TEXA TMD MKG SA User manual

SUMMARY
REVISION OF THE MANUAL.................................................................................3
1 INTRODUCTION.................................................................................................4
2 LEGEND OF THE SYMBOLS USED..................................................................5
3 SPECIFIC SAFETY RULES FOR INSTALLING TMD MKG SA..........................7
3.1 Glossary...................................................................................................................7
3.2 General Rules...........................................................................................................8
3.3 Operator Safety........................................................................................................9
3.4 Device Safety.........................................................................................................10
3.5 Safety during the Installation..................................................................................11
4 OPERATION OF THE RADIO DEVICES..........................................................12
5 ENVIRONMENTAL INFORMATION.................................................................13
6 REGULATORY INFORMATION........................................................................14
7 TMD MKG SA....................................................................................................15
8 TECHNICAL FEATURES..................................................................................16
9 TMD MKG SA INSTALLATION.........................................................................17
10 ACTIVATION...................................................................................................18
10.1 Activation through MKG SA Starter......................................................................18
11 LEGAL NOTICES............................................................................................19
1

2

TMD MKG SA INSTALLATION MANUAL
REVISION OF THE MANUAL
This document is revision 02 of the TMD MKG SA technical manual.
Issue Date: 23/09/2022
3

1 INTRODUCTION
Thank you for choosing TEXA TMD for the global management of your fleet.
We are certain that you will get the greatest satisfaction from it and receive a great deal of help in
your work.
Please read this instruction manual carefully and keep it close at hand for future reference.
This manual shows and describes standard and optional features.
Therefore, the tool you have purchased may not be equipped with certain features or elements
described in this document.
Reading and understanding this manual can avoid damage to things and injury to people due to
an improper use of the tool. They cannot, however, replace or complete the skill of the
professionals for whom the tool is intended.
Thedata,featuresanddescriptionscontainedinthismanualareprovidedforinformativepurposes
only. They are not binding for TEXA S.p.A., which reserves the right to carry out any changes
deemed necessary in order to improve the product, or for any technical or commercial need, at
any time and without prior notice.
Texa S.p.A. declines any responsibility for damages to things or persons resulting from operations
performed based on possible incorrect or inaccurate information contained in this manual.
Reproduction, whole or in part, of this manual in any form without written authorisation by the
manufacturer is strictly forbidden.
4

2 LEGEND OF THE SYMBOLS USED
Some of the symbols indicated below may not be used in the manual.
Toxic material hazard Floor level obstacle warning
Explosive material hazard Laser beam hazard
Electric shock hazard Low temperature danger - freezing
Electromagnetic field hazard General Risk
Flammable material hazard Obligation to read the instructions
Hot surface hazard Safety glasses required
Corrosive substance hazard Protective gloves required
Risk of noise level above 80 dbA Protective clothing required
Moving Parts Risk Respiratory protection required
Risk of crushing hands Disconnect mains plug from electrical outlet
This is not a safety symbol.
It indicates a hazardous situation which, if not avoided, will result in
serious permanent injury or death.
This is not a safety symbol.
It indicates a hazardous situation which, if not avoided, may result in
serious permanent injury or death.
This is not a safety symbol.
It indicates a hazardous situation which, if not avoided, may result in
minor injury.
This is not a safety symbol.
It indicates a hazardous situation which, if not avoided, may result in
material damage.
5

This is not a safety symbol.
It indicates important information.
6

3 SPECIFIC SAFETY RULES FOR INSTALLING TMD MKG SA
The technology used for the design and manufacturing control of the TMD MKG SA makes it a
reliable, simple and safe device to install and use.
The personnel in charge of installing the remote diagnostic tools are required to follow the general
safety regulations, to use TMD MKG SA devices for their intended use only and to carry out the
maintenance correctly, as described in this manual.
All the requirements based on the following must be assessed and applied:
•Labour inspectorate.
•Trade associations.
•Vehicle manufacturers.
•Anti-pollution regulations.
3.1 Glossary
Operator: a qualified person responsible for installing the remote diagnostic device.
Device: any TMD MKG SA device.
The definition of "operator" cannot be applied to minors or to people
with reduced physical, sensory or mental capabilities or without any
experience or knowledge required.
7

3.2 General Rules
The operator must have carefully read all the information and instructions in the
technical documents provided with the tool.
If the operator is not able to read this manual, the operating instructions and safety
indications must be read and discussed in the operator's native language.
•The operator that works on vehicles must have basic
qualifications and knowledge of mechanics, automotive
engineering, car repair and of the potential dangers that may
arise during self-diagnosis operations.
•The operator must carefully follow all the instructions provided
in the technical documents.
•The operator must be completely clear-headed and sober when
installing and using the device; taking drugs or alcohol before or
when installing and operating the device is strictly forbidden.
•The operator is required to wear adequate personal protective
equipment (PPE) throughout the installation of the device.
•The operator must periodically inspect the device, making sure
it is in good condition and replacing it if it is damaged.
•The operator must periodically check the parts that are subject
to wear and replace them if necessary, using only original spare
parts or spare parts approved by the manufacturer.
•Theoperatormuststopusing the device immediatelyshouldany
failure occur, and promptly contact the technical assistance.
•Do not remove or damage the labels and the warnings on the
device; do not in any case make them illegible.
•The operator is prohibited from CARRYING OUT ANY
OPERATION NOT EXPRESSLY REQUESTED AND
INDICATED.
•The equipment can be used by children aged 8 years and above
and persons with reduced physical, sensory or mental
capabilities, or lack of experience or necessary knowledge, as
longastheyaresupervisedorgiveninstructionsconcerningsafe
use of the equipment and understand the hazards involved.
•Children must not play with the equipment.
•Cleaning and maintenance must not be carried out by children
without supervision.
8

3.3 Operator Safety
The device was manufactured to be electrically safe and
insulated and to work with specific supply voltage levels.
Improper use may expose the operator to the risk of electric
shock, even though of low intensity.
Safety Measures:
•Wear adequate personal protective equipment during all the operating phases.
•Do not handle or touch the device with wet hands.
•If liquid should penetrate inside the device, contact technical assistance.
•Do not wear metal rings or bracelets when working on batteries.
The device was manufactured to be electrically safe and
mechanically resistant.
However, it is necessary to reduce the risk of damages to the
device that may cause burns.
Safety Measures:
•Avoid sparks or flames near the installation.
If the device gets wet or damaged, or comes into contact with
liquids, this may cause short circuits, fire, material damage or
serious injury.
Never use a wet or damaged device.
9

3.4 Device Safety
The device was manufactured to be mechanically resistant.
Careless use and excessive mechanical strain may impair its
efficiency.
Safety Measures:
•Do not drop, shake or knock the device.
•Do not carry out any type of intervention that may damage the device.
•Do not open or disassemble the device.
•Make sure the device is properly fastened before moving the vehicle on which it is installed.
The device was manufactured to be electrically safe and to work
with specific supply voltage levels.
Failure to comply with the specifications related to the power
supply may impair its efficiency.
Safety Measures:
•Do not wet the device with water or other liquids.
•The device's power supply must always be connected following the indications provided by
the Assistance Service.
•Do not use external batteries to power the device.
•Wear the most suitable personal protective equipment to avoid static electricity.
The device was designed to be used in specific environmental
conditions.
Installing and using the device in environments with
temperatures and humidity that differ from those indicated may
impair its efficiency.
Safety Measures:
•Position the device as indicated in this manual.
•Do not expose or install the device near sources of heat.
•Always place the device in a dry area.
•Do not expose the device to rain or water jets.
•Do not use corrosive chemicals, solvents or harsh detergents to clean the device.
10

3.5 Safety during the Installation
The installation of the device was carefully tested by qualified
personnel in TEXA.
You must follow some indications provided by the vehicle
manufacturer in order to install the device correctly.
Safety Measures:
•Follow the indications provided in the vehicle's manual carefully to disassemble the plastic
parts and the access to the compartments.
•Do not compromise in any way the quality of the electrical and mechanical OEM wiring.
•Make sure the electric cables, the wiring in general, the fuel hydraulic pipes and the safety
pneumatic devices of the vehicle are not damaged during the installation.
•Do not change the current flow of an OEM circuit by cutting it off, increasing it or mechanically
changing it cables if not permitted by the vehicle manufacturer.
The device must be installed so as to ensure it can work
correctly and safely.
Make sure the installation does not interfere with the operation
of the vehicle controls.
Make sure the product's position does not compromise safety
when driving the vehicle.
Safety Measures:
•Inform the driver that the device must not be moved in any way or for any reason from the
location where it was installed.
MAGNETIC SOURCES (for example: loudspeakers) MAY
ACTIVATE THE DEVICE INAPPROPRIATELY, REDUCING THE
BATTERY LIFE.
Safety Measures:
•Do not install the device near magnetic sources.
At the end of the installation, you must restore the initial
conditions of the vehicle.
Safety Measures:
•Restore any OEM device (e.g.: covers, compartments, plastic parts, seals).
•Replace the fastening elements that are damaged.
11

4 OPERATION OF THE RADIO DEVICES
Wireless connection with Bluetooth, Wi-Fi and 2G / 3G / 4G technology
The wireless connectivity with the Bluetooth, WiFi and 2G / 3G / 4G technology is a technology
thatsuppliesastandard,reliablemethod toexchangeinformationbetweendifferentdevices,using
radio waves. Other than TEXA tools, many more products use this technology, such as cellular
phones, portable devices, computers, printers, photo cameras, Pocket PCs, etc.
The Bluetooth, WiFi and 2G / 3G / 4G interfaces look for compatible electronic devices according
to the radio signal they emit and establish a connection between them. TEXA tools select and only
prompt you with compatible TEXA devices. This does not exclude the presence of other sources
of communication or disturbance.
THE EFFICIENCY AND QUALITY OF BLUETOOTH, WiFi AND 2G / 3G / 4G COMMUNICATION
MAY BE INFLUENCED BY THE PRESENCE OF RADIO DISTURBANCE SOURCES. THE
COMMUNICATION PROTOCOL HAS BEEN DEVELOPED TO MANAGE THESE TYPES OF
ERRORS; HOWEVER, IN THESE CASES COMMUNICATION MAY BECOME DIFFICULT AND
CONNECTION MAY REQUIRE SEVERAL ATTEMPTS.
SHOULD THE WIRELESS CONNECTION ENCOUNTER SERIOUS PROBLEMS THAT MAY
COMPROMISE A REGULAR COMMUNICATION, THE SOURCE OF THE ENVIRONMENTAL
ELECTROMAGNETIC INTERFERENCE MUST BE IDENTIFIED AND ITS INTENSITY
REDUCED.
Position the tool so that the radio devices it is equipped with can work properly. In particular, do
not cover it with any shielding or metallic materials in general.
12

5 ENVIRONMENTAL INFORMATION
Do not dispose of this product with other undifferentiated solid waste.
Forinformation regarding the disposal ofthis product please see thepamphlet supplied.
13

6 REGULATORY INFORMATION
Simplified EU Declaration of Conformity
TEXA S.p.A. declares that the equipment type TMD MKG SA is compliant with the
following directives:
•RED 2014/53/EU
•RoHS 2011/65/EU
The complete text of the EU declaration of conformity is available at the following
Internet address https://www.texa.com/download.
14

7 TMD MKG SA
TMD MKG SA is a device that can increase the probability of recovering the vehicle if it is stolen.
The device is powered autonomously by an internal battery. When activated upon request, it can
provide the vehicle's GPS position for a period of time so as to support the police in recovering
the vehicle.
It is an independent device (Stand Alone) that works without the support of other devices.
It has a SIM card inside, which is needed to receive any messages from the Operations Centre.
Once installed and activated, the device remains 'dormant'.
A periodic activation of the device can be configured to make sure it is working.
The factory setting for the activation is every 12 hours.
If the vehicle is stolen, once a police report has been filed, the Operations Centre will send an
activation SMS to the device.
Upon the first programmed activation, the device receives the SMS and starts transmitting its
position once every minute, until the battery is completely drained or the stolen vehicle is
recovered.
Once its function is exhausted, the TMD MKG SA must be disposed of.
15

8 TECHNICAL FEATURES
Manufacturer: TEXA S.p.A.
Model: TMD MKG SA
CPU: CORTEX M4
Communication module: GPRS / GSM
GNSS module: GPS, GLONASS, Beidou, Compass,
Galileo
Battery: Lithium 3.6 V - 8.5 Ah
Power supply: self-powered
Operating temperature: - 20 ÷ 65 °C
Storage temperature: - 30 ÷ 80 °C
Operating moisture: 10 ÷ 80 %
Dimensions:
Weight: 170 g
Regulations and Directives: RED 2014/53/EU RoHS 2011/65/EU
Delegated Directive 2015/863/EU
Electromagnetic Compatibility:
ETSI EN 301 489-1
ETSI EN 301 489-17
ETSI EN 301 489-19
ETSI EN 301 489-52
Radio Systems:
ETSI EN 300 328
ETSI EN 301 511
ETSI EN 303 413
EN 62311
Electrical Safety: EN 62368-1
16

9 TMD MKG SA INSTALLATION
The installation must be performed by qualified personnel only.
Make sure the installation does not interfere with the vehicle
operation.
MAGNETIC SOURCES (for example: loudspeakers) MAY
ACTIVATE THE DEVICE INAPPROPRIATELY, REDUCING THE
BATTERY LIFE.
DO NOT INSTALL THE DEVICE NEAR MAGNETIC SOURCES.
Proceed as follows:
1.Install and secure the device in the position that the operator considers the most suitable to fulfil
the operating requirements.
To prevent tampering with the device, choose its installation position
carefully.
For more information and advice, contact TEXA Assistance Service.
For further information on the correct installation position, please refer to the user
manual provided with the vehicle.
17

10 ACTIVATION
In order to use the advanced functions in the device, it must be activated.
10.1 Activation through MKG SA Starter
The device can be activated by holding a magnet close to it.
Configure the device using the specific MKG SA Starter software.
The software consists of an app for Android and iOS devices that can be downloaded free of
charge from Play Store and App Store.
InorderforMKGSA Startertoworkproperly,thedeviceonwhichtheappisinstalledmustconnect
to the Internet.
You may also be required to enable the installation of apps from unknown authors.
The device can be configured at the end of the activation procedure.
The app provides detailed information on the activation and
installation of the device.
18

11 LEGAL NOTICES
TEXA S.p.A.
Via 1 Maggio, 9 - 31050 Monastier di Treviso - ITALY
Tax Code - Company Register of Treviso ID No. - VAT No.: 02413550266
Single-shareholder company subject to the direction and coordination activities of Opera Holding
S.r.l.
Paid-up share capital 1,000,000 € - R.E.A. (Economic Administrative Index) No. 208102
Legal Representative Bruno Vianello
Phone [phone]
Fax [phone]
www.texa.com
For information regarding the legal notices, please refer to the International Warranty Booklet
provided with the product.
19
