Gibson Super Gold Tone 60RV User manual

Gibson Goldtone
SERVICE MANUAL NO. GG0007
ISSUE 1
Date: December 21st 2000
Product Code : G-05
Model No : Gibson Super Gold Tone 60RV
Issued by:
Trace Elliot Limited.
Blackwater Trading Estate
The Causeway, Maldon
Essex CM4 4GG.

cd0128x1.sch-1 - Thu Dec 21 10:22:04 2000

1
C32-PCB-GA-60RV
GIBSON Super ‘GoldTone’ GA-60RV Main Valve Preamp
(Reverb/Sensitivity modifications) ISSUE 1.4 21/9/00 PS
Description Part Code Qty Where Used
PCB PC00126 issue 1 1
*** = formerly obsolete (Part to be used when old part is used up)
A.I. MACHINE
0 OHM LINK 72-RCZERO 2R12 R67
1R0 1/4W 72-RM1R-1WATT 1R73
2R7 1/4W 72-RM2R7 1R74
15R 1/4W 72-RM15R*** 2R75 R76 (inform PS)
47R 1/4W 72-RM47R 1R77
470R 1/4W 72-RM470R 1R64
820R 1/4W 72-RM820R*** 1R52 (72-RM1K)
1K5 1/4W 72-RM1K5 4R28 R34 R40 R47
2K7 1/4W 72-RM2K7 2R31 R53
5K1 1/4W 72-RM5K1*** 2R2 R3 (72-RM4K7)
8K2 1/4W 72-RM8K2 1R25
10K 1/4W 72-RM10K 1R66
10K 1W 72-RM10K-1WATT 1R44
15K 1/2W carbon 72-RC15K-.5W*** 2R56 R72 (72-RM15K)
22K 1/2W carbon 72-RC22K-.5W*** 3R58 R78 R79 (72-RM22K)
27K 1/4W 72-RM27K 2R4 R71
33K 1/4W 72-RM33K 4R8 R21 R22 R45
39K 1/4W 72-RM39K 1R36
47K 1/4W carbon 72-RC47K-.25W*** 1R70 (72-RM47K)
75K 1/4W 72-RM75K*** 4R24 R30 R33 R39 (72-RM100K)
82K 1W 72-RM82K-1WATT 1R63
100K 1/4W 72-RM100K 5R6 R9 R10 R16 R17
100K 1W 72-RM100K-1WATT 8R29 R35 R38 R43 R50 R55 R61
R68
220K 1/4W 72-RM220K 1R5
220K 1W 72-RM220K-1WATT 3R27 R32 R46
330K 1/4W 72-RM330K 3R19 R41 R54
470K 1/4W 72-RM470K 6R7 R13 R18 R42 R59 R60
680K 1/4W 72-RM680K 1R14
750K 1/4W 72-RM750K*** 1R69 (inform PS)
1M0 1/4W 72-RM1M 10 R15 R23 R26 R37 R48 R49 R51
R57 R62 R65
10M 1/4W 72-RM10M 1R1
22n 100V axial 72-C22N-100VCA 2C12 C49
100n 100V axial 72-C100N-100VCA 1C51
1N4002 72-D-IN4002 4D1 D2 D3 D4
15V ZENER 72-D-BZX55C15V 1Z1
NOT FITTED R11
Track Modification Cut track, topside, that runs below R40,
R41 & R42.
Link bottom end of R45 to REV3 Scrn
(see Paul Stevens if in doubt)

2
82R 4W resistor 72-RWW82R-4W 1R20
47p 500V ceramic 72-C47P-500VCD 2C17 C28
180p 100V ceramic 72-C180P-100VCD*** 1C46 (72-C150P-100VCA)
200p polystyrene 72-C200P-630VPA 2C3 C4 (72-C250P-500VSM)
330p 100V ceramic 72-C330P-100VCD2** 1C57 (72-C470P-50VCD)
560p 100V ceramic 72-C560P-100VCD*** 1C43 (72-C560P-100VCA)
470p polystyrene 72-C470P-160VPA*** 1C2 (72-C470P-630VPA)
500p 500V slvrmica 72-C500P-500VSM 3C9 C19 C21
680p polystyrene 72-C680P-630VPA 4C8 C31 C34 C35 (72-C1000P-500VSM)
2n2 1KV ceramic 72-C2200P-1KVCD 1C7 (72-C2N2-400VP)
22n 400V poly box 72-C22N-400VP 11 C10 C11 C13 C15 C18 C27 C36
C47 C48 C50 C52
47n 400V poly box 72-C47N-400VP2 1C5 C42
100n 250V poly box 72-C100N-250VP 1C6
220n 63V poly box 72-C220N-63VP*** 4C1 C22 C38 C41 (72-C220N-50VCA)
330n 63V poly box 72-C330N-63VP*** 1C59 (72-C330N-50VCA)
0u15 35V tant 72-C0.15-35VT 1C45
1u5 35V tant 72-C1.5-35VT 3C29 C32 C33
2u2 63V elect rad 72-C2.2-63VER*** 3C30 C37 C44 (72-C2.2-35VT)
15u 63V elect axl 72-C15-40VEA*** 7C14 C16 C20 C23 C24 C25 C26
(72-C22-63VER)
22u 63V elect rad 72-C22-63VER 2C39 C40
47u 63V elect rad 72-C47-63VER 3C54 C56 C58
4700u 35V elect rad 72-CAP-470035V 2C53 C55
SEMICONDUCTORS
3mm TRI COLOUR LED 72-LED-TRI-3mm 1D5
3mm RED LED 72-LED-RED-3mm 1D6
J175 72-FET-J-175 12 TR1 TR2 TR3 TR4 TR5 TR7 TR8
TR11 TR12 TR13 TR15 TR16
J176 72-FET-J-1761TR14 NEW PART
2N3904 72-T2N3904 6TR6 TR9 TR10 TR20 TR21 TR22
2N3906 72-T2N3906 2TR17 TR18
CONNECTORS
8 way 0.1” 72-HEAD-8W-21PL3
10 way 0.1” 72-HEAD-10W 2PL1 PL2
¼” Mono Jack SKT 72-SKT-JCKBNBG 1SK1
5 way ribbon 72-LK-5W60L 1REV2 / MV1
PUSH SWITCHES 73-SWT-F2UEE-MOM 2SW1 SW2
POTENTIOMETERS
25K LIN 73-POT-B25K 2RV3 RV8
250K LOG 73-POT-A250K 1RV10
250K LIN 73-POT-B250K 2RV2 RV7
1M0 LOG 73-POT-A1M 5RV1 RV4 RV5 RV6 RV9
CRIMP CONNECTORS 72-CRIMP-PCB-TAB 4TX8 TX9 TX10 TX11
FUSE HOLDERS 72-FUS-HLD-PCB-42FS1 check orientation
B9A PCB valve base 73-VAL-SOCKET-G7V1 –V7 on underside of PCB
BD647 72-TBD647 1TR19
TO220 HEATSINK G13-HS-TO220-14H 1TR19
M3 SCREW 71-SCR-M3X12PPB 1Part of heat sink assembly
M3 WASHER 71-WAS-M3INTSP 1Same as Speed Twin see drawing
M3 WASHER 71-WAS-M3ABLK 1“
M3 NUT 71-NUT-M3ZINC 1“
INSULATING KIT 72-MOS-PAD-TO220 1“
Heat sink compound Between TR19, heat sink & chassis

C32-PCB-PC00127
GIBSON Super ‘GoldTone’ rear board
ISSUE 1 10/5/00 PS
Description Part Code Qty Where Used
PCB PC00127 issue 1 1
*** = formerly obsolete (Part to be used when old part is used up)
A.I. MACHINE
220R 1W resistor 72-RM220R-1WATT 1R24
470R 1W resistor 72-RM470R-1WATT 1R25
620R 1/4W resistor 72-RM620R*** 2R16 R18 (72-RM1K0)
1K0 1/4W resistor 72-RM1K0 1R26
7K5 1/4W resistor 72-RM7K5*** 5R5 R7 R9 R11 R13 (72-RM10K)
10K 1/4W resistor 72-RM10K 3R2 R19 R27
47K 1/4W resistor 72-RM47K 1R4
100K 1/4W resistor 72-RM100K 12 R1 R3 R6 R8 R10 R12 R14
R17 R20 R21 R22 R23
1M0 1/4W resistor 72-RM1M 3R15 R28 R29
330n 50V axial 72-C330N-50VCA 20 C1 C2 C3 C4 C6 C8 C9
C10 C12 C13 C14 C15 C16 C17
C18 C19 C20 C21 C22 C23
1N4148 72-D-IN4148 1D1
2nd STAGE
CAPACITORS
2u2 35V elect tant 72-C2.2-35VT 1C5
15u 40V elect axial 72-C15-40VEA*** 3C11 C24 (72-C22-63VER)
NOT FITTED C7
SEMICONDUCTORS
7805 voltage regulator 72-IC-7805-REG 1IC5
ZTX614 Darlington 72-TZTX614 4TR2 TR4 TR7 TR8
J176 FET 72-FET-J-176 4TR1 TR3 TR5 TR6
4049B -Hex Inverter 72-IC-4049B 1IC1
4013B -Dual D Type 72-IC-4013B 3IC2 IC3 IC4
PLUGS/ SOCKETS
8 way 0.1” 72-HEAD-8W-21PL2
12 way 0.1” 72-HEAD-12W 1PL1
¼” Mono Jack SKT 72-SKT-JCKBNBG 3SK1 SK2 SK3
¼” Stereo Jack SKT 72-SKT-JCKBBBG 1FS2
8 pin DIN SKT PCB 73-SKT-DIN-8PIN 1FS1
SWITCHES 73-SWT-F2UEE 1SW1
73-SWT-F2UEE-MOM 1SW2
RELAY Omron G5V-173-RELAY-5V-SPCO 1RL1
POTENTIOMETERS 73-POT-A100K 1RV1
73-POT-A1M 1RV2

1
C32-PCB-PC00128
GIBSON Super ‘GoldTone’ Front Daughter Board
ISSUE 1 23/12/99 PS
Description Part Code Qty Where Used
PCB PC00128 issue 1 1
POTENTIOMETERS
250K LOG 73-POT-A250K 1RV11
1M0 LOG 73-POT-A1M 1RV12

C32-PCB-PC00129
PARTS LIST FOR GIBSON 60W VALVE POWER BOARD
ISSUE 1 18/9/00 PS
Description Part Code Qty Where Used
PCB PC00129 issue 1 1
*** = formerly obsolete (Part to be used when old part is used up)
A.I. MACHINE
0 Ohm Link 72-RCZERO 1R10
680R 1W resistor 72-RM680R-1WATT*** 1R23 (72-RM680R)
1K0 1W resistor 72-RM1K0-1WATT 2R13 R14
1K5 1/2W resistor 72-RM1K5-.5W*** 2R2 R4 (72-RM1K5)
2K2 1W resistor 72-RM2K2-1WATT 1R15
4K7 1W resistor 72-RM4K7-1WATT 1R8
10K 1W resistor 72-RM10K-1WATT 1R7
12K 1/4W resistor 72-RM12K 2R20 R21
18K 1/4W resistor 72-RM18K 2R19 R22
180K 1/4W resistor 72-RM180K 2R5 R6
220K 1W resistor 72-RM220K-1WATT 4R17 R18 R24 R25
1N4007 DIODES 72-D-IN4007 5D1 D2 D3 D4 D5
PCBMOUNT FUSE 72-FUS-125MA-F1FS3
NOT FITTED R16 C4
2nd STAGE
n.b Please insert all Wire Wounds
with pre-formed legs
1R0 4W resistor 72-RWW1R-4W 2R9 R11
1K5 4W resistor 72-RWW1K5-4W*** 2R1 R3 (72-RWW1K-
5W)
4K7 4W resistor 72-RWW4K7-4W 1R12
4n7 1KV ceramic 72-C4700P-1KVCD 4C13 C14 C17 C18
22u 160V elect rad 72-C22-160VER 1C8
100u 63V elect axl 72-C100-63VEA*** 2C11 C12 (72-C47-63VER)
22u 450V elect rad 72-C22-450VER 6C1 C2 C3 C5 C6 C7
330u250V elect rad 72-CAP-330250V 4C9 C10 C15 C16
3 way 0.1” 72-HEAD-3W-21PL3
10 way 0.1” 72-HEAD-10W 2PL1 PL2
JACK SOCKETS 73-SKT-JCKBNBG 4SK1 SK2 SK3 SK4
47K vertical trimmer 72-PRESET-47K-V2RV1 RV2
FUSE HOLDERS 72-FUS-HLD-PCB-44FS1 FS2 (check orientation)
CRIMP CONNECTORS 72-CRIMP-PCB-TAB 16 TX1-7TX10-TX18
0V TEST POINT PIN 73-TERM-PIN 1TP0
BIAS TEST POINTS 73-TERM-SCREW-M3 3BIAS0 BIAS2 BIAS3
OCTAL VALVE BASES 73-VAL-SOCKET-22V1 V2 (underneath PCB)

1
C32-PCB-PC00132x1
GIBSON Super ‘GoldTone’ Reverb Transformer Board
ISSUE 1 23/12/99
PS
Description Part Code Qty Where Used
*** = formerly obsolete
PCB PC00132 issue 1 1
TRANSFORMER 73-TRAN-BON/TRI*** 1TX1
CRIMP CONNECTORS 72-CRIMP-PCB-TAB 2J1 J2
