“FI-NSP”BOILERSONSOLIDFUEL–PELLETS
ASSEMBLING,OPERATIONANDMAINTENANCEINSTRUCTIONS
BOILER’STECHNICALBOOK

ver.2
2
ATTENTION! STRICTLY RESPECT!
To protect against acid condense and to avoid the formation of tars
attacking the boiler’s body, it is mandatory to correctly assemble one of the
following equipment: 4 way valve or thermostatic mixing valve or
thermostatic control recirculation pump, (according to the fig.
”Installation scheme”, pg. 25-28.)
The boiler operating temperature must be in the range 70 – 90 °C,
while the minimal return temperature 60°C.
Use light color pellets as fuel (with minimum residues content) with
the maximum humidity of 12% and quality dry wood with the
maximum humidity of 25%.
When sizing the central heating boiler, you must take into account
the correct calculation of the heat needs, do not oversize the boiler!
The inobservance of the requirements above entails the
warranty loss!

ver.2
3
Dear beneficiary,
Thank you for choosing FI-NSP BOILER ON SOLID FUEL – PELLETS, an innovating and
modern product, with special qualities and performances. This product provides maximum
satisfaction if you use the boiler according to the recommendations of this manual. We guarantee you
its long term use if the boiler’s putting into service is made by the authorized personnel of S.C.
TERMOFARC S.R.L.
The company provides you warranty and long term post warranty.
Many of us have the experience of heating up using fire wood or wood scrap briquettes in
the hot water boilers. It’s been a while since a new solid fuel appeared, the so-called pellets, an
ecological fuel manufactured in a similar way as the wood scrap briquettes, by pressing wood wastes
(wood scrap and wood chips),without any high pressure binders. The pellets have a cylindrical shape,
with a diameter of 6 – 10 mm and up to50 mm long, with a calorific efficiency of 4.8 - 5 kWh/kg.
Pellets are supplied in plastic bags of 15, 20, or 25 kg. Yet, in other countries, they are transported in
cisterns out of which the pellets are directly fed to tanks.
The benefit of such pellets is that they are ecological and that they may be used for heating
in central heating stations with automatic feeding.
Due to these reasons, our company executed this product, FI-NSP BOILER ON SOLID
FUEL – PELLETS made up of the pellets burner, the pellets tank with the feeding system and the
boiler type FI-NS already on the market for a long time.
This manual refers to the assembling, installation and use of the product. Thoroughly
studying the instructions, you shall get important information for the safe operation of this boiler,
thus obtaining optimum performances and long term use. To market them and for the product’s
compliance with the essential security requirements stipulated in the European Directives, the boilers
have been assessed by ISCIR CERT, consequently the compliance certificate 041B1 – 584/EC being
issued.
TERMOFARC

ver.2
4
GENERAL ISSUES
Important warning ………………………………………….………………………………………………………6
Be aware! ………………………………………………………….…………………………………………………….7
Boiler description …………………………………………….………………………………………………………8
Identification……………………………………………………….………………………………………………….8
Component parts …………………………………………………………………………………………………..9
Technical data ……………………………………………………………………………………………………………11
Accessories …………………………………………………………………………………………………………….15
CHAPTER 1 .....................................................................................................Error! Bookmark not defined.
ASSEMBLING INSTRUCTIONS ...............................................................................Error! Bookmark not defined.
1.1. Choosing the boiler ..........................................................................................Error! Bookmark not defined.
1.3. Assembling and position of the boiler ...........................................................Error! Bookmark not defined.
1.4. Assembling the pellets burner and the feeding system ..................................Error! Bookmark not defined.
1.5. Hydraulic connections ......................................................................................Error! Bookmark not defined.
1.6. Safety elements .................................................................................................Error! Bookmark not defined.
1.7. Connection of the safety elements ...................................................................Error! Bookmark not defined.
1.8. Operation of the safety exchanger (cooling coil). ...........................................Error! Bookmark not defined.
1.9. Open systems and closed systems ...................................................................Error! Bookmark not defined.
1.9.1. Open systems (with open expansion tank) ...........................................................................Error! Bookmark not defined.
1.9.2. Closed systems (with closed expansion tank).....................................................................................................................25
1.10. Pump for the heating circuit............................................................................Error! Bookmark not defined.
1.11. ESBE mixing heat valve ................................................................................Error! Bookmark not defined.
1.12. 4 ways valve.....................................................................................................Error! Bookmark not defined.
1.13. Ventilation .........................................................................................................................................................26
1.14. Installation connection schemes.......................................................................................................................26
1.15. Connection to the stack.....................................................................................................................................31
1.16. Filling in the system..........................................................................................................................................31
1.17. Circuit diagram of the boiler.............................................................................................................................32
Chapter 2 .........................................................................................................Error! Bookmark not defined.
DESCRIPTION OF THE PELLETS BURNER.......................................................................................................33
2.1. Applicability ........................................................................................................................................................33
2.2. Component parts of the burner ...........................................................................................................................33
2.3. Circuit diagram of the burner..............................................................................................................................34
2.4. Operation of the burner .......................................................................................................................................35
2.5. Functions of the programmable automaton .......................................................................................................35
2.5.1 Setting the parameters...........................................................................................................................................................36
2.6. Adjusting the burner............................................................................................................................................37
2.7. Time parameters ajustment according to the heating plant .............................................................................37
2.8. Constructive safety rules.....................................................................................................................................38
Chaper 3......................................................................................................................................................39
PUTTING INTO SERVICE...........................................................................................Error! Bookmark not defined.
3.1. The first putting into service.............................................................................Error! Bookmark not defined.
3.1.1. Checks during the first putting into service.........................................................................Error! Bookmark not defined.
3.1.2. Putting into service...............................................................................................................................................................39
3.1.2.1. Putting into service – operating on wood........................................................................................................................39
3.1.2.2. Putting into service – operating on pellets...................................................................................................................... 40
3.1.3. Commissioning to the beneficiary.......................................................................................................................................40
Chapter 4 ....................................................................................................................................................41
USE AND MAINTENANCE INSTRUCTIONS.........................................................Error! Bookmark not defined.
4.1. Boiler’s operation................................................................................................................................................41
4.1.1. Operation of the boiler on wood...........................................................................................Error! Bookmark not defined.
4.1.2. Operation of the boiler on pellets........................................................................................................................................41
4.2. Ignition.................................................................................................................................................................42
4.2.1. Ignition for the operation on wood......................................................................................................................................42
4.2.2. Ignition for the operation on pellets....................................................................................................................................42
4.3. Adjustments .......................................................................................................Error! Bookmark not defined.
4.3.1. Thermostat controller of the draft (used during the operation on wood).........................Error! Bookmark not defined.
4.3.2. Control panel (for the automatic operation on pellets)......................................................Error! Bookmark not defined.
4.4. Fuel feeding and re-feeding................................................................................................................................44
4.4.1. Feeding and re-feeding for the operation on wood............................................................................................................44
4.4.2. Feeding and re-feeding for theautomatic operation on pellets.........................................................................................45
TABLE OF CONTENTS
CUPRINS

ver.2
5
4.5. Continuous operation ........................................................................................Error! Bookmark not defined.
4.5.1. Continous operation on wood...............................................................................................Error! Bookmark not defined.
4.5.2. Continous operation on pellets.............................................................................................Error! Bookmark not defined.
4.6. Summertime operation........................................................................................................................................45
4.6.1. Summertime operation on wood...........................................................................................Error! Bookmark not defined.
4.6.2. Summertime operation on pellets.........................................................................................Error! Bookmark not defined.
4.7. Short term interruption of the operation.............................................................................................................45
4.8. Long term interruption of the operation...........................................................Error! Bookmark not defined.
4.9. Requirements for the fuel..................................................................................Error! Bookmark not defined.
4.9.1. Requirements for wood..........................................................................................................Error! Bookmark not defined.
4.9.2. Requirements for pellets........................................................................................................Error! Bookmark not defined.
4.10. Use ...................................................................................................................Error! Bookmark not defined.
4.10.1. Use when operating on wood..............................................................................................Error! Bookmark not defined.
4.10.2. Use when operating on pellets...........................................................................................................................................48
4.11. Cleaning the boiler and the burner ...................................................................................................................48
4.11.1 Way of cleaning the boiler..................................................................................................................................................49
4.12. Maintenance of the boiler and of the heating system .....................................................................................49
4.13. Boiler’s tightness...............................................................................................................................................50
4.14. Changing the door’s packing cord ...................................................................................................................50
4.15. Changing the grates ..........................................................................................................................................50
Chapter 5 .........................................................................................................Error! Bookmark not defined.
BREAKDOWNS AND SOLUTIONS ..........................................................................Error! Bookmark not defined.
Chapter 6 .........................................................................................................Error! Bookmark not defined.
SPARE PARTS ...............................................................................................................Error! Bookmark not defined.
Chapter 7 .........................................................................................................Error! Bookmark not defined.
NORMS OF LABOR PROTECTION AND FIRE FIGHTING .............................Error! Bookmark not defined.
Chapter 8 ....................................................................................................................................................53
QUALITY AND WARRANTY CONDITIONS ........................................................Error! Bookmark not defined.
HOUSE TEST REPORT ...............................................................................................Error! Bookmark not defined.
DECLARATION OF CONFORMITY .......................................................................Error! Bookmark not defined.

ver.2
6


This manual is an
integral and
essential part of the product and must be handed to the
user. It must be kept the entire operation time of the products and if the product
changes its owner, it must be handed over to the new one.


Carefully read this manual and keep it in a safe place for subsequent use.


After opening the packing, check and inventory the components to
make sure all of
them are present and complete. Do not dispose the packaging elements in the
environment and keep them out of the reach of children.


Before installing
the
FI
–
NSP boiler, carefully read the chapter “Installation
Instructions”.


The a
ssembling shall be exclusively executed by authorized personnel in compliance
with the norms in force (Romanian Standard - STAS 7132-86; STAS 3417-85; Norm I
13-94; Norm I 13/1-96; PT C 9-2003; PT A2-2003; ISCIR collection; GP 051-2000; P
118-99).
All guidelines of this manual are to be observed; any deviation may cause damages
that the constructor does not undertake the responsibility for.


In cases of faulty operation of the boiler, stop it immediately and contact one of the
centers providing repairs for this product. Never use the boiler if it does not operate
appropriately.


In case of breakdown, exclusively original component parts
shall be used for
replacement. To use other components than those recommended by the manufacturer,
first of all you need to obtain its written approval and consent.


Never use the boiler with removed or faulty safety devices. In case of breakdown,
exclusively original component parts shall be used for replacing.


This boiler is meant to be used as it was designed. Any other use is considered
inappropriate.


To guarantee the efficiency and safety of the boiler’s operation, we recommend an
annual check made by specialized and authorized personnel, respecting the
constructor’s conditions.


Before starting, using or making any maintenance operations, carefully read the
instructions of this manual. Most of the accidents are caused by the inobservance of
simple security measures and of the use procedures.


Never make cleaning or maintenance operations while the boiler is in use.


During the first putting into service of the boiler, an unpleasant scent or smoke may
appear; this is normal and it shall disappear after a short time of use.


If you do not use the installation for a longer period of time, call for the service
authorized team of Termofarc to check it.


The room where the boiler shall be assembled needs to permanently be clean, dry a
nd
well ventilated.


Children and mentally disabled persons are prohibited to use the boiler.
The boiler may only be used by trained adult persons; unsupervised children are not
allowed near the boiler.


Do not touch the hot boiler with unprotect
ed hands, use gloves. Warning! The hot
parts of the boiler may cause serious burns.

It is forbidden to use the boiler empty or partially filled with water. The use of the
boiler empty or the partially filled with water may cause an explosion. From time to
time you must check the pressure of the water in the heating installation. The boiler’s
refill and fill with heating agent shall be done only when it is stopped and cold.

It is forbidden to deposit flammable objects and materials on or around the boi
ler.

The body of the boiler needs to be null
-
connected for protection in order to have
earthing and to prevent the electric shocks if the electric components become faulty.
IMPORTANT WARNING

ver.2
7
The manufacturer disclaims all responsibility for the damages caused by assembling or use faults
and the inobservance of the manufactureer’s instructions.


While the boiler is manaully operating by wood feeding, the wood must be dry, with a
maximum humidity of 25%, and while operating automatically, the humidity of the pellets
must be of maximum 12%.


During the combustion process soot, tar and acid steam may appear. To diminish their
quantity, the boiler must operate at optimum parameters (the temperature of the heating
agent in the boiler must be of 70 - 90°C, and the temperature of the return heating agent
must be of minimum 60°C). We recommend the use of four ways valves, of thermostat
control re-circulation pumps or of heat valves TV (25, 32, 40) according to the assembling
way.


The boiler shall not be used below the no
minal capacity. In the transition period or in the
summertime (when we only need household hot water – ACM), the boiler shall be started
daily.


The boiler shall be located at the same level as the rooms to be heated or at the subsoil and
it may operate by gravitation (natural) or induced (with pump) draught.
The location of the boiler in dwelling rooms or on the access halls is forbidden.


You must have enough room to store the fuel, strictly respecting the firefighting
regulations.


The floor, the
ceiling and the walls must be executed of fire
-
proof materials according to
the applicable standards.


The heat power plant must be endowed with admission
inlets
or pipes for the fresh air
with the section of 400 cm2. The mechanical exhaust of the air is not allowed.


The burn gases pipes must be well sealed and insulated, have the minimal section
according to the “technical data” chart and the stack sufficiently high to provide an
appropriate draught of the boiler.


When placing the boiler, the foll
owing distances shall be respe
cted: 0.6 m in the lateral
of
the boiler; 0.6 m in the backside; 1.5 m in the front and 0.6 m to the ceiling.


The boiler shall be connected to an open expansion tank, accordingly dimensioned. We
may use a closed expansion tank if a permanent source of water is provided and the boiler
may be protected against overheating. On the safety turn - return pipes for the connection
of the boiler with the expansion tank, no closing or throttle parts shall be fitted.


From time to ti
me, you shall clean the smoke tracks using the upper doors. The cleaning
of the smoke tracks shall be carried out when the boiler is turned off and cooled down.


From time to time or whenever necessary, the ash must be removed from the ash pan
through the drawer. This operation shall be carried out only when the boiler is turned off
and cold. We recommend the cleaning of the burner from ash and wastes each 2 – 5 days,
depending on the quality of the used pellets.


After its putting into service, the man
ufacturer or its representative has the obligation to
train the beneficiary related to the correct use and maintenance of the boiler.


The execution of the installation and the putting into service shall be made by personnel
authorized by ISCIR (according to the prescriptions PT C9/2003) observing the
requirements of the product’s technical book.
BE AWARE!

ver.2
8


While the boiler is manaully operating by wood feeding, the wood must be dry, with a
maximum humidity of 25%, and while operating automatically, the humidity of the pellets
must be of maximum 12%.


During the combustion process soot, tar and acid steam may appear. To diminish their
quantity, the boiler must operate at optimum parameters (the temperature of the heating
agent in the boiler must be of 70 - 90°C, and the temperature of the return heating agent
must be of minimum 60°C). We recommend the use of four ways valves, of thermostat
control re-circulation pumps or of heat valves TV (25, 32, 40) according to the assembling
way.


The boiler shall not be used below the no
minal capacity. In the transition period or in the
summertime (when we only need household hot water – ACM), the boiler shall be started
daily.


The boiler shall be located at the same level as the rooms to be heated or at the subsoil and
it may operate by gravitation (natural) or induced (with pump) draught.
The location of the boiler in dwelling rooms or on the access halls is forbidden.


The operating FI
-
GS boilers must be supervised.
FI-NSP boilers are manufactured from steel sheet of 5 namely 6 mm in the inside part and 4 mm at
the external part, welded, made in eleven manufacture sizes.
From the construction point of view, they are boilers with water chamber, with chamber-type
burning point and two convective circuits of burned gases.
Their construction permits the use in two operating alternatives:
1. automatic operation, being endowed with automatic burners on pellets;
2. manual feed operation, using solid fuel (wood, coal, coke, wood scrap, wood wastes) in the
burning process;
They are meant for the heating of the buildings and the production of household hot water. They
are endowed with two heat exchangers: coil producing household hot water (the range FI-15NSP –
FI-50NSP), and cooling coil – protection against the overheating (all range of powers).
It may be assembled in a gravitational operation installation or in force circulation installation
with circulation pump;
BOILER’S DESCRIPTION

ver.2
9
Each boiler has its own identification plate.
IDENTIFICATION
fig.1.

ver.2
10

Water chamber
: they are made up of two
plan-parallel walls of steel plate of 5 – 6 mm
width, namely 4 mm, located at a distance of
60 mm. The walls of the chambers are
reinforced with round steel cross-ties of Ø 10
mm welded at both ends. 

Boiler doors: allow the wood feed and the
cleaning of the pellets burner grate (the
middle one), the ash exhaust (the lower one)
and the cleaning of the convective routes (the
upper one). The door of the ash pan also plays
a part in the admission of combustion air by
means of a throttle, in the manual feeding
operation on solid fuel (wood, coal, coke,
wood scrap briquettes, wood wastes). The air
throttle is controlled by the draft
thermocontroller on the front part of the
boiler. It provides the closing of the throttle
and thus the reduction of the combustion
primary air feed when the temperature of the
water in the boiler reaches the set value.
The lateral door (the range FI - 80 NSP – FI –
150 NSP) allows the cleaning of the pellets
burner grate.
The back door represents the assembling
place of the burner on the pellets.

Convective system: as membrane walls of
pipes Ø 42 x 4.5 mm it provides two circuits
for the burnt gases, in which zigzag
turbulence nozzles are designed.

The grate: is plane, for the combustion
of the solid fuel in layer.
The ash pan: is a drawer that may be
taken out through the door in the lower part of
the boiler.

Heat insulation: it is executed of mineral
wool.
The coil for preparing household hot
water (the range FI-15NSP – FI-50NSP): is
made up of galvanized pipe of 1/2” and
inserted into the water chambers. The cold
water enters through the upper part at approx.
10°C and comes out through the lower part at
approx. 60°C.

The
cooling coil
: is made up of galvanized
pipe inserted in the water chambers; in the upper
part it is connected to the running water network
and in the lower part it is connected to the heat
valve, with an impurities filer interposing
between them. Its function is to cool the boiler in
case of overheating.
The control panel for automatic operation:
in the upper part of the boiler there is the
adjustment, safety and automation control panel
with the following component parts :
- Thermostat for controlling and adjusting the
boiler
- Safety thermostat (stops the pellets burner at
over-temperature whenever the first thermostat is
faulty – manual resetting)
- Thermo-manometer
- Led general switch
- Wire fuse 6 - 10A
The automatic pellets burner: made up of
the burner body, turboventilator, electric igniter,
control elements with programmable automaton
and photosensor.
Pellets feeding system: made up of pellets
tank (bunker), conveyor worm, engine and
reductor for the conveyor worm drive, feeding
tube, flexible tube.

Reinforcements: the following
reinforcements are located in the upper part of the
boiler:
- ½” bleeder ( 2.5 bar )
- draft thermoragulator
- airing device
- heat valve
- environmental thermostat with radiocommand
(wireless)
COMPONENT PARTS

ver.2
11
Data related to the constructive sizes of FI-GS boilers:
TECHNICAL DATA
fig.2.
fig. 3.
1. Water chamber
2. Pipes supporting the grate
3. Plane grate
4. Convective system
5. Convective floor
6. Turn connector
7. Stack connector
8. Coil for preparing household hot water (the
range FI-15NSP – FI-50NSP)
9. Cooling coil
10. Inspection (cleaning) door
11. Fuel feeding door
12. Ash pan door with combustion air admission
valve
13. Ash pan drawer
14. Steel septum
15. Pellets burner
F
I
-
NSP HOT
WATER BOILER

ver.2
12
Side view
Front view
fig. 5.
fig. 4.
TECHNICAL DATA
fig.6.
fig.7.1

ver.2
13
fig.7.2
fig.7.3
TECHNICAL DATA

ver.2
14
Boiler
Name
UM
FI
-
15NS
P
FI
-
22NS
P
FI
-
27NS
P
FI
-
33NS
P
FI
-
40NS
P
FI
-
50NS
P
Boiler width
(B)
mm
540
540 595 595 595
635
Boiler height
(H)
mm
1280
1280
1280
1280
1280
1280
Total height
(Ht)
mm
1350
1350
1350
1350
1350
1350
Boiler length
(L)
mm 740 800 850 910 960 1020
Boiler total length
(Lt)
mm
1240
1300
1350
1410
1460
1540
Diameter of the stack inlet
(Ø
D1
)
mm
146
146
146
166
166
166
Boiler’s w
eight
kg
267 285 329 355 372 410
Weight of the system
(
no
water
)
kg
387 405 449 475 492 575
Weight of the burner
kg
26.6
26.6
26.6
26.6
26.6
33.1
Maximum operating pressure
bar
2
2
2
2
2
2
Testing maximum pressure
bar
4
4
4
4
4
4
Rated heat power on wood
Kcal/h
(kW)
15.000
17,4
22.000
25,6
27.000
31,4
33.000
38,4
40.000
46,5
50.000
58
Rated heat power on pellets
Kcal/h
(kW)
12.9
00
15
18.9
00
22
23.2
00
26,9
28.4
00
33
34.4
00
40
43.0
00
50
Efficiency
–
operation on wood
%
78
-
80
78
-
80
78
-
80
78
-
80
78
-
80
78
-
80
Efficiency
–
operation on pellets
%
85
-
90
85
-
90
85
-
90
85
-
90
85
-
90
85
-
90
Nomi
nal consumption of wood with
H
i
=
3500 kcal/kg Kg/h 5,5 8,06 9,9 12,1 14,7 18,3
Nominal consumption of pellets with
H
i
=
4150 kcal/kg Kg/h 2,59 3,8 4,7 5,7 6,9 8,6
Thermo
-
manometer inlet
(RTM)
ţoli
¼” int ¼” int ¼” int ¼” int ¼” int ¼” int
Aerator inlet
(A)
ţoli
½” int.
½” int.
½” int.
½” int.
½” int.
½” int.
Bleeder
inlet
(SS)
ţoli
½” ext
½” ext.
½” ext.
½” ext.
½” ext.
½” ext.
Turn (one way)
inlet
(RT)
ţoli
1½” ext
1½” ext
1½” ext
1½” ext
1½” ext
1½” ext
Return (two ways)
inlet
(RR)
ţoli
1½” ext
1½” ext
1½” ext
1½” ext
1½” ext
1½” ext
Draft
controller
inlet
(RRT)
ţoli
¾” int ¾” int ¾” int ¾” int ¾” int ¾” int
Cool water / household hot water inlet
(AR /
ACM) ţoli ½” ext ½” ext. ½” ext. ½” ext. ½” ext. ½” ext.
Cooling coil inlet
(ARR/RST)
ţoli
¾” ext
¾” ext
¾” ext
¾” ext
¾” ext
¾” ext
Heat valve probe inlet
(S)
ţoli
½” int.
½” int.
½” int.
½” int.
½” int.
½” int.
Boiler emptying inlet
(RG)
ţoli
½” int.
½” int.
½” int.
½” int.
½” int.
½”
int.
Necessary stack draft
mbar
0,2 – 0,3 0,2 – 0,3 0,2 – 0,3 0,2 – 0,3 0,2 – 0,3 0,2 – 0,3
Water content in the boiler
L
94 103 109 137 146 162
Temperature of the burn gases
°C
180-250 180-250 180-250 180-250 180-250 180-250
Maximum operating tempera
ture
°C
90
90
90
90
90
90
Recommended operating temperature
°C
70
-
90
70
-
90
70
-
90
70
-
90
70
-
90
70
-
90
Household hot water flow
(
∆t=30°C)
l/min
9
9
9
12
12
12
Consumed electric power at ignition
W
720 720 720 720 720 720
Consumed electric power while operating
W
120 120 120 120 120 120

ver.2
15
Boiler
Supply voltage / frequency
V/Hz
220 / 50
220 / 50
220 / 50
220 / 50
220 / 50
220 / 50
B
oiler
Name
UM
FI
-
60NS
P
FI
-
80NS
P
FI
-
100NS
P
FI
-
130NS
P
FI
-
150NS
P
Boiler width
(B)
mm
700
725
800
935
935
Boiler height
(H)
mm
1280
1280
1395
1395
1395
Total height
(Ht)
mm
1350
1350
1465
1465
1465
Boiler length
(L)
mm
1130
1380 1490 1530 1680
Boiler total length
(Lt)
mm
1650
1900
2150 2190 2340
Diameter of the stack inlet
(ØD1)
mm
196
196
216
246
246
Weight
of the boiler
kg
471
607
732
896
975
Weight of the system
(no water)
kg
636
773
911
1075
1154
Weight of the burner
kg
33.1
33.1
46.9
46.
9
46.9
Maximum operating pressure
bar
2
2
2
2
2
Testing maximum pressure
bar
4
4
4
4
4
Rated heat power on wood
Kcal/h
(kW) 60.000
69,6 80.000 93 100.000 116 130.000 150,8 150.000 174
Rated heat power on pellets
Kcal/h
(kW)
51.6
00
59,9
67.6
00
78,5
84.3
00
98
110.0
00
127,9
127.0
00
147,5
Efficiency
–
operation on wood
%
78
-
80
78
-
80
78
-
80
78
-
80
78
-
80
Efficiency
–
operation on pellets
%
85
-
90
85
-
90
85
-
90
85
-
90
85
-
90
Nominal consumption of wood with H
i
= 3500
kcal/kg Kg/h 22 29,3 36,6 47,6 55
Nomina
l consumption of pellets with H
i
= 4150
kcal/kg Kg/h 10,4 17,5 21,9 28,4 32,8
Manometer connector
(M)
ţoli
¼” int ¼” int ¼” int ¼” int ¼” int
Aerator inlet
(A)
ţoli
½” int. ½” int. ½” int. ½” int. ½” int.
Bleeder
inlet
(SS)
ţoli
¾” ext 1” ext 1” ext 1” ext 1” ext
One way inlet
(RT)
ţoli
1½” ext
2” ext
2” ext
2½” ext
2½” ext
Two
-
way inlet
(RR)
ţoli
1½” ext
2” ext 2” ext
2½” ext
2½” ext
Draft
controller
inlet
(RRT)
ţoli
¾” int ¾” int ¾” int ¾” int ¾” int
Cool water / household hot water inlet
(AR /
ACM) ţoli - - - - -
Cooling coil inlet
(ARR/RST)
ţoli
¾” ext ¾” ext ¾” ext ¾” ext ¾” ext
Heat valve probe inlet
(S)
ţoli
½” int. ½” int. ½” int. ½” int. ½” int.
Boiler emptying inlet
(RG)
ţoli
½” int. ½” int. ½” int. ½” int. ½” int.
Necessary stack draft
m
bar
0,3 – 0,4 0,3 – 0,4 0,3 – 0,4 0,3 – 0,4 0,3 – 0,4
Water content in the boiler
L
191
238
296
325
359
Temperature of the burn gases
°C
180-250 180-250 180-250 180-250 180-250
Maximum operating temperature
°C
90
90
90
90
90
Recommended operating tempe
rature
°C
70
-
90
70
-
90
70
-
90
70
-
90
70
-
90
TECHNICAL DATA

ver.2
16
B
oiler
Consumed electric power at ignition
W
935 985 985 985 985
Consumed electric power while operating
W
335 385 385 385 385
Supply voltage / frequency
V/Hz
220 / 50
220 / 50
220 / 50
220 / 50
220 / 50
Data related to the constructive sizes of the feeding system:
Name UM
Boiler
FI
-
15NSP
–
FI40
-
NSP
FI
-
50NSP
–
FI
-
150NSP
Lenght
(A)
mm
1100
1500
Width
(B)
mm
760
830
Height
(C)
mm
1460
1730
Volume of the pellets
tank L 500 850
TECHNICAL DATA
fig.8.
1. Body of the boiler
2. Supply system
3. Pellets tank provi
ded with
a cleaning door (4)

ver.2
17
Data related to the constructive sizes of the pellets burner:
Burner model Min-max power
Kw
Electrical supply Fan
W
Pellets consumption at
rated power with
Hi=4150 kcal/kg
Kg/h
V Hz
27
10
-
32
220
50
80
2,08
–
6,65
40
25
-
48
220
50
80
5,19
–
9,97
60
35
-
70
220
50
80
7,27
–
14,54
80
45
-
95
220
50
135
9,35
–
19,73
150
90
-
180
220
50
135
18,7
–
37,4
TECHNICAL DATA
COMPONENT PARTS
1. Conveyor worm
2. Pellets feeding pipe
3. Conveyor worm driving engine and
reductor
4. Flexible tube
5. Turboventilator
6. Body of the burner
7. Grate of the burner
8. Electric igniter
9. Thermocouple
10. Programmable automaton – control
block
fig.9.
fig.10.

ver.2
18
Accessories delivered with FI-NSP boiler
- Fire iron, brush and scraper
(basic package)
Control panel
(basic package)
- Ash pan drawer
(basic package)
Burner on pellets
(basic package)

- Steel baffles
(basic package)
The pellets feeding system
(basic package)

- Household hot water coil
(basic package for the range
FI-15NSP – FI-50NSP)
- Bleeder (2.5 bars)
(basic package)

- Environmental thermostat with
radio control (wireless) (basic
package)
- Aerator
(basic package)


- Assembling, use and
maintenance instructions
(basic package)
Accessories recommended as mandatory

- Open expansion tank Or - Closed expansion tank
Burner
model
A
[mm]
B
[mm]
C
[mm]
D
[mm]
E
[mm]
F
[mm]
G
[mm]
H
[mm]
I
[mm]
J
[mm]
L
[mm]
Ht
[mm]
27 300 290 345 240 220 228 60 171 185 320 750 530
40 300 290 345 240 220 228 60 171 185 320 750 530
60 295 340 395 240 280 228 60 182 252 320 830 535
80 295 340 395 240 280 228 60 182 252 320 830 535
150 360 400 450 300 360 216 60 230 308 400 1050 575
ACCESSORIES

ver.2
19
- 4 ways valve or
Heat mixing valve
TV 60ºC(25, 32, 40)-return
TV 72ºC(25, 32, 40)-turn
- Heat valve
STS 20 or TS 130- ¾”
-Circulation/
recirculation pump
Chapter 1
ASSEMBLING INSTRUCTIONS
This chapter addresses both to authorized persons proceeding to assembling the boiler, as well
as to the beneficiary who is interested in the executed works complying with the safety norms while
using all the elements contributing to the installation’s good operation.
The boiler may be assembled by companies or by ISCIR authorized personnel. The assembling
shall be executed on the grounds of a project, complying with the norms in force and with the boiler’s
technical book.
 Attention! If the boiler is not be assembled, store it in a dry place.
1.1. Choosing the boiler
The boiler must be chosen so that the rated power corresponds the heat losses and the heat
necessary according to STAS 1907, essential requirement for the accurate and economic operation.
Choosing a boiler with greater rated power shall result in tar deposits on its inside walls.
1.2. Location and position of the boiler
The boiler shall be assembled only in the heat power plants executed compliant with a project drafted by
specialized institutions, observing the safety measures stipulated in STAS 7132-86; STAS 3417-85 ; Norm I 13-
94; Norm I 13/1-96; PT C 9-2003; PT A2-2003; ISCIR collection; GP 051-2000; P 118-99.
The boiler shall be assembled in a separate room at the subsoil, basement or ground floor of the
civil or industrial buildings, except for those included in the A and B classes of inflammation or
explosion danger. As well, it is forbidden to assemble the boilers directly under rooms where
personnel cannot self-evacuate (such as the hospitals), under showrooms, stores, kindergartens or
under their access ways.
ASSEMBLING
LOCATION
The boilers room must be separate
from the adjacent rooms and have
sufficient windows. The room where
the boiler shall be assembled must be
large enough to allow the boiler
assembling on a perfectly even
surface. (Eventually on a metallic or
concrete base) respecting the
distances according to fig. 11. The
boiler shall not be assembled on
flammable material support. The
room must have a fresh air access
hole, with an opening of 400 cm2–
permanently open to the outside. We
recommend a siphon trap assembled
and drinking water pipes with
enough pressure to fill in the heat
plant installation.

ver.2
20



 Attention! Locating the boiler in dwelling rooms and on the access halls is forbidden!
1.3. Assembling the boiler’s components
The boiler is delivered completely assembled and equipped. If you encounter problems when
moving it to its operating place, the components may be disassembled as it follows, according to
blueprint in fig. 12. When disassembling it, start by removing the cover. Then remove the lateral
covers by unscrewing the M6stud bolts located two in the upper part and two in the lower lateral part.
If necessary, you my also disassemble the back cover by unscrewing the M6stud bolts, then the three
smaller components (between doors) shall be removed if you unscrew the stud bolts M6.
When the boiler is located where it is meant to operate, before assembling it, we proceed to its
dressing up. The component parts shall be assembled according to the blueprint in fig.12. The
assembling starts by fixing the back cover by means of the M6 stud bolts. Then, the three smaller
components (between doors) shall be fixed using the M6 stud bolts. Then, the two lateral covers shall
be fixed using the stud bolts M6, two in the upper part and two in the lower lateral part. When
assembling the top cover, the probes and the inlets of the control device shall the inserted in the
corresponding case and in the coupling inlet ¼”.
1.4. Assembling of the pellets burner and of the feed system
ASSEMBLING
fig.
12.
fig.
11.
ASSEMBLING
fig.13.
