THERMOROSSI BOSKY COUNTRY 30 EVO5 Installation and operating instructions

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 0
ITA - Informazioni importanti per la sicurezza ed il corretto funzionamento.
FRA - À lire impérativement ! Informations importantes pour la sécurité et le bon fonctionnement.
ENG - Must read! Important information for safety and correct operation.
DEU - Unbedingt lesen! Wichtige Informationen zur Sicherheit und zum sicheren Betrieb.
ESP - ¡Leer! Informaciones importantes para la seguridad y el correcto funcionamiento.
BOSKY COUNTRY 30 EVO5
BOSKY COUNTRY F30 EVO5
ITA - MANUALE DI INSTALLAZIONE, USO E MANUTENZIONE.
FRA - MANUEL D’INSTALLATION, D’UTILISATION ET D’ENTRETIEN.
ENG - INSTALLATION, USE AND MAINTENANCE GUIDE.
DEU - INSTALLATIONS-, BETRIEBS- UND WARTUNGSANLEITUNG.
ESP - MANUAL DE INSTALACIÓN, USO Y MANTENIMIENTO.

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 1

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 2
INDEX
1 –INTRODUCTION.................................................................................................................................. 6
2 –TECHNICAL CHARACTERISTICS...................................................................................................... 8
3 –GENERAL DESCRIPTION.................................................................................................................10
4 –INSTALLATION..................................................................................................................................13
5 –PLUMBING SYSTEM CONNECTIONS AND DIAGRAMS .................................................................14
6 –ASSEMBLING THE COMPONENTS..................................................................................................18
7 –USE OF THE APPLIANCE.................................................................................................................21
8 –CLEANING AND MAINTENANCE .....................................................................................................25
9 –SMOKE DISCHARGE TUBE..............................................................................................................27
10 –PROBLEMS, CAUSES AND SOLUTIONS.......................................................................................30
EU Declaration of Conformity (DoC) / Dichiarazione di Conformità UE (DoC)
Company name:
Azienda:
THERMOROSSI S.P.A.
Postal address:
Indirizzo:
VIA GRUMOLO, N° 4
Postcode and city:
Codice postale e città:
36011 ARSIERO (VI)
Telephone number:
Numero di telefono:
0445/741310
E-mail address:
Indirizzo e-mail:
[email protected]
declare that the DoC is issued under our sole responsibility and belongs to the following product:
dichiara che la dichiarazione viene rilasciata sotto la propria responsabilità e si riferisce al seguente prodotto:
Apparatus model / Product:
Descrizione prodotto:
WOOD STOVE
STUFA A LEGNA
Trademark:
Marchio:
THERMOROSSI S.P.A.
Models:
Modelli:
BOSKY COUNTRY 30 EVO –BOSKY COUNTRY F30 EVO
BOSKY COUNTRY 30 EVO5 –BOSKY COUNTRY F30 EVO5
The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:
L'oggetto della dichiarazione di cui sopra è conforme alla pertinente normativa di armonizzazione dell'Unione:
•Direttiva 2014/30/UE, EMCD
•Direttiva 2014/35/UE, LVD
•Direttiva 2011/65/UE, RoHS
•2014/30/EU Directive, EMCD
•2014/35/EU Directive, LVD
•2011/65/EU Directive, RoHS
Sono state applicate le seguenti norme armonizzate e/o specifiche tecniche:
The following harmonised standards and/or technical specifications have been applied:
EN 55014-1
EN 55014-2
EN 61000-3-2
EN 61000-3-3
EN 60335-1
EN 60335-2-102
EN 62233
EN 50581
EN 13240 tests carried out by the notified laboratory Kiwa Cermet Italia S.p.a (N.B. 0476) Viale Venezia, 45 31020 San
Vendemiano (TV).
Arsiero, 10/03/2023
Firma/Sign.

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 3
DICHIARAZIONE DI PRESTAZIONE IN ACCORDO CON IL REGOLAMENTO (UE) 305/2011
DECLARATION OF PERFORMANCE ACCORDING TO REGULATION (EU) 305/2011
N° 93
1
Codice di identificazione unico del prodotto-tipo: BOSKY COUNTRY 30 EVO
Unique identification code of the product type:
2
Modello, lotto, serie ai sensi dell'articolo 11, paragrafo 4: BOSKY COUNTRY 30 EVO
Model, batch or serial number required under Article 11(4):
3
Usi previsti del prodotto da costruzione, conformemente alla relativa specifica tecnica armonizzata:
Intended uses of the construction product, in accordance with the applicable harmonised technical specification:
Apparecchio per il riscaldamento domestico, con acqua, alimentato a ceppi di legna / Residential space heating appliance with water fired by wood logs
4
Nome registrato e indirizzo del fabbricante ai sensi dell'articolo 11, paragrafo 5:
Name and contact address of the manufacturer as required pursuant to Art. 11 (5):
THERMOROSSI S.P.A. Via Grumolo, n° 4 36011 Arsiero (Vicenza)
5
Nome e indirizzo del mandatario ai sensi dell’articolo 12, paragrafo 2:
Name and address of the agent as required pursuant to Article 12 (2):
-
6
Sistema di valutazione e verifica della costanza della prestazione del prodotto da costruzione di cui all'allegato V: Sistema 3
System of assessment and verification of constancy of performance of the construction product as set out in Annex V: System 3
7
Laboratorio notificato: Notified laboratory:
KIWA CERMET ITALIA S.p.A. N° 0476
Numero del rapporto di prova secondo il sistema 3 / Test report number based on System 3:
3003511
8
Prestazione dichiarata / Declared performance
Specifica tecnica armonizzata/Harmonized technical specification:
EN 13240:2001
Caratteristiche Essenziali / Essential characteristics
Prestazione / Performance
Reazione al fuoco / Reaction to fire
A1
Distanza da materiali combustibili
Distance to combustible materials
Minime distanze / Minimum distances (mm):
posteriore/rear = 300 lati/sides = 300 frontale / front = 800
soffitto/ceiling = - pavimento / floor = -
Rischio di fuoriuscita di braci incandescenti / Risk of burning fuel falling out
Conforme /Compliant
Temperatura superficiale/Surface temperature
Conforme /Compliant
Sicurezza elettrica / Electrical safety
-
Pulizia / Cleanability
Conforme /Compliant
Emissione di prodotti della combustione /Emission of combustion products
CO = 891 mg/m3a potenza termica nominale / CO at Nominal heat output
Pressione massima di esercizio / Maximum operating pressure
2.5 bar
Temperatura fumi a potenza termica nominale / Flue gas temperature at nominal heat output
T 178 °C
Resistenza meccanica (per sopportare il camino) / Mechanical resistance (to carry a
chimney)
NPD {No Determined Performance}
Potenza termica nominale / Nominal heat output
Potenza termica resa in ambiente / Room heating output
Potenza termica ceduta all’acqua / Water heating output
17.90 kW
7.66 kW
10.24 kW
Rendimento / Efficiency
88.19% alla potenza termica nominale / Nominal heat output
9
La prestazione del prodotto di cui ai punti 1 e 2 è conforme alla prestazione dichiarata di cui al punto 8. Firma/Signature:
Si rilascia la presente dichiarazione di prestazione sotto la responsabilità esclusiva del fabbricante di cui al punto 4.
The performance of the product identified in points 1 and 2 is in conformity with the declared performance in point 8.
This declaration of performance is issued under the sole responsibility of the manufacturer identified in point 4.
Arsiero, 10/11/2019
DICHIARAZIONE DI PRESTAZIONE IN ACCORDO CON IL REGOLAMENTO (UE) 305/2011
DECLARATION OF PERFORMANCE ACCORDING TO REGULATION (EU) 305/2011
N° 94
1
Codice di identificazione unico del prodotto-tipo: BOSKY COUNTRY F30 EVO
Unique identification code of the product type:
2
Modello, lotto, serie ai sensi dell'articolo 11, paragrafo 4: BOSKY COUNTRY F30 EVO
Model, batch or serial number required under Article 11(4):
3
Usi previsti del prodotto da costruzione, conformemente alla relativa specifica tecnica armonizzata:
Intended uses of the construction product, in accordance with the applicable harmonised technical specification:
Apparecchio per il riscaldamento domestico, con acqua, alimentato a ceppi di legna / Residential space heating appliance with water fired by wood logs
4
Nome registrato e indirizzo del fabbricante ai sensi dell'articolo 11, paragrafo 5:
Name and contact address of the manufacturer as required pursuant to Art. 11 (5):
THERMOROSSI S.P.A. Via Grumolo, n° 4 36011 Arsiero (Vicenza)
5
Nome e indirizzo del mandatario ai sensi dell’articolo 12, paragrafo 2:
Name and address of the agent as required pursuant to Article 12 (2):
-
6
Sistema di valutazione e verifica della costanza della prestazione del prodotto da costruzione di cui all'allegato V: Sistema 3
System of assessment and verification of constancy of performance of the construction product as set out in Annex V: System 3
7
Laboratorio notificato: Notified laboratory:
KIWA CERMET ITALIA S.p.A. N° 0476
Numero del rapporto di prova secondo il sistema 3 / Test report number based on System 3:
3003511
8
Prestazione dichiarata / Declared performance
Specifica tecnica armonizzata/Harmonized technical specification:
EN 13240:2001
Caratteristiche Essenziali / Essential characteristics
Prestazione / Performance
Reazione al fuoco / Reaction to fire
A1
Distanza da materiali combustibili
Distance to combustible materials
Minime distanze / Minimum distances (mm):
posteriore/rear = 300 lati/sides = 300 frontale / front = 800
soffitto/ceiling = - pavimento / floor = -
Rischio di fuoriuscita di braci incandescenti / Risk of burning fuel falling out
Conforme /Compliant
Temperatura superficiale/Surface temperature
Conforme /Compliant
Sicurezza elettrica / Electrical safety
-
Pulizia / Cleanability
Conforme /Compliant
Emissione di prodotti della combustione /Emission of combustion products
CO = 891 mg/m3a potenza termica nominale / CO at Nominal heat output
Pressione massima di esercizio / Maximum operating pressure
2.5 bar
Temperatura fumi a potenza termica nominale / Flue gas temperature at nominal heat output
T 178 °C
Resistenza meccanica (per sopportare il camino) / Mechanical resistance (to carry a
chimney)
NPD {No Determined Performance}
Potenza termica nominale / Nominal heat output
Potenza termica resa in ambiente / Room heating output
Potenza termica ceduta all’acqua / Water heating output
17.90 kW
7.66 kW
10.24 kW
Rendimento / Efficiency
88.19% alla potenza termica nominale / Nominal heat output
9
La prestazione del prodotto di cui ai punti 1 e 2 è conforme alla prestazione dichiarata di cui al punto 8. Firma/Signature:
Si rilascia la presente dichiarazione di prestazione sotto la responsabilità esclusiva del fabbricante di cui al punto 4.
The performance of the product identified in points 1 and 2 is in conformity with the declared performance in point 8.
This declaration of performance is issued under the sole responsibility of the manufacturer identified in point 4.
Arsiero, 10/11/2019

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 4
DICHIARAZIONE DI PRESTAZIONE IN ACCORDO CON IL REGOLAMENTO (UE) 305/2011
DECLARATION OF PERFORMANCE ACCORDING TO REGULATION (EU) 305/2011
N° 101
1
Codice di identificazione unico del prodotto-tipo:
Unique identification code of the product type:
BOSKY COUNTRY
30 EVO5
2
Modello, lotto, serie ai sensi dell'articolo 11, paragrafo 4:
Model, batch or serial number required under Article 11 (4):
BOSKY COUNTRY 30
EVO5
3
Usi previsti del prodotto da costruzione, conformemente alla relativa specifica tecnica armonizzata:
Intended uses of the construction product, in accordance with the applicable harmonised technical specification:
Apparecchio per il riscaldamento domestico, con acqua, alimentato a ceppi di legna / Residential space heating appliance with water fired by wood logs
4
Nome registrato e indirizzo del fabbricante ai sensi dell'articolo 11, paragrafo 5:
Name and contact address of the manufacturer as required pursuant to Art. 11 (5):
THERMOROSSI S.P.A. Via Grumolo, n° 4 36011 Arsiero (Vicenza)
5
Nome e indirizzo del mandatario ai sensi dell’articolo 12, paragrafo 2:
Name and address of the agent as required pursuant to Article 12 (2):
-
6
Sistema di valutazione e verifica della costanza della prestazione del prodotto da costruzione di cui all'allegato V: Sistema 3
System of assessment and verification of constancy of performance of the construction product as set out in Annex V: System 3
7
Laboratorio notificato: Notified laboratory:
KIWA CERMET ITALIA S.p.A. N° 0476
Numero del rapporto di prova secondo il sistema 3 / Test report number based on System 3:
3003511/01
8
Prestazione dichiarata / Declared performance
Specifica tecnica armonizzata/Harmonized technical specification:
EN 13240:2001
Caratteristiche Essenziali / Essential characteristics
Prestazione / Performance
Reazione al fuoco / Reaction to fire
A1
Distanza da materiali combustibili
Distance to combustible materials
Minime distanze / Minimum distances (mm):
posteriore/rear = 300 lati/sides = 300 frontale / front = 800
soffitto/ceiling = - pavimento / floor = -
Rischio di fuoriuscita di braci incandescenti / Risk of burning fuel falling out
Conforme /Compliant
Temperatura superficiale/Surface temperature
Conforme /Compliant
Sicurezza elettrica / Electrical safety
-
Pulizia / Cleanability
Conforme /Compliant
Emissione di prodotti della combustione /Emission of combustion products
CO = 220 mg/m3a potenza termica nominale / CO at Nominal heat output
Pressione massima di esercizio / Maximum operating pressure
2.5 bar
Temperatura fumi a potenza termica nominale / Flue gas temperature at nominal heat output
T 165 °C
Resistenza meccanica (per sopportare il camino) / Mechanical resistance (to carry a
chimney)
NPD {No Determined Performance}
Potenza termica nominale / Nominal heat output
Potenza termica resa in ambiente / Room heating output
Potenza termica ceduta all’acqua / Water heating output
11.1 kW
3.2 kW
8.0 kW
Rendimento / Efficiency
89.1% alla potenza termica nominale / Nominal heat output
9
La prestazione del prodotto di cui ai punti 1 e 2 è conforme alla prestazione dichiarata di cui al punto 8. Firma/Signature:
Si rilascia la presente dichiarazione di prestazione sotto la responsabilità esclusiva del fabbricante di cui al punto 4.
The performance of the product identified in points 1 and 2 is in conformity with the declared performance in point 8.
This declaration of performance is issued under the sole responsibility of the manufacturer identified in point 4.
Arsiero, 10/03/2023
DICHIARAZIONE DI PRESTAZIONE IN ACCORDO CON IL REGOLAMENTO (UE) 305/2011
DECLARATION OF PERFORMANCE ACCORDING TO REGULATION (EU) 305/2011
N° 102
1
Codice di identificazione unico del prodotto-tipo:
Unique identification code of the product type:
BOSKY COUNTRY
F30 EVO5
2
Modello, lotto, serie ai sensi dell'articolo 11, paragrafo 4:
Model, batch or serial number required under Article 11(4):
BOSKY COUNTRY
F30 EVO5
3
Usi previsti del prodotto da costruzione, conformemente alla relativa specifica tecnica armonizzata:
Intended uses of the construction product, in accordance with the applicable harmonised technical specification:
Apparecchio per il riscaldamento domestico, con acqua, alimentato a ceppi di legna / Residential space heating appliance with water fired by wood logs
4
Nome registrato e indirizzo del fabbricante ai sensi dell'articolo 11, paragrafo 5:
Name and contact address of the manufacturer as required pursuant to Art. 11 (5):
THERMOROSSI S.P.A. Via Grumolo, n° 4 36011 Arsiero (Vicenza)
5
Nome e indirizzo del mandatario ai sensi dell’articolo 12, paragrafo 2:
Name and address of the agent as required pursuant to Article 12 (2):
-
6
Sistema di valutazione e verifica della costanza della prestazione del prodotto da costruzione di cui all'allegato V: Sistema 3
System of assessment and verification of constancy of performance of the construction product as set out in Annex V: System 3
7
Laboratorio notificato: Notified laboratory:
KIWA CERMET ITALIA S.p.A. N° 0476
Numero del rapporto di prova secondo il sistema 3 / Test report number based on System 3:
3003511/01
8
Prestazione dichiarata / Declared performance
Specifica tecnica armonizzata/Harmonized technical specification:
EN 13240:2001
Caratteristiche Essenziali / Essential characteristics
Prestazione / Performance
Reazione al fuoco / Reaction to fire
A1
Distanza da materiali combustibili
Distance to combustible materials
Minime distanze / Minimum distances (mm):
posteriore/rear = 300 lati/sides = 300 frontale / front = 800
soffitto/ceiling = - pavimento / floor = -
Rischio di fuoriuscita di braci incandescenti / Risk of burning fuel falling out
Conforme /Compliant
Temperatura superficiale/Surface temperature
Conforme /Compliant
Sicurezza elettrica / Electrical safety
-
Pulizia / Cleanability
Conforme /Compliant
Emissione di prodotti della combustione /Emission of combustion products
CO = 220 mg/m3a potenza termica nominale / CO at Nominal heat output
Pressione massima di esercizio / Maximum operating pressure
2.5 bar
Temperatura fumi a potenza termica nominale / Flue gas temperature at nominal heat output
T 165 °C
Resistenza meccanica (per sopportare il camino) / Mechanical resistance (to carry a
chimney)
NPD {No Determined Performance}
Potenza termica nominale / Nominal heat output
Potenza termica resa in ambiente / Room heating output
Potenza termica ceduta all’acqua / Water heating output
11.1 kW
3.2 kW
8.0 kW
Rendimento / Efficiency
89.1% alla potenza termica nominale / Nominal heat output
9
La prestazione del prodotto di cui ai punti 1 e 2 è conforme alla prestazione dichiarata di cui al punto 8. Firma/Signature:
Si rilascia la presente dichiarazione di prestazione sotto la responsabilità esclusiva del fabbricante di cui al punto 4.
The performance of the product identified in points 1 and 2 is in conformity with the declared performance in point 8.
This declaration of performance is issued under the sole responsibility of the manufacturer identified in point 4.
Arsiero, 10/03/2023

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 5
IT –SCHEDA PRODOTTO (UE 2015/1186)
EN –PRODUCT FICHE (EU 2015/1186)
FR –FICHE PRODUIT (UE 2015/1186)
NL –PRODUCTGEGEVENSBLAD (EU 2015/1186)
DE –PRODUKTDATENBLATT (EU 2015/1186)
ES –FICHA DE PRODUCTO (UE 2015/1186)
IT –MARCHIO
EN –BRAND
FR –MARQUE
NL –MERK
DE –MARKE
ES –MARCA
THERMOROSSI S.P.A.
IT –MODELLO
EN –MODEL
FR –MODÈLE
NL –MODEL
DE –MODELL
ES –MODELO
BOSKY COUNTRY 30 EVO
BOSKY COUNTRY F30 EVO
BOSKY COUNTRY 30 EVO5
BOSKY COUNTRY F30 EVO5
IT –CLASSE DI EFFICIENZA ENERGETICA
EN –ENERGY EFFICIENCY CLASS
FR –CLASSE D'EFFICACITÉ ÉNERGÉTIQUE
NL –ENERGIE EFFICIENTIEKLASSE
DE –ENERGIEEFFIZIENZKLASSE
ES –CLASE DE EFICIENCIA ENERGÉTICA
A +
A +
IT –POTENZA TERMICA DIRETTA
EN –DIRECT HEAT OUTPUT
FR –PUISSANCE THERMIQUE DIRECTE
NL –DIREKTE WARMTEAFGIFTE
DE –DIREKTE WÄRMELEISTUNG
ES –POTENCIA CALORÍFICA DIRECTA
7.7 kW
3.2 kW
IT –POTENZA TERMICA INDIRETTA
EN –INDIRECT HEAT OUTPUT
FR –PUISSANCE THERMIQUE INDIRECTE
NL –INDIRECTE WARMTEAFGIFTE
DE –INDIREKTE WÄRMELEISTUNG
ES –POTENCIA CALORÍFICA INDIRECTA
10.2 kW
8.0 kW
IT –INDICE DI EFFICIENZA ENERGETICA
EN –ENERGY EFFICIENCY INDEX
FR –INDICE D'EFFICACITÉ ÉNERGÉTIQUE
NL –ENERGIE-EFFICIENTIE-INDEX
DE –ENERGIEEFFIZIENZINDEX
ES –ÍNDICE DE EFICIENCIA ENERGÉTICA
118
119
IT –EFFICIENZA UTILE ALLA POTENZA TERMICA NOMINALE
EN –USEFUL ENERGY EFFICIENCY AT NOMINAL HEAT OUTPUT
FR –RENDEMENT UTILE À LA PUISSANCE THERMIQUE NOMINALE
NL –NUTTIG RENDEMENT BIJ NOMINAAL VERMOGEN
DE –BRENNSTOFF-ENERGIEEFFIZIENZ BEI NENNWÄRMELEISTUNG
ES –EFICIENCIA ENERGÉTICA ÚTIL A POTENCIA CALORÍFICA NOMINAL
88.2%
89.1%
IT –EFFICIENZA UTILE AL CARICO MINIMO
EN –USEFUL ENERGY EFFICIENCY AT MINIMUM LOAD
FR –RENDEMENT UTILE À LA CHARGE MINIMALE
NL –NUTTIG RENDEMENT BIJ MINIMALE WARMTEAFGIFTE
DE –BRENNSTOFF-ENERGIEEFFIZIENZ BEI MINDESTLAST
ES –EFICIENCIA ENERGÉTICA ÚTIL A CARGA MINIMA
-
-
IT –RISPETTARE TUTTE LE ISTRUZIONI RIPORTATE SUL MANUALE DI INSTALLAZIONE USO E MANUTENZIONE
EN –ALWAYS FOLLOW THE INSTRUCTIONS PROVIDED IN THE OPERATING AND MAINTENANCE MANUAL
FR –RESPECTER TOUTES LES INSTRUCTIONS CITÉES DANS LA NOTICE D’INSTALLATION, UTILISATION ET ENTRETIEN
NL –VOLG ALTIJD DE INSTRUCTIES VAN DE INSTALLATIE-, GERUIKERSHANDLEIDING EN DE ONDERHOUDSVOORSCHRIFTEN
DE –ERFÜLLEN DIE ANWEISUNGEN DER INSTALLATION, NUTZUNG UND WARTUNG, DIE IN DEM ANLEITUNGSBUCH SIND
ES –RESPECTAR LAS INSTRUCCIONES REPORTADAS EN EL MANUAL DE UTILIZACIÓN Y MANTENIMIENTO

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 6
1 –INTRODUCTION
1.1 SAFETY GUIDELINES
This installation, use and maintenance manual is an integral and essential part of the product and must be kept by the user. Before
commencing with the installation, use and maintenance of the product, carefully read this guide. All local, national and European
regulations regarding the installation and use of the appliance must be met. The Manufacturer recommends carrying out all the
maintenance operations described in this manual.
This appliance must only be used as intended by the manufacturer. Any other use is considered incorrect and therefore hazardous;
consequently, the user shall be totally liable for the product if used improperly. Installation, maintenance and repairs must be carried
out by professionally qualified personnel, certified according to Decree no. 37 of 22 January 2008 and in compliance with current
regulations. In case of repairs only original spare parts supplied by the manufacturer must be used. Incorrect installation or poor
maintenance can injure or damage people, animals or things; in this case the manufacturer shall be relieved of all responsibility. Any
repairs or actions carried out on any systems, components or internal parts of the appliance, or on any of the accessories supplied
with it, that are not specifically authorised by Thermorossi S.p.A, will automatically void the warranty and the manufacturer's
responsibility, pursuant to Italian Decree no. 224 of the President of the Republic of 24/05/1988, art. 6/b. It is recommended to keep
this manual in a safe place that is easily accessible to all users. If the manual is lost or deteriorated contact the manufacturer for a
replacement copy. If the appliance is sold or transferred to another user ensure that the manual is handed over with it. The images
and figures featured in this manual are purely illustrative and may differ from the actual product. Furthermore, Thermorossi reserves
the right to apply changes to the content of this manual anytime and without notice.
Thermorossi S.p.A. retains copyright on this manual. These instructions may not be reproduced or communicated to third parties or
used in any other way without the necessary authorisation.
1.2 SAFETY STANDARDS
PERSONAL INJURY
This safety symbol identifies important messages throughout the manual. Read the information marked
by this symbol carefully as non-observance of this message can cause serious injury to persons using
the appliance.
DAMAGE TO PROPERTY
This safety symbol identifies messages or instructions that are fundamental for the appliance and
system to function well. To avoid serious damage to the appliance, adhere strictly to these instructions.
INFORMATION
This symbol indicates important instructions for good functioning of the appliance. If this information
is not correctly observed, the performance of the appliance will not be satisfactory.
1.3 RECOMMENDATIONS
Read this entire use and maintenance manual carefully before using the appliance as familiarity with the information
and instructions contained in it are essential for the correct use of the appliance.
No responsibility will be accepted for damages, even to third parties, if the instructions for installation, use and
maintenance of the appliance are not followed scrupulously. Modifications made to the appliance by the user or on his
behalf, must be considered to be under his complete responsibility. The user is responsible for all the operations
required for the maintenance of the appliance before and during its use.
Should you notice an excessive stagnation of flue gas in the combustion chamber, move away from the appliance
immediately. In particular move away from the glass door of the combustion chamber. The excessive concentration of
unburned gases could create an explosion that could break the glass. Do not open the loading door for any reason
whatsoever and do not approach the product until the flame has died down. Contact a technical service centre to
determine the causes. Do not turn on the appliance for any reason whatsoever following an event such as this.
1.4 GENERAL GUIDELINES
Attention: the appliance must be connected to a system provided with a PE conductor (in compliance with the
specifications concerning low-voltage equipment). Before installing the appliancecheck the efficiencyof the earth circuit
of the power supply system.
Attention: the cable section must in any case be no less than 1.5 mm². The appliance requires powering with a voltage of 230 V and
50 Hz. Position the appliance so that the electric power outlet in the room is easily accessible. Ensure that a suitable differential switch
is installed upstream from the equipment.
The product must not be used by children under the age of 8 years, by persons with physical, mental or sensorial impairments, or by
persons who are not familiar with the instructions for use and maintenance of the product (the instructions are found in this booklet).
Children must not play with the appliance.
ATTENTION: before each use make sure that the grate and the ash pan are perfectly clean and check that the firebox door is firmly
closed and airtight.

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 7
ATTENTION: it is strictly forbidden to open the door while the flame is still burning. During operation, the smoke exhaust pipes, door,
handles and some parts of the appliance may reach extremely high temperatures: be careful not to touch them and also educate
children to be aware of said risks. Do not expose your body to hot air for long, do not overheat the room in which the appliance is
installed, as these actions could cause health problems. Do not expose plants or animals directly to the hot air flow as this could have
noxious effects on them. It is prohibited to use any liquids or gases such as alcohol, petrol, etc. to light or rekindle the fire, use only
thin wood. Do not place non-heat resistant or inflammable or combustible objects in the vicinity of the appliance: keep them at a
suitable distance. Do not place wet clothing to dry on the appliance. When using a clothes horse, keep at a suitable distance. It is
strictly prohibited to disconnect the appliance from the electrical power mains while it is in operation.
Caution: do not wet the appliance and do not touch the electrical parts with wet hands. Never vacuum hot ash: this
could damage the vacuum device. All the cleaning operations described in this manual must be carried out when the
appliance is cold and shut off.
Attention! Warning for Swiss users
Refer to the local cantonal regulations imposed by the Fire Department (Mandatory signalling and safety distances)
and the Note concerning installation of heaters issued by the Association of Cantonal Fire Agencies (VKF - AEAI).
ATTENTION: it is mandatory to earth the appliance. If this instruction is not observed serious damage, which is not
covered by warranty, will result to the body of the appliance. Have an electrician check the earthing. There must be no
electric potential (Volt) between the earth of the generator and the actual earth of the system.
1.5 TRANSPORTATION AND STORAGE
TRANSPORTATION AND HANDLING
The appliance body must always be handled exclusively by means of trolleys. Take special care to protect the glass and all the fragile
parts from mechanical impact which could damage them and their correct functioning.
STORAGE
The appliance must be stored in a humid-free environment and sheltered from the weather; avoid placing the appliance directly on
the ground. The Company denies all responsibility for damage caused to wood floors or floors made from any other material. It is
inadvisable to store the product for long periods of time.
1.6 GUIDELINES FOR CORRECT DISPOSAL OF THE PRODUCT
At the end of the product’s useful life, it must be disposed of in compliance with applicable regulations and in respect
of the environment, not with urban waste. The product must be consigned to designated sorted waste collection centres
for the disposal of waste authorised by the local municipal councils. Correct disposal not only helps safeguard the
environment but it also promotes recovery and recycling of the materials.

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 8
2 –TECHNICAL CHARACTERISTICS
BOSKY
COUNTRY
30 EVO
BOSKY
COUNTRY
F30 EVO
BOSKY
COUNTRY 30
EVO5
BOSKY
COUNTRY F30
EVO5
Height (mm)
925
925
925
925
Depth (mm)
687
687
687
687
Width (mm)
600
1,048
600
1,048
Weight (kg)
251
300
251
300
Ø Internal smoke outlet (mm)
150
150
150
150
Ø External smoke outlet (mm)
154
154
154
154
Minimum draught (Pa)
18
18
12
12
Maximum permitted fuel feed kg ***
4.5
4.5
2.5
2.5
Maximum hourly consumption (kg/h) ***
4,7
4,7
2.9
2.9
Average load duration (Min) **
63
63
69
69
Firebox power (kW) **
20.30
20.30
12,5
12,5
Rated power (kW) **
17.90
17.90
11.1
11.1
Output to water (kW) **
10.24
10.24
8.0
8.0
Output to the room (kW) **
7.66
7.66
3.2
3.2
Efficiency (%) **
88.19
88.19
89.1
89.1
CO emissions (mg/m³ at 13% O2) **
891
891
220
220
Heatable volume (m³) *
480
480
300
300
Average smoke temperature (°C) **
178
178
165
165
Smoke flow rate (g/s) **
12,6
12,6
8.0
8.0
Water content (l)
27
27
27
27
Minimum working pressure
1.0
1.0
1.0
1.0
Maximum working pressure
2.5
2,5
2,5
2.5
Max delivery water temperature (°C)
80
80
80
80
Min water return temperature (°C)
55
55
55
55
Firebox feed opening dimensions (mm) (LxH)
210 X 200
210 X 200
210 X 200
210 X 200
Firebox dimensions (mm) (LxHxD)
300 x 500 x 440
300 x 500 x 440
300 x 500 x 440
300 x 500 x 440
Oven dimensions (mm) (LxHxD)
-
340 X 300 X 500
-
340 X 300 X 500
Power supply voltage and frequency (V –Hz)
230 –50
230 –50
230 –50
230 –50
** IMPORTANT: It is important to take into consideration the fact that the heatable volume is greatly influenced by the
insulation of the house (energy class of the building) and by the position of the appliance in the planimetry of the house,
therefore the indicated values may vary, even significantly.
** ATTENTION: The indicated values were obtained using beechwood logs (3-4 logs) with thermal value less than or equal
to 15,429 kJ/kg and moisture content less than 15%. The use of poorer quality firewood than that specified results in lower
yield and lower efficiency, and produces more ash. Moreover the glass on the feed door will become dirtier sooner.
*** It is strictly prohibited to load a greater quantity of fuel than that specified in the table. The warranty will not cover
damages caused by the prolonged exposure of the appliance to temperatures that are too high.

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 9
2.1 DIMENSIONS
BOSKY COUNTRY 30 EVO - BOSKY COUNTRY 30 EVO5
BOSKY COUNTRY F30 EVO - BOSKY COUNTRY F30 EVO5
VISTA FRONTALE
SCALA 1:20 VISTA FIANCO SX
SCALA 1:20 VISTA POSTERIORE
SCALA 1:20 VISTA SUPERIORE
SCALA 1:20
VISTA ISOMETRICA - SCALA 1:10
NOTE PER LA NORMALIZZAZIONE:
- Quote SEMPRE in ALTO e a DESTRA
- QUOTARE SEMPRE IL "FUORI TUTTO"
poi eventuali "sottoingombri"
- Ricordarsi di rendere visibile
le linee nascoste del vetro (se presente)
- Quotatura "assiale" per viste posteriori
- Compattare le viste ortogonali il più possibile
720
925
852
102
687
O150
103
707
626
580
308 783
140
1/2"F
1/2"F
720
600
97
598
1"F
1"F
VISTA FRONTALE
SCALA 1:20 VISTA FIANCO SX
SCALA 1:20 VISTA POSTERIORE
SCALA 1:20 VISTA SUPERIORE
SCALA 1:20
VISTA ISOMETRICA - SCALA 1:10
NOTE PER LA NORMALIZZAZIONE:
- Quote SEMPRE in ALTO e a DESTRA
- QUOTARE SEMPRE IL "FUORI TUTTO"
poi eventuali "sottoingombri"
- Ricordarsi di rendere visibile
le linee nascoste del vetro (se presente)
- Quotatura "assiale" per viste posteriori
- Compattare le viste ortogonali il più possibile
1167
1048
925
852
716
42
1"F
1"F
102
O150
542
308 475
709
144
580 46
1141
1048
645
714
515
O150

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 10
3 –GENERAL DESCRIPTION
3.1 THE FUEL
The fuel for this appliance is ordinary wood billets with a moisture content between 10% and 20% and with a thermal value of 13,000
to 15,429 Kcal/kg. We recommend using beech or common hornbeam. If using wood with a lower moisture content or with a higher
thermal value, the heat produced by the stove will be greater.
The awareness and use of the right fuel are important aspects to be observed in order to ensure correct operation and long service
life of the appliance. To this end we recommend using only dry, well-seasoned wood. We recommend against using wet wood or
wood that has been seasoned for less than 18/20 months, as this could be the cause of malfunctions and the formation of tarry
deposits that could permanently blacken the walls of the combustion chamber.
We recommend using logs with a length of 250 mm (max recommended section Ø 80 mm) and loading a maximum of 3-4 logs.
4.5 kg on BOSKY COUNTRY 30/F30 EVO
2.5 kg on BOSKY COUNTRY 30/F30 EVO5
THE FUEL FEED INTERVALS MUST NOT BE LESS THAN 1 HR. LOADING A LARGER QUANTITY OF FUEL OR
LOADING SEVERAL TIMES IN AN HOUR EXPOSES THE COMPONENTS OF THE APPLIANCE TO VERY HIGH
TEMPERATURES. FOR THIS REASON THE WARRANTY WILL NOT COVER ANY DAMAGE CAUSED BY
PROLONGED EXPOSURE OF THE APPLIANCE TO THESE TEMPERATURES.
The use of fuel that does not comply with the above specifications or the use of different substances or fuels
will immediately void the appliance warranty. The appliance must not be used as an incinerator, and it is
prohibited to use any liquid or gas fuel. Do not overload the stove with excessive quantities of fuel; adhere
strictly to the maximum declared consumption.
It is strictly prohibited to store combustible or inflammable material in the compartment under the oven. The
temperature inside can reach very high levels.

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 11
3.2 MAIN COMPONENTS
A –Primary air control
It is used to regulate the primary air inflow. The primary air passes through the grate of the firebox and fuels the combustion to
determine its power and speed. Rotate the control towards zero to reduce the air inflow. On the contrary, turn the control towards
eight to increase the air inflow. To prevent or limit condensation, it is recommended to keep the control on levels 5-6.
F –Starter
This device creates a direct bypass for the flue gases which facilitates both the lighting and refuelling operations. The riddling tool
provided must be used when activating it and only when lighting or stoking the fire.
IT IS STRICTLY PROHIBITED TO LEAVE THE STARTER OPEN DURING NORMAL OPERATION.
Leaving the starter open during normal operation results in higher fuel consumption than the declared quantity, a
considerable drop in efficiency and exposure of the appliance to extremely high temperatures. For this reason the
warranty does not cover any direct or indirect damages caused by prolonged exposure of the appliance to these
temperatures. ATTENTION: The temperature of the starter is very hot while the appliance is operating, so take
care not to touch it. The riddling tool provided must be used when handling it.
Moving the Starter outwards activates the direct bypass for the flue gases, whereas on the contrary, pushing it downwards activates
the normal flue gas path.
KEY
A
Primary air control
B
Safety heat exchanger insertion plate
C
Water thermometer
E
Pump active indicator light
F
Starter
G
Smoke deviator flap (only F30 EVO)
H
Thermostat probe and thermometer pocket
I
Air adjustment lever
L
Ash pan door
M
Inspection door
N
Grate adjustment pin
Q
Feed door
R
Oven (only F30 EVO)
S
Under-oven compartment (only F30 EVO)

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 12
LEGENDA
KEY
STARTER CHIUSO
STARTER CLOSED
STARTER APERTO
STARTER OPEN

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 13
4 –INSTALLATION
4.1 APPLIANCE LOCATION
Follow the general guidelines set out in paragraph 1.1 to the letter. Be aware that the flooring of the installation site
must be capable of withstanding the weight of the appliance and the water contained in it. If this requirement is not met,
it is obligatory to adopt countermeasures (for example, load distribution plate …).
ATTENTION: The room where the appliance is installed must be well ventilated and free
from humidity and salty air. A high level of humidity or saltiness in the room can lead to
the onset of rust or corrosion which will not be covered by warranty. The appliance must
be positioned at a minimum safe distance from walls and furnishings. If inflammable
materials are located in the vicinity of the appliance (e.g.: matchboarding, furniture,
curtains, pictures and paintings, sofas) it is mandatory to comply with the minimum
distances illustrated on the side.
If the flooring is made of wood or any other combustible material, it is mandatory to install
a fireproof floor protector plate between the appliance and the floor. Installation in the
vicinity of heat-sensitive materials is only permitted if suitable insulating and fireproof
protection is placed between the object and the appliance (ref. Uni 10683). Failure to
observe this instruction will immediately invalidate the warranty.
The installer must issue a certificate of conformity for the installation which includes the design plans and the following documents:
a) Report containing the type of materials utilised.
b) Project as defined in Article 5 of Ministerial Decree n° 37 22 January 2008.
d) References to existing partial or previous declarations of conformity (e.g., flue outlet).
e) Copy of the certificate of recognition of the professional technical qualifications.
These documents must, by law, be kept together with the installation, use and maintenance manual. The customer is
responsible for verifying, directly or indirectly, that the installation has been carried out to perfection in accordance with
relevant regulations in force. Do not install the appliance in unsuitable rooms such as bedrooms, bathrooms, garages
and/or lock-ups. It is forbidden to place the appliance in environments with an explosive atmosphere.
ATTENTION, the appliance is not simply a household appliance: if the instructions set out in this manual are not
followed and/or if installation of the appliance is not executed perfectly and/or the provisions in force are not strictly
complied with, dangerous conditions could arise for both objects and persons. It is the user’s responsibility to verify the
presence, in the room, of a vent necessary for supplying oxygen to the appliance. It is strictly prohibited to install the
appliance as inset or next to furniture.
4.2 UNPACKING THE APPLIANCE
The appliance is supplied packaged on a pallet; always use trolleys to move the appliance and the appliance must always be in a
vertical position. Before positioning and installing it dismantle the appliance from the pallet as described:
- Remove the cover, the side panels and any fastening screws from the pallet.
- Remove the appliance from the pallet with the aid of a trolley. Slip the bottom of the trolley under the back part of the appliance and
tip the trolley back onto its wheels. Given the weight of the appliance we recommend that this operation be carried out by two people.
Take care when lifting the appliance as the centre of gravity of the weight is concentrated at the front.
- Check that all the mobile parts are in place; remove the labels and stickers from the glass.
REMOVE PROTECTIVE FILM FROM THE COOKTOP.
4.3 CONNECTION TO THE FLUE OUTLET
Connection of the appliance to the flue outlet must be carried out in strict compliance with the instructions
contained in this booklet and particularly with those in the dedicated chapter.
A = 800 mm
L = 300 mm
P = 300 mm

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 14
5 –PLUMBING SYSTEM CONNECTIONS AND DIAGRAMS
5.1 GENERATOR PLUMBING COMPONENTS
5.2 GUIDELINES FOR THE HYDRAULIC SYSTEM
The hydraulic system must be installed by qualified personnel who are familiar with the standards mentioned above
and who have the appropriate professional requirements to release the declaration of conformance in accordance
with Ministerial Decree n° 37 of 22 January 2008. The system must be suitably sized in relation to the power of the
generator.
ATTENTION: it is mandatory to earth the generator. If this instruction is not observed serious damage, which is not
covered by warranty, will result to the body of the appliance. Have a skilled electrician check the earthing. There
must be no electric potential (Volt) between the generator earth and the plant’s real earth (earth plate). To prevent
electrochemical corrosion of the appliance body do not use galvanised pipes and fittings. Other materials must be
earthed with special earthing cables in order to obtain a unipotential earthing system.
5.3INSTRUCTIONS FOR EXECUTING THE HYDRAULIC SYSTEM CLOSED EXPANSION TANK
To install the system with a closed expansion tank refer to the requirements laid down in EN 10412-2:2009 for appliances with nominal
heat output not exceeding 35 kW. A closed expansion tank must be series-connected to the generator as protection for the system.
The nominal volume of the closed expansion tank must be sized in relation to the total volume of the water contained in the system.
Thermorossi prescribes the size of the closed expansion tank as equal to 10% of the volume of water contained in the entire system.
Any bulging of the boiler body caused by an incorrectly sized expansion tank will not be covered by the warranty.
The following chapter does not replace the above standards to which it makes reference. The qualified installer must in any case be
fully aware of the above standards and their amending versions.
KEY
A
Delivery tube system 1" F
B
Heat exchanger thermal relief ½" F
C
Heat exchanger discharge ½" F
D
Heating plant return 1" F

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 15
5.4 SCHEMATIC DIAGRAM OF TYPICAL OPEN EXPANSION TANK HYDRAULIC SYSTEM
LEGENDA
KEY
Dall'acquedotto
from water mains
Tubo di carico
Delivery pipe
Tubo di sicurezza
Safety tube
Scarico
Outlet
ATTENTION: it is mandatory to earth the generator. If this instruction is not observed serious damage, which
is not covered by warranty, will result to thebody of the appliance. Have a skilled electrician check the earthing.
There must be no electric potential (Volt) between the generator earth and the system’s real earth (earth plate).
To prevent electrochemical corrosion of the appliance body do not use galvanised pipes and fittings. Other
materials must be earthed with special earthing cables in order to obtain a unipotential earthing system.
ATTENTION: It is important to guarantee that the boiler return temperature always exceeds 55°C. For this reason, we recommend
installing a temperature control thermometer on the return (see diagram). Act on the head of the mixing valve to adjust the
temperature.
VSP
Gate valve
(throttle according to pressure drop in the
system)
A
Heating plant delivery
R
Heating plant return
E
Safety pipe that runs from the boiler to the
open expansion tank
S
Boiler discharge
PC
System circulating pump
VI
On-off valve
VNR
Nonreturn valve
VST
Thermal relief valve (recommended)
SCS
Safety heat exchanger (recommended)
VS
Safety valve 3 bar
TCI
Circulation tube
TSF
Vent pipe
TT
Overflow pipe
VM3VT
Anti-condensation mixing valve
T
Return temperature control thermometer

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 16
5.5 SCHEMATIC DIAGRAM OF TYPICAL CLOSED EXPANSION TANK HYDRAULIC SYSTEM
VSP
Gate valve
(throttle according to pressure drop in the
system)
A
Heating plant delivery
R
Heating plant return
VEC
Closed expansion tank, sized to at least
10% of the volume of water contained in
all the system
S
Boiler discharge
PC
System circulating pump
VI
On-off valve
VNR
Nonreturn valve
VST
Thermal relief valve
SCS
Safety heat exchanger
VS
Safety valve 3 bar
VM3VT
Anti-condensation mixing valve
T
Return temperature control thermometer
LEGENDA
KEY
Dall'acquedotto
From water mains
Scarico
Outlet
ATTENTION: it is mandatory to earth the generator. If this instruction is not observed serious damage, which
is not covered by warranty, will result to thebody of the appliance. Have a skilledelectrician check the earthing.
There must be no electric potential (Volt) between the generator earth and the system’s real earth (earth plate).
To prevent electrochemical corrosion of the appliance body do not use galvanised pipes and fittings. Other
materials must be earthed with special earthing cables in order to obtain a unipotential earthing system.
ATTENTION: It is important to guarantee that the boiler return temperature always exceeds 55°C. For this reason, we recommend
installing a temperature control thermometer on the return (see diagram). Act on the head of the mixing valve to adjust the
temperature.

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 17
5.6 SCHEMATIC DIAGRAM OF TYPICAL CLOSED EXPANSION TANK HYDRAULIC SYSTEM WITH PUFFER
TANK
LEGENDA
KEY
Dall'acquedotto
From water mains
Scarico
Outlet
ATTENTION: it is mandatory to earth the generator. If this instruction is not observed serious damage, which
is not covered by warranty, will result to the body of theappliance. Have a skilled electrician check the earthing.
There must be no electric potential (Volt) between the generator earth and the system’s real earth (earth plate).
To prevent electrochemical corrosion of the appliance body do not use galvanised pipes and fittings. Other
materials must be earthed with special earthing cables in order to obtain a unipotential earthing system.
ATTENTION: Anti-condensation mixing valve should be set at approx. 65°C. So, when the temperature of the boiler drops below this
value, the “cold” inlet closes and prevents circulation towards the puffer tank but only between the boiler supply and return. In this
way, the heat stored in the puffer tank is not dispersed to the boiler.
PC
System circulating pump
A
Heating plant delivery
VI
On-off valve
R
Heating plant return
VNR
Nonreturn valve
VEC
Closed expansion tank, sized to at least 10% of the
volume of water contained in all the system
VST
Thermal relief valve
S
Boiler discharge
SCS
Safety heat exchanger
VS
Safety valve 3 bar
VM3VT
Anti-condensation mixing valve

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 18
6 –ASSEMBLING THE COMPONENTS
6.1 INSTALLATION OF THE SAFETY HEAT EXCHANGER (OPTIONAL)
Install the safety heat exchanger in accordance with the following
procedure:
1) Remove the cover (10) by acting on the screws (7) and
washers (8).
2) Slide in the heat exchanger (1).
3) Fix the heat exchanger to the flange (9) using the elements
(2) in the following order: Gasket O-ring (3), conical washer with
the concave side towards the O-ring (4) and nut (5).
4) Fasten the flange (9) to the boiler.
5) Install the certified and calibrated two-way thermal relief
valve at the exchanger inlet, following the instructions provided
by the manufacturer and install a discharge pipe. Fasten the
sensitive element in the special pocket located in the flange (9).
The thermal relief valve must have the following characteristics:
- Double safety sensor for solid fuel generators (max. operating pressure): 10 bar
- Temperature range: 5÷110°C - calibration temperature 98°C
- Discharge capacity with Δp = 1 bar and T=110°C: 3,000 l/h - capillary tube length: 130 mm
- Certified to standard EN 14597
ATTENTION: before reassembling the remaining parts make sure that the gaskets are tight by bringing the system to pressure.
6) Reassemble the parts by carrying out the above procedure in reverse order.
ATTENTION: A CONNECTION MUST BE MADE BETWEEN THE SAFETY VALVE AND THE OUTLET TO
PREVENT DAMAGING MATERIALS SURROUNDING THE APPLIANCE WHEN THE VALVE IS ACTIVATED.
ATTENTION: IF THE SAFETY HEAT EXCHANGER IS INSTALLED TO PRODUCE DOMESTIC HOT WATER,
THE GUARANTEE FOR THE GENERATOR IS IMMEDIATELY VOIDED.
6.2 INSTALLATION OF THE CIRCULATING PUMP
It is mandatory to connect the circulating pump (not supplied as standard) to the dedicated terminal block.
The terminal block is located behind the left side panel (so it will have to be removed). Connect the power supply (230 V) to the
terminals as indicated in the figure below. Then connect the circulating pump to the terminals (PUMP). The circulating pump will thus
activate as soon as the water in the boiler will exceed the temperature of about 60°C.
This operation must be exclusively performed by qualified professional staff, as set forth by Decree no. 37 of 22nd
January 2008 and applicable laws on the subject. Before performing said task, make sure the power supply cable is
disconnected from the electrical power socket.

ENG
Installation, use and maintenance guide
BOSKY COUNTRY 30/F30 EVO - BOSKY COUNTRY 30/F30 EVO5
Page 19
LEGENDA
KEY
POMPA
PUMP
ANTICONDENSA
ANTICONDENSATION
CIRCOLATORE
CIRCULATING PUMP
ATTENTION: it is mandatory to earth the generator. If this instruction is not observed serious damage, which is
not covered by warranty, will result to the body of the generator. Have an electrician check the earthing. There
must be no electric potential (Volt) between the earth of the generator and the actual earth of the system. To
prevent electrochemical corrosion of the boiler body do not use galvanised pipes and fittings. Dedicated ground
wires must be used to ground all other materials.
6.3 MOUNTING THE CASING
After having installed the product mount the casing as illustrated in the figures below:
- Firstly fix the front majolica tiles (4) and (5) to the seats as indicated (see figure 1). It is advisable to remove the doors
in order to complete this operation. Degrease and dry both the majolica tile and the seat before securing the majolica
tile to the support with the supplied thermal silicone. Wait at least 24 hours before remounting the doors on the product.
- To mount the majolica tiles (6) first remove the black knob of the smoke deviator flap and then remove the central tile
support (8) by pulling it outwards firmly; then use the fixing elements (7) to secure the majolica tiles (6) on the support
(8).
- Fix the support (8) with the majolica tiles to the product.
- Remove the profiles (2) and (1) and mount the side majolica tiles (3).
- Fix the majolica tiles by bending the tabs indicated, assemble the profiles (1) and lastly fix the decorative profiles (2).
ATTENTION: the majolica elements are handcrafted so they could contain subtle surface imperfections, crazing or shade
variations. The layer of glaze has an expansion factor that is different to that of the majolica tiles which is what causes
the hairline cracks. This phenomenon is a natural process and is not a defect. We recommend cleaning the majolica tiles
with a dry microfibre cloth and only when the appliance has cooled down. Using moist or wet cleaning cloths would show
up the natural crazing even more.
