Textron Ransomes Parkway 2250 Plus Guide

YEARS OF MOWING
EXCELLENCE
3

© 2002, Ransomes Jacobsen Limited. All Rights Reserved

GB-1
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
1 CONTENTS
CONTENTS PAGE
1 CONTENTS ................................................................................................................ 1
2 INTRODUCTION
2.1 IMPORTANT .............................................................................................................. 2
2.2 PRODUCTIDENTIFICATION ....................................................................................... 2
3 SAFETYINSTRUCTIONS
3.1 OPERATINGINSTRUCTIONS ..................................................................................... 3
3.2 SAFETYSIGNS .......................................................................................................... 3
3.3 STARTINGTHEENGINE ............................................................................................. 3
3.4 DRIVINGTHEMACHINE ............................................................................................ 3
3.5 TRANSPORTING........................................................................................................ 3
3.6 LEAVINGTHEDRIVINGPOSITION ............................................................................ 4
3.7 SLOPES ..................................................................................................................... 4
3.8 BLOCKEDCUTTINGCYLINDERS .............................................................................. 4
3.9 ADJUSTMENTS,LUBRICATIONAND MAINTENANCE ............................................... 4
3.10 GUIDELINESFORTHEDISPOSALOFSCRAP PRODUCTS ........................................ 7
4 SPECIFICATIONS
4.1 ENGINESPECIFICATION ............................................................................................ 8
4.2 MACHINESPECIFICATION ........................................................................................ 8
4.3 DIMENSIONS ............................................................................................................. 8
4.4 VIBRATIONLEVEL .................................................................................................... 9
4.5 SLOPES ..................................................................................................................... 9
4.6 RECOMMENDEDLUBRICANTS ................................................................................. 9
4.7 CUTTINGPERFORMANCE......................................................................................... 9
4.8 CUTTINGPERFORMANCE(AREA) ............................................................................ 9
4.9 CONFORMITYCERTIFICATES ................................................................................. 10
5 DECALS
5.1 SAFETYDECALS ..................................................................................................... 12
5.2 INSTRUCTIONDECALS ............................................................................................ 12
6 CONTROLS
6.1 STARTERSWITCH ................................................................................................... 13
6.2 THROTTLECONTROLLEVER .................................................................................. 13
6.3 STEERINGWHEELRAKEADJUSTMENT .................................................................. 13
6.4 FOOTPEDAL ............................................................................................................. 13
6.5 SPEEDLIMITER ........................................................................................................ 13
6.6 TRANSPORTLATCHES ............................................................................................ 14
6.7 PARKINGBRAKE ...................................................................................................... 14
6.8 HYDRAULICLIFTLEVERS ....................................................................................... 14
6.9 UNITCOUNTERBALANCECONTROL...................................................................... 14
6.10 CUTTINGUNITSWITCHES ....................................................................................... 15
6.11 VARIABLECYLINDERSPEED ................................................................................... 15
6.12 BACKLAPPINGLEVER............................................................................................. 15
6.13 INSTRUMENTPANEL ............................................................................................... 16
6.14 DIFFLOCKCONTROL .............................................................................................. 17
7 OPERATION
7.1 DAILYINSPECTION .................................................................................................. 18
7.2 OPERATORPRESENCEANDSAFETYINTERLOCKSYSTEM ................................... 19
7.3 OPERATINGPROCEDURE ......................................................................................... 20
7.4 STARTINGTHEENGINE ............................................................................................ 21
7.5 DRIVING ................................................................................................................... 21
7.6 MOWING .................................................................................................................. 21
7.7 TOSTOPTHEENGINE .............................................................................................. 21
7.8 PUSHINGTHEMACHINEWITHTHEENGINESTOPPED ............................................ 23
8 ADJUSTMENTS
8.1 HEIGHTOFCUT ....................................................................................................... 24
8.2 SEAT(GRAMMERGS85/90) ..................................................................................... 25
8.3 SEAT(GRAMMERMSG20) ..................................................................................... 26
9 MAINTENANCE
9.2 LUBRICATIONANDMAINTENANCECHARTDIESELPOWEREDMACHINES............ 27
9.3 LUBRICATIONANDMAINTENANCECHARTLPGPOWEREDMACHINES ................ 28
9.1 DAILYCHECKS ........................................................................................................ 29
10 GUARANTEE/SALES& SERVICE ............................................................................ 30

GB-2
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
2 INTRODUCTION
2.1IMPORTANT
IMPORTANT: This is a precision machine and the service obtained from it depends on the way it is
operatedandmaintained.
ThisSAFETY ANDOPERATORS MANUALshould beregarded aspart ofthe machine. Suppliersof both
newandsecond-handmachinesareadvisedtoretaindocumentaryevidencethatthismanualwasprovided
with the machine.
This machine is designed solely for use in customary grass cutting operations. Use in any other way is
considered as contrary to the intended use. Compliance with and strict adherence to the conditions of
operation,service andrepairas specifiedby themanufacturer, alsoconstitute essentialelements ofthe
intendeduse.
Beforeattempting tooperate thismachine, ALLoperators MUSTreadthrough thismanual andmake
themselvesthoroughlyconversantwithSafetyInstructions,controls,lubricationandmaintenance.
Accidentpreventionregulations,allothergenerallyrecognizedregulationsonsafetyandoccupational
medicine,andall roadtraffic regulations shallbe observedat all times.
Anyarbitrary modificationscarried outonthismachinemay relievethe manufacturerof liabilityfor any
resultingdamageorinjury.
A MachineName
B SerialNumber
C YearofManufacture
D MachineWeight
E EnginePower
2.12 PRODUCTIDENTIFICATION

GB-3
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
3 SAFETY INSTRUCTIONS
This safety symbol indicates important safety
messages in this manual. When you see this
symbol, be alert to the possibility of injury, carefully
readthemessage thatfollows,andinform other
operators.
3.1OPERATINGINSTRUCTIONS
• Ensure that the instructions in this book
arereadandfullyunderstood.
• Nopersonshouldbeallowedtooperate
this machine unless they are fully
acquainted with all the controls and the
safetyprocedures.
• Neverallowchildrenorpeopleunfamiliar
with these instructions to usethis
machine. Local regulations may restrict
theageoftheoperator.
3.2SAFETYSIGNS
• It is essential all safety labels are kept
legible, if they are missing or illegible they
must be replaced. If any part of the
machine is replaced and it originally
carried a safety label, a new label must be
affixedto thereplacement part. New
safetylabelsareobtainablefrom
Ransomesdealers.
3.3STARTINGTHEENGINE
• Before starting the engine check that the
brakesareapplied,drivesareinneutral,
guards are in position and intact, and
bystandersare clearofthe machine.
• Do not run the engine in a building without
adequateventilation.
3.4DRIVINGTHEMACHINE
• Beforemovingthemachine, checkto
ensure that all parts are in good working
order,payingparticularattentionto
brakes, tyres, steering and the security of
cuttingblades.
• Replace faulty silencers, mow only in
daylightor goodartificial light
• AlwaysobservetheHighwayCodebothon
andoff theroads. Keepalertand awareat
all times. Watch out for traffic when
crossingornearroadways.
• Stopthebladesrotatingbeforecrossing
surfacesotherthan grass.
• Rememberthatsomepeoplearedeafor
blind and that children and animals can
beunpredictable.
• Keeptravellingspeedslowenoughforan
emergencystoptobeeffectiveandsafe
at all times, in any conditions.
• Removeoravoidobstructionsinthearea
to be cut, thus reducing the possibility of
injurytoyourselfand/or bystanders.
• Whenreversing, take specialcare to
ensure that the area behind is clear of
obstructionsand/orbystanders. DO
NOTcarrypassengers.
• Keep in mind that the operator or user is
responsibleforaccidentsorhazards
occurringtootherpeople ortheir
property.
• When the machine is to be parked,
storedorleftunattended,lowerthe
cutting means unless the transport locks
arebeingused.
• Whilemowing, alwayswear substantial
footwearand longtrousers. Donot
operatetheequipmentwhenbarefootor
wearingopensandals.
• Checkthegrass catcherfrequentlyfor
wearor deterioration. Afterstriking a
foreignobject. Inspect. the lawnmower
fordamageandmakerepairsbefore
restartingandoperatingtheequipment.
• Ifthe machinestarts tovibrate
abnormally,check immediately.
3.5TRANSPORTING
• Ensure that the cutting units are
securelyfastened inthetransport
position. Do not transport with cutting
mechanismrotating.
• Drivethemachinewithdueconsideration
ofroadand surfaceconditions,inclines
andlocalundulations.
• Suddendeceleratingorbrakingcan
cause the rear wheels to lift.
• Remember that the stability of the rear of
the machine is reduced as the fuel is
used.

GB-4
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
3 SAFETY INSTRUCTIONS
3.6LEAVINGTHEDRIVINGPOSITION
• Parkthemachineonlevelground.
• Beforeleavingthedrivingposition,stopthe
engineandmakesure allmoving partsare
stationary. Apply brakes and disengage all
drives.Removethestarterkey.
3.7SLOPES
TAKEEXTRACAREWHENWORKINGON
SLOPES
• Localundulationsandsinkage willchange
thegeneralslope.Avoidgroundconditions
which can cause the machine to slide.
• Keep machine speeds low on slopes and
duringtight turns.
• Suddendeceleratingorbrakingcancause
the rear wheels to lift. Remember there is
no such thing as a “safe” slope.
• Travelongrassslopesrequiresparticular
care.
DONOTUSEONSLOPESGREATERTHAN15°
IMPORTANT: When working on any slope set the
weight transfer, if fitted to its maximum (+) setting.
3.8BLOCKEDCUTTINGCYLINDERS
• Stopthe engineand makesure allmoving
partsare stationary.
• Applybrakesanddisengagealldrives.
• Release blockages with care. Keep all parts
of the body away from the cutting edge.
Bewareofenergyinthedrivewhichcan
causerotationwhen theblockage is released.
• Keepotherpeople awayfrom the cuttingunits
as rotation of one cylinder can cause the
others to rotate.
3.9ADJUSTMENTS,LUBRICATIONAND
MAINTENANCE
All vehicles
• Stopthe engineand makesure allmoving
partsare stationary.
• Applybrakesanddisengagealldrives.
• Readalltheappropriateservicinginstructions.
• Use only the replacement parts supplied by
theoriginalmanufacturer.
• When adjusting the cutting cylinders take
carenot toget handsand feettrapped when
rotatingcylinders.
• Makesure that otherpeople arenot touching
any cutting units, as rotation of one cylinder
can cause the others to rotate.
• Toreducethefire hazard,keep theengine,
silencerandbatterycompartmentsfreeof
grass,leavesorexcessivegrease.
• Replacewornordamagedpartsforsafety.
• Whenworkingunderneathliftedpartsor
machines,makesureadequate supportIs
provided.
• Do not dismantle the machine without
releasingorrestrainingforceswhichcan
causeparts tomove suddenly.
• Donotalterenginespeedabovemaximum
quoted in Engine Specification. Do not
changetheenginegovernorsettingsor
overspeedtheengine. Operatingtheengine
at excessive speed may increase the hazard
ofpersonalinjury.
• Whenservicingbatteries,DONOT SMOKE,
and keep naked lights away.
• Do not place any metal objects across the
terminals.
Diesel & Petrol vehicles
• Whenrefuelling,STOPTHEENGINE,DO
NOTSMOKE.Add fuelbeforestartingthe
engine,neveraddfuelwhiletheengineis
running.
• Useafunnelwhen pouringfuelfrom acaninto
the tank.
• Do not fill the fuel tank beyond the bottom of
the filler neck.
• Replace all fuel tank and container caps
securely.
• Storefuel incontainersspecifically designed
forthispurpose.
• Refueloutdoors onlyand donot smokewhile
refuelling.
• If fuel is spilled, do not attempt to start the
enginebutmovethemachineawayfromthe
areaofspillageandavoidcreatinganysource
ofignitionuntilfuelvapourshavedissipated.
• Allow the engine to cool before storing in any
enclosure.
• Neverstoretheequipment withfuel inthe
tankinside a buildingwhere fumesmay reach
anopen flameorspark.
• If the fuel tank has to be drained, this should
bedoneoutdoors.
• Do not spill fuel onto hot components.
LPG vehicles
• Only trained & competent personnel in the
useof LPG asa roadvehicle fuelare
allowed to work on LPG aspects of the
vehiclesengineorfuel system.
• Whenrefuelling,STOPTHEENGINE,DO
NOTSMOKE.Add fuelbeforestartingthe
engine,neveraddfuelwhiletheengineis
running.
• Vehicles should not be parked within 3
metersofany heatsource, open flameor
othersourcesof ignition.
• Vehiclesshouldnotbeservicedoveran
inspection pit

GB-5
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
DANGER-Indicatesanimminentlyhazardous
situation which, if not avoided, WILL result in death
orserious injury.
WARNING-Indicatesapotentiallyhazardous
situationwhich, ifnotavoided, COULD resultin
deathor seriousinjury.
CAUTION-Indicatesapotentiallyhazardous
situationwhich, ifnot avoided, MAY resultin minor
ormoderate injuryandproperty damage. Itmay
also be used to alert against unsafe practices.
IMPORTANT: Transport speed is for highway
use only. Never select transport speed on grass
areas or uneven or unsurfaced roads or tracks.
TheoperatingInstructionsfortheCuttingUnitsare
contained in a separate Publication .
• If for any reason a leak in the fuel system
issuspected,thevehicle shouldbemoved
to an isolated area clear of buildings &
peopleand asfar aspossible fromdrains
andanysource ofignition.
• Thefuelfillerbayonetonthevehicleshould
beinspected regularly forany signsof
damage.
• The gas used to fill the vehicle must be
sourcedfromareputablesupplier.
• If a machine starts to vent gas when it is
runningitshould bemoved toanarea
awayfrom anysources ofignition and
stopped. If it vents when static the
machine should not be started, all
potentialsources ofignition shouldbe
inhibiteduntiltheventing hasstoppedand
thelocalRansomesJacobsendealer
shouldbe contacted.
• WherepracticalLPGfuelledvehicles
should be parked in the open air, in a well
ventilated position. Where this is not
reasonably practical due to lack of space,
security ect. vehicles should be parked
insidesuitably designedbuildingsor
garages. Pleaserefer toHELA publication
LACNo.52/6rev
3 SAFETY INSTRUCTIONS

GB-6
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
3 SAFETY INSTRUCTIONS
California Proposition 65
EngineExhaust,someofitsconstituents,
and certain vehicle components contain
or emit chemicals known to the state of
California to cause cancer and birth
defects or other reproductive harm.
WARNING
Batteries produce explosive gases and
contain corrosive acid and supply levels
of electrical current high enough to cause
burns.
WARNING
Battery posts, terminals and related
accessories contain lead and lead
compounds
WASHHANDSAFTERHANDLING
WARNING
Hydraulic Fluid escaping under pressure
can penetrate skin and do serious
damage. Immediate medical assistance
mustbesought.
WARNING
DONOTUSEONSLOPESGREATERTHAN15°
WARNING
VENTINGGASCANCAUSEFROSTBITE
WARNING
Cutting Unit Transport Latches are a
Secondary Safety Devise.
When Transporting the machine the
Cutting units should be held in the
Transport position on the Hydraulics with
the Transport Latches Engaged.
1. Park the machine on level ground.
2. Whilst seated in the driving position
With the engine at operating speed
raise the cutting units fully by
operating lift levers, return the lever to
the neutral position.
DO NOT move the lever into the
lower position.
3. Disengage drives, stop the engine and
make sure all moving parts are
stationary. Apply brakes and remove
the starter key.
4. Transport latches can now be engaged
or released.
Before releasing transport latches
it is important that all cutting units
are fully raised.
WARNING

GB-7
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
3.10 GUIDELINESFORTHEDISPOSAL
OFSCRAPPRODUCTS
When it has been identified that a turf care
product has no further functional value and
requires disposal, the following actions should
betaken.
These guidelines should be used in
conjunction with applicable Health, Safety and
Environmental legislation and use of approved
local facilities for waste disposal and recycling.
• Position the machine in a suitable
location for any necessary lifting
equipment to be used.
• Use appropriate tools and Personal
Protective Equipment (PPE) and take
guidance from the technical manuals
applicable to the machine.
• Remove and store appropriately:
1. Batteries
2. Fuel residue
3. Engine coolant
4. Oils
• Disassemble the structure of the
machine referring to the technical
manuals where appropriate. Special
attention should be made for dealing
with ‘stored energy’ within
pressurised elements of the machine
or tensioned springs.
• Any items that still have a useful
service life as second hand
components or can be re-serviced
should be separated and returned to
the relevant centre.
• Other worn out items should be
separated into material groups for
recycling and disposal consistent with
available facilities. More common
separation types are as follows:
• Steel
• Non ferrous metals
• Aluminium
• Brass
• Copper
• Plastics
• Identifiable
• Recyclable
• Non recyclable
• Notidentified
• Rubber
• Items that cannot be separated
economically into different material
groups should be added to the
‘General waste’ area.
• Do not incinerate waste.
Finally update machinery records to indicate
that the machine has been taken out of service
and scrapped.
3 SAFETY INSTRUCTIONS

GB-8
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
4 SPECIFICATIONS
4.3 DIMENSIONS
Width of cut: 2.14metres
Transportwidth: 1.6 metres
Overallheight: 1.58metres
Overalllength: 2.68metres
Overallweightof
machine:
Diesel 1360*Kg
LPG 1388*Kg
* With 6 knife fixed head magna units, full fuel tank,
andoptionalLighting andBeacon kits
WheelTrack: 1.6metres
Wheel Base:1.5metres
UncutCircle:0.75 metres Radius
4.1 ENGINESPECIFICATION
TYPE: Kubota 28Kw @3000rpm, 4
cylinder(in-line)verticalDiesel
engine,4-stroke,watercooled,
1498cc, with 12v electric start.
Model: V1505-BBS-EC-1
MaximumSpeed: 3000+/-50RPM(Noload)
IdleSpeed: 1500+100/ -0RPM
Oil Sump Capacity:6.4 litres
Fuel: No.2-DDieselfuel(ASTMD975)
CoolantCapacity: 5litres 50/50 Anti-freeze
CoolantSpecification:
Ethyleneglycolanti-freezewith
softenedwater.
4.1.2 LPG
TYPE: Ford25Kw@3000rpm,4
cylinder(in-line)verticalPetrol
engine,4-stroke,watercooled,
1297cc, with 12v electric start.
Model: VSG413
MaximumSpeed: 3150±50RPM(Noload)
IdleSpeed: 850 ± 50 RPM
Oil Sump Capacity: 3.1litres
Fuel: LPG(Propane)
CoolantCapacity: 5litres50/50Anti-freeze
CoolantSpecification: Ethyleneglycolanti-freezewith
softenedwater.
4.2 MACHINESPECIFICATION
Frameconstruction:Heavy dutyformedsteel chassis.
Transmission: Hydrostaticpowerprovidedbya
servo-controlledtransmission
pump.Driving4indivdualwheel
motorswithapatentedparallel/
series transmission system.
Selectableforwardallwheeldrive
lockandreversefrontaxlediff
lock facility.
Cuttingunitdrive: Hydraulic,withforward,neutral,
reversecontrolvalve.Electric
dashmountedswitchforon/off
control,withfloor mountedswitch
forcyclinderengage.Handcontrol
valveforreelspeedadjustment
Speeds:
Cutting: 12 km/h
Transport: 25 km/h
Reverse: 6 km/h
Steering: Hydrostaticpoweredsteeringto
rearwheels.
Tyres:
Front- 26 x 12 -12 Dico Multi-Trac
Rear- 20 x 10 - 8 Multi-Trac
Pressures: All tyres 1.0 kg/cm
Groundpressure: 1.0 kg/cm
Brakes,Service: Positivehydrostaticbraking.
Parking: Fail safe, Oil immersed wet disc
brakes.
FuelTank
CapacityDiesel: 45Litres
CapacityLPG: 72 Litres
HydraulicTank
Capacity: 35Litres
Battery: Exide093

GB-9
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
StandardISO2631-1:1985Evaluationofhuman
exposuretowholebodyvibration--Part1:General
requirements.
sulP0522yawkraP BWseireS noitareleccAmrA/dnaH level
HRroHLxaM
s/msnoitareleccA
2
qeAXqeAYqeAZ
643,0493,0733,0
eulaVtnanimoD 493,0
0522yawkraP sulP BWseireS ydoBelohW noitareleccA level
noitacoLroolF
s/msnoitareleccA
2
noitacoLtaeS
s/msnoitareleccA
2
xyzxyz
naeM3520.00020.00070.09120.05210.03520.0
4.4 VIBRATION
Themachinewastestedforwholebodyandhand/arm
vibrationlevels. Theoperatorwasseatedinthe
normaloperatingpostionwithbothhandsonthe
steeringmechanism. Theenginewasrunningandthe
cuttingdevicewasrotating withthemachine
stationary.
StandardISO 5349: 1986 Mechanicalvibration.
Guidelinesforthemeasurementandthe
assessmentofhumanexposuretohand-transmitted
vibration
4.7CUTTINGPERFORMANCE
45 cuts per meter at 12 km/hr with 8 knife floating
headunits.
62 cuts per meter at 12km/hr with 11 knife floating
headunits.
23 cuts per meter at 12 km/hr with 4 knife fixed head
units.
34 cuts per meter at 12 km/hr with 6 knife fixed head
units.
4.8CUTTINGPERFORMANCE(AREA)
2.3 Hectares/hour at 12 km/hr with float head units.
2.3 Hectares/hour at 12 km/hr with fixed head units.
A10%allowanceisincludedfornormal overlapsand
turning at the end of each cut.
4.5 SLOPES
DONOTUSEONSLOPESGREATERTHAN15°
The slope 15° was calculated using static stability
measurementsaccordingtotherequirementsof
EN836.
4.6 RECOMMENDEDLUBRICANTS
Engineoil: ShouldbetoMIL-L-2104Corto
A.P.I. Classification SE/SF/SG
grades.[10W-30]
HydraulicOil: Shell Tellus 46 to ISO VG46, or
equivilant
Grease: ShellDarinaR2,orequivilant
ERUTAREPMETYTISOCSIVLIO
)F°93(C°4EVOBA03EAS
)F°93(C°4WOLEB03-W01ro03-W5EAS

GB-10
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
4 SPECIFICATIONS
4.9 CONFORMITYCERTIFICATES
EC Declaration of Conformity  Déclaration de Conformité CE 
EG Conformiteits-Declaratie  EG-Konformitatsbescheinigung 
Certificato di Conformità CE  EF Konformitetserklæring
E ppfyllandecertifikat  Ilmoitus yhdenmukaisuudesta ey:n sääntöjen kanss 
Declaración de Conformidad de la CE  Declaração de Conformidade da CE
We the undersigned  Nous, soussignés  Wij, ondergetekenden  Wir, die Unterzeichnenden  Noi sottoscritti Undertegnede 
Undertecknarna  Me allekirjoittaneet  Los abajo firmantes  Nós, abaixo assinados
Ransomes Jacobsen Limited
Central Avenue, Ransomes Europark,
Ipswich, England, IP3 QG
eclare that the machine escribed Below  Certifions que la machine suivante  verklaren dat onderstaand beschreven machine 
erklären, dass die nachfolgend beschriebene Maschine  ichiariamo che la macchina descritta di seguito  Erklærer, at følgende maskine 
eklarerar att den maskin som beskrivs nedan  vahvistamme, että alla kuvattu kone  Certificamos que la máquina descrita abajo 
declaramos que a máquina a seguir descrita
Make & Type  Nom & Type  Merk & Type  Marke und Typ  Marca e tipo 
Fabrikat og type  Fabrikat & typ  Malli ja tyyppi  Marca y Tipo  Marca & Tipo .............. Ransomes Parkway 2250 Plus
Category  Modèle Categorie  Kategorie  Categoria  Kategori  Luokka 
Categoría  Categoria ......................................................................................................... Ride on Cylinder Mower
Series  Série  Serie  Sarja .............................................................................................. WB / CT
Engine  Motor  Moteur  Motore  Moottori ....................................................................... Kubota / Ford
Type  Typ  Tipo  Tyyppi .................................................................................................. V1505-E / VSG413
Net Installed Power  Puissance nette  Netto geïnstalleerd vermogen 
installierte Antriebsleistung  Potenza installata netta  Nettoeffekt installere 
Installerad nettoeffekt  Asennettu nettoteho  Potencia instalada neta 
Potência real instalada ....................................................................................................... 28KW / 25KW
Cutting Width  Largeur de coupe  Maaibreedte  Schnittbreite 
Larghezza di taglio  Klippebredde  Klippbredd  Leikkuuleveys 
Anchura de corte  Potência real instalada ....................................................................... 214cm
Complies with the provisions of the following European directives and amendments and the regulations transposing it into national law 
Est conforme aux prescriptions des normes, modifications et règles européennes suivantes  voldoet aan de bepalingen van de volgende
Europese Richtlijnen en Amendementen, alsmede aan de verordeningen die deze omzetten in nationale wetgeving  den Bestimmungen der
folgenden Europa-Richtlinien einschließlich aller Änderungen und Ergänzungen sowie den Vorschriften, die diese in das nationale Recht
umsetzen, entspricht  soddisfa quanto previsto dalle seguenti direttive ed emendamenti europei e dalle normative che li riportano in legge
nazionale  Overholder bestemmelserne i følgende EF-direktiver med ændringer og i de forordninger, hvorved de omsættes til national lov 
Uppfyller kraven i följande europeiska direktiv med tillägg och regler transponerade till nationell lagstiftning  täyttää seuraavana mainittujen
Euroopan direktiivien ja muutosten ja säännösten asettamat edellyt
Machinery Safety irective  irective de sécurité des machines 
Richtlijn Machineveiligheid  Richtlinie zur Maschinensicherheit 
irettiva sulla sicurezza del macchinario  Maskinsikkerhedsdirektivet 
Maskinsäkerhetsdirektiv  Koneen turvallisuutta koskeva direktiivi 
irectiva de seguridad de maquinaria  irectiva de segurança de máquinas ................ 8/37/EC
EMC irective  irective de compatibilité électromagnétique  EMC Richtlijn 
EMK-Richtlinie  irettiva EMC  EMC-direktivet  Elektromagnetiskt kompatibilitetsdirektiv 
EMC-direktiivi  irectiva EMC ............................................................................................. 8 /336/EC
ROPS irective  irective de ROPS  ROPS Richtlijn  ROPS-Richtlinie 
irettiva ROPS  ROPS-direktivet  ROPS direktiv  ROPS-direktiivi  irectiva ROPS ...... 86/2 8/EC
Noise in the Environment irective  irectiv  Richtlijn Milieulawaa 
Richtlinie zum Umgebungslärm  irettiva sulla rumorosità nellambiente 
Støjemissionsdirektivet  Bullerdirektiv  Melu ympäristöä koskevassa direktiivissä 
irectiva sobre ruido en el ambiente  irectiva Ruído no Ambiente ................................ 2000/14/EC
Measured Sound Power Level  Niveau de puissance sonore assuré 
Gegarandeerd geluidsvermogenniveau  Garantierter Schallleistungspege 
Livello di potenza del suono misurato  Målt lydeffektniveau  Uppmätt ljudfraftsnivå 
Mitattu åånitehon taso  Nivel de Potencia Sonora  Nívelde intensidade de som medido .. 101 dB(A) LWA
Guaranteed Sound Power Level  Niveau de puissance sonore assuré 
Gegarandeerd geluidsvermogenniveau  Garantierter Schallleistungspege 
Livello di potenza del suono misurato  Garanteret lydeffektniveau 
Garanterad ljudtrycksnivå  Taattu äänitehon taso  Nivel Garantizado de Potencia Sonora 
Nível garantido de intensidade sonora .............................................................................. 105 dB(A) LWA

GB-11
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
Conformity Assessment Procedure  Procédure de conformitéévaluation  Conformiteitsbeoordelingsprocedur  Verfahren zur Beurteilung
der Konformität  Procedura di valutazione conformità  Procedure for overensstemmelsesvurdering  Procedur för utvärderande av
uppfyllande  Yhdenmukaisuuden arviointiproseduuri  Procedimiento de evaluación de conformidad  Processo de avaliação de
conformidade
Annex VI, Part 1 Annexe VI, Part 1  Bijlage VI, Part 1  Anlage VI, Part 1  Allegato VI, Part 1  Anneks VI, Part 1  Annex VI,
Part 1  Liite VI, Part 1  Anexo VI, Part 1  Anexo VI, Part 1
U.K. Notifiable Body (No.1088)  Institut britannique à notifie(No.1088)r  Britse onderzoeksinstantie (No.1088)  in GB zu informierende
Institution (No.1088)  Ente notificabile Gran Bretagna  (No.1088)  Organ, som skal underrettes (No.1088)  Brittiskt meddelandeorgan
(No.1088)  Ison-Britannian ilmoitusosapuoli (No.1088)  Cuerpo notificable en el Reino Unido (No.1088)  Entidade a notificar no Reino
Unido ( No.1088)
Sound Research Laboratories Limited
Holbrook House, Little Waldingfield
Sudbury, Suffolk CO10 0TH
Operator Ear Noise Level  Bruit au niveau des oreilles de lopérateur 
Geluidsniveau op oorhoogte bediener  Schallpegel am Ohr des Fahrers 
Livello rumorosità orecchio operatore  Støjniveau ved betjening 
Bullernivå vid operatörens öron  Käyttäjän korvaan kohdistuva äänitaso 
Nivel de ruido en el oido del operari  Nível de ruído nos ouvidos do operador ............... 85.3 dB(A)Leq ( 8/37/EC)
Complies with the following harmonised standard or technical provisions  est conforme aux normes harmonisées  Voldoet aan de
volgende geharmoniseerde norm of technische bepalingen  iese Maschine entspricht den folgenden harmonisierten Normen oder
technischen Bestimmungen  Rispetta il seguente standard armonizzato o requisiti tecnici  Overholder følgende harmoniserede
standardbestemmelser eller tekniske bestemmelser  Uppfyller följande harmoniserade standard eller tekniska definitione  täyttää
seuraavat harmonisoidut standardit tai tekniset edellytykset  Cumple con los siguientes estándares de hramonización o provisiones
técnicas  Está em conformidade com a norma harmonizada ou com as provisões técnicas seguintes
Machinery Safety  Sécurité des machines  Machineveiligheid 
Maschinensicherhei  Sicurezza del macchinario  Maskinsikkerhed 
Maskinsäkerhet  Koneen turvallisuus  Seguridad de maquinaria 
Segurança de máquinas .................................................................................................... EN836
Hand Transmitted Vibration  Vibrations transmises aux mains 
Via de hand overgebrachte trilling  Auf das Hand-Arm-System übertragene Schwingungen 
Vibrazione trasmessa dalla mano  Håndoverført vibration 
Handöverförda vibrationer  Käsivälitteinen tärinä  Vibración transmitida a la mano
 Vibrações transmitidas através das mãos ..................................................................... ISO 534 : 1 86
Whole Body Vibration  Vibrations du corps entier  Trilling hele lichaam 
Auf den gesamten Körper übertragene Schwingungen  Vibrazione di tutto il corpo 
Vibration i hele kroppen  Hel kropps vibrationer  Koko kehoon kohdistuva tärinä 
Vibración de todo el cuerpo  Vibração em todo o corpo ................................................. ISO 2631-1: 1 85
ROPS .................................................................................................................................. OECD Code 4, ROPS Static Test
Keeper of Technical File, Place & ate of eclaration  Lieu & ate de déclaration  Plaats & datum verklaringsaflegging  Ort und atum
dieser Erklärung  Luogo e data della dichiarazione  Sted og dato for erklæringen  Plats & datum för deklaration  Lausunnon paikka ja
päivämäärä  Lugar y fecha de la declaración  Local e data da declaração
Technical irector
Ransomes Jacobsen Limited
Central Avenue, Ransomes Europark,
Ipswich, England, IP3 9QG
01.01.2004
T Lansdell
Technical irector
Certificate Number  Numéro du certificat  Certificaatnummer  Zertifikat Nummer 
Numero certificato  Certifikatnummer  Certifikat nummer  Sertifikaattinumero 
Número de certificado  Número do Certificado 4117927 (Rev.3)
4 SPECIFICATIONS

GB-12
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
5 DECALS
5.2 INSTRUCTIONDECALS
1 SpeedLimiterPosition
2 CentreCuttingUnitLatch
3 Bonnet latch Point
4 HydraulicOilFilter
5 ParkingBrakeOn/Off
6 Horn
7 HydraulicOilLevel
9 TractionFootPedalControl
10 Unit GroundWeightAdjustment
11 ThrottleLever
12 Tyrepressure
13 CylinderSpeedAdjustment
14 CylinderEngageFootSwitch
15 CylinderEngageRockerSwitch
16 IgnitionSwitch
18 Jacking Points
19 HydraulicOilTank
20 DieselFuelTank
22 Lift Points
5.1SAFETYDECALS
A903491 ReadOperator'sManual.
A903489 Keepa Safe Distancefrom the
Machine.
A903492 StayClearof HotSurfaces.
A903488 DoNotOpenorRemoveSafety
Shields While the Engine is Running.
A903494 CautionRotatingBlades.
A903493 AvoidFluidEscapingUnderPressure.
ConsultTechnical ManualforService
Procedures.
A903490 DoNotRemoveSafetyShields While
EngineisRunning.
A911410 DangerofExplosion ifthe Battery
TerminalsareShortCircuited.
A911416 Maximumpermitableworkingslope.
A911434 CautionDieselfuel.

GB-13
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
6 CONTROLS
6 CONTROLS
6.1STARTERKEYSWITCH
Thestarterkey(A) shouldbe turnedclockwisetothe'pre-
heat'(No.2)positiontoheattheglowplugswhenthegreen
warninglampgoesoutonwarninglampdisplymoduleturn
thestarterkeyclockwisetothe'start'(No.3)positiontostart
theengine.After starting,the keyshouldbe releasedand
allowedtoreturnautomaticallytothe'on'(No.1)positionfor
normalrunning.
6.2THROTTLECONTROLLEVER
Thelever (B)shouldbe movedawayfromtheoperator to
increase the engine speed and towards the operator to
decreasetheenginespeed.
NOTE:Engineshouldbeusedatfullspeed.
6.4TRACTIONFOOTPEDAL
Tomovethemachineforwardpressthefrontofthefoot
pedal(A).Toreversedepresstherearofthefootpedal.
Whenthe pedalis releaseditwillreturnto itsneutral
position.
6.5SPEEDLIMITER
Thespeedlimiter(B) isoperated byslidingtheblack
knob to the right or left. When slid to the right the
machine is limited to cutting speed, when slid to the left,
transportspeedisavailable.Intransportmode,reverseis
notavailable.Whenthe speedlimiterisinthe mowspeed
positionfourwheeldriveisengaged.
IMPORTANT: To enable mow engage the speed
limiter must be in the cutting speed position. If
cutting units are rotating, moving the speed limiter
between the mow and transport positions will
engage and disengage cylinder rotation.
6.3STEERINGWHEELRAKEADJUSTMENT
The steering wheel is adjustable for rake. The clamping
releaseknob(A)issituatedonthesideofthecontrolconsole
on the right hand side. To adjust turn the clamping knob
anticlockwise to release and pivot the steering wheel
backwardsandforwardstoobtaindesiredsettingthenlock
inposition byturning clampingknob clockwise.

GB-14
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
6 CONTROLS
6.6TRANSPORTLATCHES
Whentransporting themachine ensurethecutting
units are raised and the transport latches (A) are
engaged.
6.7PARKINGBRAKES
Theparkingbrake(B)isengagedwhentheleveris
movedtowardtheoperator. Thebrakeisfittedwitha
micro switch that sensors brake position. The brake
must be applied to start the machine, and when
stoppingandleavingtheseat.
CAUTION:- The parking brake must not be
applied whilst the vehicle is moving.
6.8HYDRAULICLIFTLEVERS
The cutting units can be raised and lowered by three
controllevers(A)situatedontherighthandsideofthe
operatorsseat andcanbe operatedas follows:
CentrelevercontrolsRearUnitNo.1
Righthand levercontrols R.H.Unit No.2
Lefthand levercontrols L.H.Unit No.3
NOTE:Ifanyunitisraisedoutofworkthenloweredinto
workagainthecylinderwillnotrotateuntilthemowfoot
switch is depressed.
Tolift:Movethelever(s)upwardsandholdinposition
until the units are at the required height.
Tolower:Movethelever(s)fullydownwardsandrelease,
theunit(s)willlowertogroundlevel.DONOTholdlever
indownposition.
NOTE:Theunitswillonlyliftandlowerwhentheengine
isrunning.
IMPORTANT: If, when cutting, a lift control lever is
accidentlypulledup,thecuttingunitswillnotfloatover
groundundulationsuntiltheleverispushedfullydown
andallowedtoreturntoneutralagain.
6.9UNITCOUNTERBALANCECONTROL
Cuttingunitgroundpressurecanbevariedwithin
preset limits and is controlled by the handwheel (B)
on the right hand side of the operator's seat located
nexttothelift/lowerlevers.Thehandwheelisturned
clockwisetoreduce thegroundweight of thecutting
unit,improving slopeclimbingability.
Thehandwheel isturned anticlockwisetoincrease
thegroundweightoftheunit.Increaseddown
pressure will reduce the likelyhood of cutting unit
bouncewhencuttingundulatingground.When
cuttinglevel ground thenormal settingis midway
way between the maximum and minimum positions.

GB-15
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
6 CONTROLS
6.10CUTTINGUNITSWITCHES
To commence cutting ensure speed limiter is in
mowpositionand thecylinders havebeenlowered
Push bottom of the rocker switch (A) and depress
foot switch (B) Push top of rocker switch to stop
cutter unit rotation. (Cutting units stop rotating
automaticallywhenraised.)
NOTE: The backlapping lever must be in the
drive position before cylinders wil rotate.
6.11VARIABLECYLINDERSPEED
Thespeedofrotationofthecuttingcylindersisadjustable
bymeansofthehandwheel(A)situatedonthelefthand
side of the operator. Cylinder speed should be set to
maximum in normal cutting conditions. In very long
growthconditions,cylinderspeedshouldbereducedto
obtainbestfinish,cylinderspeedshouldalsobereduced
whencuttingveryshort,drygrasstopreventexcesive
cylinderandbottombladewear.Rotatethehandwheel
clockwisetoincreasecylinderspeed,anticlockwiseto
decreasecylinderspeed.
6.12BACKLAPPINGLEVER
Thelever(B)sets cuttingcylinderrotational direction
withthreepositions:
(a)fully towards theseat formowing, (b) fullyaway
from the seat for backlapping and (c) set in the mid
position for neutral. See the separate cutting unit
operator'smanualforanexplanationofthe
backlappingprocedure.

GB-16
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
6.13INSTRUMENTPANEL
A. ENGINEPREHEATINDICATORLAMP
Colourgreen,onwhen theignition switchis turned
clockwise to the pre-heat position. Once the lamp
goesoutthe enginecan bestarted.
B. ENGINETEMPARATUREGUAGE
Indicatescurrenttemparatureofengine,whilst
running.
C. ENGINEOVERHEATWARNINGLAMP
Colourred,onwhentheenginetemperaturereachesa
presetlevel. If thelampcomes on anda warninghorn
is sounded bring to machine to a stop, disengage the
cuttingcylinders, applythe parkingbrakeand allow
theengine tocoolby runningthe engineathalf speed
fortwominutesbeforestoppingandinvestigatingthe
cause.
D. CHARGINGWARNINGLAMP
Colourred,onwhenignitionisswitched onandwillgoout
whenthe engineis started. Ifthelight comesonwhile
theengineisrunning,thefanbeltmaybeslippingor
broken or a fault in the electrical system is indicated and
shouldbeinvestigated. STOPIMMEDIATELY.
E. ENGINEOILPRESSUREWARNINGLAMP
Colourred,onwhentheignition isswitchedon,andwill
goout oncethe enginehas started. Ifthelightcomeson
whiletheengineisrunning-STOPIMMEDIATELYas
this indicates that the engine oil pressure is too low.
Checkthe levelof oilin thesumpand topup as
necessary. Checkthe oilpressuresender switch.
Continuedoperationmaycauseextensivedamagetothe
engine.
F. ROTATINGBEACON
Press the bottom half of the switch to activate the
flashingbeacon.(Wherefitted)
G. HEADLIGHT/SIDELIGHT
Depress the bottom half of the switch to turn on the
headlightsandsidelights.(Wherefitted)
H. DIRECTIONALINDICATORS
Depress left hand-side of switch to signal left, and
right hand-side of switch to signal right. (Where
fitted)
I. HAZARDWARNINGLIGHTS.
Press the top half of the switch to turn on the hazard
warninglights.(Wherefitted)

GB-17
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
J. BLOCKEDHYDRAULICFILTER
INDICATOR.
MonitorsHydfiltercondition.Coluredred,
Illuminatespriortofilterbypassvalveoperating,
whenilluminatedfilterrequireschanging.Thelamp
shouldilluminated whiletheengine ispreheatingas
a test. It is not unusual for the lamp to stay light for
up to 3 minutes after a very cold start. But should
not stay on for longer than 5 minutes.
K. HOURMETER
Locatedon thelefthand sideof thesteering tower,
abovetheparkingbrake.Recordsenginerunning
hours.
L. FUELGUAGE
Locatedtothe leftof theengine temparatureguage.
Monitorsfuellevel.
M. HORN
Press button to sound horn.
6.14DIFFLOCKCONTROL
TheDifflock (A)is operatedby depressing thefoot
switch. When the foot switch is released the Diff
Lock ceases to operate. The Diff Lock should only
beusedinseveresituations,andshouldneverbe
used on tarmac or whilst steering

GB-18
RANSOMES PARKWAY 2250 PLUS
SAFETY AND OPERATORS MANUAL
7 OPERATION
The daily inspection should be performed
only when the engine is off and all fluids
are cold. Lower implements to the
ground, engage parking brake, stop
engine and remove ignition key.
CAUTION
7.1DAILYINSPECTION
1. Perform a visual inspection of the entire unit, look for signs of wear, loss hardwear and missing or
damaged components. Check for fuel and oil leaks to ensure connections are tight and hoses and
tubesare in goodcondition.
2. Check the fuel supply, radiator coolant level, crankcase oil level and air cleaner indicator. All fluids
must be at the full mark with the engine cold.
3. Make sure all cutting units are adjusted to the same height of cut.
4. Checkall tyresforproper inflation.
5. Test the operator presence and safety interlock system.
