Tesla WF81490MS User manual

Product images are for illustrative purposes only and may differ from the actual product.
WASHING
MACHINE
WF81490MS
User Manual
BG ROHUGR SLO SRBENG BiH/
CG

2
ENG
SAFETY INSTRUCTIONS
Please read the following safety information thoroughly and follow it strictly to minimize the risk of fire or
explosion, electric shock and to prevent property damage, personal injury or loss of life. Failing to follow
these instructions shall void any warranty.
WARNING!
This combination of symbol and signal word indicates a potentially dangerous situation which may result in
death or serious injuries unless it’s avoided.
CAUTION!
This combination of symbol and signal word indicates a potentially dangerous situation which may result in
slight or minor injuries or damage to property and the environment.
NOTE
This combination of symbol and signal word indicates a potentially dangerous situation which may result in
slight or minor injuries.
WARNING!
The electric shock!
• If the supply cord is damaged, it must be replaced by the manufacturer its service agent or similarly
qualified persons in order to avoid a hazard.
• If the machine is damaged, it must not be operated unless repaired by the manufacturer, its service agent
or similarly qualified persons. Risk of electric shock!
• The appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user maintenance shall not be made by children without
supervision.
• Children should be supervised that they do not play with the appliance.
• Children 3 years and under shall be kept away from the appliance or continuously supervised.
• Animals and children may climb into the machine. Check the machine before every operation.
• Do not climb or sit on the appliance.
Installation location and surrounding
• All washing and additional substances are to be kept in a safe place out of the reach of children.
• Do not install the machine on a carpet floor. The obstruction of the openings by a carpet can damage the
machine.
• Keep the appliance clear from heating sources and direct sunlight to avoid plastic and rubber parts to
corrode.
• Do not use the appliance in humid environments or rooms containing explosive or caustic gas. In case of
water leakage or water splashes let the appliance dry in the open air.
• The appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the
opposite side to that of the washing machine.
• Do not operate the machine in rooms with a temperature of below 5°C. This can cause damages to parts
of it. If it is unavoidable, make sure to drain the water completely from the appliance after every use (see
„Maintenance - Cleaning of drain pump filter“) to avoid damages caused by frost.
• Never use flammable sprays or substances in the immediate proximity of the appliance.
Installation
• Remove all packaging material and transport bolts before using the appliance. Otherwise, serious damage
may result.
• This appliance is equipped with a single inlet valve and can be connected to the cold water supply only.

3
ENG
• Mains plug must be accessible after installation.
• Before washing clothes for the first time, the product shall be operated once throughout all the
procedures without any clothes inside.
• Before using the washing machine, the product shall be calibrated.
• Do not put any excessively heavy objects on the appliance, like water containers or heating devices.
• The new hose-sets supplied with the appliance are to be used and that old hose-sets should not be reused.
• Max. Inlet water pressure 1 MPa. Min. inlet water pressure 0.05 MPa.
Electrical connection
• Make sure the supply cable is not trapped by the machine, it can get damaged.
• Connect the product to a grounded outlet protected by a fuse complying with the values in the “ Technical
specifications“ table. The grounding installation has to be made by a qualified electrician. Ensure that the
machine is installed in accordance with the local regulations.
• Water and electrical connections must be carried out by a qualified technician in accordance with the
manufacturer‘s instructions and local safety regulations.
WARNING!
• Don´t use multiple plugs or extension cords.
• The appliance must not have an external switching device such as a timer or connected to a circuit that is
regularly switched on and off.
• Do not pull the plug out of the mains outlet if there is flammable gas around.
• Never pull out power plug with wet hands.
• Always pull at the plug, not at the cable.
• Always unplug the appliance if it is not being used.
Water connections
• Check the connections of the water inlet tubes, the water tap and the outlet hose for possible problems
due to changes of water pressure. If the connections loosen or leak close the water tap and get it repaired.
Do not use the appliance before the pipes and hoses are installed properly by qualified persons.
• Glass door may become very hot during the operation. Keep children and pets far away from the machine
while it is operating.
• The water inlet and outlet hoses have to be safely installed and remain undamaged. Otherwise, water
leakage can occur.
• Do not remove the drain pump filter while there is still water in the appliance. Big quantities of water can
leak out, and there is a risk of scalding due to hot water.
Operation and maintenance
• Never use any flammable, explosive or toxic solvents. Do not use gasoline and alcohol etc. as detergents.
Only select detergents that are suitable for machine washing.
• Make sure that all pockets are emptied. Sharp and rigid items such as coins, brooches, nails, screws, stones
etc. may cause serious damages to this machine.
• Remove all objects from pockets such as lighters and matches before use the appliance.
• Thoroughly rinse items that have been washed by hand.
• Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, wax and wax removers should be washed in hot with an extra amount of detergent
before being dried in the appliance.
• Items containing foam rubber (latex foam), shower caps, water proof textiles, rubber backed articles and
clothes or pillows fitted with foam rubber pads should not be dried in the machine
• Fabric softeners or similar products should be used as recommended in their instructions.
• Never try to open the door forcefully. The door will unlock shortly after the end of a cycle.
• Please do not close the door with excessive force. If it is found difficult to close the door, please check if
the clothes are properly inserted and distributed.
• Always unplug the appliance and close the water tap before cleaningand maintenance and after each use.
• Never pour water over the appliance for cleaning purpose. Risk of electric shock!
• Repairs shall only be carried out by the manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard. The producer will not be responsible for damages caused by the intervention of
not authorized persons.

4
ENG
Transport
• Before Transport:
- Bolts shall be reinstalled to the machine by a specialized person
- Accumulated water shall be drained out of the machine
• This appliance is heavy. Transport with care. Never hold any protruding part of the machine when lifting.
The machine door cannot be used as a handle.
INTENDED USE
The product is intended only for home use and for textiles in household amounts suitable for machine
washing and drying. This appliance is for indoor use only and not intended for built in use. Only use
according to these instructions. The appliance is not intended for commercial use. Any other use is
considered as improper use. The producer is not responsible for any damage or injuries that may result of it.
• This appliance is intended to be used in household and similar applications such as:
-Staff kitchen areas in shops, offices and other working environments;
-Farm houses;
-By clients in hotels, motels and other residential type environments;
-Bed and breakfast type environments;
-Areas for communal use in blocks of flats or in launderettes.

5
ENG
INSTALLATION
Product Description
Accessories
NOTE
The product line chart is for reference only, please refer to real product as standard.
Transport hole plug Supply hose
cold water
Owner’s manual
Installation area
WARNING!
• Stability is important to prevent the product from wandering! Make sure the machine
is standing leveled and stable.
• Make sure that the product does not stand onto the power cord.
• Make sure to maintain the minimum distances from the walls as shown in the picture
w
w
W>20mm
Top cover
Water supply hose
Detergent dispenser
Door
Control panel
Power supply cord
Drain hose
Service filter
Drum

6
ENG
Unpacking the washing machine
WARNING!
• Packaging material (e.g. Films, Styrofoam) can be dangerous for children.
• There is a risk of suffocation! Keep all packaging well away from children.
1. Remove the cardboard box and styrofoam packing.
2. Lift the washing machine and remove the base packing. Make sure the small triangle foam is removed
with the bottom one together. If not, lay the unit down with side surface, then remove the small foam
from the unit bottom manually.
3. Remove the tape securing the power supply cord and drain hose.
4. Remove the inlet hose from the drum.
Remove transport bolts
Before installing the machine, the location characterized as follows shall be selected:
1. Rigid, dry, and level surface
2. Avoid direct sunlight
3. Sufficient ventilation
4. Room temperature is above 0°C
5. Keep far away from the heat sources such as coal or gas burning appliances.
WARNING! You must remove the transport bolts from the backside before using the product.
Loosen the 4 transport bolts
with a spanner
Remove the bolts including the
rubber parts and keep them for
future use.
Close the holes using transport
hole plugs
Levelling the washing machine
The lock nuts on all four feet must be screwed tightly against the housing.
1. Loosen the lock nut.
2. Turn the foot until it reaches the floor.
3. Adjust the legs and lock the nuts with a spanner. Make
sure the machine is level and steady.
WARNING!

7
ENG
• To prevent leakage or water damage, follow the instructions in this chapter!
• Do not kink, crush, modify or sever water inlet hose.
Connect manually, do not use tools. Check if the connections are tight.
WARNING!
Connect Water Supply Hose
Connect the water supply hose to the
water inlet valve and a water tap with cold
water as indicated.
NOTE
There are two ways to place the end of drain hose:
Drain Hose
WARNING! • Do not kink or protract the drain hose.
• Position drain hose properly ,otherwise damage might result of water leakage.
1.Put it into the water trough. 2. Connect it to the branch drain pipe of the
trough.
Water trough
CAUTION!
• Before washing, please make sure it’s installed properly.
• Your appliance was thoroughly checked before it left the factory. To remove any residual water and to
neutralize potential odors, it’s recommended to clean your appliance before first use. For this reason, start
the Cotton program at 90°C without laundry and detergent.
OPERATIONS
Quick Start
It’s recommended to calibrate the washing machine, so that provide the best performance.
The appliance is able to detect the amount of laundry loaded. This function is optimizing the product
performance by minimizing energy and water consumption, saving you money and time. For this reason it’s
recommended to calibrate the appliance for best use.
1. Remove all accessories from the drum and close the door;
2. Insert the mains plug to the socket;
3. Switch on the washing machine and press “Delay” and “Temp.” simultaneously for 10 seconds until “t19”
is displayed;
4. Press start the appliance and wait till “****” is displayed.
CALIBRATION

8
ENG
1. Before Washing
Detergent need to be added in compartment I if the pre-wash function is selected.
Power On Select function or remain
default settings
Select program Start up
3. After Washing
Buzzer beep or “End” on display.
• The ambient temperature of the washing machine should be 5-40°C. If used under 0°C, the inlet valve
and draining system may be damaged. If the machine is installed under freezing conditions, it should be
transferred to normal ambient temperature to ensure the water supply hose and drain hose can unfreeze
before use.
• Please check your laundry care labels and the detergent use instructions before wash. Use non-foaming or
less-foaming detergent suitable for machine washing properly.
Before Each Washing
Check the care label
Tie together long textile strips
and belts, close zips and
button
Sort laundry according to color and textile
type
Put small items into a laundry bag
Take all items out of the pockets
Turn easy-pilling and long-pile fabric
inside out
Plug in Open tap Load Close door Add detergent
Main
wash
Softener
Prewash
earth
terminal
NOTE
2. Washing

9
ENG
WARNING!
• Do not wash or dry articles that have been cleaned in, washed in, soaked in, or dabbed with combustible or
explosive substances like wax, oil, paint, gasoline, alcohol, kerosene, and other flammable materials.
• Washing single clothes items may easily create big eccentricity and cause alarm due to unbalance.
Therefore it is suggested to add one or two more laundry items to the wash so that spin can be done
smoothly.
Prewash detergent
Main wash detergent
Softener
Release button to pull out
the dispenser
Detergent Dispenser
CAUTION!
Detergent only need to be added in “compartment I “after
selecting pre-wash function.
Means must Means optional
Program
Cotton
Synthetic
Mix
Bed Linen
Baby Care
20ºC
Drum Clean
Program
Spin Only
Rinse & Spin
Wool
ECO 40-60
Sterilization
Quick 15’
Detergent Recommendation
Recommended
washing detergent Wash cycles Washing
temp. Type of laundry and textile
Heavy-duty detergent
with bleaching agents and
optical brighteners
Cotton, ECO
40-60, Mix,
Bed Linen
20/30/40/60 White laundry made from boil-
proof cotton or linen
Colour detergent without
bleaching agent and optical
brighteners
Cotton, Mix,
Bed Linen Cold/20/30/40 Coloured laundry made from cotton or linen
Color or mild detergent
without optical brighteners 20ºC, Synthetic 20 Coloured laundry made from easy care fibres or synetheic materials
Mild washing detergent Synthetic 20/30 Delicate textiles, silk, viscose
Special wool detergent Wool 20/30 Wool

10
ENG
Control Panel
NOTE
• Agglomerating or ropy detergent or additive can be diluted in some water before pouring it into the
detergent dispenser, to avoid its inlet to get blocked and thus cause a water overflow.
• Please choose the suitable type of detergent to get a maximum of washing performance and a minimum
of water and energy consumption
• To achieve the best cleaning result a proper detergent dosing is important.
• Use a reduced detergent amount if the drum is not filled completely.
• Always adjust the amount of detergent to the water hardness, if your tap water is soft, use less detergent.
• Dose according to how dirty your laundry is, less dirty clothes require less detergent.
• Highly concentrated (compact detergent) requires particularly accurate dosing.
Following symptoms are a sign of detergent overdosing:
- heavy foam formation
- poor washing and rinsing result
Following symptoms are a sign of detergent underdosing:
- laundry turns grey
- built-up of limescale deposits on the drum, the heating element and/or the laundry
1. Power
Product is on/off.
2. Start/Pause
Press the button to start or pause the washing
cycle.
3. Option
This allows you to select an additional function
and will light when selected.
4. Programmes
Available according to the laundry type.
5. Display
The display shows the settings, estimated
time remaining, options, and status messages
for your washer. The display will remain on
through the cycle.

11
ENG
ADisplay
Wash Time
Speed
End
Delay Time
Error
Temp.
BPre Wash CDoor Lock
DChild Lock EDelay
FSpeed Wash GNight Wash
HExtra Rinse ISteam Care
JPre Wash-Wash-Rinse-Spin
Programs
Program Load(kg) Default Time
Cotton 8.0 3:39
Synthetic 4.0 3:18
Mix 8.0 1:20
Bed Linen 8.0 1:48
Baby Care 8.0 1:42
20°C 4.0 1:01
Drum Clean −1:18
Spin Only 8.0 0:12
Rinse&Spin 8.0 0:20
Wool 2.0 1:07
ECO 40-60 8.0 3:38
Sterilization 4.0 2:27
Quick 15’ 2.0 0:15
The parameters in this table are only for user’s reference. The actual parameters maybe
different with the parameters in above mentioned table.
NOTE

12
ENG
Cycle
Nominal capacity in
kg
Temperature
setting
Cycle duration in
h:min
Energy consumption
in KWh/cycle
Water consumption in
L/cycie
Highest washing
temperature °C 1)
Residual moisture in
% / Spin speed in
rpm 2)
20°C 4.0 20 1:01 0.183 44 20 65% / 1000
Cotton 60°C 8.0 60 3:44 1.719 71 60 70% / 800
MIX 8.0 40 1:20 0.754 71 40 70% / 800
Quick 15’ 2.0 Cold 0:15 0.030 31 Cold 75% / 800
Bed Linen 8.0 40 1:48 0.803 71 40 65% / 1000
ECO 40-60 3)
8.0 -3:38 0.854 59 39 53% / 1350
4.0 -2:48 0.524 46 32 53% / 1350
2.0 -2:48 0.228 37 22 53% / 1350
• The above data is for reference only, and the data may change due to different actual use conditions.
• The valves given for programmes other than the ECO 40-60 programme are indicative only.
• Concerning to EN 60456:2016+A11:2020 With(EU) 2019/2014, (EU) 2019/2023, (EU) 2021/340, (EU)
2021/341,
The EU energy efficiency class is: B
Energy test program: ECO 40-60. Other as the default.
Half load for 8.0kg machine:4.0kg.
Quarter load for 8.0kg machine:2.0kg.
Programs
Programs are available according to the laundry type.
Programs
Cotton Hard-wearing textiles, heat-resistant textiles made of cotton or linen.
Synthetic Wash synthetic articles, for example: shirts, coats, blending.
While washing the knitting textiles, detergent quantity shall be reduced due to its loose
string construction and easily forming bubbles.
Baby Care Washing the baby’s clothes, it can make the baby’s wear cleaner and make the rinse
performance better to protect the baby skin.
Mix Mixed load consisting of textiles made of cotton and synthetics.
Bed Linen This program is specially designed for washing duvet coats.
20°C 20°C default, can choose cold water.
ECO 40-60 Default 40°C,not selectable,suitabale for laundry washing at
about 40°C-60°C.
Quick 15' Extra short programme approx, suitable for lightly soiled washing as a small amounts
of laundry.
Sterilization Keep the washing temperature above 60 degrees for more than 30 minutes, effectively
remove harmful bacteria.

13
ENG
Wool Hand or machine-washable wool or richwool textiles.Especially
gentle wash programme to prevent shrinkage, longer programme pauses (textiles rest
in wash liquor).
Spin Only Extra spin with selectable spin speed.
Rinse&Spin Extra rinse with spin
Drum Clean Specially set in this machine to clean the drum and tube. It applys 90 °C high
temperature sterilization to make the clothes washing more green. When this
programme is performed, the clothes or otherwashing cannot be added. When proper
amount of chlorine bleaching agent is put in, the barrel cleaning effect will be better.
The customer can use this programme regularly according to the need.
If there is any break in the power supply while the machine is operating, a special memory stores the selected
programme.The machine will continue the programme when the power supply is re-established.
CAUTION!
1) The highest temperature reached by the laundry in the wash cycle for at least 5 minutes.
2)
Residual moisture after the wash cycle in water content percent and the spin speed at which this was
achieved.
3) The ECO 40-60 programme is able to clean normally soiled cotton laundry declared to be washable at 40°C
or 60°C, together in the same cycle.This programme is used to assess the compliance with the regulation
(EU) 2019/2014, (EU) 2019/2023, (EU)2021/340, (EU) 2021/341
The most efficient programmes in terms of energy consumption are generally those that perform at lower
temperatures and longer duration.
Loading the household washer up to the capacity indicated for the respective programmes will contribute to
energy and water savings.
Noise and remaining moisture content are influenced by the spinning speed: the higher the spinning speed
in the spinning phase, the higher the noise and the lower the remaining moisture content.
Option
Cycle Default
Temp. (°C)
Default spin
speed in rpm Additional Functions
Wash cycles 1400
Cotton 40 800 , , , , ,
Synthetic 40 800 , , , ,
Mix 40 800 , , , , ,
Bed Linen 40 1000 , , , , ,
Baby Care 60 1000 , , , , ,
20°C 20 1000 , , ,
Drum Clean 90 -- ,
Spin Only -- 1000 ,
Rinse&Spin -- 1000 , ,

14
ENG
Cycle Default
Temp. (°C)
Default spin
speed in rpm Additional Functions
Wool 40 600 , ,
ECO 40-60 -- 1400
Sterilization 70 800 , ,
Quick 15’ -- 800 ,
• For the maximum spin speed, program time, and other details of the ECO 40-60 program, please refer to
the content on the Product Fiche page.
• If an adjustment is not possible for a cycle, the table shows which cycle offers which options for
adjustment.
NOTE
Speed Speed
When needed, the spinning speed can be adjusted pressing the Speed button in the
following steps: 1400: 0-400-600-800-1000-1200-1400
Delay
Set the Delay function:
1. Select a program
2. Press the Delay button to choose the time(the delaying time is 0-24 H.)
3. Press [Start/Pause] to start the delay operation
To cancel the Delay function, press the “Delay” button before starting the program until the display
shows 0 h. If the program has already started, switch the appliance off and afterwards on and select
a new programme.
Choose the Program Setting time Start
Delay
Pre Wash
Extra washing function before the main washing cycle starts to increase the washing performance.
Note: Detergent needs to be added to the compartment I.
Extra Rinse
The laundry will undergo an extra rinse after selecting this function.
Soil Level
The washing time will increase or decrease after you select it.
Speed Wash
The function can decrease the washing time.
My Cycle
To memory the frequently used programme.
After choosing the programme and setting the options, press [Spin] 3 sec. before start to wash.The
default setting course is Cotton.
Steam Care
Steam Care function can be selected by choose “Cotton”,“Mix“”Bed Linen” and “Baby Care”.
The customers can see the steam in the drum when operate Steam Care function.

15
ENG
Night Wash
If selected spinspeed is more than 800rpm , then change to 800rpm,meanwhile cancel the button
sound.
Child Lock
This function is meant to keep children from misusing the controls.
Mute the buzzer
Reload
Press [Spin] and [Function] simultaneously for 3 sec until the
buzzer beep. The child lock indicator switches on.
When the Child Lock is activated, the display will alternately show “CL” and the remaining time.
Pressing any other button will cause the Child Lock indicator to flash for 3 sec.
When the program ends, “CL” and “END” will alternate on the display for 10 sec, then the indicator
will flash for 3 sec.
The Child Lock deactivates the function of all buttons except the On/Off button and the Child lock
button! Only the simultaneous pressing of the two buttons [Spin] and [Function] can deactivate the
Child Lock! Please deactivate the Child Lock before selecting a new program!
This operation can be executed during the washing progress. When the drum is still rolling and
there is large amount of water with high temperature in the drum.
The state is unsafe and the door cannot be opened forcefully.To press [Start/Pause] for 3 sec. to
reload, and start the clothes adding in the midway function. Please follow the steps as bellow:
1. Wait until the drum stops rotation.
2. The door lock is unlocked.
3. Close the door when the clothes are reloaded and press the [ ] button.
After Muting the buzzer function, the sounds will not be activated any more.
Don’t use the Reload function when the water level over the edge of the
inner tub or the temperature is higher.
CAUTION!
CAUTION!
CAUTION!
Choose the Programme
To act the buzzer function, press the button again for 3 seconds. The setting will be kept until the
next reset.
Press the [Temp.] button for 3sec., the buzzer is mute.
Clothes
Press [ ] 3sec. Reload the clothes Start

16
ENG
1. Close the tap and remove the water supply hose
from it.
2. Clean the filter with a brush.
3. Unscrew the water supply hose from the backside
of the machine. Pull out the filter with long nose
pliers.
4. Use a brush to clean the filter.
5. Reinstall the filter to the water inlet and reconnect
the water supply hose.
6. Clean the Inlet filter every 3 months to ensure the
normal operation of the appliance.
Cleaning The Inlet Filter
Diminishing water flow is a sign that the filter need to be cleaned.
Cleaning The Cabinet
Proper maintenance on the washing machine can extend its working life. The
surface can be cleaned with diluted non-abrasive neutral detergents when
necessary. If there is any water overflow, use a cloth to wipe it off immediately.
Never use sharp items to clean the appliance.
Cleaning The Drum
Any rust stains left inside the drum by metal articles must be removed immediately using chlorine-free
detergents. Never use steel wool for cleaning the drum!
Cleaning the Door Seal and Glass
Wipe the glass and seal after each wash to remove lint and stains. If
lint builds up it can cause leakages. Remove any coins, buttons and
other objects from the seal after each wash. Clean the Door Seal and
Glass every month to ensure the normal operation of the appliance.
MAINTENANCES
Cleaning And Care
Always unplug the appliance and close the water tap before cleaning and
maintenance.
WARNING!
Never use abrasive or caustic agents. formic acids or
its diluted solvents or similar substances, like alcohol or
chemical products.
Keep any laundry away from the machine while cleaning the drum.
CAUTION!
NOTE
NOTE
d.
1
3
2
4

17
ENG
When the appliance is in
use and depending on the
programme selected there
can be hot water in the
pump. Never remove the
pump cover during a wash
cycle, always wait until the
appliance has finished the
cycle, and is empty. When
replacing the cover, ensure it
is securely re-tightened.
CAUTION!
Clean The Detergent Dispenser
1. Press down the release [ ] on the softener cover and pull the dispenser drawer out of the recess. Clean
the inside of the recess with a brush.
2. Lift the softener cover off the dispenser drawer and wash both items with water.
3. Restore the softener cover and push the drawer back into the recess.
Press the release and
remove the dispenser
drawer
Clean the dispenser
drawer and the softener
cover under water
Clean the recess with an
soft brush
Insert the dispenser
drawer
NOTE
• Do not use abrasive or caustic agents to clean plastic parts.
• Clean the detergent dispenser every 3 months to ensure the normal operation of the appliance.
Cleaning The Drain Pump Filter
WARNING!
• Make sure that the machine has finished the washing cycle and is empty. Switch it off and unplug it before
cleaning the drain pump filter.
• Be careful of hot water. Allow the water to cool down. Risk of scalding!
• Clean the filter periodically every 3 months to ensure the normal operation of the appliance.
Open the lower cover cap
Remove extraneous matter
Open the filter by turning
to the counter clockwise
Close the lower cover cap

18
ENG
Description Possible cause Solution
Appliance does not start Door is not closed properly
Clothes are stuck.
Close the door properly and restart.
Check the laundry.
Door can’t be opened Safety protection is
activated. Disconnect the power, restart the product
Water leakage Connections are not tight
enough.
Check and fasten the water inlet pipe.
Check and clean the outlet hose.
Detergent residues in the
detergent dispenser
Detergent is damp and/or
clotted. Clean and wipe the detergent dispenser dry.
Indicator or display does
not work
PC board or harness have
connection problems.
Switch off the power and check if the mains
plug is connected properly.
Abnormal noise Fixing bolts still in place.
Floor is not solid or level.
Check if the fixing bolts have been removed
Make sure the appliance is installed on a solid
and level floor.
Troubleshooting
Whenever there is a problem with the appliance, check if you can solve it following
the tables below. If the problem persists, please contact the customer service.
Error Codes
Description Reason Solution
Door is not closed properly Close the door properly and restart.
Water injecting problem
during wash cycle.
Check if the water pressure is high enough.
Straighten the water pipe.
Clean the inlet valve filter.
Overtime water draining Check the drain hose for blockage.
Water overflow Restart the appliance.
Others Restart the appliance. If problem persists,
please contact the customer service

19
ENG
Technical Specifications
MAX. Current 10A
Standard Water Pressure 0.05MPa~1MPa
D
W
H
Power Supply 220-240V~,50Hz
Washing Capacity 8.0kg
Dimension (WxDxH) 595x565x850
Weight 68kg
Rated Power 2000W
Customer service
Transport
IMPORTANT STEPS WHEN MOVING THE APPLIANCE
Spare part for your appliance are available for a minimum of 10 years.
In case of questions please contact our customer service at:
Risk of electric shock
• Never try repair an appliance which is defective of presumed to be defective.
You may put your own and future users’ lives in danger.Only authorised specialists are allowed to carry out
this repair work.
• Improper repair will void the warranty and subsequent damages can’t be recogniced!
• Unplug the appliance and close the water inlet tap.
• Check, if the door and the detergent dispenser are closed properly.
• Remove the water inlet pipe and the outlet hose from the house installations.
• Let the water drain completely from the appliance (see “Maintenance Cleaning the drain pump filter”)
• Important: Re-install the 4 transport bolts in the back of the appliance.
• This appliance is heavy. Transport with care. Never hold any protruding part of the machine when lifting.
The machine door cannot be used as a handle.
WARNING!

20
ENG
Packaging/Old appliance
This marking indicates that this product should not be disposed with other household wastes throughout the
EU.To prevent possible harm to the environment or human health from uncontrolled waste disposal,recycle
it responsibly to promote the sustainable reuse of material resources.To return your used device, please use
the collection systems or contact the retailer where the product was purchased. They return and can take this
product for environmental safe recycling.
Product information sheet
COMMISSION DELEGATED REGULATION (EU) 2019/2014 with regard to energy labelling of
household washing machines and household washer-dryers
Supplier’s name or trade mark: Tesla
Supplier’s address: Tesla Electronics, Litijska 47, 1000 Ljubljana, SI
Model identifier: WF81490MS
General product parameters:
Parameter Value Parameter Value
Rated capacity (a) (kg) 8,0 Dimensions in cm
Height 850
Width 600
Depth 570
Energy Efficiency
Index (a) EEIw
60,0 Energy efficiency class (a) B
Washing efficiency index (a)1,031 Rinsing effectiveness (g/kg) (a)5,0
Energy consumption in
kWh per cycle, based on
the eco 40-60 programme
at a combination of full and
partial loads. Actual energy
consumption will depend
on how the appliance is
used.
0,545
Water consumption in litre per
cycle, based on the eco 40-60
programme at a combination
of full and partial loads.
Actual water consumption will
depend on how the appliance
is used and on the hardness of
the water.
48
Maximum temperature
inside the treated textile
(a) (°C)
Rated
capacity 39
Weighted remaining moisture
content (a) (%) 53,9
Half 32
Quarter 22
Spin speed (a) (rpm)
Rated
capacity 1 350
Spin-drying efficiency class (a) B
Half 1 350
Quarter 1 350
