PrefaceSPRU976 – March 2006
Read This First
About This Manual
This document describes the Serial Rapid IO (SRIO) on the TMS320C645x devices.
Notational Conventions
This document uses the following conventions.•Hexadecimal numbers are shown with the suffix h. For example, the following number is 40hexadecimal (decimal 64): 40h.•Registers in this document are shown in figures and described in tables.– Each register figure shows a rectangle divided into fields that represent the fields of the register.Each field is labeled with its bit name, its beginning and ending bit numbers above, and itsread/write properties below. A legend explains the notation used for the properties.– Reserved bits in a register figure designate a bit that is used for future device expansion.•The term "word" describes a 32-bit value. The term "halfword" describes a 16-bit value.
Related Documentation From Texas InstrumentsThe following documents describe the C6000™ devices and related support tools. Copies of thesedocuments are available on the Internet at www.ti.com. Tip: Enter the literature number in the search boxprovided at www.ti.com .
TMS320C6000 CPU and Instruction Set Reference Guide (literature number SPRU189 ) gives anintroduction to the TMS320C62x™ and TMS320C67x™ DSPs, development tools, and third-party support.
TMS320C6455 Technical Reference (literature number SPRU965 ) gives an introduction to theTMS320C6455™ DSP and discusses the application areas that are enhanced.
TMS320C6000 Programmer's Guide (literature number SPRU198 ) describes ways to optimize C andassembly code for the TMS320C6000™ DSPs and includes application program examples.
TMS320C6000 Code Composer Studio Tutorial (literature number SPRU301 ) introduces the CodeComposer Studio™ integrated development environment and software tools.
Code Composer Studio Application Programming Interface Reference Guide (literature numberSPRU321 ) describes the Code Composer Studio™ application programming interface (API), which allowsyou to program custom plug-ins for Code Composer.
TMS320C64x+ Megamodule Reference Guide (literature number SPRU871 ) describes theTMS320C64x+ digital signal processor (DSP) megamodule. Included is a discussion on the internal directmemory access (IDMA) controller, the interrupt controller, the power-down controller, memory protection,bandwidth management, and the memory and cache.
TMS320C645x DSP Peripherals Overview Reference Guide (literature number SPRUE52 ) provides abrief description of the peripherals available on the TMS320C645x digital signal processors (DSPs).
TMS320C6455 Chip Support Libraries (CSL) (literature number SPRC234 ) is a download with the latestchip support libraries.Trademarks
C6000, TMS320C62x, TMS320C67x, TMS320C6455, TMS320C6000, Code Composer Studio, RapidIOare trademarks of Texas Instruments.
InfiniBand is a trademark of the InfiniBand Trade Association.
SPRU976 – March 2006 Preface 13Submit Documentation Feedback

1 Overview
1.1 General RapidIO System
User's GuideSPRU976 – March 2006
Serial RapidIO (SRIO)
The RapidIO peripheral used in the TMS320C645x is called a serial RapidIO (SRIO). This chapterdescribes the general operation of a RapidIO system, how this module is connected to the outside world,the definitions of terms used within this document, and the features supported and not supported forSRIO.
RapidIO™ is a non-proprietary high-bandwidth system level interconnect. It is a packet-switchedinterconnect intended primarily as an intra-system interface for chip-to-chip and board-to-boardcommunications at Gigabyte-per-second performance levels. Uses for the architecture can be found inconnected microprocessors, memory, and memory mapped I/O devices that operate in networkingequipment, memory subsystems, and general purpose computing. Principle features of RapidIO include:•Flexible system architecture allowing peer-to-peer communication•Robust communication with error detection features•Frequency and port width scalability•Operation that is not software intensive•High bandwidth interconnect with low overhead•Low pin count•Low power•Low latency
1.1.1 RapidIO Architectural Hierarchy
RapidIO is defined as a 3-layer architectural hierarchy.•Logical layer: Specifies the protocols, including packet formats, which are needed by endpoints toprocess transactions•Transport layer: Defines addressing schemes to correctly route information packets within a system•Physical layer: Contains the device level interface information such as the electrical characteristics,error management data, and basic flow control data
In the RapidIO architecture, a single specification for the transport layer is compatible with differingspecifications for the logical and physical layers (see Figure 1 ).
14 Serial RapidIO (SRIO) SPRU976 – March 2006Submit Documentation Feedback

www.ti.com
Globally
shared
memory spec
logical
Future
Message
passingsystem
I/O
Logical specification
Information necessary for the end point
to process the transaction (i.e., transaction
type, size, physical address)
to end in the system (i.e., routing address)
Information to transport packet from end
Transport specification
spec
transport
Common
between two physical devices (i.e., electrical
Information necessary to move packet
interface, flow control)
Physical specification
1x/4x
LP serialLP-LVDS
8/16 Future
spec
physical
checklist
Compliance
Inter-
operability
specification
Overview
Figure 1. RapidIO Architectural Hierarchy
SPRU976 – March 2006 Serial RapidIO (SRIO) 15Submit Documentation Feedback

www.ti.com
Host Subsystem I/O Control Subsystem
DSP Farm
TDM,GMII, Utopia
Communications Subsystem PCI Subsystem
InfiniBand HCA™
To System Area
Network
Memory
Memory Memory
Memory
RapidIO RapidIO RapidIO
RapidIO
RapidIO
Backplane
PCI
RapidIO
RapidIO
RapidIO
RapidIO
Switch
Control
Processor
IO
Processor
RapidIO to
InfiniBand
RapidIO
Switch
RapidIO
Switch
Legacy
Comm
Processor
RapidIO
Switch
RapidIO to
PCI Bridge
ASIC/FPGA
Memory Memory
Host
Processor
Host
Processor
DSP DSP DSP DSP
Comm
Processor
Overview
1.1.2 RapidIO Interconnect Architecture
The interconnect architecture is defined as a packet switched protocol independent of a physical layerimplementation. Figure 2 illustrates the interconnection system.
Figure 2. RapidIO Interconnect Architecture
(1) InfiniBand™ is a trademark of the InfiniBand Trade Association.
1.1.3 1x/4x LP-Serial
Currently, there are two physical layer specifications recognized by the RapidIO Trade Association: 8/16LP-LVDS and 1X/4X LP-Serial. The 8/16 LP-LVDS specification is a point-to-point synchronous clocksourcing DDR interface. The 1X/4X LP-Serial specification is a point-to-point, AC coupled, clock recoveryinterface. The two physical layer specifications are not compatible.
SRIO complies with the 1X/4X LP-Serial specification. The serializer/deserializer (SERDES) technology inSRIO also aligns with that specification.
The 1X/4X LP-Serial specification currently covers three frequency points: 1.25, 2.5, and 3.125 Gbps. Thisdefines the total bandwidth of each differential pair of I/O signals. An 8b/10b encoding scheme ensuresample data transitions for the clock recovery circuits. Due to the 8b/10b encoding overhead, the effectivedata bandwidth per differential pair is 1.0, 2.0, and 2.5 Gbps respectively. Serial RapidIO only specifiesthese rates for both the 1X and 4X ports. A 1X port is defined as 1 TX and 1 RX differential pair. A 4X portis a combination of four of these pairs. This document describes a 4X RapidIO port that can also beconfigured as four 1X ports, thus providing a scalable interface capable of supporting a data bandwidth of1 to 10 Gbps.
16 Serial RapidIO (SRIO) SPRU976 – March 2006Submit Documentation Feedback

www.ti.com
Serial RapidIO 1x Device to 1x Device Interface Diagram
Serial RapidIO 4x Device to 4x Device Interface Diagram
1x Device
TD[0]
TD[0]
RD[0]
RD[0] TD[0]
TD[0]
1x Device
RD[0]
RD[0]
RD[0-3]
RD[0-3]
4x Device
TD[0-3]
RD[0-3]
RD[0-3]
TD[0-3]
4x Device
TD[0-3]
TD[0-3]
1.2 RapidIO Feature Support in SRIO
Overview
Figure 3. Serial RapidIO Device to Device Interface Diagrams
Features Supported in SRIO:•RapidIO Interconnect Specification V1.2 compliance, Errata 1.2•LP-Serial Specification V1.2 compliance•4X Serial RapidIO with auto-negotiation to 1X port, optional operation for four 1X ports•Integrated clock recovery with TI SERDES•Hardware error handling including Cyclic Redundancy Code (CRC)•Differential CML signaling supporting AC and DC coupling•Support for 1.25, 2.5, and 3.125 Gbps rates•Power-down option for unused ports•Read, write, write with response, streaming write, outgoing Atomic, and maintenance operations•Generates interrupts to the CPU (Doorbell packets and internal scheduling)•Support for 8b and 16b device ID•Support for receiving 34b addresses•Support for generating 34b, 50b, and 66b addresses•Support for the following data sizes: byte, half-word, word, double-word•Big endian data transfers•Direct IO transfers•Message passing transfers•Data payloads of up to 256B•Single messages consisting of up to 16 packets•Elastic storage FIFOs for clock domain handoff•Short run and long run compliance•Support for Error Management Extensions•Support for Congestion Control Extensions•Support for one multi-cast ID
SPRU976 – March 2006 Serial RapidIO (SRIO) 17Submit Documentation Feedback

www.ti.com
1.3 Standards
1.4 External Devices Requirements
Overview
Features Not Supported:•Compliance with the Global Shared Memory specification (GSM)•8/16 LP-LVDS compatible•Destination support of RapidIO Atomic Operations•Simultaneous mixing of frequencies between 1X ports (all ports must be the same frequency)•Target atomic operations (including increment, decrement, test-and-swap, set, and clear) for internalL2 memory and registers
The SRIO peripheral is compliant to V1.2 of the RapidIO Interconnect Specification and V1.2 of theLP-Serial specification.
Table 1. RapidIO Documents and Links
Document Link Description
Official RapidIO Web Site http://www.RapidIO.org Various associated docs
SRIO provides a seamless interface to all devices which are compliant to V1.2 of the LP-Serial RapidIOspecification. This includes ASIC, microprocessor, DSP, and switch fabric devices from multiple vendors.Compliance to the specification can be verified with bus-functional models available through the RapidIOTrade Association, as well as test suites currently available for licensing.
Serial RapidIO (SRIO)18 SPRU976 – March 2006Submit Documentation Feedback

www.ti.com
2 SRIO Functional Description
2.1 Overview
SRIO Functional Description
2.1.1 Peripheral Data Flow
This peripheral is designed to be an external slave module that is capable of mastering the internal DMA.This means that an external device can push (burst write) data to the DSP as needed, without having togenerate an interrupt to the CPU. This has two benefits. It cuts down on the total number of interrupts, andit reduces handshaking (latency) associated with read-only peripherals.
SRIO specifies data packets with payloads up to 256 bytes. Many times, transactions will span acrossmultiple packets. RapidIO specifies a maximum of 16 transactions per message. Although a request isgenerated for each packet transaction so that the DMA can transfer the data to L2 memory, an interrupt isonly generated after the final packet of the message. This interrupt notifies the CPU that data is availablein L2 Memory for processing.
As an endpoint device, the peripheral accepts packets based on the destination ID. Two options exist forpacket acceptance and are mode selectable. The first option is to only accept packets whose DestIDsmatch the local deviceID in 0x0080. This provides a level of security. The second option is to acceptincoming packets matching the deviceID in either 0x0080 or 0x0084. This allows for system multicastoperations.
Data flow through the peripheral can be explained using the high-level block diagram shown in Figure 4 .High-speed data enters from the device pins into the RX block of the SERDES macro. The RX block is adifferential receiver expecting a minimum of 175mV peak-to-peak differential input voltage (Vid). Levelshifting is performed in the RX block, such that the output is single ended CMOS. The serial data is thenfed to the SERDES clock recovery block. The sole purpose of this block is to extract a clock signal fromthe data stream. To do this, a low-frequency reference clock is required, 1/10
th
or ½0
th
the data rate. Forexample, for 3.125 Gbps data, a reference clock of 312.5Mhz or 156.25Mhz is needed. Typically, thisclock comes from an off-chip stable crystal oscillator and is a LVDS device input separate to the SERDES.This clock is distributed to the SERDES PLL block which multiplies that frequency up to that of the datarate. Eight phases of this high-speed clock are created and routed to the clock recovery blocks. The clockrecovery block further interpolates eight times between these clock phases. This provides clock edgeresolution of 1/96
th
the Unit Interval (UI). The clock recovery block samples the incoming data andmonitors the relative positions of the data edges. With this information, it can provide the data and acenter-aligned clock to the S2P block. The S2P block uses the newly recovered clock to demux the datainto 10-bit words. At this point, the data leaves the SERDES macro at 1/10th the pin data rate,accompanied by an aligned byte clock.
SPRU976 – March 2006 Serial RapidIO (SRIO) 19Submit Documentation Feedback

www.ti.com
1.25-3.125 Gbps
differential data
Rx Clock
recovery S2P
10b
Clk 8b/10b
decode 8b
Clock
recovery
Rx 8b8b/10b
decode
10b
ClkS2P
Clock
recovery
Rx 8b8b/10b
decode
10b
ClkS2P
Clock
recovery
Rx 8b8b/10b
decode
10b
ClkS2P
PLL
Tx
Tx
Tx
Tx
P2S
P2S
P2S
P2S
8b
8b
8b
8b
10b 8b/10b
coding
Clk
8b/10b
coding
8b/10b
coding
8b/10b
coding
10b
Clk
10b
Clk
10b
Clk
FIFO
FIFO
FIFO
FIFO
System
clock
Capability
registers
Control
Command
and status
registers
SERDES
Clock domain 2 Clock domain 3
Clock domain 1
DMA
bus
Packet Generation
Lane striping
Lane de-skew
CRC error detection
CRC generation
Buffering address and data handoff
FIFO
FIFO
FIFO
FIFO
SRIO Functional Description
Figure 4. SRIO Peripheral Block Diagram
Within the physical layer, the data next goes to the 8b/10b decode block. 8b/10b encoding is used byRapidIO to ensure adequate data transitions for the clock recovery circuits. Here the 20% encodingoverhead is removed as the 10-bit data is decoded to the raw 8-bit data. At this point, the recovered byteclock is still being used.
The next step is clock synchronization and data alignment. These functions are handled by the FIFO andlane de-skewing blocks. The FIFO provides an elastic store mechanism used to hand off between therecovered clock domains and a common system clock. After the FIFO, the four lanes are synchronized infrequency and phase, whether 1X or 4X mode is being used. The FIFO is 8 words deep. The lanede-skew is only meaningful in the 4X mode, where it aligns each channel’s word boundaries, such that theresulting 32-bit word is correctly aligned.
The CRC error detection block keeps a running tally of the incoming data and computes the expectedCRC value for the 1X or 4X mode. The expected value is compared against the CRC value at the end ofthe received packet.
After the packet reaches the logical layer, the packet fields are decoded and the payload is buffered.Depending on the type of received packet, the packet routing is handled by functional blocks which controlthe DMA access.
2.1.2 SRIO Packets
The SRIO data stream consists of data fields pertaining to the logical layer, the transport layer, and thephysical layer.•The logical layer consists of the header (defining the type of access) and the payload (if present).•The transport layer is partially dependent on the physical topology in the system, and consists ofsource and destination IDs for the sending and receiving devices.•The physical layer is dependent on the physical interface (i.e., serial versus parallel RapidIO) andincludes priority, acknowledgment, and error checking fields.
2.1.2.1 Operation Sequence
SRIO transactions are based on request and response packets. Packets are the communication elementbetween endpoint devices in the system. A master or initiator generates a request packet which istransmitted to a target. The target then generates a response packet back to the initiator to complete thetransaction.
20 Serial RapidIO (SRIO) SPRU976 – March 2006Submit Documentation Feedback
