Tibo TI435 DAB User manual

!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
TI435 DAB – User
Manual
!

Contents
•Safety Information
•Introduction
•First time system setup
•DAB mode
•FM mode
•Using the pre-set functions
•Additional Information
•Troubleshooting
•Specifications

•Safety Information
Do not share the power socket with another
appliance.
Do not disassemble or attempt to repair the
appliance on your own.
lf you are not using the appliance, pull the power
cord out of the mains socket.
Be careful of the power cord and maintain it as
appropriate.
To ensure safety, do not twist the power cord, do
not pull it out of the socket, do not compress it or
stretch its length.
Do not use the appliance if the supply voltage is
lower than 90V or higher than 240V.
If the supply voltage is lower than 90V, the
appliance may not work and its lifetime may be
affected. lf the voltage is higher than 240V, the
appliance may catch on fire or cause a fire.

Do not wash the appliance or use it in the
bathroom, or it may cause potential injuries and
other problems.
Installation location
Leave sufficient space around the appliance of at
least 5 cm from any wall/obstacle to ensure proper
ventilation and prevent the appliance from
overheating.
The following places are not suitable installation
locations for the appliance:
•An unstable location
•A location near a heat source or in direct
sunlight.
•In a wet or dusty environment
Warning
To prevent suffering an electrical shock or another
accident, do not operate the appliance in a rainy or
humid environment.
Cleaning and maintenance
Use a soft cloth or cotton dipped in a neutral
solution for cleaning the surface of appliances. Do
not use the type of cloth that you use for washing
dishes or aggressive chemical agents.

Storm
lf the appliance is not working properly during a
storm, please disconnect the plug from the power
socket and reinsert it after a minute.
Do not drop small items or a liquid into the
appliance
In the event that you find small items or a liquid
inside the appliance, you see smoke or smell an
odour, immediately disconnect the appliance from
the power grid. Send the appliance to an authorised
service centre.
Repacking the appliance
When sending the appliance by a transport
company, use the original packaging to prevent its
damage during transport.

•Introduction
Thank you for purchasing the TIBO TI435 DAB
Tuner. We hope that your experience with the
Tuner will be enjoyable for many years to come.
With both DAB+ (Digital Audio Broadcasting plus)
and FM tuners on-board, the TIBO DAB 435 is
ideally equipped for listening to a wide range of
stations. Select DAB+ and you’ll be able to listen to
a vast range of digital radio stations, including the
popular BBC 6 Music, 4 Extra and 5 live. DAB+ also
lets you hear crisp, digital clarity of sound, free from
interference. For local stations or a more expansive
sound with national stations (roof mounted aerial
recommended) then FM is also on hand.
The TIBO TI435 DAB+ has 18 pre-sets that are
clearly accessible. (9 pre-sets for DAB mode and 9
for FM mode.) The large display is equally clear and
informative. To select stations, the simple twist and
push rotary knob makes it intuitive to use. The
simple, logical button layout makes for a design
that’s clean and easy on the eye. The Aluminium
casing is solid and fronted by a metal facial panel
that you’d usually only see on much more
expensive tuners.

•First time system setup
In the box
- TI435 DAB Tuner
- UK figure 8 plug
- EU figure 8 plug
- Remote control
- Quick start guide
- Radio aerial
Front panel layout
1) IR Remote Control Sensor
2) Info Button: Information about current radio
frequency and time
3) Scan Button: To pick up nearby radio
frequencies

4) DAB / FM: Switch between DAB and FM mode
5) Display Screen: Displays current radio frequency
and information
6) Central Dial: Long press to turn on/standby
- Short press to select desired radio station
- Turn dial to browse through nearby radio
stations
7) Direct Pre-set buttons: 9 pre-sets in DAB mode
and 9 pre-sets in FM mode
8) Aerial
Rear panel layout
1) Aerial Port
2) Line Out: Left / Right
3) AC Select
4) Mains Port
5) Power switch

Remote Control
1) Power On / Standby
2) Volume Up / Down: (N/A for the model)
3) Info Button: Press to view information about
current radio station
4) Mode Button: Switch between DAB and FM
mode
5) Light Button: Change the colour of the outer ring
surrounding the central dial
6) 10+ Button: (N/A for this model)
7) Preset Buttons 1-9: Recall direct pre-sets in FM
and DAB mode
8) Mute Button: (N/A for this model)
9) Skip forward / backward to the next radio
frequency

10) Play / Pause Button: Play desired radio
frequency
11) Select Button: Select desired radio frequency
12) Scan Button: Automatically scan for nearby
radio frequencies
13) Shift Button: (N/A for this model)
14) Group Button: (N/A for this model)
Initial setup steps
1) Find the radio aerial and screw into the aerial
port on the rear of the Tuner.
2) Connect your Tuner to an amplifier using the
RCA line out port. Connect to the appropriate RCA
line in port on the amplifier.
3) Insert the appropriate mains cable into the rear of
the Tuner and turn on your power source. Make
sure your amplifier is also turned on and connected
to speakers.
4) Turn on the power switch at the rear of the
Tuner. The front panel should light up and display
the time. This means it is in standby mode.
5) Press and hold the dial on the front panel of
Tuner or the power on button on the remote control
to turn on the Tuner.
6) When turned on, you should hear the Tuner say
“Power on, DAB/FM mode”.

•DAB mode
1) If the Tuner is in FM mode, then press the mode
button on either the Tuner or the remote to
change to DAB mode.
2) The Tuner should automatically scan for radio
stations in DAB mode but if not then just press
the scan button on the front panel or the remote.
3) Then turn the central on the panel or press the
skip track buttons on the remote to browse and
select radio stations.
•FM mode
1) If the Tuner is in DAB mode then press the mode
button on either the Tuner or the remote to
change to FM mode.
2) In FM mode, the Tuner will pick up frequencies of
87.5MHz – 108MHz. Press the scan button and
Tuner will automatically search and lock onto a
frequency. For example, 97.7MHz – 99.8MHz for
Radio 1.
3) For a manual tune, you can turn the dial on the
front panel or press the skip track buttons on the
remote to scan the frequencies 0.05MHz at each
press or turn.

•Using the pre-set functions
1) To save a radio station as a pre-set in either DAB
or FM mode, press and hold one of the pre-set
buttons 1-9 for 2 seconds on the front panel or
the remote.
2) If performed correctly, the Tuner will display the
message “pre-set stored”. Then just press that
same number to recall that pre-set.
3) You can save up to 18 pre-sets. 9 in DAB mode
and 9 in FM mode.
•Additional Information
Info Button – Primary Menu
Pressing the info button (panel or remote) whilst a
radio station is being played will allow you to view
information about that radio station. This includes:
location, signal strength, genre, current time and
much more. Continue to press the info button to
scroll through these options.

Info Button – Secondary Menu
Pressing and holding the info button on DAB mode
will bring up a secondary menu, in which you can
browse between: Full Scan, Manual Tune, DRC,
Language and Main Menu.
There is also a similar secondary menu on FM
mode that includes: Scan Setting, Audio Setting,
Language and Main Menu.
Factory Reset
The Tuner can be restored to factory settings.
Simply press and hold the info button, then scroll
along to “Main Menu” using either the dial or the
skip track buttons on the remote and press select.
Then scroll along to “Factory Reset” using the same
controls and press select.

•Troubleshooting
Problem
Possible Cause/Solution
No power
- The power switch is
turned off. Turn on power
switch.
- The power chord is
disconnected. Readjust
power chord.
No sound
- Volume control is at lowest
level. Use remote to
increase volume or turn up
volume on your amplifier.
- The RCA lead is not
inserted properly. Readjust
the RCA cable.
- There is no signal being
picked up by the aerial.
Move the aerial position in
attempt to gain a better
connection.
Suddenly no sound during
operation
- The product may have
entered overheat protection
mode. Leave the Tuner for a
while to cool down.
- RCA lead disconnected.
Reconnect RCA lead.
- Aerial has suddenly moved
position or disconnected.
Readjust/reconnect aerial.
Bad sound/sound distorted
- Audio source problem.
Perform factory reset. See
above.
- Bad or no signal from the
aerial. Readjust aerial.

Tuner not picking up a
specific radio station
- - Tuner is not in range of the
frequency of that radio
station.
- Tuner has reached
maximum capacity of
stations that can be stored.
Perform factory reset and
scan again.
•Specifications
Product name
TI435 DAB+/FM Tuner
Frequency response
20Hz – 20kHz
Impedance
4 Ohms
Power supply
100 – 240V AC
Product dimensions mm
(WxHxD)
430 x 60 x 230
Gift box dimensions mm
(WxHxD)
557 x 121 x 334
Product weight
2.95 kg
