubbling noise and splash: This noise is caused by the ow of the refrigerant in the
tubes of the system.
Water ow noise: Normal ow noise of water owing to the evaporation container during
defrosting. This noise can be heard during defrosting.
Air blow noise (Normal fan noise): This noise can be heard during the normal operation
of system due to the circulation of air.
If humidity builds up inside the fridge;
• Is all the food packed properly? Are all containers thoroughly dried before placing them
in the fridge?
• Are the fridge doors opened frequently? Humidity of the room gets into the fridge each
time the doors are opened. Humidity build up will be faster if you open the doors more
frequently, especially if the humidity of the room is high.
• Build up of water drops on the rear wall after automatic defrosting is normal. (in Static
Models)
If the doors are not opened and closed properly;
• Do the food packages prevent closing of the door?
• Are the door compartments, shelves and drawers placed properly?
• Are door gaskets broken or torn?
• Is your fridge on a level surface?
If the edges of fridge cabinet that the door joint contact are warm;
Especially in summer (hot weather), the surfaces that the joint contact may get warmer
during the operation of the compressor. This is normal.
IMPORTANT NOTES:
• If the appliance is switched off or unplugged, wait at least 5 minutes before plugging the
appliance in or restarting it in order not to damage the compressor.
• If the appliance is not used for long time (for example during holidays) defrost and clean
the refrigerator, leaving the door open to prevent the formation of midew and smell.
• If the problem persists after you have followed all the instructions above, please consult
the nearest Authorised Service.
• The appliance you have purchased is designed for home use and can be used only at
home and for the stated purposes. It is not suitable for commercial or common use. If
the consumer uses the appliance in a way that does not comply with these instructions,
we emphasise that the producer and the dealer shall not be responsible for any repair
or failure within the guarantee period.
EN -18-
Tips for saving energy
1– Install the appliance in a cool, well ventilated room , but not in direct sunlight and not near
heat source (radiator, cooker.. etc. ). Otherwise use an insulating plate.
2– Allow warm food and drinks to cool down outside the appliance.
3– When thawing frozen food, place it in the refrigerator compartment. The low temperature
of the frozen food will help to cool the refrigerator compartment when it is thawing. So it
reduces the energy requirements.
4– When placing, drinks and liquids they must be covered. Otherwise humidity increases at
the appliance. Therefore the working time gets longer. Also covering drinks and liquids
helps preserve the smell and taste.
5– When placing food and drinks, open the appliance door as briey as possible.
6– Keep the covers closed of any different temperature compartment in the appliance
(crisper, chiller ...etc. ).
7– Door gasket must be clean and pliable. Replace gaskets if worn.
• The lifetime of your appliance stated and declared by the Department of the Industry
is 10 years (the period for retaining parts required for the proper functioning of the
appliance).
EN -19-
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
CHAPTER - 7
1
A2
4
5
6
7
8
9
10
11
12
13
14
B
15
16
3
A. Freezer compartment
B. Fridge compartment
1. Freezer door shelves
2. Freezer shelf
3. Icematic *
4. Ice box tray*
5. Interior display / In room control
6. Bottle shelf / Wine rack *
7. Fridge compartment shelves
8. Ionisier *
9. Chiller shelf *
10. Glass shelf over the crisper
11. Crisper
12. Levelling feet
13. Bottle shelf
14. Adjustable door shelf *
15.Door shelves
16. Egg holder
* In some models
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.
Table of contents
Languages:
Other Telsa Refrigerator manuals
